4 Using the air disinfector ����������������������������������������������������������� 28
Understanding the air quality light ������������������������������������������������������������������ 28
Turning on and o ��������������������������������������������������������������������������������������������������� 28
Changing the mode setting ��������������������������������������������������������������������������������� 29
Switching the display indicator �������������������������������������������������������������������������� 30
Using the light on/o function ��������������������������������������������������������������������������� 30
Checking the lter status ����������������������������������������������������������������������������������������31
5 Cleaning and maintenance �������������������������������������������������������31
Cleaning schedule ����������������������������������������������������������������������������������������������������31
Cleaning the body of the air disinfector ����������������������������������������������������������32
Cleaning the particle sensor ��������������������������������������������������������������������������������32
Cleaning the surface of the lter ������������������������������������������������������������������������33
Replacing the lter ��������������������������������������������������������������������������������������������������34
Filter reset �������������������������������������������������������������������������������������������������������������������35
8 Guarantee and service �������������������������������������������������������������� 38
Order parts or accessories ����������������������������������������������������������������������������������� 38
20EN
1 Important
Safety
Read this user manual carefully before you use the appliance, and save it for future reference�
Danger
• Do not clean the appliance with water, any other liquid, or a
(ammable) detergent, nor let them enter the appliance, to avoid
electric shock and/or a re hazard�
• Do not spray any ammable materials such as insecticides or fragrance
around the appliance�
Warning
• Check if the voltage indicated on the appliance corresponds to the local
power voltage before you connect the appliance�
• If the power cord is damaged, you must have it replaced by Philips, a
service center authorized by Philips, or similarly qualied persons in
order to avoid a hazard�
• Do not use the appliance if the plug, the power cord, or the appliance
itself is damaged�
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety�
• Child shall not play with the appliance�
• Cleaning and maintenance shall not be made by children without
supervision�
• Do not block the air inlet and outlet, e�g� by placing any items on the air
outlet or in front of the air inlet�
• Make sure that foreign objects do not fall into the appliance through
the air outlet�
21EN
Caution
• This appliance is not a substitute for proper ventilation, regular vacuum
cleaning, or use of an extractor hood or fan while cooking�
• Always place and use the appliance on a dry, stable, level, and
horizontal surface�
• Leave at least 20cm free space around the appliance and leave at least
30cm free space above the appliance�
• Do not sit or stand on the appliance� Do not place anything on top of
the appliance�
• Do not place the appliance directly below an air conditioner to prevent
condensation from dripping onto the appliance�
• Only use the original Philips lters specially intended for this appliance�
Do not use any other lters�
• Combustion of the lter may cause irreversible human hazard and/
or jeopardize other lives� Do not use the lter as fuel or for similar
purpose�
• Avoid knocking against the appliance (the air inlet and outlet in
particular) with hard objects�
• Do not insert your ngers or objects into the air outlet or the air inlet to
prevent physical injury or malfunctioning of the appliance�
• Do not use this appliance when you have used indoor smoke-type
insect repellents or in places with oily residues, burning incense, or
chemical fumes�
• Do not use the appliance near gas appliances, heating devices or
replaces�
• Always unplug the appliance when you want to move, clean appliance,
replace the lter or carry out other maintenance�
• The appliance is only intended for household use under normal
operating conditions�
• Do not use the appliance in wet surroundings or in surroundings with
high humidity or high ambient temperatures, such as the bathroom,
toilet, or kitchen, or in a room with major temperature changes�
22EN
• The appliance does not remove carbon monoxide (CO) or radon (Rn)� It
cannot be used as a safety device in case of accidents with combustion
processes and hazardous chemicals�
• Do not use the lter unauthorized by Philips in order to make sure
normal running of the appliance, the air purication performace and
the safety of the lter material�
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and regulations regarding
exposure to electromagnetic elds�
Recycling
Do not throw away the product with the normal household waste at the end of its life, but
hand it in at an ocial collection point for recycling� By doing this, you help to preserve the
environment�
Follow your country's rules for the separate collection of electrical and electronic products�
Correct disposal helps prevent negative consequences for the environment and human
health�
23EN
2 Your air disinfector
Congratulations on your purchase, and welcome to Philips!
To fully benet from the support that Philips oers, register your product at
www�philips�com/welcome�
Product overview
Control panel
Air outlet
Particle sensor
Gas sensor
NanoProtect lter
Pro S3 (FY4150/01)
24EN
Back
cover
Controls overview
Control buttons
Filter status/reset buttonDisplay switch button
Power on/o buttonMode switch button
PM2.5
IAIGas
2
Display panel
/
Light on/o button
Wi-Fi indicatorAuto mode
Turbo modeSleep mode
Indoor Allergen Index
display
Gas pollution displayFilter cleaning alert
Filter replacement alert
PM2�5 display
25EN
Air disinfector principle
Disinfection factor: ltration
Air disinfector is equipped with high eciency HEPA lter can ltrate airborne bacteria
eciently� Air borne bacteria is mainly in the type of droplet and droplet nuclei (aerosol)�
Large size droplets will naturally deposit� Droplet nuclei with size range from submicron
to several microns, together with bacteria itself with size range from tens to hundreds of
nanometers, these particles will all be captured by HEPA lter in the disinfector, which has
high ltration ability to aerosol particles with size from as small as 3nm to several microns� As
there are no suitable nutrients and humidity conditions in the lter, the bacteria captured by
HEPA lter will naturally inactivate over time, and the active substances in the lter will also
accelerate the inactivation of bacteria�
3 Getting started
Installing the lter
Remove all packaging of the lter before rst use�
Note: Make sure the air disinfector is unplugged from the electrical outlet before installing
the lter�
12345
1 Pull the back cover and remove it from the appliance�
2 Pull the lter from the appliance�
3 Remove all packaging materials of the lter�
4 Put the lter back into the appliance�
5 Reattach the back cover�
26EN
Understanding Wi-Fi indicator
Wi-Fi icon statusWi-Fi connection status
Blink in orange Connecting to the smartphone
Stable in orange Connected to the smartphone
Blink in whiteConnecting to the server
Stable in white Connected to the server
Wi-Fi function disabled
Wi-Fi connection
Note:
• If you want to connect more than one air disinfector to your smart
device, you have to do this one by one� Complete the set up of
one appliance before you turn on the other appliance�
• Make sure the distance between your air disinfector and Wi-Fi
router is less than 10m without any obstruction�
• If the air disinfector installed at room corner has a weak Wi-Fi
signal, it's recommended to set Wi-Fi booster for remote usage�
1 Scan the QR code, or download the “JD Whale” App from App
market, and then install the App in your smart device�
2 Make sure your smart device is connected to your Wi-Fi
network� Launch the App�
3 Tap “+” , scan the QR code from the user manual or packing box�
4 Make sure that the Wi-Fi indicator blinks orange� Tap Next�
Note:
• If the Wi-Fi indicator is not in orange, touch and to enter pairing mode�
5 Fill the Wi-Fi information and tap Next to add a new device�
6 After the successful pairing and connection, tap Finish� The Wi-Fi indicator will light
up white�
7 If you want to add more smart device to connect with this air disinfector, tap Settings on
the top right of the App� Tap Share with family to scan the generated QR code�
8 On the device which you want to connect to this appliance, download and install the “JD
Whale” App, scan this QR code and follow step 1-6 to add more device�
9 If the connection fails or Wi-Fi inforamtion is changed, follow step 1-6 to reconnect the
Wi-Fi network�
Scan the QR code to
download JD Whale App
Use your JD account to
login the App
27EN
4 Using the air disinfector
Gas levelAir quality light color
L1Blue
L2Blue-purple
L3Purple-red
L4Red
Understanding the air quality light
The air quality light automatically goes on
when the air disinfector is switched on,
and lights up all colors in sequence� After
approximately 30 seconds, the air quality
light becomes stable� The color of the air
quality light is determined by the highest risk
index among PM2�5, IAI and Gas readings�
Air quality light colorAir quality level
BlueGood
Blue-purpleFair
Purple-redPoor
RedVery poor
PM2�5
AeraSense sensing technology accurately
detects and quickly responds to even
the slightest particle change in the air� It
provides you with reassurance with real-time
PM2�5 feedback�
Most of the indoor air pollutants fall under
PM2�5 – which refers to airborne particle
pollutants smaller than 2�5 micrometers�
Common indoor sources of ne particles are tobacco smoke, cooking, burning candles� Some
airborne bacteria and the smallest mold spores, pet allergen and dust mite allergen particles
also fall under PM2�5�
IAI
The professional-grade AeraSense sensor detects
the level of indoor air allergen and with numerical
feedback from 1 to 12 the potential risk level of
indoor air allergens can be displayed� 1 indicates
best air quality�
PM2�5 levelAir quality light color
≤35Blue
36-75Blue-purple
76-115Purple-red
>115Red
IAI levelAir quality light color
1-3Blue
4-6Blue-purple
7-9Purple-red
10-12Red
GAS
With an advanced gas sensor, a display ranging from
L1 to L4 shows the level change of potential harmful
gases (incl� VOC, odor, etc�) detected� L1 indicates
best air quality�
28EN
Turning on and o
Note:
• For optimum purication performance, close doors and windows�
• Keep curtains away from the air inlet or air outlet�
1 Put the plug of the air disinfector in the power socket�
2 Touch to switch on the air disinfector�
» The QR code for App is displayed on the screen for the
rst use, you can scan it and download the App�
» The air disinfector operates in the auto mode with PM2�5
PM2.5
IAIGas
displayed on the center of the screen�
» After measuring the air quality, the air disinfector
automatically switches to the display which has the
highest readings among PM2�5, IAI and Gas�
3 Touch and hold the button for 3 seconds to switch o the
air disinfector�
Note: If the air disinfector stays connected to the electrical outlet after turning OFF, the air
disinfector will operate under the previous settings when turned ON again�
Changing the mode setting
You can choose Auto mode, Turbo mode or the Sleep mode by touching the button�
Touch the button once to display the current mode�
Turbo Mode
Auto mode ( )
In Auto mode, the dual-sensor sense the air quality in realtime and the appliance automatically adjusts the fan speed
in accordance with the ambient air quality�
Turbo mode ( )
In Turbo mode, the air disinfector operates on the highest
speed�
29EN
Sleep Mode
3s
Sleep mode ( )
In Sleep mode, the air disinfector operates quietly at a low
speed� After 3 seconds, the screen lights o�
Switching the display indicator
Note: The PM2�5 level is displayed on the central of the screen by default�
12
Particulate
PM2.5
IAIGas
2
1 Touch the button once to switch the display indicator�
2 Touch and hold the button for 3 seconds to check the explaination of PM2�5/Gas/ IAI
level�
Matter 2.5
Using the light on/o function
PM2.5
IAIGas
2
With the light sensor, the control panel can automatically turn on, turn o or dim according to
the ambient light� The control panel will be o or dim when the ambient light is dark� You can
touch any button to wake up all lights� Then, if no further operation, all lights will be o or
dim again to match with the ambient light�
You can touch the light on/o button manually to turn o all lights and the control pa
Touch any button to wake up all lights�
30EN
nel�
Checking the lter status
• Touch the lter status check/reset button to check the lter service life status�
» The percentage of remaining service life of the lter displays on the screen�
Icon colorFilter life indicationDisplay (%)
BlueOptimal service life16-100
Filter status
%100
Blue-purpleGood service life9-15
Purple-red
Red
Service life almost
reaches the end
Service life ends, replace
the lter
4-8
0-3
Note: The appliance goes back to normal display if no operations after 3 seconds�
5 Cleaning and maintenance
Note:
• Always unplug the appliance before you clean it�
• Never immerse the appliance in water or any other liquid�
• Never use abrasive, aggressive, or ammable cleaning agents such as bleach or alcohol to
clean any part of the appliance�
• Never use any liquids (including water) to clean the lter�
• Do not attempt to clean the particle sensor and gas sensor with a vacuum�
Cleaning schedule
PM2.5
IAIGas
FrequencyCleaning method
Wipe the fabric part of the appliance
with a damp cloth, wipe the plastic
When necessary
part of the appliance with a soft, dry
cloth
Clean the air outlet cover
Every two months
When displays
on the screen
Clean the particle sensor with a dry
cotton swab
Clean the surface of the lter
31EN
Cleaning the body of the air disinfector
Regularly clean the inside and outside of the air disinfector to prevent dust from collecting�
1 Wipe the fabric surface gently with a damp cloth�
2 Use a soft, dry cloth to clean both the interior and exterior of the air disinfector and the
air outlet�
Note:
• The fabric covered on the appliance can not be removed�
• Do not use hot water, alcohol, harsh cleaners to clean the fabric�
Cleaning the particle sensor
Clean the particle sensor every 2 months for optimal functioning of the appliance�
Note:
• If the air disinfector is used in a dusty environment, it may need to be cleaned more often�
• If the humidity level in the room is very high, condensation may develop on the particle
sensor and the air quality light may indicate a more poor air quality even though the air
quality is actually good� If this occurs, clean the particle sensor�
• The gas sensor doesn't need to be cleaned�
1 Switch o the air disinfector and unplug from the power socket�
235
2 Pull the back cover and remove it from the appliance�
3 Clean the particle sensor with a damp cotton swab�
4 Dry all parts thoroughly with a dry cotton swab�
5 Reattach the back cover�
32EN
Cleaning the surface of the lter
Clean surface
of
long press
to reset.
PM2.5
IAIGas
Filter alert light statusAction
lter and
The lter cleaning alert
displays on the screen
Clean the surface of the lter with a vacuum
1 Switch o the air disinfector and unplug from the power socket�
23456
2 Pull the back cover and remove it from the appliance�
3 Pull the lter from the appliance�
4 Clean the surface of the lter with a vacuum�
5 Put the lter back into the appliance�
6 Reattach the back cover�
7 Put the plug of the air disinfector in the power socket�
8 Touch the button to switch on the appliance�
9 Touch and hold the lter status check/reset button for
3 seconds to reset the lter cleaning time�
» The screen displays a message “Filter cleaning
completed”�
10 Wash your hands thoroughly after cleaning the lter�
Filter
cleaning completed.
33EN
Replacing the lter
Understanding the healthy protection lock
This air disinfector is equipped with a lter replacement indicator to make sure that the
lter is in optimal condition when the air disinfector is operating� When the lter need to be
replaced, the lter replacement alert lights up red�
If the lter is not replaced in time, the air disinfector will stop operating and automatically
lock to protect the air quality in the room� Replace the lter as soon as possible�
Replacing the lter
PM2.5
IAIGas
Change lter
Change lter
then long
then long
press to
press to
reset
reset
lter
lter
Note:
• The lter is not washable or reusable�
• Always turn o the air disinfector and unplug from the electrical outlet before replacing the
lter�
Filter alert light statusAction
The lter replacement alert lights
up
Replace the NanoProtect lter Pro S3 (FY4150/01)
34EN
1 Switch o the air disinfector and unplug from the power socket�
23456
2 Pull the back cover and remove it from the appliance�
3 Pull the lter from the appliance�
4 Remove all packaging materials of the new lter�
5 Put the new lter into the appliance�
6 Reattach the back cover�
7 Put the plug of the air disinfector in the power socket�
8 Touch the button to switch on the appliance�
9 Touch and hold the lter status check/reset button for
3 seconds to reset the lter lifetime counter�
10 Wash your hands thoroughly after replacing the lter�
Note: Do not smell the lter as it has collected pollutants from the
air�
Filter reset
Filter has been replaced.
You can replace the lter even before lter replacement alert ( ) displays on the screen�
After replacing a lter, you need to reset the lter lifetime counter manually�
1 Touch the power button for 3 seconds to turn o the
appliance and unplug from power socket�
2 Put the power plug in the power socket�
PM2.5
IAIGas
3 Within 15 seconds after power on, touch and hold
and button for 3 seconds to reset the lter lifetime
counter�
+
3s
35EN
6 Storage
1 Turn o the air disinfector and unplug from the power socket�
2 Clean the air disinfector, particle sensor and the surface of the lter (see chapter
“Cleaning and maintenance”)�
3 Let all parts air dry thoroughly before storing�
4 Wrap the lter in air tight plastic bags�
5 Store the air disinfector, lter in a cool, dry location�
6 Always thoroughly wash hands after handling the lter�
7 Troubleshooting
This chapter summarizes the most common problems you could encounter with the
appliance� If you are unable to solve the problem with the information below, contact the
Consumer Care Center in your country�
ProblemPossible solution
The appliance does
not work even though
it is plugged in�
The airow that
comes out of the air
outlet is signicantly
weaker than before�
The air quality does
not improve, even
though the appliance
has been operating
for a long time�
36EN
• Check if the back cover is properly installed�
• The lter replacement alert has been on continuously but you
have not replaced the corresponding lter� As a result, the
appliance is now locked� In this case, replace the lter and long
press to reset the lter lifetime counter�
• The surface of the lter is dirty� Clean the surface of the lter (see
the chapter “Cleaning and maintenance”)�
• Check if the packing material is removed from the lter�
• The lter has not been placed in the appliance� Make sure that
the lter (FY4150/01) is properly installed�
• The particle sensor is wet� The humidity level in your room is high
and causes condensation� Make sure that the particle sensor is
clean and dry (see the chapter “Cleaning and maintenance”)�
• Room size is large or the outdoor air quality is poor�
For optimum purication performance, please close the doors
and windows when operating the air disinfector�
• There are indoor pollution resources� For instances, smoking,
cooking, incense, perfume or alchohol�
• Filter reaches the end of life� Replace the lter with a new one�
ProblemPossible solution
The color of the air
quality light always
stays the same�
The appliance
produces a strange
smell�
The appliance is extra
loud�
The screen displays
that the back cover is
opened�
Error code “E1”
displays on the
screen�
• The particle sensor is dirty� Clean the particle sensor (see the
chapter “Cleaning and maintenance”)�
• The rst few times you use the appliance, it may produce a plastic
smell� This is normal� However, if the appliance produces a burnt
smell even if removing lter, contact your Philips dealer or an
authorized Philips service center� The lter may produce smell
after being used for a while because of the absorption of indoor
gases� It’s recommended that you reactivate the lter by putting it
in direct sunlight for repeated use� If odor still exists, replace the
lter�
• It's normal if the appliance runs at the Turbo mode�
• In the Auto mode, if the appliance is too loud, maybe the
appliance runs at high speed automatically because air quality
becomes worse� You can choose the Sleep mode with lower noise�
• If anything drops into air outlet, it may also cause abnormal loud
sound� Immediate turn o appliance, turn appliance upside down,
to get foreign objectives out of appliance�
• If there is abnormal sound, contact the Consumer Care Center in
your country�
• Shut o the power rst, then install the back cover correctly�
Connect the appliance with power and retry�
• The motor has malfunctions� Contact the Consumer Care Center in
your country�
• If the router your air disinfector is connected to is dual – band and
currently it is not connecting to a 2�4GHz network, please switch
to another band of the same router (2�4GHz) and try to pair your
air disinfector again� 5GHz networks are not supported�
• Web authentication networks are not supported�
• Check if the air disinfector is within range of the Wi-Fi router� You
can try to locate the air disinfector closer to the Wi-Fi router�
The Wi-Fi setup is
not successful�
• Check if the network name is correct� The network name is casesensitive�
• Check if the Wi-Fi password is correct� The password is casesensitive�
• Retry the setup with the instructions in section “Wi-Fi connection”�
• The Wi-Fi connectivity can be interrupted by electromagnetic
or other interferences� Keep the appliance away from other
electronic devices that may cause interferences�
• Check if the mobile device is in airplane mode� Make sure to have
the airplane mode deactivated when connecting to the Wi-Fi
network�
• Consult the help section in the App for extensive and up-to-date
troubleshooting tips�
8 Guarantee and service
If you need information or if you have a problem, please visit the Philips website at
www�philips�com or contact the Philips Consumer Care Center in your country (you can nd
its phone number in the worldwide guarantee leaet)� If there is no Consumer Care Center in
your country, go to your local Philips dealer�
Order parts or accessories
If you have to replace a part or want to purchase an additional part, go to your Philips dealer
or visit www�philips�com/support�
If you have problems obtaining the parts, please contact the Philips Consumer Care Center in
your country (you can nd its phone number in the worldwide guarantee leaet)�
