Page 1
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION
2011
SC-LX85
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
SC-LX85
SC-LX75
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Porew Requirement Remarks
SC-LX85 SYXJ5 AC 220 V to 230 V
SC-LX75 SYXJ5 AC 220 V to 230 V
ORDER NO.
RRV4229
This service manual should be used together with the following manual(s).
Model No. Order No. Remarks
SC-57/UXJCB RRV4195
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
K-ZZZ JULY
2011 Printed in Japan
Page 2
1
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5
6 1
4 7 3
R 5 0
1
R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 103
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
A
B
CONTRAST TABLE
SC-57/UXJCB, SC-LX85/SYXJ5 and SC-LX75/SYXJ5 are constructed the same except for the following:
Mark No. Symbol and Description SC-57/UXJCB SC-LX85/SYXJ5 SC-LX75/SYXJ5 Remarks
PCB ASSEMBLIES
P85-1 1..IR POWER AMP ASSY AWH7030 AWH7037 AWH7040
NSP 1..IR BUFFER ASSY AWM8249 AWM8282 AWM8282
C
NSP 1..PRIM DISPLAY ASSY AWM8250 AWM8262 AWM8262
NSP 1..AUDIO COMPOSITE ASSY AWR7106 AWR7107 AWR7113
NSP 1..INTERFACE REG ASSY AWR7111 AWR7124 AWR7124
D
NSP 1..REG BRIDGE ASSY AWR7112 AWR7115 AWR7125
E
P85-2 2..IR BUFFER ASSY AWX9793 AWX9952 AWX9952
P85-4 2..PRIMARY ASSY AWX9799 AWX9848 AWX9848
P87-1 2..DISPLAY ASSY AWX9796 AWX9967 AWX9967
P87-4 2..MIC HP ASSY AWX9800 AWX9968 AWX9968
P83-2 2..AUDIO ASSY AWX9790 AWX9831 AWX9834
P83-3 2..COMPOSITE ASSY AWX9791 AWX9791 AWX9836
P81-3 2..IR REG ASSY AWX9806 AWX9954 AWX9954
P81-4 2..B DIODE ASSY AWX9808 AWX9958 AWX9958
P85-7 2..A REG BRIDGE ASSY AWX9810 AWX9970 AWX9970
P81-6 2..DISPLAY BRIDGE ASSY AWX9815 AWX9956 AWX9956
P81-7 2..F-IN BRIDGE ASSY AWX9816 AWX9965 AWX9965
P83-9 2..MCH BRIDGE ASSY AWX9818 AWX9818 Not used
P83-11 2..MULTI CH IN ASSY AWX9857 AWX9856 Not used
P85-8 2..REG ASSY AWX9813 AWX9955 AWX9955
P85-10 2..FB-CONNECT ASSY AWX9819 AWX9966 AWX9966
P87-6 1..FRONT HDMI USB ASSY AWX9749 AWX9969 AWX9969
P83-13 1..DAC HIGH ASSY AWX9822 AWX9858 AWX9861
F
P83-14 1..DIGITAL MAIN ASSY AWX9827 AWX9727 AWX9950
P83-15 1..COMPONENT ASSY AWX9866 AWX9951 AWX9867
> P79-2 AC Power Cord ADG7111 ADG7062 ADG7062
P79-6 Packing Case AHD8722 AHD8723 AHD8730
P79-9 Operating Instructions (En) ARB7459 Not used Not used
P79-12 Operating Instructions (CD-ROM) ARU7006 ARU7004 ARU7028
NSP P79-13 Warranty Card ARY7007 ARY7128 ARY7128
P79-14 Remote Control Unit SEL/MID AXD7612 Not used AXD7613
P79-14 RF Remote Control Unit Not used AXD7580 Not used
2
PACKING SECTION
1
2 3 4
SC-LX85
Page 3
5
6 7 8
Mark No. Symbol and Description SC-57/UXJCB SC-LX85/SYXJ5 SC-LX75/SYXJ5 Remarks
P79-15 Battery Door AZN8047 Not used AZN8047
P79-15 Battery Cover Not used AZN8049 Not used
NSP P79-17 Dry Cell Battery (R3) VEM1051 Not used VEM1051
NSP P79-17 Dry Cell Battery (LR6) Not used VEM1053 Not used
Operating Instructions Not used ARH7107 ARH7107
Operating Instructions Not used ARH7108 ARH7108
Operating Instructions Not used ARH7109 ARH7109
NSP Label (WEEE) Not used ARW7322 Not used
NSP Name Label AD(EL) Not used AAL7447 Not used
NSP Name Label RC(EL) Not used AAL7446 Not used
IR Bluster Cable Not used ADF7007 Not used
RF Receiver Box Not used AXX7272 Not used
RF Remote Caution Not used ARM7131 Not used
Manual Assy Not used AXX7286 AXX7286
Wifi Cable (service) Not used ADE7138 ADE7138
NSP
Wifi Converter E Not used
• • • • • • • • • • • •
EXTERIOR SECTION
P81-9 Power Transformer (T1501) ATS7447 ATS7448 ATS7439
> P81-10 Fuse (FU13, FU14 : 1 A) REK1142 Not used Not used
P81-10 Fuse (FU13, FU14 : T800mA) Not used AEK7072 AEK7072
>
> P81-11 Fuse (FU11, FU12, FU15 : 1.25 A) REK1143 Not used Not used
P81-11 Fuse (FU11, FU12, FU15 : T1 A) Not used AEK7073 AEK7073
>
A
B
> P81-12 Fuse (FU10 : 4 A) REK1149 Not used Not used
P81-12 Fuse (FU10 : T3.15 A) Not used AEK1059 AEK1059
>
P81-24 Insulator AMR7198 DXA1904 DXA1904
REAR SECTION
P83-16 AM/FM Tuner Unit AXX7282 AXX7283 AXX7283
P83-23 Rear Panel ANC8599 ANC8600 ANC8607
P83-25 D. Main Shield 85 (MTL) ANK7162
NSP P83-26 PC Support VEC1749
P83-36 Nylon Rivet AEC7406
ANK7162
VEC1749 Not used
AEC7406
Not used
Not used
CHASSIS SECTION
> P85-13 Fuse (FU4 : 2 A) REK1139 Not used Not used
> P85-13 Fuse (FU4 : T4 A) Not used REK1104 REK1104
P85-14 Fuse (FU21, FU22, FU31, FU32 : 1.25A) REK1143 Not used Not used
>
P85-14 Fuse (FU21, FU22 : T800 mA) Not used AEK7072 AEK7072
>
P85-14 Fuse (FU31, FU32 : T1 A) Not used AEK7073 AEK7073
>
> P85-15 Fuse (FU1 : 10 A) REK1154 Not used Not used
P85-15 Fuse (FU1 : T5 A) Not used AEK1061 AEK1061
>
FRONT SECTION
P87-13 Filter AAK8443 AAK8459 AAK8459
P87-14 Display Panel AAK8567 AAK8568 AAK8568
NSP P87-23 Panel Base AMB8041 AMB8042 AMB8042
P87-26 Door Panel ANB7562 ANB7563 ANB7563
P87-27 Front Panel (AL) ANB7565 ANB7566 ANB7570
C
D
E
P87-29 PIONEER Badge (AL) VAM1159 VAM1158 VAM1158
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES”.
When a Wifi converter is defective, please replace with a product stock of AS-WL300.
When a Wifi cable is defective or broken, please replace to ADE7138 which has clamp filter attached for this model.
SC-LX85
5
6 7 8
F
3
Page 4
1
2 3 4
CONTRAST OF PCB ASSEMBLIES
F AUDIO ASSY
A
AWX9790, AWX9831 and AWX9834 are constructed the same except for the following:
A
Mark Symbol and Description AWX9790 AWX9831 AWX9834 Remarks
JA2502, JA3202 2P PIN JACK AKB7234 AKB7234 AKB7233
CN2510 18P SOCKET AKP7123 AKP7123 Not used
JA2501, JA2503, JA2504, JA2951 AKB7218 AKB7218 XKB3017
JA3101 PIN JACK(4P) AKB7218 AKB7218 XKB3017
JA3102 RCA JACK AKB7237 AKB7237 AKB7236
JA3201 PIN JACK(6P) AKB7221 AKB7221 XKB3037
R2663, R2664 RS1/10SR331J RS1/10SR561J RS1/10SR561J
R3030, R3034 Not used RS1/10SR472J RS1/10SR472J
B
C
R3032 RS1/8SQ562J RS1/8SQ182J RS1/8SQ182J
R3951-R3958 Not used Not used RS1/10SR473J
C2501-C2504, C2521-C2524 Not used CCSRCH101J50 CCSRCH101J50
C2541-C2544, C2561, C2562 Not used CCSRCH101J50 CCSRCH101J50
C2583, C2584, C2603, C2604 Not used CCSRCH101J50 CCSRCH101J50
C3113, C3114, C3163, C3164 Not used CCSRCH101J50 CCSRCH101J50
C3213, C3214, C3263, C3264 Not used CCSRCH101J50 CCSRCH101J50
C3283, C3284, C3922, C3923 Not used CCSRCH101J50 CCSRCH101J50
C3945 Not used CCSRCH101J50 CCSRCH101J50
C2563, C2564 Not used CCSRCH220J50 CCSRCH220J50
C2661, C2662 Not used CCSRCH221J50 CCSRCH221J50
C2665, C2666, C3111, C3112 Not used CCSRCH331J50 CCSRCH331J50
C3161, C3162, C3211, C3212 Not used CCSRCH331J50 CCSRCH331J50
C3261, C3262, C3281, C3282 Not used CCSRCH331J50 CCSRCH331J50
C3924, C3925, C3944 Not used CCSRCH331J50 CCSRCH331J50
C2951, C2952, C2971, C2972 Not used CCSRCH471J50 CCSRCH471J50
C2667, C2668 Not used CCSRCH561J50 CCSRCH561J50
C3011, C3012 CCSRCH331J50 Not used Not used
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F DAC HIGH ASSY
D
B
AWX9822, AWX9858 and AWX9861 are constructed the same except for the following:
Mark Symbol and Description AWX9822 AWX9858 AWX9861 Remarks
D2130 1SS302 Not used Not used
JA2008 RCA JACK AKB7235 AKB7235 AKB7173
JA2101 8P MINI DIN SOCKET BKP1127 Not used Not used
R2002, R2004 RS1/10SR220J RS1/10SR270J RS1/10SR270J
R2133, R2134 Not used RS1/10SR0R0J RS1/10SR0R0J
R2135 RS1/10SR0R0J Not used Not used
R2140, R2141 RS1/10SR474J Not used Not used
E
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F FRONT HDMI USB ASSY
C
AWX9749 and AWX9969 are constructed the same except for the following:
F
R2142, R2143 RS1/10SR331J Not used Not used
R2144, R2145, R2231-R2233 Not used RS1/10SR0R0J RS1/10SR0R0J
R2491 RS1/8SQ105J RS1/8SQ222J RS1/8SQ222J
R2492 RS1/8SQ474J RS1/8SQ105J RS1/8SQ105J
C2124, C2126 CKSRYB103K50 Not used Not used
C2127, C2128 CEAT220M50 Not used Not used
Mark Symbol and Description AWX9749 AWX9969 Remarks
C8043, C8108 CKSSYB102K50 CCSSCH102J50
4
1
2 3 4
SC-LX85
Page 5
F MULTI CH IN ASSY
E
5
6 7 8
AWX9857 and AWX9856 are constructed the same except for the following:
Mark Symbol and Description AWX9857 AWX9856 Remarks
C7761-C7764, C7767-C7770 Not used CCSRCH101J50
C7773-C7776, C7779-C7782 Not used CCSRCH101J50
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F DIGITAL MAIN ASSY
F
AWX9827, AWX9727 and AWX9950 are constructed the same except for the following:
Mark Symbol and Description AWX9827 AWX9727 AWX9950 Remarks
R610, R618 Not used RS1/8SQ105J RS1/8SQ105J
R9513 RS1/16SS100J RS1/16SS0R0J RS1/16SS100J
R9518 RS1/16SS82R0D RS1/16SS82R0D RS1/16SS1501D
R9519 RS1/16SS331J RS1/16SS331J RS1/16SS152J
R9520 RS1/16SS7501D RS1/16SS7501D RS1/16SS3302D
R9521 RS1/16SS622J RS1/16SS622J RS1/16SS163J
R9522 RS1/16SS3301D RS1/16SS3301D RS1/16SS1502D
R9531 RS1/16SS3302D RS1/16SS9101D RS1/16SS3302D
R9532 RS1/16SS123J RS1/16SS562J RS1/16SS123J
R9533 RS1/16SS2402D RS1/16SS6801D RS1/16SS2402D
A
B
R9534 RS1/16SS2401D RS1/16SS4700D RS1/16SS2401D
R9535 RS1/16SS112J RS1/16SS301J RS1/16SS112J
R9536, R9540, R9542, R9543 RS1/8SQ0R0J Not used RS1/8SQ0R0J
R9555, R9564 RS1/8SQ0R0J Not used RS1/8SQ0R0J
C9577 Not used ACH7309 Not used
C9578 Not used ACH7314 Not used
C140, C995, C1355 VCH1277 VCH1277 CEVW221M4
C197 Not used CCSSCH101J50 CCSSCH101J50
C203, C428, C447 CKSSYB104K16 CCSSCH331J50 CCSSCH331J50
C619, C650 CCSSCH102J50 CCSSCH101J50 CCSSCH101J50
C996, C1672, C1673 ACH7306 ACH7306 Not used
C1008 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C1770, C1847 CEVW101M16 CEVW101M16 Not used
C9056, C9072 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C9314 CKSSYB104K16 CCSSCH180J50 CCSSCH180J50
C9322 Not used CCSSCH220J50 CCSSCH220J50
C9547 CKSSYB682K25 CKSSYB682K25 CCSSCH102J50
C9553 CKSSYB472K50 CKSSYB472K50 CCSSCH102J50
C9565 CKSSYB152K50 CKSSYB472K50 CKSSYB152K50
C9570 CCSSCH102J50 CKSSYB682K25 CCSSCH102J50
C9588, C9608 CFHXSQ103J16 CFHXSQ103J16 Not used
C9593 ACH7306 ACH7306 Not used
C9621 CCSSCH101J50 CKSSYB104K16 CCSSCH101J50
C9742 CCSSCH221J50 CCSSCH101J50 CCSSCH101J50
C9751 CCSSCH471J50 CCSSCH101J50 CCSSCH101J50
C
D
E
C9757 CKSSYB104K16 CCSSCH101J50 CCSSCH101J50
C1836 CEVW470M16 CEVW470M16 Not used
C156 VCH1268 VCH1268 CEVW101M4
C1031, C9004, C9702 VCH1234 VCH1234 CEVW101M16
C9537 VCH1234 VCH1234 Not used
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
SC-LX85
5
6 7 8
F
5
Page 6
F COMPONENT ASSY
H
AWX9866, AWX9951 and AWX9867 are constructed the same except for the following:
A
Mark Symbol and Description AWX9866 AWX9951 AWX9867 Remarks
F COMPOSITE ASSY
I
B
AWX9791 and AWX9836 are constructed the same except for the following:
Mark Symbol and Description AWX9791 AWX9836 Remarks
F MIC HP ASSY
J
AWX9800 and AWX9968 are constructed the same except for the following:
Mark Symbol and Description AWX9800 AWX9968 Remarks
C
F DISPLAY ASSY
K
AWX9796 and AWX9967 are constructed the same except for the following:
Mark Symbol and Description AWX9796 AWX9967 Remarks
D
F IR BUFFER ASSY
O
AWX9793 and AWX9952 are constructed the same except for the following:
Mark Symbol and Description AWX9793 AWX9952 Remarks
F IR POWER AMP ASSY
R
AWH7030, AWH7037 and AWH7040 are constructed the same except for the following:
Mark Symbol and Description AWH7030 AWH7037 AWH7040 Remarks
E
1
JA8301 6P PIN JACK AU AKB7225 AKB7225 AKB7224
JA8302, JA8304 3P PIN JACK AU AKB7228 AKB7228 AKB7227
JA8305 3P PIN JACK AU AKB7228 AKB7228 Not used
R8316, R8318, R8320 RS1/10SR68R0F RS1/10SR68R0F Not used
R8317, R8319, R8321 RS1/10SR3R9J RS1/10SR3R9J Not used
R8361, R8362 RS1/10SR0R0J RS1/10SR100J RS1/10SR100J
C8394 CCSRCH470J50 CCSRCH470J50 Not used
JA3601-JA3603 2P PIN JACK AKB7230 AKB7229
JA3604, JA3605 1P PIN JACK AKB7232 AKB7231
R3616 RS1/10SR68R0D RS1/10SR68R0F
C3608, C3610 CKSRYB104K16 CKSRYB104K50
C3473 CKSRYB471K50 CCSRCH471J50
C3490 CKSRYB102K50 CCSRCH102J50
C3006, C3302 CKSRYB471K50 CCSRCH471J50
C3102, C3201, C3306 CKSRYB102K50 CCSRCH102J50
C3104 CKSRYB102K50 CCSRCH330J50
R6857 RS1/8SQ225J RS1/8SQ224J
IC4004 TC74VHC08FK TC74VHCT08AFKS1 TC74VHCT08AFKS1
IC4905 TC7SH08FUS1 TC7SET08FUS1 TC7SET08FUS1
IC5101 UPC4570G2-A Not used Not used
Q4121, Q4221, Q4721 2SC2713 Not used Not used
Q4111, Q4211, Q4311, Q4411 LSA1576UB LTA114TUB LTA114TUB
2 3 4
Q4511, Q4611, Q4711, Q4811 LSA1576UB LTA114TUB LTA114TUB
Q4911 LSA1576UB LTA114TUB LTA114TUB
Q4122, Q4222, Q4722 LSA1576UB Not used Not used
Q4023, Q4025 LSC4081UB DTC623TU DTC623TU
Q5101 LSC4081UB Not used Not used
F
Q4105, Q4106, Q4205, Q4206 LTC124EUB DTC115EUA DTC115EUA
Q4305, Q4306, Q4405, Q4406 LTC124EUB DTC115EUA DTC115EUA
Q4505, Q4506, Q4605, Q4606 LTC124EUB DTC115EUA DTC115EUA
Q4705, Q4706, Q4805, Q4806 LTC124EUB DTC115EUA DTC115EUA
6
1
2 3 4
SC-LX85
Page 7
5
6 7 8
Mark Symbol and Description AWH7030 AWH7037 AWH7040 Remarks
Q4905, Q4906 LTC124EUB DTC115EUA DTC115EUA
D4116, D4216, D4316, D4416 RB161VA-20 RB500V-40 RB500V-40
D4516, D4616, D4716, D4816 RB161VA-20 RB500V-40 RB500V-40
D4916 RB161VA-20 RB500V-40 RB500V-40
D4005 1SS352 1SS355 1SS355
D4103, D4120, D4203, D4220 1SS302 Not used Not used
D4111, D4211, D4311, D4411 1SS302 DAN217U DAN217U
D4511, D4611, D4711, D4811 1SS302 DAN217U DAN217U
D4703, D4720 1SS302 Not used Not used
D4911 1SS302 DAN217U DAN217U
D4027, D4028, D4029, D4030 RKZ4.7KG Not used Not used
D4031 RKZ4.7KG Not used Not used
L4000 QTL1013 RS1/10SR101J RS1/10SR101J
JA4301, JA4501, JA4901 AKE7149 AKE7147 AKE7143
JA5101 SP TERMINAL 4-P(V0) AKE7149 AKE7147 AKE7143
JA4101 SP TERMINAL 6-P(V0) AKE7150 AKE7148 AKE7144
R4176, R4180, R4276, R4280 ACN7195 RS1/4S0R0J RS1/4S0R0J
R4776, R4780 ACN7195 RS1/4S0R0J RS1/4S0R0J
R5034, R5036 Not used RS1/8SQ0R0J RS1/8SQ0R0J
R4113, R4213, R4713, R5107 RS1/10SR0R0J Not used Not used
R5108, R5112, R5121, R5130 RS1/10SR0R0J Not used Not used
R5134, R5136, R5138, R5140 RS1/10SR0R0J Not used Not used
R5027, R5028, R5031, R5032 RS1/10SR0R0J RS1/10SR101J RS1/10SR101J
R4005 RS1/10SR0R0J RS1/10SR103J RS1/10SR103J
R5113, R5114, R5122, R5123 RS1/10SR100J Not used Not used
R5131, R5132 RS1/10SR100J Not used Not used
A
B
C
R4275, R4475, R4675, R4775 RS1/10SR100J RS1/10SR101J RS1/10SR101J
R4875 RS1/10SR100J RS1/10SR101J RS1/10SR101J
R4144, R4161, R4175, R4244 RS1/10SR101J Not used Not used
R4261, R4282, R4744, R4761 RS1/10SR101J Not used Not used
R4793 RS1/10SR101J Not used Not used
R4185, R4285, R4785, R5141 RS1/10SR103J Not used Not used
R4071, R4074, R5079 RS1/10SR103J RS1/10SR104J RS1/10SR104J
R4041, R4045, R4127, R4160 RS1/10SR103J RS1/10SR473J RS1/10SR473J
R4227, R4260, R4327, R4360 RS1/10SR103J RS1/10SR473J RS1/10SR473J
R4427, R4460, R4527, R4560 RS1/10SR103J RS1/10SR473J RS1/10SR473J
R4627, R4660, R4727, R4760 RS1/10SR103J RS1/10SR473J RS1/10SR473J
R4827, R4860, R4927, R4960 RS1/10SR103J RS1/10SR473J RS1/10SR473J
R4186, R4190, R4286, R4290 RS1/10SR104J Not used Not used
R4786, R4790, R5104 RS1/10SR104J Not used Not used
R5105 RS1/10SR105J Not used Not used
R4032, R4033, R4040, R4157 RS1/10SR153J RS1/10SR473J RS1/10SR473J
R4257, R4357, R4457, R4557 RS1/10SR153J RS1/10SR473J RS1/10SR473J
R4657, R4757, R4857, R4957 RS1/10SR153J RS1/10SR473J RS1/10SR473J
R4000, R4027, R4078, R4079 RS1/10SR182J RS1/10SR562J RS1/10SR562J
R4090 RS1/10SR182J RS1/10SR562J RS1/10SR562J
R4184, R4284, R4784 RS1/10SR183J Not used Not used
R5115, R5124, R5133 RS1/10SR1R0J Not used Not used
R5106, R5137, R5142 RS1/10SR223J Not used Not used
R4042, R4189, R4289 RS1/10SR273J Not used Not used
R4789 RS1/10SR273J Not used Not used
D
E
R4059 RS1/10SR2R2J RS1/10SR100J RS1/10SR100J
R5001 RS1/10SR3901F RS1/10SR1002F RS1/10SR1002F
R4124, R4224, R4324, R4424 RS1/10SR471J RS1/10SR431J RS1/10SR431J
R4524, R4624, R4724, R4824 RS1/10SR471J RS1/10SR431J RS1/10SR431J
R4924 RS1/10SR471J RS1/10SR431J RS1/10SR431J
SC-LX85
5
6 7 8
F
7
Page 8
1
Mark Symbol and Description AWH7030 AWH7037 AWH7040 Remarks
R4096, R4110, R4210, R4310 RS1/10SR472J RS1/10SR103J RS1/10SR103J
R4410, R4510, R4610, R4710 RS1/10SR472J RS1/10SR103J RS1/10SR103J
A
B
C
R4810, R4910 RS1/10SR472J RS1/10SR103J RS1/10SR103J
R5101, R5102 RS1/10SR473J Not used Not used
R5111, R5120, R5129 RS1/10SR4R7J Not used Not used
R5000 RS1/10SR5600F RS1/10SR1501F RS1/10SR1501F
R5103 RS1/10SR682J Not used Not used
R5135 RS1/10SR821J Not used Not used
R5035, R5037 RS1/8SQ0R0J Not used Not used
R5029, R5030 RS1/8SQ0R0J RS1/8SQ103J RS1/8SQ103J
R5012, R5013, R5020, R5021 RS1/8SQ103J RS1/8SQ104J RS1/8SQ104J
R5011 RS1/8SQ103J RS1/8SQ473J RS1/8SQ473J
R5019 RS1/8SQ104J RS1/8SQ224J RS1/8SQ224J
R5018 RS1/8SQ104J RS1/8SQ474J RS1/8SQ474J
R5083-R5087 RS1/8SQ105J Not used Not used
R5014, R5022 RS1/8SQ223J RS1/8SQ683J RS1/8SQ683J
R5016, R5024 RS1/8SQ473J RS1/8SQ104J RS1/8SQ104J
C4186, C4286, C4786 CCSRCH100D50 Not used Not used
C4012 CCSRCH331J50 CCSRCH221J50 CCSRCH221J50
C4045, C4049, C5001-C5005 CCSRCH331J50 Not used Not used
C4184, C4284, C4784 CCSRCH471J50 Not used Not used
C4121, C4122, C4221, C4222 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4321, C4322, C4421, C4422 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4521, C4522, C4621, C4622 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C4721, C4722, C4821, C4822 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
2 3 4
C4921, C4922 CFHXSQ103J16 CFHXSQ472J16 CFHXSQ472J16
C5102, C5103 CFHXSQ103J16 Not used Not used
C4151, C4251, C4351, C4451 CKSRYB103K50 Not used Not used
C4551, C4651, C4751, C4851 CKSRYB103K50 Not used Not used
C4951 CKSRYB103K50 Not used Not used
C4258, C4458, C4658, C4758 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
C4858 CKSRYB104K50 CKSRYB103K50 CKSRYB103K50
C4006, C4124, C4152, C4153 CKSRYB104K50 Not used Not used
D
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
E
F PRIMARY ASSY
S
C4224, C4252, C4253, C4324 CKSRYB104K50 Not used Not used
C4352, C4353, C4424, C4452 CKSRYB104K50 Not used Not used
C4453, C4524, C4552, C4553 CKSRYB104K50 Not used Not used
C4624, C4652, C4653, C4724 CKSRYB104K50 Not used Not used
C4752, C4753, C4824, C4852 CKSRYB104K50 Not used Not used
C4853, C4924, C4952, C4953 CKSRYB104K50 Not used Not used
C5101 CKSRYB104K50 Not used Not used
C5106 CKSRYB224K25 Not used Not used
C4083, C4084 Not used ACE7082 ACE7082
AWX9799 and AWX9848 are constructed the same except for the following:
Mark Symbol and Description AWX9799 AWX9848 Remarks
L1 LINE FILTER ATF7046 ATF7050
CN81 CONNECTOR B2P3-VH Not used
CN82 CONNECTOR(VH) Not used B3P5-VH
VA1 VARISTOR Not used TND10V-511KB00AAA0
C81 ACE7013 Not used
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F
8
1
2 3 4
SC-LX85
Page 9
F REG ASSY
U
Although AWX9813 and AWX9955 are different in part number, they consist of the same service components.
F IR REG ASSY
V
AWX9806 and AWX9954 are constructed the same except for the following:
Mark Symbol and Description AWX9806 AWX9954 Remarks
F B DIODE ASSY
W
AWX9808 and AWX9958 are constructed the same except for the following:
Mark Symbol and Description AWX9808 AWX9958 Remarks
F FB-CONNECT ASSY
Y
AWX9819 and AWX9966 are constructed the same except for the following:
Mark Symbol and Description AWX9819 AWX9966 Remarks
F
DISPLAY BRIDGE ASSY
e
AWX9815 and AWX9956 are constructed the same except for the following:
Mark Symbol and Description AWX9815 AWX9956 Remarks
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F
F-IN BRIDGE ASSY
f
AWX9816 and AWX9965 are constructed the same except for the following:
Mark Symbol and Description AWX9816 AWX9965 Remarks
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
F
A REG BRIDGE ASSY
h
AWX9810 and AWX9970 are constructed the same except for the following:
Mark Symbol and Description AWX9810 AWX9970 Remarks
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
5
R7258 RS1/4SA822J RS1/4SA105J
R7400 RS1/4SA823J RS1/4SA913J
R7401 RS1/4SA823J RS1/4SA683J
C7693, C7696 CCSRCH270J50 Not used
C7694, C7697 CCSRCH331J50 Not used
C7654 Not used CCSRCH101J50
C7901, C7905 Not used CCSRCH100D50
R7161 RS1/10SR0R0J RS1/10SR100J
R7669 Not used RS1/10SR105J
C7168 Not used CCSRCH101J50
C7171 Not used CCSRCH330J50
R5777, R5780 Not used RS1/10SR472J
6 7 8
A
B
C
D
E
F
SC-LX85
5
6 7 8
9
Loading...
