Planet WNAP-C3220 operation manual
Copyright
Copyright 2016 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes
the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software. Further, PLANET reserves the right to revise this publication and to
make changes from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reo
rient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may cause undesired
operation.
I
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity
to the antenna shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication
terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive
repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and
Satellite Earth Station Equipment) as of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it.
However, special attention must be paid to the dangers of electric shock and static electricity when
working with electrical equipment. All guidelines of this and of the computer manufacture must
therefore be allowed at all times to ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU
directive 1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reasons/remarks
Bulgaria None
Outdoor use; limited to 10
France
Italy None
Luxembourg None
Norway Implemented
Russian
Federation
mW e.i.r.p. within the band
2454-2483.5 MHz
None Only for indoor applications
General authorization required for outdoor use and
public service
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
If used outside of own premises, general authorization is
required
General authorization required for network and service
supply (not for spectrum)
This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Note: Please don’t use the product outdoors in France.
WEEE regulation
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
I
Revision
User Manual of PLANET 300Mbps 802.11n Ceiling-mount Wireless Access Point
Model: WNAP-C3220A
Rev: 1.0 (January, 2016)
Part No. EM-WNAP-C3220A_v1.0 (2080-E11090-000)
II
CONTENTS
Chapter 1.Product Introduction...........................................................................................................1
1.1 Package Contents ...............................................................................................................1
1.2 Product Description............................................................................................................ 2
1.3 Product Features................................................................................................................. 6
1.4 Product Specifications ....................................................................................................... 7
Chapter 2.Hardware Installation ........................................................................................................ 10
2.1 Product Outlook ................................................................................................................10
2.1.1 Panel Layout........................................................................................................... 10
2.1.2 Hardware Description .............................................................................................11
Chapter 3.Connecting to the AP........................................................................................................ 12
3.1 System Requirements ......................................................................................................12
3.2 Installing the AP ................................................................................................................12
3.2.1 Installing the AP – WNAP-C3220A......................................................................... 12
Chapter 4.Quick Installation Guide ...................................................................................................14
4.1 Manual Network Setup -- TCP/IP Configuration............................................................. 14
4.1.1 Configuring the IP Address Manually ..................................................................... 14
4.2 Starting Setup in the Web UI............................................................................................18
Chapter 5.Configuring the AP............................................................................................................ 19
5.1 Operation Mode................................................................................................................. 19
5.2 Setup Wizard...................................................................................................................... 21
5.3 TCP/IP Settings..................................................................................................................26
5.3.1 LAN Settings........................................................................................................... 26
5.4 WLAN..................................................................................................................................28
5.4.1 Basic Settings .........................................................................................................28
5.4.2 Advanced Settings.................................................................................................. 45
5.4.3 RF Output Power ....................................................................................................47
5.4.4 Security ...................................................................................................................48
5.4.5 Access Control........................................................................................................ 50
5.4.6 WDS........................................................................................................................ 52
5.4.7 Site Survey .............................................................................................................55
5.4.8 WPS........................................................................................................................56
5.4.9 Schedule .................................................................................................................60
5.5 Management ......................................................................................................................61
5.5.1 Status......................................................................................................................61
5.5.2 Statistics.................................................................................................................. 63
5.5.3 SNMP...................................................................................................................... 64
III
5.5.4 NTP Settings...........................................................................................................65
5.5.5 Schedule Reboot ....................................................................................................67
5.5.6 LOG ........................................................................................................................69
5.5.7 Upgrade Firmware ..................................................................................................70
5.5.8 Reload Settings ......................................................................................................70
5.5.9 Password ................................................................................................................72
5.5.10 LED Control ............................................................................................................73
5.5.11 Logout..................................................................................................................... 73
5.5.12 Reboot .................................................................................................................... 74
Chapter 6.Quick Connection to a Wireless Network....................................................................... 75
6.1 Windows XP (Wireless Zero Configuration)................................................................... 75
6.2 Windows 7 (WLAN AutoConfig).......................................................................................77
6.3 Mac OS X 10.x....................................................................................................................80
6.4 iPhone/iPod Touch/iPad ...................................................................................................84
Appendix A: Planet Smart Discovery Utility.....................................................................................87
Appendix B: FAQs...............................................................................................................................88
Q1: How to set up the WDS Repeater Connection..................................................................88
Q2: How to set up the Universal Repeater Connection.......................................................... 96
Appendix C: Troubleshooting.......................................................................................................... 103
Appendix D: Glossary.......................................................................................................................105
IV
FIGURE
FIGURE 2-1 WNAP-C3220A POWER LED ...............................................................................................10
FIGURE 2-2 WNAP-C3220A REAR PANEL ...............................................................................................10
FIGURE 3-1 WNAP-C3220A INSTALLATION DIAGRAM 1 ............................................................................12
FIGURE 3-2 WNAP-C3220A INSTALLATION DIAGRAM 2 ............................................................................13
FIGURE 3-3 WNAP-C3220A INSTALLATION DIAGRAM 3 ............................................................................13
FIGURE 4-1 TCP/IP SETTING................................................................................................................... 15
FIGURE 4-2 WINDOWS STAR T MENU ........................................................................................................16
FIGURE 4-3 SUCCESSFUL RESULT OF PING COMMAND ..............................................................................16
FIGURE 4-4 FAILED RESULT OF PING COMMAND .......................................................................................17
FIGURE 4-5 LOGIN BY DEFAULT IP ADDRESS............................................................................................. 18
FIGURE 4-6 LOGIN WINDOW.....................................................................................................................18
FIGURE 5-1 MAIN MENU ..........................................................................................................................19
FIGURE 5-2 OPERATION MODE.................................................................................................................20
FIGURE 5-3 SETUP WIZARD .....................................................................................................................21
FIGURE 5-4 LAN INTERFACE SETUP TOPOLOGY........................................................................................21
FIGURE 5-5 WIZARD – LAN INTERFACE SETUP ......................................................................................... 21
FIGURE 5-6 TIME ZONE SETUP TOPOLOGY ...............................................................................................22
FIGURE 5-7 WIZARD – TIME ZONE SETUP.................................................................................................22
FIGURE 5-8 WIZARD – WIRELESS BASIC SETTINGS ...................................................................................23
FIGURE 5-9 WIZARD – WIRELESS SECURITY SETUP .................................................................................. 24
FIGURE 5-10 WIRELESS SECURITY SETUP – WEP SETTING......................................................................24
FIGURE 5-11 WIRELESS SECURITY SETUP – WPA SETTING.......................................................................24
FIGURE 5-12 LAN SETTING .....................................................................................................................26
FIGURE 5-13 WIRELESS MAIN MENU........................................................................................................28
FIGURE 5-14 WIRELESS BASIC SETTINGS – AP ........................................................................................29
FIGURE 5-15 WIRELESS BASIC SETTINGS – MULTIPLE APS .......................................................................31
FIGURE 5-16 MULTIPLE-SSIDS................................................................................................................32
FIGURE 5-17 UNIVERSAL REPEATER-1 .....................................................................................................33
FIGURE 5-18 UNIVERSAL REPEATER-2 .....................................................................................................33
FIGURE 5-19 UNIVERSAL REPEATER-3 .....................................................................................................34
FIGURE 5-20 UNIVERSAL REPEATER-4 .....................................................................................................34
FIGURE 5-21 UNIVERSAL REPEATER-5 .....................................................................................................34
FIGURE 5-22 WIRELESS BASIC SETTINGS – CLIENT ..................................................................................35
FIGURE 5-23 CLIENT – SURVEY ...............................................................................................................37
FIGURE 5-24 CLIENT – AP LIST................................................................................................................38
FIGURE 5-25 CLIENT – SECURITY.............................................................................................................39
FIGURE 5-26 CLIENT – STATU S ................................................................................................................ 39
FIGURE 5-27 WIRELESS BASIC SETTINGS – WDS..................................................................................... 41
FIGURE 5-28 WIRELESS BASIC SETTINGS – REPEATER ............................................................................. 43
FIGURE 5-29 WIRELESS ADVANCED SETTINGS.......................................................................................... 45
FIGURE 5-30 RF OUTPUT POWER............................................................................................................47
FIGURE 5-31 WIRELESS SECURITY SETTINGS...........................................................................................48
V
FIGURE 5-32 WIRELESS ACCESS CONTROL..............................................................................................50
FIGURE 5-33 WIRELESS ACCESS CONTROL – DENY.................................................................................. 51
FIGURE 5-34 WDS MODE........................................................................................................................53
FIGURE 5-35 WDS SETTINGS .................................................................................................................. 53
FIGURE 5-36 WDS – SET SECURITY ........................................................................................................ 54
FIGURE 5-37 SITE SURVEY ......................................................................................................................55
FIGURE 5-38 WPS..................................................................................................................................56
FIGURE 5-39 WPS-PBC -1 .....................................................................................................................58
FIGURE 5-40 WPS-PBC -2 .....................................................................................................................58
FIGURE 5-41 WPS-PIN -1 .......................................................................................................................59
FIGURE 5-42 WPS-PIN -2 .......................................................................................................................59
FIGURE 5-43 WPS-PIN -3 .......................................................................................................................59
FIGURE 5-44 SCHEDULE .......................................................................................................................... 60
FIGURE 5-45 MANAGEMENT – MAIN MENU ...............................................................................................61
FIGURE 5-46 STATU S...............................................................................................................................62
FIGURE 5-47 STATI STICS ......................................................................................................................... 63
FIGURE 5-48 SNMP................................................................................................................................64
FIGURE 5-49 TIME ZONE SETTINGS..........................................................................................................65
FIGURE 5-50 SCHEDULE REBOOT ............................................................................................................67
FIGURE 5-51 SCHEDULE REBOOT - EXAMPLE ...........................................................................................68
FIGURE 5-52 SYSTEM LOG ......................................................................................................................69
FIGURE 5-53 UPGRADING FIRMWARE .......................................................................................................70
FIGURE 5-54 SAVE /RELOAD SETTINGS.....................................................................................................71
FIGURE 5-55 PASSWORD SETUP ..............................................................................................................72
FIGURE 5-56 LED CONTROL.................................................................................................................... 73
FIGURE 5-57 LOGOUT..............................................................................................................................73
FIGURE 5-58 REBOOT ............................................................................................................................. 74
FIGURE 6-1 SYSTEM TRAY – WIRELESS NETWORK ICON ...........................................................................75
FIGURE 6-2 CHOOSING A WIRELESS NETWORK.........................................................................................75
FIGURE 6-3 ENTERING THE NETWORK KEY ............................................................................................... 76
FIGURE 6-4 CHOOSING A WIRELESS NETWORK -- CONNECTED .................................................................. 76
FIGURE 6-5 NETWORK ICON.....................................................................................................................77
FIGURE 6-6 WLAN AUTOCONFIG.............................................................................................................77
FIGURE 6-7 TYPING THE NETWORK KEY ...................................................................................................78
FIGURE 6-8 CONNECTING TO A NETWORK ................................................................................................. 78
FIGURE 6-9 CONNECTED TO A NETWORK ..................................................................................................79
FIGURE 6-10 MAC OS – NETWORK ICON..................................................................................................80
FIGURE 6-11 HIGHLIGHTING AND SELECTING THE WIRELESS NETWORK .....................................................80
FIGURE 6-12 ENTER THE PASSWORD .......................................................................................................81
FIGURE 6-13 CONNECTED TO THE NETWORK ............................................................................................ 81
FIGURE 6-14 SYSTEM PREFERENCES....................................................................................................... 82
FIGURE 6-15 SYSTEM PREFERENCES -- NETWORK ...................................................................................82
FIGURE 6-16 SELECTING THE WIRELESS NETWORK ..................................................................................83
FIGURE 6-17 IPHONE – SETTINGS ICON.................................................................................................... 84
FIGURE 6-18 WI-FI SETTING....................................................................................................................84
VI VII
FIGURE 6-19 WI-FI SETTING – NOT CONNECTED ...................................................................................... 85
FIGURE 6-20 TURNING ON WI-FI ..............................................................................................................85
FIGURE 6-21 IPHONE -- ENTERING THE PASSWORD................................................................................... 86
FIGURE 6-22 IPHONE -- CONNECTED TO THE NETWORK ............................................................................86
User Manual of WNAP-C3220A
Chapter 1. Product Introduction
1.1 Package Contents
Thank you for choosing PLANET WNAP-C3220A. Before installing the AP, please verify the contents inside the
package box.
Thank you for choosing PLANET WNAP-C3220A. Before installing the AP, please
verify the contents inside the package box.
WNAP-C3220A
Ethernet Cable
Quick Guide
Mounting Kit
x4 x4
Power Adapter
If there is any item missing or damaged, please contact the seller immediately.
-1-
User Manual of WNAP-C3220A
1.2 Product Description
PLANET WNAP-C3220A, a 300Mbps 802.11n Wireless Range Extender, offers multiple operation modes
and complies with 802.3af Power over Ethernet standard. Particularly, it supports AP Controller features that
can increase wireless coverage and can easily be centrally managed within a network. Sleek styling housing
and ceiling-mountable design makes the WNAP-C3220A blend unobtrusively into any ceiling or wall for various
environments. This unique product also creates a secure, cost-effective and highly scalable wireless LAN
infrastructure. It is ideal for enterprises, hotels, hospitals and home users to extend wireless network coverage.
Ease of Deployment with PLANET AP Controller
To simplify the wireless deployment, the WNAP-C3220A supports AP controller, which can be switched to the
“managed AP” mode and thus can be centrally managed by PLANET Wireless AP Controller. It will certainly
benefit the system integrators when the scale of the wireless network gets bigger. With visible LED lighting, the
administrator can quickly pinpoint the localization of each ceiling-mount AP. Furthermore, the user-friendly,
graphical configuration setup wizard and PLANET Smart Discovery tool can make the WNAP-C3220A
convenient to be managed and configured remotely in a small business wireless network.
-2-
User Manual of WNAP-C3220A
Comprehensive Wireless Operation Mode
The WNAP-C3220A supports multiple types of wireless connectivity such as AP (Multi-SSIDs), Client,
Repeater/Universal Repeater, WDS Point-to-Point (PtP) and WDS Point-to-Multipoint (PtMP), allowing
users to comprehensively experience various applications. It also helps users to easily build wireless network
and extend the wireless range of the existing wireless network.
niversal Wireless Range Extender
U
To extend the coverage and eliminate the
dead spot of wireless network in every place, the WNAP-C3220A
supports not only WDS bridging, but also Universal Repeater mode which can solve the incompatibility between
brands and provides a high-speed, wide coverage. The built-in intelligent antennas offer 360 degrees of
coverage with excellent performance.
-3-
User Manual of WNAP-C3220A
Advanced, Secure Wireless Connection
In aspect of security, besides 64-/128-bit W
WPA-PSK/WPA2-PSK and 802.1x authority to secure and protect your
settings for home and SOHO network, the WNAP-C3220A supports Wi-Fi Protected Setup (WPS). By just
pressing the WPS button or keying in the PIN code, the secure connection between the WNAP-C3220A and
wireless clients will be built immediately even the user has never experienced to create a secure wireless
network. In addition, the WNAP-C3220A provides the wireless MAC filtering and SSID broadcast control to
consolidate the wireless network security and prevent unauthorized wireless connection.
legant, Unique & Ceiling-mountable Design
E
Featuring an attractive flying saucer appearance an
firmly absorbed on the ceiling or the wall, which makes the client-side installation easy and convenient. Its
streamlined body without protruding antennas gives effects of embellishment on the surroundings and also
provides greater wireless coverage.
EP encryption, the WNAP-C3220A integrates WPA/WPA2,
wireless LAN. To simplify security
d ceiling-mountable design, the WNAP-C3220A can be
-4-
User Manual of WNAP-C3220A
Flexible Deployment with PoE Feature
Compliant with IEEE 802.3af Power over Ethernet standard, the WNAP-C3220A can be powered and networked
by a single UTP cable. It thus reduces the needs of extra cables and dedicated electrical outlets on the wall,
ceiling or any other place which is difficult to reach. The wireless AP deployment becomes more flexible and
worry-free from the power outlet locations.
-5-
1.3 Product Features
Wireless Standard Compliance
Compliant with IEEE 802.11n wireless technology with data rate of up to 300Mbps
Backward compatible with 802.11b/g standard
Supports IEEE 802.3af standard-based PoE or local AC power
Secure Network Connection
Advanced security: 64-/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK (TKIP/AES
encryption), 802.1x
Supports wireless MAC address filtering control to limit the connected wireless clients
Comprehensive Wireless Advanced Features
Multiple operation modes including AP (Multi-SSIDs), Client, Repeater/Universal Repeater, WDS
Point-to-Point (PtP) and WDS Point-to-Multipoint (PtMP)
Up to 5 multiple-SSIDs to allow users to access different networks through a single AP
User Manual of WNAP-C3220A
Supports WMM (Wi-Fi Multimedia) and wireless QoS to enhance the efficiency of multimedia
application
Supports IAPP (Inter Access Point Protocol) wireless roaming to enable clients to roam across
multiple APs
Provides 5-level Transmitting Power Control to adapt various environments
Wireless schedule allows administrators to enforce time-based internet access
Self-healing (Schedule Reboot) mechanism for reliable connection
Easy Deployment & Centralized Management
Supports AP controller to enable administrator to configure and monitor multiple APs
simultaneously
Flexible deployment with standard 802.3af PoE/PD supported
Sleek, ceiling-mountable design and position LED help to locate multiple APs with ease
Step-by-step configuration with intelligent setup wizard and graphical Web-based UI
Supports SNMP-based management interface
System status monitoring including associated client list and system log
-6-
1.4 Product Specifications
User Manual of WNAP-C3220A
Product
WNAP-C3220A
300Mbps 802.11n Wireless Ceiling-mount Access Point
Hardware Specifications
PoE 802.3af PoE PD, PD Class 3
Interface
Wireless IEEE 802.11b/g/n
LAN: 1x 10/100BASE-TX, auto-MDI/MDIX, 802.3af PoE compliant
Antenna Built-in 2T2R, 3dbi antenna
LED Power/position LED (Allowing LED to turn off via software control)
Button Reset button (Press over 5 seconds to reset the device to factory default)
Material Plastic
Dimensions (Φ x H) 144 x 33 mm
Weight 128 ±5g
Power Requirements
802.3af/at PoE, 48-56V DC input, 0.35A (max.)
5V DC input, 1A (max.)
Power Consumption ≦ 4.5W (max.)
Mounting Ceiling mount, wall mount
Wireless Interface Specifications
Standard IEEE 802.11b/g/n 2.4GHz
Antenna Structure 802.11n: 2T2R MIMO
Transmission/emission type: DSSS/OFDM
Modulation
Data modulation type: OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK,
DQPSK, CCK
Frequency Range
Operating Channels
America -- FCC: 2.412~2.462GHz
Europe -- ETSI: 2.412~2.472GHz
America -- FCC: 1~11
Europe -- ETSI: 1~13
Channel Width 802.11n: 20/40MHz
802.11n (HT40): 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps (dynamic)
Data Transmission
Rates
802.11n (HT20): 130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (dynamic)
802.11g: 54/48/36/24/18/12/9/6Mbps (dynamic)
802.11b: 11/5.5/2/1Mbps (dynamic)
Transmission
Distance
Max. RF Power
Receiver Sensitivity
802.11n: up to 70m
802.11g: up to 30m
The estimated transmission distance is based on the theory.
The actual distance will vary in different environments.
802.11n: 17 ± 2dBm
802.11g: 17 ± 2dBm
802.11b: 18 ± 2dBm
IEEE 802.11b: -92dBm @ 1Mbps; -85dBm @ 11Mbps, PER < 8%
IEEE 802.11g: -88dBm @ 6Mbps; -73dBm @ 54Mbps, PER <10%
IEEE 802.11n: -90dBm @ MCS8; -70dBm @ MCS15, PER <10%
-7-
User Manual of WNAP-C3220A
Data Rate
TX Power
Software Features
Operation Mode
Wireless Mode
Wireless Encryption
Wireless Security
IEEE 802.11b: 1/2/5.5/11Mbps
IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps
IEEE 802.11n: 300Mbps in 40MHz mode/150Mbps in 20MHz mode
Provides 5-level Tx Power Control (100%, 70%, 50%, 35%, 15%)
Standalone AP
Managed AP
AP (Multiple-SSIDs)
Client
Repeater (WDS+AP)
Universal Repeater (AP+Client)
WDS PtP Bridge
WDS PtMP Bridge
WEP (64-/128-bit) encryption security
WPA/WPA2 (TKIP/AES)
WPA-PSK/WPA2-PSK (TKIP/AES)
802.1x RADIUS authentication
Wireless MAC address filtering (up to 20 entries)
Supports WPS (Wi-Fi Protected Setup)
SSID broadcast and hide
Supports WMM (Wi-Fi Multimedia) for better data transmission of video or
on-line demand
Supports wireless schedule
Wireless Advanced
Max. Clients
LAN
System Management
Max. WDS Peers
IEEE Standards
Multiple SSIDs: up to 5
Wireless Isolation: Enables it to isolate each connected wireless client of a
BSSID from communicating with each other
IAPP (Inter Access Point Protocol): 802.11f wireless roaming
Provides wireless statistics, max. associated station number
Wired: 253
2.4GHz Wireless: 32
Built-in DHCP server supporting static IP address distribution
Supports static IP and dynamic IP
Supports UPnP
Supports 802.1d Spanning Tree
Web-based (HTTP) management interface
Supports SNTP synchronization
Easy firmware upgrade via HTTP/TFTP (through AP controller)
Easily locate deployed APs through the LED control
Supports scheduled reboot
Supports Smart Discovery Utility
Supports WAPC series of AP controllers for central management
4
IEEE 802.11n (2T2R, up to 300Mbps)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
-8-
IEEE 802.3x flow control
Other Protocols and
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, SNTP
Standards
Environment & Certification
Temperature
Operating: -10 ~ 50 degrees C
Storage: -40 ~ 70 degrees C
User Manual of WNAP-C3220A
Humidity
Regulatory
Compliance
Operating: 10 ~ 90% (non-condensing)
Storage: 5 ~ 90% (non-condensing)
CE, RoHS, WEEE
-9-
Chapter 2. Hardware Installation
2.1 Product Outlook
Dimensions: 144 x 33 mm (Φ x H)
2.1.1 Panel Layout
The front and rear panels provide a simple interface monitoring the AP.
Front Panel
User Manual of WNAP-C3220A
Rear Panel
Figure 2-1 WNAP-C3220A Power LED
Figure 2-2 WNAP-C3220A Rear Panel
-10-
2.1.2 Hardware Description
LED Definition
LED COLOR STATUS FUNCTION
Green
On
User Manual of WNAP-C3220A
Device power on
PWR
Green
Green
Flash
Off
Detect and identify the LED (controlled by S/W)
Device power off (controlled by S/W)
Button definition
Object Description
Press the Reset button for over 5 seconds and then release it to restore system
Reset
to the factory default settings.
H/W Interface definition
Object Description
PoE Port
(802.3af/at PoE)
Power Connector
10/100bps RJ45 port, auto MDI/ MDI-X
Connect PoE port to the IEEE 802.3af/at PoE switch to power on the device.
Connect this port to the 5V DC power adapter to power on the device.
-11-
User Manual of WNAP-C3220A
Chapter 3. Connecting to the AP
3.1 System Requirements
Broadband Internet Access Service (Cable/xDSL/Ethernet connection)
One IEEE 802.3af/at PoE switch (supply power to the WNAP-C3220A)
PCs with a working Ethernet adapter and an Ethernet cable with RJ45 connectors
PCs running Windows XP, Windows Vista, Win 7, Win8, Win10, MAC OS 9 or later, Linux, UNIX or
other platforms compatible with TCP/IP protocols
1. The AP in the following instructions refers to PLANET WNAP-C3220A.
2. It is recommended to use Internet Explore 8.0 or above to access the AP.
3.2 Installing the AP
Before installing the AP, make sure your PoE switch is connected to the Internet through the broadband service
successfully at this moment. If there is any problem, please contact your local ISP. After that, please install the
AP according to the following steps. Don't forget to pull out the power plug and keep your hands dry.
3.2.1 Installing the AP – WNAP-C3220A
Step 1. Attach the bracket to the wall or ceiling, and mark each point in the bracket for the screws. Remove the
bracket to drill the points and insert the plastic wall-mounts. Use screws to lock the bracket by a screw
driver.
Figure 3-1 WNAP-C3220A Installation
Diagram 1
1. Plug the RJ-45 Ethernet cable into the WNAP-C3220A.
2. Plug the power adapter into the WNAP-C3220A.
-12-
User Manual of WNAP-C3220A
Step 2. Plug the RJ45 Ethernet cable and power adapter in the WNAP-C3220A. If the WNAP-C3220A is
connected to an 802.3at PoE switch, you don’t have to plug in the power adapter.
Figure 3-2 WNAP-C3220A Installation Diagram 2
Step 3. Attach the WNAP-C3220A to the mounting bracket to finish the installation.
Figure 3-3 WNAP-C3220A Installation Diagram 3
1.) ONLY use the power adapter supplied with the WNAP-C3220A. Otherwise,
the product may be damaged.
2.) For the power supply of the WNAP-C3220A, you could use either IEEE
802.3af/at PSE device or 5VDC adapter. Please do not use the 5V adapter
and PSE device at the same time or else it may damage the
WNAP-C3220A itself.
-13-
User Manual of WNAP-C3220A
Chapter 4. Quick Installation Guide
This chapter will show you how to configure the basic functions of your AP within minutes.
A computer with wired Ethernet connection to the Wireless AP is required for the first-time
configuration.
4.1 Manual Network Setup -- TCP/IP Configuration
The default IP address of the WNAP-C3220A is 192.168.1.253. And the default Subnet Mask is 255.255.255.0.
These values can be changed as you want. In this guide, we use all the default values for description.
Connect the WNAP-C3220A with your PC by an Ethernet cable plugging in LAN port on one side and in LAN
port of PC on the other side. Please power on the WNAP-C3220A by PoE switch through the PoE port.
In the following sections, we’ll introduce how to install and configure the TCP/IP correctly in Windows 7. And the
procedures in other operating systems are similar. First, make sure your Ethernet Adapter is working, and refer
to the Ethernet adapter manual if needed.
4.1.1 Configuring the IP Address Manually
Summary:
Set up the TCP/IP Protocol for your PC.
Configure the network parameters. The IP address is 192.168.1.xxx (If the default IP address of the
WNAP-C3220A is 192.168.1.253, and the DSL router is 192.168.1.254, the "xxx" can be configured to
any number from 1 to 252.) and subnet mask is 255.255.255.0.
1 Select Use the following IP address, and then configure the IP address of the PC.
2 For example, as the default IP address of the WNAP-C3220A is 192.168.1.253 and the DSL router is
192.168.1.254, you may choose from 192.168.1.1 to 192.168.1.252.
-14-
User Manual of WNAP-C3220A
Figure 4-1 TCP/IP Setting
Now click OK to save your settings.
Now, you can run the ping command in the command prompt to verify the network connection between your
PC and the AP. The following example is in Windows 7 OS. Please follow the steps below:
1. Click on Start > Run.
2. Type “cmd” in the Search box.
-15-
Figure 4-2 Windows Start Menu
User Manual of WNAP-C3220A
3. Open a command prompt, type ping 192.168.1.253 and then press Enter.
If the result displayed is similar to Figure 4-3, it means the connection between your PC and the AP
has been established well.
Figure 4-3 Successful Result of Ping Command
If the result displayed is similar to Figure 4-4, it means the connection between your PC and the AP
has failed.
-16-
User Manual of WNAP-C3220A
Figure 4-4 Failed Result of Ping Command
If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some
firewall software programs may block a DHCP request on newly installed adapters.
-17-
User Manual of WNAP-C3220A
4.2 Starting Setup in the Web UI
It is easy to configure and manage the AP with the web browser.
Step 1. To access the configuration utility, open a web-browser and enter the default IP address
http://192.168.1.253 in the web address field of the browser.
Figure 4-5 Login by Default IP Address
After a moment, a login window will appear. Enter admin for the User Name and Password, both in lower case
letters. Then click OK or press the Enter key.
Default IP Address: 192.168.1.253
Default User Name: admin
Default Password: admin
If the above screen does not pop up, it may mean that your web browser has been set to a
proxy. Go to Tools menu> Internet Options> Connections> LAN Settings on the screen that
appears, uncheck Using Proxy and click OK to finish it.
Figure 4-6 Login Window
-18-
User Manual of WNAP-C3220A
Chapter 5. Configuring the AP
This chapter delivers a detailed presentation of AP’s functionalities and features 7 main items below, allowing
you to manage the AP with ease.
Standalone AP Mode Managed AP Mode
Figure 5-1 Main Menu
During operation, if you are not clear about a certain feature, you can refer to the “Help” section at the right side
of the screen to read all the related helpful information.
5.1 Operation Mode
The Operation Mode section guides you to configuring the WNAP-C3220A to Standalone AP or Managed AP.
When switching the operation mode to Managed AP, the administrator will be able to manage the AP by
PLANET Wireless AP Controller. To configure the managed AP by PLANET Wireless AP Controller, please refer
to the WAPC-1232HP/WAPC-2864HP AP Management user’s manual.
-19-
Figure 5-2 Operation Mode
User Manual of WNAP-C3220A
The page includes the following fields:
Object Description
Standalone AP
Managed AP
AP Controller IP Address
Apply Change
Reset
In Standalone AP, the AP acts as an individual AP in the network, and you
manage it by using the Administrator Web User Interface (UI), or SNMP.
In Managed AP, the AP is part of the PLANET Wireless AP controller System, and
you manage it by using the WAPC Wireless AP controller.
Check this option and enter the IP address of the AP controller that user
specifies. The default “0.0.0.0” means any AP controller existed in the local
network can control this AP.
Click “Apply Change” to save and apply the settings.
Click “Reset” to erase all settings.
After you configure the settings on the AP Operation Mode page, you must click Apply
to apply the changes and to save the settings. Changing some settings might cause the
AP to stop and restart system processes. If this happens, wireless clients will
temporarily lose connectivity. We recommend that you change AP settings when WLAN
traffic is low.
Please back up the configuration settings before switching from the Standalone AP
mode to the Managed AP mode.
All the configurations will be erased and at the same time, the system will return to the
factory default settings once it is reverted to the Standalone AP mode.
-20-
User Manual of WNAP-C3220A
5.2 Setup Wizard
The Setup Wizard will guide the user to configuring the WNAP-C3220A easily and quickly. Select Setup Wizard
on the left side of the screen and by clicking on Next on the Setup Wizard screen shown below, you will then
name your WNAP-C3220A and set up its security.
Figure 5-3 Setup Wizard
Step 1: LAN Interface Setup
Figure 5-4 LAN Interface Setup Topology
Figure 5-5 Wizard – LAN Interface Setup
-21-
