Philips DTR201/12 product specification sheet

Philips Digital Terrestrial Receiver
DTR201
Free to air TV in DVD quality
Rapid installation
Enjoy your TV programs with enhanced picture quality, in a stylish and compact design.
• Access the Free-to-Air digital TV and radio channels
Superior audio and video quality
• RGB output on SCART
• Built-in Pulse Killer Chip neutralizes interferences
Easy to use
• Fast and automatic installation of new channels
• 7-day Electronic Program Guide for TV schedule
• 2 SCART connectors for connecting your TV and another source
Digital Terrestrial Receiver
DTR201/12
Specifications
Tuner/Reception/Transmission
• Digital TV: Terrestrial
• Demodulation type: COFDM 2K/8K, MPEG-2 compliant, Network: MFN/SFN, QAM, QPSK
DVB
• Input frequency range: 174 to 862 MHz
Connectivity
• Terrestrial antenna interface: RF in, IEC 169-2, RF
out, (bypass) IEC 169-2
• TV scart out: Audio L/R, CVBS, RGB
• VCR scart out: Audio L/R, CVBS
Convenience
• Child Protection: Child Lock+Parental Control
• Programmable Events: 8
• Ease of Installation: Autoinstall
• Parental control: Lock with PIN code
• User Interface: Automatic program list update,
Now & Next ESG, Software u TV and Radio mode
Video Decoding
• Compression Format: MPEG-2 MP@ML (std
definition)
DAYS
7
EPG
pgrade over the air,
• Resolution: up to 720 x 576 interlaced
• Aspect Ratio: 16:9, 4:3 Letterbox, 4:3 Pan Scan
Audio Decoding
• Compression format: MPEG layer I/II
• Sound system: Stereo, Mono
Power
• Mains power: 230V AC/50Hz to 12V DC
• Power consumption: 7 W
• Standby power consumption: 5 W
Dimensions
• Product dimensions (W x H x D):
199.4 x 33.4 x 95.1 mm
• Carton dimensions (WxDxH): 285 x 195 x 58
•Weight: 0.4 kg
• Weight incl. Packaging: 1.0 kg
Accessories
• Batteries: 2x AAA
• Included accessories: SCART cable, Mains cord, emote Control, User Manual
R
Highlights
2 SCART connectors
2 SCART sockets allow you to connect to 2 devices simultaneously. One connection for the TV and the other, either to a DVD recorder or VCR for recording TV content, or to a video playback device, such as a DVD or Blu-ray player. Simply connect the SCART sockets on the product to the desired device by a SCART cable, to enable transmission of the video signals.
Automatic install & update
With the launch of digital terrestrial TV, additional broadcast channels are made available. Also, the channel numbering can often be temorarily reshuffled during digital switchover. To ensure that you always have the access to all available channels, it is important that the product is able to scan and install new channels automatically. A very sensitive tuner in this product scans through the broadcasting network for new channels whenever the product is switched off. Whenever a new service is detected, it will be automatically updated and saved onto the channel list.
7-Day Electronic Program Guide
Woul d you l ike to know w hat th e TV sc hedul e is fo r today and even for the whole week? This way, you can be sure to not miss any of your favorite shows by planning your evenings or making pre-scheduled recordings. The EPG information is part of the broadcast data and, when available, this receiver compiles the programming details for the upcoming 7 days and lists it in an easy-to-read format for your reference. The EPG can be accessed via the menu, or by simply pressing the EPG button on the remote control.
Issue date 2014-02-10
Version: 1.0.9
12 NC: 8670 000 35798 EAN: 87 12581 38529 3
Free-to-Air TV channels
You want to continue watching all the traditional publicly broadcasted programs, now in digital quality as well as any new TV channels available following digital switchover. No subscription or fee required.
Pulse Killer Chip
Electrical interferences are neutralised by a built in chip called PKC
© 2014 Koninklijke Philips N.V. All Rights reserved.
Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
www.philips.com
