Philips MC108C 05 User Manual
Micro Hi-Fi System
MC108C
Important notes for users in
the U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of
plug proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 3
Amp, A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your
socket outlets, it should be cut off and an
appropriate plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 3 Amp. If a plug without a
fuse is used, the fuse at the distribution board
should not be greater than 3 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured
with the following code: blue = neutral (N),
brown = live (L).
¶ As these colours may not correspond with
the colour markings identifying the terminals
in your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make cer tain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to
1972.
2
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
1
4
2
3
8
BAND
POWER SOURCE VOLUME
iR
PROG/CLOCK
PROG TRK
MW
SHUF
TUNER CD AUX
MC108 MICRO SYSTEM
DBB
FM AM PM
REPALLMUTE
-
O
E
P
S
E
N
O
L
/
C
6
7
5
TUNING
+
0
!
@
9
#
AUX-IN
3
Contents
English
General Information
Environmental information ................................ 5
Supplied accessories ............................................ 5
Safety information ................................................ 5
Preparation
Rear connections ............................................. 6–7
Before using the remote control ...................... 7
Replacing battery (lithium CR2032)
into the remote control ..................................... 7
Maintenance.............................................. 12
Clock/Timer
Setting the clock ................................................. 13
Setting the timer ................................................. 13
Activating and deactivating TIMER ................. 13
Activating and deactivating SLEEP .................. 14
Specifications ........................................... 14
Controls
Controls on the system and remote
control .................................................................... 8
Basic Functions
Switching the system on ..................................... 9
Power-saving automatic standby ....................... 9
Adjusting volume and sound.............................. 9
CD Operation
Playing a disc ........................................................ 10
Selecting a different track ................................. 10
Finding a passage within a track ...................... 10
Different play modes: Shuffle and Repeat ..... 11
Programming track numbers ........................... 11
Erasing the programme ..................................... 11
Radio Reception
Tuning to radio stations .................................... 12
Troubleshooting .................................... 15
4
4
General Information
This product complies with the radio
interference requirements of the European
Community.
Supplied accessories
–2 speaker boxes
– remote control with battery
– AM loop antenna
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Disposal of your old product
Your product is designed and
manufactured with high quality
materials and components,
which can be recycled and
reused.
When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do
not dispose of your old products with your
normal household waste. The correct disposal of
your old product will help prevent potential
negative consequences for the environment and
human health.
Safety Information
● Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
5
Preparations
English
FM wire antenna
Speaker
(right)
Rear connections
The type plate is located at the rear of the
system.
For users in the U.K.: please follow the
instructions on page 2.
A Power
– Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
AM loop antenna
Speaker
(left)
AC power cord
B Antennas Connection
AM (MW) antenna
1 Unfold the loop antenna and if necessary, use
screws (not supplied)to fix it to a flat, hard and
stable place:
1
2
WARNING!
–For optimal performance, use only the
original power cable.
–Never make or change any connections
with the power switched on.
6
6
2 Fit the plug of the loop antenna to AM
ANTENNA as shown above.
3 Adjust the antenna for optimal reception
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
