Philips AJ3121-79 User Manual

Clock Radio

Register your product and get support at

www.philips.com/welcome

User manual

AJ3121

1

36

1

2

7

!

@

8

9

4

5

4

0

#

English

Congratulations on your purchase and welcome to Philips!

To fully benefit from the support that Philips offers, register
your product at www.philips.com/welcome.

CONTROLS (see fig. 1 )

1 SET TIME /ALARM SET

- sets the clock / alarm time

2 HR / MIN

- adjusts the hours / minutes for clock / alarm / sleep time

3 REPEAT ALARM / SLEEP OFF

- switches off the active alarm for a 9 minutes period

- switches off the radio sleep function

4 ALARM RESET

- stops the active alarm for 24 hours

5 SLEEP

- activates the radio for sleep function

- adjusts the sleep period

6 TUNING - tunes to radio stations
7 ALARM indicator - lights up when alarm is activated.
8 FM/MW - selects FM/MW waveband
9 VOLUME - adjusts the sound level
0 RADIO / ALARM

OFF: switches off the radio/alarm
RADIO ON: switches on the radio
ALARM - RADIO: activates the radio for alarm
ALARM - BUZZER: activates the buzzer for alarm

! Power cord ­@ Pigtail - improve FM reception
# Battery door - opens to store a 9 volts 6F22 battery (not included) for clock

connects to wall outlet

memory backup.

INSTALLATION

POWER SUPPLY

Check if the power supply, as shown on the type plate located on the bot-

1

tom of the set, corresponds to your local power supply. If it does not, consult
your dealer or service center.

2

Connect the power cord to the wall outlet.

3

To disconnect the set from the power supply completely, remove the
plug from the wall outlet.

CLOCK MEMORY BACKUP

The clock memory backup allows your alarm and clock time settings to be stored
for up to a day when there is a power interruption e.g. power failure. The com­plete clock radio and display illumination will be switched off. As soon as the
power supply returns, the display will indicate the correct time.

1

Remove the battery door to insert a 9 volts 6F22 type battery (not included)
for backup.

2

Replace the battery door.

NOTE:

If no backup battery is installed or the power interruption is prolonged, you
will need to set the clock and alarm times again.

Batteries contain chemical substances so they should be disposed of
properly.

Standby power consumption ..........................................................................1.8 W
