Pelco U1-1C Specsheet

PRODUCT SPECIFICATION

video management solutions

VideoXpert™ Software Distributions

SCALABLE VIDEO MANAGEMENT AND SURVEILLANCE SOFTWARE

Product Features

• Available in software-only distribution, for measured performance or

convenient migration of customer-owned hardware

• Designed to eliminate single points of failure and ensure reliability

though fault-tolerant software, distributed architecture, and multiple
levels of redundancy

• Provides scalability and modular expansion

• Provides migration paths for Endura® and Digital Sentry® systems

• Aggregates VMS networks and manage all video through a single

system (VideoXpert Ultimate distributions)

• Microsoft® Windows®-based for easy setup and maintenance

• Browser-based administration interface provides management

capabilities without a hard client

• Extensible through plug-ins including mapping, video information

overlays (eConnect), and license plate recognition (PlateSmart)

• Create and assign tags, organizing network resources as you see fit

• ONVIF compliant: Supports ONVIF S compliant cameras and devices

• Investigation mode enables operators to synchronize video playback

and export investigative playlists covering scenes of interest

• Supported languages: German, Spanish, French, Italian, Korean,

Polish, Portuguese, Russian, Turkish, Arabic, Japanese, and Chinese
(Simplified)

• Workstations available with 3D mouse and programmable keyboard

accessories to maximize operator control

VideoXpert is a video management solution designed to fit
surveillance operations of any size. Whether your operation has 100
cameras or 10,000, VideoXpert presents a solution to display, record,
and manage your video resources.

VideoXpert products are available as software distributions that you
can install on your own hardware, even existing video management
hardware. This allows you to repurpose your own hardware and
bring existing systems forward into VideoXpert.

Designed for Windows platforms, VideoXpert is easy to install, quick
to setup, and should be familiar to most users. The system supports
unicast and multicast transmission modes, making it easy to adapt to
your current network scheme. Simplified interfaces ensure that users
can adopt and use the system with relative ease. From the Web­based Admin Portal, you can configure the system, manage the
database of devices, configure users and permissions, and assign
cameras to recording devices. Through the Ops Center software,
operators gain access to high quality video and powerful
investigative tools.

VideoXpert servers can be clustered to provide redundancy and
scalability within a single environment, enabling the system to grow
in tune with your surveillance needs. As you add cameras, users, or
recording devices, you can add servers and storage, enabling the
system to support the additional resources and perform to your
expectations. VideoXpert Ultimate can even aggregate other

VideoXpert systems, tying multiple VideoXpert systems into a single
interface. Through aggregation, administrators can build and
maintain a concerted video management system containing multiple
sites.

As distributed systems, VideoXpert Ultimate and Enterprise
architecture ensure that there is no single point of failure that would
compromise the system or video recording services. The system is
designed with multiple levels of redundancy through sophisticated
failover and redundant recording schemes, maximizing system
uptime. The architecture allows individual components to continue
operating in the event of failures elsewhere in the system.

VideoXpert can integrate with physical security systems and other
building systems to deliver situational awareness and control. Built
around open standards, VideoXpert includes a complete application
programing interface (API), software development kits (SDKs), and
dedicated technical support, allowing other systems’ manufacturers
to develop interfaces leveraging VideoXpert’s capabilities.
VideoXpert also supports third-party IP cameras, allowing users to
choose across hundreds of camera options from Pelco and third-party
partners when configuring a system.

International Standards

Organization Registered Firm;

ISO 9001 Quality System

C4037 / REVISED 9-12-16

TECHNICAL SPECIFICATIONS

VideoXpert consists of four major components: Core, Media
Gateway, Ops Center, and Storage. The Core performs central
management operations, maintaining the system database,
administering user rights and permissions, routing traffic, and other
central operations. The Media Gateway handles all requests for
video, ensuring that users at all levels of network access, LAN, WAN
and even cellular, receive the right type of video for their application.
The Ops Center Client is the operator console, providing an intuitive,
but powerful interface from which users can access and investigate
video throughout the system. And Storage (VXS) records video and
delivers recorded video to users.

CORE

The Core is the heart of the VideoXpert system, it maintains the
database of cameras and recording devices. The Core also hosts a
convenient Web interface called the Admin Portal, from which you
can configure and manage the system. Through the Admin Portal,
you can administer user accounts and permissions, determining the
system functions and devices users can access. You can create and
assign “tags” to quickly organize cameras and devices within the
system. You can also configure and respond to events within the
system.

The Core browser provides basic access to video streaming
resources, ensuring that users with appropriate permissions can
view video from the system even without a hard client, using just a
standard web browser.

ensuring a seamless viewing experience. With appropriate
permissions, users can also share workspaces and even use the
same tabs simultaneously, enabling collaboration within your
surveillance operations.

The Ops Center also provides an Investigation Mode, through which
users can create playlists from multiple video clips encompassing
important scenes from an investigation. Users can export and
encrypt their investigations, storing clips relevant to their
investigation independent of the system’s network video storage for
evidentiary safe-keeping and quick access.

The Ops Center supports modular plug-ins, exposing additional
functionality for operators as required by your surveillance
operations. The Mapping plug-in enables operators to arrange and
find cameras on maps. Through mapping, operators can find and the
camera providing the view they need, when they need it. The
PlateSmart plug-in exposes license plate numbers, to track vehicles
as they come and go. The eConnect plug-in displays real-time
gaming information as a video overlay.

MEDIA GATEWAY

The Media Gateway routes video and audio traffic to appropriate
users as requested. When a user requests a video stream, the Core
fields the request and determines whether the user possesses the
appropriate permissions to view the video stream. If the user can
view the stream, the Media Gateway connects the user with the
appropriate device — camera, encoder, or recorder as necessary.

Like Core servers, Media Gateways can be added to VideoXpert
modularly, allowing a system with 1000 cameras to support 20 users,
or a system with 100 cameras to support 200 users. You can add
Media Gateways to the system in tune with media delivery needs.

CORE/MEDIA GATEWAY COMBINATION

While you can leverage separate Core and Media Gateway servers
for systems of sufficient scale, a single, combined, Core and Media
Gateway will support most VideoXpert environments. You can run
both software applications on a single server, providing the complete
range of VideoXpert functionality that you would expect for systems
with fewer than 2000 cameras and 100 simultaneous users.

OPS CENTER

The Ops Center is a Windows-based application, providing an
optimal environment from which users can watch live and recorded
video. Through the Ops Center, users can configure and recall
complete workspaces, enabling operators to quickly log in and get to
work.

STORAGE

VideoXpert Storage software (VXS) is the recording platform that
captures recorded video for your VideoXpert system. Storage
software is designed for high availability and maintains performance
levels in both normal and RAID error conditions, preventing dips in
performance and ensuring that users can always obtain the video
they need through VideoXpert.

VideoXpert Storage natively supports third-party IP cameras via
ONVIF S and driver packages, so you can bring your cameras into
VideoXpert without expensive translation interfaces.

You can configure Storage through the same Web interface you use
to configure the rest of your VideoXpert system, making it easy to set
recording schedules and assign cameras to your storage servers.
Storage supports motion, alarm, and bump-on-alarm style recording,
so you can always capture events relevant to your environment at
high quality. Storage also supports redundant recording, ensuring
that VideoXpert continues recording video even if a single Storage
server falls offline.

The application provides mechanisms to sort cameras by tags and
other criteria, making it easy for users to find the cameras they need.
Users can switch between live and recorded video on the fly,

TECHNICAL SPECIFICATIONS

LOCAL

OPERATORS

LOCAL

OPERATORS

REMOTE

OBSERVER

CORE/

MEDIA GATEWAY

3RD PARTY

SYSTEM

CUSTOMER FACILITIES

CUSTOMER FACILITIES

REMOTE CLIENT

OPS CENTER CLIENT

LOCAL

ADMINISTRATORS

ADMIN PORTAL

STORAGE

SERVER

eConnect

ADMIN PORTAL

ULTIMATE SYSTEM

ENTERPRISE

SYSTEM TOPOLOGY

VideoXpert Ultimate allows for expansion at any level of your security environment. Your system begins with a single server running Core and Media
Gateway software. Your system requires the OPS Center Clients from which to view video and Storage server for recordings. As your surveillance
needs grow, you can add servers to expand modularly within a single environment, or you can aggregate multiple VideoXpert systems to provide a
single point of access for distributed video management networks.

VIDEOXPERT ACCESSORY SERVER

You can install the VideoXpert Accessory Server to provide NTP, basic DHCP, active failover, and load balancing services for small to moderately sized
networks. The Accessory Server offers a native, multipurpose solution to control your time and addressing services from within VideoXpert.

When acting as a load balancer, the Accessory Server bridges multiple Core/Media Gateway (CMG) servers, optimizing performance and providing
redundancy for your VideoXpert network. With the Accessory Server, you can easily increase your VideoXpert network’s capacity and ensure the
system’s uptime so that users always have access to video.

ADVANCED OPERATOR CONTROLS

In addition to the standard keyboard and mouse, Ops Center workstations support an Enhanced Keyboard, and Enhanced Mouse, and the
KBD5000.The Enhanced keyboard includes programmable keys to which operators can map shortcuts to their favorite tabs and workspaces; The new
Enhanced Mouse or your existing KBD5000 are mapped to the full range of Ops Center controls; an operator can perform any and all operations using
either control.

TECHNICAL SPECIFICATIONS

MINIMUM SYSTEM
REQUIREMENTS

Processor Intel® Xeon® E3-1275 v3

Memory 32 GB DDR3 ECC 8 GB DDR3 Non-ECC 32 GB DDR3 ECC

Operating System Microsoft

Minimum Storage Required 480 GB 120 GB 120 GB 200 GB

Video System Intel HD Graphics P4700 or better

Interface Gigabit Ethernet (1000Base-T)

1

Software distributions tested without antivirus software installed.

1

Core/CMG Media Gateway Ops Center Storage

®

Intel

Xeon®

E3-1276 v3

®

Windows® Server 2012

Windows 7

Ultimate SP1

®

Microsoft

are designed to be configured

Windows® Server

2012

VGA interface; VXS models

remotely through web

interface.

SOFTWARE LICENSE, SERVER, AND WORKSTATION MODELS

Use the following table to create a model number for your VideoXpert software package. Your model number consists of the distribution you want to choose and the
model/software product you want to install. For example, an Enterprise Core licenses is modeled “E1-COR-SW”. For VideoXpert Storage and Aggregation features, you
must use camera licenses; each camera utilizing Storage or Aggregation will consume a single license (available in single or 32-count packages).

Note: Ops Center software does not require a license. You can install the software on any workstation meeting the system requirements.

Due to the complexity of network and system design for larger distributions, VideoXpert Ultimate requires either training certification, or that the installation be
performed by Pelco Professional Services. While not required for Enterprise distributions, it is strongly recommended that system installers and administrators be Pelco­certified.

Distribution Model Description

E1 BASE Enterprise base license, including one Core, one Media Gateway, one VXS license, and 32 camera licenses

COR-SW Core software license

MGW-SW Media Gateway software license

VXS-SW Storage software license

NSM-1UP Upgrade license enabling NSM5200 models to support VideoXpert systems

(Ultimate) U1

(Enterprise) E1

U1 AGG-1C (Optional) Ultimate site upgrade license for managing one camera

DSS-1UP Upgrade license enabling DS servers to serve as recorders within VideoXpert

1C-SUP1 Software upgrade subscription; entitles you to upgrades for one year

1C-SUP3 Software upgrade subscription; entitles you to upgrades for three years

1C Camera license for VideoXpert Storage (VXS)

32C 32 camera licenses for VideoXpert Storage (VXS)

TECHNICAL SPECIFICATIONS

Pelco, the Pelco logo, and other tra demarks associated with Pelco products referred

to in this publication are trademarks of Pe lco, Inc. or its affiliates. ONVIF and the

ONVIF logo are trademarks of ONVIF Inc. All other product names and

services are the property of their respect ive companies.

Product specifications and availability are subject to change without notice.

©Copyright 2016, Pelco, Inc. All rights reserved.

SUPPORTED LANGUAGES

The Admin Portal and Ops Center interfaces are available in:

•German

• Spanish

• French

•Italian

• Korean

• Polish

• Portuguese

• Russian

•Turkish

•Arabic

• Chinese (simplified)

• Japanese

VIDEOXPERT ACCESSORY SERVER

D09U-ACCSVR VideoXpert Accessory Server
D09U-ACCSVR-US VideoXpert Accessory Server with US power

D09U-ACCSVR-EUK VideoXpert Accessory Server with

cord

Europe/United Kingdom power cord

OPS CENTER CLIENT OPTIONAL ACCESSORIES

3DX-600-3DMOUSE Enhanced 3D Mouse and Joystick
Y-U0023-G910KBD Enhanced Keyboard
A1-KBD-3D-KIT2 Enhanced Keyboard and 3D Mouse

Combination Kit

STANDARDS/ORGANIZATIONS

• Pelco is a member of the MPEG-4 Industry Forum

• Pelco is a member of the Universal Plug and Play (UPnP) Forum, Steering
Committee

• Pelco is a member of the Universal Serial Bus (USB) Implementers Forum

• Pelco is a contributor to the International Standards for Organization /
Electrotechnical Commission (ISO/IEC) Joint Technical Committee 1
(JTC1), “Information Technology,” Subcommittee 29, Working Group 11

• Compliance, ISO/IEC 14496 standard (also known as MPEG-4)

• Compliance, International Telecommunication Union (ITU)
Recommendation G.711, “Pulse Code Modulation (PCM) of Voice
Frequencies”

• Compliance, Open Network Video Interface Forum (ONVIF) Profile S

Pelco by Schneider Electric

3500 Pelco Way, Clovis, California 93612-5699 United States

USA & Canada Tel [phone] Fax [phone]
International Tel [phone] Fax [phone]
www.pelco.com www.pelco.com/community
