Philips MCD700-37B User Manual
DVD Micro Theatre
702
Canada
English:
This digital apparatus does not exceed
the Class B limits for radio noise
emissions from digital apparatus as set
out in the Radio Interference
Regulations of the Canadian
Department of Communications.
Français:
Cet appareil numérique n'emet pas
de bruits radioélectriques dépassant
les limites applicables aux appareils
numériques de Class B prescrites dans
le Règlement sur le Brouillage
Radioélectrique édicté par le Ministère
des Communications du Canada.
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
ATTENTION
L'utilisation des commandes ou
réglages ou le non-respect des
procédures ci-incluses peuvent se
traduire par une exposition
dangereuse à l'irradiation.
ATENCIÓN
El uso de mando o ajustes o la
ejecucción de métodos que no sean
los aquí descritos puede ocasionar
peligro de exposición a radiación.
2
Return your Product Registration Card today
to get the very most from your purchase.
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so
don't miss out. Complete and return your Product Registration Card at once to ensure:
*Proof of
Purchase
Returning the enclosed card
guarantees that your date of
purchase will be on file, so no
additional paperwork will be
required from you to obtain war-
ranty service.
*Product Safety
Notification
By registering your product, you'll
receive notification - directly
from the manufacturer - in the
rare case of a product recall or
safety defect.
Know these
safety
CAUTION
RISK OF ELECTRIC SHOCK
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This “bolt of lightning” indicates
t
shock. For the safety of everyone in
your household, please do not remove
product covering.
uninsulated material within your
unit may cause an electrical
symbols
DO NOT OPEN
*Additional
Benefits of
Product
Ownership
Registering your product guaran-
tees that you'll receive all of the
privileges to which you're enti-
tled, including special money-sav-
ing offers.
For Customer Use
Enter below the Serial No. which is
located on the rear of the cabinet.
Retain this information for future reference.
Model No. ______________________
Serial No. ______________________
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
The “exclamation point” calls
s
literature closely to prevent operating
and maintenance problems.
attention to features for which
you should read the enclosed
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot,
fully insert.
3
Visit our World Wide Web Site at http://www.usasupport.philips.com
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS. You’ve selected one of
the best-built, best-backed products available today. We’ll do everything in our power to keep you happy with your purchase for many
years to come.
As a member of the PHILIPS “family,” you’re entitled to protection
by one of the most comprehensive warranties and outstanding service networks in the industry. What’s more, your purchase guarantees you’ll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient
home shopping network.
Most importantly, you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome - and thanks for investing in
a PHILIPS product.
P.S. To get the most from your PHILIPS purchase, be
sure to complete and return your Product Registration
Card at once.
4
IMPORTANT SAFETY INSTRUCTIONS
Clean only with dry cloth.
materials
Class II equipment symbol
This symbol indicates that the unit has
a double insulation system
5
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro-logic” and the double-D symbol are trade-
marks of dolby Laboratories.
MANUFACTURED UNDER LICENSE FROM DIGITAL
THEATER SYSTEMS, INC. US PAT. NO 5,451,942,
5,956,674, 5,974,380, 5,978,762 AND OTHER WORLD-
WIDE PATENTS ISSUED AND PENDING. “DTS” AND “DTS
DIGITAL SURROUND” ARE RESISTERED TRADEMARKS
OF DIGITAL THEATER SYSTEMS, INC. COPYRIGHT 1996,
2000 DIGITAL THEATER SYSTEMS, INC. ALL RIGHTS
RESERVED.
This product incorporates copyright protection technology
that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by
Macrovision Corporation. Reserve engineering or disassem-
bly is prohibited.
6
Index
English ------------------------------------------------ 4
Français -------------------------------------------- 42
Español --------------------------------------------- 78
English
Français
Español
7
Contents
English
General Information
Features ................................................................ 10
Supplied accessories .......................................... 10
Environment information ................................. 10
Installation ............................................................ 10
Maintenance ........................................................ 10
Connections
Connecting the speakers .................................. 11
Connecting antennas ......................................... 12
Connecting the control cable.......................... 12
Connecting a TV ................................................. 12
Connecting the power cord ............................ 12
Connecting additional equipment .................. 13
Functional Overview
DVD player and power amplifier ............. 14~15
Remote control ........................................... 15~16
Getting Started
Step 1: Inserting batteries into the Remote
Control ................................................................. 17
Using the Remote Control to operate the
Player
Step 2: Setting up the TV .................................. 17
Setting up Progressive Scan feature
To deactivate Progressive manually
Step 3: Setting language preference ................ 19
Setting the OSD Language
Setting the Audio, Subtitle and Disc Menu
language
Basic Functions
Switching on/off the system ............................. 20
Volume control ................................................... 20
Sound Control .................................................... 20
DBB (Dynamic Bass Boost)
DSC (Digital Sound Control)
LOUDNESS
Dimming the display screen ............................. 20
Disc Operations
Playable Discs ...................................................... 21
Playing discs ......................................................... 21
Using the Disc Menu .................................. 21~22
Basic playback controls .............................. 22~23
Pausing playback (DVD/VCD/CD/MP3/WMA)
Selecting a track/chapter/title (DVD/VCD/
CD/MP3/WMA)
Resuming playback from the last stopped
point (DVD/VCD/CD/MP3/WMA)
Zoom (DVD/VCD/JPEG)
Repeat (DVD/VCD/CD/MP3/WMA)
Repeat A-B (DVD/VCD/CD/MP3/WMA)
Slow Motion (DVD/VCD)
Program (not for Picture CD)
Forward/Reverse Searching (DVD/VCD/CD/
MP3/WMA)
Time search & search by chapter/track
number (DVD/VCD/CD/MP3/WMA)
Information display during playback (not for
Picture CD)
Special disc features .................................... 23~24
Playing a Title (DVD)
Camera Angle (DVD)
Changing the Audio Language (for DVD
recorded with multiple languages)
Changing the Audio Channel (for VCD only)
Subtitles (DVD)
Playing MP3/WMA/JPEG Picture disc ............ 24
Playing MP3/WMA disc ..................................... 24
General operation
Playback selection
Playing JPEG Picture CD............................ 24~25
General operation
Playback selection
Special JPEG features ......................................... 25
Preview function (JPEG)
Zoom picture (JPEG)
Slide show playback modes (JPEG)
Playback with multi-angles (JPEG)
8
System Menu Options
Basic Operations ................................................ 26
General Setup Page ..................................... 26~27
TV Display
Closed Captions
Screen Saver
Audio Setup Page ........................................ 27~28
SPDIF Setup
Dolby Digital Setup
3D Processing
HDCD
D.R.C
Video Setup Page......................................... 28~29
Component
TV Mode
Quality
Preference Page ........................................... 29~30
Parental
Default
Password Setup Page ......................................... 30
Password mode
Password
Other Functions
Radio reception .................................................. 31
Tuning to radio stations
Presetting radio stations
Listening to preset radio stations
Setting the clock ................................................. 31
Setting sleep/wake-up timer ............................ 32
Sleep timer setting
Wake-up timer setting
Contents
English
Specifications ........................................... 33
Tr oubleshooting ............................. 34~36
Glossary ......................................................... 37
9
General Information
Speaker
(Right)
Speaker
(Left)
DVD Player
Power Amplifier
Stand
English
Features
Built-in DTS and DolbyR Digital decoder, 2.0channel amplifier
Additional Component Connections
Lets you connect other audio and audio/visual
components to the DVD micro system.
Night Mode
Lets you compress the dynamic range, reducing
the difference in loudness between different
sounds in Dolby Digital mode.
Parental Control (Rating Level)
Lets you set a ratings level so that your children
cannot watch a DVD that has a rating higher
than you set.
Sleep/Wake-up Timer
Enables the system to switch on/off automatically
at a preset time.
Supplied accessories
– Remote control with two AAA batteries
– AM antenna
– FM wire antenna
–2 loudspeaker boxes including 2 speaker
cables
– Composite video cable (yellow)
– Control cable
– Stand
If any item is damaged or missing, contact
your retailer or Philips.
Environmental information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Installation
● Place the player on a flat, hard, and stable surface.
● In a cabinet, allow about 10cm (4 inches) of free
space all around the player for adequate
ventilation.
● Do not expose your player to extreme
temperatures or humidity.
● The apparatus shall not be exposed to dripping
or splashing and that no objects filled with liquid
such as vase shall be placed on the apparatus.
● No naked flame sources, such as lighted candles,
shall be placed on the apparatus.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
Maintenance
● When a disc becomes dir ty, clean it with a
cleaning cloth. Wipe the disc
from the center out, in a
straight line.
● Do not expose the player,
batteries or discs to humidity,
rain, sand or excessive heat
(caused by heating equipment
or direct sunlight). Always keep the disc tray
closed to avoid dust on the lens.
● Do not use solvents such as benzene, thinner,
commercially available cleaners, or anti-static
spray intended for colour discs.
● The lens may cloud over when the player is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the player in the warm environment until
the moisture evaporates.
10
1
2
Connections
2
Speaker
(right)
AC power cord
IMPORTANT!
– The type plate is located at the
bottom of the system.
– Before connecting the AC power
cord to the wall outlet, ensure that all
other connections have been made.
–Never make or change any
connections with the power switched
on.
FM
antenna
AM antenna
1
For MCD700
Speaker
English
(left)
Connecting the speakers
Connect the speakers to the SPEAKERS (8Ω)
terminals with two speaker cables. Right
speaker to “R” and left speaker to “L”, red wire
to “+” and silver wire to “-”. Fully insert the
stripped portion of the speaker wire into the
terminal as shown.
For MCD702
Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
–For optimal sound performance, use the supplied
speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker jacks.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
11
Connections
English
Connecting antennas
Connect the supplied AM antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AM Indoor Antenna
1
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
FM Indoor Antenna
● For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
Connecting the control cable
Connect the serial port marked “CONTROL
CABLE” at the rear of the DVD player to the
same port at the rear of the power amplifier
with the supplied flat control cable.
2
IMPORTANT!
– There are various ways to connect the
system to a TV. You only need to make
one of the best connections, depending
on the capabilities of your TV system.
– If COMPOMENT video output jacks
or S-Video jack is used for video
connection, the system’s Component
setting will need to be set accordingly.
Details are shown under “Video Setup
Page”.
● Connect the VIDEO OUTPUT jack to the
video input jack on the TV using a video cable
(yellow).
OR
Option 1
Connect the S-VIDEO output jack to the SVideo input jack on the TV using an S-Video
cable (not supplied).
OR
Option 2
Use the component video cables (red/blue/
green) to connect the DVD micro system’s
COMPONENT video output jacks to the
corresponding component video input jacks (or
labeled as Pr/Cr Pb/Cb Y or YUV) on the TV.
IMPORTANT!
– The progressive scan video quality is
only possible when using Y Pb Pr and a
progressive scan TV is required. (Proceed
to page 17-18 for detailed Progressive
Scan setup.)
Connecting a TV
You must connect a TV to your DVD micro
system in order to view the DVD/VCD playback.
12
Option 1
Option 2
Note:
–To avoid magnetic interference, do not position
the front speakers too close to your TV.
Loading...
