Pentax S1 User Manual [ru]

Digital Camera

Operating Manual

To ensure the best performance from your camera, please read the Operating Manual before using the camera.

ENG

Thank you for purchasing this PENTAX Digital Camera. Please read this manual before using the camera in order to get the most out of all the features and functions. Keep this manual safe, as it can be a valuable tool in helping you to understand all the camera’s capabilities.

Regarding copyrights

Images taken with the PENTAX Digital Camera that are for anything other than personal enjoyment cannot be used without permission according to the rights as specified in the Copyright Act. Please take care, as there are cases where limitations are placed on taking pictures even for personal enjoyment during demonstrations, performances or of items on display. Images taken with the purpose of obtaining copyrights also cannot be used outside the scope of use of the copyright as laid out in the Copyright Act, and care should be taken here also.

Regarding trademarks

• PENTAX and Optio are trademarks of HOYA CORPORATION.

• SDXC Logo is a trademark of SD-3C, LLC.

• ArcS oft, and its logo are either the registered trademark or trademark of ArcSoft Inc. in the United States and/or other countries.

• Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and other countries. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

• Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.

• All other brands or product names are trademarks or registered trademarks of their respective companies. In this manual, the ™ and ® marks are not specified.

• This product supports PRINT Image Matching III. PRINT Image Matching enabled digital still cameras, printers and software help photographers to produce images more faithful to their intentions. Some functions are not available on printers that are not PRINT Image Matching III compliant. Copyright 2001 Seiko Epson Corporation. All Rights Reserved. PRINT Image Matching is a trademark of Seiko Epson Corporation. The PRINT Image Matching logo is a trademark of Seiko Epson Corporation.

Regarding Product Registration

In order to better serve you, we request that you complete the product registration, which can be found on the CD-ROM supplied with the camera or the PENTAX website. Thank you for your cooperation. Refer to “Connecting to a Computer” (p.181) for more information.

To users of this camera

• Do not use or store this device in the vicinity of equipment that generates strong electromagnetic radiation or magnetic fields. Strong static charges or the magnetic fields produced by equipment such as radio transmitters could interfere with the monitor, damage the stored data, or affect the product’s internal circuitry and cause camera misoperation.

• The liquid crystal panel used for the display is manufactured using extremely high precision technology. Although the level of functioning pixels is 99.99% or better, you should be aware that 0.01% or fewer of the pixels may not illuminate or may illuminate when they should not. However, this has no effect on the recorded image.

• If you point the camera toward an object that is bright, a band of light may appear on the screen display. This phenomenon is referred to as “smear” and is not a malfunction of the camera.

• There is a possibility that the illustrations and the screen display in this manual are different from the actual ones.

• In this manual, SD Memory Cards, SDHC Memory Cards, and SDXC Memory Cards are referred to as SD Memory Cards hereafter.

• In this manual, the generic term “computer(s)” refers to either a Windows PC or a Macintosh hereafter.

• In this manual, the term “battery(ies)” refers to any type of batteries used for this camera and its accessories.

Using Your Camera Safely

We have paid close attention to the safety of this product. When using this product, we request your special attention regarding items marked with the following symbols.

Warning

Caution

This symbol indicates that violating this item could cause serious personal injuries.

This symbol indicates that violating this item could cause minor or medium personal injuries, or loss of property.

About the Camera

Warning

• Do not disassemble or modify the camera. High voltage areas are present inside the camera, with the risk of electric shock.

• If the camera interior is exposed due to dropping or otherwise damaging the camera, never touch the exposed portion. There is a risk of electric shock.

• Wrapping the strap around your neck is dangerous. Take care that small children do not hang the strap around their necks.

• If any irregularities occur during use, such as smoke or a strange odor, stop use immediately, remove the battery, and contact your nearest PENTAX Service Center. Continuing to use the camera can cause a fire or electric shock.

Caution

• Do not place your finger over the flash when discharging the flash. You may burn yourself.

• Do not cover the flash with clothes when discharging the flash. Discoloration may occur.

• Some portions of the camera heat up during use. There is a risk of low temperature burns when holding such portions for long periods.

• Should the monitor be damaged, be careful of glass fragments. Also, be careful not to allow the liquid crystal to get on your skin, in your eyes or mouth.

• Depending on your individual factors or physical condition, the use of the camera may cause itching, rashes or blisters. In case of any abnormality, stop using the camera and get medical attention immediately.

About the Power Adapter

Warning

• Always use the power adapter exclusively developed for this camera, with the specified power and voltage. Using a power adapter not exclusive to this camera, or using the exclusive power adapter with an unspecified power or voltage can cause a fire, electric shock, or camera breakdown. The specified voltage is 100 - 240V AC.

• Do not disassemble or modify the power adapter. This can cause a fire or electric shock.

• If the generation of smoke or strange odor from the power adapter or other abnormality occurs, immediately discontinue use and consult a PENTAX Service Center. Continuing to use the adapter can cause a fire or electric shock.

• If water should happen to get inside the power adapter, consult a PENTAX Service Center. Continuing to use the adapter can cause a fire or electric shock.

• If a thunder storm should occur while using the power adapter, unplug the adapter and discontinue use. Continuing to use the adapter can cause damage to the equipment, fire, or electric shock.

• Wipe off the plug of the power adapter if it becomes covered with dust. Accumulated dust on the plug may cause a fire.

Caution

• Do not place or drop heavy objects on the power adapter. Doing so may damage the adapter. Should the power adapter be damaged, consult a PENTAX Service Center.

• Do not touch or short-circuit the terminal area of the power adapter while the cord is plugged in.

• Do not handle the power adapter with wet hands. This can cause an electric shock.

• Do not drop the power adapter, or subject it to violent impact. This can cause equipment breakdown.

• Do not use the power adapter to charge a battery other than a rechargeable lithium-ion battery D-LI78. This can cause an explosion, or heating, or may damage the power adapter.

About the Battery

Warning

• Be sure to store the battery out of the reach of small children. Placing it in their mouths may cause an electric shock.

• If any leakage from the battery should come in contact with your eyes, do not rub them. Flush your eyes with clean water and get medical attention immediately.

Caution

• Only use the specified battery with this camera. Use of other batteries may cause an explosion or fire.

• Do not disassemble the battery. Disassembling the battery may cause an explosion or leakage.

• Remove the battery from the camera immediately if it becomes hot or begins to smoke. Be careful not to burn yourself during removal.

• Keep wires, hairpins, and other metal objects away from the + and contacts of the battery.

• Do not short the battery or dispose of the battery in fire. This can cause an explosion or fire.

• If any leakage from the battery should come in contact with skin or clothes, wash the affected areas thoroughly with water.

• Precautions for D-LI78 Battery Usage:

- USE SPECIFIED CHARGER ONLY.

- DO NOT INCINERATE.

- DO NOT DISASSEMBLE.

- DO NOT SHORT CIRCUIT.

- DO NOT EXPOSE TO HIGH TEMP. (140°F / 60°C)

Keep the Camera and its Accessories out of the Reach of Small Children

Warning

• Do not place the camera and its accessories within the reach of small children.

1. If the product falls or is operated accidentally it may cause serious

personal injuries.

2. Wrapping the strap around a neck may cause suffocation.

3. To avoid the risk of a small accessory such as the battery or SD Memory

Cards from being swallowed by mistake, keep them out of the reach of small children. Seek medical attention immediately if an accessory is accidentally swallowed.

Care to be Taken During Handling

Before Using Your Camera

• When traveling, take the Worldwide Service Network listing that is included in the package. This will be useful if you experience problems abroad.

• When the camera has not been used for a long time, make sure that it is still working properly, particularly prior to taking important pictures (such as at a wedding or when traveling). Contents of the recording cannot be guaranteed if recording, playback or transferring your data to a computer, etc. is not possible due to a malfunction of your camera or recording media (SD Memory Card), etc.

About the Battery

• Storing the battery fully charged may decrease the battery performance. Avoid storing in high temperatures.

• If the battery is left inserted and the camera is not used for a long time, the battery will over-discharge and shorten the battery’s life.

• Charging the battery a day before use or on the day of use is recommended.

Precautions on Carrying and Using Your Camera

• Do not subject the camera to high temperatures or high humidity. Do not leave the camera in a vehicle, as the temperature can get very high.

• Do not subject the camera to strong vibrations, shocks, or pressure. Use a cushion to protect the camera from vibrations of motorcycles, automobiles, or ships.

• The temperature range for camera use is 0°C to 40°C (32°F to 104°F).

• The monitor may appear black at high temperatures, but will return to normal at normal temperatures.

• The monitor may respond more slowly at low temperatures. This is due to liquid crystal properties, and is not a malfunction.

• Sudden temperature changes will cause condensation on the inside and outside of the camera. Place the camera in your bag or a plastic bag, and remove it after the temperature of the camera and surroundings are equalized.

• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt. These could cause the camera to breakdown. Wipe the camera to dry off any rain or water drops.

• Please do not press forcefully on the monitor. This could cause it to break or malfunction.

• Be careful not to sit down with the camera in your back pocket as this may damage the exterior of the camera or the display.

• Be careful not to overtighten the tripod screw when using a tripod.

• The lens on this camera is not interchangeable. The lens is not removable.

Cleaning Your Camera

• Do not clean the camera with organic solvents such as thinner, alcohol or benzine.

• Use a lens brush to remove dust accumulated on the lens. Never use a spray blower for cleaning as it may damage the lens.

Storing Your Camera

• Do not store the camera with preservatives or chemicals. Storage in high temperatures and high humidity can cause mold to grow on the camera. Remove the camera from its case and store it in a dry and well-ventilated location.

Other Precautions

• Periodic inspections are recommended every one to two years to maintain high performance.

• Refer to “Precautions When Using an SD Memory Card” (p.38) regarding the SD Memory Card.

• Please note that deleting images or sound files, or formatting the SD Memory Cards or the built-in memory does not completely erase the original data. Deleted files can sometimes be recovered using commercially available software. It is user’s responsibility to ensure the privacy of such data.

Using Your Camera Safely ............................................................... 1

Care to be Taken During Handling ................................................... 5

Contents ...........................................................................................7

Composition of the Operating Manual ............................................ 13

Camera Features ................................................................................. 14

Checking the Contents of the Package .......................................... 17

Names of Parts ............................................................................... 18

Names of Operating Parts .............................................................. 19

Monitor Indications .........................................................................20

Getting Started 29

Attaching the Strap ............................................................................. 30

Powering the Camera ......................................................................... 31

Installing the Battery .......................................................................31

Charging the Battery....................................................................... 33

Installing an SD Memory Card ........................................................... 36

Number of Recordable Images .......................................................39

Turning the Camera On and Off ........................................................40

Starting-up in the Playback Mode...................................................41

Initial Settings ..................................................................................... 42

Setting the Display Language .........................................................42

Setting the Date and Time ..............................................................46

Common Operations 49

Understanding the Button Functions ............................................... 50

A Mode .........................................................................................50

Q Mode ........................................................................................ 52

Switching Between A Mode and Q Mode ................................... 54

Setting the Camera Functions ........................................................... 55

Operating the Menus ......................................................................55

Menu List ........................................................................................ 58

Taking Pictures 63

Taking Still Pictures............................................................................ 64

Taking Pictures ............................................................................... 64

Setting the Shooting Mode .............................................................67

Using the Face Detection Function ................................................ 69

Taking Pictures Automatically (Auto Picture Mode) .......................70

Taking Pictures in the Custom Set tings

(Program Mode) ....................................................................... 71

Taking Pictures in the Basic Mode (Green Mode) ..........................72

Using the Zoom .............................................................................. 73

Taking Pictures of Dark Scenes (Night Scene/Night Scene Portrait/

Digital SR/Fireworks/Candlelight Mode) .................................. 75

Taking Pictures of People (Portrait/Natural Skin Tone Mode) ........76

Taking Pictures of Children (Kids Mode) ........................................ 77

Taking Pictures of Your Pet (Pet Mode) ......................................... 78

Taking Pictures of Sports and Leisure Activities

(Sport/Surf & Snow Mode) ....................................................... 79

Framing Your Pictures (Frame Composite Mode) ..........................80

Taking Pictures Indoors (Party Mode) ............................................81

Taking Pictures of Text (Text Mode) .............................................. 82

Taking Pictures Using the Miniature/HDR Filter .............................83

Using the Camera’s Self-timer........................................................ 84

Taking a Series of Pictures

(Continuous Shooting/Burst Shooting Mode) ........................... 85

Taking Pictures Using the Remote Control Unit (Optional) ............86

Setting the Shooting Functions......................................................... 88

Selecting the Flash Mode ............................................................... 88

Selecting the Focus Mode .............................................................. 89

Selecting the Number of Recorded Pixels...................................... 92

Compensating for Exposure (EV Compensation)...........................94

Correcting the Brightness (D-Range Setting) .................................95

Adjusting the White Balance........................................................... 96

Setting the AE Metering.................................................................. 98

Setting the Sensitivity ..................................................................... 99

Switching the Face Detection Function ........................................ 100

Setting the Shake Reduction Function ......................................... 102

Setting the Instant Review ............................................................103

Setting the Image Sharpness (Sharpness)................................... 104

Setting the Color Saturation (Saturation)......................................105

Setting the Image Contrast (Contrast) ..........................................105

Setting the Date Imprint Function .................................................106

Calling Up a Specific Function...................................................... 107

Recording Movies .............................................................................109

Recording a Movie........................................................................ 109

Selecting the Recorded Pixels and Frame Rate for Movies .........111

Setting the Movie SR (Movie Shake Reduction) Function............112

Saving the Settings (Memory) ......................................................... 113

Playing Back and Deleting Images 115

Playing Back Images ........................................................................ 116

Playing Back Still Pictures ............................................................ 116

Playing Back a Movie ...................................................................117

Multi-Image Display ......................................................................118

Using the Playback Functions ......................................................120

Slideshow ..................................................................................... 121

Rotating an Image ........................................................................124

Zoom Playback .............................................................................125

Deleting Images and Sound Files....................................................126

Deleting a Single Image ...............................................................126

Deleting Selected Images and Sound Files..................................127

Deleting All Images and Sound Files............................................128

Protecting Images and Sound Files from Deletion (Protect) ........ 129

Connecting the Camera to AV Equipment......................................132

Editing and Printing Images 135

Editing Images ..................................................................................136

Changing the Image Size (Resize) ............................................... 136

Cropping Images ..........................................................................137

Processing Images with the Miniature/HDR Filter ........................138

Processing Images with the Digital Filters .................................... 140

Compensating for an Unwanted Red-eye Effect ..........................144

Adding a Frame (Frame Composite) ............................................145

Editing Movies .............................................................................. 148

Copying Images and Sound Files.................................................150

Setting the Printing Service (DPOF)................................................153

Printing a Single Image ................................................................153

Printing All Images ........................................................................ 155

Recording and Playing Back Sound 157

Recording Sound (Voice Recording) ..............................................158

Setting the Voice Recording Function .......................................... 158

Recording Sound ..........................................................................159

Playing Back Sound ..................................................................... 159

Adding a Voice Memo to Images.....................................................161

Recording a Voice Memo .............................................................161

Playing Back a Voice Memo .........................................................162

Settings 163

Camera Settings................................................................................164

Formatting an SD Memory Card...................................................164

Changing the Sound Settings .......................................................165

Changing the Date and Time........................................................166

Setting the World Time ................................................................. 168

Changing the Display Language .................................................. 171

Changing the Naming System of the Folder.................................172

Changing the Video Output Format .............................................. 173

Adjusting the Brightness of the Display ........................................174

Using the Power Saving Function ................................................175

Setting the Auto Power Off Function ............................................ 176

Changing the Start-up Screen ......................................................177

Correcting Defective Pixels in the CCD Sensor

(Pixel Mapping) ......................................................................178

Resetting to Default Settings (Reset) ........................................... 179

Connecting to a Computer 181

Connecting to a Computer ...............................................................182

Setting the USB Connection Mode ...............................................182

Connecting the Camera and the Computer..................................184

Disconnecting the Camera from the Computer ............................185

Using the Provided Software ........................................................... 186

System Requirements ..................................................................186

Installing the Software .................................................................. 187

Using MediaImpression on Windows ...........................................190

Using MediaImpression on Macintosh ..........................................192

Appendix 195

Functions Available for Each Shooting Mode................................196

Messages ...........................................................................................198

Troubleshooting................................................................................200

Default Settings.................................................................................202

List of World Time Cities ..................................................................207

Optional Accessories ....................................................................... 208

Main Specifications ..........................................................................209

WARRANTY POLICY.........................................................................213

Index................................................................................................... 219

In this manual, the method for operating the four-way controller is shown

in illustrations, such as in the ones below.

The meanings of the symbols used in this Operating Manual are explained below.

indicates the reference page number for an explanation of the related operation.

indicates information that is useful to know.

A mode

Q mode

indicates precautions to be taken wh en operating the camer a.

This is the mode for capturing still pictures and recording movies.

This is the mode for viewing still pictures and playing back movies and sound files.

Composition of the Operating Manual

This Operating Manual contains the following chapters.

1 Getting Started –––––––––––––––––––––––––––––––––––––––––

This chapter explains what you need to do after purchasing the camera before you start taking pictures. Be sure to read this chapter and follow the instructions.

2 Common Operations ––––––––––––––––––––––––––––––––––––

This chapter explains common operations such as the functions of the buttons and how to use the menus. For more details, refer to the respective chapters below.

3 Taking Pictures ––––––––––––––––––––––––––––––––––––––––

This chapter explains the various ways of capturing images and how to set the relevant functions.

4 Playing Back and Deleting Images–––––––––––––––––––––––––

This chapter explains how to view still pictures and movies on the camera or on a TV screen and how to delete them from the camera.

5 Editing and Printing Images ––––––––––––––––––––––––––––––

This chapter explains how to edit still pictures on the camera and how to print them.

6 Recording and Playing Back Sound –––––––––––––––––––––––

This chapter explains how to record sound, add sound (a voice memo) to an image, and play them back.

7 Settings–––––––––––––––––––––––––––––––––––––––––––––––

This chapter explains how to set the camera-related functions.

8 Connecting to a Computer –––––––––––––––––––––––––––––––

This chapter explains how to connect the camera to a computer, and includes installation instructions and a general overview of the provided software.

9 Appendix––––––––––––––––––––––––––––––––––––––––––––––

This chapter deals with troubleshooting and lists the optional accessories.

Camera Features

 A shooting mode guide is displayed in the Capture Mode

Palette and a playback mode guide in the Playback Mode Palette (p.67, p.120).

 Use the Green Mode to take pictures easily using

standard settings (p.72).

In addition to basic picture-taking, the Optio S1 has a variety of shooting modes to suit different situations. This section describes how to make the most of the key features of your camera. Together with the explanations of camera operations, it will enable you to enjoy your camera to the full.

Easy-to-Navigate Capture and Playback Functions!

The user-friendly design of the Optio S1 enables easy operation with only a few buttons. Simply by choosing the appropriate icon, you can select the shooting mode (p.67) and choose the optimal settings for the situation, or the playback mode (p.120, p.136) and enjoy the various playback and editing functions. A guide on the display lets you check the functions available in each mode and how to use them.

Perfect for Portrait Shots!

 Face Detection function (p.69)  Modes for taking stunning pictures of people (p.76)

 For decorating your pictures

with a frame

The Optio S1 comes with a “Face Detection” function that spots the faces in your shot and automatically adjusts the focus and exposure for the faces. It can detect up to 16 people per shot, so it will help you take perfect group shots too. It will automatically release the shutter when people are smiling, or if anyone blinked, it will tell you that so you can take the shot again until it is perfect.

Add Fun Frames to Your Pictures!

When you take a picture with the Optio S1, you can choose from our original fun frames to create attractive framed shots (p.80). You can also add frames to pictures you have taken. Adjust the position of the subject in the picture or reduce or enlarge the picture size to match the frame shape and size. Now you no longer have to worry about the subject not fitting into the frame (p.145).

Display Your Data in Calendar Format!

With the Optio S1, you can display recorded images and movies by date in calendar format (p.119). This lets you quickly find the image or movie you want to play back.

Advanced Movie Recording Functions



Use the camera to shoot fun-filled movies of your children or pets as a visual diary of their development (p.109).

 Image processing features such as Resize (p.136),

Cropping (p.137), Digital Filter (p.140) and Red-eye Compensation (p.144) can be used.

 You can divide a movie into two or more segments and

select a frame from a movie to save it as a still picture (p.148).

The Optio S1 has a “Movie SR” function to reduce camera shake during movie recording (p.112), and it enables you to record movies in 1280×720 pixel (16:9) HDTV format (*) (p.111). * When connecting to and playing back images on AV equipment, the

recorded data is output at normal screen resolution. To view movies in HDTV, transfer the data to a computer and play it back on the computer.

A Multitude of Functions Inside the Camera for Enjoying Images Without a Computer!

The Optio S1 has a variety of functions to let you enjoy playing back and editing images without having to connect the camera to your computer. The camera is all you need to take and edit still pictures and movies (p.136).

Checking the Contents of the Package

Camera

Optio S1

USB cable

I-USB116 (*)

Power adapter

D-PA116 (*)

Items marked with an asterisk (*) are also available as optional accessories. For other optional accessories, refer to “Optional Accessories” (p.208).

Strap

O-ST116 (*)

AV cable

I-AVC116 (*)

Quick Guide Operating Manual

Software (CD-ROM)

S-SW116

Rechargeable lithium-ion

batter y D-LI78 (*)

(this manual)

Names of Parts

Lens

Flash

Self-timer lamp

Remote control receiver

Battery/card cover

Tripod socket

Microphone

Speaker

Front

Back

Display

Power switch

Shutter release button

Strap lug

PC/AV terminal

4/W button

Green/i button

Four-way controller

3 button

Shutter release button

C button

Power switch

Q button

Zoom button

Names of Operating Parts

Refer to “Understanding the Button Functions” (p.50 - p.53) for an explanation of the function of each button.

Monitor Indications

03 /0 3/ 201 1

14 :2 5

200

Histogram + Info

No Info

Normal Display

3 8

Display in A Mode

The display shows information such as the shooting conditions in the capture mode. The display changes in the following sequence each time you press the 4/W button: “Normal Display”, “Histogram + Info” and “No Info”.

03/03/2011

14:25

383838

200

When the shooting mode is set to 9 (Green) mode, the monitor display is as shown on the right. You cannot change the information on t he display by pressing the 4/W button (p.72).

Normal Display in Still Picture Capture Mode

1 4 :2 5

+ 1 .0

3 8

0 3 /0 3/ 20 1 1

F 3 .5

1 / 25 0

1 2 3

4 5 6

1/250

1/250 F3.5

F3.5

+1.0

03/03/2011

14:25

14:25+1.0

181716

12 13

Shooting mode (p.67)

Face Detection mode (p.69)

D-Range Setting (p.95)

Shake Reduction setting (p.102)13Battery level indicator (p.35)

Shutter speed

Aperture

Flash Mode (p.88)

Drive Mode (p.84, p.85)

Focus Mode (p.89)

Digital Zoom/Intelligent Zoom

icon (p.73)

* 2 varies depending on the [Face Detection] setting in the [A Rec.

Mode] menu.

I When [Face Detection] is set to [On] J When [Face Detection] is set to [Smile]

If set to [Off], nothing appears in 2.

Memory status (p.40)

Remaining image storage

capacity

Focus frame (p.64)

Current date and time (p.46)

EV Compensation (p.94)

Date Imprint setting (p.106)

World Time setting (p.168)

* 3 varies depending on the [D-Range Setting] setting in the [A Rec.

F 3 .5

1 / 25 0

3 8

200

+ 1 .0

A A A

Mode] menu.

P When [Highlight Correction] is set to O (On) Q When [Shadow Correction] is set to O (On)

When [Highlight Correction] and [Shadow Correction] are both set to O

(On)

If [Highlight Correction] and [Shadow Correction] are both set to P (Off), nothing appears in 3.

* 4 varies depending on the following conditions.

M When [Shake Reduction] in the [A Rec. Mode] menu is set to O (On)

When [Shake Reduction] is set to P (Off) (If the camera shake is likely to

occur, f is indicated when the shutter button is pressed halfway.)

* 5 and 6 appear only when the shutter release button is pressed

halfway.

* For 9, when the focus mode is set to = and the Auto-Macro function

is activated, the q appears on the display (p.89).

* Some indications may not appear depending on the shooting mode.

Histogram + Info/No Info Display in Still Picture Capture Mode

A1 to A18 and B1 appear when “Histogram + Info” is selected. Only B1 appears when “No Info” is selected.

A5 A6 A7

A8 A9

200

A10 A11

A12 A13 A14 A15

A16

1 2 3

B2 B3

1 / 250

F 3 .5

+ 1 .0

A17 A18

Shooting mode (p.67)

Face Detection mode (p.69)

D-Range Setting (p.95)

Shake Reduction setting (

Flash Mode (p.88)

Drive Mode (p.84, p.85)

Focus Mode (p.89)

Digital Zoom/

Intelligent Zoom icon (p.73) Memory status (p.40)

Remaining image storage capacity

A10

p.102

Battery level indicator (p.35)

A11

Recorded Pixels (p.92)

A12

White Balance (p.96)

A13

)

AE Metering (p.98)

A14

Sensitivity (p.99)

A15

Histogram (p.26)

A16

EV Compensation (p.94)

A17

Date Imprint setting (p.106)

A18

Focus frame (p.64)

B1 B2 B3

Shutter s Aperture

peed

* A2 varies depending on the [Face Detection] setting in the [A Rec.

Mode] menu.

I When [Face Detection] is set to [On] J When [Face Detection] is set to [Smile]

If set to [Off], nothing appears in A2.

* A3 varies depending on the [D-Range Setting] setting in the [A Rec.

Mode] menu.

P When [Highlight Correction] is set to O (On) Q When [Shadow Correction] is set to O (On)

When [Highlight Correction] and [Shadow Correction] are both set to O

(On)

If [Highlight Correction] and [Shadow Correction] are both set to P (Off), nothing appears in A3.

* A4 varies depending on the following conditions.

M When [Shake Reduction] in the [A Rec. Mode] menu is set to O (On)

When [Shake Reduction] is set to P (Off) (If the camera shake is likely to

occur, f is indicated when the shutter button is pressed halfway.)

* B2 and B3 appear only when the shutter release button is pressed

halfway.

* When the shooting mode is b (Auto Picture) and if you press the

shutter release button halfway, the automatically selected shooting mode appears in A1 even when “No Info” is selected (p.70).

* Some indications may not appear depending on the shooting mode.

Display in Q Mode

F3 .5

1/ 25 0

10 0

00 38

14 :2 5

200

Edi t

03 /0 3/ 201 1

10 0

00 38

14 :2 5

Edi t

03 /0 3/ 201 1

Edi t

Normal Display

Histogram + Info

No Info

The display shows the shooting information of the image in the playback mode. The display changes in the following sequence each time you press the 4/W button: “Normal Display”, “Histogram + Info” and “No Info”.

100

0038

100-0038

03/03/2011

14:25

Edit

100

0038

Edit

100-0038

03/03/2011

14:25

200

1/250

1/250 F3.5

F3.5

Edit

Normal Display/Histogram + Info Display in Playback Mode

F 3 .5

1 / 25 0

1 0 0

0 0 38

1 4 :2 5

200

Edit

0 3 /0 3/ 20 1 1

(All of the display items are displayed here for explanatory purposes.)

The display shows information such as the shooting conditions. A1 to A10 appear when “Normal Display” or “Histogram + Info” is selected. B1 to B7 appear only when “Histogram + Info” is selected.

3 2 1

100

0038

100-0038

A5 A6

A7 A8

B1 B2 B3 B4

B5 B6

Playback mode

Q : Still picture (p.116)

K : Movie (p.117) L : Sound (p.159)

Protect icon (p.129)

Voice memo icon (p.162)

Memory status (p.40)

Folder number (p.172)

File number

Battery level indicator (p.35)

* In “Normal Display”, A7 and A9 disappear if no operation is performed

for two seconds.

* A8 appears only when the volume is being adjusted during playback of

movies, sound files or voice memos (p.117, p.159, p.162).

* A10 appears even when “No Info” is selected, but disappears if no operation

is performed for two seconds. When no operation is performed for two seconds in “Normal Display” or “Histogram + Info”, only “Edit” disappears.

200

1/250

1/250 F3.5

F3.5

Edit

A8 A9 A10 B1 B2 B3 B4 B5 B6 B7

03/03/2011

14:25

Volume icon Captured date and time (p.46) Four-way controller guide Recorded Pixels (p.92) White Balance (p.96) AE Metering (p.98) Sensitivity (p.99) Shutter speed Aperture Histogram (p.26)

A10

Guide Indications

Number of pixels→

←Brightness→(Dark) (Bright)

Dark image Correct image Bright image

A guide indication for each available button/key operation appears as follows on the display during operation.

2 Four-way controller (2) Zoom button 3 Four-way controller (3) 4 Four-way controller (4) Shutter release button 5 Four-way controller (5)

3 button

SHUTTER

4/W button

i Green/i button

Using the Histogram

A histogram shows the brightness distribution of an image. The horizontal axis represents brightness (dark at the left and bright at the right) and the vertical axis represents the number of pixels. The shape of the histogram before and after shooting tells you whether the brightness and contrast are correct or not, and lets you decide if you need to adjust the exposure and take a picture again.

Compensating for Exposure (EV Compensation) 1p.94

Understanding Brightness

If the brightness is correct, the graph peaks in the middle. If the image is underexposed, the peak is on the left side, and if it is overexposed, the peak is on the right side.

When the image is underexposed, the part to the left is cut off (dark portions) and when the image is overexposed, the part to the right is cut off (bright portions).

Understanding Contrast

The graph peaks gradually for images in which contrast is balanced. The graph peaks on both sides but sinks in the middle for images with a large difference in contrast and low amounts of mid-level brightness.

Memo

1 Getting Started

Attaching the Strap ...................................30

Powering the Camera ...............................31

Installing an SD Memory Card .................36

Turning the Camera On and Off ..............40

Initial Settings ........................................... 42

Attaching the Strap

Attach the strap (O-ST116) supplied with the camera.

Getting Started

Pass the narrow end of the strap through the strap lug.

Pass the other end of the strap through the loop and pull tight.

Powering the Camera

Battery/ card cover

Battery lock lever

Battery

Installing the Battery

Use the rechargeable lithium-ion battery D-LI78 that is provided with the camera.

Make sure that the camera is turned off and open the battery/card cover.

Slide the battery/card cover in the direction indicated by the arrow 1 and flip the cover open 2.

Push the battery lock lever in the direction of the arrow 3 and insert the battery so that the PENTAX logo is facing toward the screen display.

Match the marks on the battery to the marks inside the battery compartment and push the battery in until it is locked in place.

Getting Started

Make sure that the battery is inserted with the PENTAX logo facing toward the screen display. If the battery is incorrectly oriented, malfunction may result.

Close the battery/card cover.

Slide the battery/card cover in the opposite direction indicated by 1. When you hear a click, the cover is securely closed.

Getting Started

Charge the battery before using it in the camera for the first time. (p.33)

To Remove the Battery

Make sure that the camera is turned off and open the battery/card cover.

Push the battery lock lever in the direction of the arrow

The battery will be ejected. Take care not to drop the battery when removing it.

• This camera uses a rechargeable lithium-ion battery D-LI78. Use of any other type of battery may damage the camera and cause a malfunction.

• Insert the battery correctly. If the battery is incorrectly oriented, malfunction may result.

• When storing the battery for more than 6 months, charge the battery for 30 minutes and store the battery separately from the camera. Be sure to recharge the battery every 6 to 12 months. Storing the battery at or below room temperature is ideal. Avoid storing it at high temperature.

• The date and time may be returned to the default setting if the camera is left without the battery for a long time.

• Be careful as the camera or the battery may become hot when the camera is used continuously for a long period of time.

Charging the Battery

Power adapter

Self-timer lamp While charging: Turns on Charging finished: Turns off

USB cable

To power outlet

Charge the battery from a power outlet using the provided power adapter (D-PA116) and USB cable (I-USB116) before using it for the first time, after a long period of non-use, or when the [Battery depleted] message appears.

Make sure that the battery is installed in the camera.

Face the } mark on the USB cable towards the 4 mark on the camera, and connect the cable to the PC/AV terminal.

Connect the other end of the USB cable to the power adapter.

Plug the power adapter into the power outlet.

The self-timer lamp turns on while the battery is charging and turns off when charging is finished.

Unplug the power adapter from the power outlet, and disconnect the USB cable from your camera.

Getting Started

• Do not use the power adapter D-PA116 to charge batteries other than the rechargeable lithium-ion battery D-LI78, as the adapter may overheat or be damaged.

• Make sure that the battery has been insert ed correctly and the cable

Getting Started

is connected properly if the self-timer lamp blinks.

• Replace the battery with a new one in the following cases:

- If the battery starts to run down more quickly (the battery may have reached the end of its service life)

- If the self-timer lamp does not light or blinks even after being charged (the battery may be faulty)

• The time required to fully charge the battery is about 140 minutes (max.). (The charging time may vary depending on the ambient temperature and charging conditions.) The appropriate ambient temperature for charging the battery is 0°C to 40°C (32°F to 104°F).

• The recha rgeable lith ium-ion battery D-LI78 can also be charge d using the optional battery charger D-BC78.

• Do not attempt to charge the battery by connecting the USB cable to a comput er, etc.

• Image Storage Capacity, Movie Recording Time, Sound Recording Time, and Playback Time

(at 23°C with the display on and the battery fully charged)

Image Storage

(flash used for 50%

180 pictures

Capacity

of shots)

Approx.

Movie Recording

Approx. 70 min. Approx. 110 min. Approx. 120 min.

Time

Sound Recording

Time

Playback Time

*1 Image Storage Capacity shows the approximate number of shots

recorded during CIPA-compliant testing (with display on, flash used for 50% of the shots, and 23 degrees centigrade). Actual performance may vary according to operating conditions.

*2 According to the result of in-house testing.

• In general, battery performance may temporarily deteriorate as the temperature decreases.

• Be sure to take a spare battery with you when traveling abroad or to a cold region, or if you intend to take a lot of pictures.

• Battery Level Indicator

You can check the battery level by the indicator on the display.

Screen Display Battery Status (green) Adequate power remains.

(green) Battery is running low.

(yellow) Battery is running very low.

(red) Battery is exhausted.

[Battery depleted] The camera will turn off after this message appears.

Getting Started

Installing an SD Memory Card

This camera uses a commercially available SD Memory Card, SDHC Memory Card, or SDXC Memory Card. (These cards are referred to as

Getting Started

SD Memory Cards hereafter.) Captured images and sound files are saved on the SD Memory Card when a card is inserted in the camera. They are saved in the built-in memory when a card is not inserted (p.40).

Be sure to use this camera to format (initialize) an SD Memory Card that is unused or has been used on other cameras or digital devices. Refer to “Formatting an SD Memory Card” (p.164) for instructions on formatting.

• The still picture storage capacity and movie recording time vary depending on the capacity of the SD Memory Card and the selected number of recorded pixels (p.39).

• The self-timer lamp blinks while the SD Memory Card is being accessed (data is being recorded or read).

Backing Up Data

The camera may not be able to access data in the SD Memory Card or built-in memory in the case of a malfunction. Use a computer or other device to back up important data in another location.

SD Memory Card

SD Memory Card socket

Battery/card cover

Make sure that the camera is turned off and open the battery/card cover.

Slide the battery/card cover in the direction indicated by the arrow 1 and flip the cover open 2.

Insert the SD Memory Card into the SD Memory Card socket so that the label is facing toward the front of the camera (the side with the lens).

Push the card in until it clicks. Data may not be recorded correctly if the card is not inserted all the way.

Close the battery/card cover.

Slide the battery/card cover in the opposite direction indicated by 1. When you hear a click, the cover is securely closed.

To Remove the SD Memory Card

Getting Started

Make sure that the camera is turned off and open the battery/card cover.

Push the card into the SD Memory Card socket to eject it.

Pull the card out.

Precautions When Using an SD Memory Card

Write-protect

switch

• The SD Memory Card is equipped with a writeprotect switch. Setting the switch to LOCK prevents new data from being recorded on the

card, the stored data from being deleted, and

Getting Started

the card from being formatted by the camera or computer. r appears on the display when the card is write-protected.

• Car e should be taken when removing the SD Memory Card immediately after using the camera, as the card may be hot.

• Keep the card cover closed and do not remove the card or turn the camera off while the data is being played back or saved to the card, or the camera is connected to a computer with the USB cable, as this may cause the data to be lost or the card to be damaged.

• Do not bend the SD Memory Card or subject it to violent impact. Keep it away from water and store away from high temperature.

• Do not remove the SD Memory Card during formatting as this may damage the card and render it unusable.

• The data on the SD Memory Card may be deleted in the following circumstances. We do not accept any liability for data that is deleted (1) when the SD Memory Card is mishandled by the user. (2) when the SD Memory Card is exposed to static electricity or electrical

interference. (3) when the SD Memory Card has not been used for a long time. (4) when the SD Memory Card is ejected or the battery is removed while the

data on the card is being recorded or accessed.

• If it is not used for a long time, the data on the card may become unreadable. Be sure to regularly make a backup of important data on a computer.

• Avoid using or storing the card where it may be exposed to static electricity or electrical interference.

• Avoid using or storing the card in direct sunlight or where it may be exposed to rapid changes in temperature or to condensation.

• When using an SD Memory Card with a slow recording speed, recording may stop while you are taking movies even when there is adequate space in the memory, or shooting and playback may take a long time.

• Be sure to format SD Memory Cards that are unused or have been used on another camera. Refer to “Formatting an SD Memory Card” (p.164).

Number of Recordable Images

The file sizes of the recorded images vary depending on the number of recorded pixels of the images, so the number of images that can be saved on an SD Memory Card or in the built-in memory also varies.

Choose the appropriate number of recorded pixels for still pictures on the [A Rec. Mode] menu.

Selecting the Number of Recorded Pixels 1p.92

Choose the appropriate number of recorded pixels and frame rate on the [C Movie] menu.

Selecting the Recorded Pixels and Frame Rate for Movies 1p.111

For an approximate guide to the number of images or the length of recorded movies that can be saved on an SD Memory Card or in the built-in memory, see “Main Specifications” (p.210).

Getting Started

Turning the Camera On and Off

Power switch

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 1 1

Memory status

Getting Started

Press the power switch.

The camera turns on and the display turns on. When you turn the camera on, the lens cover opens and the lens extends. If the [Language/u] screen or [Date Adjustment] screen appears when you turn the camera on, follow the procedure on p.42 to set the display language and/or current date and time.

Press the power switch again.

The display turns off, the lens closes, and the camera turns off.

Taking Still Pictures 1p.64

Checking the SD Memory Card

The SD Memory Card is checked when the camera turns on and the memory status is displayed.

The SD Memory Card is inserted. Images and sound files will be saved on the SD Memory

Card.

The SD Memory Card is not inserted. Imag es and sound files will be saved in the built-in

memory.

The write-protect switch on the SD Memory Card is in the LOCK position (p.38).

Images and sounds cannot be recorded.

03/03/2011

14:25

Starting-up in the Playback Mode

Q button

Power switch

If you want to play back images or sound files straightaway without taking any pictures, you can start up the camera in the playback mode.

Press the power switch while holding down the Q button.

The display turns on with the lens retracted and the camera turns on in the playback mode.

To switch from the playback mode to the capture mode, press the Q button or press the shutter release button halfway.

Playing Back Still Pictures 1p.116

Getting Started

Initial Settings

3 button

Four-way controller

4 button

The [Language/u] screen appears when the camera is turned on for the first time. Perform the operations in “Setting the Display Language”

Getting Started

below to set the language, and in “Setting the Date and Time” (p.46) to set the current date and time.

The language, date, and time can be changed later. Refer to the pages below for instructions.

• To change the language, follow the steps in “Changing the Display Language” (1p.171).

• To change the date and time, follow the steps in “Changing the Date and Time” (1p.166).

Setting the Display Language

Use the four-way controller (2345) to choose the desired display language.

English

Dansk

Deutsch

Svenska Suomi

Polski Italiano Nederlands

Magyar

Cancel

OFF

Daylight saving time

OFF

Press the 4 button.

The [Initial Setting] screen appears in the selected language. If the desired settings

Initial Setting

for [Hometown] and [DST] (Daylight Saving Time) appear, proceed to Step 3. Proceed to “To Set Hometown and DST” (p.45) if the desired settings do not appear.

Press the four-way controller (3)

Hometown New York

Settings complete

Cancel

Initial Setting

twice to select [Settings complete].

Press the 4 button.

The [Date Adjustment] screen appears. Set the date and time by following the procedure in “Setting the Date and Time” (p.46).

Hometown New York

Settings complete

Cancel

English

DST

English

DST

OFF

Getting Started

If you accidentally select the wrong language and proceed to the next procedure, perform the following operation to set the desired language.

 When the Wrong Language Has Been Inadvertently Selected

Getting Started

Press the four-way controller (5).

Use the four-way controller (2345) to select the desired language and press the 4 button.

The [Initial Setting] screen appears in the selected language.

 When the Screen After Step 2 Appears in the Wrong Language

Press the 3 button.

The setting screen is canceled and the camera is set to still picture capture mode.

Press the 3 button.

The [A Rec. Mode] menu appears.

Press the four-way controller (5) twice.

The [W Setting] menu appears.

Use the four-way controller (23) to select [Language/ u].

Press the four-way controller (5).

The [Language/u] screen appears.

Use the four-way controller (2345) to select the desired language.

Press the 4 button.

The [W Setting] menu appears in the selected language.

To reset the Hometown city, date, and time, refer to the pages below for instructions.

• To change the Hometown city, follow the steps in “Setting the World Time”

(1p.168).

• To change the date and time, follow the steps in “Changing the Date and

Time” (1p.166).

To Set Hometown and DST

OFF

Press the four-way controller (3).

The frame moves to [W Hometown].

Press the four-way controller (5).

Initial Setting

The [W Hometown] screen appears.

Hometown New York

Settings complete

Cancel

Use the four-way controller (45)

Hometown

to choose a city.

City

New York

DST

Cancel

Press the four-way controller (3).

The frame moves to [DST] (Daylight Saving Time).

Use the four-way controller (45) to select O (On) or P (Off).

Press the 4 button.

The [Initial Setting] screen reappears.

English

Getting Started

Press the four-way controller (3)

Initial Setting

to select [Settings complete].

Hometown New York

Settings complete

Cancel

Press the 4 button.

The [Date Adjustment] screen appears. Next, set the date and time.

English

DST

OFF

The video output format (NTSC/PAL) is set to the format of the city selected in [Hometown] on the [Initial Setting] screen. Refer to “List of World Time Cities” (p.207) for the video output format of each city that will be set at the time of initial setting, and “Changing the Video Output Format” (p.173) for changing the video

output format.

Getting Started

Setting the Date and Time

Set the current date and time and the display style.

Press the four-way controller (5).

The frame moves to [mm/dd/yy].

Use the four-way controller (23) to choose the date format.

Choose from [mm/dd/yy], [dd/mm/yy] or [yy/mm/dd].

Press the four-way controller (5).

The frame moves to [24h].

Use the four-way controller (23) to select [24h] (24-hour display) or [12h] (12-hour display).

Date Ad j ustme nt

Date Format

Tim e

S e tti ngs complet e

Cancel

Date Ad j ustme nt

Date Format

Tim e

S e tti ngs complet e

MENUMENU

Cancel

mm dd yy

// 24 h

/ 01

/ 201

00: 00

mm dd yy//

/ 01

/ 201

00: 00

24 h

Press the four-way controller (5).

The frame returns to [Date Format].

Press the four-way controller (3).

The frame moves to [Date].

Press the four-way controller (5).

The frame moves to the month.

Use the four-way controller (23) to change the month.

Change the day and year in the same manner. Next, change the time. If you selected [12h] in Step 4, the camera automatically switches the display between

Date Ad j ustme nt

Date Format

Tim e

S e tti ngs complet e

Cancel

am and pm corresponding to the time.

Press the four-way controller (3) to select [Settings complete].

Press the 4 button.

Date Adj ustment

Date Format

ate

Time

Settings complete

Cancel

This confirms the date and time.

If you press the 4 button in Step 10, the camera clock is reset to 0 seconds. To set the exact time, press the 4 button when the time signal (on the TV, radio, etc.) reaches 0 seconds.

When the [Initial Setting] or [Date Adjustment] screen is displayed, you can cancel the settings made up to that point and switch to the capture mode by pressing the 3 button. In this case, the [Initial Setting] screen will appear again the next time you turn the camera on.

mm dd yy// 24 h

01/ 01/ 2011

00: 00

mm dd y y/ / 24h

01/01/2011

00:00

Getting Started

The language, date, time, Hometown city, and DST setting can be changed. Refer to the pages below for instructions.

• To change the language, follow the steps in “Changing the Display Language”

(1p.171).

• To change the date and time, follow the steps in “Changing the Date and

Time” (1p.166).

• To change the Hometown city or DST setting, follow the steps in “Setting the

World Time” (1p.168).

Memo

2 Common Operations

Understanding the Button Functions ..... 50

Setting the Camera Functions .................55

Understanding the Button Functions

4 5 6

8 9

A Mode

Common Operations

1 Power switch

Turns the camera on and off (p.40).

2 Shutter release button

Focuses the camera on the subject when pressed halfway in still picture capture mode (except in 3, s and \ modes). Takes a still picture when pressed down fully (p.65). Starts and stops sound file recording in Voice Recording (p.159).

3 Zoom button

Changes the area captured by the camera (p.73). Switches to the [A Rec. Mode] menu, [C Movie] menu, or [W Setting] menu when a menu screen is displayed.

4 Q button

Switches to the Q mode (p.54).

5 C button

Starts and stops movie recording (p.109).

6 Four-way controller

2 Changes the drive mode (p.84, p.85). 3 Displays the Capture Mode Palette (p.67). 4 Changes the flash mode (p.88). 5 Changes the focus mode (p.89). 23 Adjusts the focus when the focus mode is set to \ (p.90).

7 4/W button

Changes the information on the display (p.20).

8 Green button

Switches to the 9 (Green) mode (p.72). Calls up the assigned function (p.107).

9 3 button

Displays the [A Rec. Mode] menu (p.55).

Common Operations

Q Mode

7 8

Common Operations

1 Power switch

Turns the camera on and off (p.40).

2 Shutter release button

Switches to A mode (p.54).

3 Zoom button

Press towards the left (f) during single-image display to change to four-image display. Changes to nine-image display when pressed towards the left again. Returns to the previous display when pressed towards the right ( Enlarges the image when image display. Returns to the previous display when the left (f) (p.125). Press towards the left (f) during nine-image display to change to folder or calendar display (p.119). Press towards the right (y) during folder/calendar display to change to nine-image display (p.119). Adjusts the volume during playback of movies, sound files or voice memos (p.117, p.159, p.162).

4 Q button

Switches to A mode (p.54).

) (p.118).

pressed towards

the right (y) during single-

pressed towards

5 Four-way controller

2 Plays back and pauses a movie or sound file (p.117,

p.159).

3 Displays the Playback Mode Palette (p.120).

Stops a movie or sound file during playback (p.117, p.159).

45 Displays the previous or next image or sound file during

single-image display (p.116). Fast-forwards, fast-reverses, frame forwards, frame reverses, plays back a movie in forward and reverse during movie playback (p.117). Fast-forwards, fast-reverses, and moves to the next index during sound playback (p.159).

2345 Selects an image during four-/nine-image display, a folder

during folder display, and a date during calendar display (p.118, p.119). Moves the display area during zoom display (p.125). Moves the image when using the Frame Composite function (p.145).

6 4/W button

Changes the information on the display (p.24). Returns to single-image display during four-/nine-image display or zoom display (p.118, p.125). Changes to nine-image display of the selected folder during folder display (p.119). Changes to single-image display of the selected date during calendar display (p.119).

7 Green/i button

Switches from single-image display to the Delete screen (p.126). Switches from four-/nine-image display to the Select & Delete screen (p.127). Switches from folder display to the calendar display screen (p.119). Switches from calendar display to the folder display screen (p.119).

8 3 button

Displays the [W Setting] menu during single-image display (p.55). Returns to single-image display during Playback Mode Palette display (p.120). Returns to single-image display during four-/nine-image display or zoom display (p.118). Changes to nine-image display during folder or calendar display (p.119).

Common Operations

Switching Between A Mode and Q Mode

Make sure that the camera is turned off before inserting or removing the SD Memory Card.

In this manual, the capture mode, such as for taking still pictures, is referred to as “A mode” (the capture mode). The playback mode, such as for viewing the captured images on the display, is referred to as “Q mode” (the playback mode). In Q mode, you can perform simple editing operations on the captured images.

Follow the procedure below to switch between A mode and Q mode.

Common Operations

To Switch from A Mode to Q Mode

Press the Q button.

The camera switches to Q mode.

To Switch from Q Mode to A Mode

Press the Q button or the shutter release button halfway.

The camera switches to A mode.

Displaying the data stored in the built-in memory

When an SD Memory Card is inserted in the camera, images, movies, and sound files stored on the SD Memory Card are displayed. If you want to display images, movies and sound files stored in the builtin memory, turn the camera off first, and then remove the SD Memory Card before proceeding.

Setting the Camera Functions

To change the camera settings, press the 3 button to display the menu screens. Functions for playing back and editing images and sound files are called up from the Playback Mode Palette (p.120).

Operating the Menus

There are three menus available with the camera: [A Rec. Mode], [C Movie], and [W Setting]. Press the 3 button in A mode to display the [A Rec. Mode] menu. Press the 3 button in Q mode to display the [W Setting] menu. Use the four-way controller (45) or zoom button to switch between the menus.

Rec. Mode

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

Exit

Setting

Sound Date Adjustment World Time

Folder Name Date USB Connection

Exit

1/3

01/01/2011

English

MSC

Available button operations appear on the display during menu operation (p.26).

1/3

AWB

Auto

0.0

Movie

Recorded Pixels Movie SR

Exit

1/1

Common Operations

Ex.) To set [Focusing Area] on the [A Rec. Mode] menu

Rec. Mode

1/3

ၭၭExit

EV Compensation

Recorded Pixels White Balance

AE Metering

Focusing Area

AWB

0.0

Sensitivity

Auto

Rec. Mode

1/3

Cancel

EV Compensation

Recorded Pixels White Balance

AE Metering Sensitivity

Focusing Area

AWB

0.0

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Press the four-way controller (3).

Common Operations

The frame moves to [Recorded Pixels].

Press the four-way controller (3) twice.

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

The frame moves to [Focusing Area].

Press the four-way controller (5).

A pull-down menu appears only with the items that are available with the current camera settings.

Use the four-way controller (23) to change the setting.

The focusing area changes each time the four-way controller (23) is pressed.

Rec. Mode

Exit

1/3

AWB

Auto

0.0

Press the 4 button or the four-way controller (4).

The setting is saved and then the camera is ready for setting the other functions. To exit the setting operation, press the 3 button.

To perform another operation, refer to the following alternate Step 6 options.

To Save the Setting and Start Taking Pictures

Press the shutter release button halfway.

The setting is saved and the camera returns to capture status. When the shutter release button is pressed fully, the picture is taken.

When the [W Setting] menu is displayed from Q mode, you can switch to A mode by pressing the Q button.

To Save the Setting and Start Playback of Images

Press the Q button.

When the [A Rec. Mode] menu is displayed from A mode, the setting is saved and the camera returns to playback status.

To Cancel the Changes and Continue with Menu Operations

Press the 3 button.

The changes are canceled and the screen shown in Step 3 reappears.

The 3 button function varies depending on the screen. Refer to the guide indications.

Exit Exits the menu and returns to the original screen.

Cancel Cancels the current selection, exits the menu and

Returns to the previous screen with the current setting.

returns to the previous screen.

Common Operations

Menu List

This displays the items that can be set from the menus and provides descriptions of each item. See the list of default settings in the Appendix “Default Settings” (p.202) to check whether the settings are saved when the camera is turned off and whether the settings return to the defaults when the camera is reset.

[A Rec. Mode] Menu

Common Operations

Item Description Page

Recorded Pixels For choosing the number of recorded pixels of still pictures p.92

White Balance

Focusing Area For changing the autofocus area p.91

AE Metering

Sensitivity For setting the sensitivity p.99 EV Compensation

Highlight Correction

Shadow Correction

D-Range Setting Shake Reduction

Face Detection

Blink Detection

Digital Zoom

Instant Review For choosing whether to display Instant Review p.103

Memory

Green Button

Sharpness For choosing sharp or soft outlines p.104

Saturation For setting the color saturation p.105

Contrast For setting the image contrast level p.105

Date Imprint

For adjusting the color balance according to the light conditions

For setting the area of the screen that is metered to determine the exposure

For adjusting the overall brightness of the picture p.94

For adjusting the bright areas when the image is overexposed

For adjusting the dark areas when the image is underexposed

For choosing whether to correct camera shake when taking still pictures

For spottin g the faces in your shot and automatically adjusting the focus and exposure for the faces

For choosing whether to use the Blink Detection function when the Face Detection function is activated

For choosing whether or not to use the Digital Zoom function

For choosing whether to save the set values of the shooting function or return to the defaults when the camera is turned off

For assigning a function to the Green button so that you can go straight to it in A mode

For choosing whether to imprint the date an d/or time when taking still pictures

p.96

p.98

p.95

p.102

p.100

p.74

p.113

p.107

p.106

 [A Rec. Mode] Menu 1

Rec. Mode

 [A Rec. Mode] Menu 2

 [A Rec. Mode] Menu 3

Rec. Mode

Saturation

⚳⚳

Exit

3/3

Sharpness

Contrast

Green Button

Memory

Date Imprint Off

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

Exit

1/3

AWB

Auto

0.0

Rec. Mode

D-Range Setting Shake Reduction Face Detection On Blink Detection Digital Zoom Instant Review

Exit

2/3

•Use the 9 (Green) mode to enjoy easy picture-taking using standard settings, regardless of the settings in the [A Rec. Mode] menu (p.72).

• Assigning a frequently used function to the Green button enables you to go straight to the desired function (p.107).

[C Movie] Menu

Item Description Page

Recorded Pixels For choosing the number of recorded pixels of movies p.111

Movie SR

For choosing whether or not to use the movie shake reduction function

Common Operations

p.112

Movie

Recorded Pixels Movie SR

Exit

1/1

[W Setting] Menu

Item Description Page

Sound

Date Adjustment For adjusting the date and time p.166

World Time For setting the Hometown city and Destination city p.168

Language/

Common Operations

Folder Name

USB Connection

Video Out For setting the output format to AV equipment p.173 Brightness Level For changing the brightness of the display p.174

Power Saving

Auto Power Off

Reset For returning settings to their defaults p.179

Delete All

Pixel Mapping

Format For formatting an SD Memory Card p.164

For adju sting the operation volume and playback volume, and setting the start-up sound, shutter sound, key operation sound and self-timer sound

For setting the language in which menus and messages appear

For choosing how names are assigned to folders for storing images and sound files

For setting the USB connection mode (MSC or PTP) when connected to a computer via the USB cable

For setting the time until the camera enters the powersaving mode

For setting the time until the camera turns off automatically

For deletin g all the saved images and sound files at once

For mapping out and correcting any defective pixels in the CCD sensor

p.165

p.171

p.172

p.182

p.175

p.176

p.128

p.178

 [W Setting] Menu 1

Setting

 [W Setting] Menu 2

 [W Setting] Menu 3

Setting

Pixel Mapping Format

Exit

3/3

Sound Date Adjustment World Time

Folder Name Date USB Connection

Exit

01/01/2011

English

MSC

1/3

Setting

Video Out Brightness Level Power Saving Auto Power Off Reset Delete All

ขᶖขᶖExit

NTSC

sec.

min.

2/3

Common Operations

Memo

3 Taking Pictures

Taking Still Pictures .................................. 64

Setting the Shooting Functions ...............88

Recording Movies ................................... 109

Saving the Settings (Memory) ...............113

Taking Still Pictures

Shutter release button

Zoom button

Four-way controller 4 button

Green button

Power switch

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

Focus frame

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

Face detection frame

Taking Pictures

The Optio S1 features a wide range of shooting modes and functions to suit almost any subject or scene. This chapter describes how to take pictures with the most commonly used standard settings (the factory default settings).

Press the power switch.

The camera turns on in the “still picture capture mode”.

Make sure of the subject and shooting information on the display.

The focus frame in the middle of the display indicates the zone of automatic focusing.

03/03/2011

14:25

When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

You can change the captured area by pressing the zoom button (p.73).

Right (x) Enlarges the subject. Left (w) Widens the area that is

captured by the camera.

03/03/2011

14:25

F 4 . 6

1 / 2 5 0

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

Press the shutter release button halfway.

The focus frame (or face detection frame) on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken. The flash discharges automatically depending on the light conditions. The captured image appears on the display (Instant Review: p.67) and is saved to the SD Memory Card or the built-in memory.

Press the Green button to switch to the 9 (Green) mode and let the camera set all the shooting functions automatically (p.72).

1/250

1/250 F4.6

F4.6

03/03/2011

14:25

Taking Pictures

Using the Shutter Release Button

Not pressed Pressed halfway

(first position)

Pressed fully

(second position)

The shutter release button works in a two-step action as follows.

Press halfway

This refers to pressing the shutter release button gently to the first position. This locks the focus setting and the exposure. The green focus frame is displayed on the monitor when the shutter release button is pressed halfway and the subject is in focus. If the subject is out of focus, the white focus frame appears.

Press fully

This refers to pressing the shutter release button all the way down to the

Taking Pictures

fully depressed position. This takes a picture.

Poor focusing conditions

The camera may not be able to focus under the following conditions. In these cases, lock the focus on an object the same distance away as the subject (by pressing and holding the shutter release button halfway), then aim the camera at your subject and press the shutter release button fully.

• Objects that lack contrast such as a blue sky or white wall

• Dark places or objects, or conditions that prevent light from being reflected back

• Horizontal lines or intricate patterns

• Fast moving objects

• When there is an object in the foreground and an object in the background in the captured area

• Strongly reflected light or strong backlighting (bright background)

Instant Review and Blink Detection

Can ce l

Lan ds cape

1 / 2

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 1 1

Immediately after capturing an image, it appears on the screen display for 1 second (Instant Review). If the camera detects that the subject’s eyes are closed while the Face Detection function (p.69) is activated, the message [Closed eyes have been detected] appears for 3 seconds (Blink Detection).

• When the Face Detection function does not work, Blink Detection also does not function. Even if the subjects’ faces are detected, Blink Detection may not function depending on the condition of the detected faces.

• You can also disable the Blink Detection function (p.100).

Setting the Shooting Mode

The Optio S1 has a variety of shooting modes that let you take pictures in different situations simply by choosing the appropriate mode for the particular situation from the Capture Mode Palette.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to choose a shooting mode.

When an icon is selected in the Capture Mode Palette, the guide for the selected shooting mode appears.

Landscape

For capturing landscape views. Enhances colors of sky and foliage

Cancel

1/2

Taking Pictures

Press the 4 button.

The shooting mode is fixed and the camera returns to capture status.

03/03/2011

14:25

There are 23 shooting modes which can be selected from the Capture Mode Palette.

Shooting Mode Description Page

Auto Picture Automatically selects the best capture mode. p.70

a Landscape

b Flower

Taking Pictures

c Portrait

Program

Blue Sky

Sunset For images of sunsets and warm lighting. —

Night Scene

Night Scene Portrait

Natural Skin Tone

Food

Used for basic shooting. Various functions can also be set with this mode.

Emphasizes saturation of the sky to produce a bright image.

For captur ing landscape views. Enhances co lors of sky and foliage.

For images of flowers. The outline of the flower is softened.

For night time images. Use of a tripod or other support is suggested.

For images of people at night. Use of a tripod or other support is advised.

For capturing portraits. Reproduces a healthy and bright skin tone.

For images of people. Enhances skin tones while smoothing blemishes.

For images of food and prepared dishes. Enhan ces sa turation and contrast.

c Digital SR Higher sensitivity reduces blur. p.75

Kids

Y Pet

Sport

Surf & Snow

Fireworks

Frame Composite For capturing images with a frame. p.80

B Party

Candlelight For capturing scenes in candlelight. p.75

Text

For capturing moving kids. Reproduces a healthy and bright skin tone.

For captur ing moving pets. Select the color according to the pet’s coat.

For a fast moving subject. Tracks the subject until the picture is taken.

For bright images such as sand or snow. Accurately meters for bright scenes.

For capturing fireworks. Use of a tripod or other support is suggested.

For captur ing images at parties or in dim light. Increases ISO and clarity.

Captures text in an easy to read manner. Text contrast can be adjusted.

p.71

—

p.75

p.76

—

p.77

p.78

p.79

p.75

p.81

p.82

Shooting Mode Description Page

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

Face detection frame

14:251 4 : 2 5

383 8

03/03/20110 3 / 0 3 / 2 0 1103/03/2011

14:25

When the multiple faces

are detected

Main frame White

frame

o Miniature Filter

p HDR Filter For capturing an image with HDR-like effect. p.83

For capturing an image where the subject looks like a miniature object.

* In addition to the modes listed above, 9 (Green) mode (p.72) and Voice

Recording (p.158) are also available.

• In shooting modes other than R, A , c and N, saturation, contrast, sharpness, white balance, etc. are set to the optimal settings for the selected mode.

• Some functions may not be available or may not work fully depending on the selected shooting mode. For details, refer to “Functions Available for Each Shooting Mode” (p.196).

Using the Face Detection Function

With the Optio S1, the Face Detection function is available with all shooting modes. When the camera detects a person’s face in the image, the Face Detection function displays a yellow face detection frame around the face on the screen display, sets the focus (Face Detection AF) and compensates the exposure (Face Detection AE). If the subject in the face detection frame moves, the frame also moves and changes its own size as it tracks the face.

The Face Detection function can detect up to 16 people’s faces. If it detects multiple faces, the camera displays a yellow frame over the main face and white frame(s) over the other face(s). The default setting is [On]. You can switch to the Smile Capture function that automatically releases the shutter when the subject smiles. Refer to “Switching the Face Detection Function” (p.100) for details.

p.83

03/03/2011

14:25

Taking Pictures

Taking Pictures Automatically (Auto Picture Mode)

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

In b (Auto Picture) mode, the camera automatically selects the most appropriate mode depending on the situations and subjects.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select b.

Taking Pictures

Press the 4 button.

The b mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The selected shooting mode is displayed on the top left of the screen.

Standard Night Scene Landscape

Portrait

Candlelight Blue Sky

Portrait×Backlight Sunset Portrait×Sunset

Group Photograph

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Night Scene Portrait

Text

Flower

Portrait×Blue Sky

03/03/2011

14:25

Press the shutter release button fully.

The picture is taken.

The following restrictions apply in b mode:

3 8

0 3 / 0 3 / 2 0 11

1 4 : 2 5

• [Face Detection] cannot be set to [Off].

• The focusing area setting is fixed at J (Multiple).

• The (Flower) mode cannot be selected when using Digital Zoom or Intelligent Zoom.

• If the (Night Scene) mode is selected when the flash mode is set to , (Auto) or c (Auto + Red-eye), the flash mode automatically changes to a (Flash Off).

• If the (Night Scene Portrait) mode is selected when the flash mode is set to , (Auto), the flash mode automatically changes to d (Flash On + Red-eye) when the camera detects a face and determines that the flash is needed.

Taking Pictures in the Custom Settings (Program Mode)

In R (Program) mode, the camera automatically sets the shutter speed and aperture for taking still pictures. However, you can change the settings of some functions such as the flash mode and the number of recorded pixels.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select R.

Press the 4 button.

The R mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

03/03/2011

14:25

Taking Pictures

Change the settings as needed.

Refer to “Setting the Shooting Functions” (p.88 - p.108) for details on how to set the functions.

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

3 8

Press the shutter release button fully.

The picture is taken.

Taking Pictures in the Basic Mode (Green Mode)

In 9 (Green) mode, you can enjoy easy picture-taking using standard settings, regardless of the settings in the [A Rec. Mode] menu. The 9 mode settings are as shown below.

Flash Mode , (Auto)

Drive Mode 9 (Standard)

Taking Pictures

Focus Mode = (Standard) Shake Reduction O (On) Information Display Normal Face Detection On Recorded Pixels g (4288×3216) Blink Detection O (On) White Balance F (Auto) Digital Zoom O (On) Focusing Area J (Multiple) Instant Review O (On)

AE Metering

Sensitivity Auto Contrast G (Normal) EV Compensation ±0.0 Date Imprint Off

Press the Green button in A

L (Multi-segment

metering)

Highlight Correction Shadow Correction

Sharpness G (Normal) Saturation G (Normal)

P (Off) P (Off)

mode.

The camera switches to 9 mode.

Press the Green button again to return to the status before 9 mode was selected.

When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken.

•The 9 mode is available only when it is assigned to the Green button

383838

33.5 x33. 5 x33.5 x0.9 m-0 .9 m-0.9 m-

Zoom bar

Zoom ratio

Focus range (during zooming only)

Zoom in with high image quality.

Zoom in with some degree of image deterioration.

Optical zoom range

Intelligent Zoom range

Digital Zoom range

in [Green Button] of the [A Rec. Mode] menu (p.107). By default, the 9 mode is assigned to the Green button.

•In 9 mode, you cannot change the information on the display by pressing the 4/W button.

• If you press the 3 button in 9 mode, the [W Setting] menu appears. The [A Rec. Mode] and [C Movie] menus cannot be displayed.

• When the camera is turned off in 9 mode, it turns on in 9 mode next time the power switch is pressed.

Using the Zoom

You can use the zoom to change the captured area.

Press the zoom button in A mode.

Right (x) Enlarges the subject. Left (w) Widens the area that is

captured by the camera.

When you continue to press the button towards the right (x), the camera automatically switches from optical zoom to Intelligent Zoom. Once the button is released and pressed again, the camera switches to Digital Zoom.

The zoom bar is displayed as follows.

Taking Pictures

*1 You can zoom in to a maximum of 5× optically. *2 The Intelligent Zoom range differs depending on the number of

recorded pixels. See the following table.

Recorded pixels and the maximum zoom ratio

Recorded

Pixels

g Not Available (5× optical zoom only)

l/i Not Available (5× optical zoom only)

6 Approx. 7.0×

h Approx. 11.2×

Intelligent Zoom Digital Zoom

Approx. 33.5×

(Same as

Digital Zoom)

Equivalent to approx.

33.5×

Taking Pictures

• It is recommended to use a tripod to prevent camera shake when taking pictures at high zoom.

• Pictures taken in the Digital Zoom range appear grainier than pictures taken in the optical zoom range.

• Intelligent Zoom is not available under the following conditions:

- When the number of recorded pixels is set to g/l/i (5×

optical zoom is available)

-In c (Digital SR) mode

- When the sensitivity is set to 3200 or 6400

• The image enlarged using Intelligent Zoom may appear rough on the display. This does not affect the quality of the recorded image.

• Only Digital Zoom is available while recording a movie.

• The focus range is not displayed when the focus mode is set to 3/s or the shooting mode is set to S (Fireworks), or while recording a movie.

To Set the Digital Zoom

The Digital Zoom is set to O (On) in the default setting. To take pictures using only the optical zoom and Intelligent Zoom, set the Digital Zoom to P (Off).

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [Digital Zoom].

Use the four-way controller (45) to select O or P.

O Uses Digital Zoom P Uses only optical zoom and

Intelligent Zoom

Press the 3 button.

The camera returns to capture status.

Saving the Digital Zoom Function setting 1p.113

Rec. Mode

D-Range Setting Shake Reduction Face Detection Blink Detection Digital Zoom Instant Review

Exit

2/3

Taking Pictures of Dark Scenes (Night Scene/Night Scene Portrait/Digital SR/Fireworks/Candlelight Mode)

You can choose an appropriate shooting mode for taking pictures of dark scenes, such as nightscapes.

Taking Pictures

Night Scene

Night Scene Portrait

Digital SR

Fireworks

Candlelight For capturing scenes in candlelight.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select A, B,

For night time images. Use of a tripod or other support is suggested.

For images of people at night. Use of a tripod or other support is advised. If the Face De tection function is activated when th e flash mode is set to , (Auto), the flash mode automatically changes to d (Flash On + Red-eye).

Higher sensitivity reduces blur. The sensitivity is automatically set to [Auto] and the number of record ed pixels is fixed at f (2592×1944).

For capturing fireworks. Use o f a tripod or other support is suggested. The shutter speed is fixed at 4 sec. and the sensitivity is fixed at the minimum value.

c, S or U.

Press the 4 button.

The A, B, c, S or U mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Taking Pictures

Press the shutter release button fully.

The picture is taken.

• The shutter speed tends to be slower when taking pictures of dark scenes.

• To prevent camer a shake, set [Shake Reduction] (p.102) to O (On), or use a tripod and/or the self-timer function (p.84).

Taking Pictures of People (Portrait/Natural Skin Tone Mode)

The c (Portrait) and d (Natural Skin Tone) modes are suitable for taking pictures of people. [Face Detection] (p.69) is automatically set to [On] for each shooting mode, making it easier to emphasize the subject’s face when taking pictures.

Portrait

Natural Skin Tone

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select c or d.

For capturing portraits. Reproduces a healthy and bright skin tone.

For images of people. Enhances skin tones while smoothing blemishes.

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 11

Press the 4 button.

The c or d mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken.

03/03/2011

14:25

Taking Pictures of Children (Kids Mode)

The R (Kids) mode is suitable for taking pictures of moving children. It also reproduces a healthy and bright skin tone. [Face Detection] (p.69) is automatically set to [On] for this mode, making it easier to emphasize the subject’s face when taking pictures.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select R.

Press the 4 button.

The R mode is selected and the camera returns to capture status. The camera tracks the subject and continues to focus on it. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

03/03/2011

14:25

Taking Pictures

Press the shutter release button fully.

The picture is taken.

When [Focusing Area] (p.91) is set to J (Multiple) or K (Spot), focus

Can ce l

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 1 1

can be locked by pressing the shutter release button halfway.

Taking Pictures of Your Pet (Pet Mode)

Use the Y (Pet) mode to keep your moving pet in focus and capture the color of your pet’s coat when you take a picture. Choose the appropriate icon depending on what color your pet is (closer to black or white or in between).

Taking Pictures

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select Y.

Press the 4 button.

The Y mode selection screen appears.

Use the four-way controller (23) to select Y, Z, Z, a, b or b.

There are two types of icons: a dog and cat icon. Your choice of dog or cat icon does not affect the resulting picture, so you can choose whichever you prefer. Choose an icon (white, gray, or black) whose tone best matches your pet’s coat or fur.

Press the 4 button.

The selected icon appears and the camera returns to capture status. The camera tracks the subject and continues to focus on it. When the camera detects a person’s face,

the Face Detection function is activated and the face detection frame appears (p.69).

Cancel

03/03/2011

14:25

Press the shutter release button fully.

The picture is taken.

When [Focusing Area] (p.91) is set to J (Multiple) or K (Spot), focus

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 11

can be locked by pressing the shutter release button halfway.

Taking Pictures of Sports and Leisure Activities (Sport/Surf & Snow Mode)

Sport

Surf & Snow

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select \ or Q.

Press the 4 button.

The \ or Q mode is selected and the camera returns to capture status. In \ mode, the camera tracks the subject and continues to focus on it. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken.

When [Focusing Area] (p.91) is set to J (Multiple) or K (Spot) in \ mode, focus can be locked by pressing the shutter release button halfway.

For a fast moving subject. Tracks the subject until the picture is taken.

For bright images such as sand or snow. Accurately meters for bright scenes.

03/03/2011

14:25

Taking Pictures

Framing Your Pictures (Frame Composite Mode)

3 8

0 3 / 0 3 / 2 0 11

1 4 : 2 5

In N (Frame Composite) mode, you can take pictures using the frames stored in the camera.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select N.

Taking Pictures

Press the 4 button.

The 9-frame display of the frame selection screen appears.

Use the four-way controller (2345) to choose the frame you want to use.

Press the zoom button towards the right (y).

The selected frame appears in single-image display. You can choose another frame using either of the following operations.

Four-way controller (45) Press to choose a different frame.

Zoom button towards the left (f)

Returns to the 9-frame display of the frame selection screen, and then lets you choose a different frame in the same way as Step 4.

OKOKOK

Press the 4 button.

The framed image appears on the display. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

03/ 03/ 2011

1 4:25

Press the shutter release button fully.

The picture is taken.

• The number of recorded pixels is fixed at h (2048×1536).

• Frames cannot be added to movies.

• By default, three frames are built-in to the camera. These frames are not deleted even if the built -in memory is formatted.

• The CD-ROM (S-SW116) supplied with the camera contains 90 optional frames. To save the frames into the built-in memory, copy the files from the CD-ROM (p.147).

Adding a Frame to a captured image 1p.145

Taking Pictures Indoors (Party Mode)

The B (Party) mode is suitable for taking pictures indoors, such as snapshots at parties.

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select B.

Press the 4 button.

The B mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Taking Pictures

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken.

Taking Pictures of Text (Text Mode)

Can ce l

3 8

1 4 : 2 5

0 3 / 0 3 / 2 0 11

The c (Text) mode allows you to take clear pictures of written text. This is convenient for capturing a digital copy of an important document or enhancing the legibility of small print.

Color Main tains the original color of the text.

Neg. Color Reverses the color of the text.

B & W Turns the color of the text into black and white.

Neg. B & W Turns the color of the text into reversed black and white.

Taking Pictures

Press the four-way controller (3) in A mode.

The Capture Mode Palette appears.

Use the four-way controller (2345) to select c.

Press the 4 button.

The c mode selection screen appears.

Cancel

Use the four-way controller (23) to select c, d, c or d.

Press the 4 button.

The selected icon appears and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken.

03/03/2011

14:25

Taking Pictures Using the Miniature/HDR Filter

Sel ec t the r ange to bl ur

Can ce l

3 8

0 3 / 0 3 / 2 0 11

1 4 : 2 5

In o (Miniature)/p (HDR) Filter mode, you can take impressive pictures using the filter.

o Miniature Filter

p HDR Filter For capturing an image with HDR-like effect.

Press the four-way controller (3) in A mode.

For capturing an image where the subject looks like a miniature object. The number of recorded pixels is fixed at f (2592×1944).

The Capture Mode Palette appears.

Use the four-way controller (2345) to select o or p.

Press the 4 button.

When the o mode is selected, the screen for selecting the area to be blurred is displayed. When the p mode is selected, proceed to Step 6.

Use the four-way controller (45) to select an option.

Focuses on the bottom of the image and blurs the top.

Focuses on the center of the image and blurs the top and bottom.

Focuses on the top of the image and blurs the bottom.

Press the 4 button.

The o or p mode is selected and the camera returns to capture status. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Select the range to blur

OKMENU

Cancel

OKCancel

03/03/2011

14:25

Taking Pictures

D r i v e M o d e

S e l f - t i m e r

O K

C a n c e l

Press the shutter release button fully.

The picture is taken.

Processing the captured images by using the Miniature/HDR filter 1 p.138

Using the Camera’s Self-timer

In Self-timer mode, the picture is taken ten seconds or two seconds after the shutter release button is pressed. Stabilize the camera with a tripod or other support when taking a picture

Taking Pictures

using the self-timer.

Self-timer

2 sec. Self-timer

Press the four-way controller (2) in A mode.

The [Drive Mode] screen appears.

Use the four-way controller (45) to select g and press

Use this mode when you want to be included in a group picture. The picture is taken approximately ten seconds after the shutter release button is pressed.

Use this mode to avoid camera shake. The picture is taken approximately two seconds after the shutter release button is pressed.

the four-way controller (3).

Use the four-way controller (45) to select g or Z and press the 4 button.

The camera is ready to take the picture using the self-timer. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

The picture is taken ten seconds or two seconds later.

Drive Mode

Self-timer

Cancel

Focusing may be compromised if you move the camera while the self-

O K

C a n c e l

D r i v e M o d e

C o n t i n u o u s S h o o t i n g

timer lamp is blinking when taking still pictures.

•

For movies, recording will start ten seconds or two seconds after the C button is pressed.

•

Press the shutter release button halfway while the self-timer is running to stop the countdown and press fully to restart the countdown.

• Z cannot be selected while the 9 (Green) mode settings remain at default . However, it can be selected if you select Z in another shooting mode first, and then switch the shooting mode to 9.

Taking a Series of Pictures (Continuous Shooting/Burst Shooting Mode)

In these modes, pictures are taken continuously as long as the shutter release button is pressed.

Each time an image is taken, it is saved in the memory before the

Continuous

Shooting

Burst

Shooting

The number of pictures that can be taken consecutively and the frame rate per second vary depending on the shooting condition.

Press the four-way controller (2) in A mode.

The [Drive Mode] screen appears.

next image is taken. The h igher the image quality, the longer the interval between shots. You can continue shooting until the capacity of the SD Memory Card or the built-in memory is full.

The number of recorded pixels is fixed at f (2592×1944) and pictures are taken consecutively.

Taking Pictures

Use the four-way controller (45) to select j or q and press the 4 button.

The camera is ready to take a series of pictures.

Drive Mode

Continuous Shooting

Cancel

Press the shutter release button halfway.

The focus frame on the display turns green when the camera focuses on the subject at the correct distance.

Press the shutter release button fully.

Pictures are taken continuously as long as you keep the shutter release button pressed.

• The flash does not discharge in j and q modes.

• j and q cannot be selected in 9 (Green), S (Fireworks), N

Taking Pictures

(Frame Composite), o (Miniature Filter) or p (HDR Filter) mode, or when recording a movie.

• Digital Zoom and Intelligent Zoom are not available in q mode.

• The focus, exposure and white balance are locked with the first shot.

• When [Face Detection] is set to [On] (p.69), it works only for the first shot.

• The Blink Detection function works only for the last shot.

•In b (Auto Picture) mode, pictures are taken consecutively in the shooting mode selected for the first shot.

Taking Pictures Using the Remote Control Unit (Optional)

You can use the optional remote control (p.208) to take pictures while you are away from the camera. Stabilize the camera with a tripod or other support when taking a picture using the remote control unit.

i Remote Co ntrol

The self-timer lamp blinks quickly and the picture is taken approximately three seconds after the shutter release button on the remote control unit is pressed.

0-sec Remote Control

The picture is taken immediately after the shutter release button on the remote control unit is pressed.

Press the four-way controller (2) in A mode.

The [Drive Mode] screen appears.

Use the four-way controller (45) to select i and press the four-way controller (3).

Use the four-way controller (45) to select i or h and press the 4 button.

The self-timer lamp begins to blink slowly and the camera is ready to take a picture with the remote control. When the camera detects a person’s face, the Face Detection function is activated and the face detection frame appears (p.69).

Point the remote control at the remote control receiver and press the shutter release button on the remote control.

The focus frame turns green when the subject is in focus and the camera takes a picture.

• The operating range is approx. 4 m (13 ft.) from the front of the camera when using the remote control unit.

• The camera takes a picture even if the subject is out of focus.

• Press the shutter release button on the camera halfway while the selftimer is running to stop the countdown, and press the shutter release button on the remote control again to restart the countdown.

• You cannot take a picture using the remote control unit in 9 (Green) mode.

• The self-timer lamp does not blink in Y (Pet) mode.

• When using the REMOTE CONTROL WATERPROOF O-RC1, you can record a movie by pressing the { button on the remote control or the C button on the camera.

• You can also zoom in and out using the Zoom button on the remote control.

Taking Pictures

Setting the Shooting Functions

Aut o

Fla sh Mode

Can ce l

Selecting the Flash Mode

Taking Pictures

Auto

Flash Off

Flash On The flash discharges regardless of the brightness.

Auto + Red-eye

Flash On + Red-eye

The flash discharges automatically depending on the light conditions. If the Face Detection function is activated, the flash mode is automatically set to d.

The flash does not discharge, regardless of the brightness. Use this mode to take pictures where flash photography is prohibited.

This mode reduces the phenome non of red eyes caused by the light from the flash being reflected in the subject’s eyes. The flash discharges automatically. A pr e-flash discharges before the main flash.

This mode reduces the phenome non of red eyes caused by the light from the flash being reflected in the subject’s eyes. The flash discharges regardless of the light conditions. A pre-flash discharges before the main flash.

• The flash mode is fixed at a in the following situations:

- When S (Fireworks) is selected as the shooting mode

- When recording a movie

- When j (Continuous Shooting) or q (Burst Shooting) is selected

as the drive mode

- When s (Infinity) is selected as the focus mode

•In 9 (Green) mode, you can only select , or a.

•In A (Night Scene) mode, you cannot select , and c.

Using the flash when capturing images at a close distance may cause the unevenness of the light distribution.

Press the four-way controller (4) in A mode.

The [Flash Mode] screen appears. The flash mode changes each time the button is pressed. You can also change the setting using the four-way controller (23).

Flash Mode

Auto

Cancel

F o c u s M o d e

S t a n d a r d

O K

C a n c e l

Press the 4 button.

The setting is saved and the camera returns to capture status.

About the red-eye phenomenon

Taking pictures using the flash may cause the subject’s eyes to appear red in the resulting picture. This phenomenon occurs when the light from the flash is reflected in the subject’s eyes. It can be reduced by illuminating the area around the subject or moving closer to the subject and zooming out to a wider angle. Setting the flash mode to c or d is also an effective way of reducing red eyes. If the subject’s eyes appear red despite such precautions, they can be corrected by the red-eye compensation function (p.144).

Saving the Flash Mode setting 1p.113

Selecting the Focus Mode

This mode is used when the distanc e to the subject is 40 cm (16 in.)

Standard

Macro

Super Macro

Pan Focus

Infinity

Manual Focus This mode lets you adjust the focus manually.

or more. The camera i s focused on the subject in the autofocus area when the shutter release button is pressed halfway. When the subje ct is close to the camera, the Auto-Macro function is activated and q appears on the display.

This mode is used when the distance to the subject is approx. 10 cm to 50 cm (4 in. to 20 in.). The camera is focused on the subject in the autofocus area when the shutter release button is pressed halfway.

This mode is used when the distance to the subject is approx. 5 cm to 30 cm (2 i n. to 12 in.). The c amera is focused on the subject in the autofocus area when the shutter release button is pressed halfway.

This mode is used when you ask someone to take pictures for you, or when taking pi ctures of t he scenery thro ugh the win dow of a car or train. The entire picture, from the front to the back, is focused.

This mode is used for taking distant objects. The flash is set to a (Flash Off).

Taking Pictures

Press the four-way controller (5) in A mode.

The [Focus Mode] screen appears. The focus mode changes each time the button is pressed. You can also change the setting using the four-way controller (23).

F ocus Mode

Cancel

Standard

F o c u s M o d e

M a n u a l F o c u s

O K

C a n c e l

1.0

\ indicator

Press the 4 button.

The setting is saved and the camera returns to capture status.

•In 9 (Green) mode, you can only select =, q or 3.

• The focus mode is fixed at s in S (Fireworks) mode.

• When shooting with q selected, if the subject is further than 50 cm away, the camera automatically focuses to

∞ (Infinity). By pressing the

shutter release button fully, you can also take a picture even when the focus is not set.

Saving the Focus Mode setting 1 p.113

Taking Pictures

To Set the Focus Manually (Manual Focus)

Press the four-way controller (5) in A mode.

The [Focus Mode] screen appears.

Press the four-way controller (5) to select \.

Press the 4 button.

The central portion of the image is magnified to full screen on the display.

Use the four-way controller (23) to adjust the focus.

The \ indicator appears on the display to indicate the approximate distance to the subject. Adjust the focus using the indicator as a guide.

2 for distant focus 3 for closer focus

Cancel

1.0

F ocus Mode

M anual Focus

Press the 4 button.

The focus is fixed and the camera returns to capture status. After the focus is fixed, you can press the four-way controller (5) again to display the \ indicator and readjust the focus.

The shooting mode and drive mode cannot be changed while the \ indicator is displayed.

To switch from \ to another focus mode, press the four-way controller (5) while the \ indicator is displayed.

To Set the Focusing Area

You can change the autofocus area (Focusing Area).

Multiple Normal autofocus area

Spot The autofocus area becomes smaller.

Automatic Tracking AF Keeps moving subjects in focus.

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [Focusing Area].

Press the four-way controller (5).

A pull-down menu appears.

Taking Pictures

Use the four-way controller (23) to change the focusing area setting.

Press the 4 button.

The setting is saved.

Rec. Mode

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

Cancel

1/3

AWB

0.0

Clearer

1 4 : 2 5

383838

03/03/201103 /0 3 / 20 1103/03/2011

14:25

Press the 3 button.

The camera returns to capture status.

•In 9 (Green) and b (Auto Picture) modes, the focusing area is fixed at J.

• If you change the [Focusing Area] setting frequently, you can save time by assigning it to the Green button (p.107).

Selecting the Number of Recorded Pixels

Taking Pictures

You can choose from six recorded pixels settings for still pictures. The larger the number of recorded pixels, the clearer the details will appear when you print your picture. As the quality of the printed picture also depends on the image quality, exposure control, resolution of the printer, and other factors, you do not need to select more than the required number of recorded pixels. The more pixels there are, the larger the picture and the bigger the file size. Refer to the following table for the appropriate settings according to expected usage.

Recorded Pixe ls Expected Usage

g 4288×3216

l 3216×3216

i 4224×2376 6 3072×2304

h 1920×1080 m 640× 4 80

The default setting is g.

If you select i or h, the aspect ratio of the image is 16:9 and the monitor display for recording and playback is as shown on the r ight.

For printing high quality photos or A4-size or larger prints, or editing images on a computer.

For making postcard-size prints.

For posting on a website or attaching to e-mail.

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [Recorded Pixels].

Press the four-way controller (5).

A pull-down menu appears.

Use the four-way controller (23) to change the number of recorded pixels.

Press the 4 button.

The setting is saved.

Press the 3 button.

The camera returns to capture status.

• The number of recorded pixels in 9 (Green) mode is fixed at g.

• The number of recorded pixels in N (Frame Composite) mode is fixed at h.

• The number of recorded pixels in o (Miniature Filter), c (Digital SR), or q (Burst Shooting) mode is fixed at f.

• If you change the [Recorded Pixels] setting frequently, you can save time by assigning it to the Green button (p.107).

Recordable Image No.

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

Cancel

Taking Pictures

Compensating for Exposure (EV Compensation)

You can adjust the overall brightness of the picture. Use this function to take pictures that are intentionally overexposed or underexposed.

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [EV

Taking Pictures

Compensation].

Use the four-way controller (45) to select the EV value.

To brighten, select a positive (+) value. To darken, select a negative (–) value. You can choose the EV setting in the range of –2.0 EV to +2.0 EV in 1/3 EV steps.

Press the 3 button.

The camera returns to capture status.

• When the histogram is displayed in still picture capture mode/playback mode, you can check the exposure (p.26).

• The EV compensation function cannot be used in 9 (Green) or b (Auto Picture) mode.

• If you change the [EV Compensation] setting frequently, you can save time by assigning it to the Green button (p.107).

Rec. Mode

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

ၭၭExit

1/3

AWB

Auto

0.0

Saving the EV Compensation value setting 1p.113

Correcting the Brightness (D-Range Setting)

1 4 : 2 5

3 8

0 3 / 0 3 / 2 0 1 1

Expands the dynamic range and enables a more ample gradation expression, and reduces the occurrence of overexposed and underexposed areas. Highlight Correction adjusts the overexposed areas and Shadow Correction adjusts the underexposed areas.

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [D-Range Setting].

Press the four-way controller (5).

The [D-Range Setting] screen appears.

Use the four-way controller (23) to select [Highlight Correction] or [Shadow Correction].

Use the four-way controller (45) to select O (On) or P (Off).

Press the 3 button twice.

The camera returns to capture status. The D-Range Setting icon appears on the display.

When [Highlight Correction] is set to O

When [Shadow Correction] is set to O

When [Highlight Correction] and

[Shadow Correction] are both set to O

D-Range Setting

Highlight Correction Shadow Correction

03/ 03/ 2011

1 4:25

Taking Pictures

• When [Highlight Correction] is set to O, the minimum sensitivity is ISO

125.

• If you change the [Highlight Correction] or [Shadow Correction] setting frequently, you can save time by assigning it to the Green button (p.107).

Adjusting the White Balance

White Balance

CancelCan ce l

AutoA uto

OKOKCancel

Auto

You can take pictures in natural colors by adjusting the white balance according to the light conditions at the time of shooting.

Auto The camera adjusts the white balance automatically.

Daylight Use this mode when taking pictures outside in sunligh t.

Shade Use this mode when taking pictures outside in the shade.

Tungsten Light

Taking Pictures

Fluores. Light Use this mode when taking pictures unde r fluorescent light.

Manual Use this mode when adjusting the white balance manually.

• Set another white balance setting if you are not satisfied with the color balance of pictures taken with the [White Balance] set to F.

• Depending on the selected shooting mode, the white balance setting may not be changed. Refer to “Functions Available for Each Shooting Mode” (p.196) for details.

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (23) to select [White Balance].

Press the four-way controller (5).

The [White Balance] screen appears.

Use this mode when taking pictures under electric or other tungsten light.

Use the four-way controller (23) to change the setting.

You can check the result of selected white balance setting on the preview image each time you press the four-way controller (23).

Press the 4 button.

The setting is saved.

Press the 3 button.

The camera returns to capture status.

If you change the [White Balance] setting frequently, you can save time by assigning it to the Green button (p.107).

Saving the White Balance setting 1p.113

To Set the White Balance Manually

Have a blank sheet of white paper or similar material ready.

In the [White Balance] screen, use the four-way controller (23) to select K (Manual).

Point the camera at the blank

White Balance

sheet of paper or other material so that it fills the frame displayed in the center of the screen.

SHUTTER

Cancel

Press the shutter release button fully.

The white balance is automatically adjusted.

Press the 4 button.

The setting is saved and the [A Rec. Mode] menu reappears.

Press the 3 button.

The camera returns to capture status.

Adjust

Taking Pictures

Setting the AE Metering

You can set the area of the screen where the brightness is metered to determine the exposure.

Multi-segment

metering

Center-weighted

metering

Spot AE metering

The camera divides the image into 256 areas, meters the brightness and determines the exposure.

The camera takes a reading of the overall brightness of the picture with the center of the image having more influ ence on the exposure.

The camera determines the exposure by metering the brightness only at the center of the image.

Taking Pictures

Press the 3 button in A mode.

The [A Rec. Mode] menu appears.

Use the four-way controller (

Press the four-way controller (5).

A pull-down menu appears.

Use the four-way controller (23) to select the AE Metering setting.

Press the 4 button.

The setting is saved.

Press the 3 button.

The camera returns to capture status.

) to select [AE Metering].

Rec. Mode

Recorded Pixels White Balance Focusing Area AE Metering Sensitivity EV Compensation

Cancel

1/3

AWB

Pentax S1 User Manual [ru]

Specifications and Main Features

Frequently Asked Questions

User Manual

Using Your Camera Safely

Care to be Taken During Handling

Contents

Composition of the Operating Manual

Camera Features

Checking the Contents of the Package

Names of Parts

Names of Operating Parts

Monitor Indications

1 Getting Started

Attaching the Strap

Powering the Camera

Installing the Battery

Charging the Battery

Installing an SD Memory Card

Number of Recordable Images

Turning the Camera On and Off

Starting-up in the Playback Mode

Initial Settings

Setting the Display Language

Setting the Date and Time

2 Common Operations

Understanding the Button Functions

A Mode

Q Mode

Switching Between A Mode and Q Mode

Setting the Camera Functions

Operating the Menus

Menu List

3 Taking Pictures

Taking Still Pictures

Taking Pictures

Setting the Shooting Mode

Using the Face Detection Function

Taking Pictures Automatically (Auto Picture Mode)

Taking Pictures in the Custom Settings (Program Mode)

Taking Pictures in the Basic Mode (Green Mode)

Using the Zoom

Taking Pictures of Dark Scenes (Night Scene/Night Scene Portrait/Digital SR/Fireworks/Candlelight Mode)

Taking Pictures of People (Portrait/Natural Skin Tone Mode)

Taking Pictures of Children (Kids Mode)

Taking Pictures of Your Pet (Pet Mode)

Taking Pictures of Sports and Leisure Activities (Sport/Surf & Snow Mode)

Framing Your Pictures (Frame Composite Mode)

Taking Pictures Indoors (Party Mode)

Taking Pictures of Text (Text Mode)

Taking Pictures Using the Miniature/HDR Filter

Using the Camera’s Self-timer

Taking a Series of Pictures (Continuous Shooting/Burst Shooting Mode)

Taking Pictures Using the Remote Control Unit (Optional)

Setting the Shooting Functions

Selecting the Flash Mode

Selecting the Focus Mode

Selecting the Number of Recorded Pixels

Compensating for Exposure (EV Compensation)

Correcting the Brightness (D-Range Setting)

Adjusting the White Balance

Setting the AE Metering
