Micro Hi-Fi System
MC145
Thank you for choosing Philips.
Need help fast?
Read your Quick Use Guide and/or
Owner's Manual first for quick tips
that make using your Philips product
more enjoyable.
If you have read your instructions
and still need assistance,
you may access our online help at
www.philips.com/support
1-888-PHILIPS (744-5477)
(and Model / Serial number)
or call
while with your product.
Philips vous remercie de
votre confiance.
Besoin d'une aide
rapide?
Les Guide d'utilisation rapide et Manuel de
l'utilisateur regorgent d'astuces destinées à
simplifier l'utilisation de votre produit Philips.
Toutefois, si vous ne parvenez pas à résoudre
votre probléme, vous pouvez accéder à
notre aide en ligne à l'adresse
www.philips.com/support
ou formez le
1-800-661-6162 (Francophone)
1-888-PHILIPS (744-5477) (English speaking)
Veillez à avoir votre produit à
portée de main.
(et model / serial nombre)
Gracias por escoger Philips
Necesita ayuda
inmediata?
Lea primero la Guía de uso rápido o el
Manual del usuario, en donde encontrará
consejos que le ayudarán a disfrutar
plenamente de su producto Philips.
Si después de leerlo aún necesita ayuda,
consulte nuestro servicio de
asistencia en línea en
www.philips.com/support
o llame al teléfono
1-888-PHILIPS (744-5477)
y tenga a mano el producto.
(y número de model / serial)
Canada
English:
This digital apparatus does not
exceed the Class B limits for radio
noise emissions from digital apparatus
as set out in the Radio Interference
Regulations of the Canadian
Department of Communications.
Français:
Cet appareil numérique n'emet pas
de bruits radioélectriques dépassant
les limites applicables aux appareils
numériques de Class B prescrites
dans le Règlement sur le Brouillage
Radioélectrique édicté par le
Ministère des Communications du
Canada.
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
ATTENTION
L'utilisation des commandes ou
réglages ou le non-respect des
procédures ci-incluses peuvent se
traduire par une exposition
dangereuse à l'irradiation.
ATENCIÓN
El uso de mando o ajustes o la
ejecucción de métodos que no sean
los aquí descritos puede ocasionar
peligro de exposición a radiación.
2
1
2
3
4
5
6
7
&
4
7
0
8
6
!
9
*
3
0
(
5
$
#
9
0
!
@
#
$
%
8
^
3
3
Return your Product Registration Card today
to get the very most from your purchase.
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so
don't miss out. Complete and return your Product Registration Card at once to ensure:
*Proof of
Purchase
Returning the enclosed card
guarantees that your date of
purchase will be on file, so no
additional paperwork will be
required from you to obtain war-
ranty service.
*Product Safety
Notification
By registering your product, you'll
receive notification - directly
from the manufacturer - in the
rare case of a product recall or
safety defect.
Know these
safety
CAUTION
RISK OF ELECTRIC SHOCK
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This “bolt of lightning” indicates
t
shock. For the safety of everyone in
your household, please do not remove
product covering.
uninsulated material within your
unit may cause an electrical
symbols
DO NOT OPEN
*Additional
Benefits of
Product
Ownership
Registering your product guaran-
tees that you'll receive all of the
privileges to which you're enti-
tled, including special money-sav-
ing offers.
For Customer Use
Enter below the Serial No. which is
located on the rear of the cabinet.
Retain this information for future reference.
Model No. ______________________
Serial No. ______________________
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
The “exclamation point” calls
s
literature closely to prevent operating
and maintenance problems.
4
attention to features for which
you should read the enclosed
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot,
fully insert.
Visit our World Wide Web Site at http://www.usasupport.philips.com
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS. You’ve selected one of
the best-built, best-backed products available today. We’ll do everything in our power to keep you happy with your purchase for many
years to come.
As a member of the PHILIPS “family,” you’re entitled to protection
by one of the most comprehensive warranties and outstanding service networks in the industry. What’s more, your purchase guarantees you’ll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient
home shopping network.
Most importantly, you can count on our uncompromising commitment to your total satisfaction.
All of this is our way of saying welcome - and thanks for investing in
a PHILIPS product.
P.S. To get the most from your PHILIPS purchase, be
sure to complete and return your Product Registration
Card at once.
5
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near
water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer's instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the
safety purpose of the
polarized or groundingtype plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not
fit into your outlet, consult and electrician
for replacement of the obsolete outlet.
10.
Protect the power cord from being
walked on or pinched, par ticularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11.
Only use attachments/ accessories
specified by the manufacturer.
AC Polarized
Plug
12.
13.
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14.
Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid hs been spilled or objects have fallen
into the apprartus, the apparatus has been
exposed to rain or moisture, does not
operate normaly, or has been dropped.
15.
Bettery usage
prevent battery leakage which may result in
bodily injury, property damage, or damage to
the unit:
● Install all batteries correctly, + and – as
marked on the unit.
● Do not mix batteries (old and new or
carbon and alkaline, etc.).
● Remove batteries when the unit is not used
for a long time.
16.
Apparatus shall not be exposed to
dripping or splashing.
17.
Do not place any sources of danger on
the apparatus. (e.g. liquid filled objects,
lighted candles).
18.
This product may contain lead and mercury.
Disposal of these material may be regulated
due to environment considerations.
For disposal or recycling information,
please contact your local authorities
or the Electronic Industries Alliance:
www.eiae.org.
Use only with the cart, stand,
tripod, bracket, or table specified by
the manufacturer or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
CAUTION
– To
EL 6475-E004: 03/12
6
Index
English ------------------------------------------------ 8
Français -------------------------------------------- 24
Español --------------------------------------------- 43
English
Français
Español
7
Contents
English
General Information
Environmental information ................................ 9
Supplied accessories ............................................ 9
Safety information ................................................ 9
Preparation
Rear connections ............................................... 10
Before using the remote control .................... 11
Replacing battery (lithium CR2032)
into the remote control ................................... 11
Controls
Controls on the system and remote
control .................................................................. 12
Basic Functions
Switching the system on ................................... 13
Power-saving automatic standby ..................... 13
Adjusting volume and sound............................ 13
CD Operation
Playing a disc ........................................................ 14
Selecting a different track ................................. 14
Finding a passage within a track ...................... 14
Different play modes: Shuffle and Repeat ..... 15
Programming track numbers ........................... 15
Erasing the programme ..................................... 15
Maintenance.............................................. 18
Clock/Timer
Setting the clock ................................................. 19
Setting the timer ................................................. 19
Activating and deactivating TIMER ................. 19
Activating and deactivating SLEEP .................. 20
Specifications ........................................... 20
Troubleshooting .............................. 21-22
Radio Reception
Tuning to radio stations .................................... 16
Programming radio stations ............................. 16
Tuning to preset radio stations ....................... 16
Ta pe Operation/Recording
Ta pe playback ...................................................... 17
General information on recording ................. 17
Synchro start CD recording ...................... 17-18
Recording from the radio................................. 18
8
The making of unauthorized copies of
copy-protected material, including
computer programmes, files, broadcasts
and sound recordings, may be an
infringement of copyrights and constitute
a criminal offence. This equipment should
not be used for such purposes.
General Information
This system complies with the FCC rules,
Part 15 and with 21 CFR 1040. 10.
Operation is subject to the following two
conditions:
– This device may not cause harmful
interference, and
– this device must accept any interference
received, including interference that may
cause undesired operation.
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Supplied accessories
–2 speaker boxes
– remote control with batter y
Safety Information
● Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
● The mechanical parts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
9
Preparations
English
FM antenna
Speaker
(right)
FM ANT
Rear connections
The type plate is located at the back of the
system.
A Pow er
– Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
Speaker
(left)
110V
220V
AC ~
AC power cord
B Speakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-".
WARNING!
–For optimal performance, use only the
original power cable.
–Never make or change any connections
with the power switched on.
10
● Fully insert the stripped portion of the speaker
wire into the terminal as shown.
Notes:
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Before using the remote control
1 Pull out the plastic protective sheet.
2 Select the source you wish to control by
pressing one of the source select keys on the
remote control (for example CD, TUNER).
3 Then select the desired function (for example
í,
ë).
É,
Replacing battery (lithium
CR2032) into the remote control
1 Pull out the knob A slightly to the right.
2 Pull out the battery compartment B .
3 Replace a new battery and fully insert the
battery compar tment back to the original
position.
Preparations
English
A
B
CAUTION!
Batteries contain chemical substances, so
they should be disposed off properly.
11
Controls (illustrations on page 3)
English
Controls on the system and
remote control
1 LCD Display
– shows the status of the system.
2 iR SENSOR
– infrared sensor for remote control.
3 PROG
for CD .................programs tracks and reviews the
for Tuner ............. programs tuner stations manually
program.
or automatically.
4 POWER / y
– switches the system to standby/on.
5 PLAY/PAUSE 2;
for CD .................starts or pauses CD playback.
6 TUNING, PREVIOUS/NEXT (¡1 / 2™)
for CD .................skips to the beginning of a
for Tuner ............. tunes to radio stations.
for clock/timer .. adjusts the hours and minutes
current track/previous/ next
track.
fast searches back and forward
within a track/CD.
for clock / timer functions
7 SOURCE (CD/ TUNER/ TAPE)
– switches on the system.
– selects the respective sound source for CD/
TUNER / TAPE.
8 TIMER
– activates/deactivates or sets the timer function.
9 PRESET G / H (3 / 4 on remote control)
for Tuner ............. selects a preset radio station.
0 PLAYMODE (REPEAT / SHUFFLE)
– repeats a track/CD program/ entire CD.
– plays CD tracks in random order.
! STOP/BAND 9
for CD .................stops CD playback or erase a
for Tuner ............. (on the set only) selects
CD program.
waveband.
@ DISPLAY/CLOCK
for CD .................display CD remaining time.
at standby .......... sets the clock function.
12
# DBB (Dynamic Bass Boost)
– enhances the bass.
$ VOLUME G / H (3 / 4 on remote control)
– adjusts volume level. .
%
– connect headphones.
^ Ta pe Deck Operation
OPEN•CLOSE ..Opens the tape key cover.
RECORD 0 ....... starts recording.
PLAY 2 ................. star ts playback.
à / á ............... fast rewinds/forwards the tape.
STOP•OPEN ... stops the tape; opens the tape
PA US E ................... pauses recording or playback.
compartment.
& OPEN•CLOSE
– opens/closes the CD door.
* MUTE
– switches playback sound off and on.
( SLEEP
– activates/deactivates or selects the sleeper time.
Notes for remote control:
– First select the source you wish to control
by pressing one of the source select keys on
the remote control (for example CD ,
TUNER).
– Then select the desired function (for
exampleÉ,
í
,
ë
).
IMPORTANT:
Before you operate the system, complete
the preparation procedures.
Basic Functions
Adjusting volume and sound
1 Press VOLUME G / H (3 / 4 on remote
control) to increase or decrease volume.
➜ Display shows the volume level UoL and a
number from 0-32.
2 Press DBB to switch bass
enhancement on or off.
➜ Display shows: DBB if
the DBB is activated.
3 Press MUTE on the
remote control to stop
sound play-back instantly.
➜ Playback will continue
without sound and the
display shows MUTE .
English
Switching the system on
● Press POWER (y on the remote control).
➜ The system will switch to the last selected
source.
● Press SOURCE (CD, TUNER or TAPE on
the remote control).
➜ The system will switch to the selected source.
To switch the system to standby mode
● Press POWER (y on the remote control).
● If in tape mode or recording mode, press
STOP•OPEN first.
➜ The volume level (up to maximum volume
level of 20), interactive sound settings, last
selected source and tuner presets will be
retained in the player's memory.
Power-saving automatic standby
The power-saving feature automatically switches
to standby 15 minutes after a tape or CD
playback has ended and no control is operated.
● To start sound playback you
can:
– press MUTE again;
– adjust the volume controls;
– change source.
13
CD Operation
English
IMPORTANT:
The lens of the CD player should never be
touched.
Playing a disc
This CD player plays Audio Discs including CDRecordables and CD-Rewritables.
¶ CD-ROM, CD-I, CDV, VCD, DVD or computer
CDs, however, are not possible.
1 Select CD source.
2 Lift the disc door at the edge
marked OPEN•CLOSE to
open the CD compartment.
➜ OPEN is displayed when
you open the CD compartment.
3 Insert a disc with the printed side facing up and
press down on OPEN•CLOSE to close the
CD door.
➜ rEAd is displayed as the CD player scans
the contents of a disc. The total number of
tracks and the total playing time are also shown.
4 Press 2; to start playback.
➜ Current track number followed by elapsed
playing time of the track are displayed during disc
playback.
➜ Press DISPLAY/CLOCK to display total
remain playing time.
5 To pause playback press 2;. Press 2; again to
resume play.
➜ Display: The elapsed time flashes when
playback is paused.
6 To stop disc playback, press 9.
Note: CD play will also stop when;
– the CD door is opened.
– the disc has reached the end.
– you select another source: TAPE, TUNER.
– you select standby.
– you press the tape deck PLAY 2 key.
Selecting a different track
● Press ¡1 or 2™ once or repeatedly until the
desired track number appears in the display.
● Press 2; to start playback.
Finding a passage within a track
1 Press and hold down ¡1 or 2™ .
➜ The disc is played at high speed and low
volume.
2 When you find the passage you want, release
¡1 or 2™ .
➜ Normal playback continues.
14
CD Operation
Different play modes: SHUFFLE
and REPEAT
You can select and change the various play
modes before or during playback.
REPEAT ............plays the current track
continuously
REPEAT ALL ... repeats the entire disc/
programme
SHUFFLE ......... tracks of the entire disc are
played in random order
1 To select your play mode, press PLAYMODE
(SHUFFLE or REPEAT on the remote
control) before or during playback until the
display shows the desired function.
2 Press 2; to start playback if in the STOP
position.
➜ If you have selected SHUFFLE, playback starts
automatically.
3 To return to normal playback, press
PLAYMODE (SHUFFLE or REPEAT on
the remote control) until the various SHUFFLE/
REPEAT modes are no longer displayed.
● You can also press STOP 9 to cancel your play
mode.
Programming track numbers
Programme in the STOP position to select and
store your disc tracks in the desired sequence. If
you like, store any track more than once. Up to
20 tracks can be stored in the memory.
1 Press ¡1 or 2™ to select your desired track
number.
2 Press PROG.
➜ Display shows: the selected track number.
PROG flashes and 1 Pr appears briefly.
3 Repeat steps 1-2 to select and store all desired
tracks.
➜FULLis displayed if you attempt to
programme more than 20 tracks.
4 To star t playback of your disc programme, press
2;.
Notes:
– If you wish, you can add further tracks to your
current program. Make sure you are in the STOP
position, and that you have not exceeded 20
tracks.
– Display shows NOSE if there is no track
selected.
Erasing the programme
You can erase the programme by:
● pressing 9 once in the STOP mode;
● pressing 9 twice during playback;
● opening the CD compartment;
● Select another sound source
➜PROG disappears from the display.
English
15
Radio Reception
English
Tuning to radio stations
1 Select TUNER source.
➜ is displayed.
2 Press STOP/BAND (on the set) or TUNER
(on the remote control) once or more to select
your waveband.
3 Press on TUNING ¡1 or 2™ and release
button.
➜ The radio automatically tunes to a station
with sufficient reception. Display indication during
automatic tuning Srch.
4 Repeat step 3 if necessary until you find the
desired station.
● To tune to a weak station, press TUNING ¡1
or 2™ briefly and repeatedly until you have
found optimal reception.
Helpful hints:
To improve radio reception:
–For FM, extend coil antenna at the back of the
unit fully for optimum reception.
–For AM, the set uses a built-in antenna. Direct
this antenna for best reception by turning the
whole set.
Programming radio stations
You can store up to a total of 20 (10 FW and
10 AM) radio stations in the memory.
Automatic programming
Automatic programming will start with a chosen
preset number 1. From this preset number
upwards, former programmed radio stations will
be overridden.
1 Press STOP/BAND (on the set) or TUNER
(on the remote control) once or more to select
your waveband.
2 Press PRESET G / H (3 / 4 on remote
control) to select the preset number where
programming should start.
Note:
– If no preset number is selected, default is preset
(1) and all your presets will be overridden.
3 Press PROG for more than 2 seconds to
activate programming.
➜ AUto is displayed and available stations are
programmed in order of waveband reception
strength.
Manual programming
1 Tune to your desired station (see Tuning to radio
stations).
2 Press PROG to activate programming.
➜ PROG flashes in the display.
3 Press PRESET G / H (3 / 4 on remote
control) to select a number from 1 to 10 for
FM (or 1 to 10 for AM) to this station.
4 Press PROG again to confirm the setting.
➜ PROG, the preset number and the
frequency of the preset station is shown.
5 Repeat the above four steps to store other
stations.
● You can override a preset station by storing
another frequency in its place.
16
Tuning to preset radio stations
● Press PRESET G / H (3 / 4 on the remote
control) until the desired preset station is
displayed.
Ta pe playback
1 Select TAPE source.
➜ Display: shows throughout tape
operation.
2 Pull down the plate marked “OPEN•CLOSE”
at the bottom of the main set.
3 Press STOP•OPENÇç to open the tape
door.
4 Insert a recorded tape and close the tape door.
● Load the tape with the open side downward and
the full spool to the left.
5 Press PLAY 2 to start playback.
6 To pause, press PAUSE Å. Press again to
resume.
7 Press à or á to fast wind tape in either
direction.
8 To stop the tape, press STOP•OPENÇç.
Notes:
– During playback, the keys are automatically
released at the end of a tape. To switch off the set,
press POWER.
– During fast forwarding/rewinding, the keys will
not be released at the end of a tape. To stop fast
winding, press STOP/EJECT 9/.
– The sound source cannot be changed while
playing and recording a tape.
Ta pe Operation / Recording
General information on
recording
● Recording is permissible insofar as copyright or
other rights of third parties are not infringed.
● For recording, use only NORMAL (IEC type I)
tapes on which the tabs have not yet been
broken. This deck is not suited for recording on
METAL (IEC IV) type tapes.
● The best recording level is set automatically.
Altering the VOLUME or DBB controls will not
affect the recording in progress.
● The recording sound quality might differ
depending on the quality of your recording
source and the recording tape.
● At the very beginning and end of the tape, no
recording will take place during the 7 seconds
when the leader tape passes the recorder heads.
● To protect a tape from accidental erasure, have
the tape in front of you and break out the left
tab. Recording on this side is no longer possible.
If, however, you wish to record over this side
again, cover the tabs with a piece of adhesive
tape.
Synchro start CD recording
1 Select CD source.
2 Insert a disc and if desired, programme track
numbers.
3 Press STOP•OPENÇç to open the tape
door.
4 Insert a suitable tape into the deck and close the
tape door.
5 Press RECORD 0 to start recording.
➜ Playing of the CD programme starts
automatically from the beginning of the CD
after 7 seconds. It is not necessary to start the
CD player separately.
English
17
Ta pe Operation / Recording
A A B C
English
To select and record a particular passage
within a CD track:
● Press and hold down on à or á. Release the
control when you recognize the passage you
want.
● To interrupt CD playback press 2; .
● Recording starts from this exact point in the
track when you press RECORD 0.
6 To pause, press PAUSE Å. Press again to
resume.
7 To stop recording, press STOP•OPEN.
Maintenance
Cleaning the Cabinet
● Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
● When a disc becomes dirty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
● Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic spray intended
for analogue records.
Recording from the radio
1 Tune to the desired radio station (see Tuning to
radio stations).
2 Press STOP•OPENÇç to open the tape
door.
3 Insert a suitable tape into the deck and close the
tape door.
4 Press RECORD 0 to start recording.
5 To pause , press PAUSE Å Press again to
resume.
6 To stop recording, press STOP•OPENÇç.
Cleaning the Heads and the Tape Paths
● To ensure good recording and playback quality,
clean the heads A, the capstan(s) B, and
pressure roller(s) C after every 50 hours of
tape operation.
● Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
● You can also clean the heads by playing a
cleaning tape once.
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
18
Demagnetising the heads
● Use a demagnetising tape available at your
dealer.
Setting the clock
1 In Standby mode, press DISPLAY/CLOCK
button.
➜ The clock digits for the hours flash.
2 Press ¡1 / 2™ to set the hours.
3 Press DISPLAY/CLOCK again.
➜ The clock digits for the minutes flash.
4 Press ¡1 / 2™ to set the minutes.
5 Press DISPLAY/CLOCK to confirm the time.
Note:
– If the clock has not been set, --:-- will be
displayed.
Clock/Timer
Setting the timer
● The system can be used as an alarm clock. CD
or TUNER can be set to switch on at a preset
time. The clock time needs to be set first before
the timer can be used.
● If no button is pressed within 90 seconds during
timer setup, the system will exit timer setting
mode automatically.
1 In any mode, press TIMER for more than 2
seconds.
2 Press ¡1 / 2™ (CD / TUNER or ¡1 / 2™ on
the remote control) to select sound source.
3 Press TIMER to confirm your desired source.
➜ The clock digits for the hour s flash.
4 Press ¡1 / 2™ to set the hours.
5 Press TIMER again.
➜ The clock digits for the minutes flash.
6 Press ¡1 / 2™ to set the minutes.
7 Press TIMER to confirm the time.
➜ The timer is now set and actiated.
Note:
- If source CD is selected and no disc is in the CD
tray or the disc has an error, TUNER will be
selected automatically.
Activating and deactivating
TIMER
● In standby or during playback, press
TIMER once.
➜ Display shows TIMER if activated, and
disappears if deactivated.
English
19
Clock/Timer
English
Activating and deactivating
SLEEP
The sleep timer enables the system to switch off
by itself after a set period of time.
● Press SLEEP on the remote control repeatly to
select desired time before
system shuts off.
➜ Display shows SLEEP and
series of time options for
selection: 60, 45, 30,15, 0,
60.
● To deactivate, press SLEEP on the remote
control once or more until ‘0’ is shown, or press
POWER / y on the system or remote control.
Specifications
AMPLIFIER
Output power ................................ 2 x 1.5 W RMS
Signal-to-noise ratio .......................... ≥ 62 dBA (IEC)
Frequency response ......... 63 – 16000 Hz, ± 3 dB
Impedance loudspeakers ......................................... 8 Ω
Impedance headphones ................. 32 Ω – 1000 Ω
(1)
(8 Ω, 125 Hz - 10 kHz, 10% THD)
CD PLAYER
Frequency range .................................. 63 – 16000 Hz
Signal-to-noise ratio ............................................ 65 dBA
TUNER
FM wave range ...................................87.5 – 108 MHz
MW wave range ................................ 530 – 1700 kHz
(1)
SPEAKERS
Bass reflex system
Dimensions (w x h x d) ....................................................
.................................................. 130 x 224.5 x 213 (mm)
.................................................. 5.12 x 8.84 x 8.39 (inch)
GENERAL INFORMATION
AC Power ................................................... 120 V / 60 Hz
Dimensions (w x h x d) .....................................................
.............................................. 168 x 224.5 x 214.5 (mm)
.................................................. 6.61 x 8.84 x 8.45 (inch)
Weight (with/without speakers) ..................................
............................................................ approx. 4.6 / 2.25 kg
............................................... approx. 10.1 / 4.96 pound
Standby power consumption .......................... < 3 W
TAPE DECK
Frequency response
Normal tape (type I) ...... 125 – 8000 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 34 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
20
Subject to modification
Tr oubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to remedy a problem by following these hints, consult your dealer or service centre.
Problem Solution
CD OPERATION
“no cd” is displayed. – Insert a disc.
– Check if the disc is inserted upside down.
–Wait until the moisture condensation at the lens
has cleared.
– Replace or clean the disc, see “Maintenance”.
– Use a finalised CD-RW or CD-R.
RADIO RECEPTION
Radio reception is poor. – If the signal is too weak, adjust the antenna or
connect an external antenna for better reception.
– Increase the distance between the Micro HiFi
System and your TV or VCR.
TAPE OPERATION / RECORDING
Recording or playback cannot be made. – Clean deck parts, see “Maintenance”.
– Use only normal (IEC I) tape for recording.
– Apply a piece of adhesive tape over the missing
tab space.
English
GENERAL
The system does not react when buttons – Remove and reconnect the AC power plug and
are pressed. switch on the system again.
Sound cannot be heard or is of poor – Adjust the volume.
quality. – Disconnect the headphones.
– Check that the speakers are connected correctly.
– Check if the stripped speaker wire is clamped.
The left and right sound outputs are – Check the speaker connections and location.
reversed.
21
Troubleshooting
English
The remote control does not function – Select the source (CD or TUNER, for example)
properly. before pressing the function button (É,í,ë).
– Reduce the distance between the remote control
and the system.
– Insert the batteries with their polarities
(+/– signs) aligned as indicated.
– Replace the batteries.
–Point the remote control directly toward
IR sensor on the front of the system.
The timer is not working. – Set the clock correctly.
– Press TIMER to switch on the timer.
– If a recording is in progress, stop the recording.
The Clock/Timer setting is erased. –Power has been interrupted or the power cord
has been disconnected. Reset the clock/timer.
22
Philips, P.O. Box 671539, Marietta, GA. 30006-0026
PHILIPS LIMITED WARRANTY
ONE (1) YEAR
WARRANTY COVERAGE:
PHILIPS warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
Philips warrants the product to the original purchaser or the
person receiving the product as a gift against defects in materials and workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
The Philips warranty covers new products if a defect arises and
a valid claim is received by Philips within the Warranty Period.
At its option, Philips will either (1) repair the product at no
charge, using new or refurbished replacement parts, or (2)
exchange the product with a product that is new or which has
been manufactured from new, or serviceable used parts and is
at least functionally equivalent or most comparable to the original product in Philips current inventory, or (3) refund the original purchase price of the product.
Philips warrants replacement products or parts provided under
this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product
or part is exchanged, any replacement item becomes your
property and the replaced item becomes Philips’ property.
When a refund is given, your product becomes Philips’ property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to the new products manufactured by or for Philips that can be identified by the trademark, trade name, or logo affixed to it. This Limited Warranty
does not apply to any non-Philips hardware product or any
software, even if packaged or sold with the product. NonPhilips manufacturers, suppliers, or publishers may provide a
separate warranty for their own products packaged with the
bundled product.
Philips is not liable for any damage to or loss of any programs,
data, or other information stored on any media contained within the product, or any non-Philips product or part not covered
by this warranty. Recovery or reinstallation of programs, data
or other information is not covered under this Limited
Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, misapplication, or non-Philips product, (b) to
damage caused by service performed by anyone other than
Philips or Philips Authorized Service Location, (c) to a product
or a part that has been modified without the written permission of Philips, or (d) if any Philips serial number has been
removed or defaced, or (e) product, accessories or consumables sold “AS IS” without warranty of any kind by including
refurbished Philips product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product to Philips.
• Labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation
or repair of antenna systems outside of the product.
• Product repair and/or part replacement because of improper
installation, connections to improper voltage supply, abuse,
neglect, misuse, accident, unauthorized repair or other cause
not within the control of Philips.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage occurring to product during shipping.
•A product that requires modification or adaptation to enable
it to operate in any country other than the country for
which it was designed, manufactured, approved and/or
authorized, or repair of products damaged by these modifications.
•A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., PUERTO
RICO, OR U.S. VIRGIN ISLANDS…
Contact Philips Customer Care Center at:
1-888-PHILIPS (1-888-744-5477)
TO OBTAIN ASSISTANCE IN CANADA…
1-800-661-6162 (French Speaking)
1-888-PHILIPS (1-888-744-5477) - (English or Spanish
Speaking)
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED IN DURATION TO THE DURATION
OF THIS WARRANTY.
Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how
long an implied warranty lasts, so the above limitations or
exclusions may not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
3121 233 48801
23
Loading...
