USER MANUAL
EN
02
PLEASE READ THIS USER MANUAL CAREFULLY BEFORE USING THE MACHINE.
Page 2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons do not immerse
cord, plugs, or appliance in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Save these instructions.
SAVE THESE INSTRUCTIONS
Page 3
CAUTION
This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.
1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2. Never use warm or hot water to fill the water tank. Use cold water only.
3. Keep your hands and the cord away from hot parts of the appliance during
operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6. Do not use caramelized or flavored coffee beans.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available
and may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children or tripped
over.
Page 4
2
ENGLISH
Congratulations on your purchase of a Saeco Xsmall fully
automatic espresso machine!
To fully benet from the support that Philips Saeco oers,
please register your product at www.saeco.com/welcome.
The machine is made for preparing espresso coee using
whole coee beans and for dispensing steam and hot water.
In this user manual you will nd all the information you need
to install, use, clean and descale your machine.
Page 5
ENGLISH
3
CONTENTS
IMPORTANT..................................................................................................... 4
Safety Instructions .......................................................................................................................... 4
Warnings .........................................................................................................................................4
Cautions .......................................................................................................................................... 6
Compliance with Standards ............................................................................................................ 7
INSTALLATION ................................................................................................. 8
Product Overview ............................................................................................................................ 8
General Description ......................................................................................................................... 9
PREPARING FOR USE .......................................................................................10
Machine Packaging ....................................................................................................................... 10
Preparing for Use .......................................................................................................................... 10
USING THE MACHINE FOR THE FIRST TIME ........................................................12
Circuit Priming .............................................................................................................................. 12
Automatic Rinse/Self-Cleaning Cycle............................................................................................. 13
Manual Rinse Cycle........................................................................................................................ 14
“INTENZA+” Water Filter Installation ............................................................................................ 15
ADJUSTMENTS ................................................................................................17
Saeco Adapting System ................................................................................................................. 17
Adjusting the Ceramic Coee Grinder ............................................................................................ 17
Adjusting the Coee Length ......................................................................................................... 19
ESPRESSO AND COFFEE BREWING ....................................................................20
FROTHING MILK / BREWING A CAPPUCCINO ......................................................21
Frothing milk ................................................................................................................................ 21
Steam/Coee Switchover ..............................................................................................................23
Brewing a Cappuccino ................................................................................................................... 24
DISPENSING HOT WATER .................................................................................25
CLEANING AND MAINTENANCE ........................................................................26
Daily Cleaning of the Machine ....................................................................................................... 26
Daily Cleaning of the Water Tank ................................................................................................... 27
Daily Cleaning of Steam/Hot Water wand (Pannarello, If Supplied)............................................... 27
Weekly Cleaning of Steam/Hot Water Wand (Pannarello, If Supplied). .......................................... 28
Weekly Cleaning of the Brew Group and of the Coee Outlet Duct ................................................ 29
Monthly lubrication of the brew group ......................................................................................... 31
DESCALING .....................................................................................................32
Preparation ................................................................................................................................... 32
Descaling ...................................................................................................................................... 34
Rinsing .......................................................................................................................................... 35
INTERRUPTION OF THE DESCALING CYCLE ........................................................38
UNDERSTANDING THE DIFFERENT LIGHTS ........................................................40
Control Panel ................................................................................................................................. 40
TROUBLESHOOTING ........................................................................................43
ENERGY SAVING ..............................................................................................45
Stand-by ....................................................................................................................................... 45
Disposal ........................................................................................................................................ 45
TECHNICAL SPECIFICATIONS ............................................................................46
WARRANTY AND SERVICE ................................................................................46
Warranty ....................................................................................................................................... 46
Service .......................................................................................................................................... 46
ORDERING MAINTENANCE PRODUCTS ..............................................................47
Page 6
4
ENGLISH
IMPORTANT
Safety Instructions
This machine is equipped with safety devices. Nevertheless,
read and follow the safety instructions carefully and only use
the machine properly as described in these instructions to
avoid accidental injury or damage due to improper use of the
machine. Keep this user manual for future reference.
The term WARNING and this icon warn against possible
severe injuries, danger to life and/or damage to the machine.
The term CAUTIONand this icon warn against slight
injuries and/or damage to the machine.
Warnings
• Connect the machine to a wall socket with a voltage
matching the technical specications of the machine.
• Connect the machine to a earthed wall socket.
• Do not let the power cord hang over the edge of a table or
counter, or touch hot surfaces.
• Never immerse the machine, the mains plug or power cord
in water: Danger of electrical shock!
• Do not pour liquids on the power cord connector.
• Never direct the hot water jet towards body parts: Danger
of burning!
• Do not touch hot surfaces. Use handles and knobs.
• Remove the mains plug from the wall socket:
- if a malfunction occurs;
Page 7
ENGLISH
5
- If the machine will not be used for a long time;
- before cleaning the machine.
Pull on the mains plug, not on the power cord. Do not
touch the mains plug with wet hands.
• Do not use the machine if the mains plug, the power cord
or the machine itself is damaged.
• Do not make any modications to the machine or its
power cord. Only have repairs carried out by a service
centre authorised by Philips to avoid any hazard.
• The machine should not be used by children younger than
8 years old.
• The machine can be used by children of 8 years and upwards
if they have previously been instructed on the correct use of
the machine and made aware of the associated dangers or if
they are supervised by an adult.
• Cleaning and maintenance should not be carried out by
children unless they are more than 8 years old and supervised by an adult.
• Keep the machine and its power cord out of reach of children under 8 years old.
• The machine may be used by persons with reduced physical, sensory or mental capabilities or lacking sucient
experience and/or skills if they have previously been
instructed on the correct use of the machine and made
aware of the associated dangers or if they are supervised
by an adult.
• Children should be supervised to ensure that they do not
play with the machine.
• Never insert ngers or other objects into the coee
grinder.
Page 8
6
ENGLISH
Cautions
• The machine is for household use only. It is not intended
for use in environments such as canteens, sta kitchens of
shops, oces, farms or other work environments.
• Always put the machine on a at and stable surface.
• Do not place the machine on hot surfaces, directly next to
a hot oven, heater units or similar sources of heat.
• Only put roasted coee beans into the coee bean hopper.
If ground coee, instant coee, raw coee beans or any
other substance is put in the coee bean hopper, it may
damage the machine.
• Let the machine cool down before inserting or removing
any parts.
• Never use warm or hot water to ll the water tank. Use
only cold non-sparkling drinking water.
• Never clean with scrubbing powders or harsh cleaners.
Simply use a soft cloth dampened with water.
• Descale your machine regularly. The machine indicates
when descaling is needed. Not doing this will make your
appliance stop working properly. In this case repair is not
covered under your warranty!
• Do not keep the machine at temperature below 0 °C.
Residue water in the heating system may freeze and cause
damage.
• Do not leave water in the water tank if the machine is
not used over a long period of time. The water can get
contaminated. Use fresh water every time you use the
machine.
Page 9
ENGLISH
7
Compliance with Standards
The machine complies with art.13 of the Italian Legislative
Decree dated 25 July 2005, no. 151 “Implementation of the
Directives 2005/95/EC, 2002/96/EC and 2003/108/EC on the
restriction of the use of certain hazardous substances in electrical and electronic equipment, as well as waste disposal”.
This machine complies with EU Directive 2002/96/EC.
This Philips appliance complies with all the applicable standards and regulations relating to the exposure to electromagnetic elds.
Page 10
8
INSTALLATION
Product Overview
1
26
2
15
3
4
13 12
17
8
9
10
11
5
6 7
14
16
18 19 20
21 22 23 24 25
Page 11
General Description
1. Co ee bean hopper lid
2. Co ee bean hopper
3. Co ee dispensing spout
4. Full drip tray indicator
5. Co ee grounds drawer
6. Brew group
7. Service door
8. Control panel
9. Protective handle
10. Steam/hot water wand
11. Grill
12. Drip tray
13. Water tank
14. Power cord
15. Ceramic co ee grinder
16. Grinder adjustment key
17. Pannarello (optional - only available for certain models)
18. "Double co ee" light
19. Espresso button
20. Temperature light
21. No water light
22. Co ee button
23. Control dial
24. Warning light
25. ON/OFF button with machine ready light
26. Grinder adjustment knob
ENGLISH
9
Page 12
10
ENGLISH
PREPARING FOR USE
Machine Packaging
The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.
Preparing for Use
Remove the co ee bean hopper lid and the drip tray with grill from the
1
packaging.
Remove the machine from the packaging.
2
For best use, it is recommended to:
3
• Choose a safe, level surface, where there will be no danger of overturning the machine or being injured.
• Choose a location that is su ciently well-lit, clean and near an easily reachable socket.
• Allow for a minimum distance from the sides of the machine as
shown in the illustration.
Insert the drip tray with grill into the machine. Make sure it is fully
4
inserted.
Note:
The drip tray collects the water that comes out of the dispensing spout
during each rinse/self-cleaning cycle, as well as any co ee that might be
spilled during beverage brewing. Empty and wash the drip tray daily and
each time the full drip tray indicator is raised.
Caution:
NEVER remove the drip tray when the machine has just been turned
on. Wait a couple of minutes for the machine to carry out a rinse/selfcleaning cycle.
Page 13
MAX
ENGLISH
Remove the water tank.
5
Rinse the water tank with fresh water.
6
Fill the water tank with fresh water up to the MAX level and reinsert it
7
into the machine. Make sure it is fully inserted.
Caution:
Never fi ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.
Slowly pour the co ee beans into the co ee bean hopper.
8
Caution:
Only coff ee beans must be put into the coff ee bean hopper. If ground
coff ee, instant coff ee, raw coff ee beans or any other substance is put in
the coff ee bean hopper, it may damage the machine.
11
Put the lid on the co ee bean hopper.
9
Insert the plug into the socket located on the back of the machine.
10
Page 14
12
ENGLISH
Insert the plug at the other end of the power cord into a wall socket
11
with suitable power voltage.
Make sure that the control dial is on " " position.
12
Press the
13
will begin to ash quickly, indicating that the circuit has to be primed.
“ ”
ON/OFF button to turn the machine on; the
“ ”
light
USING THE MACHINE FOR THE FIRST TIME
When using the machine for the rst time, the following activities need to
happen:
1) You need to prime the circuit.
2) The machine will perform an automatic rinse/self-cleaning cycle.
3) You need to perform a manual rinse cycle.
Circuit Priming
During this process, fresh water ows through the internal circuit of the
machine and the machine warms up. This takes a few seconds.
Place a container (1L) under the steam/hot water wand or Pannarello
1
(if supplied).
Page 15
ENGLISH
Turn the control dial to the " " position.
2
When water dispensing stops, the “ ” light ashes slowly.
3
Turn the control dial to bring it back to the "
is in warm-up mode and the "
" light ashes slowly.
Automatic Rinse/Self-Cleaning Cycle
When warm-up has been completed, the machine automatically performs
a rinse/self-cleaning cycle of the internal circuits with fresh water. This
takes less than a minute.
Place the container under the co ee dispensing spout to catch the
1
small amount of water which will be dispensed.
" position. The machine
13
Flashing
Steady on
The " " light ashes slowly.
2
Wait for the cycle to nish automatically.
3
Note:
You can stop the dispensing process by pressing either the " " or the " "
button.
Wait for water dispensing to stop. The “ ” light shines steadily.
4
Page 16
14
ENGLISH
Steady on
Manual Rinse Cycle
During this process you activate the co ee brewing cycle and fresh water
ows through the steam/hot water circuit. This takes a few minutes.
Place the container under the co ee dispensing spout.
1
Check that the “ ” light is steady on.
2
Press the “ ” button. The machine starts brewing co ee.
3
Wait until brewing has been completed and empty the container.
4
Place a container under the steam/hot water wand (Pannarello, if sup-
5
plied).
Turn the control dial to the " " position. The " " light ashes slowly.
6
Dispense all the remaining water. The " " light shines steadily.
7
Page 17
ENGLISH
Turn the control dial to the " " position.
8
Fill the water tank again with fresh water and put it back into the ma-
9
chine. Now the machine is ready for brewing co ee.
Notes:
The automatic rinse/self-cleaning cycle is initiated when the machine has
been in stand-by mode, or turned o , for more than 15 minutes.
When you have not used the machine for 2 or more weeks you also have to
perform the manual rinsing cycle.
At the end of the cycle, it is possible to brew a co ee.
15
“INTENZA+” Water Filter Installation
We recommend you to install the “INTENZA+” water lter as this prevents
limescale build-up in your machine and preserves a more intense aroma of
your co ee.
The “INTENZA+” water lter can be purchased separately. For further details, please refer to the maintenance products page in this manual.
Water is a crucial part of every co ee, so it is very important to always have
it professionally ltered. Using the “INTENZA+” water lter will prevent
mineral deposits from building up and improve your water quality.
Remove the small white lter from the water tank and store it in a dry
1
place.
Page 18
16
ENGLISH
Remove the “INTENZA+” water lter from its packaging, immerse it ver-
2
tically (with the opening positioned upwards) in cold water and gently
press the sides so as to let the air bubbles out.
Set the “INTENZA+” water lter according to the hardness of the water
3
used:
A = Soft water
B = Hard water (standard)
C = Very hard water
Put the "INTENZA +" water lter into the empty water tank. Press it
4
down until it cannot move any further.
Steady on
Fill the water tank with fresh water and reinsert it into the machine.
5
Dispense all the water in the tank by using the hot water function (see
6
the “Dispensing Hot Water” section).
Remove the tank, ll it with fresh water up to the MAX level and place
7
it back into the machine.
When the operations described above have been completed, the “ ”
8
light shines steadily. Machine is ready to brew co ee.
Note:
We recommend replacing the "Intenza +" lter every 2 months.
Page 19
ENGLISH
17
ADJUSTMENTS
The machine allows for certain adjustments so that you can brew the best
tasting co ee possible.
Saeco Adapting System
Co ee is a natural product and its characteristics may change according to
its origin, blend and roast. The machine is equipped with a self-adjusting
system that allows the use of all types of co ee beans available on the
market except for raw, caramelized and avoured co ee beans. The machine automatically adjusts itself after brewing a certain number of cups of
co ee to optimise the extraction.
Adjusting the Ceramic Coff ee Grinder
Ceramic co ee grinders always guarantee accurate and perfect grinding
and coarseness for every co ee speciality.
This provides full aroma preservation, delivering a truly Italian taste in
every cup.
Warning:
Do not insert fi ngers or other objects. Only adjust the ceramic coff ee
grinder using the grinder adjustment key. The ceramic coff ee grinder
contains moving parts that may be dangerous.
You can adjust the ceramic grinders to set the co ee grinding to your
personal taste.
Warning:
You can only adjust the coff ee grinder settings when the machine is
grinding coff ee beans.
Remove the co ee bean hopper lid.
1
Page 20
18
ENGLISH
Make sure that the “ ” green light shines steadily and that the water
2
tank and co ee bean hopper are full.
Press the "
ing.
Note:
Use the co ee grinder adjustment key provided with the machine. You will
taste the di erence after brewing 2-3 cups of co ee. If co ee is watery or is
brewed slowly, change the co ee grinder settings.
While the co ee grinder is operating, press and turn the grinder adjust-
3
ment knob inside the co ee bean hopper one notch at a time.
Warning:
Do not turn the coff ee grinder more than one notch at the time to
prevent damage.
" espresso co ee button; the co ee grinder starts grind-
The reference marks inside the co ee bean hopper indicate the grind set-
4
ting. There are 5 di erent grind settings to choose, from position 1 (
coarse grind - lighter taste to position 2 (
1
2
When adjusting has been completed, put the lid back on the co ee
5
bean hopper.
) for ne grind - stronger taste.
) for
Page 21
ENGLISH
19
Adjusting the Coff ee Length
The machine allows the amount of brewed espresso co ee to be adjusted
according to taste and cup size.
Each time the “ ” espresso button or “ ” co ee button are pressed and
released, the machine brews a pre-set amount of co ee. Each button may be
individually programmed for a speci c brew setting.
The following procedure describes how to program the “ ” button.
Place a cup under the co ee dispensing spout.
1
Flashing
Press and hold the “ ” button for a few seconds; until the “ ” and “ ”
2
lights ash slowly.
Wait until the desired quantity is reached, then press the “ ” button
3
to stop brewing.
Now the “
will brew the same amount of espresso that was just programmed.
Same procedure applies to the “
” button is programmed; each time it is pressed, the machine
” co ee button.
Page 22
20
ENGLISH
ESPRESSO AND COFFEE BREWING
Before brewing co ee, make sure that the “ ” green light shines steadily
on and that the water tank and co ee bean hopper are full.
Steady on
Make sure that the control dial is on "
Place 1 or 2 cups under the co ee dispensing spout.
1
To brew an espresso, press the “ ” espresso button; to brew a co ee,
2
press the “
To dispense 1 cup of espresso, press the button once. To dispense 2
3
cups of espresso, press the button twice consecutively.
In this operating mode, the machine automatically grinds and doses the
correct amount of co ee. Brewing two cups of espresso requires two grinding and brewing cycles, automatically carried out by the machine; during
this time, the “
” co ee button.
” light shines steadily.
" position.
After the prebrewing cycle, co ee begins to pour out of the co ee
4
dispensing spout.
Brewing stops automatically when the preset level is reached. You
5
can press either the “
early.
” button or the “ ” button to stop brewing
Page 23
ENGLISH
21
FROTHING MILK / BREWING A CAPPUCCINO
Warning:
Danger of burning! Dispensing may be preceded by small jets of hot
water. The steam/hot water wand may reach high temperatures: never
touch it with bare hands. Use the appropriate protective handle only.
Frothing milk
When you plan to dispense steam right after turning on the machine or
after brewing a co ee, some water still present in the circuit may need to
be dispensed rst.
For this, follow the steps below:
Place a container under the steam/hot water wand (Pannarello, if sup-
1
plied).
Flashing
Turn the control dial to the " " position.
2
The “ ” light ashes during the preheating time required by the
3
machine.
Page 24
22
ENGLISH
Flashing
Steam dispensing will begin when the machine reaches the optimum
4
temperature.
Turn the control dial to the “ ” position to stop dispensing steam.
5
Fill 1/3 of a carafe with cold milk.
6
Note:
When preparing your cappuccino, use cold (~5°C / 41°F) milk with a protein
content of at least 3% to ensure optimum results. Whole milk or skimmed
milk may be used depending on individual taste.
Immerse the steam/hot water wand (Pannarello, if supplied) in the
7
milk to be heated and turn the control dial to the “
machine warms up and after a few seconds steam dispensing begins.
The "
" light ashes slowly.
” position. The
Page 25
ENGLISH
Froth the milk by gently swirling the container and moving it up and
8
down.
When the milk froth has the desired consistency, turn the control dial
9
back to the “
shines steadily.
Caution:
After using the steam to froth the milk, clean the Pannarello by
dispensing a small quantity of hot water into a container. For detailed
cleaning instructions please see the “Cleaning and Maintenance”
chapter.
After having dispensed steam, you rst need to cool down the machine
before you can brew an espresso or a co ee. For this, follow the steps
described below:
” position to stop dispensing steam. The " " light
23
Flashing quickly
Steam/Coff ee Switchover
Press the “ ” or “ ” button; the " " light ashes quickly to show
1
that the machine is overheated and cannot dispense co ee.
It is necessary to dispense a small amount of water to cool the ma-
2
chine. Place a container under the steam/hot water wand (Pannarello,
if supplied).
Page 26
24
ENGLISH
Turn the control dial to the " " position. The " " light ashes slowly.
3
Hot water will be dispensed.
4
Wait until the “ ” light shines steadily. Dispensing will stop automati-
5
cally.
Turn the control dial back to the " " position.
6
Now it is possible to brew an espresso or a co ee.
7
Brewing a Cappuccino
To prepare a cappuccino, place a cup with frothed milk under the co ee
dispensing spout and brew and espresso.
Page 27
Steady on
ENGLISH
25
DISPENSING HOT WATER
Warning:
Danger of burning! Dispensing may be preceded by small jets of hot
water. The steam/hot water wand may reach high temperatures: never
touch it with bare hands. Use the appropriate protective handle only.
Before dispensing hot water, check that the “ ” light is steady on. If
1
the light ashes slowly, wait for the machine to heat up.
Place a cup under the steam/hot water wand (Pannarello, if supplied).
2
Turn the control dial to the " " position. The " " light ashes slowly.
3
The machine is in its warm-up phase and dispenses hot water after a
few seconds.
To stop hot water dispensing, turn control dial back to the “ ” position.
4
The "
" light shines steadily.
Page 28
26
ENGLISH
CLEANING AND MAINTENANCE
Daily Cleaning of the Machine
Caution:
Timely cleaning and maintenance of your machine is very important
as it prolongs the life of your machine. Your machine is continuously
exposed to moisture, coff ee and limescale!
The activities you need to perform and their frequency are described
in detail in this chapter. Not doing this will ultimately make your machine stop working properly. This repair is NOT covered by warranty!
Note:
• Use a soft, dampened cloth to clean the machine.
• Do not immerse the machine in water.
• Do not wash any of its parts in the dishwasher.
• Do not use alcohol, solvents, and/or abrasive objects to clean the machine.
• Do not dry the machine and/or its parts using a microwave and/or
standard oven.
Empty and clean the co ee grounds drawer daily with the machine
1
turned on.
Other maintenance operations can only be carried out when the machine
is turned o and unplugged.
Empty and clean the drip tray. Perform this operation also when the
2
full drip tray indicator is raised.
Page 29
ENGLISH
Daily Cleaning of the Water Tank
Remove the small white lter or the Intenza+ water lter (if installed)
1
from the water tank and wash it with fresh water.
Put the small white lter back or the INTENZA+ water lter (if installed)
2
in its housing by gently pressing and turning it at the same time.
Fill the water tank with fresh water.
3
Daily Cleaning of Steam/Hot Water wand (Pannarello, If Supplied).
The steam/hot water wand (Pannarello, if supplied) needs to be cleaned
each time after frothing milk.
Note:
Some models of the machine are supplied with a Pannarello and some
are not. Please follow the cleaning steps, depending on the model of your
machine.
27
For machines without Pannarello:
Clean the steam/hot water wand with a wet cloth to remove milk
1
residues.
For machines with Pannarello:
Remove the external part of the Pannarello and wash it with fresh
1
water.
Page 30
28
ENGLISH
Weekly Cleaning of Steam/Hot Water Wand (Pannarello, If Supplied).
For machines without Pannarello:
Remove the protective handle from the steam/hot water wand.
1
Wash the protective handle with fresh water and dry it with a cloth.
2
Clean the steam/hot water wand with a wet cloth to remove milk
3
residues.
Put the protective handle back onto the steam/hot water wand.
4
For machines with Pannarello:
Remove the external part of the Pannarello.
1
Remove the upper part of the Pannarello from the steam/hot water
2
wand.
Wash the upper part of the Pannarello with fresh water.
3
Clean the steam/hot water wand with a wet cloth to remove milk
4
residues.
Put the upper part back into the steam/hot water wand (make sure it is
5
completely inserted).
Reassemble the external part of the Pannarello.
6
Page 31
ENGLISH
Weekly Cleaning of the Brew Group and of the Coff ee Outlet Duct
The brew group should be cleaned every time the co ee bean hopper is
lled or at least once a week.
Turn o the machine by pressing the "ON/OFF" button and unplug the
1
power cord.
Remove the co ee grounds drawer. Open the service door.
2
To remove the brew group, press the «PUSH» button and pull it by the
3
handle. Pull it out horizontally without turning it by pulling it by the
handle.
29
Clean the co ee outlet duct thoroughly with a spoon handle or with
4
another round-tipped kitchen utensil.
Thoroughly wash the brew group with fresh, lukewarm water and care-
5
fully clean the upper lter.
Caution:
do not use detergent or soap to clean the brew group.
Page 32
30
ENGLISH
Let the brew group air-dry thoroughly.
6
Thoroughly clean the inside of the machine using a soft, dampened
7
cloth.
Make sure the brew group is in the o position; the two reference signs
8
must match. If they do no match, proceed as described in step (9).
Gently pull down the lever on the back of the group until it is in con-
9
tact with the brew group base and the two reference signs on the side
of the brew group match.
Press the “PUSH” button rmly.
10
Make sure that the hook which locks the brew group is in the correct
11
position. If it is still in the downward position push it upward until it
locks correctly into place.
Insert the brew group in its seat again until it locks into place WITHOUT
12
pressing the “PUSH” button.
Insert the co ee grounds drawer. Close the service door.
13
Page 33
ENGLISH
31
Monthly lubrication of the brew group
Lubricate the brew group after approximately 500 cups of co ee or once a
month. The grease to lubricate the brew group can be purchased separately. For further details, please refer to the maintenance products page in
this manual.
Caution:
Before lubricating the brew group, clean it under fresh water and let it
dry, as described in the “Brew Group Weekly Cleaning” section.
Apply the grease evenly on both side guides.
1
Also lubricate the shaft.
2
Insert the brew group in its seat until it locks into place. (see “Brew
3
Group Weekly Cleaning” section).
Insert the co ee grounds drawer and close the service door.
4
Page 34
32
ENGLISH
DESCALING
When the " " orange light turns on, you need to descale the machine.
Descaling time: 30 minutes
Not doing this will ultimately make your machine stop working properly. In this case, repair is NOT covered by warranty.
Warning:
Use the Saeco descaling solution only. Its formula has been designed
to ensure better machine performance. The use of other products may
damage the machine and leave residues in the water.
The Saeco descaling solution can be purchased separately. For further
details, please refer to the maintenance products page in this manual.
Warning:
Never drink the descaling solution or any products dispensed until the
cycle has been carried out to the end. Never use vinegar as a descaling
solution.
Do not remove the brew group during the descaling cycle.
Preparation
1 Turn o the machine by pressing the ON/OFF “ ” button.
Note:
If you don't turn off machine, you'll be making a coff ee instead of
activating the descaling cycle!
Page 35
ENGLISH
2 Before beginning the descaling cycle, empty the drip tray and
reinsert it, remove the Pannarello and the "Intenza+" water lter if
installed.
33
H2O
MAX
3 Remove and empty the water tank. Pour in the entire content of
the Saeco descaling solution. Fill the water tank with fresh water
up to the MAX level. Put the water tank back into the machine.
4 Turn the control dial to the " " position.
Page 36
34
ENGLISH
5 Place a large container under the steam/water wand.
Descaling
6 Press the " " and " " buttons at the same time for 5 seconds.
7 The “ ” orange light starts ashing slowly and will continue to
do so during the whole descaling cycle. The machine dispenses internally at several one-minute intervals the descaling solution into
the drip tray. It does not dispense the descaling solution through
the steam/hot water wand.
This procedure takes approx. 5 minutes.
8 When the " " green light turns on, turn the control dial to the "
" position.
9 After approximately 1 minute, the machine dispenses at several
one-minute intervals through the steam/hot water wand until the
water tank is empty. This procedure takes approx. 15 minutes.
Page 37
H2O
MAX
ENGLISH
10 When the " " green light is ashing slowly, turn the control dial
to the "
turns on.
11 Remove and empty the container placed under the water\steam
wand and the drip tray, then place them back in position.
Rinsing
12 Remove the water tank, rinse it and ll it up with fresh water up
to the MAX level. If the water tank is not lled up to MAX level, the
machine might require more rinse cycles. Put the water tank back
into the machine.
" position. The “ ” light turns o and the “ ” red light
35
13 When the “ ” green light turns on, turn the control dial to the " "
position. The machine performs a short circuit priming.
The “
” orange light ashes double during the whole rinse cycle.
Page 38
36
ENGLISH
14 When the “ ” green light is ashing slowly, turn the control dial
to the "
15 The machine dispenses internally directly into the drip tray. It does
not dispense through the steam/hot water wand.
16 When the “ ” green light turns on, turn the control dial to the "
wand.
Note:
if you wish to interrupt dispensing (for example to empty the container),
turn the control dial to the "
position to restart dispensing.
" position.
" position. The machine now dispenses from the steam/water
" position. Turn the control dial to the " "
17 When the rinse cycle has been completed, the “ ” orange light
turns o and the “
position.
Note:
If the “
water tank has not been lled to the MAX level for the rinse cycle. Fill the
water tank with fresh water up to the MAX level. Turn the control dial to
the "
” red light turns o and the “ ” orange light is still ashing, the
" position. Repeat point 16.
18 The “ ” green light ashes. The machine warms up and performs
the rinse cycle.
” light ashes. Turn the control dial to the " "
Page 39
ENGLISH
19 When the “ ” green light shines steadily, remove the drip tray,
rinse it and place it back.
20 Reinstall the Pannarello (if any).
37
H2O
MAX
21 Remove the water tank and rinse it. Reinstall the "Intenza+" water
lter (if any). Fill the water tank with fresh water up to the MAX
level. Place it back in the machine.
20 The machine is ready for use.
Page 40
38
H2O
ENGLISH
MAX
INTERRUPTION OF THE DESCALING CYCLE
Once you have started the descaling cycle, you must complete it till the
very end without turning o the machine.
In case you get stuck during the descaling procedure, you can exit by
unplugging the power cord. If that happens follow the steps below.
Empty the drip tray.
1
Empty and rinse carefully the water tank, then ll it with fresh water up
2
to the MAX level.
Turn on the machine. The machine will start the automatic rinse cycle.
3
Place a container under the steam/hot water dispensing spout.
4
Page 41
ENGLISH
Turn the control dial to the “ ” position and dispense 300 ml of water.
5
Turn the control dial to the “ ” position.
6
Place the container under the co ee dispensing spout.
7
39
Press the “ ” button to brew a co ee.
8
Empty the container. The machine is ready for use
9
Note:
If the “
chine at your earliest convenience.
” orange led does not turn of you still have to descale your ma-
Page 42
40
ENGLISH
UNDERSTANDING THE DIFFERENT LIGHTS
Control Panel
Light Signals Causes Solutions
The machine has reached the right
temperature and is ready:
- for co ee brewing;
- for hot water dispensing;
- for steam dispensing.
Steady on
Flashing slowly
Flashing quickly
Steady on and
light steady on
The machine is warming up to brew
espresso and dispense hot water or steam.
The machine is performing the rinse/selfcleaning phase.
The machine is dispensing.
Overheating protection enabled.
Co ee cannot be brewed yet.
The machine needs descaling! Not descaling your machine will ultimately make it stop
The machine ends the rinse/self-cleaning cycle automatically.
You can interrupt the rinse/self-cleaning cycle by pressing the “
” or “ ” buttons.
It is necessary to dispense some water to cool the machine.
working properly.
This repair is not covered by your warranty.
Page 43
Light Signals Causes Solutions
ENGLISH
41
Flashing slowly and light
steady on.
and fl ashing slowly.
Flashing slowly and light
steady on.
The machine is in the descaling mode.
The machine is in the descaling mode.
The machine is in the descaling mode. Rinse the water tank and ll it up to the MAX level.
The machine is programming the amount
of co ee to be brewed.
Turn the control dial to the “
Complete the descaling procedure.
Turn the control dial to the “
Complete the descaling procedure.
Complete the descaling procedure.
Press the button as soon as the desired amount of co ee
is reached.
” position.
” position.
and lights fl ashing
slowly
Steady on and light
fl ashing slowly
Steady on
The machine is brewing a double co ee.
Low water level. Fill the water tank with fresh water. After putting the lled water
tank back, the indicator light turns o .
Page 44
42
ENGLISH
Light Signals Causes Solutions
The co ee bean hopper is empty.
and steady on
The co ee grounds drawer is full.
steady on
The water circuit is empty. Fill the water tank with fresh water and dispense hot water.
Fill the co ee bean hopper with co ee beans. Push the “
“ ” button to make an espresso or co ee.
With the machine turned on, empty the co ee grounds drawer.
If the co ee grounds drawer is emptied when the machine is o ,
the co ee cycle counter is not reset. Wait until the
ashing before putting back the co ee grounds drawer.
Flashing quickly
Brew group is not inserted. The co ee grounds
drawer is not inserted.
Service door is open.
Control dial is not in correct position.
Check that all parts have been correctly placed and that the door is
closed. The light will now turn o .
” or
light starts
Flashing slowly
and
fl ashing slowly
All lights are fl ashing at the
same time
A fault has occurred in the brew group. Try to brew another espresso or another co ee.
The machine is out of order. Turn o the machine. Turn it back on after 30 seconds.
Try this 2 or 3 times.
If the machine does NOT start, contact the Philips Saeco hotline.
Page 45
ENGLISH
43
TROUBLESHOOTING
This chapter summarizes the most common problems you could encounter with your machine. If you are unable to solve the problem with the
information below, visit www.saeco.com/support for a list of frequently
asked questions or contact the Philips Saeco hotline in your country. The
contact details can be found in the warranty booklet packed separately or
on www.saeco.com/support.
Problem Possible Cause Solution
The machine does not turn
on.
Coee is not hot enough. The cups are cold. Preheat the cups with hot water.
No hot water or steam is
dispensed.
Espresso does not have
enough crema (see note).
The machine takes a long
time to warm up or the
amount of water dispensed
from the hot steam/hot
water wand is too small.
The brew group cannot be
removed.
The brew group cannot be
inserted.
The machine is not connected to
the power source.
The hole of the steam/hot water
wand is clogged.
Pannarello is dirty (if supplied). Clean the Pannarello.
The coee blend is unsuitable,
the coee is not freshly roasted or
the grind is too coarse.
The machine water circuit is obstructed by limescale build-up.
The brew group is out of place. Turn on the machine. Close the ser-
The coee grounds drawer is
inserted.
The brew group is not in the o
position.
The gearbox is not in the correct
position.
Connect the machine to the power
source.
Clean the hole of the steam/hot
water wand using a pin.
Make sure that the machine is o
and has cooled down before performing this operation.
Change coee blend or adjust the
ceramic coee grinder as explained
in the “Adjusting the Ceramic Coee
Grinder” section.
Descale the machine.
vice door. The brew group automatically returns to the correct position.
Remove the coee grounds drawer
before removing the brew group.
Make sure that the brew group in
the o position, as described in
the “Weekly Cleaning of the Brew
Group” chapter.
Insert the drip tray and the coee
grounds drawer. Close the service
door.
Turn on the machine without inserting the brew group. The gearbox returns to the correct position. Turn o
the machine and reinsert the brew
group as described in the “Weekly
Cleaning of the Brew Group” chapter
Page 46
44
ENGLISH
Problem Possible Cause Solution
The descaling cycle cannot
be nished.
The machine grinds the
coee beans but no coee is
brewed (see note).
The coee is too weak (see
note).
Coee is brewed slowly (see
note).
Most probably you have used not
enough water for rinsing.
The brew group is dirty. Clean the brew group (“Brew Group
The water circuit is not primed. Fill the water tank with fresh water
This might occur when the machine is automatically adjusting
the dose.
The coee dispensing spout is
dirty.
This might occur when the machine is automatically adjusting
the dose.
The ceramic coee grinder is set
to a coarse grind.
The coee grind is too ne. Change coee blend or adjust the
Unplug the power cord and follow
the instructions described in the
sector “ Interruption of the descaling
cycle”.
Cleaning” section).
and dispense hot water.
Brew a few cups of espresso coee
as described in the “Saeco Adapting
System” section.
Clean the coee dispensing spout.
Brew a few cups of espresso coee
as described in the “Saeco Adapting
System” section.
Adjust the ceramic coee grinder to
a ner setting (see the “Adjusting the
Ceramic Coee Grinder” section).
grind setting as explained in the “Adjusting the Ceramic Coee Grinder”
section.
The water circuit is not primed. Fill the water tank with fresh water
The brew group is dirty. Clean the brew group (“Brew Group
The drip tray gets lled although no water is drained.
Note:
These problems can be considered normal if the coee blend has been changed or if the machine has just been
installed. In this case, wait until the machine performs a self-adjusting operation as described in the “Saeco Adapting System” section.
Water is drained automatically by
the machine into the drip tray to
manage the rinsing of the circuits.
and dispense hot water.
Cleaning” section).
This is a standard operating proce-
dure.
Page 47
ENGLISH
45
ENERGY SAVING
Stand-by
The machine is designed for energy saving- proven by the Class A energy
label.
After 30 minutes of inactivity, the machine turns o automatically.
Disposal
Do not throw away the machine with the normal household waste at the
end of its life, but hand it in at an ocial collection point for recycling. By
doing this, you help to preserve the environment.
Packaging materials can be recycled.
- Machine: unplug the machine and cut the power cord.
- Deliver the appliance and power cord to a service centre or public
waste disposal facility.
This product complies with EU Directive 2002/96/EC.
The symbol on the product or on the packaging indicates that this product
may not be treated as household waste, instead it shall be handed over to
the applicable collection point for the recycling of electrical and electronic
equipment.
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling this product,
please contact your local city oce, your household waste disposal service
or the shop where you purchased the product.
Page 48
46
ENGLISH
TECHNICAL SPECIFICATIONS
The manufacturer reserves the right to make changes to the technical
specications of the product.
Nominal Voltage - Power Rating
- Power Supply
Housing material ABS - Thermoplastic
Size (w x h x d) 295 x 325 x 420 mm - 11.5” x 13” x 16.5”
Weight 6.9 kg - 15 lbs
Power cord length 800 - 1200 mm / 31.5” - 47”
Control panel Front panel
Pannarello (only available for
certain models)
Cup sizes Up to 95mm
Water tank 1.0 litres – 33 oz. / removable
Coee bean hopper capacity 200 g / 7.0 oz.
Coee grounds drawer capacity 8
Pump pressure 15 bar
Boiler Stainless Steel
Safety devices Thermal fuse
See data plate on the inside of the
service door
Special for cappuccinos
WARRANTY AND SERVICE
Warranty
For detailed information on your warranty and related conditions, please
read the warranty booklet supplied separately.
Service
We want to ensure that you remain satised with your machine.
If you have not already done so, please register your purchase at
www.saeco.com/welcome. This will enable us to stay in contact with you
and send you cleaning and descaling reminders.
For service or support, please visit the Philips website at www.saeco.com/
support or contact the Philips Saeco hotline in your country.
The contact details can be found in the warranty booklet packed separately or on www.saeco.com/support.
Page 49
ENGLISH
ORDERING MAINTENANCE PRODUCTS
For cleaning and descaling, use Saeco maintenance products only. You
can purchase the products at the Philips online shop (if available in your
country) at www.shop.philips.com/service, from your local dealer or
authorised service centres.
If you have any di culties obtaining maintenance products for your machine, please contact the Philips Saeco hotline in your country.
The contact details can be found in the warranty booklet supplied separately or on www.saeco.com/support.
Overview of maintenance products
INTENZA+ WATER FILTER CA6702
GREASE HD5061
47
DESCALING SOLUTION CA6700
MAINTENANCE KIT CA 6706
Page 50
Page 51
Page 52
02
Rev.00 del 15-06-14
The manufacturer reserves the right to make changes without prior notice.
www.philips.com/saeco
EN
02
Loading...
