INSTALLATION
SWM5-W/SWM5-B
Wall Mount
Indoor Only
C2223M-B (2/18)
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Only use attachments/accessories specified by the manufacturer.
6. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
7. Installation should be done only by qualified personnel and conform to all local codes.
8. Use only installation methods and materials capable of supporting four times the maximum
specified load.
9. Use only replacement parts recommended by Pelco.
Description
The SWM5-W/SWM5-B wall mount is specifically designed for the Spectra® Mini dome system. The
mount offers full feedthrough connections for a clean installation with no exposed wires.
2 C2223M-B (2/18)
Installation
The following parts are supplied:
1 Adapter plate with locking screw
1 Wall mount
2 8-15 x 0.75-inch screws (Used to attach the dome drive to the mount.)
NOTE: The hardware to mount the adapter plate to the junction box (See Figure 1 below) is not
included.
To install the SWM5-W/SWM5-B wall mount:
1. Run power, video (coax or UTP), and camera control wiring to the mounting location. If you are
using coax video, do not attach a BNC connector to the cable until step 5. Refer to Table D,
Table E, and Table F in the installation manual for the Spectra Mini dome for wiring information.
2. Thread the power, video (coax or UTP), and control wiring through the large access hole in the
adapter plate. Then attach the adapter plate to the mounting surface using either the
top/bottom or left/right pair of mounting holes. (The top/bottom pair is shown in Figure 1.)
NOTE: If mounting to anything other than a junction box, select appropriate mounting hardware
for the mounting surface.
Figure 1. Mounting the Adapter Plate
C2223M-B (2/18) 3
