Replacement
Remote
SRP4010
TAPR802
Replacement Remote for Samsung® TVs
Ersatzfernbedienung für Samsung® Fernseher
Télécommande de remplacement pour téléviseurs Samsung
User manual
Register your product and get support at
www.philips.com/support
®
Contents
Insert batteries (not included) 2
Introduction 2
Manual set up by code selection 3
Auto IR code search 4
Code Learning 5
Disposal of your old product and battery 6
Frequently asked questions 7
Need help? 7
1EN
Your replacement
Introduction
remote
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome
Insert batteries (not included)
Warning
• Check the battery polarity when inser ting in the
battery compar tment. Incorrect polarity may damage
the product.
The TV replacement remote RRC has preprogrammed the most updated IR code and is
ready to use.
Caution
• Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
Note
• When you replace the batteries, all user settings will
be retained in the memory of the universal remote for
5 minutes.
2 EN
Manual set up by code selection
The replacement remote RRC has preprogrammed the most updated IR code and
is ready to use. If it does not work, you can
manually select the code from our list that can
t your TV.
Set up by code selection
1 Switch on your TV.
2 Press and hold
for 5 seconds until the red LED is on.
and 6 at the same time
1
List of IR code for Samsung and Philips TVs
Samsung TV
00000
00001
00002
00003
00004
00005
00006
00007
00008
00009
00010
00011
00012
Philips TV
00100
00101
00102
00103
00104
00105
00106
00107
00108
00109
00110
00111
00112
Philips TV
00113
00114
00115
00116
00117
00118
00119
00120
4 Enter the selected 5-digit code using the
digit buttons.
5 If the light is off, a valid code is saved.
Otherwise, the light will ash six times, and
then remains on for code re-entry.
Note
• It is possible sometimes that your device only responds
to some of the buttons. In such case, set up with the
next code in the code list, and try operating your
device again. If there spill problem on code or key, you
can try to learn a key by learning faction if the remote
support learning function.
3 Look up the available 5-digit code. The
most popular code is listed rst. The
factory default code is 0 0 0 0 0.
3EN
Auto IR code search
1 Turn off your TV with stand-by power
4 When the TV turn on (it might takes a
few seconds for some TV to power on),
you can try other keys (except PLAY and
STOP) to see if the TV response.
2 Press and hold
for 5 seconds until the red LED is on.
3 While pointing at your TV with the RRC,
press and release the PLAY button once,
it sends Power On/Off command of an IR
code from our list.
and 6 at the same time
1
5 You can press STOP to conrm and exit
the search. If most of the other keys does
not work properly, turn off your TV and
press PLAY again to try the next code.
Note
• It is possible sometimes that your device only responds
to some of the buttons. In such case, set up with the
next code in the code list, and try operating your
device again. If there spill problem on code or key, you
can try to learn a key by learning faction if the remote
support learning function.
4 EN
Code Learning
You must have an original remote for the
Replacement Remote Control (RRC) to learn
code from it.
Learn commands
1 Press and hold
for 5 seconds until the red LED is on.
2 Enter the learning code
The red LED light will ash once and then
remains on.
and 6 at the same time
1
9 9 9 0 0
.
3 Place the RRC and the original remote,
head to head aiming at each other, on a at
surface.
Orginal Remote
Replacement
Remote
4 On the RRC, press the button that you
would like to learn a code from the
original remote. The LED will ash twice
and stay on.
5 On the original remote, press and hold the
button that you would like to learn from
for 2 seconds.
6 The LED will blink once and stay on if the
learning was successful. To learn another
key, repeat Step 4.
To exit, press 1 and 6 at the same time.
7 The LED will blink 6 times quickly if
learning failed. Repeat Step 4 to learn again.
Note
• On step 4, if no key is selected for more than 15
seconds, the LED indicator will ash six times and the
learning mode will exit automatically.
• On step 5, if no other remote signal is received for
more than 30 seconds, the LED indicator will ash
six times and then remains on. You will need to select
a desired key again for learning as in step 4 on your
replacement remote control.
• Each function key will hold only one command, a new
command to be learned will automatically replace the
previous one.
Clear learned commands
Clear all codes learned for the replacement
remote control
1 Press and hold
for 5 seconds until the red LED is on.
2 Enter the learning code
red LED light will remain on briey, ash
twice and then turns off.
» All codes learned for the replacement
remote control will be cleared.
and 6 at the same time
1
9 9 9 1 0
. The
5EN
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.
Removing the disposable batteries
To remove the disposable batteries, see section
‘Insert batteries’.
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
When this logo is attached to a product, it
means a nancial contribution has been paid to
the associated national recovery and recycling
system.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
6 EN
Frequently asked questions
My replacement remote does not work at all.
• Check if you have correctly setup the
device with the right code. Check if you
have pressed the corresponding device key
for your device.
• Check if the batteries are inserted
properly. If the batter y level is low, replace
the batteries.
• Check if your device is powered on.
If several device codes are listed under the
brand of my device, how can I select the
correct device code?
To seek the correct device code, test the codes
one by one. The codes are sorted by popularity,
and the most popular code is listed rst.
My device responds only to some of the
commands.
You have set a code for which only some
commands work properly but some do not. Try
other codes until most keys work properly or
learn the key from original remote if it support
learning function.
Need help?
We advise you to rst read this user manual
carefully. It helps you set up and use the
replacement remote.
If, however, you require extra information or
have additional questions about setup, usage,
warranty, etc of the RRC, you can always
contact us.
When calling our helpline, make sure to have
the RRC at hand when you call, so that our
operators can help you determine whether
RRC is working properly.
You will nd our contact details at the end of
this user manual. For online support, visit
www.philips.com/support
7EN
