Register your product and get support at
www.philips.com/welcome
HTS5200
EN User manual
MS-MY Manual pengguna
=+7: Ԛʹ˫
=+&1 Ⴌ߀൱Ҭ
Contents
8 Update software 15
Check software version 15
Update software from a CD-R or USB
1 Notice 2
Copyright 2
About Progressive Scan
Trademarks
2
2
9 Product speci cations 16
10 Troubleshooting 17
2 Important 3
Safety 3
Product care
3
11 Index 19
3 Disposal of your old product and
batteries 4
4 Your home theater 4
Main unit 4
Remote control
5
15
English
5 Connect your home theater 6
Connectors 6
Connect to the TV
Connect audio from TV or other devices
7
8
6 Use your home theater 9
Before you start 9
Choose your sound
Play a disc
Play from radio
Play audio from TV or other devices
Play from a USB storage device
Play from an iPod or iPhone
More play features for disc or USB
Use Philips EasyLink
9
9
10
11
11
11
12
12
7 Change settings 13
Access the setup menu 13
Change general settings
Change audio settings
Change video settings
Change preference settings
13
14
14
15
EN
1
®
®
1 Notice
©
Copyright
This item incorporates copy protection technology
that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are
prohibited.
About Progressive Scan
Consumers should note that not all high de nition
television sets are fully compatible with this
product and may cause artifacts to be displayed in
the picture. In case of 525 or 625 progressive scan
picture problems, it is recommended that the user
switch the connection to the ‘standard de nition’
output. If there are questions regarding our TV set
compatibility with this model 525p and 625p DVD
player, please contact our customer service center.
Trademarks
DivX ® and DivX Ultra ® are registered
trademarks of DivX, Inc. and are used under
license.
DivX Ultra
advanced features and premium content.
ABOUT DIVX VIDEO: DivX
format created by DivX, Inc. This is an of cial
DivX Certi ed device that plays DivX video.
Visit www.divx.com for more information and
software tools to convert your les into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certi ed
order to play DivX Video-on-Demand (VOD)
content. To generate the registration code,
locate the DivX VOD section in your device
setup menu. Go to vod.divx.com with this code
to complete the registration process and learn
more about DivX VOD.
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
Certi ed to play DivX ® video with
®
is a digital video
device must be registered in
Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents
issued & pending. DTS and the Symbol are
registered trademarks & DTS Digital Surround
and the DTS logos are trademarks of DTS, Inc.
Product includes software.
Reserved.
DTS, Inc. All Rights
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
HDMI, and HDMI logo and High-De nition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC.
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
CLASS 1
LASER PRODUCT
2
EN
2 Important
Read and understand all instructions before you
use your home theater. If damage is caused by
failure to follow instructions, the warranty does
not apply.
Safety
Risk of electric shock or re!
Never expose the product and accessories •
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the product checked before
use.
Never place the product and accessories •
near naked ames or other heat sources,
including direct sunlight.
Never inser t objects into the ventilation •
slots or other openings on the product.
Where the mains plug or an appliance •
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
Disconnect the product from the power •
outlet before lightning storms.
When you disconnect the power cord, •
always pull the plug, never the cable.
Risk of short circuit or re!
Before you connect the product to the •
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.
Risk of injury or damage to the home theater!
For wall-mountable products, use only the •
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident, injury
or damage.
For speakers with stands, use only the •
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands
on at, level surfaces that can support the
combined weight of the speaker and stand.
Never place the product or any objects •
on power cords or on other electrical
equipment.
If the product is transported in •
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
Visible and invisible laser radiation when •
open. Avoid exposure to beam.
Do not touch the disc optical lens inside the •
disc compartment.
Risk of overheating!
Never install this product in a con ned •
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Risk of contamination!
Do not mix batteries (old and new or •
carbon and alkaline, etc.).
Remove batteries if they are exhausted or •
if the remote control is not to be used for a
long time.
Batteries contain chemical substances, they •
should be disposed of properly.
Product care
Do not inser t any objects other than discs •
into the disc compartment.
Do not insert warped or cracked discs into •
the disc compar tment.
Remove discs from the disc compar tment •
if you are not using the product for an
extended period of time.
Only use micro ber cloth to clean the •
product.
English
EN
3
3 Disposal of your
4 Your home theater
old product and
batteries
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Congratulations on your purchase, and welcome
to Philips! To fully bene t from the support that
Philips offers, register your home theater at www.
philips.com/welcome.
Main unit
a +/-
Increases or decreases volume.
b Display panel
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
c ( Play/Pause )
Starts, pauses or resumes play.
d ( Stop )
Stops play. In radio mode, erases the
current preset radio station.
e ( Eject )
Ejects the disc from the disc compartment.
f Disc compartment
g ( Standby-On )
Switches the home theater on or to
standby.
h SOURCE
Selects an audio/video source for the home
theater.
4
EN
Remote control
a
b
c
c Source buttons
• DISC : Switches to disc source.
• USB : Switches to USB storage device.
• RADIO : Switches to FM radio.
• AUDIO SOURCE : Selects an audio
input source.
• DOCK for iPod : Switches to Philips
Dock for iPod/iPhone.
English
t
s
r
q
p
o
n
d
e
f
g
h
i
j
k
d SETUP
Accesses or exits the setup menu.
e ( Navigation buttons )
•
Navigate menus.
In video mode, press left or right to •
fast backward or fast forward.
In radio mode, press left or right to
•
search a radio station; press up or
down to ne tune a radio frequency.
f INFO
Displays information about what is playing.
g Playback buttons
Control playback.
h TREBLE / BASS
Changes treble or bass. Use with +/- .
i Numeric buttons
Selects an item to play.
j AUDIO SYNC
•
Selects an audio language or channel.
Press and hold to synchronize audio •
with video. Use with +/- .
m
a ( Standby-On )
•
Switches the home theater on or to
standby.
•
When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b OPEN/CLOSE
Ejects the disc from the disc compartment.
l
k SOUND MODE
Selects a sound mode.
l REPEAT / PROGRAM
•
Selects a repeat or shuf e mode.
In radio mode, programs radio stations.•
m
ZOOM
Zooms into a video scene or picture.
n HDMI / ANGLE
•
Selects video resolution of HDMI
output from the home theater.
•
Press and hold to select options for
different camera angles.
o SUBTITLE
Selects subtitle language for video.
EN
5
p SURROUND
Switches to surround sound or stereo
sound.
q +/-
Increases or decreases volume.
r ( Mute )
Mutes or restores volume.
s BACK
Returns to a previous menu screen.
t OK
Con rms an entry or selection.
5 Connect your home
theater
This section helps you connect your home theater
to a TV and other devices. The basic connections
of the home theater with its accessories are
provided in the Quick Start. For a comprehensive
interactive guide, see www.connectivityguide.
philips.com.
Note
Refer to the type plate at the back or bottom •
of the product for identi cation and supply
ratings.
Before you make or change any connections,
•
ensure that all devices are disconnected from
the power outlet.
Connectors
Side connectors
a MP3 LINK
Audio input from an MP3 player.
b ( USB )
Audio, video or picture input from a USB
storage device.
6
EN
Back connectors
Option 1: Connect to the TV through
HDMI
a HDMI OUT
Connects to the HDMI input on the TV.
b VIDEO OUT - Pr Pb Y
Connects to the component video input on
the TV.
c VIDEO OUT - VIDEO
Connects to the composite video input on
the TV.
d DIGITAL IN-COAXIAL
Connects to the coaxial audio output on
the TV or a digital device.
e DOCK for iPod
Connects to a Philips Dock for iPod/iPhone.
(Model: Philips DCK3060, sold separately.)
f SPEAKERS / SUBWOOFER
Connects to the supplied speakers and
subwoofer.
g AUDIO IN - AUX 1 / AUX 2
Connects to the analog audio output on the
TV or an analog device.
h AC MAINS~
Connects to the power supply.
i ANTENNA FM 75
Connects the FM antenna for radio reception.
Note
If the HDTV has a DVI connector, connect •
using an HDMI/DVI adapter.
If the TV supports EasyLink HDMI CEC,
•
control the home theater and TV with one
remote control (see ‘Use Philips EasyLink’ on
page 12 ) .
(Cable not supplied)
TV
Option 2: Connect to the TV through
YPbPr (component video)
Note
The component video cable or connector •
might be labeled Y Cb Cr or YUV .
(Cable not supplied)
Component Video Out
TV
English
Connect to the TV
Connect your home theater directly to a TV
through one of the following connectors (from
highest to basic quality video):
a HDMI
b Component video
c Composite video
Component Video In
EN
7
Option 3: Connect to the TV through
composite video (CVBS)
Note
The composite video cable or connector might •
be labeled AV IN , VIDEO IN , COMPOSITE or
BASEBAND .
TV
Connect audio from TV or
other devices
Use your home theater to play audio from the TV
or other devices such as a cable box. Choose from
the following connectors.
1
2
Option 2: Connect audio through coaxial
cable
Note
The digital coaxial cable or connector might be •
labeled COAXIAL/DIGITAL OUT or SPDIF
OUT .
(Cable not supplied)
Tip
Press • AUDIO SOURCE repeatedly to select
the audio output of your connection.
Option 1: Connect audio through analog
audio cables
(Cable not supplied)
1
2
TV
TV
8
EN
6 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Change virtual surround mode
DVS (Dolby Vir tual Speaker) technology
creates a highly compelling 5.1-channel listening
experience from as few as two speakers.
English
Before you start
Check that you:
Make the necessary connections and •
complete the setup as described in the
Quick Start.
Switch the TV to the correct source for the •
home theater.
Choose your sound
This section helps you choose the ideal sound for
your video or music.
Change sound mode
Select prede ned sound modes to suit your
video or music.
Press SURROUND to switch surround sound or
stereo sound.
Change treble or bass
Change the high frequency (treble) or low
frequency (bass) settings of the home theater to
suit your video or music.
1 Press TREBLE or BASS .
2 Press +/- within ve seconds to increase
or decrease treble or bass.
Play a disc
Press SOUND MODE repeatedly to cycle
through the available sound modes.
Sound mode Description
ACTION /
ROCK
DRAMA /
JAZZ
CONCERT /
CLASSIC
SPORTS Moderate mid-range and
Enhanced low and high-range.
Ideal for action movies and rock
or pop music.
Clear mid and high-range. Ideal
for drama movies and jazz music.
Neutral sound. Ideal for live
concerts and classical music.
surround effects for clear vocals
and the atmosphere of a live
sport venue.
The home theater can play a wide variety of discs,
including video, audio and mixed media (for example,
a CD-R that contains JPEG pictures and MP3 music).
1 Insert a disc into the home theater.
2 Press DISC .
The disc plays or the disc main menu appears. »
3 Press the following buttons to control play:
Button Action
Navigation
buttons
OK Con rms an entry or selection.
/
/
ZOOM Zooms into a video scene or picture.
Navigate menus.
Starts, pauses or resumes play.
Stops play.
Skips to the previous or next
track, chapter or le.
Fast backwards or fast forwards.
Press repeatedly to change the
search speed.
In pause mode, steps forward by
one frame.
EN
9
Use video options
Access several useful features while viewing
video.
Play from radio
The home theater can store up to 40 radio
stations.
Note
Available video options depend on the video •
source.
Button Action
/
AUDIO
SYNC
SUBTITLE Selects subtitle language for video.
INFO
REPEAT Repeats a chapter or title.
ANGLE Displays options for different
Searches slow-backward or
slow-forward. Press repeatedly to
change the search speed.
For VCD/SVCD, slow-backward
search is not available.
Selects an audio language or
channel.
Displays information about what
is playing.
camera angles.
1 Check that the FM antenna is connected.
2 Press RADIO .
“ » AUTO INSTALL...PRESS PLAY ’ appears
on the display panel if you have not
installed any radio stations. Press
.
3 Press the following buttons to control play:
Button Action
/
/
PROGRAM Manual: Press once to access
Selects a preset radio station.
Searches for a radio station.
Fine tunes a radio frequency.
Press and hold to erase the
preset radio station.
Press to stop the installation of
radio stations.
program mode, and press again
to store the radio station.
Automatic: Press and hold for ve
seconds to reinstall radio stations.
Use picture options
Access several useful features while viewing
pictures.
Button Action
/
/
REPEAT Repeats a single le in the folder or
INFO
Rotates the picture counterclockwise or clockwise.
Skips to the previous or next
picture.
repeats the entire folder.
Shuf es les in a folder.
Displays photo albums in a
thumbnail overview.
Use audio options
Access several useful features while audio is
played.
Note
AM and digital radio are not suppor ted. •
If no stereo signal is detected, or if fewer than •
ve stations are found, you are prompted to
install the radio stations again.
For the best reception, place the antenna away
•
from the TV or other sources of radiation.
Change tuning grid
In some countries, you can switch the FM tuning
grid between 50 kHz and 100 kHz. Changing
tuning grid erases all preset radio stations.
1 Press RADIO .
2 Press .
3 Press and hold until ‘GRID 9’ (50 kHz)
or ‘GRID 10’ (100 kHz) is displayed.
Button Action
REPEAT Repeats a track, the entire disc
or shuf e tracks.
10
EN
Play audio from TV or other
Dock your iPod or iPhone
devices
Press AUDIO SOURCE repeatedly to select
the audio output of the connected device (see
‘Connect audio from TV or other devices’ on
page 8 ) .
Play from a USB storage device
The home theater is tted with a USB connector
that allows you to view pictures, listen to music or
watch movies stored on a USB storage device.
1 Connect the USB storage device to the
home theater.
2 Press USB .
A content browser appears. »
3 Select a le, then press OK .
4 Press the playback buttons to control play
(see ‘Play a disc’ on page 9 ) .
1 Connect the dock to the home theater and
connect the yellow composite cable from
the dock to the TV. For more information,
see the Quick Start provided with the dock.
2 Switch on the iPod or iPhone and place it in
the dock.
Listen to music
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 11 ) .
2 Press DOCK for iPod on the home theater
remote control.
3 Browse on the iPod or iPhone screen to
select track.
4 Press OK to play the track.
Watch video or view slideshows
Note
English
Note
If the USB storage device does not t into the •
connector, use a USB extension cable.
The home theater does not suppor t digital
•
cameras that need a computer program to
display photos.
The USB storage device must be FAT
•
formatted, and Mass Storage Class compliant.
Play from an iPod or iPhone
By connecting and installing a Philips Dock for
iPod/iPhone, you can use the home theater to
play music, movies and photos from your iPod or
iPhone.
Note
Philips Dock for iPod/iPhone is sold separately. •
You can charge your iPod/iPhone on the dock •
while the home theater is in iPod mode.
On iPod, enable the TV ON setting. •
On iPhone, select the TV Out option. •
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 11 ) .
2 Press DOCK for iPod on the home theater
remote control.
3 Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
The TV screen goes blank. »
4 Browse on the iPod or iPhone screen to
select videos or photos.
5 Press OK on the home theater remote
control or PLAY on the iPod/iPhone to play
the video or photos.
The picture is displayed on the TV. »
EN
11
More play features for disc or
Use Philips EasyLink
USB
Several advanced features are available for video
or picture playback from a disc or USB storage
device.
Play a musical slideshow
Play music and pictures simultaneously to create
a musical slideshow. The les must be stored on
the same disc or USB storage device.
1 Select a music track, then press OK .
2 Press BACK and go to the picture
folder.
3 Select a picture, then press OK to start
slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Synchronize audio with video
If the audio and video are not synchronized, you
can delay the audio to match the video.
1 Press and hold AUDIO SYNC until the
audio sync message appears on the display
panel.
2 Press +/- within ve seconds to sync the
audio with your video.
Quick skip play to a speci c time
Quick skip to a speci c part of a video by
entering the time of a scene.
1 During video play, press INFO .
2 Press the Navigation buttons and OK to
select:
• [TT Time] : Title time.
• [Ch Time] : Chapter time.
• [Disc Time] : Disc time.
• [Track Time] : Track time.
3 Enter the time of the scene, then press OK .
The home theater supports Philips EasyLink,
which uses the HDMI CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices
that are connected through HDMI connectors can
be controlled by a single remote control.
Note
Philips does not guarantee 100% •
interoperability with all HDMI CEC devices.
1 Switch on the HDMI CEC operations on
the TV and other connected devices. See
the manual of the TV or other devices for
details.
2 Press SETUP .
3 Select [General Setup] , then press OK .
4 Select [EasyLink Setup] , then press OK .
5 Select and adjust the following settings:
• [EasyLink] : Enables or disables
EasyLink.
• [One Touch Play] : Enables or disables
One Touch Play.
If enabled, you can use the remote
control to star t disc play in the
home theater and the TV switches
automatically to the correct channel.
• [One Touch Standby] : Enables or
disables One Touch Standby.
If enabled, the home theater can
be switched off to standby by a
remote control from the TV or other
connected HDMI CEC devices.
• [System Audio Control] :Enables or
disables System audio control.
If enabled, follow the instructions on
the TV to map the connected devices
correctly to the audio connectors of
the home theater. The home theater
switches automatically to the audio
source of the connected device.
• [Audio Input Mapping] : Updates audio
input mapping if there are new devices
connected.
6 Press OK to con rm your choice.
12
Note
The connected devices must be connected •
through HDMI and switched on.
EN
7 Change settings
Change general settings
This section helps you to change the settings of
your home theater.
Caution
Most of the settings are already con gured •
with the best value for the home theater.
Unless you have a speci c reason to change a
setting, it is best to leave it at the default value.
Access the setup menu
1 Press SETUP .
The following menu appears. »
Symbol Description
[General Setup]
[Audio Setup]
[Video Setup]
1 Press SETUP .
2 Select [General Setup] , then press OK .
3 Select and adjust the following settings:
• [EasyLink Setup] : Sets up EasyLink to
enjoy easy controls of all the HDMI
CEC compliant devices using a single
remote control (see ‘Use Philips
EasyLink ’ on page 12 ) .
• [Disc Lock] : Restricts play to disc.
Password (PIN code) is required to
unlock the disc before play.
• [Display Dim] : Changes the brightness
of the display panel.
• [OSD Language] : Selects the on-
screen display menu language.
• [Screen Saver] : Enables or disables
screen saver mode. If enabled, the
screen enters idle mode after 10
minutes of inactivity (for example, in
pause or stop mode).
• [Sleep Timer] : Sets a sleep timer to
switch the home theater to standby
after a speci c time.
English
[Preference Setup]
2 Select a setup menu, then press OK .
See the following sections for information
about how to change the settings of your
home theater.
3 Press BACK to return to the previous
menu, or press
Note
You cannot change a setting that is grayed out. •
SETUP to exit.
• [DivX® VOD Code] : Displays the
DivX VOD registration code for the
home theater.
4 Press OK to con rm your choice.
Note
Before you purchase DivX videos and play •
them on the home theater, register the home
theater on www.divx.com using the DivX
VOD code.
EN
13
Change audio settings
Change video settings
1 Press SETUP .
2 Select [Audio Setup] , then press OK .
3 Select and adjust the following settings:
• [Night Mode] : Selects quiet or full
dynamic sound. Night mode decreases
the volume of loud sounds and
increases the volume of soft sounds
such as speech.
• [HDMI Audio] : Enables or disables
HDMI audio output for the TV.
• [CD Upsampling] : Converts the music
CD to a higher sampling rate using
sophisticated digital signal processing
for better sound quality.
• [Audio Sync] : Sets a delay for audio
output when you play a video disc.
4 Press OK to con rm your choice.
Note
1 Press SETUP .
2 Select [Video Setup] , then press OK .
3 Select and adjust the following settings:
• [TV System] : Selects a TV system that
is compatible with the TV.
• [TV Display] : Selects a picture display
format to t the TV screen.
• [Picture Settings] : Selects a
prede ned color setting.
• [HDMI Setup] : Selects HDMI video
resolution and the wide screen display
format for the TV. The Wide Screen
Display option is only available for 16:9
wide screen TV display setting.
• [Progressive] : Enables or disables
progressive scan mode.
4 Press OK to con rm your choice.
Note
For settings related to HDMI, the TV must be •
connected through HDMI.
Night mode is available for Dolby encoded
•
DVD and Blu-ray discs (for models support
Blu-ray playback).
CD upsampling is only available in stereo
•
mode.
Some video settings depend on the video •
source, ensure that the disc and the TV
support the setting or feature.
The best setting is automatically selected for
•
the TV. If you need to change the setting,
ensure that the TV supports the new setting.
For settings related to HDMI, the TV must be
•
connected through HDMI.
For settings related to progressive or
•
component video, the TV must be connected
through Component Video.
14
EN
Change preference settings
8 Update software
1 Press SETUP .
2 Select [Preference Setup] , then press OK .
3 Select and adjust the following settings:
• [Audio] : Selects audio language for
video.
• [Subtitle] : Selects subtitle language for
video.
• [Disc Menu] : Selects menu language
for video disc.
• [Parental] : Restricts access to discs
that are recorded with ratings. To
play all discs irrespective of the rating,
select level ‘8’.
• [PBC] : Displays or skips the content
menu for VCD and SVCD discs.
• [MP3/JPEG Display] : Displays the
MP3/JPEG folders or all the les.
• [Password] : Sets or changes a PIN
code to play a restricted disc. Enter
‘ 0000 ’ if you do not have a PIN or if
you have forgotten your PIN.
• [DivX Subtitle] : Selects a character
set that supports the DivX subtitle.
• [Version Info.] : Displays the software
version for the home theater.
• [Default] : Resets the home theater to
the default settings programmed at the
factory.
4 Press OK to con rm your choice.
Note
To check for new updates, compare the current
software version of your home theater with the
latest software version (if available) on the Philips
web site.
Check software version
1 Press SETUP .
2 Select [Preference Setup] > [Version Info.] ,
then press OK .
The software version is displayed. »
Update software from a CD-R
or USB
1 Check for the latest software version on
www.philips.com/support.
Search for your model and click on
•
‘software&drivers’.
2 Download the software onto a CD-R or
USB storage device.
3 Inser t the CD-R or connect the USB
storage device to the home theater.
4 Follow the instructions on the TV to
con rm the update.
When complete, the home theater »
automatically switches to standby.
•
If not, disconnect the power cord for a
few seconds and then reconnect it.
English
If your preferred disc language is not available, •
you can select [Other] from the list and enter
the 4-digit language code which can be found
at the back of this manual.
If you select a language that is not available
•
on a disc, the home theater uses the default
language of the disc.
You cannot reset disc lock, password (PIN
•
code) and parental control settings to their
default values.
Caution
Do not turn off the power or remove the •
CD-R or USB storage device when the
software update is in progress because you
might damage the home theater.
EN
15
9 Product specifications
Note
Speci cation and design are subject to change •
without notice.
Video
Signal system: PAL / NTSC •
HDMI output: 480i/576i, 480p/576p, 720p, •
1080i, 1080p
Audio
S/PDIF Digital audio input: •
•
Coaxial: IEC 60958-3
Region code
The type plate on the back or bottom of the
home theater shows which regions it supports
Country
Europe, United Kingdom
Asia Pacific, Taiwan, Korea
Latin America
Australia, New Zealand
Russia, India
China
DVD
Playback media
DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R
DL, CD-R/CD-RW, Audio CD, Video CD/SVCD,
Picture CD, MP3-CD, WMA-CD, DivX-CD, USB
storage device
File Format
Audio: .mp3, .wma •
Video: .divx, .divx ultra, .mpeg, .mpg, .wmv •
(simple pro le)
Picture: .jpeg, .jpg •
Ampli er
Total output power: 400 W RMS •
Frequency response: 20 Hz-20 kHz / ±3dB •
Signal-to-noise ratio: > 65 dB (CCIR) / •
(A-weighted)
Input sensitivity: •
AUX: 1000 mV
•
MP3 LINK: 550 mV•
Sampling frequency: •
•
Constant bit rate: •
•
Radio
Tuning range: •
•
•
Signal-to-noise ratio: FM 55 dB •
Frequency response: FM 60 Hz ~ 12.5 kHz •
/ ±3dB
USB
Compatibility: Hi-Speed USB (2.0) •
Class support: UMS (USB Mass Storage •
Class)
File system: FAT16, FAT32 •
Maximum memory support: < 160GB •
Main Unit
•
•
Power consumption: 100 W •
Standby power consumption: 0.3 W •
Dimensions (WxHxD): 434 x 253 x 129 •
(mm)
Weight: 3.6 kg •
Subwoofer
Impedance: 3 ohm •
Speaker drivers: 165 mm (6.5”) woofer •
Frequency response: 40 Hz-150 Hz •
Dimensions (WxHxD): 196 x 395 x 342 •
(mm)
Weight: 5.25 kg •
Cable length: 4 m •
MP3: 32 kHz, 44.1 kHz, 48 kHz
WMA: 44.1 kHz, 48 kHz•
MP3: 112 kbps - 320 kbps
WMA: 48 kbps - 192 kbps•
Asia Paci c/Latin America: FM 87.5-108
MHz (50/100 kHz)
Russia/China/India: FM 87.5-108 MHz
(50 kHz)
Power supply:
Asia Paci c/Latin America: 110-•
127V/220-240V; ~50-60Hz switchable
Russia/China/India: 220-240V, ~50Hz
16
EN
Speakers
System: full range satellite
•
Speaker impedance: 6 ohm•
Speaker drivers: 1 x 76 mm (3”) •
woofer + 25 mm (1”) tweeter
Frequency response: 150 Hz-20 kHz
•
Dimension (WxHxD): 114 x 316 x 114 •
(mm)
Weight: 1.03 kg
•
Cable length: 2 m•
Laser speci cation
Type: Semiconductor laser GaAIAs (CD) •
Wave length: 645 - 665 nm (DVD), 770 - •
800 nm (CD)
Output power: 6 mW (DVD), 7 mW •
(VCD/CD)
Beam divergence: 60 degrees. •
10 Troubleshooting
Warning
Risk of electric shock. Never remove the •
casing of the product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, register your product and get
support at www.philips.com/welcome.
If you contact Philips, you will be asked for the
model and serial number of your product. The
model number and serial number are on the back
or bottom of your product. Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
English
Main unit
The buttons on this home theater do not work.
Disconnect the home theater from the •
power outlet for a few minutes, then
reconnect.
No picture.
Ensure that the TV is switched to the •
correct source for this home theater.
If this happens when you change the TV •
system, switch to its default mode: 1) Press
. 2) Press . 3) Press SUBTITLE .
If this happens when you switch on the •
progressive scan mode, switch to its default
mode: 1) Press
AUDIO SYNC .
No picture on HDMI connection.
Check if the HDMI cable is faulty. Replace •
with a new HDMI cable.
If this happens when you change the HDMI •
video resolution, press HDMI repeatedly
until picture appears.
. 2) Press . 3) Press
EN
17
Sound
No sound.
Ensure that the audio cables are connected •
and select the correct input source (for
example, AUDIO SOURCE ) for the device
you want to play.
No sound on HDMI connection.
You might not hear any sound if the •
connected device is not HDCP (Highbandwidth Digital Content Protection)
compliant or only DVI compatible. Use an
analog or digital audio connection.
Ensure that the •[HDMI Audio] is enabled .
No sound from TV program.
Connect an audio cable from the audio •
input on the home theater to the audio
output on the TV, then press AUDIO
SOURCE repeatedly to select the correct
audio source.
Distorted sound or echo.
Ensure that the TV volume is muted or set •
to minimum if you are playing audio through
the home theater.
Audio and video are not synchronized.
1) Press and hold • AUDIO SYNC . 2) Press
+/- within ve seconds.
Play
Disc cannot be played.
Clean the disc. •
Ensure that the home theater supports the •
disc (see ‘Product speci cations’ on page
16 ) .
Ensure that the home theater supports the •
region code of the disc.
For DVD±RW or DVD±R, ensure that the •
disc is nalized.
DivX video les cannot be played.
Ensure that the DivX le is encoded •
according to the ‘Home Theater Pro le’
with the DivX encoder.
Ensure that the DivX video le is complete. •
DivX subtitles do not display correctly.
Ensure that the subtitle le name is the •
same as the movie le name.
Select the correct character set: 1) Press •
SETUP . 2) Select [Preference Setup] .
3) Select [DivX Subtitle] . 4) Select a
supported character set. 5) Press OK .
The contents of a USB storage device cannot be
read.
Ensure that the format of the USB storage •
device is compatible with the home theater
(see ‘Product speci cations’ on page 16 ) .
Ensure that the USB storage device •
is formatted with a le system that is
supported by the home theater (note that
NTFS is not supported).
‘No entry’ or ‘x’ sign appears on the TV.
The operation is not possible. •
EasyLink feature does not work.
Ensure that the home theater is connected •
to a Philips brand EasyLink TV and that
EasyLink is on .
I do not want my home theater to be switched
on when I switch on my TV.
This is the correct behavior for Philips •
EasyLink (HDMI-CEC). To make the home
theater work independently, switch off
EasyLink .
The video (movies, photos, video clips, etc.)
contents of the iPod/iPhone do not display on TV.
Video and photo browsing is not supported, •
you can only browse the video and photo
contents on the iPod/iPhone itself.
Cannot see pictures from my iPod/iPhone on the
TV.
Connect a yellow composite cable from the •
dock to the TV.
Switch the TV to the •AV/VIDEO source
(corresponding to the yellow composite
cable).
Press •PLAY on the iPod or iPhone to star t
the slideshow.
18
EN
11 Index
A
ampli er 16
audio
connection 8
language 15 , 10
synchronize with video 12
audio input mapping 12
C
care 3
change settings 13
connect
audio from TV 8 , 11
guide 6
other devices 8
TV 7
connectors 6
contact us 17
D
disc
play 9
supported discs 16
disposal of your product 4
DivX
registration code 13
subtitle 15
L
language
audio 15
disc menu 15
on-screen display 13
subtitle 15
O
one-touch play 12
one-touch standby 12
overview
connectors 6
main unit 4
remote control 5
P
password 15
options 10
slide show 12 , 10
thumbnail overview 10
troubleshooting 17
play
disc 9
options 9
radio 10
troubleshooting 18
USB storage device 11
product care 3
product speci cations 16
progressive scan 2
English
E
EasyLink
settings 12
F
le formats 16
H
HDMI CEC (see Easylink) 12
I
iPod
play 11
R
radio
play 10
program 10
tune 10
tuning grid 10
recycle 4
region code 16
remote control 5
repeat 9
rotate pictures 10
19
EN
S
safety 3
settings
general 13
parental control 15
preferences 15
restore factory settings 15
video 14
slideshow
play musical slideshow 12
software
update 15
version 15
sound
mode 9
treble and bass 9
troubleshooting 18
subtitle
language 10
system audio control 12
T
time search video 12
troubleshooting 17
TV
audio from TV 8 , 11
connect 7
U
USB
play 11
V
video
options 10
settings 14
synchronize with audio 12
video on demand (VOD) 13
20
EN
?
?
PHILIPS CONSUMER ELECTRONICS
WARRANTY POLICY FOR AUSTRALIA
Philips provides the following Consumer Electronics products with a 1 Year Manufacturers Warranty:-
Players, DVD Recorders, DVD Recorders with
Hard Disk, Personal Video Recorders, Audio Systems, Wireless Audio Systems, Home Theatre systems,
Digital Set Top Box, Digital Photo Display, MP3 players & Portable Audio products.
st
October 2007, are
supported by a 3 Year Manufacturers Warranty.
The benefits given to the purchaser by this warranty
which the purchaser has in respect
Commonwealth or State Law.
Guarantee for products purchased in Australia and used in Australia.
Model number : ………………………………………………………..
Serial number : ………………………………………………………..
Date of purchase : ………………………………………………………..
Retailer : ………………………………………………………..
the Philips Technology Care Centre on 1300 363 391 where support is provided by our trained call
centre staff.
If the product fails within the warranty period then the following will apply.
Free Repair Service – at an Authorised Service Centre
For the products listed below, please contact one of our Authorised Service Centres on 1300 361 392.
Colour Television, Plasma or LCD Television, LCD Television, Projec
DVD Recorder with Hard Drive, Personal Video Recorder, LCD Projector, Wireless Audio System, Audio
System, Home Theatre System, Digital Set-Top-Box or a Portable DVD player with an LCD screen for
which you paid more than $250.
Version 1.2: 1
st
October 2007
Free Replacement – at your Retailer
For Digital Photo Frames or any product with a purchase price of less than $250, please return the
faulty product to the place of purchase. The retailer will arrange a replacement product for you.
If your Philips product develops a fault outside of the warranty period, please contact a Philips
Authorised Service Centre on 1300 361 392
a. All claims for warranty service should be made to your nearest Philips Authorised Service Centre or
the Philips Technology Care Centre. Proof of the original date of purchase must be provided.
b. This warranty extends only to defects in material or workmanship occurring under normal use of
Warranty.
d. If a replacement product is supplied under the repair policy, it is warranted for the remainder of
the warranty period, from the original date of purchase.
e. Home service is provided only within the normal service area of the nearest Philips Authorised
Service Centre. Home Service will be provided for television only with a screen size of 29 inch or
and Plasma TV). For televisions with screen
sizes of less than 29 inch and all other products with a repair warranty, please take these products
to the nearest Authorised Service Centre.
f. This Manufacturers Warranty is limited to 3 mon
g. Product accessories are covered by the same warranty period. If an accessory is faulty, please
contact the Philips Technology Care Centre for a replacement.
h. This Manufacturers Warranty is neither transferable nor valid in countries other than Australia.
i. The warranty period is valid from the original date of purchase of the product.
This Warranty does not cover:-
a. Mileage or travel is not covered outside the Philips Authorised Service Centres’ normal service
area.
b. Service costs arising from failure to correctly adjust the controls of the product or to observe the
e product is in normal working order.
c. Product failures caused by misuse, neglect, accidental breakage, transit damage, amateur repairs
d. Cleaning of video or audio heads.
g. Second hand products.
h. Refurbished products which are covered by a 6 month manufacturers warranty.
Version 1.2: 1
st
October 2007
Language Code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072
中文
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Português 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Turkmen 8475
Twi 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yoruba 8979
Zulu 9085
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
sgptt_1023/98_v3
Loading...
