Philips 14PT2321 User Manual
14" COLOUR TELEVISION
14PT2381 /14PT2321
SMART PICTURE
CONTROLS
BIMOS
IMPROVEMENT
CIRCUITRY
SMART SOUND
CONTROLS J
13 + I
PERSONAL
PREFERENCES
WAKE-UP
TIMER
SMART PICTURE CONTROLS (Four Picture Settings)
Four picture sellings give you the best possibte pictures lor every type of programme or room iighting conditions
RICH - Dramatic, vivid picture in bright ambient light
NATURAL - Natural colours under normal ambient conditions
SOFT - Warm coiours under low light ambient conditions
PERSONAL - Own personal preference settings
POWER CHIP (BIMOS Picture Improvement Circuitry)
PHILIPS Power Chip provides you with improved picture quality.
Namely better contrast, better colour transient, belter colour reproduction and optimum sharpness.
SMART SOUND CONTROLS (Four sound settings)
Four sound settings give you crisper audio performance which caters (or different consumer sound preferences
THEATRE - For dramatic movies or Iheatre performances (Bass and Treble Boosted)
MUSIC - For music programmes (Bass Boosted)
VOICE - For news and speech programmes (Treble Boosted)
NORMAL - For programme sound without additional boosting
13 PERSONAL PREFERENCE (RF) and 1 PERSONAL PREFERENCE (AV)
This feature allows you to select & programme picture setting and sound volume level combination that soils you on
(3 different RF channels and 1 AV channel (if applicable). This will allow you to cater to the different transmission
signal conditions of different broadcasting stations. Once you have programmed your settings, SMART TV never forgets.
N
WAKE-UP TIMER
Your new alarm clock feature that can be used lor wake-up calls. You can also use this feature to remember the
programme that you would like to watch. No more missed programmes.
80
PR£
SELECTIONS
$& HTPEREAND
TUNER
CURSOR^
•
MENU “
’ For specific models and versions only
PROCKAMMABlE
HOTEL
MODE
SHARPNESS
CONTROL
6 WATTS
MPO
SOUND
OUTPUT
Philips Sound & Vision
¿e/i Kute ffw№ ireffeY
PHILIPS
FEATURES & SPECIFICATIONS
Black Matrix Square Tube
Dark Glass Screen
Sharpness Control
BIMOS Picture Improvement Circuitry
SMART PICTURE Controls
SOUND
6 Watts MPO Sound Output
Full Range Speaker
SMART SOUND Controls
CONNECTION
Front AudioA/ideo Input *(1)
Rear AudioA/ideo Input *(1)
Rear AudioA/ideo Output I TV Out I
Headphone Socket
OPERATION
TELETEXT
Full Remote Control
80 Pre-selection
Last Viewed Status
Full Menu Operation
Time Window Programme Selection
13 Personal Preference (RF)
1 Personal Preference for AV
Auto Search and Store
SWAP Function
Skip Programme
Fine Tune +/Manual Search
Auto SCAN
Sleeptimer
Wake-up Timer
Auto Switch-Off
Programme Hotel Mode
SMART Picture & Sound Controls
First Time Set-up ‘(2)
MISCELLANEOUS
Ambient Temperature
Power Consumption
- Normal Operation
- Standby
Net Weight
Gross Weight
Dimension (W x H x D)
- Set dimension
- Box dimension
Container Loading (per 40 ft, loose)
14PT2381
Min
38W
8W
9kg
11kg
392 X 340
468
700 sets
5°C.
X 421
14PT2321
Max 45 °C
38W
8W
9kg
11kg
X 379mm
X 455mm
700 sets
Note:- ’(1) 1 Video input with (2) terminals
Note:- '(2) First Time Set-up is not applicable for some versions e.g. /75
80
PRE
SELECTIONS
PHOCRAMMASLE
HOTEL
MODE
Data subject to change without notice.
S a HYPERBAND
TUNER
SHARPNESS
CONTROL
CURSORI
◄
MENU ^
6 WATTS
MPO
SOUND
OLneuT
AUTO SEARCH
AUTO STORE
ft
HEADPHONE
AUTO
SWITCH
SLEEPTIMER
(O oT
[o o)
REARA/V
,^INPUT/ OUTPLfT^
OFF
TELETEXT
PHILIPS
WAKE-UP
TIMER
HANDLE
