Always there to help you
Question?
Contact
Philips
Register your product and get support at
www.philips.com/welcome
MCD135
User manual
Contents
Listen through headphone 15
Turn on/off automatically 15
1 Safety 2
Know these safety symbols 2
Important safety instructions 2
Hearing safety 3
2 Your DVD micro system 4
Feature introduction 4
What's in the box 4
Overview of the main unit 5
3 Before use 7
Place the player 7
Install/replace the battery of remote
control 7
4 Connect 8
Connect speakers 8
Connect TV 8
Connect a USB storage device 9
Connect power 9
5 Get started 10
Turn on 10
Set the clock 10
Find the correct video input channel 10
Select the correct TV system 10
Select a language for on-screen display 10
8 Setup 17
Interface for setup menu 17
Change a setting 17
System setup 17
Language setup 18
Audio setup 18
Video setup 18
9 Product information 19
Specications 19
Supported disc formats 20
USB playability information 20
10 Troubleshooting 21
11 Notice 23
Compliance 23
Care of the environment 23
Trademark notice 24
Copyright notice 24
6 Play 11
Basic operation 11
Play a disc 11
Play recored les 11
Control the play 13
Search by time or title/chapter/track
number 14
Adjust sound 14
7 Other features 15
Listen to FM radio 15
Play audio from an external device 15
1EN
1 Safety
Important safety instructions
Read and understand all instructions before
you use this micro music system. If damage is
caused by failure to follow the instructions, the
warranty does not apply.
Caution
Use of controls or adjustments or performance of
•
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Know these safety symbols
This 'bolt of lightning' indicates uninsulated
material within your unit may cause an electric
shock. For the safety of everyone in your
household, please do not remove product
covering.
The 'exclamation mark' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, fully
insert the plug. (For regions with polarized
plugs: To prevent electric shock, match wide
blade to wide slot.)
Risk of electric shock or re!
• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact the Consumer Care
to have the product checked before use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Risk of short circuit or re!
• Before you connect the product to the
power outlet, make sure that the power
voltage matches the value printed on the
back of the product. Never connect the
product to the power outlet if the voltage
is different.
• Never expose the remote control or
batteries to rain, water, sunshine, or
excessive heat.
• Avoid force coming onto power plugs.
Loose power plugs can cause arcing or re.
Risk of injury or damage to the product!
• Use only power supplies listed in the user
manual.
• Visible and invisible laser radiation when
open. Avoid exposure to beam.
• Do not touch the disc optical lens inside
the disc compartment.
• Never place the product or any objects
on power cords or on other electrical
equipment.
2 EN
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
Risk of overheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
• Make sure that curtains or other objects
never cover the ventilation slots on the
product.
Risk of contamination!
• Remove the battery if it is exhausted or if
the remote control is not to be used for
an extended period of time.
• Batteries contain chemical substances, they
should be disposed of properly.
Warning
•
Never remove the casing of this apparatus.
• Never lubricate any part of this apparatus.
• Never place this apparatus on other electrical
equipment.
• Keep this apparatus away from direct sunlight, naked
ames or heat.
• Never look into the laser beam inside this apparatus.
• Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect this apparatus from
the power.
Hearing safety
that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your
hearing 'comfort level' adapts to higher
volumes of sound. So after prolonged
listening, what sounds 'normal' can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even
at normally 'safe' levels, can also cause
hearing loss.
• Be sure to use your equipment reasonably
and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume as your
hearing adapts.
• Do not turn up the volume so high that
you can't hear what's around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations.
Note
The type plate is located on the back of the product.
•
Listen at a moderate volume.
• Using headphones at a high volume can
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute. The
higher decibel ranges are offered for those
3EN
2 Your DVD
micro system
Region Code
You can play DVD discs marked with the
following region code.
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
If you contact the Consumer Care, you will
be asked for the model and serial number of
this apparatus. The model number and serial
number are on the rear of the apparatus. Write
the numbers here:
Model No. __________________________
Serial No. ___________________________
Feature introduction
This player can
• play videos, audios, and display pictures
from discs and USB storage devices
• play audios from iPod/iPhone
For the details of supported media, refer to
"Specications".
DVD region
code
Countries
Russia, Ukraine, India
Sound effect
This player supports the sound output by DSC
(Digital Sound Effect) and DBB (Dynamic Bass
Boost).
What's in the box
Check and identify the contents of your
package:
• Main unit
• 2 speakers
• Remote control
• Audio and video cables (white, red and
yellow connectors)
• USB cable (100 mm)
• MP3 link cable (3.5 mm plug)
• Power cord
• User manual
• Quick start guide
To fully enjoy the features, you need the
following cables.
• Component video cables
Contact local retailers to purchase these
additional cables.
4 EN
Overview of the main unit
o
n
m
l
k
j
i
h
a
• Eject or close the disc compartment.
b IR sensor
c VFD display
d Disc compartment
e VOLUME
• Increase/decrease the volume level.
f Pull to open
g
• Connect a USB storage device.
h MP3 LINK
• Connect an MP3 link cable (3.5 mm
plug).
a
b
c
d
e
f
g
i
• Socket for headphones.
j
• Start, pause or resume the play.
k
/
• Skip to the previous or next title,
chapter, track, or le.
• Search fast backward or forward.
l
• Stop the play.
m SOURCE
• Select a media source (disc, USB storage
device, FM tuner, or external device
connected through MP3 link cable).
5EN
n DBB
• Enable or disable the DBB (Dynamic
Bass Boost) feature.
o
• Turn on or off the unit.
• Switch to standby mode.
6 EN
3 Before use
Install/replace the battery of
remote control
Place the player
Note
Place this player on a at, hard, and stable surface.
•
• Never place this player in an enclosed cabinet, nor on
any other electrical equipment.
• Keep this player away from direct sunlight, naked ames,
or heat.
• Do not block any ventilation openings.
• Apparatus shall not be exposed to dripping or
splashing.
• Do not place any sources of danger on the player (for
example, liquid lled objects, lighted candles).
• Install this player near the AC outlet where the AC
power plug can be easily reached.
• To avoid magnetic interference or unwanted noise,
never place the main unit and speakers too close to
any radiation devices.
Note
Risk of explosion! Keep batteries away from heat,
•
sunshine or re. Never discard batteries in re.
• Remove the battery if the remote control is not to be
used for an extended period of time.
1
1 Pull out the battery tray.
2 Insert one lithium CR2025 battery with
correct polarity (+/-) as indicated.
3 Push and close the battery tray.
2
3
1 Place the player near to the TV.
2 Place the left and right speakers at equal
distance from the TV and at an angle
of approximately 45 degrees from the
listening position.
7EN
