Philips MX5800SA-21 User Manual

DVD VIDEO / SACD DIGITAL SURROUND SYSTEM
MX
5800SA
MX
5800SA
1
México
Es necesario que lea cuidadosamente su instructivo de manejo.
PRECAUCIÓN - ADVERTENCIA
Verifique que el voltaje de alimentación
sea el requerido para su aparato
Para evitar el riesgo de choque eléctrico, no quite la tapa.
En caso de requerir servicio, dirijase al personal calificado.
Descripción: Sistema receptor/reproductor de DVD Modelo : MX5800SA/21 Alimentación: 110–127 / 220–240V~; 50–60 Hz Consumo: 150 W Importador: Philips Mexicana, S.A. de C.V. Domicilio: Av. La Palma No. 6
Localidad y Tel: Edo. de México C.P. 52784
Exportador: Philips Electronics HK, Ltd. País de Origen: China Nº de Serie: ______________________________
ATENCIÓN
Col. San Fernando La Herradura Huixquilucan
Tel. 52 69 90 00
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO
ANTES DE USAR SU APARATO.
AVISO IMPORTANTE
Philips Mexicana, S.A. de C.V.no se hace
responsable por daños o desperfectos causados por:
– Maltrato, descuido o mal uso, presencia de
insectos o roedores (cucarachas, ratones etc.).
– Cuando el aparato no haya sido operarado
de acuerdo con el instructivo del uso, fuera de los valores nominales y tolerancias de las tensiones (voltaje), frecuencia (ciclaje) de alimentación eléctrica y las características que deben reunir las instalaciones auxiliares.
– Por fenómenos naturales tales como:
temblores, inundaciones,incendios, descargas eléctricas, rayos etc. o delitos causados por terceros (choques asaltos, riñas, etc.).
2
CAUTION
Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.
3
3
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories. “Dolby”, “Pro-Logic” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. ©1992-1999 Dolby Laboratories, Inc. All rights reserved.
Manufactured under license from Digital Theater Systems, inc. US Pat. No. 5,451,942 and other worldwide patents issued and pending. “DTS” and “DTS Digital Surround” are trademarks of Digital Theater Systems, Inc. 1996 Digital Theater Systems, Inc. All rights reserved.
4
Index
English ----------------------------------------- 6
Français-------------------------------------- 50
Español -------------------------------------- 94
------------------------------------------------------ 138
English
Français
Español
5
Contents
English
General Information
Supplied accessories ............................................ 8
Care and safety information .............................. 8
Connections
Step 1: Set up the surround speakers .............. 9
Step 2: Set up the front speakers
with the subwoofer stands................................. 9
Step 3: Connecting speakers and
twin subwoofer ................................................... 10
Step 4: Placing the speakers and subwoofer
stands .................................................................... 11
Step 5: Connecting FM/MW antennas .......... 11
Step 6: Connecting TV ....................................... 12
Using Composite Video jack (CVBS) ....... 12
Using Component Video jacks (Pr Pb Y) . 12
Using S-Video jack ........................................ 13
Using an accessory RF modulator ............ 13
Step 7: Connecting the power cord............... 14
Connections (optional)
Connecting a VCR or Cable / Satellite Box ... 15
Viewing and listening to the playback ...... 15
Using the VCR for recording DVDs ......... 15
Connecting digital audio equipment .............. 15
Listening to the playback ............................ 15
Recording (digital) ........................................ 15
Functional Overview
Main unit and remote control .................. 16–17
Control buttons available on the
remote only ................................................... 17
Getting Started
Step 1: Inserting batteries into the
remote control ................................................... 18
Using the remote control to operate
the system ...................................................... 18
Step 2: Setting the clock ................................... 18
Step 3: Setting the TV ........................................ 19
Changing the NTSC/PAL setting via
the remote control ...................................... 19
Selecting the colour system that
corresponds to your TV .............................. 19
Step 4: Selecting speaker layout ...................... 20
Changing seating control position ............ 20
Setting the speakers’ channels ................... 21
Step 5: Setting language preference ................ 21
Disc Operations
Playable discs ....................................................... 22
Playing discs ......................................................... 22
Turning on / off auto Eco standby mode .. 23
Using the Disc Menu ......................................... 23
Basic playback controls ..................................... 23
Resuming playback from the last
stopped point (DVD/VCD) ........................ 23
Replacing discs without interrupting
playback........................................................... 23
Selecting various repeat functions .................. 24
Repeat play mode ......................................... 24
Repeating a section within a
chapter/track ................................................. 24
Programme favourite tracks
(audio CDs only) ......................................... 24–25
Clearing the programme ............................. 25
Using the menu bar to programme ............... 26
Playing MP3 disc.................................................. 27
Programme MP3 disc ................................... 27
DVD Menu Options
Using the menu bar ........................................... 28
Using the Karaoke feature ............................... 29
Using the Setup Menu (User Preference
Settings) ................................................................ 30
Setting the TV shape .................................... 30
Improving the image for NTSC setting ... 31
Adjusting the picture position on the TV 31
Selecting a predefined colour setting ....... 31
Fine-tuning the personal colour setting .. 32
Improving the image for Progressive Scan
Video output setting .................................... 32
Setting the digital output ............................ 33
Setting the PCM output .............................. 33
Setting the analogue output ....................... 34
Night mode – turning on/off ..................... 34
Status window – turning on/off ................ 35
PBC (Playback Control) – turning on/ off 35
Help text – turning on/off ......................... 35
Changing the password ............................... 36
Restricting playback by setting
Parental Level ................................................ 37
Locking/Unlocking the DVD for viewing 38
Enabling Play one/ Play always .................... 39
Changing the country .................................. 39
6
Tuner Operations
Tuning to radio stations .................................... 40
Presetting radio stations ................................... 40
Using the Plug and Play ............................... 40
Automatic presetting ............................ 40–41
Manual presetting ......................................... 41
Selecting a preset radio station ....................... 41
Deleting a preset radio station .................. 41
Changing tuning grid .......................................... 41
Timer Operations
Setting the timer ................................................. 42
Activating/Deactivating the timer ............ 42
Setting the Sleep timer ..................................... 43
Sound and Volume Controls
Sound Control .................................................... 44
Selecting surround sound ........................... 44
Turning on / off clear voice effect ............... 44
Changing subwoofer volume level ............ 44
Adjusting Bass/Treble level ........................ 44
Selecting digital sound effects .................... 44
Volume Control .................................................. 44
Other Functions
Switching on/off ................................................. 45
Switching to active mode ............................ 45
Switching to Eco Power standby mode ... 45
Switching to standby mode (view clock). 45
Dimming system’s display screen .................... 45
Recording to an external device ..................... 45
Using the remote to operate your television 45
Contents
English
Troubleshooting ............................. 46–47
Specifications ........................................... 48
Glossary ......................................................... 49
7
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
DVD Home Cinema System
PHILIPS
Gerenal Information
English
Supplied accessories
Surround/ centre
speaker cable
Front speaker and Subwoofer cables
Audio cable (red/white)
Composite video cable (yellow)
Component video cables (red/blue/green)
FM wire antenna
MW loop antenna
Remote control and two batteries
AC power cable
Mini speaker stands and screws
Brackets and screws
DISC/
TUNER AUX/DI
MEDIA
TV/AV
123
456
789
SURR.
0
VOL
SYSTEM MENU
SEATING ZOOM
PREV NEXT
OK
STOP PLAY/PAUSE
REPEAT REPEATDISC SKIP
VOICE MUTE
DIM SLEEP SUB TV VOL
SOUND
PROGRAM
A-B
(2x)
Care and safety information
Avoid high temperatures, moisture,
(3x)
(2x)
DISC MENU
(4x)
(2x)
water and dust
– Do not expose the system, batteries or discs to humidity, rain, sand or excessive heat (caused by heating equipment or direct sunlight.) Always keep the disc tray closed to avoid getting dust on the lens.
Avoid condensation problem
– The lens may cloud over when the player is suddenly moved from cold to warm surroundings, making it impossible to play a disc. Leave the player in the warm environment until the moisture evaporates.
Do not block the vents
– Do not operate the DVD system in an enclosed cabinet and allow about 10 cm (4 inches) of free space all around the player for adequate ventilation.
Care of disc
– To clean a CD, wipe it in a straight line from the centre towards the edge using a soft, lint-free cloth. Do not use cleaning agent, as they may damage the disc! – Write only on the printed side of a CDR(W) and only with a soft felt­tipped pen. – Handle the disc by its edge, do not touch the surface.
Care of the cabinet
– Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasives.
Finding a suitable location
– Place the player on a flat, hard, stable surface.
Additional accessories: – Adaptor (for version/ 21S only)
8
Connections
Step 1: Set up the surround
speakers
screws
mini speaker stand
1 OR 2
1 Before connecting the speakers to the DVD
system, firmly attach the mini speaker stands to the surround speakers using the supplied screws.
OR
2 Alternatively, you can choose to mount the
speakers on the wall. Attach the supplied bracket firmly to the rear of speakers using the supplied screws. Then mount a screw (not supplied) on the wall where the speaker is to be hung and hook the speaker securely onto the mounted screw.
CAUTION!
You should get a qualified person to attach the brackets to the wall. DO NOT do it by yourself to avoid unexpected damage to the equipment or injury to personnel.
Step 2: Set up the front
speakers with the subwoofer stands
front speaker
1
2
subwoofer stand
The connections between front speakers and DVD system are through the twin subwoofer stands.
1 Attach the left front speaker to the left
subwoofer stand and right front speaker to the right subwoofer stand.
2 If you want to disconnect speaker from the
subwoofer stand, press the button at the rear of subwoofer stand while pulling up the speaker.
Note: – The front speakers are labelled as FRONT L (left) or FRONT R (right).
English
Note: – The surround speakers are labelled as REAR L (left) or REAR R (right).
9
Connections
English
Step 3: Connecting speakers
and twin subwoofer
front speaker
with subwoofer
stand (right)
L
L
R
R
SUB-WOOFER
C
DIGITAL
OUT
SL
SPEAKER SYSTEMS
SR
SURROUNDCENTER FRONT
Surround speaker
(right)
Connect the supplied speaker systems using the supplied speaker cables by matching the colours of the jacks and speaker cables. Fully insert the stripped portion of the speaker wire into the jacks.
Speakers / Subwoofer - +
Front Left (FL) (L) black white
Front Right (FR) (R) black red
Center (C) black green
Surround Left (SL) black blue
Surround Right (SR) black gray
Subwoofer (L) black purple
Subwoofer (R) black purple
DIGITAL
IN
MW
FM ANTENNA
AUDIO
VIDEO OUT
Pr
TVINLINE
AUX
CVBS
OUT
IN
L
R
Pb
Y
S-VIDEO
Surround speaker
(left)
front speaker
with subwoofer
stand (left)
VOLTAGE SELECTOR
~ AC MAINS
110V
220V
127V
240V
P-SCAN
ON OFF
Centre
speaker
Notes: – Ensure that the speaker cables are correctly connected. Improper connections may damage the system due to short-circuit. – Do not connect more than one speaker to any one pair of +/- speaker jacks. – Do not connect speakers with an impedance lower than the speakers supplied. Please refer to the SPECIFICATIONS section of this manual.
10
Connections
FM ANTENNA
MW
DIGITAL
OUT
DIGITAL
IN
AUX
IN
TVINLINE
OUT
AUDIO
VIDEO
OUT
CVBS
S-VIDEO
L
R
Pr
Pb
Y
1
2
SPEAKER SYSTEMS (4Ω)
SURROUND CENTER FRONT
L
R
SL
SR
C
SUB-WOOFER
Step 4: Placing the speakers
and subwoofers
Centre speaker and DVD system
Front speaker
with subwoofer
stand (Left)
2
1
3
Surround Speaker
(Left)
Surround Speaker
For best possible surround sound, all the speakers should be placed at the same distance from the listening position.
1 Place the left and right front speakers with
subwoofer stands at equal distances from the TV and at an angle of approximately 45 degrees from the listening position.
2 Place the centre speaker above the TV or the
DVD system so that the centre channel’s sound is localised.
3 Place the surround speakers at normal
listening ear level facing each other or mounted on the wall.
Notes: – To avoid magnetic interference, do not position the front speakers too close to your TV. – Allow adequate ventilation around the DVD system.
Front speaker
with subwoofer
stand (Right)
1
3
(Right)
Step 5: Connecting FM/ MW
antennas
FM
antenna
fix the claw
into the
slot
MW
antenna
1 Connect the supplied MW loop antenna to the
MW jack. Place the MW loop antenna on a shelf or attach it to a stand or wall.
2 Connect the supplied FM antenna to the FM
jack. Extend the FM antenna and fix its ends to the wall.
For better FM stereo reception, connect an external FM antenna (not supplied).
Notes: – Adjust the position of the antennas for optimal reception. – Position the antennas as far as possible from your TV, VCR or other radiation source to prevent unwanted interference.
MW
FM ANTENNA
11
English
Connections
P-SCAN
ON OFF
Pb
DIGITAL
OUT
DIGITAL
IN
AUX
IN
TVINLINE
OUT
AUDIO
VIDEO
OUT
CVBS
S-VIDEO
FM ANTENNA
MW
L
R
Y
AUDIO
OUT
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO OUT
Pr/Cr
Pb/Cb
Y
S-VIDEO IN
VIDEO IN
COMPONENT VIDEO IN
2
1
Pr
L
R
SL
SR
C
SUB-WOOFER
3
English
Step 6: Connecting TV
COMPONENT
VIDEO IN
S-VIDEO
IN
Pr/Cr
AUDIO
OUT
Pb/Cb
TVINLINE
2
FM ANTENNA
OUT
VIDEO
OUT
CVBS
S-VIDEO
VIDEO IN
Y
1
Pb
P-SCAN
ON OFF
Y
3
COMPONENT
VIDEO IN S-VIDEO IN
Pr/Cr AUDIO OUT
Pb/Cb
VIDEO IN
Y
SR
L
R
C
SL
SUB-WOOFER
DIGITAL
DIGITAL
MW
AUDIO
AUX
OUT
IN
L
R
IN
IMPORTANT! – You only need to make one video connection from the following options, depending on the capabilities of your TV system. – Connect the DVD system directly to the TV.
IMPORTANT! – Component Video connection provides higher picture quality. This option must be available on your TV. – The progressive scan video quality is only possible through Component Video (Pr Pb Y) output.
Using Composite Video jack (CVBS)
1 Use the composite video cable (yellow) to
connect the DVD system’s CVBS jack to the video input jack (or labelled as A/V In, Video In, Composite or Baseband) on the TV.
2 To hear the TV channels through this DVD
system, use the audio cables (white/red) to connect TV IN (L/R) jacks to the corresponding AUDIO OUT jacks on the TV.
3 Set the P-SCAN switch to ‘OFF.’
12
Using Component Video jacks (Pr Pb Y)
1 Use the component video cables (red / blue /
green) to connect the DVD system’s Pr Pb Y jacks to the corresponding Component video input jacks (or labelled as Pr/Cr Pb/Cb Y or YUV) on the TV.
2 To hear the TV channels through this DVD
system, use the audio cables (white/red) to connect TV IN (L/R) jacks to the corresponding AUDIO OUT jacks on the TV.
3 If you are using a Progressive Scan TV (TV
must indicate Progressive Scan or ProScan capability,) set the P-SCAN switch to ‘ON.’ Otherwise, set it to ‘OFF.’
SURROUND CENTER FRONT
Connections
Pb
DIGITAL
OUT
DIGITAL
IN
AUX
IN
TVINLINE
OUT
AUDIO
VIDEO
OUT
CVBS
S-VIDEO
FM ANTENNA
MW
L
R
Pr
Y
AUDIO IN R L
VIDEO
IN
TO TVINT IN
CH3 CH4
1
2
SPEAKER SYSTEMS
SURROUND CENTER FRONT
L
R
SL
SR
C
SUB-WOOFER
3
P-SCAN
ON OFF
COMPONENT
VIDEO IN
S-VIDEO
IN
Pr/Cr
AUDIO
OUT
Pb/Cb
COMPONENT VIDEO IN
S-VIDEO
IN
Pr/Cr AUDIO OUT
Pb/Cb
VIDEO IN
Y
VIDEO IN
Y
1
L
R
SUB-WOOFER
C
SL
SR
DIGITAL
DIGITAL
MW
FM ANTENNA
AUDIO
VIDEO
OUT
TVINLINE
AUX
OUT
IN
L
R
IN
2
Pr
CVBS
OUT
Pb
P-SCAN
ON OFF
Y
S-VIDEO
3
IMPORTANT!
– S-Video connection provides better picture quality. This option must be available on your TV.
Using S-Video jack
1 Use the S-video cable (not supplied) to connect
the DVD system’s S-VIDEO OUT jack to the S-Video input jack (or labelled as Y/C or S-VHS) on the TV.
2 To hear the TV channels through this DVD
system, use the audio cables (white/red) to connect TV IN (L/R) jacks to the corresponding AUDIO OUT jacks on the TV.
3 Set the P-SCAN switch to ‘OFF.’
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or Cable TV signal
IMPORTANT!
– If your TV only has a single Antenna In jack (or labelled as 75 ohm or RF In), you will need an RF modulator in order to view the DVD playback on the TV. See your electronics retailer or contact Philips for details on RF modulator availability and operations.
Using an accessory RF modulator
1 Use the composite video cable (yellow) to
connect the DVD system’s CVBS jack to the video input jack on the RF modulator.
2 Use the RF coaxial cable (not supplied) to
connect the RF modulator to your TV’s RF jack.
3 Set the P-SCAN switch to ‘OFF.’
English
13
Connections
English
Step 7: Connecting the power
cord
1
MW
FM ANTENNA
AUDIO
VIDEO
OUT
DIGITAL
OUT
L
R
DIGITAL
IN
Pr
TVINLINE
AUX
CVBS
OUT
IN
Pb
Y
S-VIDEO
AUDIO
OUT
VOLTAGE SELECTOR
110V
220V
127V
240V
P-SCAN
ON OFF
COMPONENT VIDEO IN
S-VIDEO
IN
Pr/Cr
~ AC MAINS
Pb/Cb
VIDEO IN
Y
After everything is connected properly,
1 Set the VOLTAGE SELECTOR to the local
power line voltage.
2 Plug in the AC power cord to the power
outlet. Never make or change any connections with the power switched on.
2
~ AC MAINS
2
On the DVD system,
"AUTO INSTALL – PRESS PLAY" may appear on the display panel. Press ÉÅ on the front panel to store all available radio stations or press Ç to exit (see page 40 “Tuner Operations”).
SEARCH
STOPPLAY•PAUSE SEATING
SURROUND
PLAYPAUSE
DVD VIDEO DIGITAL SURROUND SYSTEM
SOURCE
MIC LEVEL MIC
VOLUME
AUTO INSTALL - PRESS PLAY
T
N
R
E
E
C
S
C
I
D
R
I
T
G
F
H
E
DVD
T
L
ISC CHANGER
PROG TUNING CLOCKTIMER
S
R
U
-
R
R
-
U
L
S
S
B
U
14
TREBLE
BASS
Connections (optional)
DIGITAL
OUT
DIGITAL
IN
AUX IN
TV
IN
AUDIO
MW
L
R
DIGITAL IN
DIGITAL OUT
2
1
SPEAKER SYSTEMS (4)
SURROUND CENTER FRONT
L
R
SL
SR
C
SUB-WOOFER
Connecting a VCR or Cable/Satellite Box
COMPONENT
VIDEO IN
S-VIDEO
IN
Pr/Cr
AUDIO
OUT
Pb/Cb
VIDEO IN
Y
1
ANT IN
TO TV
SPEAKER SYSTEMS (4)
SURROUND CENTER FRONT
VCR or
Cable/Satellite Box
L
R
SUB-WOOFER
C
DIGITAL
AUX
OUT
SL
L
SR
R
DIGITAL
IN
2
MW
FM ANTENNA
3
AUDIO
VIDEO
OUT
Pr
TVINLINE
CVBS
OUT
IN
Pb
P-SCAN
ON OFF
Y
S-VIDEO
4
Viewing and listening to the playback
1 Connect the VCR or Cable/Satellite Box to
the TV as shown.
2 Connect the DVD system’s AUX IN (R/L)
jacks to the AUDIO OUT jacks on the VCR or cable/satellite box.
Before starting operation, press AUX/DI on the remote to select “AUX” in order to activate the input source.
Using the VCR for recording DVDs
Some DVDs are copy-protected. You cannot record or dub protected discs using a VCR.
3 Connect the DVD system’s CVBS jack to the
VIDEO IN jack on the VCR.
4 Connect the DVD system’s LINE OUT (R/L)
jacks to the AUDIO IN jacks on the VCR. This will allow you to make analogue stereo (two channel, right and left) recordings.
To view DVD playback while recording,
you must connect the DVD system to your TV using the S-VIDEO (as shown above) or the Component (Pr Pb Y) video connection.
Connecting digital audio equipment
(for example) CD Recorder
Listening to the playback
1 Connect the DVD system’s DIGITAL IN jack
to the DIGITAL OUT jack on a digital audio device.
Before starting operation, press AUX/DI on the remote to select “DI” in order to activate the input source.
Recording (digital)
2 Connect the DVD system’s DIGITAL OUT
jack to the DIGITAL IN jack on a digital recording device (DTS-Digital Theatre System compatible, with a Dolby Digital decoder, for example).
Before starting operation, set the DIGITAL OUTPUT according to the audio connection. (See page 33 “Setting the digital output”).
Notes: – Some DVDs are copy-protected. You cannot record the disc through a VCR or digital recording device. – Always refer to the owner’s manual of the other equipment for complete connection and usage details.
English
15
Loading...
+ 34 hidden pages
