ADEMCO 6160RF

Keypad/Transceiver

Installation and Setup Guide

GENERAL INFORMATION

The ADEMCO 6160RF keypad/transceiver is a combination unit that combines the functions of the following
devices:

• 6160 Alphanumeric Addressable Keypad

• 5881H RF Receiver

• 5800TM Transmitter Module

The 6160RF Keypad/Transceiver may be used on any control panel that supports 5800 Series wireless devices
(e.g., VISTA-10P, VISTA-15P, VISTA-20P).

FEATURES

• Supports wireless key transmitters (e.g.; 5804) and bi-directional transmitters (e.g.; 5804BD, 5828/5828V).

• Supports wireless keys with high-security (encryption) capability (e.g.; 5804E).

• Provides a nominal range of 200 feet' for RF transmitters (some transmitters have a shorter range).

• Supports RF jam detection when the receiver is enabled.

• Capable of sending status signals (Armed, Ready, etc.) to bi-directional units such as 5804BD, 5804BDV and

5828/5828V.

UUUU

The following 5800 series transmitters are not intended for use in UL installations: 5802, 5804, 5804BD, 5804BDV, 5804E,

LLLL

5814, 5816TEMP, 5819, 5819BRS, 5819WHS, 5828/5828V and 5850.

INSTALLING THE 6160RF

Locate the 6160RF in an area and at a height where
it is convenient for user operation. The 6160RF must
be at least 10 ft from the control panel to ensure
proper operation of the RF receiver.

Mounting and Wiring

The 6160RF has terminal blocks for connection to
power and data wires. Removing the keypad’s case
back provides access to the terminal blocks.

The 6160RF can be surface mounted directly to
walls, or to a single- or double-gang electrical box.
Follow these steps to mount and wire the keypad:

1. Push the two case release snaps at the bottom of
the keypad with the blade of a medium
screwdriver (this will push in the release snap),
then pull that side of the case back away. Insert
the screwdriver in the side of the keypad
(between the front and back case) and gently
twist to release the side locking tab. Repeat for
the other side. Refer to Figure 1 for location of the
case back release snaps and locking tabs.

Pass the wiring from the control panel through

2.

the opening in the case back. (see the control
panel’s instructions for proper run lengths.)

a. If surface wiring is being used, wiring may be

routed through the top or the bottom left-side
breakout in the case back. The breakouts must
be punched out using a screwdriver before
mounting the case back.

b. If desired, wires may be strain-relieved to the

wire tie point on the inside of the case back
with a tie wrap (not supplied).

3. Mount the case back to a wall or to an electrical
box using the 25mm-long self-tapping screws
supplied (mollies for drywall are not supplied).

4.

Connect the power and data wires from the
control panel to the terminals on the 6160RF as
indicated in Figure 2 and Table 1.

ARMED

READY

NOTE:

TO REMOVE REAR COVER
PUSH IN THE TWO MOUNTING
SNAPS LOCATED ALONG THE
BOTTOM OF THE KEYPAD
AND LIFT COVER UP.

MOUNTING

RELEASE

SNAPS

Figure 1. Removing the Case Back

LOCKING

TAB

6160RF-003-V1

+

Y

G

+

+++

WIRING TERMINALS

(TO CONTROL PANEL)

Figure 2 - 6160RF Wiring Details

6160RF-002-V1

Table 1 - Wiring Table

Keypad Control Panel Wire Color

G▼ (Data Out)

- -Aux Pwr (GND) Black
+ +Aux Pwr Red

▲Y (Data In)

Data In Green

Data Out Yellow

APPLICATION GUIDELINES FOR THE 6160RF

Use the following guidelines when planning an installation:

If… And… Then…

This is the only
transceiver on
the system,

You want to use both
the receiver and
transmitter function
on a single-partition
system,

• Set the keypad to a device address assigned to the desired partition.*

• Enable the receiver.

• Program a system House ID in the control panel (this will enable the transmitter

function).**

• Set the wireless devices that will communicate with this 6160RF to the same

system House ID.

5. Reattach the keypad to the mounted case back.
Attach the top of the keypad first, and then
press the bottom section down until it snaps
into place securely.

6. Peel off protective film on the LED panel and
install the keypad labels as required.

There is another
receiver or
transceiver on
the system,

You want to use only
the transmitter
function on a second
partition,

• Set the keypad to a device address assigned to the desired partition.*

• Disable the receiver.

• Program a DIFFERENT House ID in the 6160RF than is programmed in the control

panel.*/ **

• Set the wireless devices that will communicate with this 6160RF to the same

House ID as the 6160RF.

You want to use only
the transmitter
function on a single­partition system,

• Set the keypad to a device address assigned to the Partition 1.

• Disable the receiver.

• Program a House ID in the 6160RF that matches the system House ID

programmed in the control panel.*

• Set the wireless devices that will communicate with this 6160RF to the same

House ID.

Notes:

* On VISTA-40 panels and above, wireless keypads (e.g., 5804BD) can only be used on a single partition. This
partition is programmed in field 1*48, and must match the partition assigned to the 6160RF. Wireless keys can
be used on more than one partition, using a House ID programmed in the 6160RF and the devices. In this case,
the wireless keys must be assigned to the same partition as the 6160RF.

** On VISTA-20P panels, the 6160RF will use the House ID programmed in the panel for the partition to which
it is assigned. Wireless keypads can only be used on Partition 1.

PROGRAMMING THE 6160RF

Refer to the following procedure to program the 6160RF:

STEP DESCRIPTION

1. Enter the program mode by pressing the [1] and [3] keys simultaneously
for a few seconds within 60 seconds after applying power.

2. (Keypad Address) Enter the two-digit keypad address. Press the [✻] key
to continue.

Notes: (1) Refer to the control panel’s installation instructions for the

(2) On the VISTA-40 and above the 6160RF’s partition assignment must

3. (Receiver Enable) Enter [1] to enable, or [0] to disable Receiver. Enable
the receiver if RF transmitters or wireless keypads are programmed into
the control and no other receivers are enabled. Press the [✻] key to
continue.

acceptable keypad addresses.

match the RF keypad partition assignment programmed in field
(1*48).

- 2 -

DISPLAY

CON ADDRESS

CON ADDRESS = XX

CON ADDRESS CON ADDRESS

RECEIVER

RECEIVER

RECEIVERRECEIVER

=

OFF]

ON [0

ON [0

ON [0ON [0

OFF]

OFF] OFF]

XX

XX XX

CHOICES

00-31

1= ON
0 = OFF
