Philips 32HFL3350D/10 leaflet

Download

Page 1

Philips Professional LCD TV

81 cm (32") Pro+

LCD integrated digital

32HFL3350D

More guest comfort

Philips Digital Hospitality LCD TV with clock

This modern Hospitality TV brings more guest convenience to the room and can allow guests to connect their own devices. Since it is HD ready and digital it prepares you for the future and can offer guests the latest digital services.

Advanced hotel features and future proof

• Welcome message on screen display

• Switch On Channel Programming

• HD Ready with integrated DVB-T tuner

Differentiating guest experience

• Volume limitation

• Integrated clock display with wake up and message alarm

• One combined channel list for Analog and Digital channels

• Easy to use Hospitality Remote Control

• Philips Connectivity Panel compatible to enjoy guest devices

Best total cost of ownership

• USB cloning of all settings for quick installation

• Set-top box compatible

Sustainable and safe

• Eco-friendly design & flame retardant housing

Page 2

Professional LCD TV

81 cm (32") Pro+ LCD, integrated digital

Highlights

32HFL3350D/10

Welcome message

A welcome greeting is displayed each time the TV set is swit

Switch On Channel Programming

Perfect for in-house advertising or information c

hannels as it allows to show a predefined

channel when the TV is turned on.

HD Ready with DVB-T tuner

Have guests enjoy the exceptional picture qu

ality of High Definition pictures and be fully prepared for HD sources like HDTV settop box. The TV is able to accept analog YPbPr signals, as well as the highest quality uncompressed Digital signals via DVI or HDMI. The Digital signals will support HDCP copy protection. With the integrated DVB-T tuner the TV can offer Digital Terrestrial TV channels, next to the existing analog channels. It also allows guests to listen to digital radio stations in high quality sound without the extra investment in radio receivers.

Integrated clock display

The built-in clock display, which is also a wakeup

alarm, eliminates the need and investment for an additional clock with cables and connections in the room.

ched on.

One combined channel list

One integrated channel list for digital and ana

logue channels. This allows the guest to zapp seemless between Analogue and Digital channels.

Hospitality Remote Control

This TV comes with a stylish remote control th

at is specially designed for hospitality usage. For an easy to use experience for the guest only the most essential buttons and functions are offered. In addition, low battery check and anti-theft battery provisions are features which can contribute to efficient hotel operations.

Volume limitation

This feature predefines the volume range with w

hich the TV set is allowed to operate, preventing excessive volume adjustments and avoiding disturbance of next door guests.

Connectivity Panel compatible

This TV work seamlessly with Philips Co

nnectivity Panels. The guest can easily connect and enjoy media from a PC, MP3 player, DVD player, camcorder and various other devices. With autosensing the Connectivity Panel and the TV will automatically switch to display the content from the connected guest device.

USB Cloning

Provides the ability to easily copy all p

rogramming and channel programming settings from one TV into other TV sets in less than a minute. The feature ensures uniformity between TV sets and significantly reduces installation time and costs.

Set-top box compatible

This hotel TV can be connected to a set-top b

ox offering power on scart and the Serial Express Lite protocol.

Eco-friendly design

Sustainability is integral to the way Philips does b

usiness. Philips TVs are designed and produced according to our EcoDesign principles aimed at minimizing overall environmental impact, through lower power consumption, removal of hazardous substances, lower weight, more efficient packaging and better recyclability. Philips TVs also have a special housing of flame retardant material. Independent tests carried out by emergency fire services have shown that whereas TVs can sometimes intensify fires caused by external sources, Philips TVs will not contribute to the fire.

Page 3

Professional LCD TV

81 cm (32") Pro+ LCD, integrated digital

Specifications

32HFL3350D/10

Picture/Display

• Diagonal screen size: 32 inch / 81 cm

• Aspect ratio: 16:9, Widescreen

• Display screen type: LCD WXGA Active Matrix TFT Panel resolution: 1366 x 768p

•

• Brightness: 500 cd/m²

• Contrast ratio (typical): 1200:1

• Dynamic screen contrast: 30000:1

• Response time (typical): 5 ms

• Viewing angle (H / V): 176 / 176 degree

• Screen enhancement: Anti-Reflection coated

• Picture enhancement: 3/2 - 2/2 motion pull down,

ombfilter, Active Control, Black stretch, Blue

3D C stretch, Color Enhancement, Digital Noise Reduction, Motion adaptive de-interlacing, Progressive scan, Automatic skin tone correction, Dynamic contrast enhancement, White stretch, Green stretch, Pixel Plus HD

•Color cabinet: Black

Supported Display Resolution

• Video formats Res

olution Refresh rate 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz 1080i 50, 60Hz 720p 50, 60Hz

mputer formats

• Co Resolution Ref 640 x 480 60Hz 800 x 600 60Hz 1024 x 768 60Hz 1280 x 1024 60Hz 1366 x 768 60Hz

resh rate

Tuner/Reception/Transmission

• Aerial Input: 75 ohm coaxial (IEC75)

• Number of Preset Channels: 250

• Tuner bands: Hyperband, S-Channel, UHF, VHF

•Tuner Display: PLL

• TV system: PAL I, PAL B/G, PAL D/K, SECAM B/G, SECAM D/K, SECAM L/L',

• Video Playback: PAL, SECAM, NTSC

• Digital TV: DVB Terrestrial *

DVB C

OFDM 2K/8K

Sound

• Output power (RMS): 2 x 15W

• Sound System: Mono, Stereo, Nicam Stereo, Dolby

l (AC-3), Virtual Dolby Digital, BBE

Digita

• Sound Enhancement: Auto Volume Leveller,

credible Surround, Smart Sound

• Equalizer: 5-bands

Loudspeakers

• Built-in speakers: 2

Connectivity

•Number of Scarts: 2

• Ext 1 Scart: Audio L/R, CVBS in/out, RGB

•Ext 2 Scart: Audio L/R

, CVBS in/out

• Ext 3: Audio L/R in, YPbPr

• Ext 4: HDMI v1.3

• Ext 5: HDMI v1.3

• Ext 6: HDMI v1.3

• Front / Side connections: Audio L/R in, CVBS in, Sdeo in, USB 2.0, HDMI v1.3

• Other connections: Analog audio Le

PDIF out (coaxial), Common Interface

• Connectivity Enhancements: Serial Xpress

Fast Infrared loop through, Power on

interface, scart, USB2.0

ft/Right out, S/

Convenience

• Ease of Installation: Advanced Hotel Mode, Fine

Tuning, PLL Digital Tuning, Program Name, Cloning of TV settings via USB, Installation menu locking, Security menu access, Keyboard lock-out

• Ease of Use: Auto Volume Leveller (AVL), 1

ann

el list analog/digital, Smart Picture, Smart

ch Sound

• Comfort: Hotel Guest features, Auto power on,

st startup, Welcome message, Message

F indicator, Switch on channel, Volume limitation

• Interactive hotel features: Connectivity panel

mpatible

• Prison mode: Teletext and MHEG disable

• Clock: Integrated LCD Clock Display, Sleep Timer,

• Clock Enhancements: Synchro Time via TXT/DVB

• Teletext: 1000 page Smart Text

• Electronic Program Guide: Now + Next EPG

• Screen Format Adjustments: 4:3, Full screen,

• Remote control type: 22AV1104/10 (RC6)

• Remote Control: low battery detection, battery

• Firmware upgradeable: Firmware upgradeable via

•

Clock

Wake u

and 1

Movie exp Widescreen, Subtitle Zoom, Super Zoom, Auto Format

ti-theft protection

USB Other convenience: Kensington lock

4:9, Movie expand 16:9,

Healthcare

• Control: Multi remote control, Pendant control via

IR-link

• Safety: Double isolation Class II

Multimedia Applications

• Multimedia connections: USB

• Playback Formats: MP3, JPEG Still pictures,

eshow files (.alb)

Slid

Green Specifications

• Safety: Flame retardant housing

Power

• Mains power: 100 - 240V, 50/60Hz

• Power consumption: 130 W

• Standby power consumption: < 1.2 W

• Ambient temperature: 5 °C to 40 °C

Dimensions

•Set dimensions (W x H x D): 819 x 518 x 92 mm

• Set dimensions with stand (W x H x D):

9 x 579 x 220 mm

•Box dimensions (W x H x D): x 629 x 255 mm

• Product weight: 13 kg

• Product weight (+stand): 16 kg

• Weight incl. Packaging: 19 kg

• VESA wall mount compatible: 200 x 300 mm

Accessories

• Included accessories: Remote Control, Batteries

for remote control, Power cord, Tabletop swivel stand, Warranty Leaflet

• Optional accessories: Set up Remote RC2573GR,

•

Wallmou

(tilt) 22AV3200/10

Issue date 2014-02-06

Version: 3.5.8

12 NC: 8670 000 42183 EAN: 87 12581 44258 3

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com

* For information on DVB-T enrolled countries please ask your Philips

contact.
