Philips DigitalDiagnost C90 Specification

DigitalDiagnost C90

Digital radiography

Release 1.1

AbcDef

Secondary content

Accelerate exam performance

Key advantages

• Fast workow

• Diagnostic condence

• High exibility

Philips DigitalDiagnost C901 premium DR room is designed to
meet the diagnostic imaging needs of the most demanding
institutions. It allows you to comfortably see more patients
per day and shorten patient wait times by decreasing the
time to diagnosis with innovative tools that help drive
workow eciency. DigitalDiagnost C90’s live tube head
camera, versatile room congurations, and exam automation
technologies all help provide outstanding patient throughput.

Philips DigitalDiagnost C90 ist not available in Greater China.

Save time and provide
exceptional patient care

with the versatile DigitalDiagnost C90

Faster workow and easier collimation

DigitalDiagnost C90 integrates a touchscreen and an
optional live camera into the Eleva Tube Head for extended
Eleva control, right in the exam room. The live camera helps
with patient positioning by providing a clear view of the
collimation area which can help alleviate potential imprecise
collimation such as with bariatric patients. Better positioning
can also help eliminate time consuming retakes that add
unnecessary X-ray dose.

Utilizing the DigitalDiagnost C90 allows
you to see 15 more patients per day.

If you prefer a grid-less workow, the optional SkyFlow Plus
assists by producing images with grid-like contrast for all
anatomies. There’s no need to attach and detach a grid, so
detector/patient positioning is fast and easy. Without a grid,
retakes due to grid misalignment are a thing of the past.
SkyFlow Plus helps you work more eciently by rapidly
acquiring high-quality images, while eectively managing
scatter radiation.

2

Utilizing the DigitalDiagnost C90 allows
you to avoid around 28 retakes per week.

Since 67,5 %4 of retakes in radiography result from wrong
patient positioning, this problem is addressed by the
optional Eleva Tube Head Live Camera.
The Live Camera allows the user to check on correct
positioning prior to image acquisition also at the working
console by means of live camera images.

94 % of the users think that the live
camera images at the work station helps
to avoid retakes.

3

Faster setup time

• Live images of the collimated anatomy assist sta in initial
patient positioning (optional)

• Detect patient movement and incorrect collimation early
with a view of the collimated area at the Eleva Tube Head
and Eleva workspot (optional)

• Double check all relevant system parameters, images, and
order of views at the tube head as well as at the Eleva
workspot

75 % of the users consider the Eleva Tube
Head as helpful spending more time with
the patient.

Diagnostic condence

DigitalDiagnost C90 now oers two features to improve your
ability to provide a condent diagnosis.

Philips UNIQUE 2 image processing uses next generation

image processing software to provide superb images of
all anatomical areas. UNIQUE 2 improves clinical image
quality by providing selective enhancement of tiny details,
increased contrast, and reduced background clutter.

2

3

UNIQUE 2 beats the Philips’ benchmark,
with 80.1 % of the reader votes showing
preference or equivalence.

Philips Bone Suppression6 software helps remove bone

structures from adult erect chest images for an unobstructed
view of soft tissue. This clear view allows you to have a more
accurate image interpretation. Philips Bone Suppression can

improve actionable nodule detection by 16.8 %7 without the

need to expose the patient to additional X-ray dose. As part
of Philips’ Eleva platform, Bone Suppression is integrated
into the regular system workow. Depending on the protocol
it provides automatically processed images without the need
to send them separately to PACS.

5

1

Ph ilips Di gitalDiagnost C90 is not available in Grea ter China .

2

Compared to the pre vious r elease of Digit alDia gnost a nd based on 100 patient s per day. Actual results in other case s may vary.

3

Validate d by clinic ians in a Ph ilips’ developme nt environment.

4

Li ttle, K .J., et al. (2016) Unie d Database for Rejected Image An alysis Ac ross Mult iple Vend ors in Rad iography, Journal o f the Ame rican Co llege of Ra diolog y, 14(2),

208-216.

5

Result s of a blind ed image compar ison s tudy of UNI QUE 2 vers us UNIQUE.

6

Riverain Technologies’ ClearRead Bone Suppression

7

Fre edman M et al. Improved detec tion o f lung nod ules with novel software that sup presses the ri b and clav icle shadows on chest radi ographs. Radiology. 2011.

2

High per formance room VM90 with vertical

movable stand and table

High per formance room VS90 with vertical

stand and table

Flex room VM90 with vertical movable stand

and single side suspended table TH-S

Value room VS90 with SkyPlate sharing

between vertical stand, table or free

exposures

Chest room VS90 with vertical stand

High exibility

DigitalDiagnost C90 oers a variety of conguration options
to t your clinical application and budgetary needs. It gives
you the opportunity to choose the conguration that best
satises your departmental requirements.

1. High performance room VM90 – High patient throughput
and outstanding ergonomics with the vertical movable
stand and workow eciency with up to three detectors

2. High performance room VS90 - High patient throughput
with up to three detectors

3. Flex room VM90 – All applications performed in a small
space

4. Value room VS90 – Cost-eective room with one
detector

5. Chest room VS90 –Dedicated geometry for a full range
of chest exams

6. Emergency room – Designed to oer more space for
trauma work

DigitalDiagnost C90 moves around the patient with ease,
giving you exibility of exam preparation. Optionally the

Emergency room with ceiling suspension and

SkyPlate or SkyPlate E

8

system oers a ‘move to position’ function that allows it to
travel automatically to a selected exam position. With the
further optional fully automated ceiling suspension, both
detector and tube move in unison at the touch of a button.
This allows you to reduce patient repositioning with virtually
unlimited predened position settings.

The High performance room VM90 and Flex room VM90
also add a vertical movable stand to compensate for patient
movement and further reduce the need for repositioning.
The Flex room VM90 then takes exibility to the nex t level
with a single-side suspended table including swivel option.
The detector on the vertical movable stand slides freely
under the table for spine imaging. For bed and trolley exams,
the table can be quickly swiveled away to allow space for
easy access.

However you choose to congure your DigitalDiagnost C90,
you can select from a wide variety of innovative features
to personalize your room setup, reinforcing your primary
commitment of providing exceptional patient care. So, go
ahead and create a premium DR room like no other.

8

Sk yPlate E is not avail able in No rth America .

3

Height adjustable table (TH2)

Height adjustable table with oating tabletop, removable gr id and
3 AEC measuring chambers

Height adjustment 51.5 cm to 91.5 cm (1' 8.3" to 3')

Tabletop dimensions 240 cm × 75 cm (7' 10.5" x 2' 5.5")

Tabletop travel range longitudinal +/- 56cm (1' 8.4")

transverse +/- 12.8 cm (5.0")

Max. patient load 375 kg (827 lbs)

Table also available as single side suspended table (TH-S)

Movable vertical stand (VM)

Movable vertical stan d for ecient upright, cross-lateral and
under-the-table examinations

Vertical movement range 35 cm to 185 cm (13.8" to 6' 0.8")

Maximum horizontal

5.5 m (18' 0.5")

travel

Detector unit dimension

59.6 cm x 57.5 cm (23.5" x 22.6")

(w x h)

Tilt angle horizontal ax is –20° to +90°,

motorized tilting
vertical ax is +45° to –23°,
manual tilting

Vertical stand also available as xed vertical stand (VS).

Movable Ceiling Suspension (CSM)

Travel with Comfort Track and

longitudinal 3.44 m (11' 3.4")

Comfort Move (optional)

Travel with fully motorized
Comfort Position

8

(optional)

Ceiling height at source image
distance 110 cm (44")

Also available with extended longitudinal travel for Comfort Track,
Comfort Move and Comfort Position.

longitudinal 3.28 m (10' 9.1")

2.83 m to 3.21 m
(9' 3.4" to 10' 6.4")

9

Fixed detector

Typ e Digital Cesium Iodide at detector

Detector size 43 cm x 43 cm (17" x 17")

Active area 42 cm x 42.5 cm (16.5" x 16.7")

Image matrix size 2,840 x 2,874 pixel

Pixel size 148 μm

X-ray tube assembly

Dual-focus rotating anode X-ray tubes for excellent performance
over a long lifetime

High power X-ray tube (SRO 33100)

Maximum voltage 150 kV

Focal spot 0.6 mm maximum power 33 kW

Focal spot 1.2 mm maximum power 100 kW

Generator

Mains voltage 380 V / 400 V; 50/60 Hz, 3-phase

480 V; 60 Hz, 3-phase

Nominal power 65 kW or 80 kW

Eleva workspot

480 GB SSD total

RAM storage capacity 16 GB

Monitor 21.3" LCD color touch monitor

Matrix depth 16 bit/pixel

CD/DVD drive 24x CD reader/writer

8x DVD reader/writer

Eleva Tube Head (ETH)

Full color LCD touch display width 30.7 cm (12.1")

Minimum viewing angle in horizont al and
vertical viewing eld

6 color-coded control buttons – one for each direction

Capacitive sensor for three-axis brake-release

Data displayed at the Eleva Tube Head
amongst others:

Large SkyPlate detector

Typ e Digital Cesium Iodide at detector

Detector size 35 cm x 43 cm (14" x 17")

Active area 34.48 cm x 42.12 cm (13.6" x 16.6")

Image matrix size 2,330 x 2,846 pixel

Pixel size 148 μm

Detector pixels 6.6 Megapixel

A/D conversion 16 bits

Weight 2.8 kg (6.2 lbs)

Also available as small Sk yPlate detector.

SkyPlate E detector

Typ e Digital Cesium Iodide at detector

Detector size 35 cm x 43 cm (14” x 17”)

Active area 34.5 cm x 42.5 cm (approx. 13.6” x 16.7”)

Image matrix size 2,156 x 2,653 pixels

Pixel size 160 μm

Detector pixels 5.7 Megapixel

A/D conversion 16 bits

Weight 3.1 kg (6.8 lbs)

160°

Patient data,
Preview images,
Collimation eld size,
Generator setting,
Live Camera image
(optional)

9

Comfort Position is not available for the Emergency room conguration

Philips DigitalDiagnost C90 is not available in Greater China.

© 2020 Koninklijke Philips N.V. All right s reser ved.
Specications are subject to change without notice.
Trademarks are the propert y of Koninklijke Philips
N.V. or their respective owners.

4522 991 58151 * MAR 2020
