Sports
7000 Series
ST702
User manual
Register your product and get support at
www.philips.com/support
![](/html/48/4890/48905da2a817b5e624bed5295d081fccd1a4ccb98d38999eec77a79c1d44c344/bg2.png)
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth wireless
earpieces 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless earpieces 4
3 Get started 5
Charge the battery 5
Pair the earpieces with your
Bluetooth device at the rst
time 6
Pair the earpieces with another
Bluetooth device 6
4 Use your headphones 7
Reconnect the earpieces to your
Bluetooth device 7
Power on/o 7
Manage your calls and music 7
LED indicator status 8
How to wear 8
5 Factory reset the earpieces 9
6 Technical data 10
7 Notice 11
Declaration of conformity 11
Disposal of your old product
and battery 11
Compliance with EMF 12
Environmental information 12
Notice of compliance 12
7 Frequently asked questions 13
![](/html/48/4890/48905da2a817b5e624bed5295d081fccd1a4ccb98d38999eec77a79c1d44c344/bg3.png)
1 Important
General information
safety
instructions
Hearing Safety
Danger
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following guidelines when using your earpieces.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not recommended and may be illegal in some
areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
To avoid damage or malfunction:
Caution
Do not expose headphones to excessive heat
Do not drop your headphones.
Headphones shall not be exposed to dripping
or splashing.
Do not allow your headphones to be
submerged in water.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
If cleaning is required use a soft doth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the
like.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• Operate or store in a place where
temperature is between -10°C
(14°F) and 50°C (122 °F) (up to 90%
relative humidity.
• Battery life may be shorter in high
or low temperature conditions.
![](/html/48/4890/48905da2a817b5e624bed5295d081fccd1a4ccb98d38999eec77a79c1d44c344/bg4.png)
2 Your
Bluetooth
wireless
earpieces
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at
www.philips.com/welcome.
With this Philips wireless earpieces, you
can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
USB charging cable (for charging only)
Quick start guide
Other devices
A mobile phone or device (e.g. notebook, PDA, Bluetooth adapters, MP3
players etc) which supports Bluetooth
and is compatible to the earpieces
(see 'Technical data' on page 10).
Philips True Wireless earpieces Philips ST702
Replaceable rubber ear caps x 2 pairs
Charging case
![](/html/48/4890/48905da2a817b5e624bed5295d081fccd1a4ccb98d38999eec77a79c1d44c344/bg5.png)
Overview of your
Bluetooth wireless
earpieces
Ear Cap
Microphone
Multi-function Button
LED indicator (charging case)
Micro USB charging slot
