TABLE OF CONTENTS
Chapter 1 Introduction .......................................3
1.1 Features.........................................................3
1.2 Package Contents..........................................4
1.3 Technical Specifications.................................4
Chapter 2 Installation ......................................... 5
2.1 System Requirements Specifications............. 5
2.2 Product Details...............................................5
2.3 Hardware Installation.....................................7
Chapter 3 Operation ........................................... 9
3.1 Select PC through push buttons .................. 10
3.2 Select PC through Hot key...........................10
Chapter 4 Troubleshooting ..............................12
2
Chapter 1
Introduction
Thank you for purchasing PLANET KVM switch. PLANET
KVM switch can save your MONEY, TIME, SPACE,
EQUIPMENT and POWER.
Control multiple PCs from one keyboard, mouse and VGA
monitor. PLANET KVM switch is loaded with features such
as hot-key, front panel push button and auto scan control. It
has complete keyboard and mouse emulation for
simultaneous PCs boot-up process.
1.1 Features
2/4-port KVM switch is compact size design and portable
Support Microsoft Intellimouse, Logitech Net Mouse, etc...
Support DOS, Win3.x, Win95/98/98SE/2000/ME/XP,
WinNT, Netware, Unix, Linux
Support iMAC, Power MAC and Sun Microsystems with
USB port (Need to work with USB-PS2 adapter)
Hot Plug - Add or remove connected PCs for maintenance
without powering down the KVM switch or PCs
Very High Video Quality - Up To 1920X1440, Bandwidth:
200MHz
No Software Required - easy PC selection via Push
Buttons, Hot Keys
Auto Scan Mode for monitoring PCs
Keyboard status restored when switching PCs
LED Display for easy status monitoring
Buzzer sound for switching port confirmation
3
1.2 Package Contents
KVM-200 KVM-400
♦ 2-port KVM switch
♦ User’s manual
♦ 4-port KVM switch
♦ User’s manual
1.3 Technical Specifications
Model KVM - 200 KVM - 400
PC Port 2 4
Console Port 1 1
MAX PC
Connections
LED 2 8
PC Port
Connector
(All Female Type)
Console port
connector
(All Female Type)
PC selection Hot Key / Button
Scan Intervals 8sec.
Keyboard
Emulation
Mouse Emulation
(Console port to
PC port)
VGA Resolution Up to 1920X1440
Bandwidth 200MHz
Operating
Temperature
Storage
Temperature
Humidity 0 ~ 80% RH, non-condensing
Weight (g) 440 720
Dimension (mm) 125X72X45 200X90x45
2 4
PS/2 Keyboard mini-Din 6 pin
PS/2 Mouse Mini-Din 6 pin
VGA HDDB 15pin
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
PS/2
PS/2
0 ~ 40 Degree C (32 ~ 104 Degree F)
-20 ~ 60 Degree C (-4 ~ 140 Degree F)
4
Chapter 2
Installation
2.1 System Requirements Specifications
Model KVM-200 KVM-400
Console
side
Computer
side
Optional
VGA Monitor 1 1
PS/2 Keyboard 1 1
PS/2 Mouse 1 1
HDB-15 pin male to
male VGA cables
PS/2 cable male to
male for Keyboard
PS/2 cable male to
male for Mouse
USB-PS2 adapter is required if connect to
computer with only USB keyboard/mouse
interface.
2.2 Product Details
Front panel & Rear panel of KVM-200:
Computer power
on/off status
2-Port KVM Switch
1
2 4
2 4
2 4
2
Power
Select
KVM-200
Connect to mouse PC selection
Connect to keyboard
5
V
Monitor
DC 9
Option
Optional power adapter
Connect to computer’s VGA port
2 1
Connector to computer’s PS/2
Front panel & Rear panel of KVM-400:
Computer is selected
4-Port KVM Switch
1234
DC 9V
Reset
Option
3
6
keyboard/mouse port
On Line
Power
Select
2 1 4
KVM-400
Reset the KVM switch
2.3 Hardware Installation
Before installation, please make sure all of peripherals and
computers have been turned off.
Step 1 Connecting Monitor to the KVM switch
Connect a VGA cable (15-pin HDDB Male / Male) with the
Male side to both of the Monitor and the rear panel of the KVM
switch unit.
Step 2 Connecting Keyboard & Mouse to the
KVM switch
Connect the keyboard and mouse to the KVM switch. If you
have an AT type keyboard, you will need an AT to PS/2
adapter.
Note: Only use PS/2’s keyboard and mouse.
Step 3 Connecting VGA port of PC(s) to the KVM
switch
Now the PC connections will be made with the monitor (VGA)
connections first. Connect a VGA cable (15-pin HDDB Male /
Male) with the Male side to both of the PC’s VGA output and
the rear panel of the KVM switch unit to the connector labeled
VGA. Repeat this for all PCs.
Step 4 Connecting keyboard and mouse port of
PC(s) to the KVM switch
Connect keyboard and mouse port of your PC to the rear panel
of the KVM switch.
Step 5 Double-check all of the connections
Please check step1 ~ step4 again and then power on the
computers.
7
Note: Please do not switch the PC port (i.e. Do not press
the push button of KVM switch or run hot key) during the
computers are under boot-up process.
8
This page intentionally left blank!
9
Chapter 3
Operation
3.1 Select PC through push buttons
KVM-200 / KVM-400 has separate push buttons on the
panel. Press each button to select respective PC port.
KVM-400 has also On Line LED for each PCs. When you
select one of four PCs and it is powered on, the selected
port On Line LED is lit. When you select one of four PCs
and it is shut down or disconnected from a PC, the selected
port ON Line LED flashed.
3.2 Select PC through Hot key
You can also conveniently command PLANET KVM to
switch ports through simple key sequences. To send
commands to PLANET KVM, The SCROLL LOCK key must
be pressed twice within 2 seconds. You will hear a beep for
confirmation.
Below are the different commands:
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
S
10
Previous Channel
Next Channel
Auto Scan
Scroll
Lock
Scroll
Lock
Scroll
Lock
1(or
2,3,4)
Scroll
Lock
B
Select PC port directly
Beeper On (Factory
default off)
Note: To get out of Auto Scan Mode, Press any key or
SPACE bar.
11
Chapter 4
Troubleshooting
Ensure that all cables are well seated. Label all of cables
with the number for each respective computer to avoid
confusion.
1. KVM switch draws the power from keyboard port of
computers. If the computer like laptop computer,
notebook computer or the other computer cannot
support enough power to KVM switch, please add a DC
9V, 500mA to the power jack. The power jack polarity is
center positive.
2. Don't press any keys on the keyboard while the
selected computer is booting up. Otherwise, it might
cause the keyboard error or keyboard is not detected at
PC side.
3. The computer boot up fine, but keyboard doesn't work
Make sure the keyboard works when directly
plugged into the computer.
Try a different keyboard, but use only 101, 102 or
104-key keyboard.
4. The Mouse is not detected during PC boot up.
Make sure the mouse works when directly plugged
into the computer.
Make sure the mouse is a true PS/2 mouse. A
combo mouse will work just as long as it is set for
PS/2 mode with the correct adapter.
Try a different mouse.
5. Avoiding moving the mouse or pressing the mouse
buttons when switching the port.
12
6. Notebook computer:
Before powering on notebook computer , we recommend
the user to connect the notebook to computer port ( not
link to console directly ) first and then boot it up. If
notebook computer has been boot up already and then
the user connect it to KVM switch, please use Hot Key
command to link both of them together.
Scroll
Lock
Scroll
Lock
P
13
EM-KVM24V1
