Single/Double
Electr ic Breast Pump
Premium Plus

SCF394, SCF392

www.philips.com/mybreastpump

CB

A

A

A1

A2

A3

C5

C3 C4

C2

C1

A4

B1

B2

B3

B4

B5

B6

A5

1

English

Contents

Introduction _____________________________________________________________________________ 5
General description _______________________________________________________________________ 6
Intended use and indications for use ________________________________________________________ 6
Important safety information _______________________________________________________________ 6
Before first use ___________________________________________________________________________ 9
Cleaning and disinfecting __________________________________________________________________ 9
Using the breast pump ____________________________________________________________________ 12
Using the breast pump when you have symptoms of engorgement______________________________ 18
After use ________________________________________________________________________________ 18
Feeding breast milk with the bottle__________________________________________________________ 19
Compatibility _____________________________________________________________________________ 21
Ordering accessories ______________________________________________________________________ 21
Recycling ________________________________________________________________________________ 21
Battery removal instructions ________________________________________________________________ 22
Warranty and support _____________________________________________________________________ 23
Troubleshooting __________________________________________________________________________ 23
Undesirable side effects____________________________________________________________________ 25
Storage conditions ________________________________________________________________________ 25
Electromagnetic fields (EMF) _______________________________________________________________ 25
Technical information _____________________________________________________________________ 26
Explanation of symbols ____________________________________________________________________ 28

5

English

Introduction

Congratulations on your purchase and welcome to Philips Avent! To fully benefit from the support that
Philips Avent offers, register your breast pump at www.philips.com/mybreastpump.

The Philips Avent single/double electric breast pump Premium Plus is inspired by babies and their natural
suction movement. The soft silicone cushion stimulates the nipple with gentle massaging movements,
helping you to express milk comfortably and effectively. The combination of suction and nipple stimulation
triggers fast milk flow. The no-lean-forward design enables you to sit in a relaxed, upright position while
expressing.

Healthcare professionals and the World Health Organization recommend to exclusively feed children with
breast milk during the first six months of life and to continue giving them breast milk for two years next to
offering additional nutritious foods. This is because your breast milk is specially adapted to your baby’s
needs and helps to protect your baby against infection and allergies. To breastfeed longer, you can express
and store your milk so that your baby can still enjoy the benefits of it, even if you cannot be there to provide
it yourself. As the pump is compact, quiet and discrete to use, you can take it with you anywhere, allowing
you to express milk at your own convenience and to maintain your milk supply.

If breastfeeding goes well, it is advisable (unless recommended otherwise by your healthcare professional)
to wait until your milk supply and breastfeeding schedule are established (normally at least 2 to 4 weeks
after giving birth) before you start expressing.

6

English

General description

Note: The numbers mentioned below refer to the numbers in the figure on the front foldout page of this

user manual.

Note: The double breast pump comes with two pieces of the items shown in Figures B and C.

Product description (Fig. A)

A1 Motor unit
A2 Breast pump kit
A3 Bottle

Breast pump kit (Fig. B)

B1 Silicone tube and cap
B2 Silicone diaphragm
B3 Pump body

Philips Avent Natural bottle (Fig. C)

C1 Bottle cap
C2 Screw ring
C3 Teat

A4 Adapter
A5 Double breast pump

B4 Cover
B5 Cushion
B6 White valve

C4 Sealing disc
C5 Bottle

Accessories

There are multiple versions of this breast pump package, which all come with a different combination of the
following Philips Avent accessories:

-

Breast pads

-

Travel bag

-

Insulation pouch

Intended use and indications for use

The Philips Avent single/double electric breast pump Premium Plus is intended to express and collect milk
from the breast of a lactating woman, and indicated to alleviate the symptoms of engorgement. The device
is intended for a single user.

Important safety information

Read this user manual carefully before you use the breast pump and save it for future reference.
This user manual can also be found online on the Philips Avent website: www.philips.com/avent.
This product is operated by the lactating woman herself.
You can use this breast pump in an everyday environment.

Contraindications

English

7

- Never use the breast pump while you are pregnant, as pumping can induce labor.

Warning

Warnings to avoid choking, strangulation and injury:

- Do not allow children or pets to play with the motor unit, the adapter, packaging
materials or accessories.

- Always unplug the breast pump after use and when fully charged. Store the breast
pump when not in use.

-

This breast pump is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge. Such persons can only use this breast pump
if they are supervised by or have received proper instruction concerning use of the appliance by a person
responsible for their safety.

Warning to prevent transmitting infectious diseases:

-

If you are a mother who is infected with Hepatitis B, Hepatitis C or Human Immunodeficiency Virus (HIV),
expressing breast milk will not reduce or remove the risk of transmitting the virus to your baby through
your breast milk.

Warnings to avoid electric shock:

-

Inspect the breast pump, including the adapter, for signs of damage before each use. Do not use the
breast pump if the adapter or plug is damaged, if it does not work properly or if it has been dropped or
submerged in water.

-

Only use the adapter (S009AHz050yyyy) provided with this breast pump.

-

Always ensure that it is easy to disconnect the device from the mains in case of malfunction. The adapter
is considered the disconnection device.

Warnings to avoid contamination and to ensure hygiene:

-

For hygienic reasons, the breast pump is only intended for repeated use by a single user.

-

Clean and disinfect all parts before first use and after each use.

-

Do not use antibacterial or abrasive cleaning agents to clean the breast pump parts as this may cause
damage.

-

Wash your hands thoroughly with soap and water before you touch breast pump parts and breasts to
prevent contamination. Avoid touching the inside of containers or lids.

Warnings to avoid breast and nipple problems including pain:

-

Do not use the breast pump if the silicone diaphragm appears to be damaged or broken. See chapter
‘Ordering accessories’ for information on how to obtain replacement parts.

-

Only use accessories and parts recommended by Philips Avent.

-

There are no user serviceable parts inside the motor unit of the breast pump.

-

No modification of the breast pump is allowed. If you do so, your warranty becomes invalid.

-

Never use the breast pump while you are sleepy or drowsy to avoid lack of attention during use.

-

Always switch off the breast pump before you remove the pump body from your breast, in order to
release the vacuum.

-

If the vacuum is uncomfortable or causes pain, switch off and remove the breast pump from your breast.

English

8

English

-

Do not continue pumping for more than five minutes at a time if you do not succeed in expressing any
milk. Try to express at another time during the day.

-

If the process becomes very uncomfortable or painful, stop using the pump and consult your healthcare
professional.

Warnings to prevent damage and malfunction of the breast pump:

-

Portable radio frequency (RF) communications equipment (including mobile phones and peripherals
such as antenna cables and external antennas) should not be used closer than 30cm (12in) to any part
of the breast pump, including adapter. This could have a negative effect on the performance of the
breast pump.

-

Use of this equipment adjacent to or stacked with other equipment should be avoided because it could
result in improper operation.

Warning to avoid increased electromagnetic emissions or decreased electromagnetic immunity of
this device, resulting in improper operation:

-

Do not use any other adapter or charging cable than supplied with the device.

Battery safety instructions

- Only use thisproduct for its intended purpose and follow the general and battery safety instructions as

described in this user manual. Any misuse can cause electric shock, burns, fire and other hazards or injuries.

- To charge the battery, only use the detachable adapter

(S009AHz050yyyy) provided with the product. Do not use an extension cord.

- Charge, use and store the product at the temperature ranges indicated in the technical specifications table

in this user manual.

- Always unplug the product when it is fully charged.

- Do not burn products and their batteries and do not expose them to direct sunlight or to high

temperatures (e.g. in hot cars or near hot stoves). Batteries may explode if overheated.

- If the product becomes abnormally hot, gives off an abnormal smell, changes color or if charging takes

much longer than usual, stop using and charging the product and contact your local Philips dealer.

- Do not place products and their batteries in microwave ovens or on induction cookers.

- This product contains a rechargeable battery that is non-replaceable. Do not open the product to replace

the rechargeable battery.

Caution

Cautions to prevent damage

-

Prevent the adapter and motor unit from coming into contact with water.

-

Never put the motor unit or the adapter in water or in a dishwasher, as this causes permanent damage
to these parts.

-

Keep the adapter and the silicone tubes away from heated surfaces to avoid overheating and
deformation of these parts.

to and malfunctioning of the breast pump:

English

Before first use

Disassemble, clean and disinfect all parts that come into contact with breast milk before you use the breast
pump for the first time and after every use.

Fully charge the device before you use it for the first time or after a long period of non-use.

Cleaning and disinfecting

Overview

Clean and disinfect the parts that come into contact with the breast and breast milk as described below:

When How

9

English

Clean and disinfect before first use
and after every use.

The following parts do not come into contact with the breast and breast milk; clean them as described
below:

When How

Clean when needed. Wipe with a clean, damp cloth with

Disassemble all parts and then clean
them as described in chapter
'Cleaning' and disinfect them as
described in chapter 'Disinfecting'.

water and mild detergent.

10

English

Step 1: Disassembling

Disassemble the breast pump, bottle and storage cup completely.
Also remove the white valve from the breast pump.

Step 2: Cleaning

The parts that come in contact with milk can be cleaned manually or in the dishwasher.

Warning: Do not use antibacterial or abrasive cleaning agents to clean the breast pump

parts as this may cause damage.

Caution: Never put the motor unit or the adapter in water or in a dishwasher, as this

causes permanent damage to these parts.

Caution: Be careful when you remove and clean the white valve. If it gets damaged,
your breast pump does not function properly. To remove the white valve, gently pull at
the ribbed tab on the side of the valve. To clean the white valve, rub it gently between
your fingers in warm water with some dishwashing liquid. Do not insert objects into the
white valve, as this may cause damage.

Step 2A: Manual cleaning

5 min.

Supplies needed:

-

Mild dishwashing liquid

-

Drinking-quality water

-

Soft, clean brush

-

Clean tea towel or drying rack

-

Clean sink or bowl

English

11

English

1. Rinse all parts under a
running tap with
lukewarm water.

5. Leave all parts to air­dry on a clean tea towel
or drying rack.

2. Soak all parts for
5minutes in warm water
with some mild
dishwashing liquid.

Step 2B: Cleaning in the dishwasher

Supplies needed:

-

Mild dishwashing liquid or a dishwashing tablet

-

Drinking-quality water

Note: Food colorings may discolor parts.

3. Clean all parts with a
cleaning brush.

4. Thoroughly rinse all
parts under a running
tap with cold clear water.

1. Place all parts on the
top rack of the
dishwasher.

2. Put dishwashing liquid
or a tablet in the
machine and run a
standard program.

3. Leave all parts to air­dry on a clean tea towel
or drying rack.

12

5 min.

English

Step 3: Disinfecting

Supplies needed:

-

A household pot

-

Drinking-quality water

Caution: During disinfection with boiling water, prevent the bottle or other parts from
touching the side of the pot. This can cause irreversible product deformation or damage
that Philips cannot be held liable for.

1. Fill a household pot
with enough water to
cover all parts and place
all parts in the pot. Let
the water boil for
5minutes. Make sure the
parts do not touch the
side of the pot.

2. Allow the water to
cool down.

3. Gently remove the
parts from the water.
Place the parts on a clean
surface/tea towel or
drying rack to air-dry.

4. Store the dry items in a
clean, dry and covered
container.

Using the breast pump

Cushion size

The Philips Avent single/double electric breast pump Premium Plus has a soft, active cushion. There is only
one cushion size. It gently stimulates your nipple to trigger milk flow. The cushion is made of flexible
silicone, fitting nipple sizes up to 30mm/1.18in.

Charging the breast pump

Fully charge the battery before you use the breast pump for the first time and when the battery is low. Fully
charging the battery takes up to 4hours.

English

3 sec.

13

English

1. Switch off the device. 2. Insert the adapter into
the wall socket and
insert the small plug at
the other end into the
motor unit.

3. The battery is
charging.

4. When the battery is
fully charged, remove
the adapter from the
wall socket and pull the
small plug out of the
motor unit.

Battery indicator light description

All lights are steady
on. The battery is
fully charged.

Charged battery
operates
approximately
3pumping
sessions.*

* One session is the equivalent of 15minutes (double electric breast pump) or 30 minutes (single electric
breast pump).

Two lights are
steady on.

The battery is
charged sufficiently
for maximum two
sessions.*

First light flashes
slowly.

The battery is
charged sufficiently
for maximum one
session.*

First light flashes
quickly.

The battery is very
low, the device will
soon stop
operating, charging
is needed.

Battery lights light
up one by one and
go out all together.

The battery is
charging.

Assembling the breast pump

Make sure you have cleaned and disinfected the parts of the breast pump that come into contact with milk.

Warning: Be careful, when you have disinfected the breast pump parts by boiling
them, they can be very hot. To prevent burns, only start assembling the breast pump
when disinfected parts have cooled down.

Warning: Wash your hands thoroughly with soap and water before you touch breast
pump parts and breasts to prevent contamination. Avoid touching the inside of
containers or lids.

Check the breast pump kit parts for wear or damage before use and replace them if necessary.

Note: Correct placement of the cushion, silicone diaphragm and silicone tube is essential for the breast

pump to form a proper vacuum.

14

3 sec.

English

1. Wash your hands
thoroughly with soap
and water.

4A. Push the inner part of
the cushion into the
funnel against the line
(indicated with an
arrow).

7. Connect the tube(s) to
the motor unit.

2. Push the white valve in
the pump body as far as
possible.

5. Place the silicone
diaphragm in the pump
body.

8A. When the breast
pump is charged, you
can use it cordless. Press
and hold the on/off
button until the device
switches on.

3. Screw the pump body
onto the bottle.

5A. Make sure that the
silicone diaphragm fits
securely around the rim
by pressing it down with
your thumbs.

8B. You can also use the
breast pump connected
to the wall socket. If the
battery is low, insert the
adapter into the wall
socket and insert the
small plug at the other
end into the motor unit.

4. Place the cushion in
the pump body and
make sure that the rim
covers the pump body.

6. Attach the silicone
tube and cap onto the
silicone diaphragm.
Push down the cap until
it is securely in place.

9. The breast pump is
now ready for use.

Note: You can place

7

1 3 5

4 6

8

2

1

2

3

4

the cover over the
cushion to keep the
breast pump clean when
you take it with you and
while you are preparing
for expressing.

Motor unit part description

1 USB power inlet
2 On/off button with

pause/play function
3 Mode selection button
4 'Level down' button
5 'Level up' button
6 LED display
7 Tubing port for single breast

pump
8 Tubing ports for double

breast pump

English

15

English

LED display description

1 Battery indicator lights
2 Timer (minutes) and vacuum

level indication
3 Expression icon
4 Stimulation icon

16

English

Explanation of modes

The breast pump has two modes. Below you find an explanation of these modes.

Mode icons Mode Explanation No. of suction levels

Stimulation mode Mode to stimulate the breast to start

up the milk flow.

8 suction levels

Expression mode Mode for efficient milk removal after

milk has started flowing. After 90 sec.
of stimulation, the device
automatically switches to the
expression mode.

The number on the display shows the running time
in minutes.

When you change the suction level, the display
shows the selected suction level for a few seconds
and then shows the running time again.

16 suction levels

Pumping instructions

Warning: Before you remove the pump body from your breast, always switch off the

breast pump to release the vacuum.

Warning: Do not continue pumping for more than 5 minutes at a time if you do not

succeed in expressing any milk. Try to express at another time during the day.

Warning: If the process becomes very uncomfortable or painful, stop using the pump

and consult your healthcare professional.

Note: If you regularly express more than 125ml/4floz per session, you can purchase and use a

260ml/9floz Philips Avent Natural bottle to prevent overfilling and spillage.

Note: The breast pump can be used cordless if it is sufficiently charged, but you can also use it connected

to the wall socket.

English

3 sec.

3 sec.

17

English

1. Wash your hands
thoroughly with soap
and water and make
sure that your breast is
clean.

5. The display shows the
running time.

2. Place the breast pump
kit onto your breast.
Make sure that you
center your nipple.

6. Use the 'level up' and
'level down' buttons to
change the suction level
to your preference.

3. Press and hold the
on/off button until the
device switches on. The
indicator lights go on to
indicate that the device
is in stimulation mode.

7. After 90 seconds the
breast pump will switch
smoothly to expression
mode and slowly
increase its vacuum to
the last used expression
suction level (or level 11
when used for the first
time).

4. The breast pump starts
in stimulation mode and
slowly increases its
vacuum to the last used
stimulation suction level
(or level 5 when used for
the first time).

8. If your milk starts
flowing earlier or if you
want to switch from
expression to stimulation
mode, you can switch
modes with the mode
selection button.

9. Briefly press the on/off
button if you want to
pause. To continue,
briefly press the on/off
button again.

Tip: For optimal expression, choose the highest setting that still feels comfortable. This setting may differ

across different sessions.

Tip: You can use the double breast pump as a single breast pump by connecting only the tube of one

pump kit to the motor unit. 

10. Press and hold the
on/off button to switch
off.

11. Unplug the adapter
from the wall socket and
pull the small plug out of
the motor unit.

18

1

2

English

Using the breast pump when you have symptoms of engorgement

Breast engorgement means your breasts are overfilled with milk. This is a painful and unpleasant condition.
Frequent extraction of milk and completely emptying the breasts of milk can reduce engorgement. When
you have symptoms of engorgement, make sure you use a lower vacuum level to minimize stretching of
breast tissue.

Note: When symptoms of engorgement are present, make sure you empty your breasts completely

during each expression session.

After use

1. Unscrew the bottle. 2A. To store the breast

4. Disassemble and clean
all parts that have been
in contact with breast
milk (see 'Cleaning and
disinfecting').

milk: close the bottle
with the sealing disc and
screw ring.

5. For easy storage, wrap
the silicone tube around
the motor unit and clip
the cap onto the tube.

2B. To prepare the bottle
for feeding your baby:
place a teat in a screw
ring and screw the
assembled screw ring
onto the bottle. Seal the
teat with the bottle cap
(see 'Assembling the
bottle').

3. Remove the silicone
tube and cap from the
breast pump kit.

Warning: Refrigerate or freeze expressed milk immediately or keep it at a temperature

of 16-29°C (60-85°F) for a maximum of 4 hours before you feed your baby.

For more information about the breast pump and tips for expressing milk, visit www.philips.com/avent.

English

Storing breast milk

Below you find guidelines for storing breast milk:

Storage location Temperature Max. storage duration

Room 16-29°C (60-85°F) 4 hours

Refrigerator 4°C (39°F) 4 days

Freezer < ‑4°C (25°F) 6 months

Warning: Never refreeze thawed breast milk to avoid a decrease in milk quality.

Warning: Never add fresh breast milk to frozen breast milk to avoid a decrease in milk

quality and unintended thawing of the frozen milk.

Feeding breast milk with the bottle

For your child’s safety and health

WARNING!

-

Continuous and prolonged sucking of fluids will cause tooth decay.

-

Always check food temperature before feeding.

-

Throw away at the first signs of damage or weakness.

-

Keep components not in use out of the reach of children.

-

Never attach to cords, ribbons, laces or loose parts of clothing. The child can be strangled.

-

Never use feeding teats as a soother.

-

Always use this product with adult supervision.

-

Keep the bottle cap away from children to avoid suffocation.

-

Do not allow children to play with small parts or walk/run while using bottles.

-

Inspect all parts before use and pull the feeding teat in all directions. Throw away any part at the first
signs of damage or weakness.

-

Always discard any breast milk that is left over at the end of a feed.

19

English

Caution: To avoid damage to the bottle

-

Do not place in a heated oven, plastic can melt.

-

Plastic material properties may be affected by disinfection and high temperatures. This can affect the fit
of the bottle cap.

-

Do not leave a feeding teat in direct sunlight or heat, or leave in disinfectant for longer than
recommended because this may damage the product.

20

English

Before using the bottle

-

Inspect the bottle and feeding teat before each use and pull the feeding teat in all directions to prevent a
choking hazard. Throw away at the first signs of damage or weakness.

-

Clean and disinfect the bottle before first use and after every use (see 'Cleaning and disinfecting').

Assembling the bottle

1. The teat is easier to
assemble if you move it
back-and-forth while
pulling it upwards
instead of pulling it up in
a straight line.

5. To remove the cap,
place your hand over the
cap and your thumb in
the dent of the cap.

2. Make sure you pull the
teat through until its
lower part is aligned
with the screw ring.

3. Make sure you place
the cap vertically onto
the bottle so that the
teat sits upright.

4. Screw the screw ring
with teat and cap on the
bottle.

Heating breast milk

If you use frozen breast milk, let it defrost completely before you heat it.

Note: If you need to feed your baby quickly, you can defrost the milk in a bowl of hot water.

Heat the bottle with defrosted or refrigerated breast milk in a bowl of hot water or in a bottle warmer.
Remove the screw ring and sealing disc from the bottle.

Warning: It is not recommended to use a microwave to warm up breast milk.
Microwaves might alter the quality of breast milk and destroy some valuable nutrients
and may produce localized high temperatures. If you heat up breast milk in the
microwave, only place the container without screw ring, teat and cap in microwave.
Always stir heated breast milk to ensure even heat distribution and check the
temperature before serving.

English

21

Choosing the right teat for your baby

Philips Avent Natural teats are available with different flow rates. The breast
pump comes with teat number 1. This is a 0m+ teat, ideal for newborn and
breastfed babies of all ages.

Use a lower flow rate if your baby chokes often, if milk drips out of its mouth
during feeding or if it has trouble adjusting to the drinking speed. Use a higher
flow rate if your baby falls asleep during feeding, gets frustrated or if feeding
takes very long.

Philips Avent Natural teats are clearly numbered on the side, to indicate flow rate. For more information, see
www.philips.com/avent.

Storing the bottles

-

Store all parts in a dry, clean and covered container.

-

Do not leave a feeding teat in direct sunlight or heat, or leave in disinfectant for longer than
recommended because this may damage the product.

-

For hygiene reasons, we recommend replacing the teats after 3 months.

Compatibility

The Philips Avent single/double electric breast pump Premium Plus is compatible with all baby bottles in the
Philips Avent Natural range and Philips Avent Storage cups with adapter. We do not recommend using the
Philips Avent Natural Glass bottles with the breast pump.

English

Ordering accessories

To buy accessories or spare parts, visit www.philips.com/support or go to your Philips dealer. You can also
contact the Philips Consumer Care Center in your country.

When you order spare teats, make sure that you use a teat with the correct flow rate for your baby (see
'Choosing the right teat for your baby') and do not mix Philips Avent Anti-colic bottle parts and teats with
parts of the Philips Avent Natural bottles. They do not fit and could cause leakage or other issues.

Recycling

-

This symbol means that this product shall not be disposed of with normal household waste
(2012/19/EU).

- This symbol means that this product contains a built-in rechargeable battery which shall not be disposed
of with normal household waste (2006/66/EC). Please take your product to an official collection point or
a Philips service center to have a professional remove the rechargeable battery.

22

English

- Follow your country’s rules for the separate collection of electrical and electronic products and
rechargeable batteries. Correct disposal helps prevent negative consequences for the environment and
human health.

Battery removal instructions

-

When you handle batteries, make sure that your hands, the product and the batteries are dry.

-

To prevent batteries from heating up or releasing toxic or hazardous substances, do not modify, pierce or
damage products and batteries and do not disassemble, short-circuit, overcharge or reverse charge
batteries.

-

To avoid accidental short-circuiting of batteries after removal, do not let battery terminals come into
contact with metal objects (e.g. coins, hairpins, rings). Do not wrap batteries in aluminum foil. Tape
battery terminals or put batteries in a plastic bag before you discard them.

-

If batteries are damaged or leaking, avoid contact with the skin or eyes. If this occurs, immediately rinse
well with water and seek medical care.

Note: Only remove the rechargeable battery when you discard the product. Before you

remove the battery, make sure that the product is disconnected from the wall socket and
that the battery is completely empty.

Note: Take any necessary safety precautions when you handle tools to open the

product and when you dispose of the rechargeable battery.

1. Remove the rubber
feet from the bottom of
the motor unit.

5. Remove the frame
from the motor unit.

2. Remove the screw
with a torx screwdriver.

6. Cut or fold the edges
of the plastic battery
frame. Remove the
battery from the plastic
battery frame.

3. Open the motor unit
by pressing at the sides of
the device.

Note: Dispose of the
rechargeable battery at a
separate local collection
point. Other parts can be
disposed at a specific
place for disposal of
electric equipment.

4. Disconnect the
connectors from the
printed circuit board.

English

Warranty and support

If you need information or support, please visit www.philips.com/support or read the international
warranty leaflet.

Troubleshooting

This chapter summarizes the most common problems you could encounter with the breast pump. If you are
unable to solve the problem with the information below, visit www.philips.com/support for a list of
frequently asked questions or contact the Consumer Care Center in your country.

Problem Solution

I experience pain when I
use the breast pump.

- Choose a suction level that is comfortable for you.

- Check if the silicone diaphragm is not damaged (does not have small

cracks, holes etc.).

- Make sure that your nipple is placed in the center of the cushion.

- If the pain persists, stop using the breast pump and consult your

healthcare professional.

23

English

The breast pump does not
switch on while it is
connected to the wall
socket.

The breast pump does not
switch on (indicator lights
do not go on).

The breast pump is not
charging.

Charging the breast pump
takes a very long time.

- Only use the adapter supplied.

- Make sure that the adapter has been inserted correctly into the wall

socket and that the small plug has been inserted correctly into the motor
unit.

- Connect the adapter to another wall socket. Then press and hold the

on/off button to check if the breast pump can be switched on.

- If the problem persists, contact the Consumer Care Center via

www.philips.com/support.

- Make sure that the battery is charged (see 'Charging the breast pump') or

connect the breast pump to the wall socket.

- Only use the adapter supplied.

- Make sure that the adapter has been inserted correctly into the wall

socket and that the small plug has been inserted correctly into the motor
unit.

- The breast pump is too cold or too hot for charging. Let the breast pump

acclimatize to room temperature for 30minutes.

- If the problem persists, contact the Consumer Care Center via

www.philips.com/support.

- Only use the adapter supplied.

- Make sure that the adapter has been inserted correctly into the wall

socket and that the small plug has been inserted correctly into the motor
unit.

- The breast pump is too cold or too hot. It is recommended to charge the

breast pump at room temperature.

- If the problem persists, contact the Consumer Care Center via

www.philips.com/support.

24

English

Problem Solution

I do not feel any
suction/the suction level
is too low.

- If possible, try a higher suction level.

- Check if the silicone diaphragm is assembled correctly (see 'Assembling

the breast pump').

- Check if the white valve is not damaged and assembled correctly (see

'Assembling the breast pump').

- Check if the other parts of breast pump are intact and assembled correctly

(see 'Assembling the breast pump').

- Make sure that the pump is positioned correctly on the breast to allow a

seal between breast pump and breast.

- If you still do not feel any suction, please contact the Consumer Care

Center via www.philips.com/support.

The suction of the breast
pump is too strong.

I express little/no milk
when I use my breast
pump.

When I switch on the
breast pump after
storage, it does not start
working immediately.

The display shows ‘Er’ and
the device switches off
automatically.

- If possible, try a lower suction level. When you express for the first time,

start with the default suction level (level 5 in stimulation mode, level 11 in
expression mode) and increase/decrease the level when needed. During
different expression sessions, different levels may feel most comfortable
for you.

- Make sure that you only use the breast pump parts provided with this

breast pump.

- Check if the silicone diaphragm is not damaged (does not have small

cracks, holes etc.).

- If the problem persists, contact the Consumer Care Center via

www.philips.com/support.

- If you do not feel enough suction, please check Troubleshooting item 'I do

not feel any suction/the suction level is too low'.

- If you are using the Philips Avent breast pump for the first time, you may

need some practice before you are able to express any milk. More
expressing tips can be found on the Philips website

www.philips.com/mybreastpump.

- Make sure that the battery is fully charged (see 'Charging the breast

pump') or connect the breast pump to the wall socket.

- Perhaps you stored the breast pump at a temperature below the

minimum storage temperature or above the maximum storage
temperature. Let the breast pump acclimatize in a room of 20°C/68°F for
30minutes to adjust its temperature to the operating range (5°C/41°F to
40°C/104°F).

- If you are operating the breast pump on battery power, let it cool down

for 30minutes and try to switch it on again.

- If you are operating the breast pump with the adapter connected to the

wall socket, check if you are using the adapter that was supplied with the
device.

- If the problem persists, contact the Consumer Care Center via

www.philips.com/support.

English

Undesirable side effects

Any serious incident that has occurred in relation to this device should be reported to Philips via
www.philips.com/support and to the competent authority of the Member State in which the user and/or
patient is established.

When using the breast pump, the below undesirable side effects may occur. If you experience any of these
symptoms, contact a healthcare professional or breastfeeding specialist.

Undesirable side
effect

Pain sensation Pain felt on the breast or nipple, or felt as a response to the suction being

Description

above a comfortable level.

25

English

Sore nipples Persistent pain in the nipples at the beginning of the pumping session, or that

Erythema (redness) Redness of the skin of the breast.

Bruise A reddish-purple discoloration that does not fade when pressed. When a

Thrombus Thrombus can result into tenderness, pain, redness, swelling and/or heat.

Injured tissue on nipple
(nipple trauma)

lasts throughout the entire pumping session, or pain between sessions.

bruise fades, it may become green and brown.

- Fissures or cracked nipples.

- Skin tissue peeling off the nipple. Normally occurs in combination with

cracked nipples and/or blisters.

- Nipple tear.

- Blister. Looks like small bubbles on the surface of the skin.

- Bleeding. Cracked or torn nipples can lead to bleeding of the affected

area.

Storage conditions

Keep the breast pump out of direct sunlight as prolonged exposure may cause discoloration. Store the
breast pump and its accessories in a safe, clean and dry place.

If the device has been stored in a hot or cold environment, place it in an environment with a temperature of
20°C (68°F) for 30 minutes to let it reach a temperature within the usage conditions (5°C to 40°C/41°F to
104°F) before you use it.

Fully charge the battery before storing your breast pump for an extended period of time.

Electromagnetic fields (EMF)

This Philips device complies with all applicable standards and regulations regarding exposure to
electromagnetic fields.

26

English

Technical information

Single electric breast pump Double electric breast pump

Vacuum level Stimulation: -60 to -200 mbar (-45 to -150 mmHg)

Expression: -60 to -360 mbar (-45 to -270 mmHg)
Adjustable in steps of 20 mbar
Intermittent vacuum

Cycle speed Stimulation: 105-120 cycles/min, depending on vacuum level

Expression: 53-85 cycles/min, depending on vacuum level

Motor unit rated input 5 V d.c. / 1.1 A 5 V d.c. / 1.8 A

Mains adapter rated
input

Mains adapter rated
output

Adapter type number S009AHz050yyyy The letters "yyyy" represent the output current from 0100

Battery Rechargeable battery: 3.6V2600mAh (non-replaceable)

Power port Micro-USB

Operating conditions Temperature: 5°C to 40°C (41°F to 104°F)

Storage and
transportation conditions

Operating pressure 700-1060 hPa (<3000m altitude)

Net weight 230g 310g

External dimensions Motor unit: 145 mm x 95 mm x 45 mm (LxWxH)

Device classification Applicable classifications:

External mains adapter 100-240 V a.c. / 50/60Hz

5 V d.c. / 1.1 A 5 V d.c. / 1.8 A

(1000mA) to 0180 (1800mA), increments in steps of 100mA. The letter "z"
denotes type of plug, it can be: U, V, B, S, C, A, D, K, T, I, E, F.

Relative humidity: 15 to 90% (non-condensing)

Temperature: -20°C to 45°C (-4°F to 113°F)
Relative humidity: up to 90% (non-condensing)

Degree of protection against electric shock:

- Class II ME equipment

- Type BF applied part
The breast pump and the adapter are specified as medical electrical system

according to IEC 60601-1.

Materials ABS, silicone (motor unit)

Polypropylene, silicone (other parts)

Service life 2 years

Operational life 500 hours

English

27

Single electric breast pump Double electric breast pump

Mode of operation Continuous operation Non-continuous operation

55min on, 180min off at 22°C (72°F)
(duty cycle 23%)

20min on, 90min off at 40°C (104°F)
(duty cycle 18%)

Ingress protection IP22 (motor unit), IP20 (adapter)

Electromagnetic compatibility - compliance information

This device has been tested and found to comply with IEC 60601-1-2:2014 Ed 4.0 for electromagnetic
compatibility (EMC) as Class B according to CISPR 11:2009. Tests levels are listed in the accompanying tables.
Only use this Philips Avent single/double electric breast pump Premium Plus in combination with the
adapter supplied.

Emissions Compliance Electromagnetic environment –

RF emissions
CISPR 11

Group 1 The device does not use RF energy for its

guidance

intended function. Therefore, its RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.

English

RF emissions
CISPR 11

Harmonic emissions
IEC 61000-3-2

Voltage fluctuations /
flicker emissions

IEC 61000-3-3

Class B

Complies
Class A Category

Complies

The device is suitable for use in locations in
residential environments and in establishments
directly connected to a low voltage power
supply network which supplies buildings used
for domestic purposes.

Guidance and manufacturer's declaration – electromagnetic immunity

The Philips Avent single/double electric breast pump Premium Plus is intended for use in the
electromagnetic environment listed below. The user of the device should ensure that it is used in such an
environment to prevent improper operation.

Immunity test Immunity test level Electromagnetic environment -

Electrostatic discharge
(ESD)

IEC 61000-4-2

Radiated RF EM fields
IEC 61000-4-3

±8 kV contact
±15 kV air

10 V/m
80 MHz – 2.7 GHz
80% AM at 1 kHz

guidance

Floors can be a source of static electricity. When
the air is very dry (<20% RH) the user is advised
to prefer to use the device in a room with
concrete or wooden floors (instead of using it in
a room with a synthetic floor).

28

English

Immunity test Immunity test level Electromagnetic environment -

guidance

Proximity fields from RF
wireless communications
equipment

IEC 61000-4-3

Rated power frequency
magnetic fields IEC

61000-4-8

Electrical fast transient/
burst

IEC 61000-4-4

Surges
IEC 61000-4-5

Conducted disturbances
induced by RF fields

IEC 61000-4-6

385 (27), 450 (28), 710 (9),
745 (9), 780 (9), 810 (28),
870 (28), 930 (28), 1720
(28), 1845 (28), 1970 (28),
2450 (28), 5240 (9), 5500
(9), 5785 (9) MHz (V/m)

30 A/m
50 Hz or 60 Hz

±2 kV
100 kHz repetition

frequency

±1 kV Line-to-line
±2 kV Line-to-ground

3 Vrms, before modulation
is applied

0.15 MHz – 80 MHz
6 Vrms, before modulation

is applied, in ISM and
amateur radio bands
between 0.15 MHz and 80
MHz

80% AM at 1 kHz

The device is immune against any RF wireless
communication device such as smart phone, Wi­Fi or Bluetooth device at a distance of 30cm or
more. Avoid a closer distance as this may result
in improper operation.

Mains power quality expected of a typical
commercial or residential environment.

Mains power quality expected of a typical
commercial or residential environment.

Voltage dips, short
interruptions and voltage
variations on power supply
input lines

IEC 61000-4-11

Note: UT is the AC mains voltage prior to application of the test level. If in the unlikely event the Philips
Avent single/double electric breast pump Premium Plus is locked inoperative in a function by disturbances
from other devices beyond the levels stated in the table above, the device will shut-off completely and
restart. In that case make sure the distance to the other device causing this disturbance is enlarged.

0 % UT; 0.5 cycle at 0°, 45°,
90°, 135°, 180°, 225°, 270°
and 315°
0 % UT; 1 cycle and 70 %

UT; 25/30 cycles single
phase at 0°

0 % UT; 250/300 cycle

Mains power quality expected of a typical
commercial or residential environment. At
power interruptions the breast pump will
automatically switch-over to battery mode
without interruption of the function.

Explanation of symbols

The warning signs and symbols are essential to ensure that you use this device safely and correctly and to
protect you and others from injury. Below you find the meaning of the warning signs and symbols on the
label and in the user manual.

Symbol Explanation

Indicates to follow the instructions for use.

Symbol Explanation

Indicates important information such as warnings and cautions.

English

29

Indicates usage tips, additional information or a note.

Indicates the manufacturer.

Indicates the manufacturing date.

Indicates the compliance with the essential requirements of theCouncil Directive 93/42/EEC
of 14June1993 concerning medical devices.

Indicates that the device is a medical device.

Indicates that the part of the appliance that comes into physical contact with the user (also
known as the applied part) is of type BF (Body Floating) according to IEC 60601-1. The applied
part is the breast pump kit.

Indicates 'Class II Equipment'. The adapter is double-insulated (Class II).

Indicates manufacturer's catalog number of the breast pump.

English

Indicates 'direct current'.

Indicates 'alternating current'.

Indicates separate collection for electrical and electronic equipment in accordance with the
EU directive. Electrical waste products should not be disposed of with household waste. See
chapter 'Recycling' for more information.

Indicates that this product contains a built-in rechargeable battery which shall not be
disposed of with normal household waste (2006/66/EC). See chapter 'Recycling' for more
information.

Indicates the protection against ingress of solid foreign objects greater than 12.5mm and
against harmful effects due to the ingress of dripping water when tilted at 15degrees.

Indicates the protection against ingress of solid foreign objects greater than 12.5mm and no
protection against ingress of water.
