Pioneer DJm-909 User Manual 2

DJ MIXER

DJM-909

Operating Instructions

Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference. In some countries or regions, the shape of the power plug and power outlet may sometimes differ from that shown in the explanatory drawings. However the method of connecting and operating the unit is the same. K015 En

NOTE: THE NO USER-SERVICEABLE PARTS COMPARTMENT WARNING IS LOCATED ON THE APPLIANCE BOTTOM.

IMPORTANT NOTICE

The serial number for this equipment is located on the bottom plate. Please write this serial number on your enclosed warranty card and keep it in a secure area. This is for your security.

WARNING:

Handling the cord on this product or cords associated with accessories sold with the product will expose you to lead, a chemical known to the State of California and other governmental entities to cause cancer and birth defects or other reproductive harm.

Wash hands after handling.

CONTENTS

FEATURES

CAUTIONS REGARDING HANDLING ...................... 4

Location ........................................................................... 4

Condensation .................................................................. 4

Cleaning the Unit ............................................................ 4

FEATURES ................................................................. 4

CHECKING ACCESSORIES ....................................... 5

1) Designed for high sound quality

Electronic parts have been carefully selected and internal circuitry redesigned to provide the shortest-possible signal paths, thus realizing true club sound with power to spare.

2) Effects create new performance potential

1 50 effects in 2 systems: Each channel can be preset with

CONNECTIONS ......................................................... 5

PART NAMES AND FUNCTIONS ............................. 7

Top Panel ........................................................................ 7

Front Panel .................................................................... 12

Rear Panel ..................................................................... 13

Touch Panel Display Contents ...................................... 14

Touch Panel Display Selection ...................................... 15

2 Fader effects: an industry first, Pioneer’s “fader effects”

BPM COUNTING ..................................................... 16

FADER OPERATIONS .............................................. 17

EFFECT FUNCTIONS ............................................... 19

Types of Effects ............................................................ 19

Using the Effect Functions ........................................... 22

Presetting Effects ......................................................... 23

Effect Parameters ......................................................... 24

3 Beat effects: linked to track tempo (BPM: beats per

4 Effect frequency selection: effects can be targeted at HI,

TROUBLESHOOTING .............................................. 27

SPECIFICATIONS .................................................... 28

3) Ergonomic, user-customizable cross fader

1 Cross-fader “feeling” adjustment: the specific physical

CAUTIONS REGARDING HANDLING

Location

Install the unit in a well-ventilated location where it will not be exposed to high temperatures or humidity.

÷ Do not install the unit in a location which is exposed to

direct rays of the sun, or near stoves or radiators. Excessive heat can adversely affect the cabinet and internal components. Installation of the unit in a damp or dusty environment may also result in a malfunction or accident. (Avoid installation near cookers etc., where the unit may be exposed to oily smoke, steam or heat.)

÷ When the unit is used inside a carrying case or DJ booth,

separate it from the walls or other equipment to improve heat radiation.

Condensation

When this unit is brought into a warm room from previously cold surroundings or when the room temperature rises sharply, condensation may form inside, and the unit may not be able to attain its full performance. In cases like this, allow the unit to stand for about an hour or raise the room temperature gradually.

Cleaning the Unit

÷ Use a polishing cloth to wipe off dust and dirt. ÷ When the surfaces are very dirty, wipe with a soft cloth

dipped in some neutral cleanser diluted five or six times with water and wrung out well, then wipe again with a dry cloth. Do not use furniture wax or cleaners.

÷ Never use thinners, benzene, insecticide sprays or other

chemicals on or near this unit, since these will corrode the surfaces.

2 Independent cross fader lag cut: the mechanical play

3 Independent cross fader curve: an industry first, the

4 “Contactless fader” mechanism: based on Pioneer’s

4) Touch-panel display provides both wide

The top panel LCD display includes a fader edit monitor that displays information about user fader settings (curve, reverse, cut lag, etc.) together with other information necessary for remix and DJ play. The use of a touch panel also makes it possible to select effects easily with a single touch.

5) Other features

1 An industry first for DJ mixers, this unit supports use of an

2 When connected via a control cord to a Pioneer DJ CD

3 “Fader reverse” function allows reversing of the

4 Delicate 33-step channel fader curve settings. 5 Can be connected in series to other mixers for “session”

three of 50 possible effects. Sequential effects can be called up seamlessly merely by touching the names of the effects on the top panel’s LCD touch panel, creating a new level of DJ performances.

allow the user to change effect parameters by operating the sliders for the cross fader or channel fader, thus providing greater operating facility compared to conventional rotating dials, while also allowing the DJ to apply scratch sounds to effects and create other new remix performances.

minute), “beat effects” allow the user to apply echo, delay and other effects with perfect timing.

MID, and LOW frequency ranges as desired; simultaneous multiple frequency ranges can also be specified.

sensation of cross fader operation is all-important to the DJ; the “feeling” adjustment provided in this mixer is an industry first, allowing the user to adjust the physical sensation of the slider to personal preferences, for the smoothest possible cross fader operation.

(the lag distance before sound begins) at each end of the cross fader slider can be adjusted using the fader lag cut function, thus allowing adjustment of the sound cut when performing scratch play.

right-left independently adjustable (33 steps) cross fader curve control goes beyond the symmetrical type of cross fader curve on conventional mixers, thus broadening DJ performance capabilities.

own proprietary technology, this new contactless optical fader assures durable and stable operation under the severest of DJ performance conditions.

information and ease of operation

optional foot switch to allow quick ON/OFF control of effects.

player (sold separately), operation of the fader can be used for automatic “fader start” play.

directions of fader operation movement.

output of mixed sounds.

CHECKING ACCESSORIES

÷ Hexagonal Allen driver

(for cross fader operating load adjust screw)

÷ These operating instructions ÷ Warranty

CONNECTIONS

When connecting or changing the connection of units, make sure to first turn off the power switch and disconnect the power cord from the outlet. This mixer is not furnished with any connection cables; when performing connections, use the cables that came provided with your player and other components, or purchase commercially available audio cables.

1. Connecting Input Components

[DJ CD Player]

Analog turntable 2

Cassette deck, etc.

CDJ-800, CDJ-1000, CDJ-1000MK2, CDJ-100S, CDJ-700S, CDJ-500II, CMX-3000, CMX-5000, DMP-555

Player B

Player A

Analog turntable 1

Cassette deck, etc.

CH-2

R L

MASTER 2

SIGNAL

GND

BOOTH/

SESSION OUT

SEND RETURN

R RL L

PHONO

/ LINE

PHONO

LINE

CH-2 PLAYER

CONTROL

ONTRAST

(MONO) (MONO)

MASTER 1

3 COLD 1 GND

2 HOT

RIGHT

CH-2 PHONO/LINE selector switch

DJ CD Players 1

Connect the AUDIO OUT connectors from Player A to the CH-1 CD input jacks of the DJ mixer, and connect the AUDIO OUT connectors from Player B to the CH-2 CD input jacks. When using one of the listed DJ CD players, the control cord furnished with the CD player should be connected between the player and the DJ mixer. In this way, the DJ mixer’s fader lever can be operated to control operation of the DJ CD player for fader start play and back cue.

Analog turntable / Cassette deck, etc. 2

Connect the analog turntable 1 output cables to the CH-1 PHONO/LINE jacks of the DJ mixer, and connect the ground wire to the SIGNAL GND terminal. Set the CH-1 PHONO/ LINE selector switch to [PHONO]. When connecting a cassette deck or other such component to these jacks, set the CH-1 PHONO/LINE selector switch to [LINE].

R L R LR L

CH-1

SIGNAL

MIC

PHONO

LINE

GND

PHONO

/ LINE

CH-1 PLAYER

CONTROL

CH-1 PHONO/LINE selector switch

Connect the analog turntable 2 output cables to the CH-2 PHONO/LINE jacks of the DJ mixer, and connect the ground wire to the SIGNAL GND terminal. Set the CH-2 PHONO/ LINE selector switch to [PHONO]. When connecting a cassette deck or other such component to these jacks, set the CH-2 PHONO/LINE selector switch to [LINE]. * The PHONO input for this DJ mixer supports use of a MM

cartridge.

MIC 3

The MIC jack on this unit supports use of either PHONE type or XLR type plugs.

SESSION IN 4

When using multiple mixers simultaneously, use the appropriate audio cables to connect the other mixer outputs to these jacks.

SESSION IN

Microphone

Other mixer output

CONNECTIONS

2. Connecting Foot Switch and Headphones (front panel)

Headphones

FADER REVERSE

CH-1 C.F. CH-2

Foot switch

OFF

FOOT SW

OFFONOFF

CH-1

OFF

CH-2

(pedal switch)

Foot switch 5

Allows the connection of a foot switch with a 6.3 mm monaural plug. The foot switch control effect ON/OFF.

3. Output Connections

Power amplifier

(supporting RCA input)

Power amplifier

(for booth monitor)

MASTER 2

BOOTH/

SESSION OUT

CH-2

R L

PHONO

/ LINE

PHONO

LINE

SIGNAL

GND

Power cord

R RL L

CH-2 PLAYER

CONTROL

PROFESSIONAL 2CHANNEL MIXER

DJM-909

FADER CURVE

CROSS FADER 2CROSS FADER 1 CH-2CH-1

FADER CUT LAG

MAXMIN

FADE R START

C.F. 1 CH-1 C.F. 2 CH-2

PHONES

POWER

Headphones 6

Use to connect headphones with a 6.3 mm diameter stereo plug.

CONTRAST BRIGHT

SEND RETURN

(MONO) (MONO)

MASTER 1

3 COLD 1 GND

2 HOT

CH-1

SIGNAL

MIC

PHONO

LINE

GND

SESSION IN

PHONO

/ LINE

CH-1 PLAYER

CONTROL

External effector

Power amplifier

(supporting XLR input)

To SESSION IN jacks of other mixer

External effector 7

Use a 6.3 mm monaural plug to connect the external effector’s input connectors to the DJ mixer’s SEND jacks. When using an effector with a monaural input, connect it to the L channel output only. The signal actually sent to the effector will represent a mix of L and R signals. Use a 6.3 mm monaural plug to connect the external effector’s output connectors to the DJ mixer’s RETURN jacks. When using an effector with monaural output, connect only the L channel input. The signal received from the effector will be input to both L and R channels.

Master output

MASTER 1 8

XLR type balanced output.

Power outlet

MASTER 2 9

RCA type unbalanced output.

BOOTH/SESSION OUT p

These jacks are provided for booth monitor output. The sound volume here is controlled by the booth monitor level dial, regardless of the setting of the MASTER LEVEL dial. When using this unit in tandem with another mixer, connect these jacks to the other mixer’s session input connectors.

Power cord q

After completing all other connections, connect the power plug to a standard power outlet or to the auxiliary power outlet of an amplifier.

PART NAMES AND FUNCTIONS

Top Panel (1)

20 21

22 23 24

PHONO 1

/LINE 1

CD 1

BANK 1

MIC LEVEL

–

12-12

LOW

12-12

MIC SEND

SESSION IN

–

CH-1 SEND CH-2 SEND

TRIM

BANK 2

BANK 3

–

FX ADJ. FX ADJ.

6-26

FADER

CURVE

MID

BANK EDIT

TIME/SELECT

6-26

LOW

MIX/DEPTH

-26

OFF OFF

PROFESSIONAL 2CHANNEL MIXER

DJM-909

EFFECT EFFECT

MAXMIN

TAP TAP

LOCK ON

OFF

TIME/SELECT

MIX/DEPTH

BANK 1

BANK 2

BANK 3

FADE R

CURVE

EDIT

CH-1MIC

BANK

MAXMIN

FADER START

TRANSFORM

–

PHONO 2

/LINE 2

TRIM

MID

LOW

10 11

CD 2

MASTER LEVEL

–

BOOTH/SESSION OUT

–

6-26

–

6-26

CH-1 CH-2

6-26

FADER START

PHONES

SELECT

MASTER EFFECT CUE

15 16

17 18

REVERSE

MASTER LEVEL

REVERSE

CH-1 FADER ST AR T

CH-1 CH-2

8 7 6 5 4 3 2 1 0

9 5 3 1 0

–

dB dB

CH-1 CH-2

9 5 3 1 0

–

9 8 7 6 5 4 3 2 1 0

CH-2 FADER ST AR T

32 33

34 35

C.F.1 FADER START

FOOT SW POWER

27 28 29

1 CH-1 input selector switch

(MIC – PHONO 1/LINE 1 – CD 1)

Use to select input signal from MIC jack, CH-1 PHONO/LINE input jacks, or CH-1 CD input jacks, and send them to the TRIM control. * When [MIC] is selected, the MIC signals are sent directly to

the TRIM section without passing through the microphone level and microphone equalizer circuits.

2 CH-1 TRIM dial

Use to adjust the CH-1 input signal level (range of

adjustment: +9 dB to –∞).

REVERSE

FEELING ADJ.

C.F.2 FADER START

PHONES

3 Microphone level dial (MIC LEVEL)

Use to adjust the microphone level (range of adjustment:

0 dB to –∞).

4 Microphone equalizer dials (HI/LOW)

Use to adjust microphone treble response (range of adjustment: 10 kHz, ±12 dB).

LOW

Use to adjust microphone bass response (range of adjustment: 100 Hz, ±12 dB).

PART NAMES AND FUNCTIONS

5 CH-1 equalizer dials (HI/MID/LOW)

Use to adjust CH-1 input treble response (range of adjustment: 13 kHz, +6 dB to –26 dB).

MID

Use to adjust CH-1 input midrange response (range of adjustment: 1 kHz, +6 dB to –26 dB).

LOW

Use to adjust CH-1 input bass response (range of adjustment: 70 Hz, +6 dB to –26 dB).

6 MIC SEND button and indicator

When set to On, the indicator lights, and microphone signals are output at the SEND jacks. This function is disabled when the CH-1 input selector switch is set to [MIC].

7 Session input level dial (SESSION IN)

Use to adjust the session input volume (range of adjustment:

0 dB to –∞).

8 CH-1 SEND button and indicator

When set to On, the indicator lights, and CH-1 signals are output at the SEND jacks.

9 CH-1 EQ ON/OFF switch and indicator

When set to [ON], the indicator lights and CH-1 equalizer is enabled. When set to [OFF], the indicator goes out and the equalizer circuit is bypassed.

10 CH-2 input selector switch

(CH-1 – PHONO 2/LINE 2 – CD 2)

Use to select input signal from CH-1 (component selected with CH-1 input selector switch), CH-2 PHONO/LINE input jacks, or CH-2 CD input jacks, and send them to the TRIM control. * When [CH-1] is selected, signals are sent to the CH-2 TRIM

control without being sent through the CH-1 TRIM control.

11 CH-2 TRIM dial

Use to adjust the CH-2 input signal level (range of

adjustment: +9 dB to –∞).

12 MASTER LEVEL dial

User to adjust the master output volume level (range of

adjustment: 0 dB to –∞).

13 Booth monitor level dial

(BOOTH/SESSION OUT)

Use to adjust the volume level of signals at the BOOTH/

SESSION OUT jacks (range of adjustment: 0 dB to –∞).

This level can be set independently of the setting of the MASTER LEVEL dial.

14 Headphones level dial (PHONES)

Use to adjust the volume level of the headphones output

(range of adjustment: 0 dB to –∞).

15 Monitor SELECT switch

MASTER position

selects MASTER output. (This setting allows output regardless of the setting of the MASTER LEVEL dial.)

EFFECT position

Regardless of the [ON/OFF] setting of the EFFECT switch, the output is the signal selected with CUE, with effects added.

CUE position

selects the channel adjusted with the headphone mixing lever (17).

16 CH-2 equalizer dials (HI/MID/LOW)

Use to adjust CH-2 input treble response (range of adjustment: 13 kHz, +6 dB to –26 dB).

MID

Use to adjust CH-2 input midrange response (range of adjustment: 1 kHz, +6 dB to –26 dB).

LOW

Use to adjust CH-2 input bass response (range of adjustment: 70 Hz, +6 dB to –26 dB).

17 Headphone mixing lever (CH-1 – CH-2)

This lever does not function when the monitor SELECT switch (15) is set to [MASTER]. When the monitor SELECT switch (15) is set to [EFFECT] or [CUE], moving the lever to the left side produces CH-1 monitor output, while moving it to the right produces CH-2 monitor output. Centering the lever at the center detent position produces balanced output of CH-1 and CH-2 signals.

18 CH-2 SEND button and indicator

When set to On, the indicator lights, and CH-2 signals are output at the SEND jacks.

19 CH-2 EQ ON/OFF switch and indicator

When set to [ON], the indicator lights and the CH-2 equalizer is enabled. When set to [OFF], the indicator goes out and the equalizer circuit is bypassed.

20 CH-1 FADER START button

When this button is set to On, fader start and back cue can be performed on the CH-1 CD player. Whether the operation is initiated by operation of the CH-1 fader lever, or by the cross fader lever is determined by the position of the front panel’s FADER START selector switch; the selection is indicated by the lighting of the top panel’s CH-1 FADER START indicator or C.F.1 FADER START indicator. * For DJ CD players supporting the fader start/back cue

function, see page 5, “1. Connecting Input Components”.

21 CH-1 output On/Off lever (TRANSFORM)

Use to set CH-1 output to On or Off (Mute). The lever’s setting angle can be changed in 45° increments (changing of the angle should be performed by an authorized Pioneer service technician).

PART NAMES AND FUNCTIONS

22 CH-1 REVERSE indicator

When lighted, indicates that the front panel’s FADER REVERSE switch has been set so that the CH-1 fader lever operates in the reverse direction (see front panel item 52).

23 CH-1 fader lever

The CH-1 fader lever is used to control the level of signals sent to the cross fader. Signal level is maximum at scale mark “10,” and minimum at scale mark “0”. When the front panel CH-1 FADER REVERSE switch is set to [ON], the signal level is maximum at scale mark “0,” and minimum at scale mark “10”. * The channel fader curve can be adjusted by means of the

front panel FADER CURVE dials.

24 CH-1 FADER START indicator

Lights when the CH-1 fader start/back cue function is enabled (see also top panel item 20 and front panel item 53).

25 C.F.1 FADER START indicator

Lights when CH-1 cross-fader start/back cue function is enabled (see also top panel item 20 and front panel item 53).

26 Level meters

Displays CH-1 and CH-2 peak levels or master output (stereo) peak levels (see also item 33).

27 Cross fader REVERSE indicator

Indicates that the front panel’s FADER REVERSE switch has been set so that the cross fader now operates in reverse (left side is CH-2, right side is CH-1) (see also front panel item 52).

32 CH-2 REVERSE indicator

When lighted, indicates that the front panel’s FADER REVERSE switch has been set so that the CH-2 fader lever operates in the reverse direction (see front panel item 52).

33 MASTER LEVEL display button and indicator

When depressed to the On position, the indicator lights and the level meters display the master output (stereo) peak levels. When turned Off, the level meters display the peak levels for CH-1 (left) and CH-2 (right) (see also item 26).

34 CH-2 fader lever

The CH-2 fader lever is used to control the level of signals sent to the cross fader. Signal level is maximum at scale mark “10,” and minimum at scale mark “0”. When the front panel CH-2 FADER REVERSE switch is set to [ON], the signal level is maximum at scale mark “0,” and minimum at scale mark “10”. * The channel fader curve can be adjusted by means of the

front panel FADER CURVE dials.

35 CH-2 FADER START indicator

Lights when the CH-2 fader start/back cue function is enabled (see also top panel item 30 and front panel item 53).

36 C.F.2 FADER START indicator

Lights when CH-2 cross-fader start/back cue function is enabled (see also top panel item 30 and front panel item 53).

28 Cross fader lever

When the lever is moved to the left side, CH-1 is at maximum output and CH-2 is at minimum. When moved to the right side, CH-2 is at maximum output and CH-1 is at minimum. * The cross fader curve can be adjusted individually for CH-1

and CH-2 by means of the front panel FADER CURVE dials.

29 Operating load adjust screw (FEELING ADJ.)

The hexagonal Allen screw located next to the panel’s slider opening can be rotated with a hexagonal Allen driver to adjust the sliding resistance of the cross fader lever. (See page 17,

“Operating load adjust screw”.)

30 CH-2 FADER START button

When this button is set to On, fader start and back cue can be performed on the CH-2 CD player. Whether the operation is initiated by operation of the CH-2 fader lever, or by the cross fader lever is determined by the position of the front panel’s FADER START selector switch; the selection is indicated by the lighting of the top panel’s CH-2 FADER START indicator or C.F.2 FADER START indicator. * For DJ CD players supporting the fader start/back cue

function, see page 5, “1. Connecting Input Components”.

31 CH-2 output On/Off lever (TRANSFORM)

Use to set CH-2 output to On or Off (Mute). This lever’s setting angle can be changed in 45° increments (changing of the angle should be performed by an authorized Pioneer service technician).

PART NAMES AND FUNCTIONS

Top Panel (2)

39 40

42 43

PHONO 1

/LINE 1

CD 1

BANK 1

MIC LEVEL

–

12-12

LOW

12-12

MIC SEND

SESSION IN

–

CH-1 SEND CH-2 SEND

FADER START

TRIM

BANK 2

BANK 3

–

FX ADJ. FX ADJ.

6-26

FADE R

CURVE

MID

BANK EDIT

TIME/SELECT

6-26

LOW

MIX/DEPTH

-26

OFF OFF

TRANSFORM TRANSFORM

PROFESSIONAL 2CHANNEL MIXER

DJM-909

EFFECT EFFECT

MAXMIN

TAP TAP

LOCK ON

OFF

BANK 1

TIME/SELECT

MIX/DEPTH

BANK 2

BANK 3

FADER

CURVE

BANK

EDIT

PHONO 2

/LINE 2

CD 2

CH-1MIC

TRIM

–

MID

LOW

MAXMIN

MASTER LEVEL

–

BOOTH/SESSION OUT

–

6-26

–

6-26

CH-1 CH-2

6-26

FADER START

PHONES

SELECT

MASTER EFFECT CUE

46 47

49 50

37 Touch Panel

Touch this screen to set effects in accordance with the displayed menus. * The panel’s screen contrast and backlight luminance can

be adjusted (see rear panel items 61 and 63).

38 CH-1 effect bank buttons and indicators

(BANK 1, 2, 3)

When one of these buttons is pressed, the indicator lights and the corresponding preset effect is enabled. Each BANK button can be recorded with three effects for CH-1 (at time of shipping, the buttons have been factory preset with typically used effects). BANK 1 is selected in the default condition after power is initially turned on.

39 CH-1 effect parameter adjust button (FX ADJ.)

Press to display the touch panel’s CH-1 effect parameter adjust menu.

40 Fader curve display and CH-1 effect select

button (FADER CURVE/BANK EDIT)

Press to display the fader curve on the touch panel. Holding the button depressed for about one second will cause the touch panel to display the CH-1 effect select menu.

41 CH-1 effect time adjust/select dial

(TIME/SELECT)

Use to adjust the time parameters of effects applied to CH-1 (rotate clockwise to lengthen, counterclockwise to shorten). When the effect select menu is displayed, causes the effects list to scroll.

42 CH-1 effect mix ratio/depth adjust dial

(MIX/DEPTH)

Use to adjust the volume (amount) of effects applied to CH-1 (rotate clockwise to increase effects, counterclockwise to reduce).

PART NAMES AND FUNCTIONS

43 CH-1 effect switch and indicator

(EFFECT LOCK ON/OFF/ON)

To turn effects [ON], either pull switch forward (switch returns automatically to [OFF] when released) or slide to far side to the [LOCK ON] position. When effects are [ON], the indicator flashes and effects are applied to CH-1.

44 CH-1 TAP button

Under normal conditions, the automatic BPM counter operates to display the track’s BPM value on the touch panel. Automatic BPM counting may be difficult with some tracks, however. In such cases, or if you wish to deliberately set a different BPM, use the TAP button.

• The BPM value can be changed by rotating the TIME/ SELECT dial while holding the TAP button depressed.

• Tapping the button in time with the beat will cause the function to switch to the manual BPM count mode; the tapped beat will be counted and displayed as the BPM value. Returning to the auto BPM mode is performed from the effect parameter adjust screen (see page 16,

“Automatic Mode BPM Counting”) .

45 CH-2 effect bank buttons and indicators

(BANK 1, 2, 3)

When one of these buttons is pressed, the indicator lights and the corresponding preset effect is enabled. Each BANK button can be recorded with three effects for CH-2 (at time of shipping, the buttons have been factory preset with typically used effects). BANK 1 is selected in the default condition after power is initially turned on.

49 CH-2 effect mix ratio/depth adjust dial

(MIX/DEPTH)

Use to adjust the volume (amount) of effects applied to CH-2 (rotate clockwise to increase effects, counterclockwise to reduce).

50 CH-2 effect switch and indicator

(EFFECT LOCK ON/OFF/ON)

51 CH-2 TAP button

• The BPM value can be changed by rotating the TIME/SELECT dial while holding the TAP button depressed.

“Automatic Mode BPM Counting”) .

46 CH-2 effect parameter adjust button (FX ADJ.)

Press to display the touch panel’s CH-2 effect parameter adjust menu.

47 Fader curve display and CH-2 effect select

button (FADER CURVE/BANK EDIT)

Press to display the fader curve on the touch panel. Holding the button depressed for about one second will cause the touch panel to display the CH-2 effect select menu.

48 CH-2 effect time adjust/select dial

(TIME/SELECT)

Use to adjust the time parameters of effects applied to CH-2 (rotate clockwise to lengthen, counterclockwise to shorten). When the effect select menu is displayed, causes the effects list to scroll.

PART NAMES AND FUNCTIONS

Front Panel

52 53

FADER REVERSE

CH-1 C.F. CH-2

PROFESSIONAL 2CHANNEL MIXER

DJM-909

FOOT SW

OFF

CH-1

OFF

CH-2

52 FADER REVERSE switches

CH-1 ON/OFF

When set to [ON], the top panel’s CH-1 REVERSE indicator lights, and the CH-1 fader lever operates in the reverse direction (scale mark “0” becomes 0 dB attenuation, and “10” becomes minus infinity). The fader start function also operates in reverse.

CH-2 ON/OFF

When set to [ON], the top panel’s CH-2 REVERSE indicator lights, and the CH-2 fader lever operates in the reverse direction (scale mark “0” becomes 0 dB attenuation, and “10” becomes minus infinity). The fader start function also operates in reverse.

C.F. ON/OFF

When set to [ON], the top panel’s cross fader REVERSE indicator lights, and the cross fader lever operates in the reverse direction (left side becomes CH-2, and right side becomes CH-1). The fader start function also operates in reverse.

53 FADER START selector switches

C.F.1 / CH-1

This switch determines whether the fader start operation for the CD player connected to CH-1 is activated by the cross fader lever, or by the CH-1 fader lever. When the top panel’s CH-1 FADER START button is set to On, selecting [C.F.1] causes the top panel’s C.F.1 FADER START indicator to light, and selecting [CH-1] causes the top panel’s CH-1 FADER START indicator to light.

C.F.2 / CH-2

This switch determines whether the fader start operation for the CD player connected to CH-2 is activated by the cross fader lever, or by the CH-2 fader lever. When the top panel’s CH-2 FADER START button is set to On, selecting [C.F.2] causes the top panel’s C.F.2 FADER START indicator to light, and selecting [CH-2] causes the top panel’s CH-2 FADER START indicator to light.

FADER CURVE

FADER CUT LAG

MAXMIN

565758

FADER ST ART

C.F. 1 CH-1 C.F. 2 CH-2

PHONES

CROSS FADER 2CROSS FADER 1 CH-2CH-1

POWER

54 Headphone output jack (PHONES)

Accepts a 6.3 mm stereo headphones plug.

55 POWER switch

56 Fader attenuation dials (FADER CURVE)

CH-1

Use to adjust CH-1’s fader attenuation curve.

CH-2

Use to adjust CH-2’s fader attenuation curve.

CROSS FADER 1

Use to adjust cross fader’s CH-1 attenuation curve.

CROSS FADER 2

Use to adjust cross fader’s CH-2 attenuation curve.

FADER CUT LAG

Use to adjust mechanical play at both extremes of the cross fader movement (the range in which lever movement produces no effect).

(See page 17, “Fader attenuation curve adjustment”.)

57 Foot switch channel select switch

(FOOT SW CH-1/OFF/CH-2)

Use to select whether the Effect On/Off foot switch function operates on channel 1 [CH-1], channel 2 [CH-2]. When the switch is in the center position, both CH-1 and CH-2 are [OFF].

58 Foot switch jack (FOOT SW)

This 6.3 mm RCA jack can be used to connect an On/Off type pedal switch used to turn effects On and Off. Various types of foot switch are available; some turn On when pressed, some turn Off when pressed, and others have locking mechanisms (alternate On/Off with successive presses). Select the type in accordance with your own preferences.

Rear Panel

PART NAMES AND FUNCTIONS

59 60 61 62 63 64 65

CONTRAST BRIGHT

SEND RETURN

R RL L

(MONO) (MONO)

CH-2 PLAYER

CONTROL

CH-2

R L

MASTER 2

SIGNAL

BOOTH/

SESSION OUT

GND

PHONO

LINE

PHONO

/ LINE

59 CH-2 input jacks

Connect to audio output from CH-2 CD player.

PHONO / LINE

Connect to audio output from CH-2 analog turntable, cassette deck or other line signal level component.

60 External effector output jacks (SEND)

Connect to the input connectors of an external effector. When the top panel switches (MIC SEND, CH-1 SEND, and CH-2 SEND) are set to On, these jacks output the MIC, CH-1, and CH-2 signals to the external effector. When using an effector with a monaural input, connect it to the L channel output only. The signal actually sent to the effector will represent a mix of L and R signals.

MASTER 1

3 COLD 1 GND

2 HOT

CH-1

PHONO

/ LINE

SIGNAL

GND

CH-1 PLAYER

CONTROL

PHONO

LINE

MIC

SESSION IN

67686970717273

67 CH-1 PHONO/LINE selector switch

Use to set the input sensitivity at the CH-1 PHONO/LINE connectors. The [PHONO] position supports an MM type cartridge. * When no analog turntable is used, set this switch to the

[LINE] side.

68 CH-1 signal ground (SIGNAL GND)

Connect to the CH-1 analog turntable’s ground wire. Note that this is not meant as a safety ground.

69 CH-1 PLAYER CONTROL jack

When a Pioneer DJ CD player is connected to the CH-1 CD jacks, a special control cord can be used to connect this jack to the player’s control jack, thus enabling the fader start function.

61 Touch panel screen contrast control (CONTRAST)

Use to adjust the top panel’s touch panel contrast.

62 External effector return jacks (RETURN)

Connect to the output connectors of the external effector. When using an effector with monaural output, connect only to the L channel input. The signal received from the effector will be input to both L and R channels.

63 Touch panel backlight control (BRIGHT)

Use to adjust the top panel’s touch panel backlight luminance.

64 CH-1 input jacks

Connect to the audio output of the CH-1 CD player.

PHONO / LINE

Connect to audio output from CH-1 analog turntable, cassette deck or other line signal level component.

65 Microphone input jack (MIC)

Connect to a microphone with XLR type or PHONE type plug. When applying effects to the microphone sound, set the top panel’s CH-1 input selector switch (MIC–PHONO 1/LINE 1– CD1) to the [MIC] position.

66 Session input jacks (SESSION IN)

When using multiple mixers simultaneously, connect the other mixer outputs to these jacks.

70 MASTER 1 jacks

XLR type balanced output. Connect to the power amplifier’s balanced input jacks.

71 CH-2 PLAYER CONTROL jack

When a Pioneer DJ CD player is connected to the CH-2 CD jacks, a special control cord used to connect this jack to the player’s control jack, thus enabling the fader start function.

72 CH-2 PHONO/LINE selector switch

Use to set the input sensitivity at the CH-2 PHONO/LINE connectors. The [PHONO] position supports an MM type cartridge. * When no analog turntable is used, set this switch to the

[LINE] side.

73 CH-2 signal ground (SIGNAL GND)

Connect to the CH-2 analog turntable’s ground wire. Note that this is not meant as a safety ground.

74 BOOTH/SESSION OUT jacks

Connector jacks for booth monitor output. When using this unit in tandem with another mixer, connect these jacks to the other mixer’s session input jacks.

75 MASTER 2 jacks

RCA type unbalanced output. Connect to the power amplifier’s unbalanced input jacks.

PART NAMES AND FUNCTIONS

Touch Panel Display Contents

BPM

TIME/SELECT

MIX/DEPTH

EDIT 2 CH

PICH

AUTO

BANK 1

BANK 2

BANK 3

120

FADE R CURVE

EDIT

BANK

MAXMIN

BPM

BANK 1

EDIT 1 CH

TIME

BANK 2

LOW MID HI LOW MID HI

AUTO

BANK 3

FX ADJ. FX ADJ.

FADER CURVE

BANK EDIT

TIME/SELECT

EFFECT EFFECT

MIX/DEPTH

MAXMIN

EDIT 2 CH

FOOT

PICH

2000

AUTO

BPM

120

PROFESSIONAL 2CHANNEL MIXER

120

DJM-909

LOCK ON

OFF

TAP TAP

The touch panel display has four basic patterns (A-D). The screen contents shown in the accompanying illustrations depict one example of the basic patterns, while actual displays may differ, depending on the kind of settings and status involved.

A. Effect type display (main page)

This display appears when the power is first turned on, or when one of the BANK (1-3) buttons is pressed. The effects for each channel are displayed as buttons, with the currently selected button displayed in reverse illumination (in this manual, indicated as black characters against white background). Other displays show status of foot switch, selected effect parameters, frequency bands subject to effects, TIME display and BPM display.

CH-1 side EFFECT + | = CH-2 side EFFECT

When a foot switch is connected, FOOT is displayed. The frequency band subjected to effects is highlighted (HI, MID, LOW). BPM count method is displayed (AUTO). Currently selected effect is highlighted (ECHO, PITCH SHIFTER).

EDIT 1 CH

FOOT

TIME

LOW MID HI LOW MID HI

AUTO

2000

120

BPM

B. Effect select display

Hold the FADER CURVE/BANK EDIT button depressed for about one second to change the screen to the main page effect select menu (settable independently for each channel). Rotate the TIME/SELECT dial to select the effect to be allocated to each button from the list of 50 effects displayed (see page 23, “Presetting effects”).

Effect list (ECHO)

(Example): CH-1 side.

The button being edited (here, ECHO) appears highlighted.

CH 1 BANK EDIT

≠

1.DELAY

.ECHO

NEC

3.P

4.PIT

5.R

DLY EC

6.DK L

7.ROL

C. Effect parameter adjust display

Press the FX ADJ. button to display the effect parameter adjust menu (settable independently for each channel). From this menu, BPM AUTO can be selected. Also, effect selection (cross fader / channel fader) can be selected for fader type.

AUTO

BPM

ECHO

TIME

FOOT

2000120

Select frequency band for effect (HI, MID, LOW).

Select effect parameter (4/1).

CH1

Select method of BPM count (BPM AUTO).

D. Fader status display

Press the FADER CURVE/BANK EDIT button to view the fader status in a graphic display. By rotating the front panel FADER CURVE dial, the various attenuation responses can be set in 33 steps, and each step number also displayed. The amount of cross fader lag is also given a numerical display.

FADER CURVE

CH-1 fader data =

CH 1 CH 2

NOR

M AL

CF 1

32 32

NOR

M AL

FADER CUT LAG : 1 .0

Cross fader lag data (FADER CUT LAG)

CF 2

1616

NOR

+ CH-2 fader

M AL

data

+ Cross fader

data

Touch Panel Display Selection

Changing between the touch panel’s four basic display patterns (A, B, C, D) is performed by pressing the operating buttons at the panel’s sides.

Effect select display

CH 1 BANK EDIT

FADER

Hold FADER CURVE/BANK

CURVE

EDIT button depressed.

BANK EDIT

PART NAMES AND FUNCTIONS

Effect parameter adjust display

ECHO

FOOT

TIME

AUTO

CH1

BPM

2000120

1.DELAY

.ECHO

NEC

3.P EC

4.PIT

5.R

DLY EC

6.DK

7.ROL

Press FADER CURVE/ BANK EDIT button.

Turn power ON

Hold FADER CURVE/BANK EDIT button depressed.

Hold FADER CURVE/ BANK EDIT button depressed.

FADER CURVE

BANK EDIT

POWER

FADER CURVE

BANK EDIT

Press FADER CURVE/ BANK EDIT button.

FADER CURVE

BANK EDIT

Effect type display (main page)

2000

120

FOOT

EDIT 2 CH

PICH

AUTO

BPM

EDIT 1 CH

TIME

LOW MID HI LOW MID HI

AUTO

Press FADER CURVE/ BANK EDIT button.

NOR

M AL

CH 1

FADER CURVE

BANK EDIT

FADER CURVE

CH 2

FADER CURVE

BANK EDIT

BPM

120

Press FX ADJ. button.

1616

NOR

M AL

Press FX ADJ. button.

FX ADJ.

BANK 1

BANK 2

BANK 3

FX ADJ.

Press FX ADJ. button.

Press BANK buttons.

FADER CURVE

Press FADER CURVE/

BANK

BANK EDIT button.

EDIT

CF 1

32 32

NOR

M AL

FADER CUT LAG : 1 .0

Fader status display

CF 2

BPM COUNTING

Automatic Mode BPM Counting

This function automatically counts the track’s speed in BPM (Beats Per Minute), displaying the results as a numerical value. The functions does not merely count the bass beat, but uses a computer to calculate the track’s original BPM required by the DJ. The display provides a visual standard in addition to the human ear, thus allowing the DJ to quickly match two tracks possessing differing speeds. When auto mode is used to count BPM, the calculated BPM value is displayed on the LCD panel, allowing quick matching of tracks with differing speeds. (Counting range: 70.0 to

180.0 BPM) The display flashes during BPM counting. * Some tracks may not be counted properly, in which case

manual count should be used. (See page 11, top panel items 44, 51)

Touch panel (main page)

AUTO lights in auto mode.

BPM value display

EDIT 1 CH

TIME

LOW MID HI LOW MID HI

AUTO

2000

120

FOOT

EDIT 2 CH

PICH

TAP

BPM

120

BPM

BPM value display

TAP lights during manual count mode (TAP button input)

7 Selecting Auto Mode

1. Press the FX ADJ. button to cause the touch panel screen to display the effect parameter adjust menu.

If the CH-1 FX ADJ. button is pressed, the CH-1 display appears; if the CH-2 FX ADJ. button is pressed, the CH-2 display appears.

BANK 1

ECHO

BANK 2

FOOT

TIME

TAP

CH1

BPM

BANK 3

FX ADJ. FX ADJ.

FADER CURVE

BANK EDIT

2000120

BANK 1

BANK

BANK 3

FADER CURVE

BAN

EDIT

2. Press the BPM TAP button (displayed in manual mode), to display the BPM AUTO button.

BANK 1

BANK 2

BANK 3

CH1

ECHO

FOOT

TIME

TAP

BPM

2000120

BANK 1

BANK

BANK 3

¶ The BPM value can be input directly by rotating

the TIME/SELECT dial while holding the TAP button depressed.

FX ADJ. FX ADJ.

FADER CURVE

BANK EDIT

FADER CURVE

BAN

EDIT

FADER OPERATIONS

Adjusting Fader Lever Operating Sensation

Operating load adjust screw (FEELING ADJ.)

The supplied hexagonal Allen driver can be used to adjust the hexagonal Allen screw located next to the top panel’s cross fader slider opening, thus modifying the sliding resistance of the lever. Rotate the screw clockwise to increase sliding resistance and counterclockwise to reduce resistance.

REVERSE

FEELING ADJ.

Cross fader lag adjustment

The mechanical play (the lag or range of movement in which no functional effect takes place) at the two extreme ends of the top panel cross fader lever movement can be adjusted by using the front panel’s FADER CUT LAG dial, within a range of 1-6 mm.

Press FADER CURVE/BANK EDIT button.

FADER REVERSE

CH-1 C.F. CH-2

OFF

OFFONOFF

FOOT SW

CH-1

OFF

CH-2

BANK 1

FADER CURVE

CH 1 CH 2

FADER CURVE

BANK EDIT

NOR

M AL

CF 1

32 32

NOR

M AL

FADER CUT LAG : 1 .0

BANK 2

BANK 3

FX ADJ. FX ADJ.

1616

CF 2

Cross fader cut lag dimension display

FADER START

PROFESSIONAL 2CHANNEL MIXER

DJM-909

FADER CURVE

CROSS FADER 2CROSS FADER 1 CH-2CH-1

FADER CUT LAG

MAXMIN

C.F. 1 CH-1 C.F. 2 CH-2

NOR

M AL

BANK 1

BANK

BANK 3

FADER CURVE

PHONES

BAN

EDIT

POWER

Lag Lag

REVERSE

FEELING ADJ.

FADER 1

FADER CURVE

CROSS

FADER CUT LAG

MAXMIN

Fader attenuation curve adjustment

The front panel’s FADER CURVE dials can be used to adjust the attenuation curve response of the cross fader and channel fader. The cross fader can be adjusted independently for CH-1 and CH-2 sides. By pressing the top panel’s FADER CURVE/BANK EDIT button, the adjustment status can be displayed on the touch panel.

7 Channel fader curve adjustment (CH-1, CH-2)

LEVEL

012345678910 012345678910

Channel fader lever positions

Cross fader curve adjustment (CROSS FADER 1, 2)

LEVEL

012345678910

Fader reverse function

The operating directions of the CH-1, CH-2 and cross fader levers can be reversed by setting the front panel’s FADER REVERSE switches to their [ON] positions.

When the CH-1 (or CH-2) FADER REVERSE switch is set to [ON], the top panel CH-1 (or CH-2) REVERSE indicator lights, and the corresponding lever’s operating direction is reversed (scale mark “0” becomes attenuation 0 dB, while scale mark “10” becomes minus infinity). The fader start function also operates in reverse. When the C.F. FADER REVERSE switch is set to [ON], the top panel’s cross fader REVERSE indicator lights, and the lever operating direction is reversed (left side becomes CH-2 and right side becomes CH-1). The fader start function also operates in reverse.

FADER REVERSE

CH-1 C.F. CH-2

OFF

Fader Start Function

When the CH-1 and CH-2 jacks of this unit are connected to a separately sold Pioneer DJ CD player (models CDJ-1000, CDJ-1000MK2, CDJ-800, CDJ-100S, CDJ-700S, CDJ-500II, CMX-3000, CMX-5000 or DMP-555), the channel fader and cross fader functions can be used to automatically start playback of the connected CD player (the applicable control cord must be connected). By moving the mixer’s channel fader or cross fader lever, the CD player’s pause function is released and play starts instantly. Also, by returning the fader lever to its original position, the CD player can be returned to its cue point (back cue function), thus allowing sampling playback.

Cross fader lever positions

FADER OPERATIONS

Cross fader start play and back cue play

When the CH-1 CD player is held in standby at the cue point, merely moving the cross fader lever from the right (CH-2) side to the left (CH-1) side will cause the CH-1 CD player to begin playback. When the cross fader lever reaches the left (CH-1) side, CH-2 CD player performs back cue (returns to its cue point). Likewise, when the CH-2 CD player is in standby at its cue point, moving the cross fader lever from the left (CH-1) side to the right (CH-2) side causes CH-2 CD player to begin playback. When the cross fader lever reaches the right (CH-2) side, CH-1 CD player performs back cue. * Back cue is performed even if the input selector switch is

not set to CD.

Start playback with channel fader 1 To control a connected CD player, set the front

panel FADER START selector switch for the corresponding channel to its [CH-1] or [CH-2] position.

When using the CH-1 fader lever to start the CH-1 CD player, set the front panel C.F.1/CH-1 switch to the [CH-1] position; when using the CH-2 fader lever to start the CH-2 CD player, set the front panel C.F.2/CH-2 switch to [CH-2] position.

FADER START

C.F. 1 CH-1 C.F. 2 CH-2

2 Press the top panel FADER START button so that

the indicator lights.

When the CH-1 FADER START button is pressed, the CH-1 FADER START indicator lights. When the CH-2 FADER START button is pressed, the CH2 FADER START indicator lights.

3 Set the channel fader lever to the [0] scale mark. 4 Adjust the CD player to its cue point and set for

cue point standby.

5 Begin moving the channel fader lever with the

timing you wish, thereby beginning playback on the CD player.

FADER START

÷ If the cue point has already been set, there is no need to

set the CD player again for standby at the cue point.

÷ After playback has once begun, moving the channel fader

lever back to the “0” scale mark will cause the CD player to return to its cue point and enter the standby mode again (back cue).

Start playback with cross fader 1 To control a connected CD player, set the front

panel FADER START selector switch for the corresponding channel to its [C.F.1] or [C.F.2] position.

When using cross fader lever to start the CH-1 CD player, set the front panel C.F.1/CH-1 switch to the [C.F.1] position; when using the cross fader lever to start the CH-2 CD player, set the front panel C.F.2/CH-2 switch to [C.F.2] position.

FADER START

C.F. 1 CH-1 C.F. 2 CH-2

2 Press the top panel FADER START button so that

the indicator lights.

When the CH-1 FADER START button is pressed, the C.F.1 FADER START indicator lights. When the CH-2 FADER START button is pressed, the C.F.2 FADER START indicator lights.

3 Move the cross fader lever to the side opposite

from the channel you wish to start.

4 Adjust the CD player to its cue point and set for

cue point standby.

5 Begin moving the cross fader lever with the

timing you wish, thereby beginning playback on the CD player.

FADER START

REVERSE

C.F.1 FADER START

CH-1 FADER ST AR T

REVERSE

CH-1 CH-2

9 8 7 6 5 4 3 2 1 0

REVERSE

FEELING ADJ.

÷ If the cue point has already been set, there is no need to

set the CD player again for standby at the cue point.

9 8 7 6 5 4 3 2 1 0

CH-2 FADER ST AR

÷ If the cross fader lever is moved fully after the beginning of

playback, the opposite channel’s CD player will return to its cue point and enter standby there (back cue).

EFFECT FUNCTIONS

Types of Effects

This unit is equipped with a beat effector linked to the BPM, and fader effector linked to the channel or cross fader, producing a total of 50 basic effects, but an even wider variety of effects can be produced by varying the parameters of each effect.

Beat Effector (effects linked to BPM)

Name

1 DELAY (*1)

2 ECHO (*1)

3 PAN ECHO (*1)

4 PITCH ECHO (*1)

5 REVERSE DELAY (*1)

6 DUCKING ECHO (*1)

7 ROLL (*2)

8 HOLD ECHO (*1) (*2)

9 MULTI TAP DELAY (*1)

10 RAIN (*1)

11 REVERB1 (*1)

12 REVERB2 (*1)

13 REVERB3 (*1)

14 PITCH SHIFTER1

15 PITCH SHIFTER2

16 PAN

17 TRANS

18 RHYTHM TRANS

19 TRANS PAN

20 TREMOLO

21 VIBRATO

In time with BPM, outputs repeat sound once.

In time with BPM, outputs repeat sound several times, while diminishing.

In time with BPM, outputs repeat sound, alternately to left and right.

In time with BPM, outputs repeat sound while changing pitch.

In time with BPM, outputs repeat sound in reverse of playback direction.

Outputs repeat sound when input sound level drops below a certain point.

With the turning ON of the EFFECT switch as a trigger, the input sound is recorded, and the recorded sound is repeated in units of individual beat.

In time with BPM, outputs repeat sound several times while diminishing. Repeat sound is preserved even if EFFECT switch is turned OFF.

Output delay sound in time with beat, at intervals of preset delay time.

Outputs sound with feeling of being in water.

Produces reverberation sound similar to that of a garage-sized room.

Produces reverberation sound similar to that of a large hall.

Hall reverberation (echo) is added to sound lag timed to BPM.

Allows changing of pitch within range of ± 1 octave.

Outputs three types of pitches together with preset pitches.

In time with BPM, outputs sound alternately to left and right.

In time with BPM, cut sound.

Cut sound in time with BPM and preset pattern.

In time with BPM, cut long-period PAN outputs at set time.

Produces wavering sound by applying tonal modulation.

Apply modulation to frequency, thus producing tonal variation.

Function

FX ADJ. Parameter (touch panel)

Set delay time of 1/8 to 8/1 of each beat of BPM.

Set delay time of 1/8 to 2/1 of each beat of BPM; and set pitch shifter up or down.

Set delay time of 1/8 to 8/1 of each beat of BPM.

Set effect time of 1/8 to 8/1 of each beat of BPM.

Set delay time of 1/8 to 8/1 of each beat of BPM.

Set delay time of 1/4 to 1/1 of each beat of BPM; select delay pattern; and set feedback ON/OFF.

Set delay time of 1/8 to 8/1 of each beat of BPM.

8 patterns can be set based on different filters.

Set delay time of 1/8 to 4/1 of each beat of BPM.

Set amount of pitch shift.

Set type of changing pitch harmonies.

Set right-left allocation time in units of 1/8 to 8/1 of each beat of BPM.

Set cut time in units of 1/8 to 8/1 of each beat of BPM.

Set effect time of 1/2 to 2/1 of each beat of BPM; and select cut pattern.

Set cut time in units of 1/16 to 1/1 of each beat of BPM; and set PAN period.

Set modulation period based on beats calculated from BPM.

(*1) When the channel fader or cross fader is used to lowering sound volume, no effect sounds will be heard, even if monitor

SELECT switch is set to the [EFFECT] position.

(*2) When EFFECT switch is turned OFF, no effect sounds will be heard even if the monitor SELECT switch is set to the [EFFECT]

position.

EFFECT FUNCTIONS

Name

22 CHORUS1

23 CHORUS2

24 CHORUS3

25 FLANGER1

26 FLANGER2

27 PHASER1

28 PHASER2

29 TOUCH PHASER

30 TOUCH PHASER2

31 FILTER (LPF)

32 FILTER (HPF)

33 FILTER (BPF)

34 FILTER PAN

35 COMPRESSOR

Function

Produces broadened musical effect resembling the production of same pitch sounds from multiple sources.

Produces even broader musical effect than CHORUS1.

Changes degree of waver in chorus sound.

Produce flange effect by adding delayed sound. In time with BPM, change frequency band receiving flange effect.

In time with BPM, change frequency band receiving flange effect, thus producing either undulating or rotating effect.

Phase effect is produced by adding sound with delayed phase. The phase-affected frequency band changes in time with BPM.

Phase-affected frequency band changes in time with BPM. Phase effect change is inverted between L and R.

Phase effect is produced in correspondence to input volume. The higher the input volume, the higher the frequencies producing the effect.

Phase effect is produced in correspondence to input volume. The higher the input volume, the lower the frequencies producing the effect.

Change low-pass filter’s cutoff frequency in time with BPM.

Change high-pass filter’s cutoff frequency in time with BPM.

Change band pass filter’s center frequency in time with BPM.

In time with BPM, bass and treble sounds pan in opposite directions.

Inputs above the threshold level are compressed before output.

FX ADJ. Parameter (touch panel)

Set period of chorus wavers based on beats calculated from BPM.

Set period of chorus waver based on beats calculated from BPM, and set degree of chorus sound waver.

Set period of flange effect shift based on beats calculated from BPM.

Set period of phase effect shift based on beats calculated from BPM.

Set the number of filter stages producing the phase effect. Greater numbers of stages produce deeper effects.

Set period of cutoff frequency shift based on beats calculated from BPM.

Set period of center frequency shift based on beat calculated from BPM.

Set period of cutoff frequency shift based on beats calculated from BPM.

Set degree of compression.

Fader Effector (effects linked to channel or cross fader)

Name

36 FADER ROLL (*2)

37 FADER MULTI TAP DELAY

(*1)

38 FADER TRANS PAN

39 FADER PITCH SHIFTER

40 FADER RING

41 FADER VOCODER1

42 FADER VOCODER2

43 FADER FILTER (LPF)

44 FADER FILTER (HPF)

45 FADER FILTER (BPF)

46 FADER FLANGER

47 FADER PHASER

48 FADER SYNTHE1

49 FADER SYNTHE2

50 FADER SYNTHE3

EFFECT switch turn ON or fader position is used as trigger to record input sound, and then output the sound repeatedly within range of 1/1 to 1/16 beat.

At preset intervals repeat sound is output at 1/1 to 1/16 beat set with fader.

In time with the BPM, long-period PAN output is cut at time corresponding to fader position.

In response to fader position, pitch of input sounds is changed.

Produces metallic bass sound effect.

Vocoder effect; modulates internal oscillator sound in response to input sound. Depending on fader position, changes internal oscillator sound’s fundamental frequency. 7 code sounds can be added.

Changes low-pass filter’s cutoff frequency, depending on fader position.

Changes high-pass filter’s cutoff frequency, depending on fader position.

Changes band-pass filter’s center frequency depending on fader position.

Changes frequency band subjected to flanger effect, depending on fader position.

Changes frequency band subjected to phaser effect, depending on fader position.

Outputs sine wave sound source.

Outputs sawtooth wave sound source.

Outputs square wave sound source.

Function

EFFECT FUNCTIONS

FX ADJ. Parameter (touch panel)

Select either channel fader or cross fader. Set base ROLL time to 1/2, 1/1, or 2/1.

Select either channel fader or cross fader. Set basic beat time of 1/2 to 2/1 for each BPM beat, and set delay pattern selection.

Select either channel fader or cross fader. Set PAN operation period and basic effect time to be cut with fader.

Select either channel fader or cross fader. Set type of pitch change.

Select either channel fader or cross fader. Set frequency of sound effect.

Select either channel fader or cross fader. Set code type.

Select either channel fader or cross fader.

Select either channel fader or cross fader. Set number of filter stages producing phase effect. Greater numbers of stages produce deeper effects.

Select either channel fader or cross fader. Select frequency equivalent to note “DO”.

(*1) When the channel fader or cross fader is used to lowering sound volume, no effect sounds will be heard, even if monitor

SELECT switch is set to the [EFFECT] position.

(*2) When EFFECT switch is turned OFF, no effect sounds will be heard even if the monitor SELECT switch is set to the [EFFECT]

position.

EFFECT FUNCTIONS

Using the Effect Functions

The basic procedures is as follows: [Select effect type] = [Set parameters (while monitoring through headphones] =[Set EFFECT switch to ON]. Below are examples of this basic operation procedure; other effects are produced in much the same way:

[Example 1] Apply delay to CH-1 track:

1. Touch the touch panel’s CH-1 (left side) DELAY button (select effect type).

• If the DELAY button is not displayed, select and display

the button as follows:

1Hold the CH-1 (left side) FADER CURVE/BANK EDIT

button depressed for about 1 second to set the touch panel to the effect select menu.

2Of the touch panel’s three buttons, select (touch) the

one in which you wish to record the DELAY.

3Rotate the TIME/SELECT dial to select DELAY. 4Press (touch) the MEMORY button. 5Press the FADER CURVE/BANK EDIT button to leave

the effect select menu.

• If DELAY is preset in the BANK 1, 2, or 3 buttons,

DELAY can be selected by pressing the corresponding button (see page 23 “Presetting Effects.”)

2. Press the CH-1 (left side) FX ADJ. button to display the effect parameter adjust menu on the touch panel.

3. Use the touch panel’s LOW, MID, and HI buttons to select the frequency ranges for the effect.

• The selected range button will appear highlighted. * It may not be possible to select the frequency range,

depending on the type of effect.

4. Press the touch panel’s 1/8 to 8/1 buttons as desired to select the delay time (parameter value setting).

• Set delay time of 1/8 to 8/1 for each beat of BPM.

• Set monitor SELECT switch to [EFFECT] to confirm the

effect sound through the headphones (effects marked with the note *1 on the effects chart cannot be heard unless the EFFECT switch is set to [ON]).

• The TIME/SELECT dial can be rotated to produce even

finer delay time settings. Setting delay time of 1/2 per beat of tempo (BPM) will cause the touch panel’s 1/2 button to be highlighted, and this can be used as a general reference when adjusting the parameter.

5. Use the MIX/DEPTH dial to set the level balance between sound source and delay sound.

• Rotate to left to reduce, and rotate to right to increase

the delay sound.

6. Set EFFECT switch to [ON] or [LOCK ON].

• The EFFECT indicator will begin flashing red, and the

effect (delay) will be applied to the master output.

• When the EFFECT switch is set to [ON] by pulling the

switch forward, the switch will automatically return to [OFF] when released.

Note:

• Select effects only when the EFFECT switch is in the [OFF]

position. If effects are selected when the EFFECT switch is in the [LOCK ON] position, noise may be produced.

[Example 2] Apply fader roll to CH-1 track

1. Touch the touch panel’s CH-1 (left side) FADER ROLL button (select effect type).

• If the FADER ROLL button is not displayed, select and

display the button as follows:

1Hold the CH-1 (left side) FADER CURVE/BANK EDIT

button depressed for about 1 second to set the touch panel to the effect select menu.

2Of the touch panel’s three buttons, select (touch) the

one in which you wish to record the FADER ROLL.

3Rotate the TIME/SELECT dial to select FADER ROLL. 4Press (touch) the MEMORY button. 5Press the FADER CURVE/BANK EDIT button to leave

the effect select menu.

• If FADER ROLL is preset in the BANK 1, 2, or 3 buttons,

FADER ROLL can be selected by pressing the corresponding button (see page 23 “Presetting

Effects.”)

2. Press the CH-1 (left side) FX ADJ. button to diplay the effect parameter adjust menu on the touch panel.

3. Use the touch panel’s LOW, MID, and HI buttons to select the frequency ranges for the effect.

• The selected range button will appear highlighted. * It may not be possible to select the frequency range,

depending on the type of effect.

4. Press the touch panel’s 1/2, 1/1, and 2/1 buttons as desired to select the roll time (parameter value setting).

• Standard roll times can be set as 1/2, 1/1, or 2/1.

• Set monitor SELECT switch to [EFFECT] to confirm the

effect sound through the headphones (effects marked with the note *1 on the effects chart cannot be heard unless the EFFECT switch is set to [ON]).

• The TIME/SELECT dial can be rotated to produce even

finer roll time settings. Setting roll time to 1/1 per beat of tempo (BPM) will cause the touch panel’s 1/1 button to be highlighted, and this can be used as a general reference when adjusting the parameter.

5. Use the MIX/DEPTH dial to set the roll sound level.

• Rotate to left to reduce, and rotate to right to increase

the roll sound.

6. Use touch panel’s CROSS FADER button to select fader.

• The fader used for fader effects can be set to either

channel fader or cross fader.

7. Set EFFECT switch to [ON] or [LOCK ON].

• The EFFECT indicator will begin flashing red, and the

effect will be applied to the master output.

• When the EFFECT switch is set to [ON] by pulling the

switch forward, the switch will automatically return to [OFF] when released.

Note:

• Make selection of effects and type of fader (channel or cross)

only when the EFFECT switch is in the [OFF] position. If effects are selected when the EFFECT switch is in the [LOCK ON] position, noise may be produced.

Presetting Effects

Of the effects displayed on the touch panel’s main page (effect type menu), three types can be set for each channel CH-1 and CH-2 in the BANK buttons (1/2/3). The preset effects can then be called up at a single touch.

1. Select the channel (CH-1/CH-2) whose preset value you wish to change.

• Press and hold depressed for about one second the

FADER CURVE/BANK EDIT button corresponding to the channel (CH-1/CH-2) in which you wish to change the effect setting. The touch panel will change to show the effect selection menu for the chosen channel.

2. Change the effect

1Press the BANK button (1/2/3) whose setting you wish

to change.

2Of the three touch panel buttons, press (touch) the one

in which you wish to record a new effect.

3Rotate the TIME/SELECT dial to select effect. 4Press (touch) the touch panel’s MEMORY button.

If a different BANK button is pressed or EFFECT switch operated without first pressing the MEMORY button, no effect will be recorded.

EFFECT FUNCTIONS

BPM

TIME/SELECT

MIX/DEPTH

BANK 1

BANK 2

BANK 3

FADE R CURVE

BANK 1

EDIT 1 CH

TIME

BANK 2

LOW MID HI LOW MID HI

AUTO

BANK 3

FX ADJ. FX ADJ.

FADER

CURVE

BANK EDIT

TIME/SELECT

EFFECT EFFECT

MIX/DEPTH

MAXMIN

EDIT 2 CH

FOOT

PICH

2000

AUTO

BPM

120

PROFESSIONAL 2CHANNEL MIXER

120

DJM-909

LOCK ON

OFF

TAP TAP

BANK

EDIT

MAXMIN

• Up to three effects can be recorded in a single BANK

button. Repeat steps 2–4 to record the presets.

3. Leave the effect selection (BANK EDIT) menu

• Press the FADER CURVE/BANK EDIT button to leave

the effect selection menu.

DLY

I V V

B B

1 2

TIME/SELECT

MIX/DEPTH

BANK 1

BANK 2

BANK 3

FADE R CURVE

BANK 1

CH 1 BANK EDIT

BANK 2

BANK 3

FX ADJ. FX ADJ.

FADER

CURVE

BANK EDIT

TIME/SELECT

EFFECT EFFECT

MIX/DEPTH

MAXMIN

1.DELAY

2.ECHO A

NEC

3.P

4.PIT V

5.R

6.DK

7.R

HLD

9.T

10.

11 . 12 .RE

PROFESSIONAL 2CHANNEL MIXER

DJM-909

LOCK ON

OFF

TAP TAP

BANK

EDIT

MAXMIN

EFFECT FUNCTIONS

Effect Parameters

The 50 built-in effects can be modified by parameters for time and amount to produce a wider variety of effects. Operate the TIME/ SELECT dial to adjust time parameters (parameter 1), and use the MIX/DEPTH dial to adjust amount parameters (parameter 2). Also with fader effects, the position of the fader lever can be used to produce changes resulting in an even wider range of effects.

7 Beat effects

No.

Name

DELAY (*1)

ECHO (*1)

PAN ECHO (*1)

PITCH ECHO (*1)

REVERSE DELAY (*1)

DUCKING ECHO (*1)

ROLL (*2)

HOLD ECHO (*1) (*2)

MULTI TAP DELAY (*1)

RAIN (*1)

REVERB1 (*1)

REVERB2 (*1)

REVERB3 (*1)

PITCH SHIFTER1

PITCH SHIFTER2

PAN

TRANS

RHYTHM TRANS

TRANS PAN

TREMOLO

VIBRATO

CHORUS1

CHORUS2

CHORUS3

FLANGER1

FLANGER2

Parameter 1 (TIME/SELECT dial)

Explanation

Set delay time.

Set effect time.

Set delay time.

Set effect time.

Reverberation time

Delay time

Set pitch to be changed.

Set type of harmonization.

Set effect time.

Fine setting of modulation period.

Set period of chorus modulation.

Set period of flange effect frequency shift.

Setting range (unit)

1 – 10000 (msec)

40 – 10000 (msec)

10 – 10000 (msec)

1 – 10000 (msec)

10 – 10000 (msec)

2 – 10000 (msec)

8 – 1200 (msec)

40 – 10000 (msec)

10 – 200 (%)

10 – 5000 (msec)

–100 to +100 (%)

1 – 5

10 – 16000 (msec)

10 – 8000 (msec)

10 – 2000 (msec)

10 – 16000 (msec)

1 – 16000 (msec)

10 – 32000 (msec)

Parameter 2 (MIX/DEPTH dial)

Explanation

Set balance between source and delay sounds.

Set balance between source and echo sounds.

Set balance between source and delay sounds.

Set balance between source and echo sounds. No effect sounds will be heard if the input sounds are above a certain level even when the dial is rotated fully to the right.

Set balance between source and ROLL sounds.

Set balance between source and echo sounds.

Set balance between source and delay sounds.

Rotate to right to increase effect.

Change amount of reverberation.

Change volume of echo sound + reverb sound.

Set balance between source and pitch-shifted sounds.

Set balance between source and effect sounds.

Change the sound volume waver.

Change the frequency waver.

Change the chorus sound volume.

Rotate to right for stronger effect.

EFFECT FUNCTIONS

No.

PHASER1

PHASER2

TOUCH PHASER1

TOUCH PHASER2

FILTER (LPF)

FILTER (HPF)

FILTER (BPF)

FILTER PAN

COMPRESSOR

Name

Parameter 1 (TIME/SELECT dial)

Explanation

Set period of phase effect frequency shift.

Set sensitivity corresponding to input volume.

Set period of cutoff frequency shift.

Set period of center frequency shift.

Set period of cutoff frequency shift.

Set time until completely compressed. The time required to return to the original state is simultaneously set at the same value.

Setting range (unit)

10 – 32000 (msec)

1 – 100 (%)

10 – 32000 (msec)

1 – 100 (msec)

Parameter 2 (MIX/DEPTH dial)

Explanation

Rotate to right for stronger effect.

Rotate to right for increased resonance and more unusual sound.

Change threshold level. Rotate to right for stronger effect.

(*1) When the channel fader or cross fader is used to lowering sound volume, no effect sounds will be heard, even if monitor

SELECT switch is set to the [EFFECT] position.

(*2) When EFFECT switch is turned OFF, no effect sounds will be heard even if the monitor SELECT switch is set to the [EFFECT]

position.

7 Fader effects

Fader lever

Explanation

Change roll time

Change reference beat time.

Change cut time

Change pitch of input sound.

Change frequency of effect sound

Change fundamental frequency of oscillating sound.

Changes cutoff frequency of lowpass filter.

Changes cutoff frequency of highpass filter.

Changes band-pass filter’s center frequency.

No.

Name

FADER ROLL (*2)

FADER MULTI TAP DELAY (*1)

FADER TRANS PAN

FADER PITCH SHIFTER

FADER RING

FADER VOCODER1

FADER VOCODER2

FADER FILTER (LPF)

FADER FILTER (HPF)

FADER FILTER (BPF)

Parameter 1 (TIME/SELECT dial)

Explanation

Set reference ROLL time

Set reference effect time

Set reference effect time.

Set type of pitch change.

Change fundamental frequency of effect sound.

Set sensitivity corresponding to input volume

—

Setting range (unit)

40 – 10000 (msec)

8 – 1200 (msec)

40 – 2000 (msec)

1 – 3

500 – 8000 (Hz)

1 – 100 (%)

—

Parameter 2 (MIX/DEPTH dial)

Explanation

Set balance between source and ROLL sounds.

Set balance between source and delay sounds.

Set balance between source and effect sounds.

Set balance between source and pitch-shifted sounds.

Change effect sound level.

Adjust volume of code selected on panel menu.

Rotate to right for increased resonance and more unusual sound.

EFFECT FUNCTIONS

Fader lever

Explanation

Changes frequency

No.

FADER FLANGER

Name

Parameter 1 (TIME/SELECT dial)

Explanation

—

Setting range (unit)

—

Parameter 2 (MIX/DEPTH dial)

Explanation

Rotate to right for increased effect.

band subject to flange effect.

FADER PHASER

—

Rotate to right for increased effect.

Changes frequency band subject to phase effect.

FADER SYNTHE1

FADER SYNTHE2

Base frequency

40 – 23999 (Hz)

40 – 23899 (Hz)

Left half changes volume, right half changes volume of the set frequency.

Left half changes volume, right half changes volume of neighboring

Changes to stairstepped sound.

frequency.

FADER SYNTHE3

Base frequency

40 – 23899 (Hz)

Left half changes volume, right half changes volume of neighboring

Changes to stairstepped sound.

frequency.

(*1) When the channel fader or cross fader is used to lowering sound volume, no effect sounds will be heard, even if monitor

SELECT switch is set to the [EFFECT] position.

(*2) When EFFECT switch is turned OFF, no effect sounds will be heard even if the monitor SELECT switch is set to the [EFFECT]

position.

BLOCK DIAGRAM

MIC

PHONO

/LINE

CH-1

PHONO

/LINE

CH-2

SESSION

FOOT SW

OFF

CH-1

CH-2

RIAA

PHONO

LINE

PHONO

LINE

EFX CONTROL

MIC

/LINE

CH-1

MIC LEVEL

2-BAND EQ.

3-BAND EQ.

CH-1 TRIM

3-BAND EQ.

CH-2 TRIM

MIC, CH-1, CH-2 SEND RETURN IN

B A

OFF

SESSION IN

H.P. CH-1

LEVEL CH-1

H.P. CH-2

LEVEL CH-2

OFF OFF

OFF

EFFECT

OFF ON ON OFF

ON OFF ON OFF

OFF

ON ON

MIC SEND

H.P. EFX CH-1

CH-1 SEND

H.P. EFX CH-2

CH-2 SEND

SEND

MIX

H.P.F.

MASTER LEVEL

H.P. MASTER

LEVEL MASTER

MASTER 1 MASTER 2

BOOTH/SESSION OUT

H.P. MASTER

H.P. EFX CH-1

H.P.

CH-1

H.P. EFX CH-2

H.P. CH-2

LEVEL CH-1

LEVEL CH-2

LEVEL MASTER

MASTER

EFFECT

CUE

CH-1

CH-2

PHONES

CH-1/CH-2

MASTER LEVEL(L/R)

BOOTH/ SESSION OUT

PHONES

LEVEL METER

14 9 5 3 1 0

–

22 dB dB

CH-1 CH-2

14 9 5 3 1 0

–

SEND

EFFECTOR

RETURN

VOLTAGE CONTROL SIGNAL

LAG CUT CONTROL

VCA CONTROL

CROSS FADER

FADER CURVE CH-1, CH-2, CROSS

FADER REVERSE CH-1, CH-2, CROSS

TRANS CH-1, CH-2

TROUBLESHOOTING

Incorrect operations are often mistaken for trouble and malfunctions. If you think there is something wrong with this component, check the points below. Sometimes the trouble may originate from another component. Thus, also check the other electrical appliances also in use. If the trouble cannot be rectified even after checking the following items, contact your dealer or nearest PIONEER service center.

Problem Possible Cause Countermeasure

The power does not turn on.

There is little or no sound.

Sound is distorted.

CD player’s fader won’t start.

Effects don’t work.

÷ The power cord has not been connected.

÷ The Input selector switch is in the wrong

position.

÷ The rear panel’s PHONO/LINE selector switch is

set to [LINE] when a analog turntable is connected to the input connectors.

÷ The connection cable hasn’t been connected

properly or has been disconnected.

÷ The terminal or plug is dirty. ÷ The TRANSFORM lever is tripped.

÷ Master output level is too high. ÷ Input level is too high.

÷ The rear panel’s PHONO/LINE selector switch is

set to [PHONO] when a cassette deck or other line component is connected to the input connectors.

÷ The top panel’s FADER START button is set to Off. ÷ The rear panel’s PLAYER CONTROL jack hasn’t

been connected.

÷ EFFECT switch is [OFF]. (If hand is released

when switch is in [ON] position, it will return to [OFF].)

÷ The effect MIX/DEPTH dial is set to [MIN].

÷ Connect the cord to a power outlet.

÷ Set the Input selector switch to the device

currently playing.

÷ Set the PHONO/LINE selector switch to

[PHONO].

÷ Connect it properly.

÷ Clean and reconnect. ÷ Return the TRANSFORM lever to its upright

position.

÷ Adjust MASTER LEVEL dial. ÷ Adjust the TRIM dial so that the input level

approaches 0 dB on the peak level meter.

÷ Set the PHONO/LINE selector switch to [LINE].

÷ Set the top panel’s FADER START button to On. ÷ Use the control cord to connect the unit and CD

player.

÷ Either hold EFFECT switch at [ON] position, or

set to [LOCK ON].

÷ Adjust effect MIX/DEPTH dial properly.

External effector’s sound distorted.

External effector don’t work.

BPM can’t be measured, or value is strange.

The counted BPM differs from the CD’s published value.

Can’t see touch panel display.

÷ The input level from the external effector is too

high.

÷ The top panel’s SEND buttons (MIC SEND, CH-1

SEND, CH-2 SEND) are set to Off.

÷ An external effector’s output coupler is not

connected to the RETURN jacks.

÷ Input level is too high or too low.

÷ BPM may not measure properly with some

tracks.

÷ Different counting methods are used, resulting in

some variation in values.

÷ Improper contrast adjustment.

÷ Backlight is too dark.

÷ Lower the external effector’s output level.

÷ Turn on the top panel’s SEND button

corresponding to the channel you wish to apply external effects to (indicator will light).

÷ Connect an external effector’s output coupler to

the RETURN jacks.

÷ Adjust TRIM dial to set input level around 0 dB

on the peak level meter.

÷ Set other channels so that input level is around 0

dB.

÷ Strike TAP switch to count BPM manually.

÷ No response necessary.

÷ Adjust touch panel CONTRAST control on rear-

panel.

÷ Adjust the rear panel’s touch panel backlight

control (BRIGHT).

Static electricity or other external interference may cause the unit to malfunction. To restore normal operation, turn the power off and then on again.

SPECIFICATIONS

Audio Section

Input terminal (input level/impedance)

CD 1, 2 ....................................... –14 dBV (200 mV) / 22 kΩ

LINE 1, 2 .................................... –14 dBV (200 mV) / 22 kΩ

PHONO 1, 2 .................................. –54 dBV (2 mV) / 47 kΩ

MIC .................................................. –54 dBV (2 mV) / 3 kΩ

SESSION IN ............................... –14 dBV (200 mV) / 22 kΩ

RETURN .................................... –14 dBV (200 mV) / 22 kΩ

Output terminal (output level/impedance)

MASTER OUT 1 (XLR) .......................... 0 dBV (1 V) / 600 Ω

MASTER OUT 2 (RCA) ........................... 0 dBV (1 V) / 1 kΩ

BOOTH / SESSION OUT ........................ 0 dBV (1 V) / 1 kΩ

SEND ........................................... –14 dBV (200 mV) / 1 kΩ

PHONES ..................................... 6 dBV (2 V) / 22 Ω or less

(Rated load impedance 32 Ω)

Frequency characteristics

CD, LINE, MIC ........................................... 20 Hz to 20 kHz

PHONO (RIAA) .......................................... 20 Hz to 20 kHz

SN ratio

CD, LINE ............................... 93 dB or more (EFFECT OFF)

PHONO ......................................................... 78 dB or more

MIC ............................................................... 64 dB or more

Microphone equalizer (MIC)

HI .............................................................+12 dB to –12 dB

LOW ........................................................ +12 dB to –12 dB

Electrical Section, etc.

Power supply voltage ................................... AC 120 V, 60 Hz

Power consumption ...................................................... 31 W

Operating temperature ........ +5 °C to +35 °C (41 °F to 95 °F)

Operating humidity ...............................................5% to 85%

External dimensions ..... 251 (W) x 381.6 (D) x 107.9 (H) mm

9-7/8 (W) x 15 (D) x 4-1/4 (H) in

Weight .......................................................................... 6.5 kg

14 lbs 5 oz

Accessories

÷ Hexagonal Allen driver ...................................................... 1

÷ These operating instructions............................................. 1

÷ Warranty ............................................................................ 1

For improvement purposes, specifications and design may be subject to modification without notice.

Total harmonic distortion rate

CD, LINE ........................................................ 0.02% or less

Cross talk (1 kHz) ............................................. 77 dB or more

Channel equalizer (CD, LINE/PHONO)

HI ............................................................... +6 dB to –26 dB

MID ............................................................ +6 dB to –26 dB

LOW .......................................................... +6 dB to –26 dB

Should this product require service in the U.S.A. and you wish to locate the nearest Pioneer Authorized Independent Service Company, or if you wish to purchase replacement parts, operating instructions, service manuals, or accessories, please call the number shown below.

800 – 782 – 7210

Please do not ship your product to Pioneer without first calling the Customer Support Division at the above listed number for assistance.

PIONEER ELECTRONICS (USA), INC. CUSTOMER SUPPORT DIVISION P.O. BOX 1760, LONG BEACH, CA 90801-1760, U.S.A.

For warranty information please see the Limited Warranty sheet included with your product.

Should this product require service in Canada, please contact a Pioneer Canadian Authorized Dealer to locate the nearest Pioneer Authorized Service Company in Canada. Alternatively, please contact the Customer Service Department at the following address:

Pioneer Electronics of Canada, Inc.

300 Allstate Parkway Markham, ON L3R OP2 (905) 479-4411 1 (877) 283-5901

For warranty information please see the Limited Warranty sheet included with your product.

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS (USA) INC. Multimedia and Mass Storage Division: 2265 East 220th Street, Long Beach, CA 90810, U.S.A. TEL: 800-444-OPTI (6784) PIONEER ELECTRONICS OF CANADA, INC. Industrial Products Department: 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada TEL: 905-479-4411

Printed in <DRB1349-A><TSZRW/03J00000>

Pioneer DJm-909 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual
