Philips 65OLED935/43 user manual
OLED935 Series
User Manual
65OLED935
Register your product and get support at
www.philips.com/TVsupport
Contents
1 What's new 4
1.1 Home and channels
1.2 Apps and Philips TV Collection
4
4
2 Setting Up 5
2.1 Read Safety
2.2 TV Stand and Wall Mounting
2.3 Tips on Placement
2.4 Power Cable
2.5 Antenna Cable
5
5
5
5
5
3 Remote Control 7
3.1 Key Overview
3.2 Pair Your Remote Control to TV
3.3 Voice Search
3.4 IR Sensor
3.5 Batteries
3.6 Cleaning
7
8
8
8
9
9
4 Switching On and Off 10
4.1 On or Standby
4.2 Keys on TV
10
10
5 Channels 11
5.1 Watching channels
5.2 Favourite Channels
5.3 Closed captioning (CC) and language
11
12
13
6 Channel Installation 15
6.1 Antenna/Cable Installation
6.2 Service navigation
6.3 Channel List Copy
15
15
15
7 Connect Devices 17
7.1 About Connections
7.2 Home Theatre System - HTS
7.3 Smartphones and Tablets
7.4 Blu-ray Disc Player
7.5 Bluetooth
7.6 Headphones
7.7 Game Console
7.8 USB Hard Drive
7.9 USB Keyboard
7.10 USB Flash Drive
7.11 Photo Camera
7.12 Camcorder
7.13 Subwoofer
7.14 Computer
17
17
18
18
18
19
19
19
20
21
21
21
22
22
8 Connect your Android TV 23
8.1 Network and Internet
8.2 Google Account
8.3 Home Screen
8.4 Philips TV Collection App
23
24
25
26
9 Apps 27
9.1 About Apps
27
9.2 Google Play
9.3 Start or Stop an App
9.4 Lock Apps
9.5 Manage Apps
9.6 Storage
27
28
28
29
29
10 Internet 31
10.1 Start Internet
10.2 Options on Internet
31
31
11 Quick Menu 32
12 Sources 33
12.1 Switch to a device
12.2 Options for a TV Input
12.3 Device Name and Type
12.4 Rescan Connections
33
33
33
33
13 Networks 35
13.1 Network
13.2 Bluetooth
35
35
14 Settings 36
14.1 Picture
14.2 Sound
14.3 Ambilight Settings
14.4 Eco Settings
14.5 General Settings
14.6 Clock, Region, and Language Settings
14.7 Android Settings
14.8 Universal Access Settings
14.9 Lock Settings
36
39
41
43
43
46
46
46
47
15 Videos, Photos and Music 48
15.1 From a Computer or NAS
15.2 Favourites Menu
15.3 Most Popular Menu and Last Played Menu
15.4 From a USB Connection
15.5 Play your Videos
15.6 View your Photos
15.7 Play your Music
48
48
48
48
48
49
51
16 TV Guide 52
16.1 What You Need
16.2 TV Guide Data
16.3 Using the TV Guide
52
52
52
17 Recording and Pause TV 54
17.1 Recording
17.2 Pause TV
54
55
18 Smartphones and Tablets 57
18.1 Philips TV Remote App
18.2 Google Cast
57
57
19 Games 58
19.1 What You Need
19.2 Gamepads
19.3 Play a Game From Game Console
58
58
58
2
20 Ambilight 59
20.1 Ambilight Style
20.2 Ambilight Off
20.3 Ambilight Settings
20.4 Lounge Light Mode
20.5 Sunrise Alarm
20.6 Ambisleep
20.7 Ambilight Extension
59
59
59
59
60
60
60
21 Top Picks 62
21.1 Now on TV
21.2 TV on Demand
21.3 Video on Demand
62
62
62
22 Software 64
22.1 Update Software
22.2 Software Version
22.3 Automatic Software Update
22.4 View Software Update History
22.5 Open Source Software
22.6 Open Source License
22.7 Announcements
64
64
64
64
65
65
65
23 Specifications 66
23.1 Environmental
23.2 Power
23.3 Operating System
23.4 Reception
23.5 Display Type
23.6 Display Input Resolution
23.7 Connectivity
23.8 Sound
23.9 Multimedia
66
66
66
66
66
66
67
67
67
24 Help and Support 68
24.1 Register your TV
24.2 Using Help
24.3 Troubleshooting
24.4 Online Help
24.5 Support and Repair
68
68
68
71
72
25 Safety and Care 73
25.1 Safety
25.2 Screen Care
73
74
26 Terms of Use 75
26.1 Terms of Use - TV
26.2 Terms of Use - Smart TV
26.3 Terms of Use - Philips TV Collection
75
75
75
27 Copyrights 76
27.1 HDMI
27.2 Dolby Audio
27.3 Dolby Vision and Dolby Atmos
27.4 DTS-HD (italics)
27.5 DTVi
27.6 DTS Play-Fi
27.7 Wi-Fi Alliance
27.8 Kensington
27.9 Other Trademarks
76
76
76
76
76
76
77
77
77
28 Disclaimer regarding services
78
and/or software offered by third
parties
Index 79
3
1
What's new
1.1
Home and channels
The new Home launcher
Press HOME on your remote control to get your
new Android Home screen. From here you can decide
what to watch by browsing entertainment options
from app and live TV. Your Home has channels to let
you discover great contents from your favourite apps.
You can also add additional channels or find new
apps to get more contents.
“Play Next” channel
You can always know what to watch next from Play
Next channel on the Home screen. Start watching
from where you left off and get notifications about
new episodes in the Play Next channel. Press and
hold Select on a movie or TV show to add it directly
to the Play Next channel.
All your premium apps are available within the Philips
TV Collection app. Launch it using the banner on
the Apps row. The Philips TV Collection app will also
contain recommendations for new Apps and more.
Accessing settings from Home
You can access All Settings menu via the icon at the
top right corner. You can also find the Frequent
settings menu and common menu items in the Philips
TV Menu, which can be invoked directly from the
remote control.
System bar on Home screen
The System bar on the top of Home screen contains
following features.
- Search button: to trigger Google search with voice
or text input.
- Input source: to launch the input source list and
switch to any of the connected devices.
- Notifications: to provide you the messages about
your Smart TV system.
- Settings: to access all setting menu and adjust the
TV settings.
- Clock: to indicate the system clock.
1.2
Apps and Philips TV Collection
Favourite Apps on the first row
You can find more apps in the Apps page which can
be opened by clicking the Apps icon at the left end of
the Apps row. You can also add more apps as
favourite from the Apps page.
Philips TV Collection
4
2
Setting Up
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
2.1
Read Safety
Read the safety instructions first before you use the
TV.
To read the instructions, in Help, press the colour
key Keywords and look up Safety Instructions.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com.
Use the product type number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
2.3
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Dim lighting conditions in the room for best
Ambilight effect.
• The ideal distance to watch TV is 2 to 5 times its
diagonal screen size. When seated, your eyes should
be level with the centre of the screen.
• When wall mounted, position the TV up to 15 cm
away from the wall.
Note:
Please keep the TV away from dust-producing
sources such as stoves. It is suggested to clean the
dust regularly to avoid getting dust into the TV.
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
• 65OLED935
VESA MIS-F 300x300, M6 (min.: 10mm, max.:15mm)
Preparation
Make sure that the metal screws, to mount the TV to
the VESA-compliant bracket, go about 10mm deep
inside the threaded bushes of the TV.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
2.4
Power Cable
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
For more information, in Help, press the colour
key Keywords and look up Switching On for
more information on switching the TV on or off.
5
2.5
Antenna Cable
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
6
3
Remote Control
3.1
Key Overview
Top
Middle
1 - OK key
To confirm a selection or setting. To open the channel
list while watching TV.
1 - Standby / On
To switch the TV on or back to Standby.
2 - VOICE microphone
3 -
To select one of the Ambilight style.
4 - Philips TV Collection
To launch Philips TV Collection App.
5 - YouTube
To open the YouTube App directly.
6 - Quick Menu
To open the Quick Menu with typical TV functions.
7 - - EXIT
To switch back to watch TV or to stop an interactive
TV application.
8 -
To open the Netflix App directly. With the TV switched
on or from standby.
• If you have a Netflix membership subscription, you
can enjoy Netflix on this TV. Your TV must be
connected to the Internet.
• To open Netflix, press to open the Netflix
App. You can open Netflix immediately from a TV in
standby.
www.netflix.com
2 - BACK
To switch back to the previous channel you selected.
To return to previous menu.
To go back to the previous App/Internet page.
3 - Playback and Record
• Play , to playback.
• Pause , to pause playback
• Stop , to stop playback
• Rewind , to rewind
• Fast forward , to go fast forward
• Record , to start recording
4 - Colour keys
Direct selection of options. Blue key , opens Help.
5 - Arrow / navigation keys
To navigate up, down, left or right.
6 - HOME
To open the Home menu.
7 - OPTIONS
To open or close the options menu.
Bottom
9 - SOURCES / PAIR
• To open or close the Sources menu.
• To pair the remote control to the TV.
10 - Google Assistant™
To launch the Google Assistant™.
7
1 - TV Guide
To open or close the TV Guide.
2 - Volume
Prese + or - to adjust the volume level.
(within 1m distance) during pairing in order to ensure
success.
3 - If the TV does not launch the voice control
field when press , pairing was unsuccessful.
4 - It is advisable to wait until the set has fully started
up and launched all background processes before
pairing mode is entered as the toast message
containing further instructions may appear too late,
thereby negatively impacting the pairing procedure.
Pairing or pairing again
If the pairing with the remote control was lost, you
can pair the TV with the remote control again.
You can simply long press
the PAIR key (approximate for 3 seconds) for
pairing.
Alternatively, go Settings > Wireless and networks
> Remote control > Pair remote control, then follow
the on-screen instructions.
3 - Number keys
To select a channel directly.
4 - (Dot)
To enter digital sub-channels
5 - Channel
Prese + or - to switch to the next or previous channel
in the channel list. To open the next or previous page
in Text/Teletext.
6 - Mute
To mute the sound or to restore it.
7 - Channel list
To open the channel list.
3.2
Pair Your Remote Control to TV
This remote control uses both Bluetooth and IR
(infrared) to send its commands to the TV.
• You can use this remote control via IR (infrared) for
most operations.
• To use advanced operation like voice search and
remote control keyboard, you need to pair (link) the
TV with the remote control.
When you start the initial TV installation, the TV
invites you to long press the PAIR key, and by
doing so, the pairing will be done.
Note:
A message appears when the pairing is successful.
Remote Control Software
Settings > Wireless and networks > Remote
control > Remote control info
Once the remote control is paired, you can check the
current remote control software version.
Settings > Wireless and networks > Remote
control > Update remote control software
Check available remote control software for updates.
3.3
Voice Search
You can search for videos, music or anything else on
the Internet by simply using your voice. You can
speak into the microphone on the remote control.
You need to pair the remote control to the TV before
use voice search.
To use Voice...
1 - Press on remote control, the blue light on the
remote control lights up and the search field
opens, the microphone is active.
2 - Speak out what you are looking for with clear
pronunciation. You can speak for 10 seconds before
the microphone switches off. It might take some time
for the results to appear.
3 - In the list of search results, you can select the
item you want.
1 - Once the remote control has entered pairing
mode successfully, the blue LED indicator ring around
the microphone on the front side of the remote
control starts blinking.
2 - The remote control must be kept close to the TV
8
3.4
IR Sensor
The TV can receive commands from a remote control
that uses IR (infrared) to send commands. If you use
such a remote control, always make sure you point
the remote control at the infrared sensor on the front
of the TV.
Warning
Do not put any objects in front of IR sensor of the TV,
it may block the IR signal.
3.5
Batteries
If the TV does not react on a key press on the remote
control, the batteries might be empty.
To replace the batteries, open the battery
compartment on the back-bottom of the remote
control.
household cleaners on the remote control.
1 - Slide the battery door in the direction shown by
the arrow.
2 - Replace the old batteries with 2 Alkaline, type
AAA-LR03-1.5V batteries. Make sure the and the
ends of the batteries line up correctly.
3 - Reposition the battery door and slide it back until
it clicks.
Remove the batteries if you are not using the remote
control for a long time.
Safely dispose of your old batteries according to the
end of use directions.
For more information, in Help, select Keywords and
look up End of use.
3.6
Cleaning
Your remote control is treated with a scratch-resistant
coating.
To clean the remote control, use a soft damp cloth.
Never use substances such as alcohol, chemicals or
9
4
4.2
Switching On and Off
4.1
On or Standby
Make sure the TV is connected to the mains AC
power. Connect the supplied power cord to the AC
in connector at the back of the TV. The indicator light
at the bottom of the TV lights up.
Switch on
Press on the remote control to switch the TV
on. Alternatively, press HOME. You can also
press the small joystick key on the back of the TV to
switch the TV on in case you can't find the remote
control or its batteries are empty.
Switch to standby
To switch the TV to standby, press on the remote
control. You can also press the small joystick key on
the back of the TV.
Keys on TV
If you lost the remote control or its batteries are
empty, you can still do some basic TV operations.
To open the basic menu…
1 - With the TV switched on, press the joystick key on
the back of the TV to bring up the basic menu.
2 - Press left or right to select Volume,
Channel or Sources. Select Demo, to start
a demo movie.
3 - Press up or down to adjust the volume or tune to
the next or previous channel. Press up or down to go
through the list of sources, including the tuner
selection. Press the joystick key to start the demo
movie.
4 - The menu will disappear automatically.
To switch the TV on standby, select and press the
joystick key.
In standby mode, the TV is still connected to the
mains power but consumes very little energy.
To switch off the TV completely, disconnect the
power plug.
When disconnecting the power plug, always pull the
power plug, never the cord. Ensure that you have full
access to the power plug, power cord and outlet
socket at all times.
10
5
Channels
5.1
Watching channels
Tune to a Channel
press BACK to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
For more information, in Help, press the colour
key Keywords and look up Child Lock for more
information.
To start watching TV channels, press . The TV tunes
to the channel you last watched.
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press BACK.
You can also tune to channels from a Channel List.
Lock a Channel
Lock and Unlock a Channel
Age Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Child
Lock code first.
To set an age rating…
1 - Press , select All Settings and press OK.
2 - Select Child Lock > Age rating lock and
press OK.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set code in Child lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
4 - Back in Age rating lock, select the age and
press OK.
5 - Press (left) repeatedly if necessary, to close
the menu.
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to lock.
4 - Press OPTIONS and select Lock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it. A
locked channel is marked with a (lock).
6 - Press (left) to go back one step or
press BACK to close the menu.
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to unlock.
4 - Press OPTIONS and select Unlock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
To switch off the parental age rating, select Free.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Content rating
To set a content rating that will lock rated
programmes...
1 - Press , select All Settings and press OK.
2 - Select Child lock and press (right) to enter
the menu.
3 - Select Content rating lock .
4 - Set the content and press OK. The selected
content is blocked.
5 - Press (left) repeatedly if necessary, to close
the menu.
11
Channel Options
Open options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
(analogue or digital) or depending on the TV settings
you made, some options are available.
To open the options menu…
1 - While watching a channel, press OPTIONS.
2 - Press OPTIONS again to close.
connected HDMI device.
2 - Press OPTIONS, select Picture-in-picture, and
press OK.
3 - The channel or video you are watching appears
in a small window, in a corner of the screen chosen
by the system.
4 - You can continue watching TV or video while
using other apps.
5 - On the top row of the Home screen, you can
select Open or Stop to switch back or close the small
screen.
Note:
Closed Caption
Switch Closed caption on or off with this options.
Select On during mute to show closed captions only
when the sound is muted with .
Caption Service
Select the correct type of closed caption services.
Audio Language
For digital broadcast, you can select an available
audio language temporarily if none of your preferred
languages are available.
DTVi Applications
Display the list of Digital TV interactive applications.
• You can only watch a video, e.g. of a TV channel, in
the Picture-in-picture mode. The audio itself will be
mute.
• The Picture-in-picture window will be closed when
you initiate playback of another video content since
there can only be a single playback happening at a
time. Some apps may additionally close the Picturein-picture window on their own in the instances in
which its presence would impede your use of them.
• The “Picture-in-picture” menu option can only be
activated if the Home screen is running in the
background. If you see the option disabled, please go
to the Home screen first.
5.2
Favourite Channels
About Favourite Channels
In a favourite channel list, you can collect the
channels you like.
Mono / Stereo
You can switch the sound of an analogue channel to
Mono or Stereo.
To switch to Mono or Stereo…
1 - Tune to an analoge channel.
2 - Press OPTIONS, select Mono/Stereo and
press (right).
3 - Select Mono or Stereo and press OK.
4 - Press (left) to go back one step or
press BACK to close the menu.
Picture-in-picture
While watching a TV channel or a video from a
connected HDMI device, you can shrink the video to a
corner and then browse Home screen or apps.
To launch the Picture-in-picture window…
1 - Tune to a TV channel or watch a video from a
You can create 4 different lists of favourite channels
for easy channel zapping. You can name each
Favourites List individually. Only in a Favourites List
you can reorder channels.
With a Favourites List selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when using
or keys.
* Note: Favourite channel list is not available when
installation country is UK and Italy.
Create a Favourites List
To create a favourite channels list…
1 - Press , to switch to TV.
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Create Favourites List and press OK.
12
5 - In the list at the left, select a channel you want as
a favourite and press OK. Channels come in the list at
the right in the order you add them. To undo, select
the channel in the list at the left and
press OK again.
6 - If necessary, you can go on selecting and adding
channels as favourites.
7 - To finish adding channels, press BACK.
The TV will ask to rename the Favourites List. You can
use the on-screen keyboard.
Remove a Favourites List
To remove a Favourites List…
1 - Open the Favourites List you want to remove.
2 - Press OPTIONS, select Remove Favourites
List and press OK.
3 - Confirm to remove the list.
4 - Press BACK to close the channel list.
1 - Use the on-screen keyboard to delete the
current name and enter a new name.
2 - When done, select Close and press OK.
The TV will switch to the newly created Favourites
List.
You can add a range of channels in one go or start a
Favourites List by duplicating the channel list with all
channels and removing the channels you do not
want.
The channels in the Favourites List are renumbered.
Edit Favourites
To add a consecutive range of channels to a
Favourites List in one go, you can use Edit favourites.
To add a range of channels…
1 - Open the Favourites List where you want to add a
range of channels.
2 - Press OPTIONS, select Edit favourites and
press OK.
3 - In the list at the left select the first channel of the
range you want to add and press OK.
4 - Press (down) to select the last channel of the
range you want to add. The channels are marked at
the right.
5 - Press OK to add this range of channels and
confirm.
5.3
Closed captioning (CC) and language
Closed Caption
You can display closed captions at all times or only
when the TV is muted.
Note:
• Not all TV programmes, commercials and features
include closed captioning information. See your local
TV programme listings about channels with
closed captions. The captioned programmes
are typically listed with service marks, such as 'CC', in
the TV listings.
Switch on closed caption
1 - While you watch TV, press OPTIONS.
2 - Select Closed caption > Closed caption
on and press OK.
Select type of closed caption
1 - While you watch TV, press OPTIONS.
2 - Select Caption service.
3 - Select the correct type of closed captions and
press OK.
Audio Language
You can also start creating a Favourites List from Edit
favourites.
Rename a Favourites List
To rename a Favourites List…
1 - Open the Favourite List you want to rename.
2 - Press OPTIONS, select Rename Favourites
List and press OK.
3 - Use the on-screen keyboard to delete the current
name and enter a new name.
4 - When done, select Close and press OK.
5 - Press BACK to close the channel list.
If the TV channel broadcasts multiple or dual audio
languages, you can select your preferred audio
language.
1 - While you watch TV, press OPTIONS.
2 - For digital channels, select Audio Language. For
analogue channels, select Alternate Audio.
Press OK to confirm your selection.
3 - Select from the available languages, then
press OK.
Note:
If you have selected Alternate Audio for analogue
channels, select between:
• Main: Primary audio language or
• SAP: Secondary audio language
13
Menu Language
Change the language of the TV menus and messages
1 - Select Settings > Region and
language > Menu language and press OK.
2 - Select on the language you need and press OK.
3 - Press BACK to close the menu.
14
6
Channel Installation
6.1
Antenna/Cable Installation
To check the current version of the channel list…
1 - Select Settings > Channels, select Channel
List Copy, select Current Version and press OK.
2 - Press OK to close.
Current software version
Reinstall All Channels
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels…
1 - Select Settings > Channels > Antenna/cable
Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Search for Channels and press OK.
4 - Select Start and press OK.
5 - Follow the instructions on scree. This can take a
few minutes.
6 - Press (left) to go back one step or
press BACK to close the menu.
6.2
Service navigation
Service navigation
Settings > Channels > Service navigation.
Switch the availability to navigate through primary
channels only or all channels, on or off.
To check the cuurent version of the TV software…
1 - Select Settings > Update Software and
press (right) to enter the menu.
2 - Select Current Software Info and press OK.
3 - The version, release notes and creation date are
shown. Also, the Netflix ESN Number is shown if
available.
4 - Press (left) repeatedly if necessary, to close
the menu.
Copy a Channel List
To copy a channel list…
1 - Switch on the TV. This TV should have channels
installed.
2 - Plug in a USB flash drive.
3 - Select Settings > Channels > Channel List
Copy and press OK.
4 - Select Copy to USB and press OK. You might
be asked to enter the Child Lock PIN code to copy the
channel list.
5 - When copying is done, unplug the USB flash
drive.
6 - Press (left) repeatedly if necessary, to close
the menu.
Now you can upload the copied channel list onto
another Philips TV.
6.3
Channel List Copy
Introduction
Channel List Copy is intended for dealers and expert
users.
With Channel List Copy, you can copy the channels
installed on one TV onto another Philips TV of the
same range. With Channel List Copy, you avoid the
time-consuming channel search by uploading a
predefined channel list on a TV. Use a USB flash drive
of minimum 1 GB.
Conditions
• Both TVs are from the same year range.
• Both TVs have the same hardware type. Check the
hardware type on the TV type plate on the back of
the TV.
• Both TVs have compatible software versions.
Current channel version
Channel List Version
Check the current version of the channel list...
1 - Select Settings > Channels and
press (right) to enter the menu.
2 - Select Channel List Copy and select Current
Version, then press OK.
3 - Press (left) repeatedly if necessary, to close
the menu.
Upload a Channel List
To not Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To a TV that is not yet installed
15
1 - Plug in the power plug to start the installation and
select language and country. You can skip the
channel search. Finish the installation.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, select Settings
> Channels > Channel List Copy > Copy to TV and
press OK. Enter your PIN code if necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
To Installed TVs
Depending on whether your TV is already installed or
not, you must use a different method to upload a
channel list.
To an already installed TV
1 - Verify the country setting of the TV. (To verify this
setting, see chapter Reinstall All Channels. Start this
procedure until you reach the country setting.
Press BACK to cancel the installation.)
If the country is correct continue with step 2.
If the country is not correct, you need to start a
reinstallation. See chapter Reinstall All Channels and
start the installation. Select the correct country and
skip the channels search. Finish the installation. When
done, continue with step 2.
2 - Plug in the USB flash drive that holds the channel
list of the other TV.
3 - To start the channel list upload, select Settings
> Channels > Channel List Copy > Copy to TV and
press OK. Enter your PIN code if necessary.
4 - The TV notifies you if the channel list is copied to
the TV successfully. Unplug the USB flash drive.
16
7
HDMI ARC
Connect Devices
7.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use good quality
cables to ensure a good transfer of picture and
sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
Antenna port
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
All of the HDMI connections on the TV have HDMI
ARC (Audio Return Channel).
If the device, typically a Home Theatre System (HTS),
also has the HDMI ARC connection, connect it to any
of the HDMI connections on this TV. With the HDMI
ARC connection, you do not need to connect the
extra audio cable that sends the sound of the TV
picture to the HTS. The HDMI ARC connection
combines both signals.
You can use any HDMI connection on this TV to
connect the HTS but ARC is only available for 1
device/connection at a time.
HDMI CEC - EasyLink
Connect HDMI CEC-compatible devices to your TV,
you can operate them with the TV remote control.
EasyLink HDMI CEC must be switched on on the TV
and the connected device.
Switch on EasyLink
Settings > General
settings > EasyLink > EasyLink > On.
Operate HDMI CEC-compatible devices with TV
remote control
HDMI ports
HDMI Quality
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD)
TV signals.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.
If a device connected with HDMI is not working
correctly, check if a different HDMI Ultra HD setting
can solve this problem. In Help, press the colour
key Keywords and look up HDMI Ultra HD.
Copy protection
HDMI ports support HDCP 2.2 (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
Settings > General
settings > EasyLink > EasyLink remote
control > On.
Note:
• EasyLink might not work with devices from other
brands.
• The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theatre Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink. Example HDMI CEC branding names are
property of their respective owners.
7.2
Home Theatre System - HTS
17
Connect with HDMI ARC
TV are HDMI ARC connections.
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
HDMI ARC
If your Home Theatre System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal. But once you have
connected the Home Theatre System, the TV can
only send the ARC signal to this HDMI connection.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Connect with HDMI
7.3
Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can
use a wireless connection. For a wireless connection,
on your smartphone or tablet download the Philips
TV Remote App from your favourite app store.
7.4
Blu-ray Disc Player
Use a High speed HDMI cable to connect the Bluray Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC,
you can operate the player with the TV remote
control.
In Help, press the colour key Keywords and
look up EasyLink HDMI CEC for more information.
Use an HDMI cable to connect a Home Theatre
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
If the Home Theatre System has no HDMI ARC
connection, add an optical audio cable (Toslink) to
send the sound of the TV picture to the Home Theatre
System.
Audio to video synchronisation (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theatre Systems with
a disc player to match the sound with the video.
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theatre System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theatre System has no DTS sound processing.
You can fix this by setting the Digital Out Format of
the TV to Stereo.
Select Settings
> Sound > Advanced > Digital Out Format .
No sound
If you cannot hear the sound from the TV on your
Home Theatre System, check if you connected the
HDMI cable to an HDMI ARC connection on the
Home Theatre System. All HDMI connections on the
7.5
Bluetooth
Pairing a Device
Position the wireless speaker within a distance of 5
meters from the TV. Read the user manual of the
device for specific information on pairing and on
wireless range. Make sure the Bluetooth setting on TV
is switched on.
Once a wireless gamepad is paired, you can use it.
When a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.
To pair a bluetooth device with the TV…
1 - Switch on the bluetooth device and place it within
range of the TV.
2 - Select Settings > Wireless and Networks and
press (right) to enter the menu.
3 - Select Bluetooth > Search Bluetooth Device,
and press OK.
4 - Select Search and press OK. Follow the
instuctions on screen. You will pair the device with the
TV and the TV will store the connection. You might
need to unpair a paired device first if the maximum
number of paired devices was reached.
5 - Select the type of device and press OK.
6 - Press (left) repeatedly if necessary, to close
the menu.
18
Select a Device
To select a wireless device…
1 - Select Settings > Wireless and Networks and
press OK.
2 - Select Bluetooth > Search Bluetooth
Device and press OK.
3 - In the list, select the wireless device and
press OK.
4 - Press (left) repeatedly if necessary, to close
the menu.
Remove a Device
You can connect or disconnect a wireless Bluetooth
device. You can also remove a wireless Bluetooth
device. If you remove a Bluetooth device, the device
will be unpaired.
To remove or disconnect a wireless device…
1 - Select Settings > Wireless and Networks and
press OK.
2 - Select Bluetooth > Remove Bluetooth
device and press OK.
3 - In the list, select the wireless device and
press OK.
4 - Select Disconnect or Remove and press OK.
5 - Select OK and press OK to confirm.
6 - Press (left) repeatedly if necessary, to close
the menu.
7.6
Headphones
You can connect a set of headphones to
the connection on the back of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume…
1 - Select Settings, select Sound > Headphone
Volume and press OK.
2 - Press the arrows (up) or (down) to adjust
the value.
3 - Press (left) repeatedly if necessary, to close
the menu.
7.7
Game Console
HDMI
For best quality, connect the game console with a
High speed HDMI cable to the TV.
7.8
USB Hard Drive
What You Need
If you connect a USB Hard Drive, you can pause or
record digital TV broadcasts (DVB broadcasts or
similar).
Minimum Disk Space
• To Pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 4GB disk
space.
• To Record
To pause and record a broadcast, you need a
minimum of 250GB disk space.
19
For more information on how to install a USB Hard
Drive, in Help, press the colour
key Keywords and look up USB Hard Drive.
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
* Connect the USB Hard Drive with size less than 2TB.
To format a USB Hard Drive…
1 - Connect the USB Hard Drive to one of the USB
connections on the TV. Do not connect another USB
device to the other USB ports when formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - Select Recordings if you want to perform Pause
TV and Recordings, otherwise, select Apps to store
apps. Follow the instructions on screen.
4 - All files and data will be removed after formatting.
5 - When the USB Hard Drive is formatted, leave it
connected permanently.
For more information, in Help, press the colour
key Keywords and look up Pause TV,
Recording, or Apps.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
Formatting
Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive. Formatting removes all files from the USB Hard
Drive. If you want to record broadcasts with TV Guide
data from the Internet, you must setup the Internet
connection first before you install the USB Hard Drive.
7.9
USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
Use one of the USB connections to connect.
Configure
Install the keyboard
To install the USB keyboard, switch on the TV and
connect the USB keyboard to one of
the USB connections on the TV. When the TV
detects the keyboard for the first time, you can select
your keyboard lay-out and test your selection. If you
select a Cyrillic or Greek keyboard layout first, you
can select a secondary Latin keyboard layout.
To change the keyboard layout setting when a layout
was selected…
1 - Select Settings > General Settings and
press (right) to enter the menu.
2 - Select USB Keyboard Settings, and press OK to
start the keyboard setup.
Warning
20
Special Keys
Keys for entering text
• Enter key = OK
• Backspace = delete character before cursor
• Arrow keys = navigate within a text field
• To switch between keyboard layouts, if a secondary
layout is set, press the Ctrl + Spacebar keys
simultaneously.
Keys for apps and Internet pages
• Tab and Shift + Tab = Next and Previous
• Home = scroll to the top of the page
• End = scroll to the bottom of the page
• Page Up = jump one page up
• Page Down = jump one page down
• + = zoom in one step
• - = zoom out one step
• * = fit the web page to the screen width
7.10
of the photo is higher.
For more information on watching or playing content
from a USB flash drive, in Help, press the colour
key Keywords and look up Photos, Videos and
Music.
7.11
Photo Camera
To view photos stored on your digital photo camera,
you can connect the camera directly to the TV.
Use one of the USB connections on the TV to
connect. Switch on the camera after you made the
connection.
If the contents list does not appear automatically,
press SOURCES , and select USB.
Your camera might need to be set to transfer its
content with PTP (Picture Transfer Protocol). Read
the user manual of the digital photo camera.
USB Flash Drive
You can view photos or play your music and videos
from a connected USB flash drive.
Insert a USB flash drive in one of
the USB connections on the TV while the TV is
switched on.
Ultra HD on USB
You can view photos in Ultra HD resolution from a
connected USB device or flash drive. The TV will
downscale the resolution to Ultra HD if the resolution
of the photo is higher. You cannot play a video with
native resolution higher than Ultra HD on any of the
USB connections.
The TV detects the flash drive and opens a list
showing its content.
If the contents list does not appear automatically,
press SOURCES and select USB.
To stop watching the USB flash drive content,
press EXIT or select another activity.
To disconnect the USB flash drive, you can pull out
the flash drive anytime.
Ultra HD on USB
You can view photos in Ultra HD resolution from a
connected USB device or flash drive. The TV will
downscale the resolution to Ultra HD if the resolution
For more information on viewing photos, in Help,
press the colour key Keywords and look
up Photos, Videos and Music.
7.12
Camcorder
For best quality, use an HDMI cable to connect the
camcorder to the TV.
21
7.13
Subwoofer
Connect a subwoofer to boost the bass and enhance
your listening experience.
7.14
Computer
You can connect your computer to the TV and use
the TV as a PC monitor. Use an HDMI cable to
connect the computer to the TV.
22
8
Connect your
select OK to make the connection immediately.
3 - A message will be shown when the connection is
successful.
Android TV
8.1
Network and Internet
Home Network
To enjoy the full capabilities of your Philips Android
TV, your TV must be connected to the Internet.
Connect the TV to a home network with a high-speed
Internet connection. You can connect your TV
wirelessly or wired to your network router.
Connect to Network
Wireless Connection
What You Need
To connect the TV to the Internet wirelessly, you need
a Wi-Fi router with a connection to the Internet.
Use a high-speed (broadband) connection to the
Internet.
Problems
Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi
802.11b/g/n/ac devices in your proximity might
disturb the wireless network.
• Make sure that the firewalls in your network allow
access to the TV's wireless connection.
• If the wireless network does not work properly in
your home, try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the
router connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.
• Use a high-speed (broadband) Internet connection
for your router.
DHCP
• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be switched on.
In Help, press the colour key Keywords and look
up Troubleshooting for more information.
Turn Wi-Fi On or Off
Settings > Wireless and Networks > Wired or WiFi > Wi-Fi On/Off.
Make the Connection
Settings > Wireless and Networks > Wired or Wi-
Fi > Connect to Network > Wireless.
1 - In the list of found networks, select on your
wireless network. If your network is not in the list
because the network name is hidden (you switched
off the SSID broadcast of the router), select Add New
Network to enter the network name yourself.
2 - Depending on the type of router, enter your
encryption key - WPA or WPA2. If you entered the
encryption key for this network before, you can
Wired Connection
What You Need
To connect the TV to the Internet, you need a
network router with a connection to the
Internet. Use a high-speed (broadband) connection
to the Internet.
23
Make the Connection
Settings > Wireless and Networks > Wired or Wi-
Fi > Connect to Network > Wired.
1 - Connect the router to the TV with a network cable
(Ethernet cable**).
2 - Make sure that the router is switched on.
3 - The TV constantly searches for the network
connection.
4 - A message will be shown when the connection is
successful.
Settings > Wireless and Networks > Wired or Wi-
Fi > Switch on with Chromecst.
Set it On to allow this TV to be switched on from a
Chromecast app on your mobile device. Power
consumption of the TV in standby status will be
higher when switched this on. The Wi-Fi (WoWLAN)
setting should be turned on firstly before you can
change the setting of Switch on with Chromecast.
Switch on Wi-Fi connection
If the connection fails, you can check the DHCP
setting of the router. DHCP should be switched on.
**To fulfill EMC regulations, use a shielded FTP Cat.
5E Ethernet cable.
Network Settings
View Network Settings
Settings > Wireless and Networks > Wired or Wi-
Fi > View Network Settings.
You can view all current network settings here. The IP
and MAC address, signal strength, speed, encryption
method, etc.
Network Configuration - Static IP
Settings > Wireless and Networks > Wired or Wi-
Fi > Network Configuration > Static IP.
If you are an advanced user and want to install your
network with Static IP addressing, set the TV to Static
IP.
Network Configuration - Static IP Configuration
Settings > Wireless and Networks > Wired or Wi-
Fi > Network Configuration > Static IP
Configuration.
1 - Select Static IP Configuration and configure the
connection.
2 - You can set the number for IP
Address, Netmask, Gateway, DNS 1, or DNS 2.
Switch On with Wi-Fi (WoWLAN)
Settings > Wireless and Networks > Wired or Wi-
Fi > Wi-Fi On/Off.
You can switch on or off Wi-Fi connection on your
TV.
Digital Media Renderer - DMR
Settings > Wireless and Networks > Wired or Wi-
Fi > Digital Media Renderer - DMR.
If your media files do not play on your TV, make sure
that the Digitial Media Renderer is switched on. As a
factory setting, DMR is switched on.
TV Network Name
Settings > Wireless and Networks > Wired or Wi-
Fi > TV Network Name.
If you have more than one TV in your home network,
you can give the TV a unique name.
Clear Internet Memory
Settings > Wireless and Networks > Wired or Wi-
Fi > Clear Internet Memory.
With Clear Internet Memory you clear your Philips
server registration and parental rating settings, your
video store app logins, all Philips TV Collection
favourites, Internet bookmarks and history. Interactive
MHEG applications can also save so-called 'cookies',
on your TV. These files will also be cleared.
8.2
Google Account
Settings > Wireless and Networks > Wired or Wi-
Fi > Switch On with Wi-Fi (WoWLAN).
You can switch this TV on from your smartphone or
tablet if the TV is in Standby. The setting Switch On
with Wi-Fi (WoWLAN) must be switched on.
Switch on with Chromecast
Sign In
To enjoy the full capabilities of your Philips Android
TV, you can sign in to Google with your Google
Account.
By signing in you'll be able to play your favourite
games across phone, tablet and TV. You'll also get
customised video and music recommendations on
24
your TV home screen as well as access to YouTube,
Google Play and other apps.
Sign In
Use your existing Google Account to sign in to
Google on your TV. A Google Account consists of an
email address and a password. If you don't have an
Google Account yet, use your computer or tablet to
create one (accounts.google.com). To play games
with Google Play, you need a Google+ profile. If you
did not sign in during the first TV installation, you can
always sign in later.
To sign in after you did the TV installation…
1 - Select Settings > Android Settings and
press OK.
2 - Select Account & Sign-In and press OK.
3 - Select Sign In and press OK.
4 - Select Use your remote and press OK.
5 - With the on-screen keyboard, enter your email
address and press OK.
6 - Enter your password and press OK to sign in.
7 - Press (left) repeatedly if necessary, to close
the menu.
Android Settings
You can set or view several Android specific settings
or information. You can find the list of apps installed
on your TV and the storage space they need. You can
set the language you like to use with Voice
Search. You can configure the onscreen keyboard or
allow apps to use your location. Explore the different
Android settings. You can go
to www.support.google.com/androidtv for more
information on these settings.
To open these settings…
1 - Select Settings > Android Settings, and
press OK.
2 - Explore the different Android settings.
3 - Press BACK if necessary, to close the menu.
channels or find new apps to get more contents.
The Home screen is organised in channels…
Apps
Your favourite Apps are placed on the first row. In this
row you will also find the Apps for TV, like Philips TV
Collection, Watch TV, TV Guide, Media and others.
You can find more apps in the Apps page which can
be opened by clicking the Apps icon at the left end of
the Apps row. You can also add more apps as
favourite from the Apps page.
The Apps page contains all installed Apps that come
with the TV and the Apps you install from Philips TV
Collection or Google Play™ Store yourself.
Live TV
Live TV channel shows the currently running
programmes from the installed channels.
Play Next channel
You can always know what to watch next from Play
Next channel on the Home screen. Start watching
from where you left off and get notifications about
new episodes in the Play Next channel. Press and
hold Select on a movie or TV show to add it directly
to the Play Next channel.
Google Play Movies & TV channel
Rent movies or TV shows on this channel from
Google Play Movies & TV.
Help channel
This channel contains "How to…" tutorial videos to let
you know how to unbox, how to connect external
devices, how to install channel, etc.
YouTube channel
This channel contains your Recommended,
Subscriptions or Trending YouTube videos.
Customize channels
Click the CUSTOMIZE CHANNELS button to add and
remove channels from your Home screen.
8.3
Home Screen
About the Home Screen
To enjoy the benefits of your Android TV, connect the
TV to the Internet.
Like on your Android smartphone or tablet, the Home
screen is the centre of your TV. From the Home sreen
you can decide what to watch by browsing
entertainment options from app and live TV. Your
Home has channels to let you discover great contents
from your favourite apps. You can also add additional
See also www.support.google.com/androidtv
Open the Home Screen
To open the Home screen and open an item…
1 - Press HOME.
2 - Select an item and press OK to open or start it.
3 - Press BACK continuously or
press HOME can go back to Home screen.
When opening the Home screen, the background
application/content playback will stop. You have to
select the application or content from the Home
25
Loading...
