Philips MG7770-15 Operating Instructions
MG7770
1MM
2MM
3-7MM
BODY 5MM
BODY 3MM
4MM
9MM
12MM
16MM
9 10
7 8
2
3
1
6
5
1312
1817
2119 20
11
161514
4
22
23
25
24
empty page before TOC
English 6
Čeština 24
Eesti 43
Hrvatski 62
Latviešu 81
Lietuviškai 100
Magyar 119
Polski 139
Română 160
Shqip 179
Slovenščina 197
Slovensky 215
Srpski 235
Български 252
Македонски 274
Русский 294
Українська 314
Қазақша
333
English
6
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Full-size hair trimmer
2 On/off button
3 Battery status indicator
4 Socket for small plug
5 Body shaver
6 Skin protector
7 Extra-wide hair trimmer
8 Precision trimmer
9 Precision shaver
10 Nose trimmer
11 Hair comb wide 5/32in. (4mm)
12 Hair comb wide 3/8in. (9mm)
13 Fading hair comb 5/32in.-3/8in. (4-9mm)
14 Hair comb wide 15/32in. (12mm)
15 Hair comb wide 21/32in. (16mm)
16 Fading hair comb 5/32in.-3/8in. (4-9mm)
17 Body comb 1/8in. (3mm)
18 Body comb 3/16in. (5mm)
19 Stubble comb 3/64in. (1mm)
20 Stubble comb 5/64in. (2mm)
21 Adjustable comb (3-7mm)
22 Supply unit
23 Small plug
24 Cleaning brush
25 Pouch
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
English
English
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the
detachable supply unit (HQ8505) provided
with the appliance.
- The supply unit contains a transformer. Do
not cut off the supply unit to replace it with
another plug, as this causes a hazardous
situation.
7
English
8
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
- Always unplug the appliance before you
clean it under the tap.
- Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never immerse the charging
stand in water and do not rinse
it under the tap.
English
- Never immerse the appliance in
water. Do not use the appliance
in the bath or shower.
- Never use water hotter than
60°C to rinse the appliance.
- Only use this appliance for its
intended purpose as shown in
the user manual.
- For hygienic reasons, the
appliance should only be used
by one person.
- Do not use the supply unit in or
near wall sockets that contain
an electric air freshener to
prevent irreparable damage to
the supply unit.
- Never use compressed air,
scouring pads, abrasive
cleaning agents or aggressive
liquids such as petrol or
acetone to clean the appliance.
9
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
English
10
General
- This appliance can be safely cleaned under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
- Maximum noise level: Lc = 69dB(A)
Charging
Battery status indications
- When the battery is almost empty, the battery
status indicator flashes orange.
- When the appliance is charging, the battery
status indicator flashes white slowly.
- During quick charge, the battery status indicator
flashes white. After approx. 5 minutes of
charging, the appliance contains enough power
for one cordless trimming session.
- When the battery is fully charged, the battery
status indicator lights up white continuously.
Note: After approx. 30 minutes, the light goes out
automatically.
Charging
Charge the appliance before you use it for the first
time and when the display indicates that the
battery is almost empty. When the appliance has
charged for 3 hours, it has a cordless operating
2
1
1
2
time of up to 5 hours.
1 Make sure the appliance is switched off.
2 Insert the small plug into the appliance and put
the supply unit in the wall socket.
3 After charging, remove the supply unit from the
wall outlet and pull the small plug out of the
appliance.
Quick charge
After approx. 5 minutes charging, the appliance
contains enough power for one cordless trimming
session.
Using the appliance
Note: This appliance can only be used without
cord.
Note: Switch off and clean the appliance after each
use.
Detaching and attaching cutting elements
1 To detach a cutting element, push upwards
against the teeth of the cutting element and
take it off the handle.
English
11
2 To attach a cutting element, insert the lug of the
cutting element into the guiding slot at the front
and push the back of the cutting element onto
the appliance ('click').
1
2
English
12
Detaching the precision shaver and nose trimmer
1 Place your finger on the arrow at the back of
the attachment and push it off the handle in the
direction of the arrow.
Attaching and detaching combs
1 To attach any type of guard onto a cutting
element, slide the front part of the guard onto
the teeth of the cutting element. Then push
down the center of the guard with your fingers
or the palm of your hand ('click').
2 To detach any type of comb from the cutting
element, carefully pull its back part off the
appliance and then slide it off the cutting
element.
Note: When trimming for the first time, start by
using the comb with the maximum trimming
length setting to familiarize yourself with the
appliance.
Switching the appliance on and off
Press the on/off button once to turn the appliance
on or off.
Attachments for use on beard
Full-size hair trimmer
Use the full-size hair trimmer without a comb to
trim hair close to the skin (to a length of 1/32in
(0.5mm) or to create clean lines around your
= mm
beard, neck and sideburns.
1 To trim hair close to the skin, place the flat side
of the cutting element against your skin and
make strokes against the direction of hair
growth.
2 For contouring, hold the cutting element
perpendicular to the skin and move it upwards
or downwards with gentle pressure.
Beard combs
Attach a beard comb to the full-size hair trimmer
to trim your beard and moustache evenly. The
appliance comes with 5 beard combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb inch mm
Stubble comb 3/64in. 1mm
Stubble comb 5/64in. 2mm
Adjustable beard
comb
1/8in.- 9/32in. 3mm-7mm
1 Attach the comb to the full-size hair trimmer.
2 Adjustable comb: Push the length selector to
the left or right to select the desired hair length
setting.
English
13
English
14
3 To trim the most effective way, move the comb
against the direction of hair growth. Make sure
the surface of the comb always stays in contact
with the skin.
Attachments for use on body
- Use the green body combs to trim body hair.
- When you trim for the first time, use the
5mm/3/16in. body comb to familiarize yourself
with the appliance.
- Make sure hair is clean and dry as wet hair
tends to stick to the body.
- When trimming sensitive areas, always use a
body comb.
- Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards, downwards, or
across). Practice is best for optimum results.
- Always make smooth and gentle movements
and be sure the surface of the comb always
stays in contact with your skin.
- When too many hairs have accumulated on the
appliance, blow the hairs out before use, for
best trimming results.
Body combs
Attach a body comb to the full-size hair trimmer to
trim hairs below the neckline. The appliance comes
with 2 body combs. The hair length settings are
indicated on the combs. The settings correspond
to the remaining hair length after trimming.
Comb inch mm
Body comb (green) 1/8in. 3mm
Body comb (green) 3/16in. 5mm
English
1 Attach a body comb to the full-size hair
trimmer.
2 To trim in the most effective way, stretch the
skin with your free hand and move the comb
against the direction of hair growth. Make sure
the surface of the comb always stays in contact
with the skin.
Body shaver
Attach the body shaver to the appliance, to shave
hairs below the neckline such as your armpits and
chest. Only use the body shaver with the skin
protector.
1 Attach the body shaver to the appliance.
2 Attach the skin protector to the full-size hair
trimmer.
3 To shave in the most effective way, stretch the
skin with your free hand and move the shaver
against the direction of hair growth. Make sure
the surface of the shaver always stays in full
contact with the skin.
15
Attachments for use on head
Extra-wide hair trimmer
Use the extra-wide hair trimmer without a comb to
clip the hair on your head very close to the skin
(1/32in (0.5mm) or to contour the neckline and
area around the ears.
1 To contour the hairline around the ears, comb
the hair ends over the ears.
English
16
2 Tilt the appliance in such a way that only one
edge of the cutter blades touches the hair ends
when you shape the contours around the ears.
3 To contour the nape of the neck or sideburns,
turn the appliance and make downward
strokes.
4 Move the appliance slowly and smoothly
following the natural hairline.
Full-size hair trimmer
Use the full-size hair trimmer without a comb to
clip the hair on your head very close to the skin
(1/32in (0.5mm) or to contour the neckline and
area around the ears.
1 To contour the hairline around the ears, comb
the hair ends over the ears.
2 Tilt the appliance in such a way that only one
edge of the cutter blades touches the hair ends
when you shape the contours around the ears.
3 To contour the nape of the neck or sideburns,
turn the appliance and make downward
strokes.
4 Move the appliance slowly and smoothly
following the natural hairline.
Hair combs wide
Attach a wide hair comb to the extra-wide hair
trimmer to evenly trim the hairs on your head. The
appliance comes with 4 wide hair combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb inch mm
Hair comb 5/32in. 4mm
Hair comb 3/8in. 9mm
Hair comb 15/32in. 12mm
Hair comb 21/32in. 16mm
1 Attach a comb to the extra-wide hair trimmer.
2 Move the trimmer slowly over the crown from
different directions to achieve an even result.
Make sure the surface of the comb always stays
in contact with the skin.
-
Always move the trimmer against the
direction of hair growth. Press lightly.
-
Make overlapping passes over the head to
ensure that all hair that should be cut has
been cut.
Fading hair comb
Attach the fading hair combs to the extra-wide hair
trimmer to trim the hair around the ears with a
faded result. The appliance comes with 2 combs.
Use both combs to trim hair around both ears.
Choose a hair comb based on the preferred
trimming direction of back to front or front to back.
Always make sure that you hold the side of the
comb with the short teeth closest to your ear.
Comb inch mm
Fading hair combs 5/32in.-3/8in. 4-9mm
1 Attach the comb to the extra-wide hair trimmer
to trim the hair around the ear. Then attach the
other comb to trim the hair around the other
ear.
English
17
English
18
2 Place the appliance on your hair at the back or
front of your ear, depending on the trimming
direction you prefer. Always make sure that the
side of the comb with the short teeth is closest
to your ear.
3 Move the trimmer slowly around the ear, while
holding it steady. For best results, move the
trimmer against the direction of hair growth
(back to front).
Precision attachments for use on face
Precision trimmer
Use the precision trimmer to create fine lines and
contours around your facial style, close to the skin
(to a length of 1/32in./0.5mm).
1 Hold the precision trimming head perpendicular
to the skin and move the trimming head
upwards or downwards with gentle pressure.
Nose trimmer
Use the nose trimmer to trim your nose hair and
ear hair.
- Make sure nasal passages are clean. Make sure
outer ear channels are clean and free from wax.
- Do not insert the tip more than 3/16in./5mm.
- Always clean the attachment after each use.
Trimming nose hair
1 Gently move the tip in and out of nose while
turning it around to remove unwanted hairs.
Trimming ear hair
1 Slowly move the tip round the ear to remove
hairs that stick out beyond the rim of the ear.
2 Gently move the tip in and out of the outer ear
channel to remove unwanted hairs.
Precision shaver
Use the precision shaver after trimming, to shave
unwanted hairs on cheeks, chin and along the
beard with precision. Make sure to pre-trim your
beard first, with the full-size hair trimmer without
comb, to obtain the best result.
Note: Use the precision shaver to remove
remaining hairs and detailing your beard style. It is
not suitable for a full face shave.
1 Gently press the precision shaver onto the skin
and shave along contoured edges to remove
any unwanted hairs.
Cleaning
Never use scouring pads, abrasive cleaning
agents or aggressive liquids such as gasoline or
acetone to clean the product.
Never dry the trimmer teeth with a towel or
tissue, as this may damage the trimmer teeth.
After every use: cleaning under the tap
1 Turn off the appliance and disconnect from the
wall socket.
2 Remove any comb or cutting element from the
appliance.
3 Rinse the hair chamber under a warm tap.
English
19
English
20
4 Clean the cutting element and comb under a
warm tap.
5 Carefully shake off excess water and let all parts
air dry completely.
Thorough cleaning
1 Turn off the appliance and disconnect from the
wall socket.
2 Wipe the handle of the appliance with a dry
cloth.
3 Remove any comb or cutting element from the
appliance.
4 Remove any hairs that have accumulated in the
hair chamber with the cleaning brush supplied.
5 Remove any hairs that have accumulated in the
cutting elements and/or combs with the
cleaning brush supplied.
6 Clean the cutting elements under a warm tap.
7 Clean the combs under a warm tap.
8 Carefully shake off excess water and let all parts
air dry completely.
Cleaning the nose trimmer
Clean the nose trimmer immediately after use and
when a lot of hair or dirt has accumulated on the
nose trimmer head.
1 Rinse the nose trimmer head with hot water.
2 Turn on the appliance and rinse the nose
trimmer head once more to remove any
remaining hairs. Then turn off the appliance
again.
For a thorough clean, immerse the nose trimmer
head in a bowl with warm water for a few minutes
and then turn on the appliance to remove
stubborn hair/debris.
3 Carefully shake off excess water and let all parts
air dry completely.
Cleaning the precision shaver
1 Hold the precision shaver at the grooves on
each side and pull the top part off the bottom
part.
2 Blow and/or shake out any hair that has
accumulated inside the precision shaver.
Do not use the cleaning brush to remove hairs
from the shaving foil.
3 Clean the top part of the precision shaver under
a warm tap.
4 Carefully shake off excess water and let all parts
air dry completely.
5 Reattach the top part onto the bottom part of
the precision shaver.
Cleaning the body shaver
1 Remove the skin protector upwards off the
shaver.
English
21
English
22
2 Clean the skin protector and body shaver under
a warm tap.
Do not use the cleaning brush to remove hairs
from the shaver or skin protector.
3 Carefully shake off excess water and let both
parts air dry completely.
4 Reattach the skin protector onto the body
shaver.
Storage
- Store the appliance in the pouch supplied.
Note: Make sure the appliance is dry before you
store it in the pouch.
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).
Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
- This symbol means that this product contains a
built-in rechargeable battery which shall not be
disposed of with normal household waste
(2006/66/EC). Please take your product to an
official collection point or a Philips service
center to have a professional remove the
rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product. Before you remove
the battery, make sure that the product is
disconnected from the wall socket and that
the battery is completely empty.
Take any necessary safety precautions
when you handle tools to open the product
and when you dispose of the rechargeable
battery.
1 Check if there are screws in the back or front of
the appliance. If so, remove them.
2 Remove the back and/or front panel of the
appliance with a screwdriver. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3 Remove the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Warranty restrictions
Cutting units are not covered by the terms of the
international warranty because they are subject to
wear.
English
23
Čeština
24
Úvod
Společnost Philips Vám gratuluje ke koupi a vítá
Vás! Chcete-li využívat všech výhod podpory
nabízené společností Philips, zaregistrujte svůj
výrobek na stránkách www.philips.com/welcome.
Všeobecný popis (obr. 1)
1 Velký zastřihovač vlasů
2 Vypínač
3 Ukazatel stavu baterie
4 Zásuvka pro malou zástrčku
5 Holicí strojek na tělo
6 Ochrana pokožky
7 Velmi široký zastřihovač vlasů
8 Přesný zastřihovač
9 Přesný holicí strojek
10 Zastřihovač chloupků vnose
11 Široký hřebenový nástavec 4mm
12 Široký hřebenový nástavec 9mm
13 Hřebenový nástavec pro stupňovitý střih
4–9mm
14 Široký hřebenový nástavec 12mm
15 Široký hřebenový nástavec 16mm
16 Hřebenový nástavec pro stupňovitý střih
4–9mm
17 Hřeben na zastřihování chloupků na těle 3mm
18 Hřeben na zastřihování chloupků na těle 5mm
19 Hřeben na strniště 1mm
20 Hřeben na strniště 2mm
21 Nastavitelný hřeben (3–7mm)
22 Napájecí jednotka
23 Malá zástrčka
24 Čisticí kartáč
25 Pouzdro
Čeština
Čeština
Důležité bezpečnostní informace
Před použitím přístroje ajeho příslušenství si
pečlivě přečtěte tuto příručku sdůležitými
informacemi auschovejte ji pro budoucí použití.
Dodané příslušenství se může pro různé výrobky
lišit.
Nebezpečí
- Zdroj udržujte vsuchu.
Varování
- Knabíjení baterie používejte pouze
odnímatelnou napájecí jednotku (HQ8505)
dodávanou stímto přístrojem.
- Zdroj obsahuje transformátor. U zdroje
nikdy neodřezávejte a nenahrazujte
zástrčku. Mohlo by tak dojít knebezpečné
situaci.
25
Čeština
26
- Tento přístroj mohou používat děti od 8let
věku. Osoby somezenými fyzickými,
smyslovými nebo duševními schopnostmi
nebo nedostatkem zkušeností aznalostí jej
mohou používat, pokud jsou pod dohledem
nebo byly poučeny obezpečném používání
přístroje apokud chápou související rizika.
Děti si spřístrojem nesmí hrát. Děti nesmí
provádět bez dozoru čištění auživatelskou
údržbu.
- Před čištěním pod tekoucí vodou přístroj
vždy odpojte od sítě.
- Před použitím přístroj vždy zkontrolujte.
Přístroj nepoužívejte, je-li poškozený, aby
nedošlo ke zranění. Poškozenou součástku
vyměňujte vždy za původní typ.
- Neotvírejte přístroj, ani se nepokoušejte
vyměnit akumulátor.
Upozornění
- Dobíjecí stojan nesmíte nikdy
ponořit do vody ani ho mýt pod
tekoucí vodou.
- Nikdy neponořujte přístroj do
vody. Nepoužívejte přístroj ve
vaně ani ve sprše.
Čeština
- Koplachování přístroje nikdy
nepoužívejte vodu teplejší než
60°C.
- Přístroj používejte pouze
kúčelu, ke kterému je určen, jak
je vyobrazeno vuživatelské
příručce.
- Zhygienických důvodů by měla
přístroj používat pouze jedna
osoba.
- Nepoužívejte zdroj vzásuvce,
ve které je zapojen elektrický
osvěžovač vzduchu, ani vjejí
blízkosti. Předejdete tak
nenapravitelnému poškození
zdroje.
- Kčištění přístroje nikdy
nepoužívejte stlačený vzduch,
kovové žínky, abrazivní ani
agresivní čisticí prostředky, jako
je například benzín nebo
aceton.
27
Elektromagnetická pole (EMP)
Tento přístroj Philips odpovídá všem platným
normám a předpisům týkajícím se vystavení
účinkům elektromagnetických polí.
Čeština
28
Obecné informace
- Tento přístroj lze bezpečně vyčistit pod tekoucí
vodou.
- Napájecí jednotku lze připojit do sítě onapětí
vrozmezí 100 až 240V.
- Zdroj transformuje 100V až 240V na bezpečné
nízké napětí nižší než 24V.
- Maximální hladina hluku: Lc = 69dB(A)
Nabíjení
Kontrolky stavu baterie
- Když ukazatel stavu baterie bliká oranžově, je
baterie téměř vybitá.
- Když se přístroj nabíjí, ukazatel stavu baterie
pomalu bíle bliká.
- Při rychlém nabíjení ukazatel stavu baterie bíle
bliká. Po cca 5minutách nabíjení je kapacita
baterie holicího strojku dostatečná na jedno
stříhání bez použití napájecího kabelu.
- Jakmile je baterie nabitá, ukazatel stavu baterie
nepřetržitě bíle svítí.
Poznámka: Kontrolka se automaticky vypne
přibližně po 30minutách.
Nabíjení
Přístroj nabijte před prvním použitím nebokdyž
displej ukazuje, že je baterie téměř vybitá. Po
tříhodinovém nabití pracuje přístroj bez připojení
ksíti až 5hodin.
1 Ujistěte se, že je přístroj vypnutý.
2
1
1
2
2 Malou zástrčku zasuňte do přístroje anapájecí
jednotku zapojte do elektrické zásuvky.
3 Po nabití vytáhněte napájecí jednotku
zelektrické zásuvky amalý konektor zpřístroje.
Rychlé nabíjení
Po cca 5minutách nabíjení je kapacita baterie
přístroje dostatečná na jedno stříhání bez použití
napájecího kabelu.
Používání přístroje
Poznámka: Tento přístroj lze používat pouze bez
kabelu.
Poznámka: Po každém použití přístroj vypněte
avyčistěte.
Snímání a nasazování střihacích jednotek
1 Chcete-li střihací jednotku sejmout, zatlačte
směrem nahoru proti zubům střihací jednotky a
vyjměte ji zrukojeti.
2 Chcete-li střihací jednotku nasadit, umístěte
výstupek střihací jednotky do vodicí drážky
vpředu a zatlačte zadní část střihací jednotky
do přístroje (ozve se zaklapnutí).
Čeština
29
1
2
Čeština
30
Sejmutí přesného holicího strojku a
zastřihovače chloupků vnose
1 Položte prst na šipku na zadní straně nástavce,
zatlačte ve směru šipky a sejměte nástavec
zrukojeti.
Nasazování a snímání hřebenů
1 Když chcete na střihací jednotku nasadit
hřeben, nasaďte jeho přední část na zuby
střihací jednotky. Prsty nebo dlaní pak zatlačte
uprostřed hřebene (ozve se zacvaknutí).
2 Chcete-li sejmout hřeben ze střihací jednotky,
opatrně sejměte zadní část zpřístroje a pak ho
vysuňte ze střihací jednotky.
Poznámka: Pokud spřístrojem pracujete
poprvé, zvolte hřeben smaximální délkou
zastřižení, abyste si vyzkoušeli práci
spřístrojem.
Zapínání avypínaní přístroje
Stisknutím vypínače přístroj zapnete nebo vypnete.
Nástavce na zastřihování vousů
Velký zastřihovač
Chcete-li zastřihnout vlasy blízko pokožky (na
délku 0,5mm) nebo dosáhnout precizních linií
Loading...
