Philips 40PFT6300/60, 48PFT6300/60, 55PFT6300/60 operating instructions

Download

www.philips.com/welcome

6300 series

User Manual

40PFH6300

40PFT6300 40PFT6300

48PFH6300

48PFT6300 48PFT6300 55PFH6300

55PFT6300 55PFT6300

1 TV Tour 3

1.1 Pause TV and recordings 3

1.2 EasyLink 3

2 Setting up 4

2.1 Read safety 4

2.2 TV stand and wall mounting 4

2.3 Tips on placement 4

2.4 Power cable 4

2.5 Antenna cable 4

2.6 Satellite dish 5

3 Connect devices 6

3.1 About connections 6

3.2 Common interface - CAM 8

3.3 Set-top box - STB 8

3.4 Satellite receiver 8

3.5 Home Theatre System - HTS 9

3.6 Blu-ray Disc player 10

3.7 DVD player 10

3.8 Game console 10

3.9 USB Hard Drive 11

3.10 USB flash drive 12

3.11 Camcorder - HDMI 12

3.12 Computer 12

3.13 Headphones 12

4 Switch on 14

4.1 On, Standby or Off 14

4.2 Keys on TV (For 4100, 4200, 4101, 4111, 4201, 6300,

630) series 14

4.3 Sleep timer 14

4.4 Switch Off Timer 14

5 Remote control 15

5.1 Key overview (For 630, 6300 series) 15

5.2 IR sensor 15

5.3 Batteries 16

5.4 Cleaning 16

6 TV channels 17

6.1 Channel Lists 17

6.2 Watching TV channels 17

6.3 Channel list copy 21

7 Channel installation - Antenna, Cable

7.1 Update channels 23

7.2 Reinstall channels 23

7.3 DVB-T or DVB-C 23

7.4 Manual Installation 24

8 TV guide 26

8.1 What you need 26

8.2 Using the TV guide 26

9 Recording and pause TV 28

9.1 Recording 28

9.2 Pause TV 29

10 Sources 30

10.1 Switch to a device 30

10.2 From standby 30

10.3 EasyLink 30

11 Timers and clock 31

11.1 Sleep timer 31

11.2 Clock 31

11.3 Switch off timer 31

12 Videos, Photos and Music 32

12.1 From a USB connection 32

12.2 Play your videos 32

12.3 View your photos 32

12.4 Play your music 33

13 Settings 34

13.1 Picture 34

13.2 Sound 37

13.3 General settings 39

13.4 Ambilight (For 630/6300 series) 40

14 Specifications 42

14.1 Environmental 42

14.2 Reception for PxH / PxT models 43

14.3 Display 43

14.4 Power 43

14.5 Dimensions and weights 44

14.6 Connectivity 44

14.7 Sound 44

14.8 Multimedia 44

15 Software 45

15.1 Software update 45

15.2 Software version 45

15.3 Open source software 45

15.4 Open source license 45

16 Troubleshooting and support 48

16.1 Troubleshooting 48

16.2 Register 49

16.3 Help 49

16.4 Online help 49

16.5 Consumer Care / Repair 50

17 Safety and care 51

17.1 Safety 51

17.2 Screen care 52

18 Terms of use, copyrights and licenses

18.1 Terms of use 53

18.2 Copyrights and licenses 53

Index 55

TV Tour

1.1

Pause TV and recordings

If you connect a USB Hard Drive, you can pause and record a broadcast from a digital TV channel.

Pause your TV and answer that urgent phone call or simply take a break during a sports match, while the TV stores the broadcast on the USB Hard Drive. You can start watching again later.

With a USB Hard Drive connected, you can also record digital broadcasts. You can record while you are watching a programme or schedule a recording of an upcoming programme.

1.2

EasyLink

With EasyLink you can operate a connected device, like a Bluray Disc player, with the remote control of the TV.

EasyLink uses HDMI CEC to communicate with the connected devices.

Setting up

TP Vision Europe B.V. bears no responsibility for improper mounting or any mounting that results in accident or injury.

2.1

Read safety

Read the safety instructions first before you use the TV.

In Help, go to Safety and care > Safety.

2.2

TV stand and wall mounting

TV stand

You can find the instructions for mounting the TV stand in the Quick Start Guide that came with the TV. In case you lost this guide, you can download it from

www.philips.com.

Use the product type number of the TV to look for the Quick Start Guide to download.

Wall mounting

For 6300 series

Your TV is also prepared for a VESA-compliant wall mount bracket (sold separately). Use the following VESA code when purchasing the wall mount . . . To fix the bracket securely, use screws with a length indicated in the drawing.

2.3

Tips on placement

- Position the TV where light does not shine directly on the screen.

- Position the TV up to 15 cm away from the wall.

- The ideal distance to watch TV is 3 times its diagonal screen size. When seated, your eyes should be level with the centre of the screen.

2.4

Power cable

- Insert the power cable into the POWER connector on the back of the TV.

- Make sure the power cable is securely inserted in the connector.

- Make sure that the power plug, in the wall socket, is accessible at all times.

- When you unplug the power cable, always pull the plug, never pull the cable.

- 40Pxx6300 - VESA MIS-F 200x200, M6 (Minimum 14 mm, Maximum 24 mm)

- 48Pxx6300 - VESA MIS-F 400x400, M6 (Minimum 14 mm, Maximum 24 mm)

- 55Pxx6300 - VESA MIS-F 400x400, M6 (Minimum 14 mm, Maximum 24 mm)

Caution

Wall mounting the TV requires special skills and should only be performed by qualified personnel. The TV wall mounting should meet safety standards according to the TV's weight. Also read the safety precautions before positioning the TV.

Although this TV has a very low standby power consumption, unplug the power cable to save energy if you do not use the TV for a long period of time.

2.5

Antenna cable

Insert the antenna plug firmly into the ANTENNA socket at the back of the TV.

You can connect your own antenna or an antenna signal from an antenna distribution system. Use an IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C input signals.

2.6

Satellite dish

- For PHK/PFK models Attach the satellite F-type connector to the satellite

connection SAT at the back of the TV.

Connect devices

3.1

About connections

Copy protection

Connectivity guide

Always connect a device to the TV with the highest quality connection available. Also, use good quality cables to ensure a good transfer of picture and sound.

If you need help to connect several devices to the TV, you can visit the Philips TV connectivity guide. The guide offers information on how to connect and which cables to use.

Go to www.connectivityguide.philips.com

Antenna port

If you have a Set-top box (a digital receiver) or Recorder, connect the antenna cables to run the antenna signal through the Set-top box and/or Recorder first before it enters the TV. In this way, the antenna and the Set-top box can send possible additional channels to the Recorder to record.

HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Bluray Disc. Also referred to as DRM (Digital Rights Management).

HDMI ARC

HDMI 1 connection on the TV have HDMI ARC (Audio Return Channel). If the device, typically a Home Theatre System (HTS), also has the HDMI ARC connection, connect it to HDMI 1 on this TV. With the HDMI ARC connection, you do not need to connect the extra audio cable that sends the sound of the TV picture to the HTS. The HDMI ARC connection combines both signals.

In case you prefer to switch off ARC on the HDMI connections, press and select Setup and press OK. Select TV

settings > Sound > Advanced > HDMI 1 - ARC.

HDMI ports

HDMI quality

An HDMI connection has the best picture and sound quality. Use an HDMI cable for TV signal.

For best signal quality transfer, use a High speed HDMI cable and do not use an HDMI cable longer than 5 m.

HDMI CEC - EasyLink

EasyLink

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC (Consumer Electronics Control) to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

EasyLink setup

The TV comes with EasyLink switched on. Make sure that all HDMI CEC settings are properly set up on the connected EasyLink devices. EasyLink might not work with devices from other brands.

HDMI CEC on other brands

The HDMI CEC functionality has different names on different brands. Some examples are: Anynet, Aquos Link, Bravia Theatre Sync, Kuro Link, Simplink and

Viera Link. Not all brands are fully compatible with EasyLink.

Example HDMI CEC branding names are property of their respective owners.

Operate devices

To operate a device connected to HDMI and set up with EasyLink, select the device - or its activity - in the list of TV connections. Press  SOURCES , select a device connected to an HDMI connection and press OK.

Once the device is selected, the TV remote control can control the device. However and  OPTIONS keys and some other TV keys are not forwarded to the device. If the key you need is not on the TV remote control, you can select the key in the Options menu. Press  OPTIONS and select Controls in the menu bar. On the screen, select the device key you need and press OK. Some very specific device keys might not be available in the Controls menu.

Note: Only devices that support EasyLink Remote Control function will respond to the TV remote control.

EasyLink On or Off

DVI to HDMI

If you still own a device that only has a DVI connection, you can connect the device to any of the HDMI connection with a DVI to HDMI adapter.

Use a DVI to HDMI adapter if your device only has a DVI connection. Use one of the HDMI connections and add an Audio L/R cable (mini-jack 3.5mm) to Audio In for sound, on the back of the TV.

Copy protection

DVI and HDMI cables support HDCP (High-bandwidth Digital Content Protection). HDCP is a copy protection signal that prevents copying content from a DVD disc or Blu-ray Disc. Also referred to as DRM (Digital Rights Management).

Audio Out - Optical

Audio Out - Optical is a high quality sound connection. This optical connection can carry 5.1 audio channels. If your device, typically a Home Theatre System (HTS), has no HDMI ARC connection, you can use this connection with the Audio In Optical connection on the HTS. The Audio Out Optical connection sends the sound from the TV to the HTS.

The TV comes with all EasyLink settings switched on. You can switch off any EasyLink setting independently.

To switch off EasyLink completely . . .

1. Press and select Setup and press OK.

2. Select TV settings > General settings > EasyLink.

3. Select EasyLink.

4. Select Off and press OK.

5. Press , repeatedly if necessary, to close the menu.

EasyLink Remote Control EasyLink Remote Control

If you want devices to communicate but you don't want to operate them with the TV remote control, you can switch off EasyLink remote control separately. You can control multiple HDMI-CEC compliant devices with your TV remote control.

In the EasyLink settings menu, select EasyLink Remote Control and select Off.

You can set the type of the audio out signal to fit the audio capabilities of your Home Theatre System.

If the sound does not match the video on screen, you can adjust the audio to video synchronization.

Scart

SCART is a good quality connection. The SCART connection can be used for CVBS and RGB video signals but cannot be used for High Definition (HD) TV signals. The SCART connection combines video and audio signals.

Use the SCART adapter cable to connect your device.

It may take a few minutes before the CAM is activated. Removing the CAM will deactivate the broadcast service on TV. If a CAM is inserted and subscription fees are paid, (connection methods can differ), you can watch the TV broadcast. The inserted CAM is exclusively for your TV.

3.3

Set-top box - STB

3.2

Common interface - CAM

CI+

This TV is ready for the CI+ Conditional Access. With CI+ you can watch premium HD programmes,

like movies and sports, offered by digital TV broadcasters in your region. These programmes are scrambled by the TV broadcaster and descrambled with a prepaid CI+ module. Digital TV broadcasters provide this CI+ module (Conditional Access Module - CAM) when you subscribe to their premium programmes. These programmes have a high level of copy protection.

Contact a digital TV broadcaster for more information on terms and conditions.

Use 2 antenna cables to connect the antenna to the Set-top box (a digital receiver) and the TV.

Next to the antenna connections, add an HDMI cable to connect the Set-top box to the TV.

Auto switch off Switch off this automatic timer, if you only use the

remote control of the Set-top box. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

CAM

Insert a CAM module

Switch off the TV before inserting a CAM. Look on the CAM for the correct method of insertion. Incorrect insertion can damage the CAM and TV.

Use the Common Interface slot on the TV to insert the CAM card. With the front of the card facing to you, gently insert the CAM as far as it will go. Leave the card in the slot permanently.

To switch off the Switch off timer, press and select Setup and press OK. Select TV settings > General settings > Switch off timer and set the slider bar to Off.

3.4

Satellite receiver

Connect the dish antenna cable to the Satellite receiver.

Next to the antenna connection, add an HDMI cable to connect the device to the TV.

Connect with HDMI

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

If the Home Theatre System has no HDMI ARC connection, add an optical audio cable (Toslink) to send the sound of the TV picture to the Home Theatre System.

Auto switch off

Switch off this automatic timer, if you only use the remote control of the Set-top box. Do this to prevent the TV from switching off automatically after a 4 hour period without a key press on the remote control of the TV.

To switch off the Switch off timer, press and select Setup and press OK. Select TV settings > General settings > Switch off timer and set the slider bar to Off.

3.5

Home Theatre System - HTS

Connect with HDMI ARC

Use an HDMI cable to connect a Home Theatre System (HTS) to the TV. You can connect a Philips Soundbar or an HTS with a built-in disc player.

HDMI ARC

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Audio Out settings

Audio Out delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is automatically synchronised and always correct.

Audio sync delay

For some Home Theatre Systems you might need to adjust the audio sync delay to synchronise the audio to video. On the HTS, increase the delay value until there is a match between picture and sound. A delay value of 180ms may be required. Read the user manual of the HTS. With a delay value set up on the HTS, you need to switch off Audio Out delay on the TV.

To switch off the Audio Out delay . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out delay.

3. Select Off and press OK.

4. Press , repeatedly if necessary, to close the menu.

Audio to video synchronisation (sync)

If the sound does not match the video on screen, you can set a delay on most Home Theatre Systems with a disc player to match the sound with the video.

Audio Out offset

If you cannot set a delay on the Home Theatre System, you can set the TV to sync the sound. You can set an offset that compensates the time necessary for the Home Theatre System to process the sound of the TV picture. You can set the value in steps of 1ms. Maximum setting is 12ms. The Audio out delay setting should be switched on.

To synchronise the sound on the TV . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out offset.

3. Use the slider bar to set the sound offset and press OK.

4. Press , repeatedly if necessary, to close the menu.

Audio Out format

If you have a Home Theatre System (HTS) with multichannel sound processing capabilities like Dolby Digital, DTS® or similar, set the Audio out format to Multichannel. With Multichannel, the TV can send the compressed multichannel sound signal from a TV channel or connected player to the Home Theatre System. If you have a Home Theatre System without multichannel sound processing, select Stereo.

To set the Audio Out format . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out format.

3. Select Multichannel or Stereo.

4. Press , repeatedly if necessary, to close the menu.

No sound

If you cannot hear the sound from the TV on your Home Theatre System, check the following . . .

- Check if you connected the HDMI cable to a HDMI 1 connection on the Home Theatre System.

- Check if the HDMI ARC setting on the TV is switched On. Go to > Setup > TV settings > Sound > Advanced > HDMI 1 -ARC.

3.6

Blu-ray Disc player

Use a High speed HDMI cable to connect the Blu-ray Disc player to the TV.

Audio Out levelling

Use the Audio Out leveling setting to level the volume (loudness) of the TV and the Home Theatre System when you switch over from one to another. Volume differences can be caused by differences in sound processing.

To level the difference in volume . . .

1. Press and select Setup and press OK.

2. Select TV

settings > Sound > Advanced > Audio out leveling.

3. If the volume difference is large, select More. If the volume difference is small, select Less. Press , repeatedly if necessary, to close the menu.

Audio Out leveling affects both the Audio Out Optical and HDMI ARC sound signals.

Problems with HTS sound

Sound with loud noise

If you watch a video from a plugged in USB flash drive or connected computer, the sound from your Home Theatre System might be distorted.

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out format.

If the Blu-ray Disc player has EasyLink HDMI CEC, you can operate the player with the TV remote control.

3.7

DVD player

Use an HDMI cable to connect the DVD player to the TV.

If the DVD player is connected with HDMI and has EasyLink CEC, you can operate the player with the TV remote control.

3.8

Game console

HDMI

For best quality, connect the game console with an High speed HDMI cable to the TV.

Best Setting

you can check if you can record digital TV channels in your country. Press  TV GUIDE on the remote control. If there is a Record button on the TV guide page, you can record.

Installation

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive.

1. Connect the USB Hard Drive to one of the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2. Switch on the USB Hard Drive and the TV.

3. When the TV is tuned to a digital TV channel, press (Pause). Trying to pause will start the formatting.



Follow the instructions on screen. When the USB Hard Drive is formatted, leave it

connected permanently.

Before you start playing a game from a connected game console, we advice you to set the TV in the ideal setting Game.

To set the TV to the ideal setting…

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Advanced > Activity style.

3. Select Game, Computer or TV. The setting TV returns to the picture settings for watching TV.

4. Press , repeatedly if necessary, to close the menu.

3.9

USB Hard Drive

What you need

If you connect a USB Hard Drive, you can pause or record a TV broadcast. The TV broadcast must be a digital broadcast (DVB broadcast or similar).

To pause

To pause a broadcast, you need a USB 2.0 compatible Hard Drive with a minimum of 32GB disc space.

To record

To pause and record a broadcast, you need a minimum of 250GB disc space.

TV guide

Before you decide to buy a USB Hard Drive to record,

Warning

The USB Hard Drive is formatted exclusively for this TV, you cannot use the stored recordings on another TV or PC. Do not copy or change recording files on the USB Hard Drive with any PC application. This will corrupt your recordings. When you format another USB Hard Drive, the content on the former will be lost. A USB Hard Drive installed on your TV will need reformatting for use with a computer.

Formatting

Before you can pause or record a broadcast, you must connect and format a USB Hard Drive. Formatting removes all files from the USB Hard Drive.

Warning

To format a USB Hard Drive…

1. Connect the USB Hard Drive to one of

the USB connections on the TV. Do not connect another USB device to the other USB ports when formatting.

2. Switch on the USB Hard Drive and the TV.

3. When the TV is tuned to a digital TV channel,

press  (Pause). Trying to pause will start the formatting. Follow the instructions on screen.

When the USB Hard Drive is formatted, leave it connected permanently.

3.12

Computer

Connect

3.10

USB flash drive

You can view photos or play your music and videos from a connected USB flash drive.

Insert a USB flash drive in one of the USB connections on the TV while the TV is switched on.

The TV detects the flash drive and opens a list showing its content. If the contents list does not appear automatically, press  SOURCES , select USB and press OK.

To stop watching the USB flash drive content, press

EXIT or select another activity.



To disconnect the USB flash drive, you can pull out the flash drive anytime.

You can connect your computer to the TV and use the TV as a PC monitor.

With HDMI

Use an HDMI cable to connect the computer to the TV.

With DVI to HDMI

Alternatively, you can use a DVI to HDMI adapter to connect the PC to HDMI and an audio L/R cable (minijack 3.5mm) to AUDIO IN L/R on the back of the TV.

3.11

Camcorder - HDMI

For best quality, use an HDMI cable to connect the camcorder to the TV.

Best Setting

Ideal monitor setting

If your computer is added as a Computer type of device in the Source menu (the list of connections), the TV is set to the ideal Computer setting automatically.

If you use your computer to watch movies or use it to play games, you might want to set the TV back to the ideal TV watching or gaming setting.

To set the TV to the ideal setting manually . . .

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Activity style.

3. Select Game, Computer or TV. The

setting TV returns to the picture settings for watching TV.

4. Press , repeatedly if necessary, to close the

menu. Remember to set the Game or computer setting back

to Computer when you stop playing the game.

3.13

Headphones

Side

You can connect a set of headphones to  connection on the TV. The connection is a minijack 3.5mm. You can adjust the volume of the headphones separately.

To adjust the volume . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Headphone volume and press OK.

3. Press  (up) or  (down) to adjust the volume.

4. Press , repeatedly if necessay, to close the menu.

key.

Switch on

4.1

On, Standby or Off

For 6300 series

Before you switch on the TV, make sure you plugged in the mains power in the POWER connector on the back of the TV.

To put the TV in Standby when the indicator light is off, press the small joystick key on the back of the TV. The indicator will light up.

With the TV in standby, press  on the remote control to switch the TV on.

Switch to standby

To switch the TV to Standby, press  on the remote control.

Switch Off

To switch the TV Off, press the joystick key. The indicator light goes off. The TV is still connected to the mains power but consumes very little energy.

To switch off the TV completely, disconnect the power plug. When disconnecting the power plug, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

4.3

Sleep timer

With the sleep timer, you can set the TV to switch to standby automatically after a preset time.

To set the sleep timer . . .

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Sleep

timer. With the slider bar you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the sleep timer is switched off.You can always switch off your TV earlier or reset the time during the countdown.

3. Press , repeatedly if necessary, to close the

menu.

4.4

Switch Off Timer

If the TV receives a TV signal but you don't press a key on the remote control during a 4 hour period, the TV switches off automatically to save energy. Also, if the TV does not receive a TV signal nor a remote control command for 10 minutes, the TV switches off automatically.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

4.2

Keys on TV (For 4100, 4200, 4101, 4111, 4201, 6300, 630) series

If you lost the remote control or its batteries are empty, you can still do some basic TV operations.

To open the basic menu…

1. With the TV switched on, press the joystick key on the back of the TV to bring up the basic menu.

2. Press left or right to select  Volume,  Channel or  Sources.

3. Press up or down to adjust the volume or tune to the next or previous channel. Press up or down to go through the list of sources, including the tuner selection.

4. The menu will disappear automatically. To switch the TV off, select  and press the joystick

To deactivate the Switch Off Timer …

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Switch

off timer.

3. Press  (up) or  (down) to adjust the

value. The value 0 deactivates the automatic switch off.

4. Press , repeatedly if necessary, to close the

menu.

Remote control

5.1

Key overview (For 630, 6300 series)

To open or close programme infomation.

4.  BACK

To switch back to the previous channel you selected. To close a menu without changing a setting.

5. HOME

To open or close the home menu.

6.  EXIT

To switch back to watching TV.

Top

1.  Standby / On

To switch the TV on or back to Standby.

2. Playback keys

- Play , to playback

- Pause , to pause playback

- Stop , to stop playback

- Rewind , to rewind

- Fast forward , to go fast forward

- Record , to record now

3. To select an Ambilight setting.

4.  SETUP To open the Settings menu.

5.  FORMAT To open or close the Picture format menu.



Ambilight

7.  OPTIONS

To open or close the Options menu.

8. OK key

To confirm a selection or setting.

9. Arrow / navigation keys

To navigate up, down, left or right.

10.  LIST

To open or close the channel list.

Bottom

1.  Volume

To adjust the volume level.

2. Number keys and text keypad

To select a TV channel directly or to enter text.

Middle

1. To open or close the Sources menu - the list of connected devices.

2. Colour keys The buttons function follow the on-screen instructions.

3.  INFO

SOURCES



3. SUBTITLE

To switch subtitles on, off or Automatic.

4.  TV GUIDE

To open or close the TV guide.

5.  Mute

To mute the sound or to restore it.

6.  Channel

To switch to the next or previous channel in the channel list. To open the next or previous page in Text/Teletext. To start the next or previous chapter on a disc.

7. TEXT

To open or close Text / Teletext.

5.2

IR sensor

The TV can receive commands from a remote control that uses IR (infrared) to send commands. If you use such a remote control, always make sure you point the remote control at the infrared sensor on the front of the TV.

5.3

Batteries

1. Slide the battery door in the direction shown by the arrow.

2. Replace the old batteries with 2 type AAA-LR03-1.5V batteries. Make sure the + and the - ends of the batteries line up correctly.

3. Reposition the battery door.

4. Slide it back until it clicks. Remove the batteries if you are not using the remote

control for a long time. Safely dispose of your old batteries according to the end of use directions.

5.4

Cleaning

Your remote control is treated with a scratch-resistant coating.

To clean the remote control, use a soft damp cloth. Never use substances such as alcohol, chemicals or household cleaners on the remote control.

select All, Favourites, Radio, and New channels.

TV channels

6.1

Channel Lists

About channel lists

After a channel installation, all channels appear on the channel list. Channels are shown with their name and logo if this information is available.

With a channel list selected, press the arrows  (up) or  (down) to select a channel, then press OK to watch the selected channel. You only tune to the channels in that list when using   or   keys.

Channel icons

After an Automatic Channel Update of the channel list, newly found channels are marked with a  (star). If you lock a channel, it will be marked with a  (lock).

Radio stations

If digital broadcasting is available, digital radio stations are installed during installation. Switch to a radio channel just like you switch to a TV channel. A Cable (DVB-C) channel installation usually places radio stations from channel number 1001 onwards.

This TV can receive digital television standard DVB . TV may not work properly with some operators of digital television , non-compliance with requirements of the standard in full.

6.2

Watching TV channels

Watching channels

Tune to a channel

To watch TV channels, press . The TV tunes to the TV channel you last watched.

Switch channels

- To switch channels, press   or  .

- If you know the channel number, type in the

number with the number keys. Press OK after you entered the number to switch immediately.

Previous channel

- To switch back to the previously tuned channel,

press .

Channel list

While watching a TV channel, press  LIST to open the channel lists.

The channel list can have several pages with channels. To view the next or previous page, press  + or  . To close the channel lists without switching channel, press  LIST again.

Radio channels

If digital broadcasting is available, digital radio station are installed during installation. Switch to a radio channel just like you switch to a TV channel.

Open a channel list

To open the current channel list…

1. Press , to switch to TV.

2. Press  LIST to open the current channel list.

3. Press  LIST again to close the channel list.

Filter a channel list

You can filter a list with all channels. You can set the channel list to show only TV channels or only Radio stations.

To set a filter on a list with all channels…

1. While watching a TV channel, press open the channel list.

2. Press  OPTIONS to open Option menu.

3. Select List, then you can



LIST to

Lock a channel

Lock and unlock a channel

To prevent children from watching a channel or a programme, you can lock channels or lock age rated programmes.

You can lock a channel to prevent children from watching it. To watch a locked channel you need to enter the Child lock code. You cannot lock programmes from connected devices.

To lock a channel . . .

1. While watching a TV channel, press  LIST to

open the Channel list.

2. In any list, select the channel you want to lock.

3. Press  OPTIONS and select Lock channel. In a

channel list, a locked channel is marked with a lock .

To unlock a channel, select the locked channel in the channel list, press  OPTIONS , then select Unlock channel. You will need to enter the Child lock code.

1. While watching a channel, press  OPTIONS.

2. Press  OPTIONS again to close.

Subtitles and subtitle language

Parental rating

To prevent children from watching a programme not suitable for their age, you can use an age rating.

Some digital broadcasters have age rated their programmes. When the age rating of a programme is equal to or higher than the age you have set as age rating for your child, the programme will be locked. To watch a locked programme you must enter the child lock code. The parental age rating is set for all channels.

To set an age rating . . .

1. Press and select Setup and press OK.

2. Select Channel settings > Child lock > Parental rating and press OK.

3. Enter a 4-digit Child lock code. Enter a 4-digit Child lock code and confirm. Now you can set an age rating.

4. Set the age and press OK.

5. Press , repeatedly if necessary, to close the menu.

6. To switch off the parental age rating, select None as age setting.

The TV will ask for the code to unlock the programme. For some broadcasters / operators, the TV only locks programmes with a higher rating.

Set or change the lock code

To set the lock code or to change the current code . . .

1. Press and select Setup and press OK.

2. Select Channel settings > Child lock > Change code and press OK.

3. If a code is set already, enter the current Child lock code and then enter the new code twice.

The new code is set.

Forgotten your code?

To override and enter a new child lock code in case you forget it, enter 8888.

Switch On

To switch on Subtitles, press SUBTITLE. You can set subtitles to Subtitles off, Subtitles

on, or Automatic. Automatic

If language information is part of the digital broadcast and the broadcasted programme is not in your language (the language set on TV), the TV can show subtitles automatically in one of your preferred subtitle languages. One of these subtitle languages must also be part of the broadcast.

You can select your preferred subtitle languages in Subtitle Language.

Preferred subtitle languages Subtitles for digital channels

There is no need to set subtitles in Text for digital channels. Digital channels can offer several subtitle languages for a programme. You can set a preferred primary and secondary subtitle language. If subtitles in one of these languages are available, the TV will show them. If none of the preferred subtitle languages are available, you can select another subtitle language which is available.

To set the primary and secondary subtitle language . . .

1. Press and select Setup and press OK.

2. Select Channel settings and select Languages.

3. Select Primary subtitle language or Secondary

subtitle language and press OK.

4. Select a language and press OK.

5. Press , repeatedly if necessary, to close the

menu.

Channel options

Open options

While watching a channel, you can set some options. Depending on the type of channel you are watching

(analogue or digital) or depending on the TV settings you made, some options are available.

To open the options menu…

Select a subtitle language

If none of the preferred subtitle languages are available, you can select another subtitle language if available. If no subtitle languages are available, you cannot select this option.

To select a subtitle language when none of your preferred languages are available…

1. Press  OPTIONS.

2. Select Subtitle language and select one of the

languages as subtitles temporarily.

Subtitles for analogue channels

For analogue channels, you need to make the subtitles available for each channel manually.

1. Switch to a channel and press TEXT to open Text.

2. Enter the page number for subtitles, usually 888.

3. Press TEXT again, to close Text. If you select On in the Subtitle menu when watching

this analogue channel, subtitles will be shown if available. To know if a channel is analogue or digital, switch to the channel and open Status in the Options menu.

Dual I-II

If an audio signal contains two audio languages but one language — or both — has no language indication, this option is available.

Common Interface

If prepaid premium content is available from a CAM, you can set the provider settings with this option.

MHP applications

Audio language

Preferred audio language

Digital TV channels can broadcast audio with several spoken languages for a programme. You can set a preferred primary and secondary audio language. If audio in one of these languages is available, the TV will switch to this audio. If none of the preferred audio languages is available, you can select another audio language which is available.

To set the primary and secondary audio language . . .

1. Press and select Setup and press OK.

2. Select Channel settings and select Languages.

3. Select Primary audio language or Secondary audio language and press OK.

4. Select a language and press OK.

5. Press , repeatedly if necessary, to close the menu.

Select an audio language

To select an audio language when none of your preferred audio language is available . . .

1. Press  OPTIONS .

2. Select Audio language and select an audio language you want temporarily and press OK.

Audio languages for the hearing and visually impaired

Some digital TV channels broadcast special audio and subtitles adapted for people who are hearing or visually impaired.

Enable or disable the MHP applications.

Status

Select Status to view technical information on the channel (if it is analogue or digital) or a connected device you are watching.

Favourite channels

About favourite channels

You can create a favourite channel list that only holds the channels you want to watch. With the Favourite channel list selected, you will only see your favourite channels when you switch through channels.

Create a favourites list

1. While watching a TV channel, press

open the channel list.

2. Select All to view all channels.

3. Select the channel, and press  (yellow) to mark

as favourite.

4. The selected channel is marked with a .

5. To finish, press . The channels are added to the

Favourites list.

To remove a channel from the favourites list, select the channel with , then press  (yellow) again to unmark as favourite.



LIST to

Video selection

Digital TV channels can offer multi video signals (multifeed broadcast), different camera viewpoints or angles of the same event or different programmes on one TV channel. The TV shows a message if any such TV channels are available.

Reorder channels

You can only reorder channels in the Favourites list.

1. In the channel list Favourites, highlight the channel

you want to reposition.

2. Press  (green).

3. Select the channel to reorder and press OK.

4. Press the Navigation buttons to move the

highlighted channel to another location and press OK.

5. Once complete, press  EXIT to exit from the Favourite channel list.

Rename channels

2. Select a word or number with the arrow keys.

3. Press OK again to jump immediately to the next

occurence of this word or number.

4. Press OK again to jump to the subsequent

occurence.

5. To stop searching, press  (up) until nothing is

selected.

You can rename channels in the channel list.

1. Select the channel you want to rename in one of the channel lists.

2. Press  (red).

3. You can enter text with the the on-screen keyboard.

Text / Teletext

Text pages

To open Text (Teletext) while you are watching TV channels, press TEXT. To close Text, press TEXT again.

Select a Text page

To select a page . . .

1. Enter the page number with the number keys.

2. Use the arrow keys to navigate.

3. Press a colour key to select a colour-coded subject at the bottom of the screen.

Text sub-pages

A Text page number can hold several subpages. The subpage numbers are shown on a bar next to the main page number. To select a subpage, press  or .

T.O.P. Text pages

Some broadcasters offer T.O.P. Text. To open T.O.P. Text pages within Text, press

OPTIONS and select T.O.P. overview. Favourite pages

The TV makes a list of the last 10 Text pages you opened. You can easily reopen them again in the Favourite Text pages column.

1. In Text, select the star in the top left corner of the screen to show the column of favourite pages.

2. Press  (down) or  (up) to select a page number and press OK to open the page.

You can clear the list with the option Clear favourite pages.



Text from a connected device

Some devices that receive TV channels can also offer Text. To open Text from a connected device . . .

1. Press , select the device and press OK.

2. While watching a channel on the device, press

OPTIONS , select Show device keys and select



the  key and press OK.

3. Press  to hide the device keys.

4. To close Text, press  again.

Digital Text (UK only)

Some digital broadcasters offer dedicated Digital Text or interactive TV on their digital TV channels. This includes normal Text using the number, colour and arrow keys to select and navigate.

To close Digital Text, press .

Text options

In Text, press  OPTIONS to select the following . . .

- Freeze page / Unfreeze page

To stop the automatic rotation of subpages.

- Dual screen / Full screen

To show the TV channel and Text alongside each other.

- T.O.P. overview

To open T.O.P. Text.

- Enlarge / Normal view

To enlarge the Text page for comfortable reading.

- Reveal

To unhide hidden information on a page.

- Cycle subpages

To cycle subpages when these are available.

- Language

To switch the group of characters that Text uses to display correctly.

- Text 2.5

To activate the Text 2.5 for more colours and better graphics.

Search Text

You can select a word and scan Text for all occurences of this word.

1. Open a Text page and press OK.

Text setup

Copy channel list

Text language

Some digital TV broadcasters have several Text languages available. To set your primary and secondary Text language . . .

1. Press and select Setup and press OK.

2. Select Channel settings > Languages.

3. Select Primary Teletext or Secondary Teletext.

4. Select your preferred Text languages.

5. Press , repeatedly if necessary, to close the menu.

Text 2.5

If available, Text 2.5 offers more colours and better graphics. Text 2.5 is activated as a standard factory setting. To switch off Text 2.5 . . .

1. Press TEXT.

2. While watching the teletext, press  OPTIONS.

3. Select Text 2.5 > Off.

4.Press , repeatedly if necessary, to close the menu.

To copy a channel list . . .

1. Switch on the TV which has its channels installed.

Plug in a USB memory device.

2. Press and select Setup and press OK.

3. Select TV settings > General settings > Copy

channel list > Copy to USB and press OK. To copy the channel list from this TV, you might be asked to enter the Child lock code you entered during the installation.

4. When copying is done, unplug the USB memory

device. Now you can upload the copied channel list onto

another Philips TV.

Upload channel list

To not Installed TVs

Depending on whether your TV is already installed or not, you must use a different method to upload a channel list.

6.3

Channel list copy

Introduction

Channel list copy is intended for dealers and expert users. In some countries, Channel list copy is only availble for copying satellite channels.

With Channel list copy, you can copy the channels installed on one TV onto another Philips TV of the same range. With Channel list copy, you avoid the time-consuming channel search by uploading a predefined channel list on a TV. Use a USB flash drive of minimum 1 GB.

Conditions

- Both TVs are from the same year range.

- Both TVs have the same hardware type. Check the hardware type on the TV type plate on the back of the TV. Typically noted as Q . . . LA

- Both TVs have compatible software versions.

Current version

You can check the current version of the TV software with Current software

info in > Setup > Software settings.

To a TV that is not yet installed

1. Plug in the power plug to start the installation and

select language and country. You can skip Search for channels. Finish the installation.

2. Plug in the USB memory device that holds the

channel list of the other TV.

3. To start the channel list upload, press and

select Setup and press OK.

4. Select TV settings > General settings > Copy

channel list > Copy to TV and press OK. You might be asked to enter the Child lock code of this TV.

5. The TV notifies you if the channel list is copied to

the TV successfully. Unplug the USB memory device.

To Installed TVs

Depending on whether your TV is already installed or not, you must use a different method to upload a channel list.

To an already installed TV

1. Verify the country setting of the TV. (To verify this

setting, press and select Setup and press OK. Select Search for channels > Reinstall channels and press OK. Press  and later Cancel to leave the Search for channels.) If the country is correct continue with step 2. If the country is not correct, you need to start a reinstallation. To start the reinstallation, press and select Setup and press OK. Select TV settings > General settings > Re-install TV > OK. Select the correct country and skip the Search for

channels. Finish the installation. When done, continue with step 2.

2. Plug in the USB memory device that holds the channel list of the other TV.

3. To start the channel list upload, press and select Setup and press OK.

4. Select TV settings > General settings > Copy channel list > Copy to TV and press OK. You might be asked to enter the Child lock code of this TV.

5. The TV notifies you if the channel list is copied to the TV successfully. Unplug the USB memory device.

them.

Channel installation

- Antenna, Cable

7.1

Update channels

Automatic update

If you receive digital channels, you can set the TV to automatically update the list with new channels. Alternatively, you can start a channel update yourself.

Automatic channel update

Once a day, at 6 AM, the TV updates the channels and stores new channels. New channels are stored in the All channels list but also in the New channels list. Empty channels are removed. If new channels are found or if channels are updated or removed, a message is shown at TV start up. The TV must be in standby to automatically update channels.

7.2

Reinstall channels

Reinstall All Channels

You can reinstall all channels and leave all other TV settings untouched.

If a PIN code is set, you will need to enter this code before you can reinstall channels.

To reinstall channels…

1. Press and select Setup and press OK.

2. Select Search for channels > Re-install

Channels and press OK.

3. Select the country where you install the TV.

4. Select Antenna (DVB-T) or Cable (DVB-C) . The

channel search may take a few minutes. Follow the instructions on screen.

To switch off the message at start up . . .

1. Press and select Setup and press OK.

2. Select Channel settings and press OK.

3. Select Channel installation > Channel update message > Off.

To switch off the Automatic channel update . . .

1. Press and select Setup and press OK.

2. Select Channel settings and press OK.

3. Select Channel installation > Automatic channel

update > Off. Start an update

To start an update yourself . . .

1. Press and select Setup and press OK.

2. Select Search for channels and press OK.

3. Select Update channels and follow the instructions on screen. The update may take a few minutes.

In certain countries, the Automatic channel update is done while watching TV or any moment when the TV is in standby.

New channels

New channels added with the automatic channel update are easy to find in the channel list New. The same new channels are also stored in the All or Radio channel list.

New channels are kept in the channel list New as long as you don't mark them as a favourite or tune to

Reinstall TV

You can redo a full TV installation. The TV is completely reinstalled.

To redo a full TV installation…

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Reinstall

TV and press OK. The installation may take a few minutes. Follow the instructions on screen.

7.3

DVB-T or DVB-C

DVB-T or DVB-C reception

DVB Settings

Access DVB settings

1. Press and select Setup and press OK.

2. Select Search for channels and press OK.

3. Select Re-install Channels.

4. Select the country where you install this TV.

5. Select Cable (DVB-C).

6. Select Start to search channels, or select Settings

for DVB-C settings.

7. Press , repeatedly if necessary, to close the

menu.

Symbol rate mode

Free / Scrambled

If your cable provider did not give you a specific

symbol rate value to install the TV channels, leave the Symbol rate mode setting on Automatic.

If you received a specific symbol rate value, select Manual. However, the value you received could be in the predefined list of symbol rates already. Select Predefined symbol rates to check if your value is available automatically.

Symbol rate

With the Symbol rate mode set to Manual, you can enter the symbol rate value you received from your cable provider. To enter the value, use the number keys.

Network frequency

With Frequency scan set to Quick or Advanced, you can enter here the network frequency value received from your cable provider. To enter the value, use the number keys.

Frequency scan

Select the method of searching for channels. You can select the faster Quick scan method and use the predefined settings used by most cable providers in your country.

If you have a subscription and a CAM - Conditional Access Module for pay TV services, select Free + scrambled. If you did not subscribe to pay TV channels or services, you can select Free channels

only.

Reception Quality

You can check the quality and signal strength of a digital channel. If you have your own antenna, you can reposition the antenna to try and improve the reception.

To check the reception quality of a digital channel…

1.Tune to the channel.

2. Press and select Setup and press OK.

3. Select Channel settings and press OK.

4. Select Channel installation > Digital: Reception

Test and press OK.

5. Select Search and press OK. The digital

frequency is shown for this channel.

6. Select Search again and press OK to check the

signal quality of this frequency. The test result is shown on screen. You can reposition the antenna or check the connections to possibly improve the reception.

7. You can also change the frequency yourself. Select

the frequency number one by one and use the  (up) or  (down) keys to change the value. Select Search and press OK to test the reception again.

If this results in having no channels installed or if some channels are missing, you can select the extended Full scan method. This method will take more time to search for and install channels.

Network ID

With Frequency scan set to Quick, you can enter here the network ID value received from your cable provider. To enter the value, use the number keys.

Digital channels

If you know your cable provider is not offering digital channels, you can skip searching for digital channels. Select Off.

Analogue channels

If you know your cable provider is not offering analogue channels, you can skip searching for analogue channels. Select Off.

7.4

Manual Installation

Analogue TV channels can be manually installed, channel by channel.

To install analogue channels manually . . .

1. Press and select Setup and press OK.

2. Select Channel settings > Channel

installation > Analogue : manual installation and press OK.

- System

To set up the TV system, select System and press OK. Select your country or the part of the world where you are now.

- Search channel

To find a channel, select Search channel and press OK. Select Search and press OK. You can also enter a frequency yourself. If the reception is poor, press Search again. If you want to store the channel, select Done and press OK.

- Fine tune

To fine tune a channel, select Fine tune and press OK. You can fine tune the channel with  or . If you want to store the channel found, select Done and press OK.

- Store

You can store the channel on the current channel number or as a new channel number. Select Store current channel or Store as new channel.

You can redo these steps until you found all available analogue TV channels.

Change day

TV guide

8.1

What you need

With the TV guide you can view a list of the current and scheduled TV programmes of your channels. Depending on where the TV guide information (data) is coming from, analogue and digital channels or only digital channels are shown. Not all channels offer TV guide information.

The TV can collect TV guide information for the channels that are installed on the TV (e.g the channels you watch with Watch TV). The TV cannot collect the TV guide information for channels viewed from a digital receiver.

8.2

Using the TV guide

Open the TV guide

To open the TV guide, press  TV GUIDE. Press  TV GUIDE again to close. The first time you open the TV guide, the TV scans all

TV channels for programme information. This may take several minutes. TV guide data is stored in the TV.

Tune to a programme

The TV guide can show scheduled programmes for the upcoming days (maximum up to 8 days).

If the TV guide information comes from the broadcaster, you can press  + to view the schedule of one of the next days. Press   to go back to the previous day. Alternatively, you can press  OPTIONS and select Change day. Select Previous day, Today or Next day and press

OK, to select the day of the schedule.

Set a reminder

You can set a reminder for a programme. A message will alert you at the start of the programme. You can tune to this channel immediately.

In the TV Guide a programme with a reminder is marked with a  (clock).

To set a reminder…

1. Press  TV GUIDE and select an upcoming

programme.

2. Press  OPTIONS.

3. Select Set reminder and press OK.

To clear a reminder…

1. Press  TV GUIDE and select a programme with

the reminder.

2. Press  OPTIONS.

3. Select Clear reminder and press OK.

Switch to a programme

From the TV guide, you can switch to a current programme. To select a programme, use the arrow keys to highlight the programme name. Navigate to the right to view programmes scheduled later that day. To switch to the programme (channel), select the programme and press OK.

View programme details

To call up the details of the selected programme, press  INFO .

Search by genre

If the information is available, you can look up scheduled programmes by genre like movies, sports, etc.

To search for programmes by genre, press OPTIONS and select Search by genre. Select a genre and press OK. A list with the found programmes appears.

List of reminders

You can view a list of the reminders you have set.

List of Reminders

To open the list of reminders…

1. Press  TV GUIDE.

2. Press the colour key  Recordings .



3. At the top of the screen, select  Scheduled and press OK.

4. In the list of scheduled recordings and reminders, select the tab Reminders and press OK to view the reminders only.

5. Press the colour key  Remove to remove the selected reminder. Press the colour key  Record to record the selected programme.

Set a Recording

You can set a recording in the TV Guide*. In the TV Guide, a programme set to be recorded is

marked with  . To see the recording list, press  Recordings , a

programme set to be recorded is marked with a  (red dot) on the front of the programme name.

To record a programme…

1. Press  TV GUIDE and select a future or ongoing programme.

2. Press the colour key  Record . To cancel a recording…

1. Press  TV GUIDE and select the programme set for recording.

2. Press the colour key  Clear Recording .

Recording and pause TV

9.1

Recording

What you need

You can record a digital TV broadcast and watch it later.

1. Press  TV GUIDE.

2. On the TV Guide, select the channel and

programme you wish to record. Press  (right) or  (left) to scroll through the programmes of a channel. Use the colour key  Day to select the day you need.

3. With the programme highlighted, press the colour

key  Record . The programme is scheduled for recording. A warning will show automatically when overlapping recordings are scheduled. If you plan to record a programme in your absence, remember to leave the TV switched to Standby and the USB Hard Drive switched on.

To record a TV programme you need…

- a connected USB Hard Drive formatted on this TV

- digital TV channels installed on this TV

- to receive channel information for the on screen TV Guide

- a reliable TV clock setting. If you reset the TV clock manually, recordings may fail.

You cannot record when you are using Pause TV. In terms enforcement of copyright legislation, some

DVB providers can apply different restriction by means of DRM (Digital Right Management) technology. In case of broadcasting protected channels, recording, record validity or number of views may be restricted. Recording may be completely prohibited. In case of trying to record a protected broadcasting or play back an expired recording, , an error message can appear.

Record a programme

Record now

To record the programme you are watching right now, press  (Record) on the remote control. The recording will start immediately.

List of recordings

You can view and manage your recordings in the list of recordings. Next to the list of recordings, there is a separate list for scheduled recordings and reminders.

To open the list or recordings…

1. Press  TV GUIDE.

2. Press the colour key  Recordings .

3. In the list of recordings, select the

tabs New, Watched or Expired and press OK to filter your view.

4. With a recording selected in the list, you can

remove the recording with the colour key  Remove or stop an ongoing recording with the colour key  Stop Recording . You can rename a recording with the colour key  Rename .

Broadcasters can limit the number of days a recording can be viewed. When this period expires, the recording will be marked as expired. A recording in the list can show the number of days before it expires.

When a scheduled recording was prevented by the broadcaster or when the broadcast was interrupted, a recording is marked as Failed.

Recording Conflicts

To stop the recording, press  (Stop). When TV Guide data is available, the programme you

are watching will be recorded from the moment you pressed the recording key until the programme ends. If no TV Guide data is available, the recording will only last 30 minutes. You can adjust the end time of the recording in the list of Recordings.

Schedule a recording

You can schedule a recording of an upcoming programme for today or a few days from today (maximum of 8 days away). The TV will use the data from the TV Guide to start and end the recording.

To record a programme…

When two scheduled recordings are overlapping in time, there is a recording conflict. To solve a recording conflict, you can adjust the start and end time of one or both scheduled recordings.

To adjust the start or end time of a scheduled recording…

1. Press  TV GUIDE.

2. Press the colour key  Recordings .

3. At the top of the screen, select  Scheduled and

press OK.

4. In the list of scheduled recordings and reminders,

select the tab Recordings and press OK to view the scheduled recordings only.

5. Select the scheduled recording that conflicts with

another scheduled recording and press the colour

key  Adjust Time .

6. Select the start or end time and change the time with the  (up) or  (down) keys. Select Apply and press OK.

Manual Recording

You can schedule a recording that is not linked to a TV programme. You set the tuner type, channel and the start and end time yourself.

With the USB Hard Drive connected and formatted, the TV continuously stores the TV broadcast you are watching. When you switch to another channel, the broadcast of the former channel is cleared. Also when you switch the TV to standby the broadcast is cleared.

You cannot use Pause TV when you are recording.

Pause a programme

To schedule a recording manually…

1. Press  TV GUIDE.

2. Press the colour key  Recordings .

3. At the top of the screen, select  Scheduled and press OK.

4. Press  OPTIONS, select Schedule and press OK.

5. Select the tuner from where you want to record and press OK.

6. Select the channel to record from and press OK.

7. Select the day of the recording and press OK.

8. Set the start and end time of the recording. Select a button and use the  (up) or  (down) keys to set the hours and minutes.

9. Select Schedule and press OK to schedule the manual recording.

The recording will appear in the list of scheduled recordings and reminders.

Watch a Recording

To watch a recording…

1. Press  TV GUIDE.

2. Press the colour key  Recordings .

3. In the list of recordings, select the recording you need and press OK to start watching.

4. You can use the keys  (pause),  (play),  (rewind),  (fast forward) or  (stop).

5. To switch back to watch TV, press  EXIT.

To pause and resume a broadcast… To pause a broadcast, press  (Pause). A progress

bar at the bottom of the screen appears briefly. To call up the progress bar, press  (Pause) again. To resume watching, press  (Play).

With the progress bar on screen, press  (Rewind) or press  (Forward) to select from where you want to start viewing the paused broadcast. Press these keys repeatedly to change speed.

You can pause a broadcast for a maximum time span of 90 minutes.

To switch back to the live TV broadcast, press  (Stop).

Replay

Since the TV stores the broadcast you are watching, you can mostly replay the broadcast for a few seconds.

To replay a current broadcast…

1. Press  (Pause)

2. Press  (Rewind). You can press

to select from where you want to start viewing the paused broadcast. Press these keys repeatedly to change speed. At one point you will reach the start of the broadcast storage or the maximum time span.

3. Press  (Play) to watch the broadcast again.

4. Press  (Stop) to watch the broadcast live.

repeatedly



9.2

Pause TV

What you need

You can pause a digital TV broadcast and resume watching it a bit later.

To pause a TV programme you need…

- a connected USB Hard Drive formatted on this TV

- digital TV channels installed on this TV

- to receive channel information for the on screen TV Guide

Sources

10.1

Switch to a device

In the list of connections - the Source menu - you can find the devices connected to the TV. From this Source menu, you can switch to a device.

Sources menu

To open the Sources menu, press  SOURCES . To switch to a connected device, select the device with the arrows  (left) or  (right) and press OK. To close the Source menu without switching to a device, press  SOURCES again.

10.2

From standby

With the TV in standby, you can switch on a connected device with your TV remote control.

Play

To switch on both disc player and TV from standby and start playing the disc or programme immediately, press  (play) on the TV remote control. The device should be connected with an HDMI cable and both TV and device must have HDMI CEC switched on.

Home Theatre System You can switch on your Home Theatre System to

listen to an audio disc or a radio channel and leave the TV in standby. To only switch on the HTS, with the TV in standby, press  SOURCES on the TV remote control.

10.3

EasyLink

With EasyLink you can operate a connected device with the TV remote control. EasyLink uses HDMI CEC to communicate with the connected devices. Devices must support HDMI CEC and must be connected with an HDMI connection.

Timers and clock

11.1

Sleep timer

With the sleep timer, you can set the TV to switch to standby automatically after a preset time.

To set the sleep timer . . .

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Sleep timer. With the slider bar you can set the time to up to 180 minutes in increments of 5 minutes. If set to 0 minutes, the sleep timer is switched off.You can always switch off your TV earlier or reset the time during the countdown.

3. Press , repeatedly if necessary, to close the menu.

11.2

3. Press , repeatedly if necessary, to close the

menu.

Clock

To know what time it is, press  TV GUIDE to find the time in the TV guide.

In some countries, digital broadcasts do not send UTC

- Coordinated Universal Time information. The daylight saving change might be ignored and the TV might show an incorrect time.

To correct the TV clock . . .

1. Press and select Setup and press OK.

2. Select TV settings > General settings >

Clock > Auto clock mode and select Country dependent.

3. Select Daylight saving and select the appropriate setting.

11.3

Switch off timer

If you do not press a key on the remote control during a 4 hour period, or if the TV receives no input signal nor remote control commands for 10 minutes, the TV switches off automatically to save energy.

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-top box - STB) and you do not use the remote control of the TV, you should deactivate the automatic switch off.

To deactivate the Switch off timer . . .

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Switch off timer and set the slider bar to 0 (Off).

Videos, Photos and Music

To show the progress bar when a video is playing (playhead position, duration, title, date, etc.), press  INFO. Press again to hide the info.

12.1

From a USB connection

You can view your photos or play your music and videos from a connected USB flash drive or USB Hard Drive.

With the TV switched on, plug in a USB flash drive or a USB Hard Drive to one of the USB connections. The TV detects the device and will list your media files.

If the list of files does not appear automatically…

1. Press  SOURCES, select  USB and press OK.

2. Select  USB Devices and press  (right) to select the USB device you need.

You can browse your files in the folder structure you have organised on the drive.

To stop playing videos, photos and music, press  EXIT.

Warning

Video options

During the video playback, press  OPTIONS to…

- Subtitles

Display the subtitles if available.

- Audio language

Play the audio language if available.

- Repeat, Play once

Play videos repeatedly or once.

- Shuffle on, Shuffle off

Play videos in sequence or at random.

- Show info

Display the file name.

- Subtitle settings

Set subtitle colour and position if available.

If you try to pause or record a programme with a USB Hard Drive connected, the TV will ask you to format the USB Hard Drive. This formatting will delete all current files on the USB Hard Drive.

12.2

Play your videos

Play videos

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

To play a video on TV… Select  Videos , and select the file name and

press OK.

- To pause the video, press OK. Press OK again to continue.

- To rewind or go fast forward, press  or . Press the keys several times to speed up - 2x, 4x, 8x, 16x, 32x.

- To jump to the next video in a folder, press OK to pause and select  on screen and press OK.

- To stop the video playback, press  (Stop).

- To go back to the folder, press .

Progress Bar

12.3

View your photos

View photos

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

To view all photos on TV…

Select  Photos , and select All and press OK.

To view a photo on TV…

Select  Photos , and select the file name and press OK.

To start a slide show on TV…

If there are several photos in a folder, you can start a slide show.

To start a slide show…

1. Select the folder with photos.

2. Press the colour key  Slide Show .

- To jump to the next or previous

photo, press  (right - next) or  (left - previous).

- To pause the slide show, press OK. To start again,

press OK again.

- To stop the slide show, press OK and press .

Info

12.4

To view info on a photo (size, creation date, file path, etc.), select a photo and press  INFO. Press again to hide the info.

Slideshow with music

You can watch a slideshow of your photos and listen to your music at the same time. You must start the usic before you start the photo slideshow.

To play music with the slide show…

1. Select a song or a folder with songs and press OK.

2. Press  INFO to hide file info and progress bar.

3. Press .

4. Now use the navigation arrows to select the folder with photos.

5. Select the folder with photos and press  Slide Show.

6. To stop the slideshow, press .

Photo options

Play your music

Play music

How you open the list of your media files on TV depends on the type of device where the files are stored. See the chapters above.

To play a song on TV… Select  Music , and select the file name and

press OK If there are several songs in a folder, you can listen to

them one after the other.

- To pause a song, press OK. Press OK again to

continue.

- To rewind or go fast forward, press  or . Press

the keys several times to speed up - 2x, 4x, 8x, 16x, 32x.

- To jump to the next song in a folder, press OK to

pause and select  on screen and press OK.

- To go back to the folder, press , the music will

keep on playing.

- To stop the music playback, press  (Stop).

With a photo on screen, press  OPTIONS to…

- Start slideshow, Stop slideshow

Start or stop slideshow.

- Slideshow transitions

Set the transition from one picture to the next.

- Slideshow frequency

Select the display time for each photo.

- Repeat, Play once

View the pictures repeatedly or once only.

- Shuffle off, Shuffle on

View the pictures in sequential order, or at random.

- Rotate image

Rotate photo.

- Show info

Display the picture name, date, size and next picture in the slide show.

Progress Bar

To show the progress bar when a song is playing (playhead position, duration, title, date, etc.), press  INFO . Press again to hide the info.

Music options

Options for playing music...

- Stop playback

Stop music play.

- Repeat, Play once

Play songs repeatedly or once.

- Shuffle on, Shuffle off

Play songs in sequence or at random.

- Show info

Display the file name.

- Stop music

Stop the music playing in the background.

Settings

13.1


1. Press and select Setup and press OK.

2. Select TV settings > General

settings > Location and press OK.

3. Select Home and press OK.

4. Press , repeatedly if necessary, to close the

menu.

Picture style

Select a style

For easy picture adjustment, you can select a preset Picture Style.

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Picture style, and select one of the styles in the list.

3. Select a style and press OK. The available Picture styles are ...

- Personal - The picture preferences you set during the first start up.

- Vivid - Ideal for daylight viewing

- Natural - Natural picture settings

- Standard - Most energy conscious setting -

Factory setting

- Movie - Ideal for watching movies

- Photo - Ideal for viewing photos

- Energy saving - Energy-efficient settings

Customise a style

Any picture setting you adjust, like Colour or Contrast, is stored in the currently selected Picture style. It allows you to customise each style.

Picture settings

Colour

With Colour, you can adjust the colour saturation of the picture.

To adjust the colour ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Colour.

3. Press  (right) and adjust the value with

or  (down).

4. Press , repeatedly if necessary, to close the

menu.

Contrast

With Contrast, you can adjust the brightness of the display backlight.

To adjust the level ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Contrast.

3. Press  (right) and adjust the value with

or  (down).

4. Press , repeatedly if necessary, to close the

menu.



(up)

Restore a style

The selected style will store the changes you made. We recommend to adjust the picture settings for the style Personal only. The Picture style - Personal can save its settings for each individual connected device in Sources menu.

To restore the style to its original setting…

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Restore style, and select the Picture Style you want to restore.

3. Press OK. The style is restored.

Home or Shop

If the Picture style is switched back to Vivid every time you switch on the TV, the TV location is set to Shop. A setting meant for in-store promotion.

To set the TV for Home use…

Sharpness

With Sharpness, you can adjust the level of sharpness in fine detail of the picture.

To adjust the sharpness ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Sharpness.

3. Press  (right) and adjust the value with

or  (down).

4. Press , repeatedly if necessary, to close the

menu.

Advanced picture settings



(up)

Game or computer

Custom colour temperature

When you connect a device, the TV recognizes its type and gives each device a correct type name. You can change the type name if you wish. If a correct type name for a device is set, the TV automatically switches to the ideal TV settings when you switch to this device in the Sources menu.

If you have a game console with a built-in Blu-ray Disc player, you might have set the type name to Bluray Disc. With Activity style you can switch to the ideal settings for gaming manually. Don't forget to switch to TV, when you return to watch TV.

To switch the setting manually…

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Advanced > Activity style.

3. Select Game, Computer or TV. The setting TV returns to the picture settings for watching TV.

4. Press , repeatedly if necessary, to close the menu.

With Custom colour temperature, you can set a colour temperature yourself. To set a custom colour temperature, first select Custom in the Colour temperature menu. Custom colour temperature is a setting intended for expert users.

To set a custom colour temperature…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Colour.

3. Select Custom Colour Temperature and

press OK.

3. Press the arrows  (up) or  (down) to adjust

the value. WP is white point and BL is black level. You can also select one of the presets in this menu.

4. Press , repeatedly if necessary, to close the

menu.

Contrast Settings

Contrast modes

Colour settings

Colour enhancement

With Colour enhancement, you can enhance the colour intensity and the details in bright colours.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Advanced > Colour.

3. Select Colour enhancement and press OK.

3. Select Maximum, Medium, Minimum or Off.

4. Press , repeatedly if necessary, to close the menu.

Colour temperature

With Colour temperature, you can set the picture to a preset colour temperature or select Custom to set a temperature setting yourself with Custom colour temperature. Colour temperature and Custom colour temperature are settings intended for expert users.

To select a preset…

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Advanced > Colour.

3. Select Colour Temperature and press OK.

3. Select Normal, Warm or Cool. Or select Custom if you want to customise a colour temperature yourself.

4. Press , repeatedly if necessary, to close the menu.

With Contrast Mode, you can set the level at which power consumption can be reduced by dimming the intensity of the screen. Choose for the best power consumption or for the picture with the best intensity.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Contrast > Contrast mode.

3. Select Standard, Best power, Best picture,

or Off.

4. Press , repeatedly if necessary, to close the

menu.

Dynamic contrast

With Dynamic Contrast, you can set the level at which the TV automatically enhances the details in the dark, middle and light areas of the picture.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Contrast > Dynamic contrast.

3. Select Maximum, Medium, Minimum or Off.

4. Press , repeatedly if necessary, to close the

menu.

Brightness

With Brightness, you can set the level of brightness of the picture signal. Brightness is a setting intended for expert users. We recommend non-expert users to adjust the brightness of the picture with the Contrast setting.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Sharpness > Super resolution.

3. Select On or Off.

4. Press , repeatedly if necessary, to close the

menu.

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Contrast > Brightness.

3. Press  (right) and adjust the value with



(up)

or  (down).

4. Press , repeatedly if necessary, to close the menu.

Video contrast

With Video Contrast, you can decrease the range of the video contrast.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Contrast > Video contrast.

3. Press  (right) and adjust the value with



(up)

or  (down).

4. Press , repeatedly if necessary, to close the menu.

Gamma

With Gamma, you can set a non-linear setting for picture luminance and contrast. Gamma is a setting intended for expert users.

Noise reduction

With Noise reduction, you can filter out and reduce the level of image noise.

To adjust the noise reduction…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Sharpness > Noise reduction.

3. Select Maximum, Medium, Minimum or Off.

4. Press , repeatedly if necessary, to close the

menu.

MPEG artefact reduction

With MPEG artefact reduction, you can smoothen the digital transitions in the picture. MPEG artefacts are mostly visible as small blocks or jagged edges in images.

To reduce the MPEG artefacts…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Sharpness > MPEG artefact reduction.

3. Select Maximum, Medium, Minimum or Off.

4. Press , repeatedly if necessary, to close the

menu.

To adjust the level…

1. Press and select Setup and press OK.

2. Select TV

settings > Picture > Advanced > Contrast > Gamma.

3. Press  (right) and adjust the value with



or  (down).

4. Press , repeatedly if necessary, to close the menu.

Sharpness settings

Super resolution

With Super Resolution, you switch on a superior sharpness in line edges and contours.

To switch on or off…

(up)

Format and edges

Picture format

If black bars appear on top and bottom or on both sides of the picture, you can adjust the picture format to a format that fills the screen.

To change the picture format ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Format and

edges > Picture format.

3. Select a format from the list and press OK.

4. Press , repeatedly if necessary, to close the

menu. To change the picture format while watching TV ...

1. While watching a TV channel, press  to open

the Picture format menu.

2. Select a format from the list and press OK.

Screen edges

With Screen edges, you can slightly enlarge the picture to hide distorted edges.

To adjust the edges ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Format and edges > Screen edges.

3. Adjust the value with  (up) or  (down).

4. Press , repeatedly if necessary, to close the menu.

Restore a style

The selected style will store the changes you made. We recommend to adjust the sound settings for the style Personal only. The Sound Style - Personal can save its settings for each individual connected device in Sources menu.

To restore the style to its original setting…

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Restore style.

Sound settings

Bass

Picture shift

With Picture shift, you can slightly move the position of the picture.

To move the picture ...

1. Press and select Setup and press OK.

2. Select TV settings > Picture > Format and edges > Picture shift.

3. Adjust the position with  (up),  (down), (right), or  (left).

4. Press , repeatedly if necessary, to close the menu.

13.2



Sound

Sound style

Select a style

For easy sound adjustment, you can select a preset setting with Sound style.

With Bass, you can adjust the level of low tones in the sound.

To adjust the level ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Bass.

3. Press  (right) and adjust the value with

or  (down).

4. Press , repeatedly if necessary, to close the

menu.

Treble

With Treble, you can adjust the level of high tones in the sound.

To adjust the level ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Treble.

3. Press  (right) and adjust the value with

or  (down).

4. Press , repeatedly if necessary, to close the

menu.



(up)

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Sound style, and select one of the styles in the list.

3. Select a style and press OK. The available Sound styles are ...

- Personal - The sound preferences you set during the first start up.

- Original - Most neutral sound setting

- Movie - Ideal for watching movies

- Music - Ideal for listening to music

- Game - Ideal for gaming

- News - IIdeal for speech

Surround mode

With Surround mode, you can set the sound effect of the TV speakers.

To set the surround mode ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Surround mode.

3. Press  (right) and select Stereo or Incredible

surround.

4. Press , repeatedly if necessary, to close the

menu.

Headphones volume

With Headphones volume, you can set the volume of a connected headphones separately.

To adjust the volume . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Headphones volume.

3. Press  (up) or  (down) to adjust the volume.

4. Press , repeatedly if necessary, to close the menu.

Advanced sound settings

Auto volume levelling

menu.

Clear sound

With Clear sound, you improve the sound for speech. Ideal for news programmes. You can switch the speech improvement on or off.

To switch on or off ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Clear

sound.

3. Press  (right) and select On or Off.

4. Press , repeatedly if necessary, to close the

menu.

With Auto volume leveling, you can set the TV to automatically level out sudden volume differences. Typically at the beginning of adverts or when you are switching channels.

To switch on or off ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Auto volume leveling.

3. Press  (right) and select On or Off.

4. Press , repeatedly if necessary, to close the menu.

TV speakers

You can send the TV sound to a connected audio device - a Home Theatre System or audio system. With TV speakers, you select where you want to hear the TV sound and how you want to control it.

- If you select Off, you permanently switch off the TV speakers.

- If you select On, the TV speakers are always on. With an audio device connected with HDMI CEC, you

can use one of the EasyLink settings.

- If you select EasyLink, the TV sends the TV sound to the audio device. The TV will switch off the TV speakers when the device is playing the sound.

- If you select EasyLink autostart, the TV will switch on the audio device, send the TV sound to the device and switch off the TV speakers. With EasyLink or EasyLink autostart selected, you can still switch to TV speakers or device speakers in the Picture and sound menu.

To set the TV speakers ...

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > TV speakers.

3. Press  (right) and select Off, On, EasyLink or EasyLink autostart.

4. Press , repeatedly if necessary, to close the

HDMI1-ARC

If you do not need an Audio Return Channel (ARC) on any of the HDMI connections, you can switch the ARC signal off.

1. Press and select Setup and press OK.

2. Select TV

settings > Sound > Advanced > HDMI 1 - ARC.

3. Press  (right) and select On or Off.

4. Press , repeatedly if necessary, to close the

menu.

Audio out format

With Audio out format you can set the audio out signal of the TV to fit the sound processing capabilities of your Home Theatre System.

To set Audio out format…

1. Press and select Setup and press OK.

2. Select TV

settings > Sound > Advanced > Audio out format.

3. Press  (right) and

select Multichannel or Stereo.

4. Press , repeatedly if necessary, to close the

menu.

Audio out levelling

With Audio out leveling you can level the sound volume of the Home Theatre System with the volume of the TV when you switch over from one to another.

To level the difference in volume…

1. Press and select Setup and press OK.

2. Select TV

settings > Sound > Advanced > Audio out levelling.

3. Select More, Medium, or Less, then press OK.

4. If the volume difference is large, select More. If

the volume difference is small, select Less.

5. Press , repeatedly if necessary, to close the menu.

Menu language

To change the language of the TV menus and messages…

Audio out delay

With a Home Theatre System (HTS) connected to the TV, the picture on TV and the sound from the HTS should be synchronised.

Automatic audio to video sync

With recent Philips Home Theatre Systems, the audio to video sync is automatically synchronised and always correct.

Audio sync delay

To switch off the Audio Out delay . . .

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out delay.

3. Select Off and press OK.

4. Press , repeatedly if necessary, to close the menu.

Audio out offset

If you cannot set a delay on the Home Theatre System, you can set a delay on the TV with Audio out offset.

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Menu

language.

3. Select on the language you need.

4. Press , repeatedly if necessary, to close the

menu.

Clock

Date and Time

Automatic

In some countries, digital broadcasts do not send UTC

- Coordinated Universal Time information. The

daylight saving change might be ignored and the TV might show an incorrect time.

When you record programmes - scheduled in the TV Guide, we recommend not to change the time and date manually. In some countries, for some network operators, the Clock setting is hidden to avoid an incorrect clock setting.

To correct the TV clock automatically...

1. Press and select Setup and press OK.

2. Select TV settings > General

settings > Clock > Auto Clock Mode, and select Country dependent.

3. Select Daylight saving and select the appropriate

setting.

4. Press , repeatedly if necessary, to close the

menu.

To synchronise the sound on the TV…

1. Press and select Setup and press OK.

2. Select TV settings > Sound > Advanced > Audio out offset.

3. Use the slider bar to set the sound offset and press OK.

4. Press , repeatedly if necessary, to close the menu.

13.3

General settings

Manual

To set the TV clock manually…

1. Press and select Setup and press OK.

2. Select TV settings > General

settings > Clock > Auto Clock Mode, and select Manual.

3. Select Date and Time to adjust.

4. Press , repeatedly if necessary, to close the

menu.

Time zone

To set the time zone…

1. Press and select Setup and press OK.

2. Select TV settings > General

settings > Clock > Time zone.

3. Select one of the time zones.

4. Press , repeatedly if necessary, to close the menu.

Sleep timer

With the sleep timer, you can set the TV to switch to standby automatically after a preset time.

To set the sleep timer . . .

1. Press and select Setup and press OK.

3. Press , repeatedly if necessary, to close the menu.

Switch off timer

If you use the TV as a monitor or use a digital receiver to watch TV (a Set-Top Box - STB) and you do not use the remote control of the TV, you should deactivate this automatic switch off.

To deactivate the Switch off timer …

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Switch off timer.

3. Select inside the slider bar to adjust the value. The value 0 (Off) deactivates the automatic switch off.

4. Press , repeatedly if necessary, to close the menu.

TV placement

As part of the first installation, this setting is set to either On a TV stand or On the Wall. If you have changed the placement of the TV since then, adjust this setting accordingly for best sound reproduction.

1. Press and select Setup and press OK.

2. Select TV settings > General settings > TV

Placement and press OK.

3. Select On a TV stand or On the Wall.

4. Press , repeatedly if necessary, to close the

menu.

Factory settings

You can set the TV back to the original TV settings (the factory settings).

To switch back to the original settings…

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Factory

Settings and press OK.

3. Press , repeatedly if necessary, to close the

menu.

Reinstall TV

You can redo a full TV installation. The TV is completely reinstalled.

To redo a full TV installation…

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Reinstall

TV and press OK.

3. Follow the instructions on screen. The installation

may take a few minutes.

13.4

Ambilight (For 630/6300

Location

To set the TV for Home use…

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Location and press OK.

3. Select Home and press OK.

4. Press , repeatedly if necessary, to close the menu.

series)

Ambilight style

Ambilight can have a dynamic mode or a static mode. With Dynamic mode, the TV follows the colours of the image on screen. With Static, Ambilight has a constant static colour. You can create an Ambilight static colour yourself.

To select an Ambilight mode . . .

1. Press and select Setup and press OK.

2. Select TV settings > Ambilight > Ambilight

mode.

3. Select Dynamic or Static.

4. Press , repeatedly if necessary, to close the menu.

Advanced Ambilight settings

To select a static colour . . .

1. Press and select Setup and press OK.

2. Select TV settings > Ambilight > Ambilight mode > Static and press OK.

3. Select the colour from the colour palette. Press OK to confirm.

4. Press , repeatedly if necessary, to close the menu.

Ambilight brightness

With Ambilight Brightness, you can set the level of brightness of the Ambilight.

To adjust the level . . .

1. Press and select Setup and press OK.

2. Select TV settings > Ambilight > Brightness.

3. Press OK and adjust the value with  (up) or  (down).

4. Press , repeatedly if necessary, to close the menu.

Wall colour

With Wall colour, you can neutralise the influence of a coloured wall on the Ambilight colours. Select the colour of the wall behind the TV and the TV will modify the Ambilight colours to appear as they are intended.

To select the colour of the wall . . .

1 - Press and select Setup and press OK. 2 - Select TV settings > Ambilight > Advanced > Wall colour. 3 - Select the colour sample that matches the colour of the wall behind the TV and press OK. 4 - Press

menu.

TV switch off

With TV switch off, you can set Ambilight to switch off immediately or slowly fade out when you switch off the TV. The slow fade out gives you some time to switch on the lights in your living room.

, repeatedly if necessary, to close the



Ambilight saturation

With Ambilight Saturation, you can set the level of saturation of the Ambilight.

To adjust the level . . .

1. Press and select Setup and press OK.

2. Select TV settings > Ambilight > Saturation.

3. Press OK and adjust the value with  (up) or  (down).

4. Press , repeatedly if necessary, to close the menu.

Dynamic speed

With Dynamic, you can set the speed at which Ambilight responds to the images on screen. Adjust the speed between Relaxed or Dynamic. The Ambilight mode must be set to Dynamic before you can adjust Dynamic speed.

To adjust the speed . . .

1. Press and select Setup and press OK.

2. Select TV settings > Ambilight > Dynamic.

3. Press  (right) and adjust the value with or  (down).

4. Press , repeatedly if necessary, to close the menu.



(up)

To select the TV switch off . . .

1 - Press and select Setup and press OK. 2 - Select TV settings > Ambilight > Advanced > TV switch off. 3 - Select Fade out to off or Immediate switch off. 4 - Press

menu.

, repeatedly if necessary, to close the



European energy label

Specifications

14.1

Environmental

Saving energy

The Eco settings bundle the settings that help the environment. While you are watching TV channels, press  to open Eco settings. Press  again to close Eco settings .

Energy saving

This Picture style sets the picture, in the most ideal energy conscious setting.

Screen off

If you only listen to music, you can switch off the TV screen to save energy. Select Screen off and press OK. To switch the screen back on, press any key on the remote control.

Auto switch off

If you do not press a key on the remote control during a 4 hour period, or if the TV receives no signal for 10 minutes, the TV switches off automatically to save energy. If you use the TV as a monitor or use a digital receiver to watch TV (a Set-top box - STB) and you do not use the remote control of the TV, deactivate the automatic switch off.

In addition to the Eco settings, your TV also has environmentally friendly technology with regard to power consumption.

Inactive devices off

Switch off connected EasyLink HDMI-CEC (Consumer Electronic Control) compliant devices that are inactive.

Power management

The advanced power management of this TV ensures the most efficient use of energy. You can check how your personal TV settings, the level of brightness in current onscreen pictures, and the surrounding light conditions determine the relative power consumption. To check the relative power consumption . . .

The European Energy Label informs you on the energy efficiency class of this product. The greener the energy efficiency class of this product is, the lower the energy it consumes. On the label, you can find the energy efficiency class, the average power consumption of this product in use and the average energy consumption for 1 year. You can also find the power consumption values for this product on the Philips website for your country at

www.philips.com/TV

Product Fiche

For 6300 series 40PFx6300

- Energy Efficiency Class : A+

- Visible Screen Size : 102 cm / 40 inch

- On Mode Power Consumption (W) : 49 W

- Annual Energy Consumption (kWh) * : 72 kWh

- Standby Power Consumption (W) **: 0.30 W

- Off Mode Power Consumption (W) : 0.30 W

- Display Resolution (Pixels) : 1920x1080p

48PFx6300

- Energy Efficiency Class : A+

- Visible Screen Size : 121 cm / 48 inch

- On Mode Power Consumption (W) : 67 W

- Annual Energy Consumption (kWh) * : 98 kWh

- Standby Power Consumption (W) **: 0.30 W

- Off Mode Power Consumption (W) : 0.30 W

- Display Resolution (Pixels) : 1920x1080p

55PFx6300

- Energy Efficiency Class : A+

- Visible Screen Size : 139 cm / 55 inch

- On Mode Power Consumption (W) : 72 W

- Annual Energy Consumption (kWh) * : 104 kWh

- Standby Power Consumption (W) **: 0.30 W

- Off Mode Power Consumption (W) : 0.30 W

- Display Resolution (Pixels) : 1920x1080p

* Energy consumption kWh per year, based on the power consumption of the television operating 4 hours per day for 365 days. The actual energy consumption depends on how the television is used.

** When the TV is turned off with the remote control and no function is active.

1. Press and select Setup and press OK.

2. Select Watch demos > Active control Demo and press OK.

3. Select a setting to check the corresponding values.

End of use

Disposal of your old product and batteries

14.3

Display

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC.

Please inform yourself about the local separate collection system for electrical and electronic products.

Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste.

Type

For 6300 series

Diagonal screen size :

- 40Pxx6300 : 102 cm / 40 inch

- 48Pxx6300 : 122 cm / 48 inch

- 55Pxx6300 : 140 cm / 55 inch

Display resolution:

- PFx6300 : 1920x1080p

Display resolutions

Computer formats - HDMI (Resolution - refresh rate) 640 x 480 - 60 Hz 800 x 600 - 60 Hz 1024 x 768 - 60 Hz 1280 X 720 - 60 Hz 1280 X 768 - 60 Hz 1280 x 1024 - 60 Hz 1360 x 768 - 60 Hz 1680 x 1050 - 60 Hz* 1920 x 1080 - 60 Hz*

Computer formats - VGA (Resolution - refresh rate) 640 x 480 - 60 Hz 800 x 600 - 60 Hz 1024 x 768 - 60 Hz 1280 x 1024 - 60 Hz 1360 x 768 - 60 Hz 1920 x 1080 - 60 Hz*

Please find out for yourself about the local rules on separate collection of batteries because correct disposal will help to prevent negative consequences for the environment and human health.

14.2

Reception for PxH / PxT models

- Aerial input : 75 ohm coaxial (IEC75)

- Tuner bands : Hyperband; S-Channel; UHF; VHF

- DVB : DVB-T (terrestrial, antenna) COFDM 2K/8K; DVB-T2 : only for TV types '. . . T/12'; DVB-C (cable) QAM

- Analogue video playback : NTSC; SECAM; PAL

- Digital video playback : MPEG2 SD/HD (ISO/IEC 13818-2); MPEG4 SD/HD (ISO/IEC 14496-10)

- Digital audio playback (ISO/IEC 13818-3)

Video formats (Resolution - refresh rate) 480i - 60 Hz 480p - 60 Hz 576i - 50 Hz 576p - 50 Hz 720p - 50Hz, 60 Hz 1080i - 50Hz, 60 Hz 1080p - 24Hz, 25Hz, 30Hz, 50Hz, 60 Hz

* For PFxxxxx sets only.

14.4

Power

Product specifications are subject to change without notice. For more specification details of this product, see www.philips.com/support

Power

- Mains power : AC 220-240V +/-10%

- Ambient temperature : 5°C to 35°C

- Standby power consumption : less than 0.3W

- Power saving features : Eco mode, Picture mute (for radio), Auto switch off , Eco settings menu.

The power rating stated on the product typeplate is the power consumption for this product during normal household use (IEC 62087 Ed.2). The maximum power rating, stated between brackets, is used for electrical safety (IEC 60065 Ed. 7.2).

14.5

Dimensions and weights

For 6300 series

40Pxx6300

- without TV stand: Width 911 mm - Height 528.3 mm - Depth 47.7 mm Weight ± 9.26 kg

- with TV stand: Width 911 mm - Height 591.6 mm - Depth 241.5 mm

- Weight ± 12 kg

48Pxx6300

- without TV stand: Width 1079.4 mm - Height 623.1mm - Depth 48.3 mm

- Weight ± 12.3 kg

- with TV stand: Width 1079.4 mm - Height 686.2 mm - Depth 263.6 mm - Weight ± 16 kg

55Pxx6300

- without TV stand: Width 1235 mm - Height 710.6 mm - Depth 48 mm Weight ± 17 kg

- Satellite

TV Side

- CI: Common Interface

- USB

- Headphones: Stereo 3.5mm mini-jack

For PxH6300/PxT6300

TV Rear

- HDMI 1 ARC: HDMI Audio Return Channel

- HDMI 2

- SERV. U: Service port

- SCART (RGB/CVBS): SCART adaptor

- AUDIO IN (DVI/VGA): Stereo 3.5mm mini-jack

- DIGITAL AUDIO OUT: SPDIF

- TV ANTENNA: 75 ohm coaxial (IEC)

TV Side

- CI: Common Interface

- USB

- Headphones: Stereo 3.5mm mini-jack

14.7

Sound

For 6300 series

- Mono / Stereo

- Sound enhancement : Incredible Surround, Clear

Sound

- Output power:

20W (RMS @ 15% THD)

- with TV stand: Width 1235 mm - Height 776.7 mm - Depth 279 mm Weight ± 20.5 kg

14.6

Connectivity

For 6300 series

For PxK6300 TV Rear

- HDMI 1 ARC: HDMI Audio Return Channel

- HDMI 2

- SERV. U: Service port

- SCART (RGB/CVBS): SCART adaptor

- AUDIO IN (DVI/VGA): Stereo 3.5mm mini-jack

- DIGITAL AUDIO OUT: SPDIF

- TV ANTENNA: 75 ohm coaxial (IEC)

14.8

Multimedia

Note: Multimedia file names must not exceed 128 characters.

Supported multimedia connections

- USB (FAT / FAT 32 / NTFS): only connect USB

devices that consume 500 mA of power or less.

Supported image files

- JPEG: *.jpg, *.jpeg

- PNG: *.png.jpg

Supported audio files

- MPEG1: *.mp3

Supported video files

- *.avi, *.mp4, *.mov, *.mkv, *.mpg, *.mpeg

Supported subtitle format

- SRT: multiple language support

15.3

Software

15.1

Software update

It might be necessary to update the TV software. You need a computer and a USB memory device to upload the software on the TV. Use a USB memory device with 256MB free space. Make sure that write protection is switched off.

1. Start the update on TV

To start the software update . . . Press , select Setup and press OK. Select Update software > USB and press OK.

2. Identify the TV

Insert the USB memory into one of the USB connections of the TV. Select Start and press OK. An identification file is written on the USB memory device.

3. Download the TV software

Insert the USB memory into your computer. On the USB memory device, locate the file update.htm and double click it. Click on Send ID. If new software is available, download the .zip file. After the download, unzip the file and copy the file autorun.upg onto the USB memory device. Do not place this file in a folder.

4. Update the TV software

Insert the USB memory into the TV again. The update starts automatically. The TV switches itself off for 10 seconds and then back on again. Please wait.

Do not . . .

- use the remote control

- remove the USB memory device from the TV If a power cut occurs during the update, never

remove the USB memory device from the TV. When the power returns, the update will continue.

15.2

Software version

Open source software

This television contains open source software. TP Vision Europe B.V. hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such offer is requested by the respective licences.

This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain the source code, please write in English to . . .

Intellectual Property Dept. TP Vision Europe B.V. Prins Bernhardplein 200 1097 JB Amsterdam The Netherlands

15.4

Open source license

Open source license statement

Acknowledgements and License Texts for any open source software used in this product. This is a document describing the distribution of the source code used in this product, which fall either under the GNU General Public License (the GPL), or the GNU Lesser General Public License (the LGPL), or any other open source license. Instructions to obtain source code for this software can be found in the documentation supplied with this product. TP VISION MAKES NO WARRANTIES WHATSOEVER, EITHER EXPRESS OR IMPLIED, INCLUDING ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS SOFTWARE.

TP Vision offers no support for this software. The preceding does not affect your warranties and statutory rights regarding any product(s) you purchased. It only applies to this source code made available to you.

To view the current TV software version ...

1. Press and select Setup and press OK.

2. Select Software settings and press OK.

3. Select Current software info and see Release Version.

4. Press , repeatedly if necessary, to close the menu.

libsqlite3 (3.7.14)

SQLite is a C library that implements an SQL database engine. Programs that link with the SQLite library can have SQL database access without running a separate RDBMS process.

Source: http://linuxappfinder.com/package/libsqlite

3-0

libpng

libpng is the official PNG reference library. It supports almost all PNG features.

Source: www.libpng.org

layers, not only on top of the Linux Framebuffer Device.

It is a complete hardware abstraction layer with software fallbacks for every graphics operation that is not supported by the underlying hardware. DirectFB adds graphical power to embedded systems and sets a new standard for graphics under Linux.

Source: http://directfb.org/

OpenSSL (1.0.0.d)

The OpenSSL Project is a collaborative effort to develop a robust, commercial-grade, full-featured, and Open Source toolkit implementing the Secure Sockets Layer (SSL v2/v3) and Transport Layer Security (TLS v1) protocols as well as a full-strength general purpose cryptography library. The project is managed by a worldwide community of volunteers that use the Internet to communicate, plan, and develop the OpenSSL toolkit and its related documentation.

Source: www.openssl.org

libboost (1.51)

Boost provides free peer-reviewed portable C++ source libraries, and emphasize libraries that work well with the C++ Standard Library.

Boost libraries are intended to be widely useful, and usable across a broad spectrum of applications.

The Boost license encourages both commercial and non-commercial use.

Source: www.boost.org

libTomMath (0.42.0)

LibTom Projects are open source libraries written in portable C under WTFPL. The libraries supports a variety of cryptographic and algebraic primitives designed to enable developers and students to pursue the field of cryptography much more efficiently.

Source: http://libtom.org/

MTD utility (1.5.0)

MTD subsystem (stands for Memory Technology Devices) provides an abstraction layer for raw flash devices. It makes it possible to use the same API when working with different flash types and technologies, e.g. NAND, OneNAND, NOR, AG-AND, ECC'd NOR, etc.

MTD subsystem does not deal with block devices like MMC, eMMC, SD, CompactFlash, etc. These devices are not raw flashes but they have a Flash Translation layer inside, which makes them look like block devices. These devices are the subject of the Linux block subsystem, not MTD.

libjpeg (6b)

Libjpeg is a widely used C library for reading and writing JPEG image files.

Source: http://libjpeg.sourceforge.net/

zlib (1.2.7)

A massively spiffy yet delicately unobtrusive compression library

Source: www.zlib.net

libdirectfb (1.4.11)

DirectFB is a thin library that provides hardware graphics acceleration, input device handling and abstraction, integrated windowing system with support for translucent windows and multiple display

Source: http://www.linuxmtd.infradead.org/source.html

libscew

The aim of SCEW is to provide an easy interface around the XML Expat parser, as well as a simple interface for creating new XML documents. It provides functions to load and access XML elements without the need to create Expat event handling routines every time you want to load a new XML document.

SCEW is freely available for download under the terms of the GNU Lesser General Public License v2.1 (LGPL).

Source: http://www.nongnu.org/scew/

libexpat

Expat is an XML parser library written in C. It is a stream-oriented parser in which an application

registers handlers for things the parser might find in the XML document (like start tags).

Source: http://expat.sourceforge.net/

libdrm

libdrm provides core library routines for the X Window System to directly interface with video hardware using the Linux kernel's Direct Rendering Manager (DRM).

Source: http://dri.freedesktop.org/libdrm/

FFMpeg (0.6)

A complete, cross-platform solution to record, convert and stream audio and video.

Source: www.ffmpeg.org

Philips startup screen

Troubleshooting and support

16.1

Troubleshooting

Channels

No digital channels found during the installation

See the technical specifications to make sure that your TV supports DVB-T or DVB-C in your country. Make sure that all cables are properly connected and that the correct network is selected.

Previously installed channels are not in the channel list

Make sure that the correct channel list is selected.

When the TV is in standby, a Philips startup screen is displayed, then the TV returns to standby mode. This is normal behaviour. When the TV is disconnected and reconnected to the power supply, the startup screen is displayed at the next startup. To switch on the TV from standby, press on the remote control or the TV.

The standby light keeps on blinking

Disconnect the power cable from the power outlet. Wait 5 minutes before you reconnect the power cable. If the blinking reoccurs, contact Philips TV Consumer Care.

Wrong menu language

Change the language back to your language.

1. Press and select Setup and press OK.

2. Select TV settings > General settings > Menu

language and press OK.

3. Select the language you want and press OK.

4. Press , repeatedly if necessary, to close the

menu.

General

The TV does not switch on

- Disconnect the power cable from the power outlet. Wait for one minute then reconnect it.

- Make sure that the power cable is securely connected.

Creaking sound at startup or switch off

When you are turning the TV on, off or to standby, you hear a creaking sound from the TV chassis. The creaking sound is due to the normal expansion and contraction of the TV as it cools and warms up. This does not affect performance.

TV does not respond to the remote control

The TV requires some time to start up. During this time, the TV does not respond to the remote control or TV controls. This is normal behaviour. If the TV continues to be unresponsive to the remote control, you can check if the remote control is working by means of a mobile phone camera. Put the phone in camera mode and point the remote control to the camera lens. If you press any key on the remote control and you notice the infra red LED flicker through the camera, the remote control is working. The TV needs to be checked. If you do not notice the flickering, the remote control might be broken or its batteries are low. This method of checking the remote control is not possible with remote controls which are wirelessly paired with the TV.

The TV goes back to standby after showing the


No picture / distorted picture

- Make sure that the antenna is properly connected

to the TV.

- Make sure that the correct device is selected as the

display source.

- Make sure that the external device or source is

properly connected.

Sound but no picture

- Make sure that the picture settings are set correctly.

Poor antenna reception

- Make sure that the antenna is properly connected

to the TV.

- Loud speakers, unearthed audio devices, neon

lights, high buildings and other large objects can influence reception quality. If possible, try to improve the reception quality by changing the antenna direction or moving devices away from the TV.

- If reception on only one channel is poor, fine-tune

this channel.

Poor picture from a device

- Make sure that the device is connected properly.

- Make sure that the picture settings are set correctly.

Picture settings change after a while

Make sure that Location is set to Home . You can change and save settings in this mode.

A commercial banner appears

Make sure that Location is set to Home. Picture does not fit the screen

Change to a different picture format. Press .

Picture format keeps changing with different channels

Select a non 'Auto' picture format.

Picture position is incorrect

EasyLink does not work

- Make sure that your HDMI devices are HDMI-CEC

compatible. EasyLink features only work with devices that are HDMI-CEC compatible.

No volume icon shown

- When a HDMI-CEC audio device is connected this

behaviour is normal.

Photos, videos and music from a USB device do not show

Picture signals from some devices may not fit the screen correctly. Check the signal output of the connected device.

Computer picture is not stable

Make sure that your PC uses the supported resolution and refresh rate.

Sound

No sound or poor sound quality

If no audio signal is detected, the TV automatically switches the audio output off — this does not indicate malfunction.

- Make sure that the sound settings are correctly set.

- Make sure that all cables are properly connected.

- Make sure that the volume is not muted or set to zero.

- Make sure that the TV audio output is connected to the audio input on the Home Theatre System.

- Sound should be heard from the HTS speakers.

- Some devices may require you to manually enable HDMI audio output. If HDMI audio is already enabled, but you still do not hear audio, try changing the digital audio format of the device to PCM (Pulse Code Modulation). Refer to the documentation accompanying your device for instructions.

- Make sure that the USB storage device is set to

Mass Storage Class compliant, as described in the storage device's documentation.

- Make sure that the USB storage device is

compatible with the TV.

- Make sure that the audio and picture file formats

are supported by the TV.

Choppy playback of USB files

- The transfer performance of the USB storage

device may limit the data transfer rate to the TV which causes poor playback.

16.2

Register your TV and enjoy a range of benefits including full support (including downloads), privileged access to information about new products, exclusive offers and discounts, the chance to win prizes and even participate in special surveys about new releases.

Go to www.philips.com/welcome

16.3

Help

Connections

HDMI

- Note that HDCP (High-bandwidth Digital Content Protection) support can delay the time taken for a TV to display content from an HDMI device.

- If the TV does not recognise the HDMI device and no picture is displayed, switch the source from one device to another and back again.

- If there are intermittent sound disruptions, make sure that output settings from the HDMI device are correct.

- If you use an HDMI-to-DVI adapter or HDMI-toDVI cable, make sure that an additional audio cable is connected to AUDIO IN (mini-jack only), if available.

This TV offers help on screen.

Open Help

1. Press to open the Home menu.

2. Select Help and press OK.

UMv_v9_20160323 UMv_v11_20160505

16.4

Online help

To solve any Philips TV related problem, you can consult our online support. You can select your language and enter your product model number.

Go to www.philips.com/support . On the support site you can find your country's

telephone number to contact us as well as answers to frequently asked questions (FAQs). In some countries, you can chat with one of our colaborators and ask your question directly or send a question by email. You can download new TV software or the manual to read on your computer.

16.5

Consumer Care / Repair

For support and repair, call the Consumer Care hotline in your country. Find the telephone number in the printed documentation that came with the TV. Or consult our website www.philips.com/support .

TV model number and serial number

You might be asked to provide the TV product model number and serial number. Find these numbers on the packaging label or on the type label on the back or bottom of the TV.

Warning



Do not attemp to repair the TV yourself. This may cause severe injury, irreparable damage to your TV or void your warranty.

Risk of injury or damage to the TV

Safety and care

17.1

Safety

Important

Read and understand all safety instructions before you use the TV. If damage is caused by failure to follow instructions, the warranty does not apply.

Secure the TV from falling over

Always use the supplied wall bracket to secure the TV from falling over. Mount the bracket and secure the TV onto the bracket, even if you put the TV on the floor.

You can find the mounting instructions in the Quick Start Guide that came with the TV. In case you lost this guide, you can download the guide from

www.philips.com

Use the product type number of the TV to look for the Quick Start Guide to download.

- Two people are required to lift and carry a TV that

weighs more than 25 kg or 55 lbs.

- If you mount the TV on a stand, only use the

supplied stand. Secure the stand to the TV tightly. Place the TV on a flat, level surface that can support the weight of the TV and the stand.

- When wall mounted, ensure that the wall mount

can safely bear the weight of the TV set. TP Vision bears no responsibility for improper wall mounting that results in accident, injury or damage.

- Parts of this product are made of glass. Handle with

care to avoid injury or damage.

Risk of damage to the TV !

Before you connect the TV to the power outlet, ensure that the power voltage matches the value printed on the back of the TV. Never connect the TV to the power outlet if the voltage is different.

Risk of injury

Follow these precautions to prevent the TV from toppling over and causing injury:

Risk of electric shock or fire

- Never expose the TV to rain or water. Never place liquid containers, such as vases, near the TV. If liquids are spilt on or into the TV, disconnect the TV from the power outlet immediately. Contact Philips TV Consumer Care to have the TV checked before use.

- Never expose the TV, remote control or batteries to excessive heat. Never place them near burning candles, naked flames or other heat sources, including direct sunlight.

- Never insert objects into the ventilation slots or other openings on the TV.

- Never place heavy objects on the power cord.

- Avoid force coming onto power plugs. Loose power plugs can cause arcing or fire. Ensure that no strain is exerted on the power cord when you swivel the TV screen.

- To disconnect the TV from the mains power, the power plug of the TV must be disconnected. When disconnecting the power, always pull the power plug, never the cord. Ensure that you have full access to the power plug, power cord and outlet socket at all times.

- Never place the TV on a surface covered by a cloth

or other material that can be pulled away.

- Ensure that no part of the TV hangs over the edge

of the mounting surface.

- Never place the TV on tall furniture, such as a

bookcase, without anchoring both the furniture and TV to the wall or a suitable support.

- Teach children about the dangers of climbing on

furniture to reach the TV.

Risk of swallowing batteries !

The remote control may contain coin-type batteries which can easily be swallowed by small children. Keep these batteries out of reach of children at all times.

Risk of overheating

Never install the TV in a confined space. Always leave a space of at least 10 cm or 4 inches around the TV for ventilation. Ensure curtains or other objects never cover the ventilation slots on the TV.

Lightning storms

Disconnect the TV from the power outlet and antenna before lightning storms. During lightning storms, never touch any part of the TV, power cord or antenna cable.

Risk of hearing damage

Avoid using earphones or headphones at high volumes or for prolonged periods of time.

Low temperatures

If the TV is transported in temperatures below 5 degrees Celsius or 41 degrees Fahrenheit, unpack the TV and wait until the TV temperature reaches room temperature before connecting the TV to the power outlet.

Humidity

In rare occasions, depending on temperature and humidity, minor condensation can occur on the inside of the TV glass front (on some models). To prevent this, do not expose the TV to direct sunlight, heat or extreme humidity. If condensation occurs, it will disappear spontaneously while the TV is playing for a few hours. The condensation moisture will not harm the TV or cause malfunction.

17.2

Screen care

- Never touch, push, rub or strike the screen with any object.

- Unplug the TV before cleaning.

- Clean the TV and frame with a soft damp cloth and wipe gently. Never use substances such as alcohol, chemicals or household cleaners on the TV.

- To avoid deformations and colour fading, wipe off water drops as quickly as possible.

Avoid stationary images as much as possible. Stationary images are images that remain onscreen for extended periods of time. Stationary images include onscreen menus, black bars, time displays, etc. If you must use stationary images, reduce screen contrast and brightness to avoid screen damage.

18.1

Europe B.V. or one of its affiliates, hereinafter referred to as TP Vision, which is the manufacturer of the product. TP Vision is the warrantor in relation to the TV with which this booklet was packaged. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V or their respective owners. TP Vision reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly.

The written material packaged with the TV and the manual stored in the memory of the TV or downloaded from the Philips website are believed to be adequate for the intended use of the system.

The material in this manual is believed adequate for the intended use of the system. If the product, or its individual modules or procedures, are used for purposes other than those specified herein, confirmation of their validity and suitability must be obtained. TP Vision Europe B.V. warrants that the material itself does not infringe any United States patents. No further warranty is expressed or implied. TP Vision Europe B.V. cannot be held responsible neither for any errors in the content of this document nor for any problems as a result of the content in this document. Errors reported to Philips will be adapted and published on the Philips support website as soon as possible. Terms of warranty Risk of injury, damage to TV or void of warranty! Never attempt to repair the TV yourself. Use the TV and accessories only as intended by the manufacturer. The caution sign printed on the back of the TV indicates risk of electric shock. Never remove the TV cover. Always contact Philips TV Customer Care for service or repairs. Any operation expressly prohibited in this manual, or any adjustments and assembly procedures not recommended or authorised in this manual, shall void the warranty. Pixel characteristics This LCD/LED product has a high number of colour pixels. Although it has effective pixels of 99.999% or more, black dots or bright points of light (red, green or blue) may appear constantly on the screen. This is a structural

property of the display (within common industry standards) and is not a malfunction.

CE compliance

Hereby, TP Vision Europe B.V. declares that this television is in compliance with the essential requirements and other relevant provisions of Directives 1999/5/EC RTTE), 2004/108/EC (EMC), 2006/95/ EC (Low Voltage), 2009/125/EC (Energy Labelling) and 2011/65/EC (RoHS).

From June 2016 onwards the following Directives are valid 2014/53/EU (RED), 2009/125/EC (Eco Design), 2010/30/ EU (Energy Labelling) and 2011/65/EC (RoHS).

Compliance with EMF TP Vision Europe B.V. manufactures and sells many products targeted at consumers which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals. One of Philips’ leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the Electro Magnetic Field (EMF) standards applicable at the time of producing the products. Philips is committed to develop, produce and market products that cause no adverse health effects. TP Vision confirms that, as long as its products are handled properly for their intended use, they are safe to use according to scientific evidence available today. Philips plays an active role in the development of international EMF and safety standards, enabling Philips to anticipate further developments in standardisation for early integration in its products.

18.2

Copyrights and licenses

HDMI

HDMI®

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

Dolby

Dolby®

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

MHEG software

The copyright in MHEG software (the Software) comprised in this television (this product) and included to enable you to use interactive television features is owned by S&T CLIENT SYSTEMS LIMITED (the Owner). You are permitted to use the Software only in conjunction with this product.

Kensington

Kensington and Micro Saver are registered US trademarks of ACCO World Corporation with issued registrations and pending applications in other countries throughout the world.

Other trademarks

All other registered and unregistered trademarks are the property of their respective owners.

Philips 40PFT6300/60, 48PFT6300/60, 55PFT6300/60 operating instructions

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Index
