Philips MX2791C User Manual
27" Stereo Remote Color Monitor/Receiver
(screen size measured diagonally)
• Two-tuner PIP
• MagnaVue™ Plus
• MagnaGlo™
remote control
• Remote Locator™
• Dynamic comb filter
• Video DNR
• Audio/video
jack panel
• dbx
®
hi-fi stereo
sound system with
surround sound jacks
• Incredible Stereo™
Color Television
MX2791B
• SmartSound™
• SmartPicture™
• Surf™
• SmartMute™
• First Time Setup
• Onscreen Clock
Universal TV/VCR/Cable Remote
(Remote # RCU81E)
Color Television
MX2791B
MagnaVue™ Plus
A unique combination of contrast enhancement, color enrichment technologies, and LTI™ that produces deeper, more vibrant colors with an
unrivaled picture that’s larger than life.
Luminance Transience Improvement (LTI™)
A new generation of edge enhancement technology applied directly to the
video processing circuitry creates a remarkable increase in clarity and sharpness at the point of transition from dark to light areas of the video image.
When coupled with other recent advancements, LTI™ produces a picture
so sharp and well defined that you’ll never want to go to the movies again.
Two-Tuner PIP
Now you can enjoy all the benefits of Smart Window™ PIP without a
VCR! With two separate tuners (and two separate tuner inputs), you can
tune to your favorite show with Tuner One, for example, while scanning
other channels with Tuner Two in the PIP window. The A/V inputs are
also available as PIP sources so all functions of standard PIP are still
accessible. You can swap the main and secondary pictures, position
secondary pictures in any screen corner, even freeze the main picture
information and put it into the inset picture. In all cases, the main picture
is provided with its corresponding audio.
Green Stretch
Advanced chroma processing circuitry takes automatic flesh-tone correction to a new level making flesh-tones more true-to-life for eye-popping
realism in your TV picture.
Dynamic Comb Filter
Improved Image Definition (IID™)
Video DNR (Dynamic Noise Reduction)
SmartPicture™
27'' Dark Glass Flat Square Picture Tube
Black Stretch
Blue Stretch
Remote Control
MagnaGlo™ Remote Control
No more fumbling in the dark to access TV and VCR functions. Just
press the button on the remote control and all buttons on the
remote control glow.
Remote Locator™
Lost or misplaced remotes are easy to find! Simply press the POWER
button on the TV. The words “Locating Remote” appear on the screen
and the remote control beeps–leading you right to it. Press any key on
the remote to stop the beeping.
Universal TV/VCR/Cable Remote
Controls all features and functions of this monitor/receiver with direct
menu access, including the Two-Tuner A/B Switch, Smart Window™ PIP
with On/Off, Position, Freeze, Swap, Source, and PIP CHANNEL ;
Multimedia Mode, Incredible Stereo™, Surf™, and the dual A/V input/
tuner switch. It also activates the exclusive SmartSound™, SmartClock™,
and SmartPicture™ options. In addition, this remote controls all important
operating features and functions of virtually all infrared VCRs, most
brands of DVD Video players, virtually all brands of DBS receivers, and
on/off as well as CHANNEL functions on most cable converter/
decoders. (Remote # RCU81E)
Convenience
Multimedia Mode
Simply press the MULTIMEDIA button on the remote control and
sequentially scroll through the various inputs. The SmartPicture™ option
is automatically set to MULTIMEDIA for optimal adjustment of customer
controls. The third time the MULTIMEDIA button is pressed, the TV
returns to the original tuner source and all settings revert to their previous
condition…automatically!
UP DN
SmartSurf™
SmartClock™
SmartMute™
Easy First Time Setup
Alternate Channel
Onscreen Clock with Sleep Timer and Alarm Timer
Parental Control
Trilingual Onscreen Display
Auto Programming
Closed Caption
Onscreen Volume Bar
Sound
SmartSound™
When activated, SmartSound™ keeps volume levels constant between
programs and commercials, and from one channel to another. SmartSound™
constantly monitors the audio signal, reducing a signal that’s too loud and
increasing a signal that’s too weak.
Surround Sound
Experience the full three-dimensional effect of a live musical performance
or theater with four or more speakers. The front left and right speakers
contain directional sounds creating stereo spread or what’s known as the
“wall of sound” as well as other important effects that help “steer” the
audio more realistically to the listener’s ears. The rear speakers help to
recreate the reflective ambience of the original room in which the audio
was recorded. They generate short echoes and delays that help make the
entire audio experience more lifelike.
dbx
®
Hi-Fi Stereo Sound System with Surround Sound Jacks
Incredible Stereo™
Tone Controls
Audio/Video Jack Panel
Audio/Video Jack Panel (J834)
The A/V jack panel on the back of this set includes dual audio/video inputs for
connection of a VCR, DVD Video player, Web browser, or other accessory
equipment; variable audio outputs which allow sound from TV or accessories
to be routed through a home audio system; standard video output for connection to a VCR; S-video input for connection of a high-resolution video
accessory, and dual RF inputs for tuner “A” and tuner “B”.
Surround Sound Jacks
Additional Features Include:
• Channel edit
• Total remote menu format tuning with multicolor onscreen graphics
• 181-channel capability
• 4-way cursor control
• Random channel access
• Programmable scan tuning
• Status recall
• Mono/stereo/SAP select
• Cable/normal select
• Two 5" oval, full-range speakers with menu-selectable speaker switch
UPC: 037849865200
Product dimensions: 30"W x 22.8"H x 19.9"D
Product weight: 78 lbs.
Carton dimensions: 34"W x 26.6"H x 23.1"D
Carton weight: 82 lbs.
Master pack: 1
Carton Contains: 27" Stereo Remote Color Monitor/Receiver, MagnaGlo Universal TV/VCR/CBL
Locator Remote Control w/Batteries, Operating Instructions, Warranty Information
Printed in U.S.A.
©1998 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
KID Design 97451, Philips Consumer Electronics Co.
Subject to modification without notice
* MagnaVue, MagnaGlo, Smart Window, Remote Locator, SmartSound,
LTI, IID, SmartPicture, SmartClock, SmartMute, SmartSurf, and
Incredible Stereo are trademarks of Philips Consumer Electronics Co.
dbx is a registered trademark of dbx, Inc. Sunnyvale, CA
