Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Full-size hair trimmer
2 On/off button
3 Battery status indicator
4 Socket for small plug
5 Body shaver (MG7730, MG7720, MG7715 only)
6 Skin protector (MG7730, MG7720, MG7715 only)
7 Precision trimmer (MG7730, MG7720, MG7715,
MG7710 only)
8 Precision shaver (MG7730, MG7720, MG7710
only)
9 Nose trimmer
10 Extra-wide hair trimmer (MG7730 only)
11 Hair comb regular 3/8in. (9mm) (MG7720,
MG7715, MG7710 only)
12 Hair comb regular 15/32in. (12mm) (MG7720,
MG7715, MG7710 only)
13 Hair comb regular 21/32in. (16mm) (MG7720,
MG7715, MG7710 only)
14 Hair comb wide 5/32in. (4mm) (MG7730 only)
15 Hair comb wide 3/8in. (9mm) (MG7730 only)
16 Hair comb wide 15/32in. (12mm) (MG7730 only)
17 Hair comb wide 21/32in. (16mm) (MG7730 only)
18 Body comb 1/8in. (3mm)
19 Body comb 3/16in. (5mm)
20 Stubble comb 3/64in. (1mm)
21 Stubble comb 5/64in. (2mm)
22 Adjustable comb (3-7mm)
23 Supply unit
24 Small plug
25 Cleaning brush
26 Pouch
English
English
Note: The accessories supplied may vary for
different products. The box shows the accessories
that have been supplied with your appliance.
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the
detachable supply unit (HQ8505) provided
with the appliance.
- The supply unit contains a transformer. Do
not cut off the supply unit to replace it with
another plug, as this causes a hazardous
situation.
7
English
8
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
- Always unplug the appliance before you
clean it under the tap.
- Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never immerse the charging
stand in water and do not rinse
it under the tap.
English
- Never immerse the appliance in
water. Do not use the appliance
in the bath or shower.
- Never use water hotter than
60°C to rinse the appliance.
- Only use this appliance for its
intended purpose as shown in
the user manual.
- For hygienic reasons, the
appliance should only be used
by one person.
- Do not use the supply unit in or
near wall sockets that contain
an electric air freshener to
prevent irreparable damage to
the supply unit.
- Never use compressed air,
scouring pads, abrasive
cleaning agents or aggressive
liquids such as petrol or
acetone to clean the appliance.
9
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
English
10
General
- This appliance can be safely cleaned under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Battery status indications
- When the battery is almost empty, the battery
status indicator flashes orange.
- When the appliance is charging, the battery
status indicator flashes white slowly.
- During quick charge, the battery status indicator
flashes white. After approx. 5 minutes of
charging, the appliance contains enough power
for one cordless trimming session.
- When the battery is fully charged, the battery
status indicator lights up white continuously.
Note: After approx. 30 minutes, the light goes out
automatically.
Charging
Charge the appliance before you use it for the first
time and when the display indicates that the
battery is almost empty. When the appliance has
charged for 1 hours, it has a cordless operating
time of up to 2 hours.
2
1
1
2
1 Make sure the appliance is switched off.
2 Insert the small plug into the appliance and put
the supply unit in the wall socket.
3 After charging, remove the supply unit from the
wall outlet and pull the small plug out of the
appliance.
Quick charge
After approx. 5 minutes charging, the appliance
contains enough power for one cordless trimming
session.
Using the appliance
Note: This appliance can only be used without
cord.
Note: Switch off and clean the appliance after each
use.
Detaching and attaching cutting elements
1 To detach a cutting element, push upwards
against the teeth of the cutting element and
take it off the handle.
2 To attach a cutting element, insert the lug of the
cutting element into the guiding slot at the front
and push the back of the cutting element onto
the appliance ('click').
English
11
1
2
English
12
Detaching the precision shaver and nose trimmer
1 Place your finger on the arrow at the back of
the attachment and push it off the handle in the
direction of the arrow.
Attaching and detaching combs
1 To attach any type of guard onto a cutting
element, slide the front part of the guard onto
the teeth of the cutting element. Then push
down the center of the guard with your fingers
or the palm of your hand ('click').
2 To detach any type of comb from the cutting
element, carefully pull its back part off the
appliance and then slide it off the cutting
element.
Note: When trimming for the first time, start by
using the comb with the maximum trimming
length setting to familiarize yourself with the
appliance.
Switching the appliance on and off
Press the on/off button once to turn the appliance
on or off.
Attachments for use on beard
Full-size hair trimmer
Use the full-size hair trimmer without a comb to
trim hair close to the skin (to a length of 1/32in
= mm
(0.5mm) or to create clean lines around your
beard, neck and sideburns.
1 To trim hair close to the skin, place the flat side
of the cutting element against your skin and
make strokes against the direction of hair
growth.
2 For contouring, hold the cutting element
perpendicular to the skin and move it upwards
or downwards with gentle pressure.
Beard combs
Attach a beard comb to the full-size hair trimmer
to trim your beard and moustache evenly. The
appliance comes with 5 beard combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb inch mm
Stubble comb 3/64in. 1mm
Stubble comb 5/64in. 2mm
Adjustable beard
comb
1/8in.- 9/32in. 3mm-7mm
1 Attach the comb to the full-size hair trimmer.
2 Adjustable comb: Push the length selector to
the left or right to select the desired hair length
setting.
English
13
English
14
3 To trim the most effective way, move the comb
against the direction of hair growth. Make sure
the surface of the comb always stays in contact
with the skin.
Attachments for use on body
- Use the green body combs to trim body hair.
- When you trim for the first time, use the
5mm/3/16in. body comb to familiarize yourself
with the appliance.
- Make sure hair is clean and dry as wet hair
tends to stick to the body.
- When trimming sensitive areas, always use a
body comb.
- Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards, downwards, or
across). Practice is best for optimum results.
- Always make smooth and gentle movements
and be sure the surface of the comb always
stays in contact with your skin.
- When too many hairs have accumulated on the
appliance, blow the hairs out before use, for
best trimming results.
Body combs
Attach a body comb to the full-size hair trimmer to
trim hairs below the neckline. The appliance comes
with 2 body combs. The hair length settings are
indicated on the combs. The settings correspond
to the remaining hair length after trimming.
Comb inch mm
Body comb (green) 1/8in. 3mm
Body comb (green) 3/16in. 5mm
English
1 Attach a body comb to the full-size hair
trimmer.
2 To trim in the most effective way, stretch the
skin with your free hand and move the comb
against the direction of hair growth. Make sure
the surface of the comb always stays in contact
with the skin.
Body shaver
Attach the body shaver to the appliance, to shave
hairs below the neckline such as your armpits and
chest. Only use the body shaver with the skin
protector.
1 Attach the body shaver to the appliance.
2 Attach the skin protector to the full-size hair
trimmer.
3 To shave in the most effective way, stretch the
skin with your free hand and move the shaver
against the direction of hair growth. Make sure
the surface of the shaver always stays in full
contact with the skin.
15
Attachments for use on head
Extra-wide hair trimmer
Use the extra-wide hair trimmer without a comb to
clip the hair on your head very close to the skin
(1/32in (0.5mm) or to contour the neckline and
area around the ears.
1 To contour the hairline around the ears, comb
the hair ends over the ears.
English
16
2 Tilt the appliance in such a way that only one
edge of the cutter blades touches the hair ends
when you shape the contours around the ears.
3 To contour the nape of the neck or sideburns,
turn the appliance and make downward
strokes.
4 Move the appliance slowly and smoothly
following the natural hairline.
Hair combs wide
Attach a wide hair comb to the extra-wide hair
trimmer to evenly trim the hairs on your head. The
appliance comes with 4 wide hair combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb inch mm
Hair comb 5/32in. 4mm
Hair comb 3/8in. 9mm
Hair comb 15/32in. 12mm
Hair comb 21/32in. 16mm
1 Attach a comb to the extra-wide hair trimmer.
2 Move the trimmer slowly over the crown from
different directions to achieve an even result.
Make sure the surface of the comb always stays
in contact with the skin.
-
Always move the trimmer against the
direction of hair growth. Press lightly.
-
Make overlapping passes over the head to
ensure that all hair that should be cut has
been cut.
Full-size hair trimmer
Use the full-size hair trimmer without a comb to
clip the hair on your head very close to the skin
(1/32in (0.5mm) or to contour the neckline and
area around the ears.
1 To contour the hairline around the ears, comb
the hair ends over the ears.
2 Tilt the appliance in such a way that only one
edge of the cutter blades touches the hair ends
when you shape the contours around the ears.
3 To contour the nape of the neck or sideburns,
turn the appliance and make downward
strokes.
4 Move the appliance slowly and smoothly
following the natural hairline.
Hair combs regular
Attach a regular hair comb to the full size hair
trimmer to evenly trim the hairs on your head. The
appliance comes with 3 hair combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb inch mm
Hair comb 3/8in. 9mm
Hair comb 15/32in. 12mm
Hair comb 21/32in. 16mm
1 Attach a comb to the full size hair trimmer.
English
17
English
18
2 Move the trimmer slowly over the crown from
different directions to achieve an even result.
Make sure the surface of the comb always stays
in contact with the skin.
-
Always move the trimmer against the
direction of hair growth. Press lightly.
-
Make overlapping passes over the head to
ensure that all hair that should be cut has
been cut.
Precision attachments for use on face
Precision trimmer
Use the precision trimmer to create fine lines and
contours around your facial style, close to the skin
(to a length of 1/32in./0.5mm).
1 Hold the precision trimming head perpendicular
to the skin and move the trimming head
upwards or downwards with gentle pressure.
Nose trimmer
Use the nose trimmer to trim your nose hair and
ear hair.
- Make sure nasal passages are clean. Make sure
outer ear channels are clean and free from wax.
- Do not insert the tip more than 3/16in./5mm.
- Always clean the attachment after each use.
Trimming nose hair
1 Gently move the tip in and out of nose while
turning it around to remove unwanted hairs.
Trimming ear hair
1 Slowly move the tip round the ear to remove
hairs that stick out beyond the rim of the ear.
2 Gently move the tip in and out of the outer ear
channel to remove unwanted hairs.
Precision shaver
Use the precision shaver after trimming, to shave
unwanted hairs on cheeks, chin and along the
beard with precision. Make sure to pre-trim your
beard first, with the full-size hair trimmer without
comb, to obtain the best result.
Note: Use the precision shaver to remove
remaining hairs and detailing your beard style. It is
not suitable for a full face shave.
1 Gently press the precision shaver onto the skin
and shave along contoured edges to remove
any unwanted hairs.
Cleaning
Never use scouring pads, abrasive cleaning
agents or aggressive liquids such as gasoline or
acetone to clean the product.
Never dry the trimmer teeth with a towel or
tissue, as this may damage the trimmer teeth.
After every use: cleaning under the tap
1 Turn off the appliance and disconnect from the
wall socket.
2 Remove any comb or cutting element from the
appliance.
3 Rinse the hair chamber under a warm tap.
English
19
English
20
4 Clean the cutting element and comb under a
warm tap.
5 Carefully shake off excess water and let all parts
air dry completely.
Thorough cleaning
1 Turn off the appliance and disconnect from the
wall socket.
2 Wipe the handle of the appliance with a dry
cloth.
3 Remove any comb or cutting element from the
appliance.
4 Remove any hairs that have accumulated in the
hair chamber with the cleaning brush supplied.
5 Remove any hairs that have accumulated in the
cutting elements and/or combs with the
cleaning brush supplied.
6 Clean the cutting elements under a warm tap.
7 Clean the combs under a warm tap.
8 Carefully shake off excess water and let all parts
air dry completely.
Cleaning the nose trimmer
Clean the nose trimmer immediately after use and
when a lot of hair or dirt has accumulated on the
nose trimmer head.
1 Rinse the nose trimmer head with hot water.
2 Turn on the appliance and rinse the nose
trimmer head once more to remove any
remaining hairs. Then turn off the appliance
again.
For a thorough clean, immerse the nose trimmer
head in a bowl with warm water for a few minutes
and then turn on the appliance to remove
stubborn hair/debris.
3 Carefully shake off excess water and let all parts
air dry completely.
Cleaning the precision shaver
1 Hold the precision shaver at the grooves on
each side and pull the top part off the bottom
part.
2 Blow and/or shake out any hair that has
accumulated inside the precision shaver.
Do not use the cleaning brush to remove hairs
from the shaving foil.
3 Clean the top part of the precision shaver under
a warm tap.
4 Carefully shake off excess water and let all parts
air dry completely.
5 Reattach the top part onto the bottom part of
the precision shaver.
Cleaning the body shaver
1 Remove the skin protector upwards off the
shaver.
English
21
English
22
2 Clean the skin protector and body shaver under
a warm tap.
Do not use the cleaning brush to remove hairs
from the shaver or skin protector.
3 Carefully shake off excess water and let both
parts air dry completely.
4 Reattach the skin protector onto the body
shaver.
Storage
- Store the appliance in the pouch supplied.
Note: Make sure the appliance is dry before you
store it in the pouch.
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).
Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
- This symbol means that this product contains a
built-in rechargeable battery which shall not be
disposed of with normal household waste
(2006/66/EC). Please take your product to an
official collection point or a Philips service
center to have a professional remove the
rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product. Before you remove
the battery, make sure that the product is
disconnected from the wall socket and that
the battery is completely empty.
Take any necessary safety precautions
when you handle tools to open the product
and when you dispose of the rechargeable
battery.
1 Check if there are screws in the back or front of
the appliance. If so, remove them.
2 Remove the back and/or front panel of the
appliance with a screwdriver. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3 Remove the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Warranty restrictions
Cutting units are not covered by the terms of the
international warranty because they are subject to
wear.
English
23
Dansk
24
Introduktion
Tillykke med dit køb, og velkommen til Philips! For
at få fuldt udbytte af den support, Philips tilbyder,
skal du registrere dit produkt på
www.philips.com/welcome.
Generel beskrivelse (fig. 1)
1 Hårtrimmer i fuld størrelse
2 On/off-knap
3 Batteristatusindikator
4 Lille strømstik
5 Bodyshaver (kun MG7730, MG7720, MG7715)
6 Hudbeskytter (kun MG7730, MG7720, MG7715)
7 Præcisionstrimmer (kun MG7730, MG7720,
MG7715, MG7710)
8 Præcisionsshaver (kun MG7730, MG7720,
MG7710)
9 Næsehårstrimmer
10 Ekstra bred hårtrimmer (kun MG7730)
11 Hårkam, almindelig 9 mm (3/8") (kun MG7720,
MG7715, MG7710)
12 Hårkam, almindelig 12 mm (15/32") (kun
MG7720, MG7715, MG7710)
13 Hårkam, almindelig 16 mm (21/32") (kun
MG7720, MG7715, MG7710)
14 Hårkam, almindelig 4 mm (5/32") (kun MG7730)
15 Hårkam, bred 9 mm (3/8") (kun MG7730)
16 Hårkam, bred 12 mm (15/32") (kun MG7730)
17 Hårkam, bred 16 mm (21/32") (kun MG7730)
18 Kropskam 3 mm (1/8")
19 Kropskam 5 mm (3/16")
20 Stubbekam 1 mm (3/64")
21 Stubbekam 2 mm (5/64")
22 Justerbar kam (3-7 mm)
23 Oplader
24 Lille stik
25 Rensebørste
26 Etui
Dansk
Dansk
Bemærk: Det medfølgende tilbehør kan variere for
forskellige produkter. Boksen viser det tilbehør, der
leveres sammen med apparatet.
Vigtige sikkerhedsoplysninger
Læs disse vigtige oplysninger omhyggeligt
igennem, inden apparatet og tilbehøret tages i
brug, og gem dem til eventuel senere brug. Det
medfølgende tilbehør kan variere for forskellige
produkter.
Fare
- Hold forsyningsenheden tør.
Advarsel
- Brug kun den aftagelige forsyningsenhed
(HQ8505), der fulgte med apparatet, til at
oplade batteriet.
- Strømforsyningsenheden indeholder en
transformator. Klip ikke
strømforsyningsenheden af og udskift den
med et andet stik, da dette vil føre til farlige
situationer.
25
Dansk
26
- Dette apparat må bruges af børn fra 8 år og
opefter og personer med reducerede
fysiske, sensoriske eller mentale evner eller
manglende erfaring og viden, hvis de er
blevet instrueret i sikker brug af apparatet
og forstår de medfølgende risici. Lad ikke
børn lege med apparatet. Rengøring og
vedligeholdelse må ikke foretages af børn
uden opsyn.
- Tag altid stikket ud af apparatet, inden det
skylles under vandhanen.
- Kontroller altid apparatet, indendu
anvender det. Anvend ikke apparatet, hvis
det er beskadiget, da dette kan forårsage
personskade. Udskift altid en beskadiget del
med en tilsvarende original type.
- Apparatet må ikke åbnes i forbindelse med
udskiftning af det genopladelige batteri.
Forsigtig
- Opladeren må aldrig kommes
ned i vand eller skylles under
vandhanen.
- Apparatet må aldrig kommes
ned i vand. Brug ikke apparatet
i kar- eller brusebad.
Dansk
- Rens aldrig apparatet med
vand, der er varmere end 60°C.
- Brug kun apparatet til det
tilsigtede formål som vist i
brugervejledningen.
- Af hygiejniske grunde bør
apparatet kun anvendes af en
og samme person.
- Brug ikke
strømforsyningsenheden i eller i
nærheden af stikkontakter, som
indeholder en elektrisk
luftfrisker, for at forhindre
uoprettelig beskadigelse af
strømforsyningsenheden.
- Brug aldrig trykluft,
skuresvampe eller skrappe
rengøringsmidler, som f.eks.
benzin, acetone eller lignende,
til rengøring af apparatet.
27
Elektromagnetiske felter (EMF)
Dette Philips-apparat overholder alle branchens
gældende standarder og regler angående
eksponering for elektromagnetiske felter.
Dansk
28
Generelt
- Dette apparat kan skylles under rindende vand
uden risiko.
- Forsyningsenheden er egnet til netspændinger
fra 100 til 240 volt.
- Strømforsyningsenheden omformer 100-240
Volt til en lav sikkerhedsspænding under 24
Volt.
Opladning
Batteristatusindikatorer
- Når batteriet næsten er tomt, blinker
batteristatusindikatoren orange.
- Når apparatet oplades, blinker
batteristatusindikatoren langsomt hvidt.
- Under lynopladning blinker
batteristatusindikatoren hvidt. Efter ca. 5
minutters opladning er apparatet tilstrækkeligt
opladet til en trimning uden ledning.
- Når batteriet er fuldt opladet, lyser
batteristatusindikatoren konstant hvidt.
Bemærk: Lyset slukker automatisk efter ca. 30
minutter.
Opladning
Oplad apparatet, før du bruger det første gang, og
når displayet viser, at batteriet næsten er tomt. Når
apparatet har ladet op i 1 time, kan det bruges
uden ledning i op til 2 timer.
2
1
1
2
1 Kontroller, at apparatet er slukket.
2 Sæt det lille stik i apparatet, og sæt opladeren i
stikkontakten.
3 Efter opladning skal du tage opladeren ud af
stikkontakten og det lille stik ud af apparatet.
Lynopladning
Efter ca. 5 minutters opladning er apparatet
tilstrækkeligt opladet til en trimning uden ledning.
Sådan bruges apparatet
Bemærk: Dette apparat kan kun bruges uden
ledning.
Bemærk: Sluk og rengør apparatet efter hver brug.
Aftagning og påsætning af skæreenheder
1 For at tage en skæreenhed af skal du skubbe
opad mod skæreenhedens tænder og fjerne
den fra grebet.
2 For at sætte en skæreenhed på skal du placere
den lille tap på skærenheden i hullet forrest på
apparatet og trykke bagsiden af skærenheden
fast ("klik").
Dansk
29
1
2
Dansk
30
Aftagning af præcisionsshaveren og næsehårstrimmeren
1 Placer din finger på pilen bagpå tilbehøret, og
skub det af grebet i pilens retning.
Påsætning og aftagning af kamme
1 For at sætte en hvilken som helst beskyttende
enhed på skæreenheden skal du sætte den
forreste del af den beskyttende enhed på
skæreenhedens tænder. Tryk derefter ned midt
på den beskyttende enhed med fingrene eller
håndfladen ("klik").
2 For at tage en hvilken som helst kam af
skæreenheden skal du forsigtigt trække
kammens bagerste del af apparatet og derefter
tage den af skæreenheden.
Bemærk: Hvis det er første gang, du bruger
trimmeren, anbefales det at bruge kammen
med den højeste længdeindstilling, indtil du
vænner dig til at bruge apparatet.
Sådan tændes og slukkes apparatet
Tryk på on/off-knappen én gang for at tænde eller
slukke apparatet.
Tilbehør til skæg
Hårtrimmer i fuld størrelse
Brug hårtrimmeren i fuld størrelse uden kam, hvis
du vil klippe håret meget kort (0,5 mm) eller rette
Loading...
