Pitco Ppe14d-l Parts List

IMPORTANT FOR FUTURE REFERENCE

Please complete this information and retain this manual
for the life of the equipment:

Model #: ___________________________

Serial #: ___________________________

Date Purchased: ____________________

Exploded Parts Manual

PE14D: Electric Floor Model Pasta Cooker

Built after 11/2003

L22-282, rev. 0 (1/06)

WARNING
DO NOT store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.

WARNING
Improper installation, alteration, service or
maintenance can cause property damage, injury
or death. Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this appliance.

WARNING
Installation, maintenance and repairs should be
performed by a Pitco Authorized Service and
Parts (ASAP) company technician or other
qualified personnel. Installation, maintenance or
repairs by an unauthorized and unqualified
personnel will void the warranty.

WARNING
Installation and all connections must be made
according to national and local regulations and
codes in force.

WARNING
During the warranty period if a customer elects
to use a non-original part or modifies an original
part purchased from Pitco and/or its Authorized
Service and Parts (ASAP) companies, this
warranty will be void. In addition, Pitco and its
affiliates will not be liable for any claims,
damages or expenses incurred by the customer
which arises directly or indirectly, in whole or in
part, due to the installation of any modified part
and/or received from an unauthorized service
center.

WARNING
This appliance, when installed, must be
electrically grounded in accordance with local
codes, or in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70, or the
Canadian Electrical Code, CSA C22.2, as
applicable.

WARNING
If the appliance is equipped with a power cord
and it is damaged, it must be replaced by a Pitco
Authorized Service and Parts (ASAP) company
technician, or a similarly qualified person in
order to avoid a hazard.

WARNING
The power supply must be disconnected before
servicing, maintaining or cleaning this appliance.

WARNING
The appliance is NOT jet stream approved. DO
NOT clean the appliance with a water jet.

WARNING
DO NOT attempt to move this appliance or
transfer hot liquids from one container to
another when the unit is at operating
temperature or filled with hot liquids. Serious
personal injury could result if skin comes in
contact with the hot surfaces or liquids.

WARNING
DO NOT sit or stand on this appliance. The
appliance’s front panel, tank, splash back, tank
cover, workshelf, drain board is not a step.
Serious injury could result from slipping, falling
or contact with hot liquids.

WARNING
NEVER use the appliance as a step for cleaning
or accessing the ventilation hood. Serious injury
could result from slips, trips or from contacting
hot liquids.

WARNING
Completely shut the appliance down when liquid
is being drained from the appliance. This will
prevent the appliance from heating up during the
draining and filling process. Serious injury can
occur.

WARNING
DO NOT operate appliance unless all panels and
access covers are attached correctly.

WARNING
Adequate means must be provided to LIMIT the
movement or this appliance without depending
on the gas or electrical cord connection. Single
appliances equipped with legs must be stabilized
by installing anchor straps. All appliances
equipped with casters must be stabilized by
installing restraining chains.

WARNING
DO NOT alter or remove structural material on
the appliance to accommodate placement under
a ventilation hood.

ii

WARNING
It is recommended that this appliance be
inspected by a qualified service technician for
proper performance and operation on a yearly
basis.

WARNING
A country approved all pole circuit breaker with
a minimum open contact gap of 3mm must be
used for proper installation. (CE countries)

TABLE OF CONTENTS PE14D Electric Floor Model Pasta Cooker

PE14D EXPLODED .....................................................................................2

PE14D Exploded Parts List.................................................................................................................2

PE14D Exploded Drawing ................................................................................................................... 3

A) TANK................................................................................................. 4

Tank Drawing A Parts List .................................................................................................................. 4

Tank Drawing A....................................................................................................................................5

B) CABINET........................................................................................... 6

Cabinet Drawing B Parts List .............................................................................................................6

Cabinet Drawing B............................................................................................................................... 7

C) ENTRANCE BOX.................................................................................8

Entrance Box Drawing C Parts List ................................................................................................... 8

Entrance Box Drawing C.....................................................................................................................9

D) FRONT PANEL BEZEL...................................................................10

Front Panel Bezel Drawing D Parts List ..........................................................................................10

Front Panel Bezel Drawing D............................................................................................................11

E) DOOR & ELEMENT SHIELD............................................................. 12

Door & Element Shield Drawing E Parts List..................................................................................12

Door & Element Shield Drawing E ................................................................................................... 13

F) DUAL BASKET LIFT OPTION ..........................................................14

Dual Basket Lift Option Drawing F Parts List ................................................................................. 14

Dual Basket Lift Option Drawing F...................................................................................................15

G) SINGLE BASKET LIFT OPTION ....................................................16

Single Basket Lift Option Drawing G Parts List .............................................................................16

Single Basket Lift Option Drawing G............................................................................................... 17

H) MANUAL FILL OPTION..................................................................18

Manual Fill Option Drawing H Parts List .........................................................................................18

Manual Fill Option Drawing H...........................................................................................................19

L22-282, rev. 0 (1/06) iii

I) MIXING VALVE OPTION................................................................... 20

Mixing Valve Option Drawing I Parts List........................................................................................20

Mixing Valve Option Drawing I .........................................................................................................21

J) FAUCET OPTION .............................................................................. 22

Faucet Option Drawing J Parts List................................................................................................. 22

Faucet Option Drawing J ..................................................................................................................23

K) BATTERY OPTION ......................................................................... 24

Battery Option Drawing K Parts List ...............................................................................................24

Battery Option Drawing K ................................................................................................................. 25

L) ACCESSORIES .................................................................................26

Accessories Drawing L Parts List.................................................................................................... 26

Accessories Drawing L .....................................................................................................................27

iv

PE14D Exploded

PE14D Exploded Parts List

ITEM # PART # PART DESCRIPTION

1 P0075400 SCREW 10-24 X 1/2 SELF TAP
2 PP10195 SCREW 1/4-20 X 3/4 BUTTON HEAD HEX
3 PP10693 SCREW 10-24 X 3/8 THRUSS HEAD PHILLIPS

2

PE14D Electric Floor Model Pasta Cooker

PE14D Exploded Drawing

L22-282, rev. 0 (1/06) 3

A) Tank

Tank Drawing A Parts List

ITEM # PART # PART DESCRIPTION

1A
1B B3318202-C TANK WELDMENT PE14D W/MIXING VALVE
1C B3318203-C TANK WELDMENT PE14D W/FAUCET

7A B8018104 PIPING TUBE DRAIN PE14D
7B B8017905 PIPING TUBE DRAIN LH PE14D
7C B8017906 PIPING TUBE DRAIN RH PE14D

10 B4000802-C HANDLE VALVE WELDMENT PPE14,PPG14
11 PP10949 PROBE PG14D, PE14D
12 P5045047 CONNECTOR PROBE SST
13 PP10938 BUSHING REDUCER HEX 1/2 X 1/4 NPT 316 SST
14 A3316203 TANK SEAL PROBE TEFLON
15 P5047581 THERMOSTAT 1C1B2 (ELEC PASTA)
16 A3316101 TANK SLEEVE TEFLON PG14,PE14,CPE14
17 A1101602-C BASKET HANGER PG14D, PE14D
18 B3305301-C TANK SCREEN DRAIN OVERFLOW WELDMENT PPE14D
19 B3305401-C TANK SCREEN DRAIN VALVE WELDMENT PPE14
20 P0112000 SCREW 10-24 X 1/2 HEX HEAD CAP SST
21 A1407802-C CLAMP BULB HI-LIMIT PE14D
22 PP10568 NUT WING 10-24 SS
23 PP10665 SCREW 10-24 X 3/8 ROUND HEAD SST
24 60116501 ELEMENT FLAT BAR 12.5KW 240V
24 PP11209 ELEMENT FLAT BAR 12.5KW 208V
24 PP11210 ELEMENT FLAT BAR 12.5KW 230V
25 A3343502 TANK ELEMENT HOLD DOWN PLATE PE14D
26 A3343402 TANK ELEMENT HOLD DOWN BRACKET PE14D
27 OBS, REPLACE WITH ITEMS 25 & 26
28 OBS, REPLACE WITH ITEMS 25 & 26
29 DO NOT USE, REPLACE WITH B8702601-CL
30 PP10803 SWITCH HI LIMIT 250F LB117-026
31 PP10658 BUSHING REDUCER HEX 3/8 X 1/4 NPT BRASS
32 A3316201 TANK SEAL CAPILLARY TEFLON PG14D

B3318201-C TANK WELDMENT PE14D

2 PP10839 PLUG SST (316) 3/8 SQUARE HEAD
3 A3316001 TANK COUPLING PLUG TEFLON PG14, PE14D
4 P0190145 PIN CLEVIS 1/4 OD X 2-1/4 LONG
5 PP10565 VALVE BALL 1-1/4 STANDARD PORT SST
6 P0190200 PIN COTTER 1/16 X 3/4 LONG ZN

8 A3318603-C TANK HOSE OVERFLOW 22.0 RTG18 PG14D
9 PP10620 CLAMP HOSE WORMGEAR #20

4

Tank Drawing A

PE14D Electric Floor Model Pasta Cooker

L22-282, rev. 0 (1/06) 5

B) Cabinet

Cabinet Drawing B Parts List

ITEM # PART # PART DESCRIPTION

1 B1814501-C CABINET WELDMENT PG14D,RS14D
2 A1615102-C CABINET BACK UPPER PG14D, PE14D, RS14D
3 A1615202-C CABINET BACK BOTTOM SST PG14D,RTE14, PE14D
4 A1835901-C CABINET AIRVENT PE14D

5 A3661801-C FRONT PANEL CABLE RETAINER PE14D
6A A1826101-C CABINET PLATE RETAINER VALVE PG14D W/FILL
6B A3650601-C FRONT PANEL PLATE RETAINER VALVE PG14D
6C A1826103-C CABINET PLATE RETAINER VALVE PG14D W/O FILL

7 P0075400 SCREW 10-24 X 1/2 SELF TAP

8 B3609602-C FRONT PANEL WELDMENT PG14D, PE14D

9 P6071300 CATCH MAGNET STANDARD
10 A1847002 CLAMP BRACKET MAGNET CATCH

11A A1835701-C CABINET HEAT SHIELD OUTER PG14D MIXING VALVE
11B A1826201-C CABINET SHIELD HEAT OUTER PG14D

B3900701 LEG SET W/HARDWARE 6" (4-PACK)

12

13

B3900909 LEG ADJUSTABLE 6" SS
P0020600 SCREW 1/4-20 X 5/8 HEX HEAD CAP ZN
P0093300 NUT HEX (KEP) 1/4-20 ZN
B3901501 CASTER 6" SET W/HARDWARE
P0020600 SCREW 1/4-20 X 5/8 HEX HEAD CAP ZN
P0093300 NUT HEX (KEP) 1/4-20 ZN
PP10808 CASTER SWIVEL 6 NONLOCKING
PP10809 CASTER SWIVEL 6 LOCKING

6

Cabinet Drawing B

PE14D Electric Floor Model Pasta Cooker

L22-282, rev. 0 (1/06) 7

C) Entrance Box

Entrance Box Drawing C Parts List

ITEM # PART # PART DESCRIPTION

B2916401-C ENTRANCE BOX ASSEMBLY 208V 1PH PE14D
B2916402-C ENTRANCE BOX ASSEMBLY 240V 1PH PE14D
B2916403-C ENTRANCE BOX ASSEMBLY 208V 3PH PE14D
B2916404-C ENTRANCE BOX ASSEMBLY 240V 3PH PE14D
B2916405-C ENTRANCE BOX ASSEMBLY 200V 1PH PE14D
B2916406-C ENTRANCE BOX ASSEMBLY 220V 1PH PE14D
B2916407-C ENTRANCE BOX ASSEMBLY 200V 3PH PE14D

1

B2916408-C ENTRANCE BOX ASSEMBLY 220V 3PH PE14D
B2916409-C ENTRANCE BOX ASSEMBLY 346/200V 3PH PE14D
B2916410-C ENTRANCE BOX ASSEMBLY 380/220V 3PH PE14D
B2916411-C ENTRANCE BOX ASSEMBLY 400/230V 3PH PE14D
B2916412-C ENTRANCE BOX ASSEMBLY 415/240V 3PH PE14D

B2916413-C ENTRANCE BOX ASSEMBLY 208V 3PH DUAL PWR SPLY PE14D
2 A2964001-C ENTRANCE BOX BACK PE14D
3 B2910601-C ENTRANCE BOX WELDMENT WIRE PIPE PE14D
4 A2954201-C ENTRANCE BOX BODY PE14D
5 P0075400 SCREW 10-24 X 1/2 SELF TAP
6 P0092300 NUT HEX (KEP) 10-24 ZN
7 PP10698 SCREW 10-24 X 5/8 ROUND HEAD PHILLIPS
8 PP10605 FASTENER TERMINAL BLOCK LABEL
9 P5047301 BLOCK TERMINAL 3 POST ENTRANCE

10 P6094942 LABEL,MARKING STRIP L1 TO L
11 P5047302 BLOCK TERMINAL 2 POST ENTRANCE
12 P6094940 LABEL MARKING STRIP L1 & L2
13 A6043901 LABEL MARKING STRIP L3&N

14 PP10693 SCREW 10-24 X 3/8 THRUSS HEAD PHILLIPS
15A A2954303-C ENTRANCE BOX COVER PE14D INTERNATIONAL & 3PH DOMESTIC
15B B2913201-C ENTRANCE BOX COVER WELDMENT PE14D 1PH DOMESTIC

16 PP10429 TRANSFORMER 80VA 120/208/240V TO 24V

17 P5045282 BLOCK TERMINAL 4POLE BARRIER

18 P5045701 FUSE 40A SLOW BLOW

19 P5045792 FUSEBLOCK 3 POST 300V 60A

20 PP10560 CONTACTOR 24VAC 3POLE QUICK DISCONNECTS

21 B5307303 ELECTRIC ASSEMBLY SNUBBER 24V CONTACTOR

22 P6071493 PLUG HOLE 1/2 PLATED

23 P5045720 FUSE 4A SLOW BLOW GLASS

24 P5045794 FUSEHOLDER (LITTLEFUSE)

25 P5045240 CLAMP ROMEX 3/8

26 PP10914 BUSHING STRAIN RELIEF CABLE DIA .17

27 P6071228 GROMMET 1.703ID X 2.5OD

29 60145301 LUG GROUND ALUM

30 B6782101-C WIRING CONTROL PE14D

B6782601-C WIRING POWER SINGLE PHASE PE14D

31

B6782701-C WIRING POWER THREE PHASE DELTA PE14D
B6782801-C WIRING POWER THREE PHASE WYE PE14D

8

PE14D Electric Floor Model Pasta Cooker

Entrance Box Drawing C

L22-282, rev. 0 (1/06) 9

D) Front Panel Bezel

Front Panel Bezel Drawing D Parts List

ITEM # PART # PART DESCRIPTION

B3615505-C FRONT PANEL BEZEL ASSEMBLY DIGITAL EP3310
B3615506-C FRONT PANEL BEZEL ASSEMBLY DIGITAL EP3310 W/FILL
B3615508-C FRONT PANEL BEZEL ASSEMBLY DIGITAL PE14D MIXING VALVE

1A

1B

2A A6066901 LABEL OVERLAY BEZEL PG14D DIGITAL W/FILL

2B A6066801 LABEL OVERLAY BEZEL PG14D DIGITAL

2C A6067201 LABEL OVERLAY BEZEL PG14D ELECTRIC TSTAT W/FILL

2D A6067101 LABEL OVERLAY BEZEL PG14D ELECTRIC TSTAT

3A

3B B3628701-C FRONT PANEL BEZEL WELDMENT DIGITAL EP3310 MIXING VALVE

3C A3641302-C FRONT PANEL BEZEL PG14D ELECTRIC TSTAT

3D A3650802-C FRONT PANEL BEZEL PG14D ELECTRIC TSTAT MIXING VALVE

4A PP10939 CONTROL DIGITAL EP3310 PASTA

4B

4C

7A P5047118 SWITCH ROCKER SPST (1-0) 28V GREEN LAMP

7B PP10654 SWITCH ROCKER SPST W/BLK (1-0)

9A B6780602-C WIRING ELECTRIC TSTAT PE14D W/MIXING VALVE

9B B6780601-C WIRING ELECTRIC TSTAT PE14D

B3615511-C FRONT PANEL BEZEL ASSEMBLY DIGITAL COMPACT 4 BUTTON
B3615515-C FRONT PANEL BEZEL ASSEMBLY DIGITAL PIZZA HUT
B3615512-C FRONT PANEL BEZEL ASSEMBLY DIGITAL 4 BUTTON W/FILL
B3615516-C FRONT PANEL BEZEL ASSEMBLY DIGITAL PIZZA HUT W/FILL
B3615606-C FRONT PANEL BEZEL ASSEMBLY PE14D ELECTRIC TSTAT W/FILL
B3615607-C FRONT PANEL BEZEL ASSEMBLY PE14D ELECTRIC TSTAT
B3615608-C FRONT PANEL BEZEL ASSEMBLY ELECTRIC TSTAT MIXING VALVE

B3615401-C FRONT PANEL BEZEL WELDMENT PG14D DIGITAL EP3310
B3615402-C FRONT PANEL BEZEL WELDMENT PG14D DIGITAL 4 BUTTON

60143701 CONTROL COMPACT PASTA 4 BUTTON

60143702 CONTROL COMPACT 4 BUTTON PIZZA HUT
5 P0080601 WASHER FLAT #10
6 P0092300 NUT HEX (KEP) 10-24 ZN

8 PP10093 SWITCH ROCKER SPDT W/BLK (1-1)

10

PE14D Electric Floor Model Pasta Cooker

Front Panel Bezel Drawing D

L22-282, rev. 0 (1/06) 11

E) Door & Element Shield

Door & Element Shield Drawing E Parts List

ITEM # PART # PART DESCRIPTION

1 B2301123-C DOOR ASSEMBLY PG14D,PE14,PE14D
2 PP11006 HANDLE DOOR RECESSED PLASTIC
3 B3801601 HINGE WELDMENT LOWER RH
4 B3801501 HINGE WELDMENT UPPER RH
5 A2966901-C ENTRANCE BOX ELEMENT SHIELD COVER PE14D
6 PP10693 SCREW 10-24 X 3/8 THRUSS HEAD PHILLIPS
7 PP10687 SCREW 6-32 X 5/16 THRUSS HEAD PHILLIPS
8 A2954701-C ENTRANCE BOX ELEMENT SHIELD SIDE PE14D
9 A2967001-C ENTRANCE BOX ELEMENT SHIELD BOTTOM PE14D

10 P0075400 SCREW 10-24 X 1/2 SELF TAP
11 B6782201-C WIRING HI-LIMIT PE14D

12

PE14D Electric Floor Model Pasta Cooker

Door & Element Shield Drawing E

L22-282, rev. 0 (1/06) 13

F) Dual Basket Lift Option

Dual Basket Lift Option Drawing F Parts List

ITEM # PART # PART DESCRIPTION

B5606501-C BASKET LIFT ACTUATOR BOX DUAL 120V PASTA

B5606502-C BASKET LIFT ACTUATOR BOX DUAL 208V PASTA

1

B5606503-C BASKET LIFT ACTUATOR BOX DUAL 230V PASTA
2 A5619702-C BASKET LIFT MOUNT SIDE LH PE14D
3 A5619704-C BASKET LIFT MOUNT SIDE RH PE14D
4 PP10023 SCREW 10-24 X 3/8 SELF TAPPING
5 A5618302 BASKET LIFT MOUNT BOTTOM SG
6 A5619802-C BASKET LIFT DRIP SHIELD PE14D
7 PP10668 NUT ACORN W/CENTERLOCK 1/4-20
8 A5617902 BASKET LIFT HANGER SUPPORT AXLE SG DUAL
9 A5619602-C BASKET LIFT HANGER SUPPORT PE14D DUAL

10 A5617801 BASKET LIFT HANGER SUPPORT WHEEL SG
11 B5606101 BASKET LIFT HANGER WELDMENT LH PE14D DUAL
12 B5606102 BASKET LIFT HANGER WELDMENT RH PE14D DUAL
13 B5606301-C BASKET LIFT HANGER SUPPORT ASSEMBLY, PE14D DUAL
14 B5604102 BASKET LIFT ASSEMBLY LINEAR ACTUATOR DUAL PASTA

A2958102 ENTRANCE BOX SWITCH COVER 120V SG

15

16 60134304 BASKET LIFT ACTUATOR RH PASTA
17 60134303 BASKET LIFT ACTUATOR LH PASTA
18 60134001 CONTROL BASKET LIFT DRIVER BOARD
19 PP10429-M TRANSFORMER 80VA 120/208/240V TO 24V
20 B6779001 WIRING B/L MAIN ACTUATOR
21 B6744901 WIRING VOLTAGE SELECTOR SWITCH
22 B6779101 WIRING B/L TRANSFORMER ACTUATOR DUAL

A2958104 ENTRANCE BOX SWITCH COVER 208V SG

A2958106 ENTRANCE BOX SWITCH COVER 220/240V SG

14

PE14D Electric Floor Model Pasta Cooker

Dual Basket Lift Option Drawing F

L22-282, rev. 0 (1/06) 15

G) Single Basket Lift Option

Single Basket Lift Option Drawing G Parts List

ITEM # PART # PART DESCRIPTION

B5606801-C BASKET LIFT ACTUATOR BOX SINGLE 120V PASTA

B5606802-C BASKET LIFT ACTUATOR BOX SINGLE 208V PASTA

1

B5606803-C BASKET LIFT ACTUATOR BOX SINGLE 230V PASTA
2 A5619702-C BASKET LIFT MOUNT SIDE LH PE14D
3 A5619704-C BASKET LIFT MOUNT SIDE RH PE14D
4 PP10023 SCREW 10-24 X 3/8 SELF TAPPING
5 A5618302 BASKET LIFT MOUNT BOTTOM SG
6 A5619802-C BASKET LIFT DRIP SHIELD PE14D
7 PP10668 NUT ACORN W/CENTERLOCK 1/4-20
8 A5617904 BASKET LIFT HANGER SUPPORT AXLE PE14D SINGLE
9 A5620002-C BASKET LIFT HANGER SUPPORT PE14D SINGLE

10 A5617801 BASKET LIFT HANGER SUPPORT WHEEL SG
11 B5606701-C BASKET LIFT HANGER SUPPORT ASSEMBLY, PE14D SINGLE
12 B5605701 BASKET LIFT HANGER WELDMENT PE14D SINGLE

A2958102 ENTRANCE BOX SWITCH COVER 120V SG

13

14 B5606601 BASKET LIFT ASSEMBLY LINEAR ACTUATOR SINGLE PASTA
15 60134303 BASKET LIFT ACTUATOR LH PASTA
16 60134001 CONTROL BASKET LIFT DRIVER BOARD
17 PP10429-M TRANSFORMER 80VA 120/208/240V TO 24V
18 B6779001 WIRING B/L MAIN ACTUATOR
19 B6744901 WIRING VOLTAGE SELECTOR SWITCH
20 B6779102 WIRING B/L TRANSFORMER ACTUATOR SINGLE

A2958104 ENTRANCE BOX SWITCH COVER 208V SG

A2958106 ENTRANCE BOX SWITCH COVER 220/240V SG

16

PE14D Electric Floor Model Pasta Cooker

Single Basket Lift Option Drawing G

L22-282, rev. 0 (1/06) 17

H) Manual Fill Option

Manual Fill Option Drawing H Parts List

ITEM # PART # PART DESCRIPTION

1 PP10911 FITTING,COMPRESSION COPPER ELBOW 1/2" TUBE X 3/8 NPT
2 A8017501 PIPING REFILL VALVE OUTLET PG14D
3 PP10830 FITTING,COMPRESSION COPPER STRAIGHT 1/2" TUBE X 3/8 NPT
4 PP10945 VALVE,WATER 3/8 BALL BRASS
5 PP10270 BOLT U-1/2
6 A8017401 PIPING REFILL VALVE INLET PG14D
7 A8017902-C PIPING BRACKET MANUAL FILL PG14D
8 PP10693 SCREW 10-24 X 3/8 THRUSS HEAD PHILLIPS
9 P0092300 NUT HEX (KEP) 10-24 ZN

10 PP10726 VALVE CHECK 3/8 BALL BRASS
11 P0093300 NUT HEX (KEP) 1/4-20 ZN
12 B8029301-C PIPING HANDLE VALVE WATER WELDMENT PG14D
13 PP10944 KNOB MANUAL REFILL VALVE

18

PE14D Electric Floor Model Pasta Cooker

Manual Fill Option Drawing H

L22-282, rev. 0 (1/06) 19

I) Mixing Valve Option

Mixing Valve Option Drawing I Parts List

ITEM # PART # PART DESCRIPTION

1 PP11190 VALVE MIXER 3/8 NPT HOT + COLD
2 PP11189 FAUCET FLUSH 3/8 NPT
3 PP10911 FITTING,COMPRESSION COPPER ELBOW 1/2" TUBE X 3/8 NPT
4 A8022901 PIPING TUBING TANK SUPPLY WATER PG14D
5 PP10657 BUSHING REDUCER HEX 1/2 X 3/8 NPT BRASS
6 PP10830 FITTING,COMPRESSION COPPER STRAIGHT 1/2" TUBE X 3/8 NPT
7 A8022801 PIPING TUBING SUPPLY WATER COLD PG14D
8 A8022701 PIPING TUBING SUPPLY WATER HOT PG14D

20

PE14D Electric Floor Model Pasta Cooker

Mixing Valve Option Drawing I

L22-282, rev. 0 (1/06) 21

J) Faucet Option

Faucet Option Drawing J Parts List

ITEM # PART # PART DESCRIPTION

1A P6071000 FAUCET PASTA DOUBLE JOINTED 18
1B P6071002 FAUCET PASTA B200

2 PP10672 COUPLING BRASS 3/8 NPT
3 A8030701 PIPING WATER FAUCET SUPPLY TUBE RS14D
4 PP10830 FITTING,COMPRESSION COPPER STRAIGHT 1/2" TUBE X 3/8 NPT
5 PP10657 BUSHING REDUCER HEX 1/2 X 3/8 NPT BRASS

22

PE14D Electric Floor Model Pasta Cooker

Faucet Option Drawing J

L22-282, rev. 0 (1/06) 23

K) Battery Option

Battery Option Drawing K Parts List

ITEM # PART # PART DESCRIPTION

1 A1820002-C CABINET COVER STRIP REAR SST PPG14D, PPE14D
2 P0075400 SCREW 10-24 X 1/2 SELF TAP
3 A1203502-C CABINET BOTTOM BRACE JOINING PLATE PPG14D, PPE14D
4 P0093300 NUT HEX (KEP) 1/4-20 ZN
5 A1813602-C CABINET COVER UPRIGHT FRONT
6 P0020600 SCREW 1/4-20 X 5/8 HEX HEAD CAP ZN
7 B8018001 PIPING TUBING DRAIN LINE PPG14D
8 PP10032 GASKET DRAIN LINE (SLEEVE)
9 PP10034 CLAMP BAND 1.97

24

PE14D Electric Floor Model Pasta Cooker

Battery Option Drawing K

L22-282, rev. 0 (1/06) 25

L) Accessories

Accessories Drawing L Parts List

ITEM # PART # PART DESCRIPTION

1 A3305701 ROD CLEAN OUT DRAIN
2 B4512601 ELEMENT RACK PE14D
3 B4512702 BASKET PASTA LARGE BULK FINE MESH
4 B4510202 BASKET PASTA SMALL BULK FINE MESH
5 B4510001 BASKET PASTA ROUND 4-7/8
6 B4510002 BASKET PASTA ROUND 4-7/8 FINE MESH
7 B4509901 BASKET PASTA ROUND 6-1/2
8 B4509801 BASKET PASTA OBLONG
9 P6071998 INDIVIDUAL SERVING BASKET

10 B4511701 PASTA RACK PORTION PPG14
11 PP10730 BRUSH NYLON CLEANING STRAIGHT

26

PE14D Electric Floor Model Pasta Cooker

Accessories Drawing L

L22-282, rev. 0 (1/06) 27

In the event of problems with or
questions about your order, please
contact the Pitco Frialator factory at:
[phone] US and Canada only or
[phone] World Wide
Website Address: www.pitco.com

MAILING ADDRESS – P.O. BOX 501, CONCORD, NH 03302-0501

SHIPPING ADDRESS – 10 FERRY ST., CONCORD, NH 03301

L22-282, rev. 0 (01/06)

In the event of problems with or questions
about your equipment, please contact the
Pitco Frialator Authorized Service and Parts
representative (ASAP) covering your area, or
contact Pitco at the numbers listed to the left.
