PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

Directions For Use

PRF227S

PLPLW225S

W225S

3135-125-20871

PRELIMINAR

PRELIMINARYY

PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1. Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water

- for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved

with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

6B. Tilt/Stability - All televisions must comply with recommended inter-

national global safety standards for tilt and stability properties of its cabinet design.

• Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet which could ultimately overturn the product.

• Also, do not endanger yourself, or children, by placing electronic equipment/toys on the top of the cabinet. Such items could unsuspectingly fall from the top of the set and cause product damage and/or personal injury.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a builtin installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

11. Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the appliance.

12. Cleaning - The appliance should be cleaned only as recommended by the manufacturer.

13. Power Lines - An outdoor antenna should be located away from power lines.

14. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges.

Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mats and supporting structure grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna-discharge unit, connection to grounding electrodes and requirements for the grounding electrode. See Fig. below.

15. Non-use Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.

16. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

17. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled into the appli-

ance; or

C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or exhibits

a marked change in performance; or

E. The appliance has been dropped, or the enclosure damaged.

18. Servicing - The user should not attempt to service the appliance

beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

Note to the CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

SAFETY INSTRUCTIONS - Read before operating equipment

PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

INTRODUCTION

Philips Institutional TV Software

Your Philips Institutional Television can be configured to operate in either "Consumer" or "Commercial" operational modes.

Commercial Mode: Your Philips Institutional Television is configured at the Factory to operate in Commercial mode. When the television is in Commercial mode, access to its operation from its front panel controls or from a guest-mode remote can be limited, depending upon the settings of the Institutional TV features. For examples, the unit’s front panel controls can be “locked-out” (rendered inoperable), only certain channels can be selected, and/or the volume can be limited to a given range.

Consumer Mode: When in the Consumer mode, the unit operates as a standard TV, bypassing the Institutional Television feature set, thus allowing normal initial power ON, channel selection, and volume control (as well as a variety of selectable Menu features). When the TV is in Consumer mode, Philips RC-5 system 0 (guest-mode) remotes, such as the RC2524BK and the RL9820BK (optional accessories) can access the Consumer-mode Main Menu, and configure the television to the full extent offered in this mode. Guest-mode 21-button remotes such as the RC2524BK use the Menu button to access the Consumer menu. Guest-mode 20-button remotes such as the RL9820BK, which do not have a Menu button, use the Sleep button to access the Consumer menu. Simultaneously pressing the front panel’s Volume - and Volume + buttons also invokes the Consumer menu.

Identifying the Operational Mode: To identify the television’s operational mode, a system 7 (commercial setup mode) master setup remote (RG4172BK, optional accessory) must be used. With the RG4172BK in setup mode (press TV SETUP on the RG4172BK), press Recall. The following information will appear on-screen:

Changing Operational Modes: To change the television’s mode between Consumer and Commercial modes, a system 7 (commercial setup mode) master setup remote must be used. With the RG4172BK in setup mode (press TV SETUP on the RG4172BK), enter the following keystroke sequence: 0 2 4 9 9 5 Menu. Only the RG4172BK, when it is in setup mode can change the television’s mode between Consumer and Commercial, and provide complete access to the television’s Institutional Features. The RG4172BK can be set to operate in either its master setup remote mode, or in guestmode. The RG4172BK’s guest mode facilitates testing the desired Institutional / Commercial configuration.

STATUS ITEM STATUS DATA MEANING

SYSTEM STATUS (LO1ITV-US4PV)

n/a

Information title

MODE COMMERCIAL / CONSUMER

Operational mode

CHANNEL CHANNEL, INPUT (CHANNEL, INPUT)

Currently-tuned channel

DCM OFF / ON

Data communications module offline / online

CODES 211 222 001 035

Internal data for factory / service use.

SIGNAL TUNED / NOT TUNED

Signal present / absent

OP HRS 0031h

Number of cumulative hours unit has been operated (hexadecimal)

ERRORS 0 0 0 0 0

Internal data for factory / service use.

VERSION 3.3

Television software version.

PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

CURRENT MODE COMMERCIAL / CONSUMER CONSUMER MODE: PRESS 1 COMMERCIAL MODE: PRESS 2 EXIT WITHOUT CHANGING MODES: PRESS 0

OPERATIONAL MODE

To change the operational mode of the Philips Institutional TV, use the RG4172BK in setup mode (press TV SETUP on the RG4172BK), and enter the following keystroke sequence: 0 2 4 9 9 5 Menu. Select the desired mode from the Operational Mode menu.

IMPORTANT NOTE:

IF YOU CHANGE THE OPERATIONAL MODE TO CONSUMER MODE,

YOU MUST POWER THE TELEVISION OFF AND BACK ON TO COMPLETE THE MODE CHANGE.

NOTE:

ONCE THE TELEVISION IS IN CONSUMER MODE, DO NOT USE THE SETUP REMOTE TO ACTIVATE COMMER-

CIAL

FEATURES. OTHERWISE, THE COMMERCIAL FEATURES WILL AFFECT CONSUMER OPERATION. IT WILL THEN

NECESSARY TO PLACE THE TELEVISION BACK INTO COMMERCIAL MODE, THEN INTO CONSUMER MODE, AND

THEN

POWERED OFF AGAIN TO

PROPERLY PLACE THE

TELEVISION BACK INTO CONSUMER MODE.

RC2524BK

Guest Remote

29-button guest remote with menu button, additional features (VCR control, etc.)

RL9820B

Guest Remote

20-button guest remote.

RG4172BK

Setup Remote

Master setup remote. Required to change operational modes and access Institutional features. Press TV SETUP to place remote in SETUP mode.

Remote controls (optional accessories) used with Philips Institutional televisions.

SETTING THE INSTITUTIONAL TV OPERATIONAL MODE

RC2573*

Future version of master setup remote. Fully functionally equivalent to RG4172BK. Put switch in SETUP position to place remote in setup mode. *Exact model number subject to change.

PHILIPS INSTITUTIONAL TV REMOTE CONTROLS

The following table summarizes the Commercial and Consumer menu items available on your Philips Institutional television. The functions of these menu items will be discussed in greater detail later in this booklet. Menu items denoted with a “>” invoke sub-menus, which will also be discussed later in this booklet. The column labeled CONSUMER indi- cates the Main Menu items that are available when the television is in Consumer mode, and Menu or Sleep is pressed on a guest-mode remote (or RG4172BK master setup remote in guest mode). The column labeled COMMERCIAL indicates the Setup Menu items available with the RG4172BK master setup remote whenever the setup remote is in setup mode.

PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

MENU ITEM

MENU TITLE

LANGUAGE

CHANNEL INSTALL

CABLE TUNING

BRIGHTNESS

COLOR

CONTRAST

SHARPNESS

TINT

NOISE REDUCTION

SOUND MODE

SAP

AUDIO OUT

BALANCE

TREBLE

BASS

INCRED STEREO

AVL

VOLUME BAR

MIN VOLUME *

MAX VOLUME *

SWITCH ON VOLUME *

SWITCH ON CHANNEL *

POWER ON *

CHANNEL DISPLAY *

KEYBOARD LOCK *

ESP *

AUDIO/VIDEO MUTE

EXT AUD / VID OUT

WELCOME MESSAGE *

CHANNEL GUIDE *

REMINDER

3 DIGIT ENTRY *

A/CH A/V SWITCH *

SAVE CC *

V-CHIP MENU ITEM *

SAVE V-CHIP *

V-CHIP SETUP

SLEEPTIMER

SECURITY *

EXIT

SETTINGS / OPTIONS

SETUP MENU / MAIN MENU

ENGLISH/ESPANOL/FRANÇAIS

ON/OFF

----|---- 0 - 63

----|---- -31 - +31

ON/OFF

MONO / STEREO

OFF / NO SAP / ON

FIXED / VARIABLE

----|---- 0

----|---- -31 - +31

ON / OFF

----|---- 0 - 63

----|---- 0 - 63 / STANDARD

Ch. 1-125 / FRONT / AUX / S-VIDEO / CVI / STANDARD

STANDARD / FORCED

NUMBER/LABEL/ALL/NONE

ON/OFF

1-99/OFF

OFF / BLACK / BLUE

ON / OFF

POWER ON/OFF/ON

ON / OFF

OFF/CC-1/CC-2/CC ON MUTE

ON / OFF

OFF/15/30/45/60/90/120/180/240

STANDARD/HIGH

COMMERCIAL

SETUP MENU

CONSUMER

MAIN MENU

* COMMERCIAL FEATURE

ITV MENU ITEMS & AVAILABILITY IN CONSUMER &COMMERCIAL MODES (MODELS PRF227S, PLW225S)

PLW225S & PRF227S DFU # 3135-125-20871 PRELIMINARY 04/15/02

ITV Menu Items & Availability In Commercial Mode (Features Menu) (models PRF227S, PLW225S)

The following menu is available on your Philips Institutional television when it is in Commercial mode. The Features Menu items are limited to the following when pressing Menu or Sleep on a guest-mode remote (or RG4172BK master setup remote in guest mode), or when pressing the front panel keyboard’s VOLUME + and VOLUME - simultaneously (provided the television’s front panel keyboard has not been locked out, see KEYBOARD LOCK).

CC OFF/CC-1/CC-2/CC ON MUTE

SLEEPTIMER OFF/15/30/45/60/90/120/180/240

V-CHIP SETUP

(see V-CHIP MENU ITEM)

EXIT >

FEATURES MENU

Notes:

 Regardless of whether the television is in Consumer or Commercial mode, if you press Menu on an RG4172BK master setup remote when the setup remote is in setup mode, the television’s SETUP MENU described earlier will appear.



Certain features that are unique to commercial setup, such as POWER ON FORCED and KEYBOARD LOCK will

remain in effect immediately after the television is placed in Consumer mode

IF THE TELEVISION IS NOT FIRST POW-

ERED OFF. Such features are denoted with a “*” in the menu item summary and descriptions.

 The limited Features Menu appears when the television is in Commercial mode and a guest remote (or setup remote in guest mode) Menu or Sleep button is pressed, or when the television’s front panel keyboard VOLUME - and VOLUME + are pressed simultaneously (provided the television’s front panel keyboard is not locked out, see KEYBOARD LOCK).

Front Panel Controls*

Refer also to the sections in this documentation regarding the use of the front panel controls, specifically front keyboard lock-out*.

PRF227S: The PRF227S front panel is limited to power on/off.

PLW225S: The PLW225S front panel consists of power on/off, volume, and channel controls. Channel - and Channel +

normally change the television’s channel or input to any of the channels or inputs currently in the Channel Ring (see Channel Ring). Volume + and Volume - normally control the television’s audio volume. However, simultaneously pressing Volume + and Volume - invokes a menu. This will be either the Features Menu (see Features Menu, if the television is in Commercial Mode, or the Main Menu, if the television is in Consumer Mode. Once either menu is active, Channel + and Channel - navigate vertically to select a menu item, and Volume + and Volume - change the currently-selected menu item.

* NOTE: F

RONT PANEL CONTROLS ARE INOPERATIVE IF THE FRONT KEYBOARD HAS BEEN LOCKED OUT. SEEFRONT

KEYBOARD LOCKOUT.
