Philips 223S7, 243S7 User Manual

S line

S230S8line

223S7/243S7

www.philips.com/welcome
EN User manual	1
Customer care and warranty 22
Troubleshooting & FAQs	26

Table of Contents

1. Important  1

1.1Safety precautions and

maintenance  1 1.2 Notational Descriptions  3 1.3 Disposal of product and packing material  4

2. Setting up the monitor  5

2.1 Installation  5

2.2 Operating the monitor  7

2.3 Remove the Base Assembly for VESA Mounting  10

2.4 SoftBlue Technology introduction  11

3. Image Optimization  12

3.1 SmartImage  12

3.2 SmartContrast  13

4. Technical Specifications  14

4.1 Resolution & Preset Modes  19

5. Power Management  20

6.Customer care and warranty  22

6.1 Philips’ Flat Panel Monitors

Pixel Defect Policy  22

6.2 Customer Care & Warranty  25

7. Troubleshooting & FAQs  26

7.1 Troubleshooting  26

7.2 General FAQs  28

1. Important

1. Important

This electronic user’s guide is intended for anyone who uses the Philips monitor. Take time to read this user manual before you use your monitor. It contains important information and

notes regarding operating your monitor.

The Philips guarantee applies provided the product is handled properly for

its intended use, in accordance with its operating instructions and upon presentation of the original invoice or cash receipt, indicating the date of purchase, dealer’s name and model

and production number of the product.

1.1Safety precautions and maintenance

Warnings

Use of controls, adjustments or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor.

Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the

equalizer to maximum increases the earphones and headphones output voltage and therefore the sound

pressure level.

Operation

•Please Keep the monitor out of direct sunlight, very strong bright lights and away from any other heat source. Lengthy exposure to this type of environment may result in discoloration and damage to the monitor.

•Remove any object that could fall into ventilation holes or prevent proper cooling of the monitor’s electronics.

•Do not block the ventilation holes on the cabinet.

•When positioning the monitor, make sure the power plug and outlet are easily accessible.

•If turning off the monitor by detaching the power cable or DC power cord, wait for 6 seconds before attaching the power cable or DC power cord for normal operation.

•Please use approved power cord provided by Philips all the time. If your power cord is missing, please contact with your local service center. (Please refer to Customer Care Consumer Information Center)

•Do not subject the monitor to severe vibration or high impact conditions during operation.

•Do not knock or drop the monitor during operation or transportation.

•Excessive usage of monitor can cause eye discomfort, it’s better to take shorter breaks more often at your workstation than longer breaks and less often; for example a 5-10 minute break after 50-60-minute continuous screen use is likely to be better than a 15-minute break every two hours. Try to keep your eyes from eye strain while using the screen for a constant period of time by :

•Looking at something varying distances after a long period focusing on the screen.

•Conscious Blinking often while you work.

•Gently closing and rolling your eyes to relax.

1

1.Important

•Reposition your screen to appropriate height and angle according to your height.

•Adjusting the brightness and contrast to appropriate level.

•Adjusting the environment lighting similar to that of your screen brightness, avoid the fluorescent lighting, and surfaces that don't reflect too much light.

•Seeing a doctor if your symptoms.

Maintenance

•To protect your monitor from possible damage, do not put excessive pressure on the LCD panel. When moving your monitor, grasp the frame to lift; do not lift the monitor by placing your hand or fingers on the LCD panel.

•Unplug the monitor if you are not going to use it for an extensive period of time.

•Unplug the monitor if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power is off. However, never use organic solvent, such as, alcohol, or ammonia-based liquids to clean your monitor.

•To avoid the risk of shock or permanent damage to the set, do not expose the monitor to dust, rain, water, or excessive moisture environment.

•If your monitor gets wet, wipe it with dry cloth as soon as possible.

•If foreign substance or water gets in your monitor, please turn the power off immediately and disconnect

the power cord. Then, remove the foreign substance or water, and send it to the maintenance center.

•Do not store or use the monitor in locations exposed to heat, direct sunlight or extreme cold.

•In order to maintain the best performance of your monitor and use it for a longer lifetime, please use the monitor in a location that falls within the following temperature and humidity ranges.

•Temperature: 0-40°C 32-104°F

•Humidity: 20-80% RH

Important information for Burn-in/ Ghost image

•Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your monitor will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging” or “ghost imaging”, on your screen.

•“Burn-in”, “after-imaging”, or “ghost imaging” is a well-known phenomenon in LCD panel technology. In most cases, the “burned in” or “after-imaging” or “ghost imaging” will disappear gradually over a period of time after the power has been switched off.

Warning

Failure to activate a screen saver, or a periodic screen refresh application

may result in severe “burn-in” or “afterimage” or “ghost image” symptoms that will not disappear and cannot be repaired. The damage mentioned above is not covered under your warranty.

2

1. Important

Service

•The casing cover should be opened only by qualified service personnel.

•If there is any need for any document for repair or integration, please contact with your local service center. (please refer to the chapter of “Consumer Information Center”)

•For transportation information, please refer to “Technical Specifications”.

•Do not leave your monitor in a car/ trunk under direct sun light.

Note

Consult a service technician if the monitor does not operate normally, or you are not sure what procedure to take when the operating instructions given in this manual have been followed.

1.2 Notational Descriptions

The following subsections describe notational conventions used in this document.

Notes, Cautions and Warnings

Throughout this guide, blocks of text may be accompanied by an icon and printed in bold or italic type. These blocks contain notes, cautions or warnings. They are used as follows:

Note

This icon indicates important information and tips that help you make better use of your computer system.

Caution

This icon indicates information that tells you how to avoid either potential damage to hardware or loss of data.

Warning

This icon indicates the potential for bodily harm and tells you how to avoid the problem.

Some warnings may appear in alternate formats and may not be accompanied by an icon. In such cases, the specific presentation of the warning is mandated by the relevant regulatory authority.

3

1. Important

1.3Disposal of product and packing material

Waste Electrical and Electronic

Equipment-WEEE

This marking on the product or on its packaging illustrates that, under European Directive 2012/19/EU

governing used electrical and electronic appliances, this product may not be disposed of with normal household waste. You are responsible for disposal of this equipment through a designated waste electrical and electronic equipment collection. To determine the locations for dropping off such waste electrical and electronic, contact your local government office, the waste disposal organization that serves your household or the store at which you purchased the product.

Your new monitor contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of.

All redundant packing material has been omitted. We have done our utmost to make the packaging easily separable into mono materials.

Please find out about the local regulations on how to dispose of your old monitor and packing from your sales representative.

Taking back/Recycling Information for Customers

Philips establishes technically and economically viable objectives

to optimize the environmental performance of the organization's product, service and activities.

From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end- of-life management primarily entails participation in national take-back initiatives and recycling programs whenever possible, preferably

in cooperation with competitors, which recycle all materials (products and related packaging material) in accordance with all Environmental Laws and taking back program with the contractor company.

Your display is manufactured with high quality materials and components which can be recycled and reused.

To learn more about our recycling program please visit

http://www.philips.com/a-w/about/ sustainability.html

4

2. Setting up the monitor

2. Setting up the monitor

2.1 Installation

Package contents

Install the base

1.Place the monitor face down on a smooth surface. Pay attention not to scratch or damage the screen.

S line

S lineS line

Quick

Start

Register your product and get support at

www.philips.com/welcome

	Monitor
	User’s Manual
	* CD
Power	* VGA
* DP	* HDMI
(2X3S7EYMB,	(2X3S7EHMB,
2X3S7EJMB)	2X3S7EJMB)
*Audio	* USB
	( 2X3S7EJMB)

*Different according to region

2.Hold the stand with both hands.

(1)Gently attach the stand to the VESA mount area.

(2)Use a screwdriver to tighten the assembly screws, and secure the stand to the monitor tightly.

(3)Gently attach the base to the stand.

(4)Use your fingers to tighten the screw located at the bottom of the base, and secure the base to the stand tightly.

2

1

4 3

5

2. Setting up the monitor

	Connecting to your PC	223S7EJMB

2X3S7EHMB
					9
6	5	4	3	2
				1	4
					5
					3

1

2

1 Kensington anti-theft lock

2Earphone jack

3Audio input

4VGA input

5HDMI input

6AC power input

2X3S7EYMB
6	5	4	3	2
				1	4
					5
					3

8	6	5	4	3	2
	7

1 Kensington anti-theft lock

2Earphone jack

3Audio input

4VGA input

5HDMI input

6DisplayPort input

7USB downstream

8USB upstream

9AC power input

2

1 Kensington anti-theft lock

2Earphone jack

3Audio input

4VGA input

5DisplayPort input

6AC power input

6

2. Setting up the monitor

243S7EJMB

9

1

8	7	6	5	4	3	2

1 Kensington anti-theft lock

2Earphone jack

3Audio input

4VGA input

5HDMI input

6DisplayPort input

7USB upstream

8USB downstream

9AC power input

Connect to PC

1.Connect the power cord to the back of the monitor firmly.

2.Turn off your computer and unplug its power cable.

3.Connect the monitor signal cable to the video connector on the back of your computer.

4.Plug the power cord of your computer and your monitor into a nearby outlet.

5.Turn on your computer and monitor. If the monitor displays an image, installation is complete.

2.2 Operating the monitor

Description of the control buttons

3

7

6

5

4

2

1

Switch monitor’s power

ON and OFF.

Access the OSD menu. Confirm the OSD

adjustment.

Adjust the OSD menu.

Adjust the speaker volume.

Change the signal input source.

Return to previous OSD level.

SmartImage. There are multiple selections: EasyRead, Office, Photo, Movie, Game, Economy, LowBlue Mode and Off.

7

2. Setting up the monitor

Description of the On Screen Display

What is On-Screen Display (OSD)?

On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. A user friendly on screen display interface is shown as below:

Basic and simple instruction on the control keys

In the OSD shown above, you can press buttons at the front bezel of the monitor to move the cursor, and press

OK button to confirm the choice or change.

The OSD Menu

Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on.

Main menu			Sub menu
		LowBlue Mode				On		1, 2, 3
						Off
		Input				VGA
						HDMI (2X3S7EHMB)
						HDMI 1.4 (2X3S7EJMB)
						DisplayPort (2X3S7EYMB, 2X3S7EJMB)


Audio

Color

Language

OSD Settings

Setup

Picture Format				Wide Screen, 4:3
Brightness		0~100
Contrast		0~100
Sharpness		0~100
SmartResponse				Off, Fast, Faster, Fastest
SmartContrast				On, Off
Gamma		1.8, 2.0, 2.2, 2.4, 2.6
Pixel Orbiting				On, Off
Over Scan				On, Off
Volume				0~100
Stand-Alone				On, Off
Mute				On, Off
Audio Source				Audio In,
				HDMI (2X3S7EHMB,
				2X3S7EJMB)
				DisplayPort (2X3S7EYMB,
				2X3S7EJMB)
Color Temperature				Default (2X3S7EYMB,
sRGB				2X3S7EHMB),
				Native (2X3S7EJMB),
				5000K, 6500K, 7500K,
				8200K, 9300K, 11500K
User Define				Red: 0~100
				Green: 0~100
				Blue: 0~100

English, Deutsch, Español, Ελληνική, Français, Italiano, Maryar Nederlands, Português, Português do Brasil Polski ,Svenska Suomi Türkçe Čeština Українська, ,

Horizontal								0~100
Vertical						0~100
Transparency									Off, 1, 2, 3, 4
OSD Time Out									5s, 10s, 20s, 30s, 60s
Auto
H.Position								0~100
V.Position									0~100
Phase							0~100
Clock							0~100
Resolution Notification									On, Off
Reset									Yes, No

Information

8
