AZ1330D
Docking Entertainment System
User manual
Important notes for users in the U.K.
Mains plug
This apparatus is fitted with an approved 13 Amp plug.To change a fuse in this type of
plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 3 Amp, A.S.T.A. or BSI approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and an
appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a
value of 3 Amp. If a plug without a fuse is used, the fuse at the distribution board
should not be greater than 3 Amp.
Note:The severed plug must be disposed of to avoid a possible shock hazard should it
be inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue = neutral (N),
brown = live (L). As these colours may not correspond with the colour markings identifying the terminals in your plug, proceed as follows:
• Connect the blue wire to the terminal marked N or coloured black.
• Connect the brown wire to the terminal marked L or coloured red.
• Do not connect either wire to the earth terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain that the cord grip is clamped over the
sheath of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
Hearing Safety
Listen at a moderate volume.
• Using headphones at a high volume can impair your hearing. This product can produce sounds in
decibel ranges that may cause hearing loss for a normal person, even for exposure less than a
minute. The higher decibel ranges are offered for those that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your hearing "comfort level" adapts to higher volumes of
sound. So after prolonged listening, what sounds "normal" can actually be loud and harmful to
your hearing. To guard against this, set your volume to a safe level before your hearing adapts and
leave it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, without distor tion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even at normally "safe" levels, can also cause hearing loss.
• Be sure to use your equipment reasonably and take appropriate breaks.
Be sure to observe the following guidelines when using your headphones.
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume as your hearing adapts.
• Do not turn up the volume so high that you can't hear what's around you.
• You should use caution or temporarily discontinue use in potentially hazardous situations.
• Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may
create a traffic hazard and is illegal in many areas.
AUX
VOLUME
DBB
P
R
O
G
M
O
D
E
P
O
W
E
R
S
O
U
R
C
E
A
L
B
U
M
/
P
R
E
S
E
T
-
A
L
B
U
M
/
P
R
E
S
E
T
+
DOCK
DOCK FOR
DOCKING ENTERTAINMENT SYSTEM AZ1330D
for
MP3-WMA PLAYBACK
iR
$
#
2
@
0
9
%
^
!
3
4
7
5
6
1
6 x R20 • UM-1 • D-CELLS
8
& (
)
™
7
≤
@
¡
8
6
4
∞
*
£
1
X
2
3
1
2
8
3
6
7
4
5
9
Supplied accessories
– AC power cord
– Remote control
– Docking kit
• 1 x Apple iPod dock (pre-installed with the
main set)
• dock adaptors (8 adaptors for different iPod
types)
• 1 dust cover (keep the dock connector
from covering dust and dirt)
Top and front panels (See 1)
1 Telescopic antenna – improves FM
reception
2 DOCK –
selects dock source
3 Dock connector – connects iPod
player
4
VOLUME/
VOL +/- –
adjusts volume level
5
MODE – selects different play modes:
e.g. REPEAT or SHUFFLE (random
order)
6 PROGRAM
For disc
– programs tracks and reviews the
program
For Tuner
– auto searches and stores radio
stations
7 ALBUM/PRESET
+/- (
3, 4
)
For MP3-CD/ WMA play:
– select albums
For Tuner
– selects a preset radio station
8 / – opens/closes the disc tray
9
SOURCE:–selects CD/MP3-CD, DOCK
mode, Tuner or AUX
0
POWER –powers on/off the system
!2;–
starts or pauses disc/DOCK playback
∞§
For disc
/ DOCK play:
– skips to the beginning of a current/
previous/ later track
– fast searches backwards and forwards
within a track
For Tuner:
– tunes to a radio station
9 –stops disc playback;
–
erases a program
DBB – turns on/off bass enhancement
@ p – 3.5 mm stereo headphone socket
Helpful hints: The speakers will be muted
when headphones are connected to the set.
#
AUX jack –connects an external source
(3.5 mm socket)
$ Battery door – opens to insert 6 x 1.5V
R-20/ -UM1/ D-cells
% Disc tray – load a disc
^ iR – infrared sensor for remote control
Remote control (See 1)
& CD – selects disc mode
* TUNER – selects tuner mode
( DOCK – selects dock (iPod) source
) AUX– selects AUX mode
¡
9 –stops disc playback;
–
erases a program
™ REPEAT – repeats a track/disc/all
programmed tracks
£ SHUFFLE – turns on/off the random play
mode
≤ DBB – turns on/off bass enhancement
∞ MUTE –mutes or restores the volume
Power Supply
Whenever convenient, use the power supply
cord if you want to conserve battery life.
Make sure you remove the plug from the set
and wall outlet before inserting batteries.
Batteries
Main set (See 1)
• Insert 6 batteries, type R-20, UM1 or D-
cells (not included, preferably alkaline) with
the correct polarity.
English Controls / Power Supply
Remote control
Important!
• Before using the remote control, remove
the insulation plastic tab as shown
in figure 9.
• If the remote control does not function
correctly or the operating range is
reduced, replace the battery with a new
(CR2025) type battery.
1 Pull the battery tray out as shown
in figure 9.
2 Replace a new battery according to polarity
indication, and fully insert the battery tray
back to the original position.
• Incorrect use of batteries can cause
electrolyte leakage and will corrode the
compartment or cause the batteries to burst:
• Do not mix battery types: e.g. alkaline with
carbon zinc. Only use batteries of the same
type for the set.
• When inser ting new batteries, do not try to
mix old batteries with the new ones.
• Remove the batteries if the set is not to be
used for a long time.
Batteries contain chemical substances, so
they should be disposed of properly.
Using AC power
1 Check if the power/mains voltage, as shown
on the type plate located on the
bottom of the set, corresponds to your
local power supply. If it does not, consult your
dealer or service center.
2 Connect the power cord to the
AC~ MAINS inlet and the wall socket.The
set is now ready for use.
3 To switch the set off completely, withdraw
the power cord from the wall socket.
4 Install the unit near the AC outlet and where
the AC power plug can be easily reached.
• Disconnect the power cord from the wall
socket to protect your set during heavy
thunderstorms. Children could seriously injure
themselves as the free end of the cable may
still be live if only the connector is removed
from the MAINS socket at the back of the
unit.
The type plate is located on the
bottom of the set.
Auto power saving
• In CD and DOCK mode, if AZ1330D is in
the PAUSE position for 5
minutes, it will auto
switch to the stop position.
• In CD and DOCK mode, if AZ1330D is in
the STOP position for 15
minutes, it will auto
switch to standby to save power.
Helpful hints:
– To avoid unnecessary energy consumption,
always press POWER on the set to power
off the set after using the set.
CAUTION
- Visible and invisible laser radiation.
If the cover is open, do not look at
the beam.
- High voltage! Do not open.You run
the risk of getting an electric shock.
The machine does not contain any
user-serviceable parts.
- Modification of the product could
result in hazardous radiation of
EMC or other unsafe operation.
This set complies with the radio
interference requirements of the
European Union.
Power Supply
Basic functions
Switching on/off the set
1 To switch on, press POWER.
➜ Display lights up.The system will switch to
the last selected source.
2 To switch off, press POWER again.
➜ Display lights off.
Adjusting volume and sound
Adjust the sound with the VOLUME and
DBB controls.
Digital tuner
Tuning to radio stations
1 Press repeatedly SOURCE (or TUNER
on the remote control) to select FM or
MW.
➜ “TUNER” is displayed briefly, then the
radio station frequency, waveband and, if
programmed, a preset number are shown
(See 2).
2 Press and hold ∞ or § until the frequency in
the display starts running.
➜ The radio automatically tunes to a station
of sufficient reception. Display shows
“
SEARCH” during automatic tuning.
3 Repeat step 2 if necessary until you find the
desired station.
• To tune to a weak station, press ∞ or §
briefly and repeatedly until you have found
optimal reception.
To improve radio reception:
• For FM, extend, incline and turn the
telescopic aerial. Reduce its length if the signal
is too strong.
• For MW, the set uses a built-in aerial. Direct
this aerial by turning the whole set.
Programming radio stations
You can store 15 FM and 10 MW radio
stations in the memory manually or
automatically (Auto store).
Manual programming
1 Tune to your desired station (see Tuning to
radio stations).
2 Press PROG to activate programming.
➜ Display: PROG flashes.
3 Press ALBUM/PRESET +/-
(ALBUM/PRESET
3, 4
on the remote
control ) once or more to allocate a number
(from 1 to 25).
4 Press PROG to confirm.
5 Repeat steps 1-4 to store other stations.
Helpful hints:
– You can erase a preset station by storing
another frequency in its place.
Autostore
Autostore automatically starts programming
radio stations from preset 1. Any previous
presets e.g. manually programmed will be
erased.
1 Press repeatedly SOURCE (or TUNER
on the remote control) to select FM or
MW.
2 Press PROG until “AUTO” flashes.
➜ Available stations are programmed (MW
or FM). After all stations are stored, the
first autostore preset station will then
automatically play.
To listen to a preset or autostore
station
Press the ALBUM/PRESET +/-
(ALBUM/PRESET
3, 4
on the remote
control ) buttons once or more until the
desired preset station is displayed.
Basic Function/Radio MP3-CD/CD Player
About MP3
The music compression technology MP3
(MPEG1 Audio Layer 3) significantly reduce
the digital data of an audio CD while
maintaining CD quality sound.
•
Getting MP3 files: you can either download
legal music files from the internet to your
computer hard disc, or create such files by
converting audio CD files in your computer
through appropriate encoder software.
(128kbps bit rate or higher is recommended
for MP3 files.)
•
Creating a MP3 CD: burn the music files
from your computer hard disc on a CDR or
CDRW using your CD burner.
Helpful hints:
– Make sure that the file names of the MP3 files
end with .mp3 or .wma.
– Number of albums: maximum 100.
– Number of tracks: maximum 999.
– The length of file names affects the number of
tracks for playback.With shorter file names,
more files can be burned on a disc.
Playing a disc
This player plays Audio Discs including
CD-R/ CD-RW, MP3 CD and WMA. Do not
try to play a CD-ROM, CD-I, CDV, VCD,
DVD or computer CD.
IMPORTANT!
• CDs encoded with copyright protection
technologies by some record companies may
be unplayable by this product.
• DRM-protected WMA disc is not supported.
1 Press repeatedly SOURCE (CD on the
remote control) to select CD source.
➜ Display shows flashing “READ” if CD
source is selected (see 3).
➜ “ NO DISC” will be displayed if CD is not
loaded.
3 Press / to open the disc door.
4 Insert a disc with the printed side facing up
and press the disc door gently to close.
➜ The disc scanning of MP3-CD may run
longer than audio CD.
➜ Display: The total number of tracks
appears (and album number for
MP3/WMA) (see 4).
5 Press
2;
to start playback.
➜ First the song title of the track scrolls
across the display, then the track number
and the elapsed playing time are displayed.
For MP3-CD/ WMA only:
➜ The current track number (TRK) and
album number (ALB) will be displayed
interchangeably.
6 To pause playback press
2;
.
➜ Display:
2
and the elapsed playing time
flash.
7 Press
2;
again to resume playback.
8 To stop playback, press
9
.
Helpful hints:
The disc playback will also stop when:
– you open the disc compartment door ;
– you select FM, MW, AUX or DOCK;
– the disc has reached the end of the playback.
Selecting a different track
• Press ∞ or § once or repeatedly until the
desired track number appears in the display.
For MP3-CD/WMA: First press
ALBUM/PRESET +/- ( ALBUM/
PRESET
3, 4
on the remote control )
once or more to find your album.
• In the pause/stop position, press 2; to star t
playback.
MP3-CD/CD Player
Finding a passage within a
track
1 During playback, press and hold down
∞ or §
.
➜ The disc is played at high speed and low
volume.
2 When you recognize the passage you want,
release
∞ or §
.
➜ Normal playback resumes.
Programming tracks
You may store up to 20 tracks in the desired
sequence. If you like, store any track more
than once.
1 In the stop position, press
∞or§
to select
your desired track number.
• For MP3-CD/WMA: First press
ALBUM/PRESET +/- ( ALBUM/PRE-
SET
3, 4
on the remote control ) once or
more to find your album.
2 Press PROG to store desired track.
➜ Display shows “PRO 2” , indicating the
programmed location (See 5).
• If you attempt to program without first
selectig a track, display will show “SELECT
TRACK” briefly, then the total track number
and playing time.
3 Repeat steps 1 to 2 to select and store all
desired tracks.
4 Press
2;
to play the program.
➜ “PROG” is dispalyed during program
playback.
To review your program
In the stop position, press and hold PROG 3
seconds.
➜ The display shows all the stored tracks
(and album numbers for MP3) in
sequence.
Helpful hints:
– Display shows “NO PROG” if no track is
programmed.
– If you try to store more than 20 tracks, no
track can be stored and the display will show
”PROGRAM FULL”.
To erase a program
You can erase a program by:
– pressing
9
(twice during playback or once in
the stop position);
– selecting FM, MW, AUX or DOCK;
– pressing POWER to power off;
– opening the disc door.
➜ “PROGRAM CLEAR” scrolls across the
display once, and “PROG” disappears.
Selecting different play
modes (See 6)
You can select and change the various play
modes before or during playback, and
combine play modes with PROG.
REP – plays the current track continuously.
REP ALL – plays the entire disc/program
continuously.
SHUF – plays all tracks in random order.
REP ALL SHUF – plays all tracks in
random order continuously.
1 To select play modes, press MODE on the
set (REPEAT or SHUFFLE on the remote
contorl) once or more.
2 Press 2; to star t playback if in the stop
position.
➜ Shuffle play will start automatically soon
after shuffle mode is selected.
3 To select normal playback, press MODE on
the set (REPEAT or SHUFFLE on the
remote control) repeatedly until the various
play modes are no longer displayed.
– You can also press 9 to cancel your play
modes.
Helpful hints:
– Shuffle (SHUF and REP ALL SHUF) play is
not available in the program mode.
MP3-CD/CD Player
DOCK
Auxiliary connection
Playing iPod using
AZ1330D
By connecting the iPod to your AZ1330D,
you can listen to the sound of the docked
player through the powerful speakers of the
Hi-Fi system.
Compatible portable player
•
Most Apple iPod models with 30-pin dock
connector as follows:
20GB, 40GB, 20/30GB photo, 40/60GB
photo, 30GB video, 60/80GB video, mini and
nano.
Dock adaptor
Before plugging your player in the dock, snap
the suitable dock adaptor into the dock to
provide a snug fit for the player to be docked.
Selecting the correct dock adaptor
• For the iPod dock, 8 dock adaptors of
different type, as indicated at the back of the
adaptor, are included to fit the following iPod:
20GB, 40GB, 20/30GB photo, 40/60GB
photo, 30GB video, 60GB video, miniand nano.
Playing Apple iPod using AZ1330D
1 Snap the compatible iPod into the dock
connector.
•
AZ1330D will auto switch to DOCK source
(See 7).
2 For iPod, the connected player will play
automatically.
Notes:
–
By using the buttons ( 2;, ¡1, 2™ and
VOLUME ) on the AZ1330D and its remote
control, the following disc playback features are
available: Play/Pause, selecting next/previous track,
fast forwarding/rewinding and changing volume.
–
The buttons ( 2; , ¡1, 2™ and VOLUME ) on
the AZ1330D and its remote control can work
only with playback of the audio contents stored
on the docked player.
Charging iPod battery using the dock
In the power-on and standby mode of
AZ1330D, you can charge the iPod when
docking.
Helpful hints:
–
In DOCK and CD mode, if AZ1330D is in the
STOP position for 15 minutes, it will auto switch
to standby.
Connecting an external device
You can listen to the sound of the connected
external device through your AZ1330D’s
speakers.
1 Press repeatedly SOURCE (or AUX on the
remote contorl) to select AUX mode.
2 Use a line-in cable (not supplied) to connect
AZ1330D’s AUX jack (3.5 mm, located on
the top panel) to an AUDIO OUT or
headphone jack on an external equipment
(such as CD player, or VCR)
Environmental information
All unnecessary packaging material has been omitted.The packaging can be easily separated
into three materials: cardboard, polystyrene and plastic.
Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packaging, dead batteries and old equipment.
Safety information
• Place the set on a hard, flat and stable surface
so that the system does not tilt.
• Do not expose the set, batteries, CDs to
humidity, rain, sand or excessive heat caused
by heating equipment or direct sunlight.
• The apparatus shall not be exposed to
dripping or splashing.
• Adequate ventilation with a minimum gap of
15 cm between the ventilation holes and
surrounding surfaces is necessary to prevent
heat build-up.
• The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
• No objects filled with liquids, such as vases,
shall be placed on the apparatus.
• No naked flame sources, such as lighted
candles, should be placed on the apparatus.
• The mechanical parts of the set contain
self-lubricating bearings and must not be oiled
or lubricated.
• To clean the set, use a dry cloth. Do not use
any cleaning agents containing alcohol,
ammonia, benzene or abrasives as these may
harm the housing.
CD player and CD handling
• If the CD player cannot read CDs correctly,
use a cleaning CD to clean the lens before
taking the set to repair.
• The lens of the CD player should never be
touched!
• Sudden changes in the surrounding
temperature can cause condensation on the
lens of your CD player. Playing a CD is then
not possible. Do not attempt to clean the
lens but leave the set in a warm environment
until the moisture evaporates.
• Always close the CD door to avoid dust on
the lens.
• To clean the CD, wipe in a straight line from
the center towards the edge using a soft,
lint-free cloth. Do not use cleaning agents as
they may damage the disc.
• Never write on a CD or attach any stickers
to it.
Disposal of your old product
Your product is designed and manufactured with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to
a product it means the product is covered by the
European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for electrical and electronic products.
Please act according to your local rules and do not dispose of your old products with
your normal household waste. The correct disposal of your old product will help prevent
potential negative consequences for the environment and human health.
Safety & Maintenance (See 8)
No sound/ power
– Volume not adjusted
• Adjust the VOLUME
– Power cord not securely connected
• Connect the AC power cord properly
– Batteries dead/ incorrectly inserted
• Inser t (fresh) batteries correctly
– Disc contains non-audio files
• Inser t a suitable disc or press
∞ or §
once or
more skip to an audio track, instead of the data
files.
Display does not function properly/No
reaction to operation of any of the
controls
– Electrostatic discharge
• Switch off and unplug the set. Reconnect after a
few seconds.
no indication
– No disc inserted
• Inser t a suitable disc
– Disc badly scratched or dirty
• Replace/clean CD (See Maintenance)
– CD-R(W) is blank or the disc is not finalized.
• Use a finalized CD-R(W)
– Laser lens steam up
• Wait until lens has cleared.
Note:
Make sure the CD is not encoded with
Copyright protection technologies, as some
do not conform to the Compact
Disc standard.
The disc skips tracks
– Disc damaged or dirty
• Replace or clean disc
– Shuffle or program is active
• Switch off shuffle/program
Sound skips during MP3 playback
– MP3 file made at compression level exceeding
320kbps
• Use a lower compression level to record CD
tracks into MP3 format
– Disc damaged or dirty
• Replace or clean disc.
Note:
DRM-protected WMA disc is not supported.
Dock operation
–
The menu navigation or photo playback of the
docked player cannot be carried out through the
buttons on AZ1330D or its remote control.
• The buttons on AZ1330D and its remote control
can control playback of audio contents only.To
navigate the menu, use the controls on the
docked player.
–
Some buttons on AZ1330D and its remote
control have no function.
• The buttons ( 2; , ¡1, 2™ and VOLUME )
function only.
Troubleshooting
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or service centre.
WARNING: Do not open the set as there is a risk of electric shock. Under no cir-
cumstances should you try to repair the set yourself, as this will invalidate the guarantee.
Meet Philips at the Internet
http://www.philips.com
Printed in China PDCC-JH-ZC-0711
W
English
Loading...
