6 ENGLISH

Important

Read these instructions for use carefully before using the appliance and save them for future reference.

Check if the voltage indicated on the appliance corresponds to the local mains voltage before you connect the appliance.

Do not use the appliance if the plug, the cord or the appliance itself is damaged.

If the mains cord of this appliance is damaged, it must be replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.

Keep the appliance out of the reach of children.

Never suck up water or any other liquid. Never suck up flammable substances and do not suck up ashes until they are cold.

Do not point the hose at the eyes or ears nor put it in your mouth when the vacuum cleaner is switched on and the hose is connected to the vacuum cleaner.

When the vacuum cleaner is used to suck up fine dust, the pores of the dustbag may become clogged, causing the passage of air through the dustbag to become obstructed.As a result, the dustbag-full indicator will indicate that the dustbag needs to be replaced. Even though the dustbag may not be full, it must be replaced.

Never use the appliance without the Motor Protection Filter.This could damage the motor and shorten the life of the appliance.

Only use Philips double-layer paper dustbags or the reusable dustbag provided.

Preparing for use

Hose

1 To connect the hose, push it into the appliance and turn it clockwise (fig. 1).

To disconnect the hose, turn it anticlockwise and pull it out of the appliance.

Tubes

1Connect the tubes to each other and to the handgrip by inserting the narrow section into the wider section while turning it a little.The tube with the clip is the lower tube (fig. 2).

You can connect the accessories in the same way.

Disconnect the accessories and tubes by pulling them and turning them a little.

Combi nozzle

The combi nozzle can be used on either carpets (with the brush strips folded in) or hard floors (with the brush strips folded out):

1Push the rocker switch on top of the combi nozzle with your foot to make the brush strips for cleaning hard floors come out of the nozzle housing (fig. 3).

2Push the rocker switch on the other side to make the brush strips disappear into the housing (fig. 4).

Crevice tool

The crevice tool can be used to clean hard-to-reach places.

To use the crevice tool, pull it out of the storage compartment at the rear of the vacuum cleaner (fig. 5).

ENGLISH 7

Using the appliance

Vacuum cleaning

1Pull the cord out of the appliance and put the mains plug in the wall socket.

2Switch the appliance on by pushing the on/off button on top of the appliance with your foot.

You can carry the vacuum cleaner by the handle on top of the appliance (fig. 6).

Adjusting suction power

You can adjust the suction power by means of:

the slide on the handgrip, or (fig. 7).

the electronic suction power control (specific types only) (fig. 8).

Storage

1Switch the appliance off and remove the mains plug from the wall socket.

2Rewind the mains cord by pressing the cord rewind button.

3Put the appliance in upright position and attach the lower tube to the appliance by means of the clip (fig. 9).

Replacement

Replacing the dustbag

Replace the dustbag as soon as the 'dustbag full' indicator has changed colour permanently.

Always unplug the appliance before replacing the dustbag.

1Open the cover (fig. 10).

2Pull the dustbag holder towards you to unlock the dustbag (1) and lift the dustbag out of the appliance (2) (fig. 11).

3Put a new dustbag into the appliance. Position the opening of the dustbag directly opposite the hose connection opening (1). Pull the front of the dustbag forwards until it locks into place in the holder (2) (fig. 12).

Reusable dustbags

If provided, you can use the reusable dustbag instead of paper dustbags.The reusable dustbag can be used and emptied repeatedly.

For removing and inserting the reusable dustbag, simply follow the instructions for replacing paper dustbags.

To empty the reusable dustbag:

1Remove the clip by sliding it off the dustbag sideways (fig. 13).

2Shake out the contents into a dustbin.

3Close the dustbag by sliding the clip back onto the bottom edge of the dustbag.
