Philips FW560C User Manual [en, es, fr]
rW 560C
IW&20C Mini IfïFi System
m
Owner's IVli.innnI
MecJe irertiploi
Instrucriivo cle iTioriojc'e
Toll Free Help Line
Ligne d'assistance en service libre
Línea de ayuda telefónica sin cargo
531-0039
Return your Warranty Registration card today to
ensure you receive all the benefits you’re entitled to.
Once your Philips Magnavox purchase is registered, you're eligible
to receive all the privileges of owning a Philips Magnavox product.
^Warranty i
Verification
Registering your product within 10 days
confirms your right to maximum protection
under the terms and conditions of your
Philips Magnavox warranty.
Know these
symbols
^ Owner I
Confirmation
Your completed Warranty Registration
Card serves as verification of ownership in
the event of product theft or loss.
RISK OF ELECTRIC SHOCK
A
CAUTION: TO REOUCE THE RISK OF ELECTRIC SHOCK. DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
DO l\IOT OPEN
So complete and return the Warranty Registration Card enclosed
with your purchase at once. And take advantage of these
important benefits.
^ Model I
Registration
Returning your Warranty Registration Card
right away guarantees you’ll receive all
the information and special offers which you
qualify for as the owner of your model.
For Customer Use
Enter below the Serial No. which is located on the
A
rear of the cabinet. Retain this information for
future reference.
Model No. ______________________________________________
Serial No.
_______________________________________________
A
A
This “bolt of lightning” indicates uninsulated material
within your unit may cause an electrical shock. For the
safety of everyone in your household, please do not
remove product covering.
The “exclamation point” calls attention to features for
which you should read the enclosed literature closely to
prevent operating and maintenance problems.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN
OR MOISTURE.
CAUTION: To prevent electric shock, match wide
blade of plug to wide slot, and fully insert.
MAC5097
PHILIPS
Visit our World Wide Web Site at http://www.magnavox.com
PHILIPS
MAGNAVOX
Congratulations on your purchase,
and welcome to the **family!**
Dear Philips Magnavox product owner:
Thank you for your confidence in Philips Magnavox.You’ve
selected one of the best-built, best-backed products available
today. And we’ll do everything in our power to keep you
happy with your purchase for many years to come.
As a member of the Philips Magnavox “family,” you’re
entitled to protection by one of the most comprehensive
warranties and outstanding service networks in the
industry.
What’s more, your purchase guarantees you’ll receive all
the information and special offers for which you qualify,
plus easy access to accessories from our convenient home
shopping network.
And most importantly you can count
on our uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome-and thanks for
investing in a Philips Magnavox product.
Sincerely,
Robert Minkhorst
President and Chief Executive Officer
P.S. Remember, to get the most from your Philips
Magnavox product, you must return your
Warranty Registration Card within 10 days. So
please mail it to us right now!
CAUTION
A
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
A
A
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
This symbol warns the user that uninsulated voltage
within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make
any kind of contact with any inside part of this unit
This symbol alerts the user that important literature
concerning the operation and maintenance of this
unit has been included. Therefore, it should be read
carefully in order to avoid any problems.
\K
AVIS
A
Attention: Afin de prévenir le risque de chocs électriques,
Toute réparation devrait être confiée à un personnel qualifié.
A
A
RISQUE DE CHOCS ELECTRIQUES
NE PAS OUVRIR
ne pas retirer les vis.
Ce symbole indique la présence d'une tension
suffisamment élevée pour engendrer un risque de
chocs électriques.
Ce symbole indique que le manuel d'installation
fourni avec l'appareil contient d'importantes
recommandations quant au fonctionnement et
à l'entretien de ce dernier.
\ж
AVISO
A
Atención: Para reducir el riesgo de choque elécrico,
En su interior no hay piezas que el usuario pueda reparar.
A
A
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
no quite la tapa (o el panel posterior).
Para servicio dirijase a personal calificado.
Este símbolo tiene por finalidad advertir al usuario de
la presencia de tensión peligrosa no aislada dentro de
la caja del aparato, que puede ser lo suficientemente
fuerte para constituir un peligro de choque eléctrico.
Este símbolo sirve para advertir al usuario de la
presencia de instrucciones de manejo y
mantenimiento (servicio) importantes en el manual
que acompaña al aparato.
A
WARNING
To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION
Use of controls or adjustments or performance of
procedures other than herein may result in
hazardous radiation exposure.
The set complies with the FCC-Rules, Part 15 and with 21
CFR 1040.10.
Canada
This digital apparatus does not exceed the Class B limits
for radio noise emissions from digital apparatus as set out
in the Radio Interference Regulations of the Canadian
Department of Communications.
AVIS
Afin de réduire tout risque d'incendie ou de choc
électrique, il ne faut pas exposer cet appareil à la
pluie ou à l'humidité.
AHENTION
L'utilisation des commandes ou réglages ou le nonrespect des procédures ci-incluses peuvent se
traduire par une exposition dangereuse à
l'irradiation.
L'appareil répond aux normes FCC, Part 15 et 21 CFR
1040.10.
Canada
Cet appareil numérique n'emet pas de bruits
radioélectriques dépassant les limites applicables aux
appareils numériques de Class B prescrites dans le
Règlement sur le Brouillage Radioélectrique édicté par le
Ministère des Communications du Canada.
AVISO
Para reducir el riesgo de fuego o choque eléctrico,
no exponga el aparato a la lluvia o humedad.
ATENCIÓN
El uso de mando o ajustes o la ejecuccién de
métodos que no sean los aquí descritos puede
ocasionar peligro de exposición a radiación.
El aparato cumple las normas FCC, Parte 15 y 21 CFR
1040.10.
México
Es necesario que lea cuidadosamente su instructivo de
manejo.
PRECAUCION - ADVERTENCIA
I NO ABRIR, RIESGO DE CHOQUE ELECTRICO I
I
VERIFIQUE QUE EL VOLTAJE DE ALIMENTACION
__________
I SEA EL REQUERIDO PARA SU APARATO
PARA EVITAR EL RIESGO DE CHOQUE ELECTRICO, NO QUITE LA TAPA;
EN CASO DE REQUERIR SERVICIO, DIRIJASE AL PERSONAL AUTORIZADO DE PHILIPS.
ATENCION
ÑOM
Index
ENGLISH Page
General/Safety Information
Preparation
Controls...............................................................12-13
Operating the System
CD.........................................................................16-18
Tuner....................................................................19-20
Tape
Aux.............................................................................22
Clock/Timer..............................................................23
Recording............................................................24-25
Maintenance.............................................................25
Specifications
Troubleshooting
........................................................
.....................................................................
...........................................................
......................................................
.................................
......................................
6-9
10-11
14 -15
21-22
26
27
FRANÇAIS Page
Généralités / Informations relatives
à la sécurité.......................................................30 - 33
Opérations Préalables
Commandes........................................................36-38
Utilisation de L'appareil..................................38 - 39
Lenteur de Disques Compacts........................40 - 42
Syntoniseur.......................................................43 - 44
Platine Cassette................................................45 - 46
Aux.............................................................................46
Enregistrement.................................................47 - 48
Horloge / Minuterie
Entretien....................................................................50
Caractéristiques.......................................................51
Remèdes en cas de panne...............................52 - 53
.......................................
........................................
34-35
49 - 50
ESPAÑOL Página
Información General / de Seguridad
Preparativos.....................................................60 - 61
Controles...........................................................62 - 64
Funcionamiento del Sistema
Reproductor de CD..........................................66 - 68
Sintonizador
Reproductor de Casete
Aux.............................................................................72
Reloj/Temporizador
Grabación............................................................74-75
Mantenimiento
Especificaciones
Solución de Problemas
.....................................................
..........................................
.......................................................
.......................................................
............................
...................................
...........................................
............
56 - 59
64-65
69 - 70
71 - 72
72-73
75
76
77
SAFETY INSTRUCTIONS - Bead before operating equipment
This product was designed and manufactured to meet strict quality and safety standards.
There are, however, some installation and operation precautions which you should be
particularly aware of.
1.
Read Instructions - All the safety and operating instructions should be read
before the appliance is operated.
2.
Retain Instructions - The safety and operating instructions should be retained
for future reference.
3.
Heed Warnings - All warnings on the appliance and in the operating instructions
should be adhered to.
4.
Follow Instructions - All operating and use instructions should be followed.
Water and Moisture - The appliance should not be used near water - for
5.
example, near a bathtub, washbowl, kitchen sink, laundry tub or swimming pool,
or in a wet basement.
6.
Carts and Stands - The appliance should be used only with a cart or stand that
is recommended by the manufacturer.
6A.
7.
Wall or Ceiling Mounting - The appliance should be mounted to a wall or
ceiling only as recommended by the manufacturer.
8.
Ventilation - The appliance should be situated so that its location or position
does not interfere with its proper ventilation. For example, the appliance should
not be situated on a bed, sofa, rug, or similar surface that may block the
ventilation openings; or, placed in a built-in installation, such as a bookcase or
cabinet that may impede the flow of air through the ventilation openings.
9.
Heat - The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including amplifiers) that
produce heat.
10.
Power Sources - The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked on the appliance.
Grounding or Polarization - Precautions should be taken so that the grounding-
11.
or polarization means of an appliance is not defeated.
An appliance and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
CAUTION : To prevent electric shock, match the
wide blade of this plug to the wide slot and fully insert.
Do not use this (polarized) plug with an extension cord,
receptacle or other outlet unless the blades can be fully inserted to prevent blade
exposure.
AC
Polarized Plug
12. Power Cord Protection - Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cords and plugs, convenience receptacles, and the point
where they exit from the appliance.
13. Cleaning - The appliance should be cleaned only as recommended by the
manufacturer.
14. Power Lines - An outdoor antenna should be located away from power lines.
15. Outdoor Antenna Grounding - If an outside antenna is connected to the
receiver, be sure the antenna system is grounded so as to provide some protection
against voltage surges and built up static charges.
Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides
information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of grounding
connectors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode. See Figure below.
16. Nonuse Periods - The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
17. Object and Liquid Entry - Care should be taken so that objects do not fall and
liquids are not spilled into the enclosure through openings.
18. Damage Requiring Service - The appliance should be serviced by qualified
service personnel when;
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a marked
change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
19. Servicing - The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing should be referred to
qualified service personnel.
SAFETY INSTRUCTtONS
Note to the CATV system installer
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Example of Antenna Grounding as
per NEC - National Electrical Code
;y.;:
92/11
EL 4562-1
LIMITED WARRANTY
AUDIO SYSTEM
One Year Free Labor
One Year Free Service on Parts
This product must be carried in for repair.
WHO IS COVERED?
You must have proof of purchase to receive warranty
service. A sales receipt or other document showing that
you purchased the product is considered proof of purchase.
WHAT IS COVERED?
Warranty coverage begins the day you buy your product.
For one year thereafter, all parts will be repaired or replaced,
and labor is free. After one year from the day of purchase,
you pay for the replacement or repair of all parts, and for
all labor charges.
All parts, including repaired and replaced parts, are covered
only for the original warranty period. When the warranty
on the product expires, the warranty on ail replaced and
repaired parts also expires.
WHAT IS EXCLUDED?
Your warranty does not cover:
• labor charges for installation or setup of the product,
adjustment of customer controls on the product, and
installation or repair of antenna systems outside of the
product.
• product repair and/or part replacement because of misuse,
accident, unauthorized repair or other cause not within
the control of Philips Consumer Electronics Company.
• reception problems caused by signal conditions or cable
or antenna systems outside the unit.
• a product that requires modification or adaptation to
enable it to operate in any country other than the
country for which it was designed, manufactured,
approved and/or authorized, or repair of products
damaged by these modifications.
• incidental or consequential damages resulting from the
product. (Some states do not allow the exclusion of
incidental or consequential damages, so the above
exclusion may not apply to you.This includes, but is not
limited to, prerecorded material, whether copyrighted or
not copyrighted.)
• a product that is used for commercial or institutional
purposes.
WHERE IS SERVICE AVAILABLE?
Warranty service is available in all countries where the
product Is officially distributed by Philips Consumer
Electronics Company. In countries where Philips Consumer
Electronics Company does not distribute the product, the
local Philips service organization will attempt to provide
service (although there may be a delay if the appropriate
spare parts and technical manual(s) are not readily
available).
MAKE SUREYOU KEER..
Please keep your sales receipt or other document showing
proof of purchase. Attach it to this owner’s manual and
keep both nearby. Also keep the original box and packing
material in case you need to return your product.
BEFORE REQUESTING SERVICE...
Please check your owner’s manual before requesting
service. Adjustments of the controls discussed there may
save you a service call.
TO GET WARRANTY SERVICE IN
U.S.A., PUERTO RICO OR U.S. VIRGIN
ISLANDS...
Take the product to a Philips factory service center (see
enclosed list) or authorized service center for repair.When
the product has been repaired, you must pick up the unit at
the center. Centers may keep defective parts.
(In U.S.A., Puerto Rico and U.S.Virgin Islands, all implied
warranties, including implied warranties of merchantability
and fitness for a particular purpose, are limited in duration
to the duration of this express warranty. But, because some
states do not allow limitations on how long an implied
warranty may last, this limitation may not apply to you.).
TO GET WARRANTY SERVICE IN CANADA...
Please contact Philips at:
1-800-661-6162 (French Speaking)
1-800-363 7278 (English Speaking)
(In Canada, this warranty is given in lieu of all other
warranties. No other warranties are expressed or implied,
including any implied warranties of merchantability or
fitness for a particular purpose. Philips is not liable under
any circumstances for any direct, indirect, special, Incidental
or consequential damages, howsoever incurred, even if
notified of the possibility of such damages.)
REMEMBER...
Please record the model and serial numbers found on the
product below. Also, please fill out and mail your warranty
registration card promptly. It will be easier for us to notify
you if necessary.
MODEL#
SERIAL#
This warranty gives you specific legal rights. You may have other
rights which vary from state/province to state/province.
_______________________________________________________
________________________________________________________
Philips Service Company, P.O. Box 555, Jefferson
City,Tennessee 37760,(423) 475-8869
EL4965E005 /MAC4110/1-97
GENERAL INFORMATION
General Information
• The typeplate (which contains the serial
numher) is located at the rear of the system.
• Recording is permissible if copyright or other
rights of third parties are not infringed.
• This device complies with part 15 of FCC rules.
Operation is subject to the following two
conditions:
- This device may not cause harmful
interference, and
- This device must accept any interference
received, including interference that may
cause undesired operation.
Environmental Information
All unnecessary packaging material has been omitted.
We have done our utmost to make the packaging easily
separable into three mono-materials; cardboard (box),
polystyrene foam (buffer) and polythene (bags, protective
foam sheet).
Your system consists of materials which can be recycled
and reused if disassembled by a specialized company.
Please observe the local regulations regarding the
disposal of packaging materials, exhausted batteries and
old equipment.
________________
Accessories (Supplied)
Remote control
Batteries (2 x AAA size) for remote control
AM loop antenna
FM antenna wire
AC power cord
Philips Magnavox SS-50 surround speakers (for model
FW560Conlyl
Philips Magnavox SS-15R surround speakers (for
model FW520C only).
Safety Information
Before operating the system, check that the operating
voltage indicated on the typeplate (or the voltage
indication beside the voltage selector) of your system
is identical with the voltage of your local power
supply. If not, please consult your dealer. The type
plate is located at the rear of your system.
When the system is switched on, do not move it
around.
Place the system on a solid base (e.g. a cabinet).
Place the system in a location with adequate
ventilation to prevent internal heat build-up in your
system.
The system incorporates a built-in safety feature that
prevents over heating (for model FW560C only).
Do not expose the system to excessive moisture, rain,
sand or heat sources.
Under no circumstances should you repair the system
yourself, as this will invalidate the warranty!
If the system is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture
may condense on the lens of the CD unit inside the
system. Should this occur, the CD player will not
operate normally. Leave the power on for about one
hour with no disc in the system until normal playback
is possible.
Electrostatic discharge may cause unexpected
problems. See whether these problems disappear if
you unplug the AC power cord and plug it in again
after a few seconds.
To disconnect the system from the power supply
completely, remove the AC power plug from the
wall socket.
Rear Connections
lllillllll
10
PREPARATION
■
® AM Antenna Connection
Connect the supplied loop antenna to the AM AERIAL
terminal. Place the AM loop antenna far away from the
system and adjust its position for the best reception.
(g) FM Wire Antenna Connection
Connect the supplied FM wire antenna to the FM 300 Q
terminal. Adjust the position of the FM antenna for the
best reception.
Outdoor Antenna
For better FM stereo reception connect an outdoor FM
antenna to the FM AERIAL 300 Q terminal using a 300 £2
dipole wire.
(c) Speakers' Connection
• Connect the right speaker to Front terminal R, with the
red wire to + and the black wire to —.
• Connect the left speaker to Front terminal L, with the
red wire to + and the black wire to —.
• Clip the stripped portion of the speaker wire as shown.
________________
________
___________________
Rear Surround Speakers'
Connection
• Connect the supplied surround speakers to enhance
the surround effect. The surround speakers should be
placed at normal listening ear level or mounted on the
wall at the back of the room.
• Connect the black or non-marked wires to the black
REAR terminals and the white or marked wires to the
greg REAR terminals.
(D Connecting other equipment to your
system
You can connect the audio left and right OUT terminals of
a TV, Laser Disc player, VCR or DVD player to the AUX IN
terminals at the rear of the system.
0
Subwoofer Out Connection
You can connect either an optional active subwoofer or
an optional wireless active subwoofer to the
SUBWOOFER OUT terminal. The wireless system uses a
radio frequency transmitter. The subwoofer reproduces
just the low bass effect (e.g. explosions, the rumble of
spaceships, etc.). Be sure to follow the instructions
supplied with the subwoofer.
__________________________________
____________
(G) Line Out (wireless ready} (for model FW560C
only)__________________________________________________
You may install additional front active speakers away
from the system (e.g. in another room) to reduce the
inconvenience of running long speaker wires across
rooms. You can place as many remote speakers as you
like provided that they operate at the same radio
frequency. Connect the wireless radio frequency
transmitter to the LINE OUT terminals. Place the active
speakers at your preferred location. Be sure to follow the
instructions supplied with the active speakers.
Note:
- Availability of wireless transmitter and its peripherals
are subjected to the approval of local authorities.
Please check with respective local safety or approving
authority.
0 AC Power Supply
After all other connections have been made, connect the
AC power cord to the system and to the wall outlet.
_________________________
Inserting batteries into tbe Remote
Control
• Insert the batteries (Type
R03orAAA) into the
remote control as shown in
the battery compartment.
• To avoid damage from
possible battery leakage,
remove dead batteries or
batteries that will not be
used for a long time. For replacement, use type R03 or
AAA batteries.
________________________________
t
I
11
IDOLS
I
22
21
Ш
Ш
13
16
12
Controls on the system and remote control
[T] STANDBY*ON
H] CLOCK*TIMER
2 DISPLAY
2 CD CAROUSEL TRAY
[6] 3 CD DIRECT PLAY
[7] DISC CHANGE
2 OPEN*CLOSE
[9] DYNAMIC BASS BOOST (DBB)
M DIGITAL SOUND CONTROL DISPLAY PANEL
______________________________________
- to switch the system on or to standby mode.
- to store radio stations automatically by pressing
and holding for 2 seconds (only in Standby or
Demonstration mode).
- to view clock, set clock or timer.
SOURCE-to select the following:
CD (CD 1
TUNER (BAND)
TAPE (TAPE 1*2)
AUX (VIDEO)
- to view the current setting of the system.
- to select a CD tray for playback.
- to change CD(s).
- to open or close the CD carousel tray.
- to select bass boost level (Beat, Punch, Blast).
- to view the selected DSC setting.
.........
to select CD mode. When in
CD stop mode; to select
respective disc tray.
..........
to select Tuner mode. When
in Tuner mode; to select the
waveband: FM or AM.
.......
to select Tape mode.
......... .....
to select external source (e.g.
DVD, TV, Laser Disc or VCR
sound).
d DIGITAL SOUND CONTROL (DSC)
- to select the desired sound effect: OPTIMAL,
JAZZ, CLASSIC, ROCK or TECHNO.
d PROGRAM
- to program CD tracks in CD mode or preset radio
stations in tuner mode.
d VOLUME
- to adjust the volume level,
d HEADPHONES 0
- to connect headphones jack.
M DUBBING
- to dub a tape in normal or high speed.
M MODE SELECTION
◄◄ SEARCH ►► (◄◄ TUNING ►►)
for CD
.....................
for TUNER
to search backward/forward.
.............
to tune to a lower or higher radio
frequency.
STOPH (CLEAR)
for CD......................to stop CD playback or clear a
program.
for TUNER
.............
to stop programming.
PLAY^ / PAUSE II
for CD......................to start or interrupt playback.
PREV W/NEXT N (T PRESET A)
for CD......................to skip to the beginning of the
current or previous/next track.
for TUNER
.............
to select a preset radio station in
memory.
d TAPE DECK 2 OPERATION
PLAY ►
►►
STOP'OPEN
....................
...............................
..............................
........
to start playback.
to rewind the tape.
to fast forward the tape.
... to stop playback or to open the
tape door.
PAUSE........................to interrupt playback.
TAPE DECK 1 OPERATION
RECORD
PLAY ►
«
......................................
►►
STOP*OPEN
PAUSE
...................
....................
...............................
...........
............. .......
to start recording.
to start playback.
to rewind the tape.
to fast forward the tape.
to stop playback/recording or to
open the tape door.
to interrupt playback or
recording.
REPEAT
- to repeat a CD track.
SHUFFLE
- to play all the available discs and their tracks in
random order.
MUTE
- to switch off the sound temporarily or to switch on
again.
(])
- to switch the system to standby mode.
Notes for remote control:
- First select the source you wish to control by pressing
one of the source select buttons on the remote control
(e.g. CD, TUNER, TAPE 1/2 or AUX).
- Then select the desired function (PLAY, NEXT, etc.).
H
P
OPERATING THE SYSTEM
^ mwo ^
S L ^
’ C O C U C C T
i_ / f -_i -i -i L. i
MINI HIFI SYSTEM
STANDBY-ON
.№[!jo:aai
Important:
Before you begin operating the system, complete
the preparation procedures.
Demonstration mode______________________
The system has a demonstration mode that shows the
various features offered by the system. Whenever the
system is switched on from the wall socket, the
demonstration mode will start automatically.
Notes:
- During demonstration mode, if you press any source
for standby-on) button, the system will switch to the
respective (or standby) mode.
- When the system is switched to standby mode, 5
seconds later, the demonstration mode will begin
again.
DIGITAL SOUND CONTROL DISPLAY
Æ
r ^
Switching the system ON
• Press STANDBY»ON (on the system only), CD,
TUNER, TAPE orAUX
You can also switch on the system by pressing any one of
the 3 CD DIRECT PLAY buttons.
Switching the system to standby mode
• Press STANDBY*ON again.
Selecting the Source
• Press the respective source selection button: CD,
TUNER, TAPE orAUX
Tbe display indicates the selected source.
To cancel demonstration mode
• Press and hold STOP ■ (on the system only)ior 3
seconds \o stop the demonstration.
The demonstration mode will be switched off
permanently.
Note:
- For an external source, make sure you have connected
the audio left and right OUT terminals of the external
equipment (TV, VCD. Laser Disc or DVD player) to the
AUX IN terminals.
Easy Set (only in standby or Demonstration mode)
EASY SET allows you to store all available radio stations
in a particular band (FM»AM) automatically (see Easy
Set under TUNER section).
14
■11
OPERATING THE SYSTEM
-HI
Sound Control
VOLUME ADJUSTMENT
Adjust VOLUME to increase or decrease the sound
level.
For Personal Listening
Connect the headphones jack to the iHl socket at the
front of the system. The speakers will be muted.
DIGITAL SOUND CONTROL (DSC)
The DSC feature enables you to enjoy special sound
effects that have preset equalizer settings, providing the
best music reproduction.
• Press DIGITAL SOUND CONTROL (DSC) to select
OPTIMAL. JAZZ, CLASSIC, ROCK or TECHNO
-■ The Digital Sound Control display panel will light up
respectively. At OPTIMAL setting, the DSC display
panel does not light up.
- "OPTinnL, JHZZ, CLRG5IC, ROCK or
TCChTJu" will be displayed.
Automatic DSC-DBB selection
The best setting for the DBB is automatically generated
for the respective DSC selection. You can also manually
select the DBB setting that best suits your listening
environment
DYNAMIC BASS BOOST (DBB)
The DBB mode enhances the bass response.
• Press DBB briefly to select the various level of bass
boost.
The DBB button lights up.
"BCOT, PORCH or SLRGT" will be displayed.
DBB
DBB
OFF
DBB
■■
BEAT
DBB
PUNCH
DBB
^¡¡1
BLAST
To switch off DBB
• Press DBB briefly until the DBB button light is
switched off.
"]jB5 Orr" will be displayed.
Note:
- Some CDs or tapes might be recorded in high
modulation. It may cause distortion at high volume. If
this occurs, switch off Incredible Surround (If
available), DBB level or reduce the volume.
MUTE fon:y on remote control)
This feature allows you to temporarily switch off the
sound of the system without switching off the system
when you require a moment of silence.
• Press MUTE on the remote control to switch off the
sound.
— "tVOTC" will be displayed.
• Press MUTE again on the remote control or increase
the VOLUME level to switch on the sound.
'vi
DSC Selection
Rock ^
Techno
DBB Selection
Punch
Punch
Beat
— Blast
^ Blast
15
CD
Warning!
1) This system is designed for conventional CDs.
Do not use any accessories like disc stabilizer
rings or CD treatment sheets, etc., which may
damage the CD mechanism.
2) Do not load more than one disc into each tray.
3) When the CD changer is loaded with CD(s), do
not turn over or shake the system. This may jam
the changer.
You can load up to three discs in the CD changer
for continuous playback without interruption.
16
\
I SrANDSYON I I fC 'S]
/\ ClCrCK-TiVfi!
'loiswi '(!!.“£]
MINI HIFI SYSTEM
C01 • 2 • 3 Bi-U O Tf P i 3 - i ViOEO
1 SEARCH STOP PLAY PAUSE PREV NEXT
OL-sfiNC. I
f, fi •' j
Loading the CD Changer
___________________
1 Press CD to select CD mode.
2 Press 0PEN*CL0SE
-* The CD compartment slides out.
3 Load a CD with the printed side up in the right tray.
• You can load another disc in the left tray.
• To load the third disc, press DISC CHANGE.
-* The CD changer carousel will rotate until the empty
tray is at the right hand side and is ready for loading.
— Playback will always start with the disc in the outer
right disc tray.
4 Press OPEN*CLOSE to close the CD compartment.
The total number of tracks and playing time of tbe
last selected disc appear on the display.
I
iM
3 CD Direct Play
• You can play a CD directly by pressing the
corresponding 3 CD DIRECT PLAY (1 - 3) button. The
CD player will stop at the end of playback of the
selected disc.
— When the button is lighted, it indicates that there is
a disc loaded in the disc tray.
Playing a CD
1 Press PLAY ► to start playback.
The disc tray, track number and elapsed playing
time of the current track appear on the display.
-• The LED on the respective 3 CD Direct Play button
will be flashing.
• To interrupt playback, press PAUSE II.
The playing time flashes.
• To resume playback, press PLAY ► again.
2 To stop playback, press STOP ■.
Note:
- All the available discs will be played once, then stop.
When the CD has stopped playing, the system will
switch to the standby mode after 15 minutes if no
button is pressed.
Disc Change
You can change the outer 2 discs while the third inner
disc is at the stop or playback mode.
1 Press DISC CHANGE
— The CD compartment slides out.
2 Replace the discs in the left and right disc trays.
• If you press DISC CHANGE again during playback,
the CD will stop playing.
— The CD carousel tray will rotate until the inner tray
is at the right hand side and is ready for changing.
3 Press DPEN»CLDSE to close the CD compartment.
Selecting a desired track
Selecting a desired track at the stop mode
1 Press PREV N or NEXT ►! until the desired track
appears on the display.
2 Press PLAY ► to start playback.
-* * The selected track number and elapsed playing
time appear on the display.
Selecting a desired track during playback
1 Press PREV N or NEXT ►! until the desired track
appears on the display.
— The selected track number and elapsed playing
time appear on the display.
• If you press PREV \< once it will skip to the beginning
of the current track and play the track again.
Searching for a particular passage during playback
• Press and hold ◄◄ or ►► until the desired passage is
located.
— The volume will be reduced.
• Playback returns to normal when ◄◄ or ►► is
released.
Programming Tracks
Programming tracks of a loaded CD is possible in the stop
mode. The display will indicate the total tracks stored in
the program. Up to 40 tracks can be stored in the memory
in any order. When 40 tracks are stored and you attempt
to store another track, the display will show TRDBRnn
nil I "
I UL-L. .
1 Load the desired discs in the disc trays.
2 Press PROGRAM to start programming.
-* The PROGRAM flag starts flashing
3 Press the CD (CD 1 •2*3) to select the desired disc.
4 Press PREV !◄ or NEXT ►! to select the desired
track.
5 Press PROGRAM to store the track.
• Repeat steps Jto 5to store other discs and tracks.
6 Press STOP ■ once to end programming mode.
— The total number of tracks programmed and total
playing time appear on the display.
____________________________
_______________________
17
CD
Notes:
- If the total playing time is more than "33 ■'5 3" or if
one of the programmed tracks has a number greater
than 30, then -. - - " appears in the display instead
of the total playing time.
- During programming, If no button is pressed within 20
seconds, the system will exit program mode
automatically.
Playing the program
_______________________
1 Press PLAY ► to start program playback.
— "PLPiy PPOGPnrr will be displayed.
The track number and elapsed playing time of the
current track will appear on the display.
• If you press REPEAT during program playback, the
current track will be played repeatedly.
-* The REPEAT and PROGRAM flags will be displayed.
2 Press STOP ■ to stop program playback.
Note:
- If you press any of the 3 CD DIRECT PLAY buttons, the
system will play the selected disc or track and the
stored program will be ignored temporarily. The
PROGRAM flag will also temporarily disappear from
the display and then reappear, when the playback for
the selected disc ends.
Reviewing the program
____________________
Erasing the program (in the stop model
• Press CLEAR on the system.
- "PROGRRn CLERREr will be displayed.
Note:
- The program will be erased when the system is
disconnected from the power supply. If the CD
carousel Is opened, the tracks belonging to the outer
two trays will be erased and the display will show
Shuffle (only on remote control)
It will play all the available discs and their tracks in
random order. Shuffle may also be used when tracks are
programmed.
To shuffle all the discs and tracks
1 Press SHUFFLE
"EE'uEEEE" will be displayed.
The SHUFFLE flag, the disc and the track selected
at random appear on the display.
• The discs and the tracks will now be played in random
order until you press STOP ■.
• If you press REPEAT during shuffling, the current track
will be played repeatedly.
- The REPEAT and SHUFFLE flags will be displayed.
2 Press SHUFFLE again to resume normal playback.
The SHUFFLE flag disappears from the display.
Repeat (only on remote control)
It will play the current track repeatedly.
1 Press REPEAT during playback.
'VEPEEIT TRRuK" will be displayed.
-* The REPEAT flag and the track selected appear on
the display.
• The track will now be played repeatedly until you
press STOP ■.
2 Press REPEAT again to resume normal playback.
-* The REPEAT flag disappears from the display.
Reviewing of the program is only possible in the stop
mode.
• Press PREV !◄ or NEXT N repeatedly to review the
programmed tracks.
• Press STOP ■ to exit review mode.
18
Note:
- All the available discs will be played once, then stop.
TUNER
Easy Set (only in Standby or Demonstration mode} Tuning to Radio Stations
EASY SET allows you to store all available radio stations
in a particular band (EM»AM) automatically.
• Press and hold STANDBY*ON (on the system only)
for 2 seconds.
-* TnS'J 5CT" will be displayed and followed by
— Easy set will start with the last active band.
All available radio stations with sufficient signal
strength will be stored or until 40 presets are filled.
Notes:
- When EASY SET is used, all previously stored stations
will be erased.
- The last preset station will appear on the display
when Easy Set is completed.
1 Press TUNER to select TUNER mode.
— "TLIN'Ef?" will be displayed.
-* The preset station number, frequency and
waveband appear on the display.
2 Press TUNER (BAND) to select the desired
waveband: EM or AM.
3 Press TUNING ◄◄ or ►► for more than one second,
then release.
-* The display will show "5iTnf?CM" until a radio
station with sufficient signal strength is found.
• Repeat this procedure until the desired radio station is
reached.
• To tune to a weak station, briefly press TUNING ◄◄
or ►► until the display shows the desired frequency
and/or when the best reception has been obtained.
Storing Preset Radio Stations
You can store up to 40 radio stations in the memory.
When a preset radio station is selected, the preset
number appears next to the frequency on the display.
_____________
Automatic programming
1 Press TUNER
2 Press TUNER (BAND) to select the desired
waveband: EM or AM.
3 Press PROGRAM for more than one second.
PROGRAM flag starts flashing and "EiLITO" will be
displayed.
-*■ Every available radio station will be stored
automatically. The frequency and preset number
will be displayed briefly.
-* The system will stop searching when all the
available radio stations are stored or when the
memory for 40 preset radio stations is used.
-* The system will remain tuned to the last stored
preset radio station,
• Repeat the above procedure to store other preset
stations for the other waveband. Remember to select
the next available preset number before proceeding. If
not, some of the preset radio stations may be erased.
Notes:
- You can cancel the automatic programming by
pressing PROGRAIYI or STOP ■ ,
- If you want to reserve a section of preset numbers, for
example preset numbers 1 to 9, select preset 10
before starting automatic programming: now only the
preset numbers 10 to 40 will be programmed.
19
Manual programming
1 Press TUNER
2 Press TUNER (BAND) to select the desired
waveband; FM or AM.
3 Press PROGRAM for less than one second.
PROGRAM flag, the frequency and preset station
number start flashing.
— The next available preset number will be displayed
for selection.
4 Press TUNING or ►► to tune to the desired
frequency.
• When all 40 presets are stored, no preset number is
shown.
— The message VROGRnn TULL" will be
displayed.
• If you wish to store the radio station to another preset
number, press PRESET T or A to select the desired
preset number.
5 Press PROGRAM again.
-* PROGRAM flag will stop flashing, and the radio
station will be stored.
• Repeat the above procedure to store other preset radio
stations.
Tuning to Preset Radio Stations
• Press PRESET T or A to select the desired preset
number.
The preset number, frequency and waveband
appear on the display.
________
Notes:
- You can cancel the manual programming by pressing
STOP m.
- During programming, If no button is pressed within 20
seconds, the system will exit program mode
automatically.
20
Loading a tape
• Press ST0P»0PEN.
• The tape deck door opens.
• Load the tape with the open
side downward and the full
spool to the left.
• Close the tape deck door.
Tape Playback
1 Press TAPE to select TAPE mode.
— "TRPC" will be displayed.
2 Load the tape into the desired tape deck.
3 Press PLAY ► to start playback.
• To interrupt playback, press PAUSE.
• To resume playback, press PAUSE again.
4 Press STOP*OPEN to end playback.
Rewind/Fast Forward
TAPE
At the stop mode
1 You can rewind or fast forward the tape by pressing
◄◄ or ►► respectively.
The tape will stop automatically at the end of the
rewinding or fast forwarding.
2 Press STOP»OPEN to stop rewind or fast forward.
21
Continuous Playback from Tape Deck 2
to Tape Deck 1______________________________
1 Press TAPE to select TAPE mode.
2 Load the tapes in tape deck 1 and 2.
3 Press PLAY ► on tape deck 2.
4 Press PAUSE on tape deck 1,
5 Press PLAY ► on tape deck 1.
-*• Playback will begin with tape deck 2 and will
continue with tape deck 1 when tape deck 2 ends.
6 Press STOP*OPEN if you want to stop playback
before the end of the tape in tape deck 1 and 2.
AUX
Notes:
- During rewinding or fast forwarding a tape, it is also
possible to select another source mode (e.g. CD,
TUNER or AUX mode).
- Check and tighten slack tape with a pencil before use.
Slack tape may get jammed or burst in the mechanism.
- C-120 tape is extremely thin and easily get deformed
or damaged. It is not recommended for use in this
system.
~ Store the tapes at room temperature and do not put
them too close to magnetic field (for example,
transformer, TV or loudspeaker boxes).
22
Selecting External Equipment
If you have connected the audio out terminals of the
external equipment (TV, VCR, Laser Disc or DVD player) to
the AUX IN terminals, you can hear the sound from the
system.
• Press AUX to select the external mode.
— "Run" will be displayed.
Note:
- All the sound control features (e.g. DSC, DBB, etc.) are
available for selection.
_____________
f
CLOCK
TIMER
Notes:
- During clock setting, if no button is pressed within 90
seconds, the system will exit clock setting mode
automatically.
- When power interruption occurs, the clock setting is
erased.
Timer Setting
_______________________________
5 Press CLOCK*TIMER again to store the start time
and the selected source.
The TIMER is now set.
The TIMER flag remains on the display.
• To exit without storing the setting, press STOP ■ .
• At the preset time, the TIMER will be activated.
The selected source will be played.
-* The TIMER flag disappears from the display.
View Clock
You can view the clock (if it is set) at standby or any
source mode. It will be displayed for about 7 seconds.
• Press CLOCK*TIMER briefly.
" /u- c'S AM" (the current time) will be displayed,
will be displayed if the clock is not set.
Clock setting
The clock is set in 12-hour mode, e.g. ic-QD AM or
I'c' Clu PM. Before setting the clock, you must be in the
View Clock mode.
1 Press CLOCK*TIMER to select clock mode.
— " !,P:OG AM" or the current time starts flashing.
— , 1-^ , H, ■" light up.
2 Set the hour with ◄•^or^^.
3 Set the minute with W or ►!.
4 Press CLOCK«TIMER again to store the setting.
The clock starts running.
• To exit without storing the setting, press STOP ■ .
• The system can switch on to CD or TUNER mode
automatically at a preset time. It can serve as an
alarm to wake you up. After half an hour from the
preset time, the system will return to the standby
mode if no button is pressed.
• Before setting the timer, make sure the clock is set
correctly.
• The timer has to be reset or start again for each
subsequent preset time.
• The volume of the timer will be at the last setting
before the system is switched to standby mode.
1 Press and hold CLOCK*TIMER for more than 2
seconds to select timer mode.
— "ON ic'. iJlJ AM" or the last set timer starts
flashing. The TIMER flag will be displayed.
The last selected source is lighted while other
available sources are flashing.
— H , ►), ■ " light up.
2 Press CD or TUNER to select the desired source.
3 Press ◄◄ or ►► to set the hour for the timer to start.
4 Press M or H to set the minute for the timer to start.
Notes:
- During timer setting, if no button is pressed within 90
seconds, the system will exit timer setting mode
automatically.
- If the source selected is TUNER, the last tuned
freguency will be switched on.
- If the source selected is CD, playback will begin with
the first track of the last selected disc. If the CD trays
are empty, the TUNER will be selected instead.
To cancel the TIMER
1 Press CLOCK*TIMER for more than 2 seconds.
2 Press PAUSE II to cancel the timer.
— TEIUEEL" will be displayed.
The TIMER flag disappears from the display.
To start the TIMER again (for the same time)
1 Press CLOCK*TIMER for more than 2 seconds.
2 Press CLOCK*TIMER again to store the start time
and the selected source.
23
»siililia
ummmMrn,
Notes:
- For recording, use only tape of lEC type I (normal tape}.
- The tape is secured at both ends with leader tape. At
the beginning and end of tape, nothing will be
recorded for six to seven seconds.
- The recording level is set automatically, regardless of
the position of VOLUME or DBS.
- To prevent accidental recording, break out tbe tab on
the left shoulder of the tape side.
One Touch Recording
• For One Touch recording, as soon as you press
RECORD, the current source will be recorded on tape
deck 1.
1 Load a blank tape in tape deck 1.
2 Press RECORD on tape deck 1 to start recording.
The RFC flag starts flashing.
3 Press PAUSE te interrupt recording.
4 Press STOP*OPEN on tape deck 1 to stop recording.
______________________
24
Loading...
