PHILIPS 246E7QDAB User Manual [fr]

246E7
276E7

www.philips.com/welcome

EN User manual 1
Customer care and warranty 16
Troubleshooting & FAQs 24

Table of Contents

1. Important ....................................... 1

1.1 Safety precautions and

maintenance .................................. 1

1.2 Notational Descriptions ............. 2

1.3 Disposal of product and packing

material ........................................... 3

2. Setting up the monitor ............... 4

2.1 Installation ..................................... 4

2.2 Operating the monitor ................6

2.3 MHL (Mobile High-Denition

Link) introduction ........................ 8

3. Image Optimization .................... 9

3.1 SmartImage Lite ........................... 9

3.2 SmartContrast ..............................10

4. Technical Specications ............11

4.1 Resolution & Preset Modes .....14

5. Power Management ..................15

6. Customer care and warranty ...16

6.1 Philips’ Flat Panel Monitors

Pixel Defect Policy ......................16

6.2 Customer Care & Warranty .......19

7. Troubleshooting & FAQs .......... 24

7.1 Troubleshooting .........................24

7.2 General FAQs ..............................26

7.3 MHL FAQs ....................................28

1. Important

1. Important

This electronic user’s guide is intended
for anyone who uses the Philips
monitor. Take time to read this user's
manual before you use your monitor.
It contains important information and
notes regarding the operation of your
monitor.

The Philips guarantee applies provided
the product is handled properly for
its intended use, in accordance with
its operating instructions and upon
presentation of the original invoice
or cash receipt, indicating the date of
purchase, dealer’s name and model and
production number of the product.

1.1 Safety precautions and maintenance

Warnings

Use of controls, adjustments or
procedures other than those specified
in this documentation may result in
exposure to shock, electrical hazards
and/or mechanical hazards.

Read and follow these instructions
when connecting and using your
computer monitor.

Operation

• Please Keep the monitor out of

direct sunlight, very strong bright
lights and away from any other heat
source. Lengthy exposure to this
type of environment may result in
discoloration and damage to the
monitor.

• Remove any object that could fall

into ventilation holes or prevent
proper cooling of the monitor’s
electronics.

• Do not block the ventilation holes

on the cabinet.

• When positioning the monitor, make
sure the power plug and outlet are
easily accessible.

• If turning o the monitor by detach­ing the power cable or DC power
cord, wait for 6 seconds before
attaching the power cable or DC
power cord for normal operation.

• Please use approved power cord
provided by Philips at all times. If
your power cord is missing, please
contact your local service center.
(Please refer to Customer Care Con­sumer Information Center)

• Do not subject the monitor to se­vere vibration or high impact condi­tions during operation.

• Do not knock or drop the monitor
during operation or transportation.

Maintenance

• To protect your monitor from pos­sible damage, do not put excessive
pressure on the LCD panel. When
moving your monitor, grasp the
frame to lift; do not lift the monitor
by placing your hand or ngers on
the LCD panel.

• Unplug the monitor if you are not
going to use it for an extensive pe­riod of time.

• Unplug the monitor if you need to
clean it with a slightly damp cloth.
The screen may be wiped with a
dry cloth when the power is o.
However, never use organic solvent,
such as, alcohol, or ammonia-based
liquids to clean your monitor.

• To avoid the risk of shock or perma­nent damage to the set, do not ex­pose the monitor to dust, rain, water,
or excessive moisture environment.

• If your monitor gets wet, wipe it with
dry cloth as soon as possible.

• If foreign substance or water gets in
your monitor, please turn the power

1

1. Important

o immediately and disconnect the
power cord. Then, remove the for­eign substance or water, and send it
to the maintenance center.

• Do not store or use the monitor in
locations exposed to heat, direct
sunlight or extreme cold.

• In order to maintain the best per­formance of your monitor and use
it for a longer lifetime, please use
the monitor in a location that falls
within the following temperature
and humidity ranges.

• Temperature: 0-40°C 32-104°F

• Humidity: 20-80% RH

• IMPORTANT: Always activate a mov-

ing screen saver program when you
leave your monitor unattended.
Always activate a periodic screen
refresh application if your monitor
will display unchanging static con­tent. Uninterrupted display of still
or static images over an extended
period may cause “burn in”, also
known as “after-imaging” or “ghost
imaging”, on your screen.

• "Burn-in", "after-imaging", or "ghost
imaging" is a well-known phenom­enon in LCD panel technology.
In most cases, the “burned in” or
“after-imaging” or “ghost imag­ing” will disappear gradually over a
period of time after the power has
been switched o.

Warning

Failure to activate a screen saver, or
a periodic screen refresh application
may result in severe “burn-in” or “after­image” or “ghost image” symptoms
that will not disappear and cannot be
repaired. The damage mentioned above
is not covered under your warranty.

Service

• The casing cover should be opened
only by qualied service personnel.

• If there is any need for any docu­ment for repair or integration,
please contact with your local
service center. (please refer to the
chapter of "Consumer Information
Center")

• For transportation information,
please refer to "Technical Specica­tions".

• Do not leave your monitor in a car/
trunk under direct sun light.

Note

Consult a service technician if the
monitor does not operate normally, or
you are not sure what procedure to take
when the operating instructions given in
this manual have been followed.

1.2 Notational Descriptions

The following subsections describe
notational conventions used in this
document.

Notes, Cautions and Warnings

Throughout this guide, blocks of text
may be accompanied by an icon and
printed in bold or italic type. These
blocks contain notes, cautions or
warnings. They are used as follows:

Note

This icon indicates important
information and tips that help you make
better use of your computer system.

Caution

This icon indicates information that
tells you how to avoid either potential
damage to hardware or loss of data.

2

1. Important

Warning

This icon indicates the potential for
bodily harm and tells you how to avoid
the problem.

Some warnings may appear in alternate
formats and may not be accompanied
by an icon. In such cases, the specific
presentation of the warning is mandated
by the relevant regulatory authority.

1.3 Disposal of product and packing material

Waste Electrical and Electronic
Equipment-WEEE

This marking on the product or on
its packaging illustrates that, under
European Directive 2012/19/EU
governing used electrical and electronic
appliances, this product may not be
disposed of with normal household
waste. You are responsible for disposal
of this equipment through a designated
waste electrical and electronic
equipment collection. To determine the
locations for dropping off such waste
electrical and electronic, contact your
local government office, the waste
disposal organization that serves your
household or the store at which you
purchased the product.

Your new monitor contains materials
that can be recycled and reused.
Specialized companies can recycle
your product to increase the amount of
reusable materials and to minimize the
amount to be disposed of.

All redundant packing material has been
omitted. We have done our utmost to
make the packaging easily separable
into mono materials.

Please find out about the local
regulations on how to dispose of your
old monitor and packing from your sales
representative.

Taking back/Recycling Information for
Customers

Philips establishes technically and
economically viable objectives
to optimize the environmental
performance of the organization's
product, service and activities.

From the planning, design and
production stages, Philips emphasizes
the important of making products that
can easily be recycled. At Philips,
end-of-life management primarily
entails participation in national take­back initiatives and recycling programs
whenever possible, preferably
in cooperation with competitors,
which recycle all materials (products
and related packaging material) in
accordance with all Environmental
Laws and taking back program with the
contractor company.

Your display is manufactured with high
quality materials and components
which can be recycled and reused.

To learn more about our recycling
program please visit

http://www.philips.com/a-w/about/
sustainability.html

3

2. Setting up the monitor

2. Setting up the monitor

2.1 Installation

Package contents

* AC/DC Adapter * VGA

* DVI * HDMI

Install base stand

1. Place the monitor face down on soft
and smooth surface taking care to
avoid scratching or damaging the
screen.

246E7

2. Hold the base stand with both
hands and firmly insert the base

Monitor

使用

前请阅读使用说明

©

2

User’s Manual

0

1

5

SmartControl software

K

保留备用

o

n

i

n

k

l

i

j

k

e

P

h

i

l

i

p

s

N

.

V

.

A

l

l

r

i

g

h

t

s

n

r

o

i

e

s

s

r

e

e

Philips and the Philips’ Shield Emblem are registered trademarks of

r

V

v

.

e

Koninklijke Philips N.V. and are used under license from Koninklijke

a

d

n

.

i

Philips N.V.

U

h

n

C

a

n

u

i

t

h

d

o

e

t

r

n

i

i

z

r

e

p

d

d

d

n

u

a

p

l

e

i

c

d

a

a

t

i

o

M

.

n

s

i

w

s

a

l

a

e

v

l

i

o

b

a

l

a

c

i

t

l

i

o

p

n

p

a

o

f

*CD

stand into the base column.

(1) Gently attach the base to the base

column until the latch locks the
base.

(2) Use your fingers to tighten the

screw located at the bottom of
the base, and secure the base to
the column tightly.

2

* Audio Cable

* Different according to region.

Note

246E7Q/246E7QD/246E7QDA/276E7Q:
Use only the AC/DC adapter model:
Philips ADPC1936.

276E7QD/276E7QDA:Use only the AC/
DC adapter model: Philips ADPC1945.

1

4

2. Setting up the monitor

1

2

1

2

3

4

3

1

123

3

2

465

4

5

1

1

3

42576

4

5

6

2

3

Connecting to your PC

246E7Q/276E7Q:

1

AC/DC power input

2

VGA input

3

DVI input

4

Kensington anti-theft lock

246E7QD/276E7QD

1

AC/DC power input

2

HDMI Audio out

3

VGA input

4

DVI input

5

MHL-HDMI input

6

Kensington anti-theft lock

：

246E7QDA/276E7QDA

1

AC/DC power input

2

Earphone jack

3

Audio input

4

VGA input

5

DVI input

6

MHL-HDMI input

7

Kensington anti-theft lock

Connect to PC

1. Connect the power cord to the back
of the monitor firmly.

2. Turn off your computer and unplug
its power cable.

3. Connect the monitor signal cable to
the video connector on the back of
your computer.

4. Plug the power cord of your
computer and your monitor into a
nearby outlet.

5. Turn on your computer and monitor.
If the monitor displays an image,
installation is complete.

：

5

2. Setting up the monitor

2.2 Operating the monitor









 













Front view product description

Description of the On Screen Display

What is On-Screen Display (OSD)?

On-Screen Display (OSD) is a feature in
all Philips LCD monitors. It allows an end
user to adjust screen performance or
select functions of the monitors directly
through an on-screen instruction
window. A user friendly on screen
display interface is shown as below:

246E7Q/276E7Q:





Press more than 3 seconds
to switch display power ON
or OFF.

Access the OSD menu.
Confirm the OSD
adjustment.

246E7Q/276E7Q: Change
display format.
246E7QD/246E7QDA/
276E7QD/276E7QDA:
Adjust the speaker volume.

Adjust the OSD menu.

Change the signal input
source.

Adjust the OSD menu.
SmartImage Lite. There are

three
modes to be selected:
Standard,
Internet and Game.

Return to previous OSD
level.

246E7QD/246E7QDA/
276E7QD/276E7QDA:





Basic and simple instruction on the
control keys

To access the OSD menu on this Philips
Display simply use the single toggle
button on the backside of the Display
bezel. The single button operates like
a joystick. To move the cursor, simply
toggle the button in four directions.
Press the button to select desired
option.

6

2. Setting up the monitor

Main menu Sub menu


OSD Settings

Setup

Language

Color

Audio

(available for
selective models)

Input

Picture Format

Brightness

Contrast

Horizontal

Vertical

Transparency

OSD Time Out

H.Position

Auto

V.Position

Phase

Clock

Resolution
Notication

Reset

Information

English, Deutsch, Español, Ελληνική, Français,
Italiano, Maryar，Nederlands, Português,
Português do Brasil，Polski，Русский ,Svenska，
Suomi，Türkçe，Čeština，Українська, 简体中文,

繁體中文，日本語，한국어

Color Temperature

sRGB

User Dene

Adobe RGB

Mute

VGA

DVI

MHL-HDMI (available for selective models)

SmartResponse

SmartContrast

Gamma

Over Scan
(available for selective models)

Sharpness
(available for selective models)

Pixel Orbiting

Volume

Wide Screen, 4:3

0~100

0~100
0~100

0~100

0~100

O, 1, 2, 3, 4

5s, 10s, 20s, 30s, 60s

0~100

On, O

Yes, No

0~100

0~100

0~100

6500K, 9300K

Red: 0~100

0~100

Green: 0~100

Blue: 0~100

O, Fast, Faster, Fastest

On, O

1.8, 2.0, 2.2, 2.4, 2.6

On, O

On, O

On, O

Audio

(available for
selective models)

Stand-Alone

Volume

0~100

On, O

Mute

On, O

Audio Source

Audio In, MHL-HDMI

The OSD Menu

Below is an overall view of the structure
of the On-Screen Display. You can use
this as a reference when you want to
work your way around the different
adjustments later on.

Resolution notification

This monitor is designed for optimal
performance at its native resolution,
1920×1080@60Hz. When the monitor
is powered on at a different resolution,
an alert is displayed on screen: Use
1920×1080@60Hz for best results.

Display of the native resolution alert can
be switched off from Setup in the OSD
(On Screen Display) menu.

Physical Function

Tilt

20°

-5°

7

2. Setting up the monitor

MHL

2.3 MHL (Mobile High-Deni­tion Link) introduction

(246E7QD/246E7QDA/
276E7QD/276E7QDA)

What is it?

Mobile High Definition Link (MHL) is
a mobile audio/video interface for
directly connecting mobile phones
and other portable devices to high­definition displays.

An optional MHL cable allows you
to simply connect your MHL capable
mobile device to this large Philips MHL
display, and watch your HD videos
come to life with full digital sound.
Now not only you can enjoy your
mobile games, photos, movies, or
other apps on its big screen, you can
simultaneously charge your mobile
device so you never run out of power
half way.

How do I use the MHL function?

To use the MHL function, you need an
MHL-Certified mobile device. To find
a list of MHL-certified devices, visit
the official MHL website (http://www.
mhlconsortium.org)

You also need a optional MHL certified
special cable in order to use this
function.

How does it work? (how do I

connect?)

Connect the Optional MHL cable to the
mini USB port on the mobile device
side, and the [MHL-HDMI] marked
port on the monitor side. You are now
ready to view the images on your big
screen display and operate all function
on you the mobile device such as
internet surfing, game playing, photo
browsing…etc. if your monitor has
speaker function, then you will be able
to hear accompanying sound too. When
the MHL cable is disconnected or the

mobile device is turned off, the MHL
function will be automatically disabled.

Note

• The port marked [MHL-HDMI] is the
only port on the monitor that sup­ports the MHL function when the
MHL cable is used. Note that the
MHL certied cable is dierent than
a standard HDMI cable.

• A mobile device with MHL certica­tion must be purchased separately

• You may have to manually switch
the monitor to MHL-HDMI mode in
order to activate the monitor, if you
have other devices already working
and connected to available inputs

• Standby/O energy saving of ErP is
not applicable for the MHL charging
functionality

• This Philips display is MHL certied.
However, in case your MHL device
does not connect or work correctly,
check with your MHL device FAQ
or vendor directly for direction. The
policy of your device manufacturer
may require you to purchase their
brand specic MHL cable or adapter
in order to work.

8
