Pelco SWM-CAWT User Manual

INSTALLATION

SWM-CA Series
Corner Mount Adapter

C295M-A (12/09)

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 C295M-A (12/09)

Introduction

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Only use attachments/accessories specified by the manufacturer.

6. Installation should be done only by qualified personnel and conform to all local codes.

7. Use only installation methods and materials capable of supporting four times the maximum specified load.

8. Only use replacement parts recommended by Pelco.

9. Use stainless steel hardware to fasten the mount to outdoor surfaces.

10. To prevent damage from water leakage when installing a mount outdoors on a roof or wall, apply sealant around the bolt holes between the
mount and mounting surface.

DESCRIPTION

The SWM-CA Series corner mount adapter is designed to adapt Pelco’s SWM Series wall mount to the end of a wall or the corner of a structure.
It can be used for indoor and outdoor applications. The adapter is constructed of aluminum and is available in a light gray or white polyester
powder coat finish.

The SWM-CA24 houses a 100 vA transformer that converts 120 or 230 VAC input to 24 VAC. An input voltage selector switch and fuse are
provided on the transformer module.

MODELS

SWM-CA Corner adapter with cable feedthrough for use with the SWM Series wall mount; gray finish

SWM-CAWT Same as SWM-CA except white finish

SWM-CA24 Same as SWM-CA except includes a 100 vA transformer to convert 120 or 230 VAC input to 24 VAC

PARTS LIST

Qty Description

1 Corner mount adapter
2 Screw, 1/4-20 x 0.375-inch (0.95 cm) socket head; for attaching the SWM Series wall mount to the corner mount adapter
3 Fast-acting fuses, 1.6 A, 120 VAC, (SWM-CA24 model only); one fuse ships in the transformer module fuse holder
3 Slow-blow fuses, 500 mA, 230 VAC (SWM-CA24 model only)

The following parts are needed but not supplied:

Qty Description

2 Stainless steel bolts, 0.375-inch (M8) diameter; appropriate length for attaching the corner mount adapter to the mount surface
1 Duct sealant
