Philips 7616X, 7617X User Manual

7617X 7616X

Rechargeable Cordless Razor

ENGLISH

3. Never operate this razor if it has a damaged cord or charging plug, if it is not working properly, if it has been dropped or damaged, or dropped into water while plugged in. Return the razor to an Authorized Norelco Service Location for examination and repair.

4. Keep the razor, cord and charging plug away from heated surfaces.

5. Never drop or insert any object into any opening.

6. Do not charge or plug in razor outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.

7. Do not use this razor with a damaged or broken comb, as facial injury may occur.

8. Always attach plug to razor first, then charging plug into outlet. Be certain that plug is inserted firmly into razor,up to mark indicated on plug.To disconnect, turn razor off then remove charging plug from outlet.

9. Never put the razor in direct sunlight or store in a pouch at a temperature above 140ºF.

10.Razor can be rinsed under running tap water. Do not submerge razor in water.

11.To prevent possible damage to the cord, do not wrap cord around the razor.

SAVE THESE INSTRUCTIONS

IMPORTANT

Your razor contains NICKEL-CADMIUM RECHARGEABLE BATTERIES. See Battery Removal instruction sheet for

battery disposal information.

IMPORTANT SAFETY INSTRUCTIONS

When using an electric razor, basic safety precautions should always be followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for a razor that has fallen into water. Unplug immediately.

2. Do not use razor while bathing or in a shower.

3. Do not place or store razor while plugged in where it can fall or be pulled into a tub or sink. Do not place or drop into water or other liquid.

4. Always unplug this razor from the electrical outlet immediately after use, except when razor is (re)charging.

5. Unplug this razor before cleaning.

6. When discarding razor, unplug razor and remove rechargeable batteries. See Battery Removal instructions.

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1. Close supervision is necessary when this razor is used by, on, or near children or invalids.

2. Use this razor for its intended household use as described in this manual. Do not use attachments not recommended by Philips Electronics North America Corporation.

ENGLISH

Table of Contents

Features.........................................................2-3

LED Charge Indicator ...................................4

Charging............................................................4

Put It To The Test & Shaving Tips.................5

How To Shave With An

Electric Razor ..................................................6

Trimming...........................................................7

Cleaning ......................................................7-11

Assistance.......................................................12

Accessories....................................................12

Battery Removal...........................................13

Spanish ............................................................14

Warranty.......................................Back Cover

ENGLISHENGLISH

Name Address City State Zip Daytime Telephone No. ( ) Email Address REASON FOR RETURNING:

60-DAY MONEY-BACK

GUARANTEE

To enjoy the closest and most comfortable shave from your new Norelco Men’s Razor, the razor should be used exclusiv

ely for 3 weeks. This allows your hair and skin enough time to adapt to the Norelco Shaving System. If, after that period of time, you are not fully satisfied with your Norelco Men’s Razor, send the product back and we’ll refund you the full purchase price. The razor must be shipped

prepaid by insured mail, insurance prepaid, and have the sales slip, indicating purchase price and the date of purchase, enclosed.The razor must

be postmarked no later than 60 da

ys after the date of purchase. Norelco reserves the right to verify the purchase price of the razor and limit refunds not to exceed suggested retail price.

Send dated sales receipt, your complete name and address as indicated below, and the razor, prepaid to:

Norelco Consumer Products Company

A Division of Philips Electronics

North America Corporation

450 North Medinah Road, Dock 16

Roselle, IL 60172-2329

Please allow 4-6 weeks for delivery of check. (Please Print)

AREA CODE

ENGLISH

Pop-Up Trimmer

Automatic

Worldwide Voltage

100V to 240V AC

Cleaning Brush

Travel/Storage Pouch

Rechargeable - Initial 12 hours Full Charge

for up to 45 minutes

of cordless shave time

Cordless - To shave

without a cord

Full 2-Year Warranty

60-Day Money-Back

Guarantee

Features

Quadra Action Shaving System

Razor Head Assembly

Protective Razor Head Cap

Individually Floating Heads

Razor Head Release Button

• Hair Chamber captures shaven hair

Electronic ON/OFF Button

LED Charge Indicator Light

ENGLISH

How the Norelco Lift and Cut®Patented Shaving System Makes Close Comfortable:

Groove channels beard closer to cutting system

Lifter raises hair Slots to cut long hairs Holes to cut short hairs

even closer

Recharging

First time charging requires 12 hours.After initial charge, recharging requires approximately 8 hours.

Disconnect the charging plug from outlet. Do not keep razor permanently plugged into outlet.

Put It To The Test & Shaving & Tips

◗ 21 Day Trial and Conversion Process.

It is a fact that your skin and beard need time to adjust to a new shaving system.

◗ Use your new razor exclusively for 3 weeks to

fully enjoy the closeness of a Norelco shave.

◗ At first you may not get as close a shave as you

expect, or your face may even become slightly irritated.This is normal since your beard and skin will need time to adjust. Invest 3 weeks and you'll soon experience the full joy of your new razor.

◗ Stick with it! If you alternate shaving

methods during the adjustment period, it may make it more difficult to adapt to the Norelco shaving system.

◗ If you are still not convinced after 21 days,

Norelco will refund you the full purchase price, guaranteed.

ENGLISH

LED Charge Indicator

◗ LED Charge Indicator Light

The green LED Charging Indicator will light up to indicate razor is (re)charging.

Charging

◗ Battery performance is best if you recharge

only when the batteries are (almost) completely empty.

◗ Charging or recharging at temperatures below

40ºF or higher than 95ºF adversely affects lifetime of batteries.

◗ Continuously recharging razor will reduce life of

batteries.

Connect cord to razor. Plug the charging plug into any 120V to 240V AC outlet. Use only the charging plug provided.The green Charging Indicator will light up to indicate razor is (re)charging.

◗ An adaptor plug may be necessary for charging

in some foreign countries. Use an attachment plug adaptor of the proper configuration for the power outlet.The charging plug will automatically convert to work on 100V to 240V AC Systems.

◗ Do not charge razor in pouch.

First time charging and recharging after non-use for 1 month or more requires a full 12 hours.

ENGLISH

Trimming

To groom sideburns and moustache:

Turn razor ON.

Push up Trimmer Slide Switch.The Trimmer can be activated while the razor is running.

Hold Trimmer as shown and move in downward strokes with gentle pressure.

Close Trimmer by sliding Trimmer switch down.

Turn razor OFF.

Cleaning

Every Week: Razor Heads

◗The easiest and most hygienic way to clean the

razor heads is to rinse them every week with hot water. Water from the tap should be on a hot setting but BE CAREFUL TO TEST WATER FIRST SO AS NOT TO BURN OR SCALD HANDS.

◗ Regular cleaning guarantees better shaving

results.

◗ You may also quickly rinse your razor heads

after each

use.

ENGLISH

How To Shave With An Electric Razor

◗ Use this razor for its intended household use as

described in this manual.

◗ Shaving with a clean, dry face gives the best

results.

Turn razor ON. Shave against the direction of beard growth using both straight and circular movements.

Stretch your skin with your free hand so blades can lift and cut whiskers. Gently press razor to skin, so the floating heads can follow the contours of your face. DO NOT press too hard.Too much pressure can pinch the skin into the combs.

Turn razor OFF.

Put the protective razor head cap on the razor to protect razor heads.

◗ Replace Quadra Action razor heads (model #

HQ6) once a year for optimal shaving results.

ENGLISH
