English
Introduction
Congratulations on your purchase and welcome to Philips!To fully benefit from the support that
Philips offers, register your product at www.philips.com/welcome.
General description (Fig. 1)
1Active Fragrance cartridge
2Suction power knob
3Cord rewind button
4On/off button
5Dustbag-full indicator
6Hose connection opening
7Dust cover release tab
8 Motor protection filter holder
9Front handle
10Removable strip (some countries only)
11Reusable dustbag (some countries only)
12Dustbag holder
13Synthetic dustbag
14Rear wheel
15Accessory holder (specific types only)
16Small nozzle
17Crevice tool
18Small brush (specific types only)
19Spring-loaded lock button
20Hose with handgrip
21Combination nozzle
22Rocker switch for carpet/hard floor settings
23Tri-Active nozzle (specific types only)
24Rocker switch for carpet/hard floor settings
25Parking/storage ridge
26Side brush
27Accessory clip (specific types only)
28Telescopic tube
29Filter grille (open)
30Mains plug
31Parking slot
32Super Clean Air HEPA 12 filter/Ultra Clean Air HEPA 13 filter
33Swivel wheel
34Storage slot
35Type plate
Important
Read this user manual carefully before you use the appliance and save it for future reference.
Danger
-Never suck up water or any other liquid. Never suck up flammable substances and do not suck up ashes until they are cold.
Warning
-Check if the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.
-Do not use the appliance if the plug, the mains cord or the appliance itself is damaged.
English
-If the mains cord is damaged, you must have it replaced by Philips, a service centre authorised by
Philips or similarly qualified persons in order to avoid a hazard.
-This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-Children should be supervised to ensure that they do not play with the appliance.
-Do not point the hose, the tube or any other accessory at the eyes or ears nor put it in your mouth when it is connected to the vacuum cleaner and the vacuum cleaner is switched on.
Caution
-When you use the vacuum cleaner to vacuum ashes, fine sand, lime, cement dust and similar substances, the pores of the dustbag become clogged. As a result, the dustbag-full indicator will
indicate that the dustbag is full. Replace the disposable dustbag and empty the reusable dustbag, even if it is not full yet (see chapter ‘Replacing/emptying the dustbag’).
-Never use the appliance without the motor protection filter.This could damage the motor and shorten the life of the appliance.
-Only use Philips s-bag ` synthetic dustbags or the reusable dustbag provided (some countries only).
-The translucent display panel is made of recyclable polycarbonate (>PC<).
Electromagnetic fields (EMF)
This Philips appliance complies with all standards regarding electromagnetic fields (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientific evidence available today.
Preparing for use
Hose
1To connect the hose,push it firmly into the appliance (‘click’) (Fig.2).
2To disconnect the hose,push the buttons (1) and pull the hose out of the appliance
(2)(Fig.3).
Tube
1To connect the tube parts to each other and to the handgrip of the hose,press the springloaded lock button.Then insert the part with the lock button into the part with the hole and fit the lock button into the hole (‘click’) (Fig.4).
2To disconnect the tube from the handgrip,press the spring-loaded lock button and pull the handgrip out of the tube.
Note: Use the same method to connect and disconnect the accessories.
Telescopic tube (specific types only)
1 Adjust the tube to the length you find most comfortable during vacuum cleaning (Fig.5).
Tri-Active nozzle (specific types only)
TheTri-Active nozzle is a multi-purpose nozzle for carpets and hard floors.
-The side brushes catch more dust and dirt at the sides of the nozzle and allow you to clean better along furniture and other obstacles (Fig. 6).
-The opening at the front of the nozzle allows you to suck up larger particles (Fig. 7).
1 To clean hard floors,push the rocker switch on top of the nozzle with your foot (Fig.8).
English
,The brush strip for cleaning hard floors comes out of the housing.At the same time,the wheel is lifted to prevent scratching and to increase manoeuvrability.
2To clean carpets,push the rocker switch again (Fig.9).
,The brush strip disappears into the nozzle housing and the wheel is lowered automatically.
Combination nozzle (specific types only)
The combination nozzle can be used on either carpets or hard floors.
1 To clean hard floors,push the rocker switch on top of the nozzle with your foot (Fig.10).
,The brush strip for cleaning hard floors comes out of the nozzle housing.
2To clean carpets,push the rocker switch again (Fig.11).
,The brush strip disappears into the nozzle housing.
Crevice tool, small nozzle and small brush
1Connect the crevice tool (1),the small nozzle (2) or the small brush (specific types only) (3) directly to the handgrip or to the tube (Fig.12).
Accessory clip (specific types only)
1Snap the crevice tool and the small nozzle into the clip.
2Snap the accessory clip onto the tube (Fig.13).
Accessory holder (specific types only)
1Snap the accessory holder onto the handgrip (Fig.14).
2Snap two accessories into the accessory holder:
-Crevice tool and small nozzle (Fig. 15).
Note: Make sure the suction opening of the small nozzle points away from the holder.
-Crevice tool and small brush (Fig. 16).
Note: Make sure the suction opening of the small brush points towards the holder.
Using the appliance
1Pull the cord out of the appliance and put the mains plug in the wall socket.
2Press the on/off button on top of the appliance with your foot to switch on the appliance (Fig.17).
3During vacuum cleaning,you can adjust the suction power with the knob on top of the appliance (Fig.18).
-Use maximum suction power to vacuum very dirty carpets and hard floors.
-Use minimum suction power to vacuum curtains, table carpets, etc.
4If you want to pause for a moment,insert the ridge on the nozzle into the parking slot to park the tube in a convenient position (Fig.19)
Active Fragrance Control (specific types only)
The scent granules have been specially developed for use in your Philips vacuum cleaner. Only use the Philips s-fresh ` scent granules in your vacuum cleaner.
If the vacuum cleaner is equipped withActive Fragrance Control,keep it out of the reach of children,both during and after use.Store the vacuum cleaner in a locked cupboard if there are small children in the house.
The scent granules are not edible.
English
In case of eye contact,flush immediately with plenty of water.
Filling the cartridge
1Place your thumb and index finger on the sides of the cartridge.Press on the disc (1) and lift the cartridge out of the holder (2) (Fig.20).
2To remove the cap of the cartridge,apply pressure on the small pressing points (1) and then pull the cap upwards (2) (Fig.21).
3Open the package at the small opening at the top.
4Fill the cartridge with the contents of one whole package of scent granules.
5 Close the cartridge by putting the cap back onto it (‘click’).
6Re-insert the cartridge into the holder (‘click’).It only fits into the holder in one way (Fig.22).
Replace the granules when the cartridge no longer emits any fragrance.
Setting the fragrance level
-You can set the fragrance level by turning the cartridge forwards (maximum emission) and backwards (minimum emission) (Fig. 23).
-When you store the vacuum cleaner or do not want any fragrance to be emitted, close the cartridge by turning it backwards until the openings of the cartridge are no longer visible.
Storage
1Switch off the appliance and remove the mains plug from the wall socket.
2Press the cord rewind button to rewind the mains cord (Fig.24).
3Put the appliance in upright position.To attach the nozzle to the appliance,insert the ridge on the nozzle into the storage slot (Fig.25).
4Always put theTri-Active nozzle in the carpet setting when you store it.Also prevent the side brushes from becoming bent (Fig.8).
Replacing/emptying the dustbag
Always unplug the appliance before you replace the disposable dustbag or empty the reusable dustbag.
Replacing the disposable dustbag
-Replace the dustbag as soon as the dustbag-full indicator has changed colour permanently, i.e. even when the nozzle is not placed on the floor (Fig. 26).
1Pull the cover upwards to open it (Fig.27).
2Lift the dustbag holder out of the appliance (Fig.28).
Make sure you hold the dustbag upright when you lift it out of the appliance.
|
|
Pull at the cardboard tag to remove the full dustbag from the holder (Fig.29). |
3 |
||
, |
When you do this,the dustbag is sealed automatically. |
|
4Slide the cardboard front of the new dustbag into the two grooves of the dustbag holder as far as possible. (Fig.30)
5 Put the dustbag holder back into the vacuum cleaner (Fig.31).
Note: If no dustbag has been inserted, you cannot close the cover.
