Philips HD2145 User Manual
User Manual
HD2145
EN
Contents
1 Important 4
Power failure backup
function 7
Electromagnetic elds
(EMF) 7
2 Your All-in-One cooker 8
What’s in the box 8
Product overview 9
Control panel overview 10
3 Using your All-in-One
cooker 11
Before rst use 11
Cooking program 12
Preparations before
cooking 13
Pressure cooking 14
Adding ingredient 16
Multi-cooking 17
Source thickening 18
Preset time for delayed
cooking 19
Setting up child lock 19
Setting up My Favourite
menu 20
4 Cleaning and Maintenance 21
Inner lid 21
Steam valve 21
Floater 21
Pressure regulator 22
Interior 22
Exterior 22
Accessories and inner pot 22
5 Recycling 23
6 Guarantee and service 23
7 Specications 24
8 Troubleshooting 25
3
EN
1 Important
Read this safety leaet carefully before
you use the appliance and save it for
future reference.
Danger
•
The appliance must not
be immersed.
Warning
•
This appliance is
intended to be used in
household and similar
applications such as:
•
sta kitchen areas
in shops, oces
and other working
environments;
•
farm houses;
•
by clients in hotels,
motels and other
residential type
environments;
•
bed and breakfast type
environments.
This appliance is not
•
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their
safety.
•
Children should be
supervised to ensure that
they do not play with the
appliance.
•
If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
agent or similarly
qualied persons in order
to avoid a hazard.
•
The appliance is not
intended to be operated
by means of an external
timer or a separate
remote-control system.
•
The ducts in the pressure
regulator allowing the
escape of steam should
be checked regularly to
ensure that they are not
blocked.
•
The container must not
be opened until the
pressure has decreased
suciently.
4
EN
•
WARNING: Make sure
to avoid spillage on the
power connector to avoid
a potential hazard.
•
Always follow the
instructions and use the
appliance properly to
avoid potential injury.
•
THE surface of the
heating element is
subject to residual heat
after use.
•
Use a clean and soft cloth
to clean the surfaces in
contact with food.
•
Only connect the
appliance to a grounded
power outlet. Always
make sure that the plug
is inserted rmly into the
power outlet.
•
Do not use the appliance
if the plug, the power
cord, the inner pot, the
sealing ring, or the main
body is damaged.
•
Do not let the power cord
hang over the edge of the
table or worktop on which
the appliance stands.
•
Make sure the heating
element, the temperature
sensor, and the outside
of the inner pot are clean
and dry before you put
the plug in the power
outlet.
•
Do not plug in the
appliance or turn the
control knob with wet
hands.
•
Make sure the power
socket is clean and dry
before you plug in the
appliance.
•
Do not use the appliance
if too much air or steam
is leaking from under the
top lid.
•
When cooking soup or
viscous liquid, do not
release pressure by
turning the pressure
regulator to the steam
vent position, otherwise
liquid might spurt from
the pressure regulator
valve. Wait until the
pressure is naturally
released and the oater
has dropped to open the
top lid.
5
EN
Caution
•
Never use any
accessories or parts from
other manufacturers or
that Philips does not
specically recommend. If
you use such accessories
or parts, your guarantee
becomes invalid.
•
Do not expose the
appliance to high
temperatures, nor
place
it on a working or still hot
stove or cooker.
Do not expose the
•
appliance to direct
sunlight.
Place the appliance on
•
a stable, horizontal, and
level surface.
Do not use the handle on
•
the top lid to move the
appliance, use the side
handles instead.
When pressure is being
•
released from the
pressure regulator valve,
hot steam or liquid will be
ejected. Keep hands and
face away from the steam
vent.
•
Always put the inner pot
in the appliance before
you put the plug in the
6
power outlet and switch
it on.
•
Do not place the inner
pot directly over an open
re to cook food.
•
Do not use the inner pot
if it is deformed.
•
Make sure that the
sealing ring is clean and
in good condition.
•
The accessible surfaces
may become hot
when the appliance is
operating. Take extra
caution when touching
the surfaces.
•
Beware of hot steam
coming out of the oating
valve and pressure
regulator valve during
cooking or when you
open the lid. Keep hands
and face away from the
appliance to avoid the
steam.
•
Do not lift and move
the appliance while it is
operating.
•
Do not exceed the
maximum water level
indicated in the inner pot
to prevent overow.
•
Do not place the cooking
utensils inside the pot
while cooking.
EN
•
Only use the cooking
utensils provided. Avoid
using sharp utensils.
•
To avoid scratches, it is
not recommended to
cook ingredients with
crustaceans, shellsh and
meats with protruding
bones. Remove the hard
shells or excessive bone
before cooking.
•
Do not place a magnetic
substance on the lid. Do
not use the appliance
near a magnetic
substance.
•
Always let the appliance
cool down to room
temperature before you
clean or move it.
•
Always clean the
appliance after use.
The detachable
inner lid, including its
components can be put
into the dishwasher for
clean, but other parts
of the appliance can
not be washed in the
dishwasher.
•
Always unplug the
appliance if not used for a
longer period.
•
If the appliance is
used improperly or for
professional or semiprofessional purposes, or
if it is not used according
to the instructions in
this safety leaet, the
guarantee becomes
invalid and Philips refuses
liability for any damage
caused.
•
Visit www.philips.com/
support to download the
user manual..
Power failure backup
function
This appliance has a backup function
that reserves the status before a power
failure.
•
If the power failure occurs during
a cooking process, and the power
supply is resumed within 30 minutes,
the countdown of the cooking time
continues where it is left o.
•
If the power failure occurs when the
appliance is at preset mode, and the
power supply is resumed within 30
minutes, the countdown of the preset
time continues where it is left o.
•
If the power supply is not resumed
within 30 minutes, the appliance
might not continue with the previous
working process, but stay in standby
mode.
Electromagnetic elds
(EMF)
This Philips appliance complies with all
applicable standards and regulations
regarding exposure to electromagnetic
elds.
7
EN
2 Your All-in-One cooker
Congratulations on your purchase, and welcome to Philips!
To fully benet from the support that Philips oers, register your product at
www.Philips.com/welcome.
What’s in the box
Main unit Steaming plate
Inner Pot Rice&Soup ladle
Measuring cup Power cord
detachable inner lid User manual
Recipe book Warranty card
www.philips.com/welcome
User Manual
www.philips.com/welcome
Recipe Book
www.philips.com/welcome
Warranty
8
EN
Product overview
a Top lid i Water level indication
b
Sealing ring
c Detachable inner lid k Temperature controller
d Cap nuts l Power socket
e Safety valve m Lid open button
f Anti-block cap n Lid lock/unlock handle
g Floating valve o Steam valve
h Inner pot p Pressure regulator
a
b
c
d
e
f
g
h
i
j
k
j
Control panel
p
o
n
m
l
9
