Page 1

COMPACT DISC RECORDER

PDR-609

Operating Instructions

Page 2

IMPORTANT

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

CAUTION: TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

READ INSTRUCTIONS — All the safety and operating

instructions should be read before the product is operated.

RETAIN INSTRUCTIONS — The safety and operating

instructions should be retained for future reference.

HEED WARNINGS — All warnings on the product and

in the operating instructions should be adhered to.

FOLLOW INSTRUCTIONS — All operating and use

instructions should be followed.

CLEANING — Unplug this product from the wall outlet

before cleaning. The product should be cleaned only with a polishing cloth or a soft dry cloth. Never clean with furniture wax, benzine, insecticides or other volatile liquids since they may corrode the cabinet.

ATTACHMENTS — Do not use attachments not

recommended by the product manufacturer as they may cause hazards.

WATER AND MOISTURE — Do not use this product

near water — for example, near a bathtub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

ACCESSORIES — Do not place this product on an

unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

CART — A product and cart combination should be

moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

VENTILATION — Slots and openings in the cabinet are

provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

POWER SOURCES — This product should be operated

only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company.

LOCATION – The appliance should be installed in a

stable location.

NONUSE PERIODS – The power cord of the appliance

should be unplugged from the outlet when left unused for a long period of time.

GROUNDING OR POLARIZATION

¶ If this product is equipped with a polarized alternating

current line plug (a plug having one blade wider than the other), it will fit into the outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

¶ If this product is equipped with a three-wire

grounding type plug, a plug having a third (grounding) pin, it will only fit into a grounding type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

POWER-CORD PROTECTION — Power-supply cords

should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

OUTDOOR ANTENNA GROUNDING — If an outside

antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure A.

LIGHTNING — For added protection for this product

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

POWER LINES — An outside antenna system should

not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

OVERLOADING — Do not overload wall outlets,

extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

ELECTRIC SERVICE EQUIPMENT

Fig. A

OBJECT AND LIQUID ENTRY — Never push objects of

any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

SERVICING — Do not attempt to service this product

yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

DAMAGE REQUIRING SERVICE — Unplug this product

from the wall outlet and refer servicing to qualified service personnel under the following conditions:

¶ When the power-supply cord or plug is damaged. ¶ If liquid has been spilled, or objects have fallen into

the product.

¶ If the product has been exposed to rain or water. ¶ If the product does not operate normally by following

the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

¶ If the product has been dropped or damaged in any

way.

¶ When the product exhibits a distinct change in

performance — this indicates a need for service.

REPLACEMENT PARTS — When replacement parts

are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

SAFETY CHECK — Upon completion of any service or

repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

WALL OR CEILING MOUNTING — The product should

not be mounted to a wall or ceiling.

HEAT — The product should be situated away from heat

sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

NEC — NATIONAL ELECTRICAL CODE

Page 3

WARNING: TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

[For U.S. model] IMPORTANT NOTICE

The serial number for this equipment is located in the rear. Please write this serial number on your enclosed warranty card and keep it in a secure area. This is for your security.

[For Canadian model] CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT

USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE

ATTENTION: POUR PREVENIR LES CHOCS

ELECTRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSERESS A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.

[For Canadian model]

This Class B digital apparatus complies with Canadian ICES-003.

[Pour le modèle Canadien]

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

[For U.S. model] DANGER – LASER RADIATION WHEN

OPEN. AVOID DIRECT EXPOSURE TO BEAM.

This caution can be found on the rear panel of the unit.

Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference. In some countries or regions, the shape of the power plug and power outlet may sometimes differ from that shown in the explanatory drawings. However, the method of connecting and operating the unit is the same.

CAUTION:

¶ Use of controls or adjustments or performance of procedures other than those specified herein hazardous radiation

exposure.

¶ The use of optical instruments with this product will increase eye hazard.

English

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

Information to User

Alteration or modifications carried out without appropriate authorization may invalidate the user’s right to operate the equipment.

Page 4

IMPORTANT

FOR USE IN THE UNITED KINGDOM

The wires in this mains lead are coloured in accordance with the following code:

Blue : Neutral Brown :Live

If the plug provided is unsuitable for your socket outlets, the plug must be cut off and a suitable plug fitted.

The cutoff plug should be

This product complies with the Low Voltage Directive (73/23/EEC, amended by 93/68/ EEC), EMC Directives (89/ 336/EEC, 92/31/EEC and 93/68/EEC).

disposed of and must not be inserted into any 13 amp socket as this can result in electric shock. The plug or adaptor of the distribution panel should be provided with a 5 amp fuse. As the colours of the wires in the mains lead of this appliance may not correspond with coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

Do not connect either wire to the earth terminal of a three-pin plug.

NOTE

After replacing or changing a fuse, the fuse cover in the plug must be replaced with a fuse cover which corresponds to the colour of the insert in the base of the plug or the word that is embossed on the base of the plug, and the appliance must not be used without a fuse cover. If lost, replacement fuse covers can

INFRINGEMENT OF COPYRIGHT [For U.K. model]

Recording and playback of copyrighted material may require consent. See the Copyright Design and Patent Act 1988.

CAUTION

This product contains a laser diode of higher class than 1. To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel. The following caution label appears on your unit. Location: Rear of the unit.

CLASS 1 LASER PRODUCT

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion-and, most importantly, without affecting your sensitive hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

÷ Start your volume control at a low setting. ÷ Slowly increase the sound until you can hear it comfortably and

clearly, and without distortion.

Once you have established a comfortable sound level:

÷ Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association’ s Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise. This list of sound levels is included for your protection.

Decibel Level Example

30 Quiet library, soft whispers 40 Living room, refrigerator, bedroom away from traffic 50 Light traffic, normal conversation, quiet office 60 Air conditioner at 20 feet, sewing machine 70 Vacuum cleaner, hair dryer, noisy restaurant 80 Average city traffic, garbage disposals, alarm clock

at two feet.

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE

90 Subway, motorcycle, truck traffic, lawn mower 100 Garbage truck, chain saw, pneumatic drill 120 Rock band concert in front of speakers, thunderclap 140 Gunshot blast, jet plane 180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

Page 5

Contents

1 Before You Start

Feature of the PDR-609 CD recorder ...................................... 6

Checking what’s in the box..................................................... 6

Using this manual................................................................... 6

Hints on installation ............................................................... 6

Putting the batteries in the remote control ............................ 7

Avoiding condensation problems ....................................... 7

Care and maintenance ............................................................ 7

Cleaning external surfaces ................................................. 7

Moving the unit .................................................................. 7

Storing optical cable .......................................................... 7

Handling discs .................................................................... 7

Storing discs ....................................................................... 8

Discs to avoid ...................................................................... 8

CD lens cleaner ................................................................... 8

About CD, CD-R and CD-RW discs .......................................... 8

Playback-only CDs ............................................................. 8

CD-Recordable discs ........................................................... 8

CD-Rewritable discs ............................................................ 8

Consumer-use discs ............................................................ 8

Recording and finalizing discs .......................................... 9

Recording copyright material ............................................ 9

2 Connecting Up

Connecting up for digital playback & recording.................. 10

About optical and coaxial jacks ....................................... 10

Using the digital inputs .................................................... 10

Using the digital outputs .................................................. 10

CD text compatible components ...................................... 10

Connecting up for analog playback & recording ................. 11

Connecting other Pioneer Î components .................... 11

3 Controls and Displays

Front panel ............................................................................ 12

Remote control ...................................................................... 13

Display ................................................................................... 14

4 Getting Started

Switching on for the first time .............................................. 15

Selecting tracks directly......................................................... 16

Using the menu features ....................................................... 16

Showing CD text information ............................................... 16

Showing disc information..................................................... 17

Introduction to CD recording................................................ 17

Digital recording restrictions ........................................... 17

Recording modes .............................................................. 18

Miscellaneous information .............................................. 18

Digital recording from DAT.............................................. 18

Digital signal interruptions.............................................. 18

Power interruptions .......................................................... 18

Recording one track from a source ...................................... 19

Recording all tracks from a source ....................................... 20

Automatically recording and finalizing a disc ..................... 21

Manual recording.................................................................. 22

Setting the digital recording level ......................................... 23

Setting the analog recording level ........................................ 24

Setting the balance ................................................................ 25

Finalizing a disc .................................................................... 26

5 More Playback Features

Programming the track order ............................................... 27

Clearing the playlist ......................................................... 27

Clearing a track from the playlist .................................... 27

Checking what's in the playlist ........................................ 27

Replacing a track in the playlist ...................................... 27

Playing tracks at random...................................................... 28

Repeating tracks .................................................................... 28

Fading in and fading out ...................................................... 28

Playing a disc with skip IDs .................................................. 28

Skipping unwanted tracks..................................................... 29

Setting skip IDs ................................................................. 29

Clearing skip IDs .............................................................. 29

6 More Recording Features

Using CD text ......................................................................... 30

Editing CD text ................................................................. 31

Copying track names to other tracks .................................... 32

Automatically numbering tracks .......................................... 33

Manually numbering tracks ................................................. 33

Starting tracks in time increments ....................................... 34

Recording fade ins and fade outs.......................................... 34

Setting the fade length .......................................................... 34

Recording a fade in ............................................................... 34

Recording a fade out ............................................................. 34

Recording blank sections ...................................................... 35

Checking what's at the end of a disc .................................... 35

Monitoring a source .............................................................. 36

Checking for digital copy protection..................................... 36

Erasing a CD-RW disc ........................................................... 37

When a non-finalized disc is loaded................................ 37

When a finalized disc is loaded ........................................ 38

Reinitializing a disc ......................................................... 38

7 Additional Information

Understanding display messages .......................................... 39

Troubleshooting .................................................................... 40

Display messages relating to playback ............................ 40

Display messages relating to recording ........................... 41

Specifications......................................................................... 43

English

Page 6

1 Before you start

Features of the PDR-609 CD recorder

Create your own audio CDs

At last, there's a convenient and affordable way to make your own audio CDs. Create your own original recordings, or put together compilations of your favorite tracks from your existing CDs. Other uses include making high-quality recordings from radio or satellite broadcasts, and making personal copies of CDs, MDs, etc. to keep in the car, keeping the originals safe at home. The CD text feature of the PDR-609 allows you put text information on your recordings to easily identify and select from the contents.

Make digital recordings from any source

The PDR-609 can accept digital input via optical or coaxial cable, meaning that you can connect it to almost any other digital audio component. Also, thanks to the built in sampling rate converter, you can make direct digital recordings from satellite (usually 32kHz), DCC and DAT (up to 48kHz), as well as CD and MD (both 44.1kHz). A sampling rate converter ‘through’ feature (for 44.1kHz sources only) enables you to record HDCD and DTS encoded CDs too. Analog sources are also catered for with the analog line inputs, suitable for connection to standard audio components such as cassette decks and turntables.

Use both ordinary recordable CDs and rewritable CDs

Ordinary recordable CDs (CD-R) can be recorded on just once, but the relatively cheap cost of blank discs and the ability to play the recorded discs on any ordinary CD player* make them ideal for many applications. Compact Disc Rewritable, or CD-RW, is a more recent type of recordable CD that allows erasing and re-recording of the disc. Although the blank discs are more expensive, this ability to use the discs over and over gives them the edge in terms of flexibility over CD-R**.

* While most CD players should have no problems with

CD-R discs, if the laser pickup is dirty (from prolonged exposure to tobacco smoke, for example), the player may not be able to read some CD-R discs.

** At the time of writing, most ordinary CD players cannot play CD-RW discs. Check in the instructions that came with the player for

compatibility.

Checking what’s in the box

Make sure that you’ve received the following supplied accessories with your PDR–609 CD Recorder:

1 Two sets of audio cords

2 AC power cord

• Also included in the box is your warranty card and this instruction manual.

3 Two ‘AA’ size R6P batteries

4 Remote control unit

Using this manual

This manual is for the PDR–609 CD Recorder. It is split into two sections: the first shows how to set up the CD recorder; the second takes you through each stage of operation. Set up, which starts here, shows you how to get your new CD recorder up and running with the rest of your stereo system.

In the second section of the manual, starting on page16, you’ll learn how to use the various features of the recorder. The final part of the manual provides reference information on display messages you might encounter during use, a troubleshooting section, and technical specifications.

Hints on installation

We want you to enjoy using the PDR–609 for years to come, so please bear in mind the following points when choosing a suitable location for it:

Do...

✔ Use in a well-ventilated room. ✔ Place on a solid, flat, level surface, such as a table, shelf or

stereo rack.

Don’t...

✘ Use in a place exposed to high temperatures or humidity,

including near radiators and other heat-generating appliances.

✘ Place on a window sill or other place where the player will

be exposed to direct sunlight.

✘ Use in an excessively dusty or damp environment. ✘ Place directly on top of an amplifier, or other component

in your stereo system that becomes hot in use.

✘ Use near a television or monitor as you may experience

interference—especially if the television uses an indoor antenna.

✘ Use in a kitchen or other room where the player may be

exposed to smoke or steam.

✘ Place on an unstable surface, or one that is not large

enough to support all four of the unit’s feet.

Page 7

1 Before you start

Putting the batteries in the remote control

• Turn over the remote control, then press and slide the battery compartment cover off.

• Put in the batteries supplied, taking care to match the plus and minus ends of each battery with the markings inside the compartment.

• Slide the cover back on, and your remote is ready for use.

Caution!

Incorrect use of batteries can result in hazards such as leakage and bursting. Please observe the following:

• Don’t mix new and old batteries together

• Don’t use different kinds of battery together—although they may look similar, different batteries may have different voltages.

• Make sure that the plus and minus ends of each battery match the indications in the battery compartment.

• Remove batteries from equipment that isn’t going to be used for a month or more.

• When disposing of used batteries, please comply with governmental regulations or environmental public institution’s rules that apply in your country or area.

English

Avoiding condensation problems

Condensation may form inside the player if it is brought into a warm room from outside, or if the temperature of the room rises quickly. Although the condensation won’t damage the player, it may temporarily impair its performance. For this reason you should leave it to adjust to the warmer temperature for about an hour before switching on and using.

Care and maintenance

Cleaning external surfaces

To clean the compact disc recorder, wipe with a soft, dry cloth. For stubborn dirt, wet a soft cloth with a mild detergent solution made by diluting one part detergent to 5 or 6 parts water, wring well, then wipe off the dirt. Use a dry cloth to wipe the surface dry. Do not use volatile liquids such as benzene and thinner which may damage the surfaces.

Moving the unit

If you need to move the unit, first switch it off and unplug from the wall outlet. Never lift or move the unit during playback or recording—the disc rotates at a high speed and may be damaged.

Handling discs

When holding CDs of any type, take care not to leave fingerprints, dirt or scratches on the disc surface. Hold the disc by its edge or by the center hole and edge. Damaged or dirty discs can affect playback and/or recording performance. Take care also not to scratch the label side of the disc. Although not as fragile as the recording side, scratches can still result in a disc becoming unusable.

Should a disc become marked with fingerprints, dust, etc., clean using a soft, dry cloth, wiping the disc lightly from the center to the outside edge. If necessary, use a cloth soaked in alcohol, or a commercially available CD cleaning kit to clean a disc more thoroughly. Never use benzine, thinner or other cleaning agents, including products designed for cleaning vinyl records.

Wipe lightly from the center of the disc using straight strokes.

Don’t wipe the disc surface using circular strokes.

Storing optical cable

When storing optical cable, coil loosly as shown at right. The cable may be damaged if bent around sharp corners.

+ than =

5-14/16 in

(15 cm)

Page 8

1 Before you start

Storing discs

Although CD, CD-R and CD-RW discs are more durable than vinyl records, you should still take care to handle and store discs correctly. When you're not using a disc, return it to its case and store upright. Avoid leaving discs in excessively cold, humid, or hot environments (including under direct sunlight).

When labeling discs, use a felt-tip pen sold for marking CDs. Don't glue paper or put stickers onto the disc, or use a pencil, ball-point pen or other sharp-tipped writing instrument. These could all damage the disc.

For more detailed care information see the instructions that come with discs.

Discs to avoid

CDs spin at high speed inside the player during playback and recording. If you can see that a disc is cracked, chipped, warped, or otherwise damaged, don't risk using it in your CD recorder or player—you could end up damaging the unit.

The PDR–609 is designed for use with conventional, fully circular CD’s only. Use of shaped CD’s is not recommended for this product. Pioneer disclaims all liability arising in connection with the use of shaped CD’s.

CD lens cleaner

The compact disc recorder's pickup lens should not become dirty in normal use, but if for some reason it should malfunction due to dirt or dust, consult your nearest Pioneer authorized service center. Although lens cleaners for compact disc recorders are commercially available, we do not recommend using them since some may damage the lens.

About CD, CD-R and CD-RW discs

The PDR–609 is compatible with three types of compact disc:

Playback-only CDs

This unit will playback any ordinary audio CDs carrying the Compact Disc Digital Audio mark shown right.

CD-Recordable discs

Recordable CDs, or CD-R, carry the mark shown right, and are 'write once'. This means that having recorded something on the disc it is permanent—it can't be re-recorded or erased.

CD-Rewritable discs

Rewritable CDs, or CD-RW, carry the mark shown right. As the name indicates, you can erase and re-record material on these discs so that they can be used over and over again.

CD TEXT discs

CD Text discs, carry the mark shown right. These are commercially available discs that will display the disc title, artist name, and

track titles of the disc when played in a CD text compatible player.

Consumer-use discs

The PDR–609 is only compatible with special consumer-use CD-R and CD-RW discs. These are clearly marked For

Music Use Only, For Consumer, or For Consumer Use. Other types of CD-R or CD-RW discs, such as

those available for computer-based CD recorders, will not work with this recorder.

Pioneer has checked the following branded discs for compatibility with this recorder (as of May 2000):

• Eastman Kodak Company

• Fuji Photo Film Co., Ltd.

• Hitachi Maxell, Ltd.

• Mitsui Chemicals, Inc.

• Sony Corporation

• Ritek Corporation

• Taiyo Yuden Co., Ltd.

• TDK Corporation

• Verbatim Corporation

• Pioneer Corporation Sample discs from the following makers have also been

checked for compatibility (as of May 2000):

• Mitsubishi Chemical Corporation*

• Ricoh Company, Ltd.* * At the time of writing, discs branded under these names are

not available. Note: Discs from all of the above makers may also be sold

under different brand names.

Page 9

1 Before you start

Recording and finalizing discs

Unlike other recording media, recordable CDs have a number of distinct states, and what you can do with a disc depends on the current state of the disc. The figure below shows the three states—blank, partially recorded, and finalized—and

summarizes what’s possible (✔) and impossible (✘) in each.

CD-R

Recordable

✔ ✘

Erasable

✘

Skip ID set/clear

✘

Plays in ordinary CD player

Recordable

✔ ✘

Erasable

✔

Skip ID set/clear

✘

Plays in ordinary CD player

Recordable

✘ ✘

Erasable

✘

Skip ID set/clear

✔

Plays in ordinary CD player

Recording

CD-R

Finalization

Recordable

✔ ✘

Erasable

✘

Skip ID set/clear

✘

Plays in ordinary CD player

Recordable

✔ ✔

Erasable

✔

Skip ID set/clear

✘

Plays in ordinary CD player

Recordable*

✘ ✔

Erasable

✘

Skip ID set/clear*

✘

Plays in ordinary CD player**

* Once the CD-RW has been erased, it becomes recordable

again and skip IDs can be set and cleared.

** In general, current CD players cannot play CD-RW discs.

However, this situation may change.

The process of finalization fixes the contents of a CD-R in place for good by creating a Table of Contents (TOC, for short) at the beginning of the disc which tells other players exactly what's on the disc and where to find it. See Finalizing a disc on page 42 for more on finalization.

CD-RW

FINALIZE

Recording copyright material

The price of a consumer-use disc includes a copyright fee that has been paid to the copyright owner (in countries where the copyright fee collection system has been established based on their respective copyright laws). This means that you can use these discs to record music and other material for your personal use. If you want to use a disc for anything other than personal use, you must get permission from the copyright owner (note that copyright laws vary from country to country; check the copyright-related laws in your particular country for more information).

Broadcast programs, CDs, other recorded media (cassettes, vinyl records, etc.) and musical performances are all protected by copyright laws. You must get permission from the copyright owner if you sell, transfer, distribute or lease a disc recorded from the above mentioned sources, or if you use it as part of a business (such as for background music in a store).

Keep in mind the following when using the remote control unit:

• Make sure that there are no obstacles in between the remote and the remote sensor on the unit.

• Use within the operating range and angle, as shown in the diagram below.

• Remote operation may become unreliable if strong sunlight or fluorescent light is shining on the unit’s remote sensor.

• Remote controllers for different devices can interfere with each other. Avoid using remotes for equipment located near this unit while using the PDR–609.

• Replace the batteries when you notice a fall off in the operating range of the remote.

English

23ft. (7m)

Page 10

2 Connecting up

PDR–609 CD-Recorder

LINE

REC

PLAY

OUT

L R

TEXT

CONTROL

DIGITAL IN

OPTICAL COAXIAL OPTICAL COAXIAL

DIGITAL OUT

AC IN

Choose either the coaxial or the optical connector.

CONTROL

OPTICAL COAXIAL

DIGITAL OUT

Digital playback component (CD, MD, DAT player, etc.)

Before making or changing the connections, switch off the power and disconnect the power cord from the AC outlet.

Note: It is not possible to daisy-chain several units together for digital duplication.

Connecting up for digital playback & recording

The diagrams on these pages show possible connections with various other components in your system. Before you start connecting your system, make sure that all the components are switched off and disconnected from the wall outlet.

About optical and coaxial jacks

The PDR–609 has both optical and coaxial jacks for both digital input and output. There’s no need to connect both, but since some equipment has only one type of connector—and you can only connect like with like—having both on this unit can be an advantage.

To use the optical jack, you’ll need an optical cable. These are readily available at audio dealers. When buying, check that the cable is no longer than 3m.

Pull out the dust cap and store it in a safe place for future use. Check that both optical plug and socket are free from dust—if necessary, clean with a soft, dry cloth. The optical lead will only go in one way, so match up the jack and the plug before inserting fully.

When connecting optical leads, take care not to bend the

OPTICAL COAXIAL

DIGITAL IN

Digital recording component (CD-R, MD, DAT recorder, etc.)

cable around sharp corners as this can damage the cable. Likewise, when storing optical cable, coil loosely (as shown on page 8).

If you’re using one of the coaxial-type digital connectors you’ll need a lead with an RCA/phono plug at each end (the same type of connector as the Video cable).

Using the digital inputs

To make direct digital recordings on the PDR–609 you’ll need to connect the digital output of a source (like a CD, MD, or DAT player) to one of the digital inputs on this unit. To make recordings from analog sources (like a turntable or cassette deck) it’s usually easiest to connect this player to your amplifier/ receiver’s tape inputs and outputs—see page 15 for more on this.

Using the digital outputs

If you have another digital recorder, such as a MD or DAT recorder, you might want to use the PDR–609 as a digital source. In this case, connect one of the digital outputs of the PDR–609 to a similar digital input on your other digital recorder.

CD text compatible components

If you wish to record CD text as well as audio information from an external CD player (compatible with CD text), you must connect the CONTROL IN on the unit to the

CONTROL TEXT jack on the PDR-609 using a commer-

cially available cord with a mono mini-plug. At the time of writing, the Pioneer PD-F1009 is the only CD player that can perform this operation.

Note: Make sure that at least one set of analog terminals is connected to the amplifier when using CD text control cords.

Page 11

2 Connecting up

English

LINE

REC

PLAY

OUT

MD/TAPE

INPUTOUTPUT

PLAYREC

CONTROL

DIGITAL IN

TEXT

OPTICAL COAXIAL OPTICAL COAXIAL

OUT

CONTROL

DIGITAL OUT

AC IN

Connecting up for analog playback & recording

Before you start, make sure that all the components are switched off and disconnected from the wall outlet.

Next, connect this unit to your amplifier/receiver using the two sets of supplied audio leads—one set for playback, the other for recording. On the rear panel of your amplifier find an unused set of inputs/outputs for a tape/md recorder (check the instruction manual that came with your amplifier if you’re unsure about which terminals to use).

Using this set up you can make recordings from any other component connected to the amplifier, via the analog inputs of this unit.

Connecting other Pioneer Î components

If you are using a Pioneer amplifier or receiver that has this feature, you can control this unit with the multi-remote controller that came with your amplifier/receiver. The advantage of this is that you can use a single remote control to operate several components. Check the instruction manual that came with your amplifier or receiver for more information on using its remote as a multi-controller.

Use a commercially available cord with a mono mini-plug at either end to connect the CONTROL OUT terminal of the amplifier/receiver to the CONTROL IN terminal of this unit.

Note: Make sure that at least one set of analog terminals is connected to the amplifier when using Î control cords.

POWER-CORD CAUTION

Handle the power cord by the plug part. Do not pull out the plug by tugging the cord, and never touch the power cord when your hands are wet, as this could cause a short circuit or electric shock. Do not place the unit, a piece of furniture, or other object on the power cord or pinch the cord in any other way. Never make a knot in the cord or tie it with other cords. The power cords should be routed so that they are not likely to be stepped on. A damaged power cord can cause a fire or give you an electric shock. Check the power cord once in a while. When you find it damaged, ask your nearest Pioneer authorized service center or your dealer for a replacement.

Page 12

3 Controls and Displays

12345 678910

◊ÛB->?/

AUTO

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

AUTO

FINALIZEERASE

MANUAL

11 1 2 1 3 14 15 16 17 18 19 2 0 21 2 2 2 3 2 4

Front panel

1 POWER switch (p.15)

Switches power to the unit on and off.

2 SCROLL (p. 16)

Press to scroll through long names in CD text.

3 TIME (p.17)

Switches the display mode (elapsed track time, remaining track time, total disc playing time, etc.)

4 DISPLAY/CHARA (p.16,30)

Press to switch between display modes (disc title, artist name, track title) (p.16), and between upper- and lower-case characters while using CD text (p.30).

5 MONITOR (p.23-25,36)

Press to monitor the selected input and display digital source information.Indicator lights up to remind you when you are monitoring.

6 OPEN/CLOSE 0 (p.15)

Press to open or close the disc tray.

7 RECORD ¶ (p.22–25)

Press to enter record-pause mode for setting input levels, etc.

8 REC MUTE • (p.35)

Records a blank section on a disc (for space between tracks, etc.)

9 DIGITAL REC LEVEL / 4 ¢ (Jog dial)

Turn the jog dial to: set the digital recording level (p.23); skip tracks (p.15); select options in the menu (p.23,25,33-35); cycle through characters in CD text (p.30); select tracks to erase (p.38-39).

Push the jog dial to: start playback (stop mode only) (p.15); input track numbers (during programming) (p.27); select characters in CD text (p.30); confirm menu settings (p.16).

10 ANALOG REC LEVEL (p.24)

Sets the recording level for analog-input recording.

11 ERASE (p.38–39)

Press to start erasing tracks, or to re-initialize a disc.

MONITOR

SELECTOR

COMPACT DISC DIGIT AL RECORDER

ANALOG

REC BALANCE

INPUT

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

12 FINALIZE (p.26)

Press to start the disc finalization process (to make recordable CDs playable on ordinary CD players). Indicator lights up during finalization.

13 AUTO/MANUAL (p.33–34)

Switches between automatic and manual track numbering when recording a disc.

14 INPUT SELECTOR (p.19–24,37)

Switches between the analog, optical digital and coaxial digital inputs.

15 Remote sensor (p.9) 16 Character display (p.14) 17 1 ¡ / REC BALANCE (p.15,25,30)

Press and hold for fast-reverse and fast-forward playback (p.15). Use when recording to set left and right input levels (p.25).Use to move cursor back and forth across character display while using CD text (p.30).

18 6 (p.15,19-22)

Press to play, pause, or resume playing, a disc. Also use to start recording from record-pause mode.

19 NAME (p.30–32)

Use to cycle through CD text naming options.

20 7 (p.16,19–22)

Press to stop playback or recording.

21 SYNCHRO (p.19–21)

Press to start recording on detection of an input signal.

22 MENU/DELETE (p.16,23,25,30,33,35)

Press to cycle through the preference menu options(p.16, 23, 25,33,35). Press to delete characters while editing CD text (p.30).

23 PHONES jack

Plug in a pair of stereo headphones for private listening or monitoring.

24 LEVEL

Use to adjust the phones volume.

Page 13

3 Controls and Displays

Remote control

1 • REC MUTE (p.35)

Records a blank section on a disc (for space between tracks, etc.)

2 ¶ REC (p.22–25)

Press to enter record-pause mode.

3 TIME (p.17)

Switches the display mode (elapsed track time, remaining track time, total disc playing time, etc.)

4 DISPLAY/CHARA

Press to switch between display modes (disc title, artist name, track title) (p.16), and between upper- and lower-case characters while using CD text (p.30).

5 SCROLL (p.16)

Press to scroll through long names in CD text.

6 MARK / 10/0

Press to choose symbol characters when using CD text. As a numeric key, this represents zero.

7 MENU/DELETE (p.16,23,25,30,33,35)

Press to cycle through the preference menu options. Press to delete characters while editing CD text.

8 4 (p.15)

Press to skip backward tracks. Also performs those operations assigned to turning the jog dial (see page 12).

9 Playback control (p.15–16,19–22) / ENTER

3 Press to play, or resume playing, a disc. 1 and ¡Press and hold for fast-reverse and fast-

forward playback, and to move cursor position using CD text.

7 Press to stop playback or recording. ENTER Confirm playback, recording, menu settings (p.16),

and characters in CD text (p.30).

10 ø

Press to skip backward index points.

11 RANDOM (p.28)

Press to start random playback.

12 REPEAT (p.28)

Use to set the repeat mode (current track, disc, or repeat off).

13 PROGRAM (p.27)

Use to program the playback order of tracks on a disc.

14 FADER (p.28,34)

Press to fade in or fade out during playback or recording.

11 12 13

1 2

5 6

7 8

•

TIME

DISPLAY /CHARA

SCROLL

MENU/

DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

15 SKIP PLAY (p.28)

16 SKIP ID SET (p.29)

REC SYNCHRO

AB C D EF

1 2 3

GH I M NOJK L

5 6

PQ RS TU V WXY Z

7 8

10/0 >10

CURSOR

¡

ENTER

PROGRAM CHECK CLEAR

SKIP ID

CLEAR

SET

AUTO/

MANUAL

NAMEMARK

¢

NPUT

SELECTER

Î

18 19

24 25 26

27 28

17 SKIP ID CLEAR (p.29)

18 SYNCHRO (p.19–21)

19 AUTO/MANUAL (p.33–34)

20 Number / Letter buttons

21 NAME (p.30–32)

Use to cycle through CD text naming options.

22 >10 (p.16,27)

Use to select track numbers over 10.

23 ¢ (p.15)

Press to skip forward tracks. Also performs those operations assigned to turning the jog dial (see page 12).

24 Ø

Press to skip forward index points.

25 NAME CLIP (p.32)

Press to copy the current CD text to the recorder’s memory.

26 8 (p.15,22)

Press to pause playback or recording.

27 CHECK (p.27)

Press repeatedly to step through the program playlist.

28 CLEAR (p.27)

Press to clear the last track in a programmed playlist.

29 INPUT SELECTOR (p.19–24,37)

Switches between the analog, optical digital and coaxial digital inputs.

English

Press to switch skip play on and off.

Instructs the player to skip a particular track on playback.

Clears the above setting.

Press to start recording on detection of an input signal.

Switches between automatic and manual track numbering when recording a disc.

(p.16,27,30)

Use to jump directly to track numbers for playback, selecting track numbers for editing / programming, and selecting letters when using CD text.

Page 14

3 Controls and Displays

312 456 7 8910

TOTAL

REMAIN

TIME

DISC TRACK ARTST

ANALOG OPTICAL

COAXIAL

TRK INDEX MIN SEC

50 32 18 12 6 2 0dBOVER

Display

1 CD text indicators(p.16)

DISC Lights up when disc information is displayed. TRACK Lights up when track information is displayed. ARTST Lights up when artist information is displayed.

2 TOTAL / REMAIN / TIME (p.17)

Indicates whether the current displayed time is elapsed, remaining, or total time for a disc or individual tracks.

3 Message/time display

4 FADER (p.28,34)

Blinks during fade in or fade out.

5 3 (p.15–16) Lights up during playback.

8 (p.15,22) Lights during play- or record-pause.

6 REC (p.22–25,34)

Lights up to when recording or record-paused. Blinking display indicates record muting.

7 CD TEXT (p.15,30,31)

Lights if the CD currently loaded contains CD text.

8 CD / CD–R / CD–RW (p.15)

Indicates the type of disc currently loaded.

9 FINALIZE (p.21,26)

Lights up if the CD-RW currently loaded has been finalized. Also blinks during automatic finalization recording (p.21,26).

10 SYNC / SYNC-1 (p.19–21)

Lights up when the recorder is in automatic synchro recording mode.

11 AUTO TRK (p.33)

Lights when automatic track numbering is on during recording.

12 MANU TRK (p.34)

Lights up when manual track numbering is on during recording.

CD TEXT

CD-RW

FINALIZE SYNC-1

FADER

AUTO TRK MANU TRK

SKIP ON

VOL

RPT-1

PGM RDM

13 SKIP ON (p.28)

Lights up to indicate that a disc contains skip IDs. When setting or clearing skip IDs, the word SKIP blinks.

14 PGM (p.27)

Lights up when program-play is active.

15 RDM (p.28)

Lights up when random-play is active.

16 RPT / RPT-1 (p.28)

Lights up when repeat play is active.

17 Recording level balance (p.16,23,25)

Displays the digital recording volume. If the balance has been changed, the indicator (L or R) of the louder channel lights up. Both indicators light when the balance is unchanged. Track numbers are displayed while using CD text.

18 OVER indicator (p.24)

Indicates that the input signal overloaded the disc during recording.

19 Recording level meter (p.19–24)

Displays the input level during recording, or the recorded level during playback.

20 ANALOG (p.19–24,37)

Lights when the analog input is selected.

OPTICAL (p.19–24,37)

Lights when the optical digital input is selected.

COAXIAL (p.19–24,37)

Lights when the coaxial digital input is selected.

1112131415161719 1820

Page 15

4 Getting Started

5,6

8 7 9

7105,6

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

SET

SCROLL

ANALOG

REC BALANCE

DIGITAL

REC LEVEL

PUSH ENTER

CURSOR

ENTER

SKIP ID

◊ÛB->?/

TEXT

ABC DEF

¡

CLEAR

TIME

FINALIZEERASE

REC LEVEL

PUSH ENTER

MENU/

DELETE

SYNCHRO

CD TEXT

AUTO/

MANUAL

NAMEMARK

¢

NPUT

SELECTER

Î

AUTO

MONITOR

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

DIGITAL

Legato Link Conversion

ANALOG

REC LEVEL

8 7 9 6

Switching on for the first time

The next few pages take you through switching on the PDR–609, playing discs, and doing some basic recording. Before proceeding with this section you should have at least connected your recorder to an amplifier. (If you haven't, turn to pages 10–11 for more on connecting the PDR– 609 to other components in your system.)

1 Switch the POWER to _ON.

The record indicator flashes, and the main display panel lights up.

• Also make sure that your amplifier is switched on and the input function set to the PDR–609.

2 Press OPEN/CLOSE 0 to open

the disc tray.

3 Load a pre-recorded audio CD.

Place the disc in the disc tray label-side up.

• The disc tray has guides for both CD singles (8cm) and regular CDs (12cm). Do not use an adaptor when playing CD singles: it could damage the recorder.

• Never load more than one disc at a time.

4 Press OPEN/CLOSE 0 to close

the disc tray.

Once the recorder has found out what is on the disc, the display will show track and disc information or, depending on the disc, CD text.

If the disc does not contain CD text, you should see a display that looks something like this:

Number of tracks on disc

Total playing time of disc

O3 45:37

Indicates a pre-recorded disc

• Pressing 3 (6 on the front panel) will also close the disc tray (but you won’t see the above display).

If the disc contains CD text, the CD TEXT indicator lights up and the entire disc title automatically scrolls across the display. The first 12 characters of the disc title remain, as seen in the display below:

CD TEXT

BEST CLASSIC

You can switch CD text information displays by pressing DISPLAY/CHARA.

See page 16 for more on CD text displays.

Pressing TIME allows you to switch to the disc and track time information displays.

See page 17 for more on time displays.

5 Press 3 to start the disc

playing.

Pressing 6 or the jog dial on the front panel also starts playback.

6 To pause playback, press 8 (or

6 again).

To resume playback, press either 8 again, or 3 (6). The recorder only remains paused for 10 minutes, then it stops.

7 To fast-reverse or fast-forward,

press and hold 1 or ¡.

8 To skip back or forward to

another track, press 4 or ¢ (on the front panel, turn the jog dial).

Pressing ¢ once skips to the start of the next track on the disc. Further presses take you to subsequent tracks.

Pressing 4 once takes you to the beginning of the current track. Further presses skip to the start of previous tracks.

You can use 4 or ¢ while the disc is paused or stopped as well. The track number changes while the disc remains paused/stopped.

9 To skip back or forward index

markers, press ø or Ø on the remote control.

Because most CDs don’t have index markers, you will generally see 01 in the index display for each track.

10 To stop playback, press 7.

Take out the CD from the disc tray before switching off the unit.

English

Page 16

4 Getting Started

Number buttons

REC SYNCHRO

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

10/0 >10

CURSOR

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SET

CLEAR

AUTO/

MANUAL

NAMEMARK

¢

¡

NPUT

SELECTER

Î

•

TIME

DISPLAY /CHARA

SCROLL

MENU/ DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

DISPLAY/CHARA

Selecting tracks directly

If you want to start directly from a track other than the first, just enter the track number from the remote control. If you do the same thing during playback, the recorder immediately jumps to that track on the disc.

• While a disc is stopped, paused or playing, enter the track number you want to play.

The recorder jumps directly to that track. If the recorder was stopped, the track then starts playing.

For track numbers 1 to 10, use the corresponding number button.

For track numbers over 10, press the >10 button, then enter the track number. For example, to select track 28:

TUV

ABC

>10

Showing CD text information

If the CD contains text information, you can see this in the display during both playback and when the disc is stopped. The DISPLAY/CHARA button switches between the different text displays. When a disc with text is loaded into the recorder, the entire disc title automatically scrolls across the display. The first 12 characters of the disc title remain. Press SCROLL at any time to see the full title scroll across the display.

• During playback, press DIS-

PLAY/CHARA to switch the display.

There are three different displays. Press

DISPLAY/CHARA repeatedly to switch

between them:

BEST CLASSIC

Disc name

◊ÛB->?/

AUTO

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

AUTO

FINALIZEERASE

MANUAL

DISPLAY/CHARA

•

REC SYNCHRO

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

CLEAR

¡

MANUAL

SELECTER

AUTO/

NAMEMARK

NPUT

MONITOR

INPUT

SELECTOR

¢

Î

Using the menu features

Several features of the CD recorder can be accessed by using the MENU/DELETE key. This menu is like a selection of preferences that will stay in memory even if the system is turned off (see note below).The jog dial cycles you through the features listed below (refer to the page numbers listed to set your preferences in the menu).

• Digital volume (p.23)

• Balance (p.25)

• Silence threshold for auto track numbering (p.33)

• Time increment recording (p.35)

• Fade length (p.35)

Note: The time increment will default to

OFF when: recording is stopped; auto track

numbering is turned off; power is switched off.

Mozart3rd Movement

Artist nameTrack name

• While stopped, press DISPLAY/

CHARA to switch the display.

There are two different displays. Press

DISPLAY/CHARA repeatedly to switch

between them:

BEST CLASSIC

Disc name

Mozart

Artist name

Page 17

4 Getting Started

TIME

4 ¢

SCROLL

•

TIME

DISPLAY /CHARA

SCROLL

MENU/

DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

4 ¢

ANALOG

REC BALANCE

TEXT

TIME

◊ÛB->?/

AUTO

TIME

MANUAL

TRACK NO.

WRITE

AUTO

FINALIZEERASE

MANUAL

REC SYNCHRO

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

10/0 >10

CURSOR

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SET

CLEAR

DIGITAL

REC LEVEL

PUSH ENTER

MENU/ DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Showing disc information

The PDR-609 can display various kinds of disc and track information during both playback and recording. The TIME button switches between the different time display modes. Additionally, while stopped, individual track information is available from the track skip buttons (4 and ¢), or by turning the jog dial.

Introduction to CD recording

The PDR-609 is designed to let you make extremely high quality digital recordings onto recordable compact discs. For flexibility, you can use either rewritable discs (CD-RW) or write-once discs (CD-R). For more general information on the discs you can and can’t use with this recorder, see About CD, CD-R and CD-RW Discs on

English

page 10. The following 2-page overview

• During playback, press TIME to switch the display mode.

There are three different displays. Press

TIME repeatedly to switch between them:

gives you some idea of what the PDR-609 is capable of, and also provides guidance on what to avoid and things to be careful of when recording. We strongly recom-

mend that you read these pages fully

MANUAL

O2 O1 O2:16 O2 O1–O3:2O

Elapsed playback

MONITOR

INPUT

SELECTOR

time of current track

Remaining playing time of current track

ALL –46:4O

Remaining playing time of all tracks

• During recording, press TIME to switch the display mode.

There are two different displays. Press

AUTO/

TIME repeatedly to switch between them:

before proceeding to the more detailed instructions on the following pages.

Digital recording restrictions

This unit has been designed exclusively for recording and playback of audio discs— you can’t record other CD formats, such as computer CD-ROMs or Dolby Digital (AC-

3).

If you record from a disc format such as

NAMEMARK

¢

¡

NPUT

SELECTER

Î

O2 O1 O7:46

Elapsed recording time

• While stopped, press TIME to switch the display mode.

There are two different displays. Press

REC –56:14

Remaining recording time available*

TIME repeatedly to switch between them:

CD+graphics, Video-CD, or other format that includes both digital audio and video or text, you will only be able to record the audio part of the disc.

In addition to standard audio CDs, this recorder will record DTS encoded audio CDs and HDCD format CDs (in this case, the recording level must be set to 0dB).

Almost all commercial digital source

O9 45:37

Total disc time and number of tracks.

REC –28:23

Remaining recording time available*

material is protected by copyright laws. For this reason, the PDR-609 uses special consumer-use blank CD-R and CD-RW discs on which a copyright fee has already

ANALOG

REC LEVEL

* Although compatible with 80 minute

discs, the remaining recording time

been paid. A further restriction comes in the form of SCMS (an acronym for Serial Copy Management System).

display will not accurately show 80 minutes for blank discs.

Page 18

4 Getting Started

This generally allows just one generation of digital recording. In other words, you can make a digital recording from an original source (such as a commercial CD), but you can’t then make further digital recordings from that copy. Most digital recording equipment uses the SCMS system, including CD and MD recorders, and DAT decks. You may also find that you can’t record certain DVD discs as the digital output of the DVD player can be disabled by the disc.

Of course, if you do encounter SCMS or other digital-copy restrictions, you can always record through the analog inputs of the PDR-609. To check whether a source is digital-copy protected, see Checking for Digital Copy Protection on page

60.

Recording modes

The recorder is equipped with a set of analog input terminals, as well as both optical and coaxial digital inputs. This means that the PDR–609 is compatible with almost all audio sources—analog or digital. It even has a built in sampling rate converter making it ideal for recording DAT tapes or satellite broadcasts, for example, which are often at sampling rates different to that of CD. Since CDs are always recorded at a sampling rate of 44.1kHz, sample rate conversion is completely automatic—if the recorder senses a digital signal at either 32 or 48kHz, it will convert it to 44.1kHz. Note that this recorder can't convert 96kHz digital sources (such as some DAT tapes and DVD discs).

Miscellaneous information

• The minimum recordable time is four seconds.

• Usually, track numbers are recorded onto the disc automatically when recording. If you decide to switch off this feature (for example, when you’re recording from a satellite broadcast), be sure to input track markers as recording is taking place—you can’t add them after recording is complete. See pages 33 for more on manual and automatic track numbering.

• The maximum number of tracks on a disc is 99.

Digital recording from DAT

If you’re recording a DAT tape that was recorded using the DAT machine's auto ID function, the IDs on the tape are slightly after the beginning of the actual recording. This can cause problems for the CD recorder:

• The start of the track may not be recorded.

• The track number will be recorded on the disc after the start of the track.

• The beginning of the next track on the DAT is unintentionally recorded.

To avoid these problems, we recommend recording start IDs on the DAT manually, if possible. If this is not possible, or if there are no start IDs on the DAT, we recommend using manual track numbering while recording to CD to ensure that new tracks are starting in the right places. Refer to the instructions for your DAT recorder for more information.

You might also encounter problems if you try to synchrorecord all tracks from a DAT that is set to program play. If you want to record a DAT in program play mode, use the 1-track synchro recording mode—see pages 20 for how to do this.

Digital signal interruptions

Sources of signal interruption include power or source component failure, accidental disconnection of the interconnect cord, and interruption of digital satellite broadcasts. In all these cases, if the signal resumes within about five seconds, the result will just be a blank section on the disc. If the interruption is longer than five seconds, the recorder displays the error message: DIN UNLOCK and recording is paused.

Power interruptions

Never switch off the PDR-609 while it's recording, or while the display shows PMA REC (Program Memory Area Recording). If there's a power failure, or you accidently disconnect the power from the wall outlet while recording is in process, you'll lose at least part of the recording.

After recording, always remove the disc from the recorder before switching the power off. Failure to do this could result in you losing some of the recorded material on the disc.

Page 19

4 Getting Started

ANALOG

REC BALANCE

TEXT

SCROLL

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/ DELETE

10/0 >10

CURSOR

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

SET

CD TEXT

◊ÛB->?/

ENTER

SKIP ID

FINALIZEERASE

ABC DEF

CLEAR

DIGITAL

REC LEVEL

PUSH ENTER

MENU/ DELETE

SYNCHRO

Legato Link Conversion

AUTO

TIME

MANUAL

TRACK NO.

WRITE

AUTO

MANUAL

AUTO/

MANUAL

NAMEMARK

¢

¡

NPUT

SELECTER

Î

Recording one track from a source

If you want to record just a single track, or a few selected tracks, from a digital (CD, MD, DCC or DAT) or an analog source, the recorder can start and stop automatically. With digital recording, there's no need to worry about recording levels—you'll get a perfect digital copy of the original (if you want to change the digital recording level, see pages 23).

If you are recording from a noisy analog source, such as a vinyl record, or from a

ANALOG

REC LEVEL

MONITOR

INPUT

SELECTOR

source with long quiet sections, the recorder may not recognize the end of the track. In this case, we recommend using manual recording (see pages 22).

1 Load a CD-R or CD-RW disc.

Check the display to make sure that there's enough space on the disc for what you want to record.

2 Press INPUT SELECTOR to

choose an input.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

Synchro recording will not work if the source is already playing!

The SYNC-1 indicator will start to blink when the recorder is ready.

CD-R

SYNC

SYNC-1

-1

The display shows the 1-track sync mode, with the SYNC-1 indicator blinking to show that recording can start.

4 Play the source.

The recorder starts recording automatically.

5 The recorder pauses recording

after recording one track.

If you're recording a CD or MD, recording pauses automatically when the track changes or there is more than five seconds of silence on the source.

If you're recording from DCC or DAT tape, recording pauses when the recorder encounters a new start ID or there is more than five seconds of silence on the source. (See also Digital recording from DAT on page 18.)

If you're recording from analog, recording pauses automatically when there is more than two seconds of silence on the source.

English

The recorder's display indicates the current input.

3 Make sure that the source is not

playing, then press SYNCHRO.

Press SYNCHRO repeatedly to change the recoding mode:

1-track sync

SYNC–1

All-track sync

SYNC–ALL

All-track sync w/ finalization

SYNC–FINAL

Record-pause (no sync)

O1 O1 OO:OO

CD-R

SYNC-1

CD-R

SYNC

CD-R FINALIZE SYNC

CD-R

6 If you're done, press 7.

To record further tracks, simply repeat steps 3 to 5.

After pressing 7, the display shows PMA

while it records the track information

REC

to the disc.

Note: If you want to record CD text information, you must record the entire disc (See Automatically recording and finalizing a disk on page 21). Text will not be copied when you record an individual track.

If you find that synchro recording does not seem to work, see the troubleshooting section on pages 40–42for possible remedies.

Page 20

4 Getting Started

ANALOG

REC BALANCE

Recording all tracks from a source

If you want to copy all the tracks from a source, use this mode. Like the 1-track synchro recording mode, the recorder starts and stops automatically. When recording from MD or CD, you can play the source in either normal play mode, or program play if you’d like the recorded tracks in a different order to the original. We do not recommend recording from a DAT in program play mode—use the 1track synchro recording mode if you want

Synchro recording won't work if the source is already playing!

The recorder goes into all-sync record pause and the SYNC indicator starts to blink.

SYNC–ALL

The display shows the all-track sync mode, with the SYNC indicator blinking to show that recording can start.

4 Play the source.

The recorder starts recording automatically.

CD-R

SYNC

to record the tracks in a different order.

If you are recording from a noisy analog

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

source, such as a vinyl record, or from a source with long quiet sections, the recorder may not recognize the end of tracks. In this case, you can still use this mode, but it may be better to use manual

track numbering (see page 33).

1 Load a CD-R or CD-RW disc.

Check the display to make sure that there's enough space on the disc for what you want to record.

2 Press INPUT SELECTOR to

SCROLL

◊ÛB->?/

FINALIZEERASE

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

choose an input.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

The recorder's display indicates the current input.

5 After recording all tracks from

the source, the recorder goes into record-pause.

After the recorder encounters about five seconds of continuous silence, it assumes the end of the source has been reached and goes into record-pause and the display shows the SYNC ALL message again. Be careful: If the recorder detects another signal or start ID (DAT or DCC) it will start recording again!

• The recorder will enter record-pause if the digital signal is interrupted for more than 5 seconds—see Digital signal interruptions on page 18.

6 Press 7 to finish recording.

After pressing 7, the display shows PMA

while it records the track information

REC

to the disc.

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

MANUAL

ABC DEF

¡

SELECTER

CLEAR

AUTO/

NAMEMARK

¢

NPUT

Î

3 Make sure that the source is not

playing, then press SYNCHRO twice.

Press SYNCHRO repeatedly to change the recording mode:

1-track sync

SYNC–1

All-track sync

SYNC–ALL

CD-R

SYNC-1

CD-R

SYNC

Note: If you find that synchro recording does not seem to work, see the troubleshooting section on pages 40-42 for possible remedies.

All-track sync w/ finalization

CD-R FINALIZE

SYNC–FINAL

SYNC

Record-pause (no sync)

O1 O1 OO:OO

CD-R

Page 21

4 Getting started

ANALOG

REC BALANCE

TEXT

◊ÛB->?/

SCROLL

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

REC LEVEL

PUSH ENTER

MENU/ DELETE

SYNCHRO

CD TEXT

TIME

FINALIZEERASE

ABC DEF

CLEAR

DIGITAL

¡

ANALOG

REC LEVEL

Legato Link Conversion

AUTO

MONITOR

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

AUTO/

MANUAL

NAMEMARK

¢

NPUT

SELECTER

Î

Automatically recording and finalizing a disc

This is a variation on all-track synchro recording on the previous page. After all tracks on the source material have been recorded, the recorder automatically finalizes the disc.

You can also copy CD text digitally as long as: it has not been copy-protected by the manufacturer; the disc you want to copy is not in program-play mode; you use a completely blank CD-R.

1 Load a CD-R or CD-RW disc.

Check the display to make sure that there's enough space on the disc for what you want to record.

2 Press INPUT SELECTOR to

choose an input.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

The display indicates the current input.

3 Make sure that the source is not

playing, then press SYNCHRO three times.

Press SYNCHRO repeatedly to change the recording mode:

1-track sync

SYNC–1

All-track sync

SYNC–ALL

All-track sync w/ finalization

SYNC–FINAL

Record-pause (no sync)

O1 O1 OO:OO

Synchro recording won't work if the source is already playing!

The recorder goes into all-sync record pause and the SYNC and FINALIZE indicators start to blink.

SYNC–FINAL

CD-R FINALIZE SYNC

CD-R

SYNC-1

CD-R

SYNC

CD-R FINALIZE SYNC

CD-R

The display shows all-track sync with finalization, with the SYNC and

FINALIZE indicators blinking to show that

recording can start.

Note: If You want to record CD text information as well, press NAME after pressing SYNCHRO. The CD TEXT indicator will light.

4 Play the source.

Recording starts automatically. If you press SYNCHRO during recording, the recorder will finish recording without finalizing the CD-R.

5 After recording all tracks on the

source, the recorder starts finalizing the disc.

After the recorder encounters about five seconds of continuous silence, it assumes the end of the source has been reached and goes into all-sync record-pause. Be careful: If the recorder detects another signal or start ID (DAT or DCC) it will start recording again!

If the recorder detects no signal for one minute, finalization starts (no more recording is possible after this so make sure that there aren’t any spaces of more than one minute during the source you’re recording). See Automatically number- ing tracks on page 33 to set the silence threshold.

Finalization takes about two minutes, during which time none of the buttons are operative.

Never turn the power off during finalization!

• If a digital signal is interrupted, the recorder continues recording. However, if no signal has been detected within five seconds, the recorder pauses recording and will not finalize the disc—see Digital signal interruptions on page 18.

• If the recorder reaches the end of the disc, the recorder begins finalization.

Note: If you find that synchro recording does not seem to work, see the troubleshooting section on pages 40–42 for possible remedies.

English

Page 22

4 Getting started

ANALOG

REC BALANCE

Manual recording

Use the manual recording method with a source where syncho recording is not suitable. For example, if you are recording from either radio, or a digital satellite, synchro recording is not possible since there are no track numbers or start IDs to signal the start and end points of the

6 Restart playback of the source

material.

If the AUTO TRACK indicator is lit in the display then the recorder will start a new track each time it detects a sound after at least two seconds of continuous silence. (To switch off auto track numbering see Manually numbering tracks on page

33.)

recording. Manual recording is also useful with a noisy analog source, such as a vinyl

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

record, or from a source with long quiet sections, where the recorder may not recognize the end of tracks.

1 Load a CD-R or CD-RW disc.

Check the display to make sure that there's enough space on the disc for what you

7 When you're done, press 7 .

After pressing 7, the display shows PMA

while it records the track information

REC

to the disc.

want to record.

2 Press INPUT SELECTOR to

choose an input.

Pressing INPUT SELECTOR repeatedly switches the active input:

SCROLL

◊ÛB->?/

FINALIZEERASE

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

Analog - Optical - Coaxial

The recorder's display indicates the current input.

•

REC SYNCHRO

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

CLEAR

Î

AUTO/

MANUAL

TEXTMARK

¢

¡

NPUT

SELECTER

3 Press RECORD ¶ ( ¶ REC on

the remote control).

The recorder goes into record-pause.The (You can also press MONITOR.)

4 Start playing the source to

check it’s recordable.

With a digital source, if the source is copyprotected using SCMS, the message Can’t

COPY appears. In either case, you won't

be able to record digitally—use the analog

inputs instead.

If necessary, set the recording level (see pages 23).

If the signal appears OK, stop the source.

5 Check that the time display

reads 00:00, then press 8 or 3 (6 on the front panel) to start recording.

If you pressed MONITOR in step 3, you’ll need to press RECORD ¶ here, then 8 or 3 (6) to start recording.

Page 23

4 Getting started

4,6

3 5

SCROLL

ANALOG

REC BALANCE

•

TIME

DISPLAY /CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

◊ÛB->?/

AUTO

TIME

MANUAL

TRACK NO.

WRITE

AUTO

FINALIZEERASE

MANUAL

4,5,6

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

AUTO/

REC SYNCHRO

MANUAL

ABC DEF

123

GHI MNOJKL

NAMEMARK

CURSOR

¢

¡

ENTER

NPUT

SKIP ID

SELECTER

SET

CLEAR

Î

Setting the digital recording level

MONITOR

INPUT

SELECTOR

ANALOG

REC LEVEL

One of the advantages of digital-to-digital recording is that you don't have to set recording levels—and risk distortion by overloading the disc. If you're recording commercial material from CD or MD, the digital level has already been optimized and you don't need to change it. If you're making a digital copy of a CD, DAT or MD that was not commercially produced and that was consistently under-recorded, you can boost the overall level by up to +20dB. Remember though, that any peaks in the original recording run the risk of distorting the copy.

If you record digital satellite broadcasts, you may also have cause to boost the recording volume since the volume of some broadcasts is relatively low, but again, if there are any peaks in the

1 Make sure one of the digital

inputs is selected.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

The recorder's display indicates the current input.

2 Make sure the recorder is

stopped, then press RECORD ¶ ( ¶ REC on the remote control).

The recorder goes into record-pause. (You can also press MONITOR.)

3 Press MENU/DELETE.

4 Turn the jog dial until D. VOL

appears in the display, then press to ENTER.

If there is nothing connected to the selected digital input, the message DIN

UNLOCK

appears in the display. The display shows current digital recording level.

English

broadcast, you run the risk of momentary distortion.

It's also possible to reduce the digital recording volume, but in most cases, this is not desirable. However, if you're putting together a mix CD (various tracks compiled from different sources), and there is a track which stands out as

generally louder than the others, then you might want to reduce the level of that track. Note that this feature will not get rid of distortion on the source material.

Once changed, the new digital recording level remains until you change it again, or

5 Turn the jog dial or press 4

or ¢ on the remote control to adjust the recording level up or down.

• The maximum adjustment possible is

between MIN(silence) and +20dB.

• Pressing the jog dial (ENTER)and

holding for 3 seconds resets to OdB.

6 Press the jog dial (ENTER) to

confirm the digital recording level.

reset it. Each digital input has its own level which can be set independently.

NOTE: If you are recording DTS encoded

audio CDs or HDCD format CDs, the digital recording level must be set to 0.0dB for recording.

Page 24

4 Getting started

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Setting the analog recording level

Compared to analog tape, the distortion that you get from overloading a CD is much less tolerable, and something you’ll definitely want to avoid.

What you want to aim for is a level where the loudest sound from your source material is recorded onto the CD at a level just below the point where it overloads (where it produces an unpleasant, buzzy distortion).

1 Press INPUT SELECTOR to

choose the analog input.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

The recorder’s display indicates the current input.

2 Make sure the recorder is

ANALOG

REC LEVEL

stopped, then press RECORD ¶ ( ¶ REC on the remote control).

The recorder goes into record-pause. (You can also press MONITOR.)

3 Start playing the source.

4 Adjust the recording level using

the ANALOG REC LEVEL

AUTO/

•

REC SYNCHRO

MANUAL

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

CLEAR

NAMEMARK

¢

¡

NPUT

SELECTER

Î

control.

Don’t let the recording level to

reach the red OVER indicator!

50 32 18 12 6 2 0 OVER

The maximum recording level

should be in this area.

When you’re happy with the recording level, stop the source.

Page 25

4 Getting started

Setting the balance

English

You can increase the relative volume of the right or left channel for both recording and playback. However, It is generally not necessary to change the balance of a commercially recorded source.

SCROLL

◊ÛB->?/

FINALIZEERASE

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

1 Press INPUT SELECTOR to

choose an input.

Pressing INPUT SELECTOR repeatedly switches the active input:

Analog - Optical - Coaxial

The recorder’s display indicates the current

ANALOG

REC BALANCE

4,6

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

input.

2 Make sure the recorder is

stopped, then press RECORD ¶ ( ¶ REC on the remote control).

The recorder goes into record-pause. (You can also press MONITOR.)

3 Press MENU/DELETE.

4 Turn the jog dial until BALANCE

appears in the display, then press to ENTER.

4,6

3 5

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

AUTO/

MANUAL

ABC DEF

NAMEMARK

¡

SELECTER

CLEAR

NPUT

¢

Î

5 Adjust the balance using the

REC BALANCE buttons (1 and ¡).

You can adjust the balance from 0dB (default) to around 5dB in either direction for digital recording, and up to around 7dB for analog recording.

• Pressing the jog dial (ENTER)and

holding for 3 seconds resets to center position.

6 Press the jog dial (ENTER) to

confirm the balance.

Page 26

4 Getting started

Finalizing a disc

Before you can play a CD-R on an ordinary CD player, the disc must go through a process called finalization. Once finalized, a CD-R disc is no longer recordable, nor will you be able to set or clear skip IDs. Finalization is not reversible for CD-Rs so be absolutely sure that everything on the disc is the way you want it before you start.

CD-RW discs can also be finalized, although you can still erase the disc afterward and reuse it, so it's not anything like as final as it is with a CD-R disc. A finalized CD-RW disc can only be played on a CD player that is compatible with CDRW discs (at present, these are very few).

Caution!

Finalization takes a couple of minutes. During this time never switch off the power to the unit—the disc may become unusable as a result.

For a CD-RW, the finalize indicator lights in the display.

None of the controls on the player or the remote have any effect during finalization. If, however, the recorder hasn't managed to finalize the disc within 10 minutes, you can abort the operation by pressing 7. If you do this, the disc won't be playable on an ordinary CD player.

1 Load the CD-R or CD-RW you

want to finalize.

Check that the disc is free from dust, dirt and scratches—if necessary, clean the disc, following the guidelines on page 8.

2 Press FINALIZE.

The FINALIZE indicator lights.

After a short while you should see a display something like this:

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

The display shows how long finalization will take—the exact time taken depends on the disc.

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Press 7 here to cancel finalization.

3 Press 8 (6 on the front

panel) to start finalization.

Finalization takes about two minutes; you'll see how long there is still to go in the display. The player stops when finished.

For a CD-R, the CD-R indicator now changes to simply CD.

Page 27

5 More playback features

ANALOG

REC BALANCE

•

TIME

DISPLAY /CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

CHECK

ANALOG

REC BALANCE

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

AUTO/

REC SYNCHRO

MANUAL

ABC DEF

123

GHI MNOJKL

NAMEMARK

CURSOR

¡

ENTER

NPUT

SKIP ID

SELECTER

SET

CLEAR

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

¢

Î

CLEAR

ANALOG

REC LEVEL

ANALOG

REC LEVEL

Programming the track order

Programming the track order means telling the player precisely which tracks, and in what order, you want played. You can program a playlist of up to 24 tracks, playing tracks more than once if you like.

The playlist you program applies only to the disc in the player at the time: as soon as you eject that disc the playlist is lost.

1 Make sure the player is

stopped, then press PROGRAM.

The PGM indicator lights and the display prompts you to enter the first track in the program:

As you program tracks, the

2 Enter the track numbers in the

total running time of the program is displayed here.

order you want them played.

There are three ways to enter track numbers:

• Using the number buttons For track numbers 1 to 10, use the corresponding number button.

For track numbers over 10, press the >10 button, then enter the track number. For example, to select track 28:

ABC

>10

• Using the track skip buttons Use the 4 and ¢ buttons to select a track; press PROGRAM to enter it into the playlist.

• Using the jog dial Turn the jog dial to select a track; push to enter it into the playlist.

TUV

PGM

Clearing the playlist

Since the program only applies as long as the disc is in the player, you can clear it by simply ejecting the disc. Alternatively, press 7 while the disc is stopped.

Clearing a track from the playlist

Delete the last (most recently) programmed step by pressing CLEAR. Press repeatedly to clear several steps (if the program is playing while you’re doing this, you can’t clear steps beyond the one that is currently playing).

Checking what's in the playlist

While the disc is stopped, you can check the contents of the playlist using CHECK on the remote control. Each press steps through the playlist, showing the step number and the corresponding track number.

P-1O O5

Programmed step number

Programmed track number

PGM

Replacing a track in the playlist

While checking the playlist (see above), you can change the track number for the step you’re on using either the number keys, the 4 and ¢ buttons, or the jog dial.

English

3 Press 3 (6 on the front

panel) to start playback.

You must press PROGRAM if you want to enter another track after you have started playback.

Page 28

5 More playback features

RANDOM

REPEAT

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

AUTO/

MANUAL

ABC DEF

NAMEMARK

¡

SELECTER

CLEAR

¢

NPUT

Î

Playing tracks at random

Selecting random play leaves the track order of the disc up to the player. Each track on the disc is played just once, but in a random order.

Press RANDOM during playback or when the disc is stopped.

The RDM indicator lights up in the display and random playback starts.

• Pressing 7 cancels random play.

Repeating tracks

Using the repeat play function you can repeat either the current track over and over, or the entire disc.

• To repeat the current track, press REPEAT once.

The RPT-1 indicator lights up in the display and the current track repeats until you either press 7, or press REPEAT twice. Either way, repeat is canceled.

You can use repeat track in normal, program or random play modes.

• To repeat the whole disc, press REPEAT twice.

The RPT indicator lights up in the display and the CD repeats until you press either 7 or REPEAT again (in which case the disc continues playing to the end, then stops).

You can use repeat disc in normal, random or program play modes.

•

REC SYNCHRO

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

SKIP ID

CLEAR

SET

SKIP PLAY

O1 O1 OO:OO

The SKIP ON indicator

lights if there are skip

IDs present on the disc.

Fading in and fading out

AUTO/

MANUAL

NAMEMARK

¢

¡

NPUT

SELECTER

Î

SKIP ON

Use the fader feature to fade the volume down gradually and pause playback, or to have the player fade in the volume when you resume playback. You can also set the length of time over which you want to fade in or fade out (See Setting the fade length on page 34).

Note: You can only hear the fades through the analog outputs.

1 Press FADER during playback to

pause the disc.

The fader indicator in the display blinks and the volume fades to zero. The player then pauses playback.

2 Press FADER to resume play-

back of a paused disc.

The fader indicator in the display blinks and the volume starts to fade in.

Playing a disc with skip IDs

If you're not sure whether a disc has skip IDs programmed, look for the SKIP ON indicator in the display when you load a disc—it will light automatically if one or more are present.

1 Load a disc.

The SKIP ON indicator lights up if there are any skip IDs on the disc. This means the player won't play those tracks that are marked by skip IDs.

2 Press SKIP PLAY to switch skip

play on/off, then press 3 (6 on the front panel).

When you turn off skip play, the player ignores the skip IDs and plays all tracks on the disc.

• If there were no skip IDs on the disc in

the first place, the SKIP PLAY button has no effect.

Page 29

5 More playback features

Skipping unwanted tracks

REC SYNCHRO

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

10/0 >10

CURSOR

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SET

CLEAR

AUTO/

MANUAL

NAMEMARK

¢

¡

NPUT

SELECTER

Î

•

TIME

DISPLAY

/CHARA

SCROLL

MENU/ DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Although you can't erase tracks on a CD-R disc, you can set what are called 'skip IDs'. These tell a CD player (though not all recognize skip IDs) not to play a particular track, and to skip to the next one on the disc.

You can also set skip IDs on CD-RWs, although it's probably a less useful feature since erasing the last track is possible should you make a mistake in recording.

If you make a mistake when setting a skip ID, you can clear it, but be careful: you can set up to 21 skip IDs per disc, but repeatedly setting and clearing skip IDs will reduce this number.

Setting skip IDs

1 Press SKIP ID SET during

playback (or paused playback)

2 The display prompts you to

confirm.

Press SKIP ID SET again to confirm. To cancel, press either SKIP ID CLEAR or 3 (6).

• Use the 4 and ¢ buttons/jog

dial to skip to other tracks that don't have skip IDs set. When you press SKIP

SET, it will be for the track that is

currently playing.

• If there’s no room left on the disc to record a skip ID, the display will show the message SKIP FULL.

3 Set further skip IDs by repeat-

ing steps 1 and 2.

4 When you're finished, stop the

disc and press OPEN/CLOSE 0.

Until you eject the disc, the recorder stores the skip ID information in its memory. On pressing 0, the recorder writes the skip ID information onto the disc.

English

of the track you want to skip.

If there's no room left on the disc to record another skip ID, the display will show the message FULL.

ANALOG

REC BALANCE

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP PLAY

SET

TEXT

CURSOR

ENTER

SKIP ID

SYNCHRO

CD TEXT

ABC DEF

CLEAR

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

DELETE

Legato Link Conversion

AUTO/

MANUAL

NAMEMARK

¢

¡

NPUT

SELECTER

Î

ANALOG

REC LEVEL

4 ¢

Clearing skip IDs

1 Press SKIP PLAY to switch off

skip play mode.

The SKIP ON indicator in the display disappears.

• If the SKIP ON indicator did not light up when you loaded the disc then there are no skip IDs present on that disc.

2 Press SKIP ID CLEAR during

playback (or paused playback) of the track you no longer need a skip ID for.

If this track doesn't have a skip ID, the player jumps to the next track that does and starts playback of that track.

3 The display prompts you to

confirm.

Press SKIP ID CLEAR again to confirm. To cancel, press either SKIP ID SET or 3 (6).

• Use the 4 and ¢ buttons/jog

dial to move between tracks that have skip IDs set. When you press SKIP ID

, it will be for the track that is

CLEAR

currently playing.

• If there’s no room left on the disc to clear a skip ID, the display will show the message SKIP FULL.

4 Clear further skip IDs by

repeating steps 2 and 3.

5 When you're finished, stop the

disc and press 0.

Until you eject the disc, the recorder stores the changes in skip ID information in its memory. On pressing 0, the recorder writes the new skip ID information onto the disc.

Page 30

6 More recording features

TEXTMARK

ABC DEF

GHI MNOJKL

PQRS TUV WXYZ

123

10/0 >10

3,6

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

2,7

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

AUTO/

•

REC SYNCHRO

MANUAL

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

6 7

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

CLEAR

¡

SELECTER

NAMEMARK

¢

NPUT

Î

2,7 7

0!"#$%&’()*+,-./<=> ?@[]ˆ_'{|}<space>

Using CD text

You can name a CD-R or CD-RW so that when you load the disc into the player, the disc name, track title, or artist name can appear in the display. Each title can be up to 120 characters long, including spaces. You can store all the text (up to 2000 characters) for up to three non-finalized discs in the recorder at one time. This is useful when you want to edit the text during another recording session with the same disc.

Be careful: When you set text for a fourth disc, the oldest text information (for the first disc) is deleted from memory. Text with CD-RW discs is deleted when you erase the corresponding track.

Once you finalize a CD-R, the text information cannot be changed. Finalized CD-Rs containing CD text can still be played on ordinary (non-CD text compatible) CD players, however the CD text will not appear in the display.

1 Make sure the disc you want to

name is loaded into the recorder and is stopped. For track names: Before proceeding to

step 2, you must choose the track you want to name by turning the jog dial. You can also name tracks during playback.

2 Press NAME.

Press NAME to switch between disc and artist name:

DISC NAME

If you are naming a track, go to step 3.

The default is disc title. Press 7 at any time to exit.

3 Wait two seconds after making

your selection, or press ENTER.

If the disc doesn't already have a name, the character display is blank, with a blinking cursor on the first character.

ARTIST NAME

If the disc is already named, the character display shows the name (or the first 12 characters if it is too long to be displayed completely), with a blinking cursor under the first character.

4 Select/change the character at

the current cursor position by turning the jog dial.

See below for the complete list of letters, numbers, and symbols available.

If you’re using the remote control, use numbers keys 1-9 for numbers and the letters shown above each key. Press a key repeatedly to cycle through the letters and numbers on that key.

Characters available for disc and track names:

ABCDEFGHIJKLMNOPQRST UVWXYZ

abcdefghijklmnopqrstuvwxyz 1234567890 !"#$%&’()*+,-./<=> ?

@[]ˆ_'{|}<space>

5 Change between uppercase,

lowercase, and numbers/ symbols by pressing DISPLAY/ CHARA.

The case of the character at the current cursor position changes between upperand lowercase and numbers/symbols with each press.

6 Confirm the character and

move the cursor to the next character position by pressing the jog dial (or ¡).

For the remote, move the cursor to the next character position by pressing ENTER.

• Move the cursor backwards or forwards

along the display using 1 and ¡.

• Insert a new character into a name by moving the cursor to the character position you want and repeating steps 4–6.

Page 31

6 More recording features

ANALOG

REC BALANCE

• Erase the character at the current

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

cursor position by pressing MENU/

DELETE.

The characters on either side of the current cursor position close to fill up the gap.

English

7 Press NAME again to enter the

text and return to the title selection display.

If you are inputting a track title, you must assign it to a track number using 4 or ¢, or the corresponding number on the

AUTO/

•

REC SYNCHRO

MANUAL

TIME

ABC DEF

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

10/0 >10

CURSOR

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SET

CLEAR

NAMEMARK

¢

¡

7 6

NPUT

SELECTER

Î

remote control. Pressing NAME twice takes you back to the previous menu (step

2).

Note: After you have finished setting the names you want in CD text, be sure to eject the disc or, if you have finished all the recording and editing that you want do to, finalize the disc as shown on page 26.

Editing CD text

The CD recorder can store information for up to three discs at one time. When an unfinalized CD-R containing CD text is loaded, this text will automatically return to memory. Before finalizing the CD-R, you can go back and edit the text as many times as you like, or until you input CD text for a fourth disc (this will erase the oldest information in memory).

1 Load the CD-R or CD-RW you

wish to edit.

2 Press NAME.

Choose the name you wish to edit as in steps 1–3 of Using CD text.

3 Edit the text.

See step 6 of Using CD text.

4 Eject or finalize the disc.

See Finalizing a disc on page 26 if you have finished all the recording and editing that you want do to.

Page 32

6 More recording features

ANALOG

REC BALANCE

Copying track names to other tracks

If you need to name several tracks with similar names—several parts of one suite, for example—you can name the first one using the procedure detailed above, then simply copy that name to the other tracks and edit them as required. This can save you a lot of time over naming each track individually. The recorder stores the last three names you've copied using the name clip function in its memory (up to 40 characters each). When you copy another

7 Use the jog dial to select one of

the previous three names stored, then press the jog dial (ENTER).

On the remote, use the 4 and ¢ buttons to select a name, then press

ENTER.

The display flashes Name Insert briefly and the selected name is inserted at the point you chose.

• Edit the name further if necessary.

8 Press NAME to leave the track

name mode.

track name, the oldest one is deleted from memory.

4,8

TEXT

CD TEXT

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

DELETE

SYNCHRO

Legato Link Conversion

ANALOG

REC LEVEL

1 Go to the track with the name

you want to copy.

Use one of the usual methods—track skip, direct selection, etc.

2 Press NAME CLIP to copy the

currently displayed into

memory.

The display should confirm that the track name has been copied.

• You cannot copy the names of commercially recorded discs.

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

MANUAL

ABC DEF

¡

SELECTER

CLEAR

AUTO/

NAMEMARK

NPUT

¢

Î

4,8

2,6

3 Go to the track that you want

to copy the name to.

4 Press NAME to start editing the

current track name.

5 Move the cursor to the postion

you want to insert the copied name.

Use the 1 and ¡ buttons to move the cursor around the character display.

6 Press NAME CLIP again.

The most recently clipped name appears.

Page 33

6 More recording features

1 2

ANALOG

REC BALANCE

•

TIME

DISPLAY /CHARA

SCROLL

MENU/

DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

REC SYNCHRO

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

10/0 >10

CURSOR

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SET

CLEAR

2,3

AUTO/

MANUAL

NAMEMARK

¡

NPUT

SELECTER

¢

Î

ANALOG REC LEVEL

Automatically numbering tracks

If you're recording from CD, MD, DCC or DAT, you can usually let the recorder number the tracks automatically as they change on the source material. When recording other digital or analog sources, the recorder will start a new track if it detects more than 2 seconds of silence. However if you’re recording a noisy vinyl record or a classical recording with long quiet sections, the recorder may not always regognize the gap between tracks. For this reason you can adjust the level of sound that the recorder regards as ‘silence’.

Each input (analog, coaxial and optical) has its own threshold level, which can be set independently.

Note: The minimum analog threshold level is -66dB.

1 When the recorder is stopped,

press MENU/DELETE.

2 Turn the jog dial until A.LVL

appears in the display, then press to ENTER.

The display shows the current ‘silence’ threshold for automatic track numbering. The default is -54dB.

3 Turn the jog dial (4 and ¢

on the remote) to change the threshold level.

Turning the dial cycles through the following levels:

-78dB to -66dB – Use these levels if you find the recorder is putting in new track numbers during very quiet sections of classical music, for example.

-60dB to -48dB – A ‘mid’ level suitable for most recordings.

-42dB to -24dB – If you find that the recorder is not putting in new track numbers because the original source is too noisy.

4 Press the jog dial (ENTER) to

confirm the new level.

If the AUTO TRK indicator is not lit, press

AUTO/MANUAL to switch it on. To

check that tracks will start at the correct points on the recording, see Monitoring a source on page 36.

English

ANALOG

REC BALANCE

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Manually numbering tracks

Although automatic track numbering is the default mode of the recorder, you can number tracks manually as recording is

taking place. In some cases—such as recording from digital satellite or Laserdisc, or from an analog source— auto track numbering may not work reliably (in these cases, a new track is

SCROLL

◊ÛB->?/

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

started after the recorder detects two

2 Start recording.

You can use manual numbering in any record mode, but it is best suited to manual digital-input or analog-input recording (see page 18 for more on these recording modes).

3 Press RECORD ¶ at any point

you want a new track to start.

CD tracks must be at least four seconds long—the recorder won’t let you start a new track less than four seconds into the current track.

seconds of silence), and it's better to use manual track numbering.

Remember: It is not possible to edit

REC SYNCHRO

MANUAL

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

AUTO/

NAMEMARK

•

TIME

DISPLAY /CHARA

SCROLL

MENU/ DELETE

track numbers after recording.

1 Make sure automatic track

numbering is switched OFF.

If the AUTO TRK indicator is lit, press

AUTO/MANUAL to switch it off.

Page 34

6 More recording features

•

TIME

DISPLAY /CHARA

SCROLL

MENU/

DELETE

REPEAT RANDOM NAME CLIP

FADER

SKIP PLAY

ANALOG

REC BALANCE

REC SYNCHRO

MANUAL

ABC DEF

123

GHI MNOJKL

PQRS TUV WXYZ

10/0 >10

CURSOR

¡

ENTER

PROGRAM CHECK CLEAR

SKIP ID

SELECTER

SET

CLEAR

2,3,4

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

AUTO/

NAMEMARK

NPUT

¢

Î

ANALOG

REC LEVEL

2,3

2,4

Starting tracks in time increments

If you aren't able to set track numbers automatically during recording (a radio program with interviews, for example), you might want to have the recorder start tracks after every three minutes or so. This will make it easier to listen back to sections of the recording at a later date. You can set the time to one, three, or five minutes.

Note: The time increment will default to

OFF when: recording is stopped; auto track

numbering is turned off; power is turned off.

1 When the recorder is stopped,

press MENU/DELETE.

2 Turn the jog dial (4 and ¢

on the remote) until T. INC. appears in the display, then press to ENTER.

The display shows the current time increment: one, three, five minutes, or

OFF. The default is OFF.

3 Turn the jog dial (4 and ¢

on the remote) to change the time increment.

4 Press the jog dial to ENTER.

SCROLL

DELETE

REPEAT RANDOM NAME CLIP

SKIP PLAY

FADER

ANALOG

REC BALANCE

•

TIME

DISPLAY

GHI MNOJKL

/CHARA

PQRS TUV WXYZ

MENU/

10/0 >10

FADER

PROGRAM CHECK CLEAR

SET

2,3,4

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

AUTO/

REC SYNCHRO

MANUAL

ABC DEF

123

NAMEMARK

CURSOR

¢

¡

ENTER

NPUT

SKIP ID

SELECTER

CLEAR

Î

ANALOG

REC LEVEL

Legato Link Conversion

2,3

2,4

Recording fade ins and fade outs

Sometimes, for example if you're recording just an excerpt from something, it may be better to fade in the recording, then fade out again at the end, rather than start and end abruptly. You can also set longer or shorter fade times so that they match the fades on other songs in your mix. Note that you can’t record a fade in when in synchro recording mode (although you can record a fade out).

Setting the fade length

1 Press MENU/DELETE. 2 Turn the jog dial until FADER

appears in the display, then press to ENTER.

3 Use the jog dial (4 and ¢

on the remote) to set the length of the fade (in seconds).

Each turn will take you forward (or back) one second. The default is 5 seconds.

Recording a fade in

• With the source playing, press FADER during record-pause mode to fade in. Recording starts with a gradual fade in.

Recording a fade out

• Press FADER during recording to fade out.

After recording the fade out, the recorder goes into record-pause mode. This happens in either normal or synchro record mode.

• You can also just press 7 if you don’t

need a fade out.

If you record a fade out during all-track sync mode, the synchro mode is canceled after the fade out (see pages 19–21 for more on synchro recording).

Note: If the recorder runs out of recording space on the disc before the source has finished, it will automatically record a fade out and stop recording.

4 Press the jog dial (ENTER) to

confirm the new fade length.

Page 35

6 More recording features

ANALOG

REC BALANCE

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

AUTO/

MANUAL

ABC DEF

NAMEMARK

¡

SELECTER

CLEAR

DIGITAL

Legato Link Conversion

¢

NPUT

Î

ANALOG

REC LEVEL

Recording blank sections

This feature is useful wherever you need some blank space recorded on the disc, for instance, at the end of a recording session so that the next track doesn't follow the last too closely. Note that you can’t start a recording with a muted section; only after a recording has started, or at the end of a recording.

1 While recording or during

record-pause mode, press • REC MUTE.

A blank space of about four seconds is recorded, then the recorder goes into record-pause mode.

• If you press and hold • REC MUTE,

you can record a blank for as long as you hold down the button.

• Pressing • REC MUTE, (without

holding) in record-pause mode records

English

four seconds of silence from the current position. Use this to create a space between tracks when recording in 1track synchro mode, for example.

2 Press 7 to finish the recording

session.

1,2

3 2

ANALOG

REC BALANCE

TEXT

•

REC SYNCHRO

TIME

123

DISPLAY

GHI MNOJKL

/CHARA

SCROLL

PQRS TUV WXYZ

MENU/

DELETE

10/0 >10

CURSOR

ENTER

REPEAT RANDOM NAME CLIP

FADER

PROGRAM CHECK CLEAR

SKIP ID

SKIP PLAY

SET

DIGITAL

REC LEVEL

PUSH ENTER

MENU/

DELETE

SYNCHRO

CD TEXT

ABC DEF

¡

SELECTER

CLEAR

ANALOG

REC LEVEL

Legato Link Conversion

AUTO/

MANUAL

NAMEMARK

¢

NPUT

Î

Checking what's at the end of a disc

You don't have to record a whole disc at once. Until you finalize the disc, further recording is possible from the end of the last track you recorded (assuming there are fewer than 99 tracks already on the disc). Here's how to check what's on the last recorded section of the disc before recording new material:

1 Press ¶ RECORD.

The recorder goes into record-pause mode.

2 Press and hold 1.

You'll hear the last recorded track in reverse. Release the button and the track plays normally to the end.

While the track is playing you can use the 1 and ¡.

If you press ¶ RECORD again while the track's playing, the recorder jumps to the end of the track and goes into recordpause.

When the track has played out, the recorder automatically enters record-pause again.

3 Once the player is back in

record-pause mode you can go ahead and record normally.

If you decide you don’t want to record, just press 7.

Page 36

6 More recording features

SCROLL

◊ÛB->?/

FINALIZEERASE

Monitoring a source

2,3

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

When recording, or in record-pause mode, the source signal is always available for monitoring through a connected amplifier or through a pair of headphones plugged into the PDR–609’s phones jack. Even if you’re not recording, you can still monitor—useful for cueing up for the next recording and also for checking that tracks are starting in the proper places during automatic track numbering.

1 Start the source component

playing.

Make sure that the input selector is set to the correct input.

2 Press MONITOR.

The indicator above the MONITOR button lights up.

If the source is copy protected, the message

Can’t COPY appears (see the following

page for more on this).

• When automatic track numbering has been selected, the TRACK indicator will light for 2 seconds at track start points. See Automatically numbering tracks on page 33 if you find the recorder can’t recognize the gaps between tracks.

• When monitoring through a digital output, you cannot hear changes you make in the recording level or balance.

3 To switch off monitoring, press

MONITOR again.

The monitor indicator switches off.

SCROLL

◊ÛB->?/

FINALIZEERASE

Checking for digital copy protection

AUTO

MONITOR

TIME

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

SELECTOR

MANUAL

Using the MONITOR button, you can also check whether or not a digital source is copy-protected with SCMS (Serial Copy Management System). SCMS allows you to make digital copies of original sources for your own use, but prevents further digital copies being made from the copy (see page 27 for more on SCMS).

1 Start playing the digital source.

Make sure that the input selector is set to the correct digital input.

2 Press MONITOR.

The display shows Can’t COPY if the source is digital-copy protected.

• Press MONITOR again to switch monitoring off.

Page 37

6 More recording features

Erasing a CD-RW

When a non-finalized

English

disc is loaded

disc

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

the great advantage of CD-RW is that the discs can be erased and reused. Various erase options are available depending on whether the disc has been finalized.

A third, special option, erases (reinitializes) the whole disc. This process takes quite a long time to complete and

Although more expensive than CD-R discs,

ANALOG

REC BALANCE

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

should be used for recovering damaged discs, not for erasing tracks from a healthy disc.

Caution!

Never switch off the power during CD-RW erasing - your disc may become unusable.

If the message CHECK DISC appears any time during any erase process, press 0, take out the disc, clean it, then try the erase command again.

Be sure to remove the disc from the recorder before switching off the power, otherwise the erase operation will not be completed.

1 Press ERASE.

The display shows ERASE LAST?.

• Press 7 to cancel last track erase here.

2 Use the jog dial or press 4

and ¢ on the remote control to change the erase option.

Switch between:

ERASE LAST? – erase just the last track

ERASE ALL? – erase all tracks

ERASE 02–[LAST TRACK]? – erase

track 2 and all subsequent tracks

ERASE 03–[LAST TRACK]? – erase

track 3 and all subsequent tracks

Keep turning the jog dial or press 4 and ¢ on the remote control to change the number of tracks to erase.

3 Press 8 (6 on the front

panel) to start erasing.

The process takes just a few seconds. During this time, the function indicator lights.

4 Eject or finalize the disc.

You must eject, then re-insert the disc if you want to record any new tracks. See Finalizing a disc on page 26 if you have finished all the recording and editing that you want do to.

Page 38

6 More recording features

When a finalized disc is loaded

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

Be careful: When you erase the TOC,

the CD text information for the disc is also copied to memory for editing purposes, erasing the oldest text information stored (as explained on page 30).

1 Press ERASE.

The display shows ERASE TOC ?.

Press 7 to cancel erase here.

2 Use the jog dial or 4 and ¢

buttons on the remote control to change the erase option.

Switch between:

ERASE TOC? – erase the table of contents

(returns disc to a non-finalized state)

ERASE ALL? – erase all tracks

3 Press 8 (6 on the front

panel) to start erasing.

The function indicator lights and the display shows ERASE, and the time remaining to completion.

You can halt this erase process by holding down the 7 button for 10 seconds.

4 Eject the disc.

You must eject, then re-insert the disc if you want to record any new tracks.

Reinitializing a disc

◊ÛB->?/

AUTO

MONITOR

TIME

SCROLL

MANUAL

TRACK NO.

WRITE

INPUT

AUTO

FINALIZEERASE

SELECTOR

MANUAL

DIGITAL

ANALOG

REC LEVEL

PUSH ENTER

ANALOG

REC BALANCE

MENU/

TEXT

DELETE

SYNCHRO

CD TEXT

Legato Link Conversion

1 Press and hold ERASE for about

four seconds.

The recorder prompts you to confirm with the message INITIALIZE?.

Press 7 to cancel all disc erase here.

2 Press 8 (6 on the front

panel) to start erasing.

The process takes about 40 minutes, depending on the disc. During this time, the display shows ERASE, followed by the remaining time to completion.

You can halt this erase process by holding down the 7 button for 10 seconds.

3 Eject the disc.

You must eject, then re-insert the disc if you want to record any new tracks.

Page 39

7 Additional information

Understanding display messages

Below is a list of messages you’ll see during normal operation of the PDR–609 together with a brief explanation of what they mean. If you need more information, turn to the page indicated.

Note: In the table below, ** indicates a track number.

egasseM noitpircseD ecnerefeR

otegassemehtroftiaW.)stnetnoCfoelbaT(COTs'csidehtgnidaersiredrocerehT

DAERCOT

.raeppasid

1–CNYS

.langistupniecruoslatigidehtstcetedredrocer

LLA–CNYS

.langistupniecruoslatigidehtstcetedredrocer

CERAMP

.gniwohssiyalpsidsihtelihwrewopehtffonrut

TESPIKS**

RLCPIKS**

?TSALESARE

.)lortnocetomerehtno

ehtgnisserpybDIpiksatesottnawuoytahtmrifnoC TESDIPIKS .nottub

ehtgnisserpybDIpiksatesottnawuoytahtmrifnoC RAELCDIPIKS .nottub

reveN.)aerAyromeMmargorP(AMPs'csidehtotatadCOTgnitirwsiredrocerehT

gnisserpybcsidWR-DCafokcarttsalehtesareottnawuoytahtmrifnoC 6 (8

51.p

ehtnehwstratsgnidroceR.edomgnidrocerlatigidcitamotuakcart-1nisitinuehT

91.p

ehtnehwstratsgnidroceR.edomgnidrocerlatigidcitamotuakcart-llanisitinuehT

02.p

92.p

73.p

English

?LLAESARE

.)lortnocetomereht

?COTESARE

?**–**ESARE

?EZILAITINI

.)lortnocetomer

gnisserpybcsidWR-DCanoskcartllaesareottnawuoytahtmrifnoC 6 (8 no

.csidehtnolairetameromdrocernacuoy,sihtgniodretfA.etatsdezilanif-non

.csidWR-DCanodedrocerskcartesareottnawuoytahtmrifnoC

gnisserpybcsidWR-DCehtezilaitini-erottnawuoytahtmrifnoC 6 (8 ehtno

73.p

aottinruterotcsidWR-DCdezilanifafoCOTehtesareottnawuoytahtmrifnoC

83.p

73.p

83.p

Page 40

7 Additional information

Troubleshooting

Below is a list of messages mainly related to playback and recording problems, together with a brief explanation and a page reference where you can find more information:

yalpsiD esuaC ydemeR

KCEHC

CSID

KCEHC

gniknilb(

)yalpsid

.ytrid

.nwod

rodegamadsicsidehT

edispudedaolsicsidehT

.retnec

,derruccororremetsysA

roesionoteudspahrep

.yticirtcelecitats

Display messages relating to playback

yalpsiD esuaC ydemeR

CSIDWEN

.dedaolsicsidknalbA -DCroR-DCknalbnoelbissopsignidrocerylnO

.yrassecensanaelC.cte,sehctarcs,trid,tsudrofkcehcdnacsidehttuoekaT

deyalpsidsiegassememasehtfI.puedis-lebaltidaolerdnacsidehttuoekaT

fI.niaganitigulpdnadrocrewopehtgulpnu,dedaolersicsidehtretfaniaga

ecivresdezirohtuareenoiPatcatnocesaelp,deyalpsidllitssiegassememaseht

deyalpsidsiegassememasehtfI.niaganitigulpdnadrocrewopehtgulpnU

.retnececivresdezirohtuareenoiPatcatnocesaelp,niaga

.elbissoptonsikcabyalP.scsidWR

CSIDON

.csid

agnidaoltuohtiwkcabyalptratsotedamsitpmettanA

.dedaolsicsidatahtkcehcdnayartehtnepO

Page 41

7 Additional information

Display messages relating to recording

Note: In the table below, ** indicates a track number.

yalpsiD esuaC ydemeR

ehtnehwsraeppasihT ORHCNYS

ypoc-latigidsilangistupniehT

tupniehtnehwdesserpsinottub

dna,tupnilatigidaottessirotceles dezingocertonsidetcelesecruoseht

.TADro,CCD,DM,DCsa

.detpurretnisawecruoslatigidehT

nasiro,oiduatonsiecruosehT

-DCa.g.e(tamrofelbitapmocni

ydaerlasawreyalpecruosehT

.drocerotgniraperpsitinuehT

dehctiwssawredrocerehT

dluocredrocerehT.csidehtgnitceje

gnidrocerlaitnesseetirwton

.csidehtotnonoitamrofni

elihW RIAPER ehtsenimaxeyllacitamotuaredrocereht,deyalpsidsi

tuohtiwgnidrocerretfadeggulpnu/ffo

YPOCt'naC

.SMCShtiwdetcetorp

CNYSt'naC

NID

KCOLNU

.)MOR

KCEHC

?TUPNI

PUTES**

RIAPER

ehtnehwgniyalp ORHCNYS

.desserpsawnottub

English

.stupnigolanaehthguorhtecruosehtdroceR

.tupnigolanaehthguorhtdrocerro,yllaunamecruosehtdroceR

ehttahtdnaylreporpdetcennocsielbactupnilatigidehttahtkcehC

.nosireyalpecruosehtforewop

.ecruoscisumralugerasiecruosehttahtkcehC

,emittrohsaretfA.reyalpecruosehtpotS 1–CNYS ro LLA–CNYS

.edomesuap-drocer–orhcnysotniseogredrocerehtdna,deyalpsidsi

.sraeppasidegassemehtlitnutiaW

gnidrocerdnasrebmunkcartehtsetadpudnacsidehtfoaeradedrocer

.csiddedroceryllufarofsetunim04tuobasekatssecorpsihT.atademit

ehtecnoelbissopsignidrocerrehtrufronoitazilaniF RIAPER egassem

.sraeppasid

.csidWR-DCehtesarero,csidrehtonaesU

remusnocrofgniebsadetangisedsitahtcsidWR-DCroR-DCadaoL

ESUREMUSNOC .noitangised

elbissopsignidrocereromoN

emitgnidrocerelbaliavaehtesuaceb

99ro,pudesuneebsahcsidehtfo

nodedrocerneebydaerlaevahskcart

WR-DCroR-DCasicsiddedaolehT

.esu

ehttuohtiwesulanoisseforprofcsid

LLUFCER

.csideht

CSIDorp

If digital synchro-recording fails to operate correctly, check the following:

1. Pause playback of the source, then press the DIGITAL SYNCHRO button again.

• If you’re recording from a portable CD player, etc., make sure that the shock-protection feature is switched off.

2. Start playback of the source component once you see the SYNCHRO indicator start to blink.

3. If none of the above solves the problem, use manual digital recording to record.

• Digital synchro-recording uses a digital sub-signal contained in the source player’s digital output. Digital synchro-recording will not work when recording from the following devices:

• CD players whose digital output does not include a sub-signal

• Portable CD, MD or DVD players which do not output a digital signal when stopped.

Page 42

7 Additional information

It’s often easy to mistake incorrect operation for trouble and malfunction of the unit. If you think there is something wrong with the component, check the points below first. If the problem persists, contact you nearest Pioneer-authorized service center and have them check over the unit.

motpmyS esuaC ydemeR

ebtonnacrewoP

.nodenrut

draehsidnuosoN

.kcabyalpgnirud

.drocertonnaC

.dezilanif

.tcerrocnisinoitcelestupniehT

golanaehT LEVELCER .woloottessilortnoc

sidnuosdedroceR

.detrotsid

lortnocetomeR

sinoitarepo

.elbissopmi

golanaehT

LEVELCER

.tcerrocnierasnoitcennoclangiS

.tesVTamorfecnerefretnisierehT

.deprawrodegamadsicsidehT

.ytridylemertxesicsidehT

.tinuniamdna

.egnarelballortnocetomer

.teltuollawehtmorfdeggulpnusidrocrewopehT

.teltuo

oerets(tnenopmocehtmorfffodenrutsawrewopehT

.detcennocsitihcihwot).cte,remitoidua,reifilpma

.ylreporppudetcennoctonsiredrocerehT

neebydaerlasahesunicsidWR-DCroR-DCehT

.hgihoottessilortnoc

)42.p(

.detsuahxeeraseirettablortnocetomerehT

tinulortnocetomerehtneewtebelcatsbonasierehT

ehtedistuodetarepogniebsitinulortnocetomerehT

)9.p(egnar

.redrocerehtotrewop

)11–01.p(reifilpma

)63.p(csidWR-DC

.csidrehtonaesU

.csidehtnaelC

.senowenhtiwseirettab

.elcatsboehtevomeR

rewopaotnidrocrewopehtgulP

ehtgniylppustnenopmocehtnonruT

ehtotyllaicepse,snoitcennocllakcehC

)11–01.p(snoitcennocllakcehC

ehtesarerocsiddezilanif-nonaesU

ecruosehtotdetcennoctupniehttceleS

.morfgnidrocerer’uoytnenopmoc

)42–32.p(levelgnidrocerehtesaercnI

levelgnidrocergolanaehtecudeR

)11–01.p(snoitcennocllakcehC

sihtllatsnirofforewopVTehtnruT

.VTehtmorfyawarehtruftinu

lortnocetomerehtfohtobecalpeR

elballortnocetomerehtnietarepO

ehtteS YALPPIKS ffootnottub

)82.p(

ehtteS YALPPIKS nootnottub

)82.p(

elbatiusaotdlohserhtecnelisehtteS

gnirebmunyllacitamotuaroflevel

)33.p(skcart

)62.p(csidehtezilaniF

fI.reyalpDCtnereffidanocsidehtyrT

nosnelpukcipehttegnehtKOsyalpti

.denaelcreyalplanigiroeht

dneehtezingocerton

cnysgnirudskcartfo

csidR-DCdedrocerA

nodeyalpebtonnac

ehT YALPPIKS noottessinottub

ehT YALPPIKS .ffoottessinottub

tessi’ecnelis‘sasdragerredrocerehttahtlevelehT

.hgihootro,wolootrehtie

nehW.gnidrocerretfadezilanifneebtonsahcsidehT

.pusthgilrotacidniR-DCeht,dedaolsicsidahcus

,ytridsireyalpDCrehtoehtfosnelpukcipehT

.scsidR-DCyalpotytilibastigniriapmi

eraskcartemoS tuohtiwdeppiks

.deyalpgnieb

seodkcabyalppikS

.ruccoton

seodredrocerehT

.gnidrocer

.sreyalpDCrehto

Page 43

7 Additional information

Specifications

1 General

Model ..................................................... Compact disc audio system

Applicable discs ......................................... CDs, CD-Rs and CD-RWs

Power supply ............. AC 120 V, 60 Hz (U.S and Canadian models)

AC 220-240 V, 50/60 Hz (U.K model)

Power consumption ................... 13 W (U.S and Canadian models)

14 W (U.K model)

Operating temperature......... +5 °C to +35 °C (+41 °F to +95 °F)

Weight (without package) .................................. 3.5 kg (7 lb 12 oz)

Max. dimensions ...................... 420 (W) × 295 (D) × 105 (H) mm

16 9/16(W) × 11 10/16 (D) × 4 3/16 (H) in.

2 Audio unit

Frequency characteristics........................................... 2 Hz to 20 kHz

Playback S/N ................ 108 dB (EIAJ) (U.S and Canadian models)

112 dB (EIAJ) (U.K model)

Playback dynamic range .............................................. 98 dB (EIAJ)

Playback total harmonic

distortion .................... 0.002 % (EIAJ) (U.S and Canadian models)

0.0017 % (EIAJ) (U.K model)

Playback channel separation .................................................. 98 dB

Recording S/N .......................................................................... 92 dB

Recording dynamic range ....................................................... 92 dB

Recording total harmonic

distortion .................... 0.005 % (EIAJ) (U.S and Canadian models)

0.004 % (EIAJ) (U.K model)

Output voltage ...............................................................................2 V

Wow-flutter .........................................Less than measurement limit

((±0.001 % W.PEAK) (EIAJ))

Number of channels .......................................... 2 channels (stereo)

Digital output:

Coaxial output ......................................... 0.5 Vp-p ±20 % (75 Ω)

Optical output ................. –15 to –21 dBm (wavelength: 660 nm)

Frequency deflection: Level 2 (standard mode)

English

*Recording specification values are for the LINE input (analog)

3 Input jacks

Optical digital input jack Coaxial digital input jack Audio LINE input jack Control IN jack

4 Output jacks

Optical digital output jack Coaxial digital output jack Audio LINE output jack Control Text jack

5 Accessories

• Remote control unit ...................................................................1

• Size AA/R6P dry cell batteries.....................................................2

• Audio cord...................................................................................2

• AC power cord .............................................................................1

• Operating Instructions ...............................................................1

• Warranty card .............................................................................1

NOTE :

subject to change without notice, due to improvements.

The specifications and design of this product are

Page 44

[For U.S. and Canadian models only]

Should this product require service in the U.S.A. and you wish to locate the nearest Pioneer Authorized Independent Service Company, or if you wish to purchase replacement parts, operating instructions, service manuals, or accessories, please call the number shown below.

8 0 0 – 4 2 1 – 1 4 0 4

Please do not ship your product to Pioneer without first calling the Customer Service Department at the above listed number for assistance.

PIONEER ELECTRONICS SERVICE, INC. CUSTOMER SERVICE DEPARTMENT P.O. BOX 1760, LONG BEACH, CA 90801-1760, U.S.A.

For warranty information please see the Limited Warranty sheet included with your product.

Should this product require service in Canada, please contact a Pioneer Canadian Authorized Dealer to locate the nearest Pioneer Authorized Service Company in Canada. Alternatively, please contact the Customer Service Department at the following address:

Pioneer Electronics of Canada, Inc. Customer Service Department 300 Allstate Parkway, Markham, Ontario L3R OP2 (905) 479-4411

1-877-283-5901

For warranty information please see the Limited Warranty sheet included with your product.

Si ce produit doit être réparé au Canada, veuillez vous adresser à un distributeur autorisée Pioneer au Canada pour obtenir le nom de la Société de Service Autorisée Pioneer le plus près de chez vous. Ou encore, veuillez communiquer avec le Service de Clientèle de Pioneer:

Pioneer électroniques du Canada, Inc. Département de service aux consommateurs 300 Allstate Parkway, Markham, Ontario L3R OP2 (905) 479-4411 1-877-283-5901

Pour obtenir des renseignements sur la garantie, veuillez vous reporter au feuillet sur la Garantie Limitée qui accompagne le produit.

PIONEER CORPORATION

PIONEER ELECTRONICS [USA] INC. PIONEER ELECTRONICS OF CANADA, INC. PIONEER EUROPE NV PIONEER ELECTRONICS AUSTRALIA PTY. LTD. PIONEER ELECTRONICS DE MEXICO S.A. DE C.V.

4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

P.O. BOX 1540, Long Beach, California 90801-1540, U.S.A.

300 Allstate Parkway, Markham, Ontario L3R OP2, Canada

Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 03/570.05.11

<00H00ZF0Q00>

178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: [03] 9586-6300 San Lorenzo 1009 3er Piso Desp. 302 Col. Del Valle Mexico D.F. C.P. 03100 TEL: 5-688-52-90

Printed in <PRB1306-B>

Pioneer PDR-609 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
