PRODUCT SPECIFICATION
camera solutions
Sarix® TI Series Thermal IP Positioning Systems
IP AND ANALOG THERMAL CAMERA WITH INTEGRATED ESPRIT® PAN/TILT
Product Features
• Uncooled, Sun-Safe, Amorphous Silicon Microbolometer
• Long Wave Infrared (LWIR)
• Esprit® Pan/Tilt
• IP and Analog Capability
• 640 x 480 and 384 x 288 Resolution Options
• 17 µm Pixel Size (640 x 480 model)
• 25 µm Pixel Size (384 x 288 model)
• Sensitivity Below NETD <50 mK at f/1.0
• 24 VAC or 120/230 VAC 50/60 Hz Selectable
• H.264 and MJPEG Compression
• Ability to Control and Monitor Video Over IPv4 and IPv6 Networks
• Built-in Analytics
• Variable Speed Pan, 0.1° to 100°/Sec with Proportional Pan
• 360° Continuous Pan Rotation
• Tilt Range of +33° to –83° from Horizontal
• Preset Positioning, Patterns, and Multiple Scan Modes
• Designed for Minimal Maintenance, No Gears to Adjust
• Adaptive Motion Detection
• ONVIF v1.02 Conformant
Positioning System
The Sarix® TI Series Thermal IP Positioning System is an
advanced thermal imaging pan/tilt system designed for easy
integration into any new or existing video security application. The
system is designed to provide detection, recognition, and
identification of people and vehicles in any lighting condition,
including complete darkness. Every Sarix TI Series features IP or
analog outputs in the same package and an integrated
environmentally protected IP66 rated enclosure with Esprit
positioner, which can be controlled using IP or analog systems that
®
use Coaxitron
or RS-422 Pelco D and Pelco P protocols. Additionally,
when used in an IP system, the Sarix TI Series features a full suite
of designed-for-thermal analytics.
At the core of the Sarix TI Series is an uncooled, sun-safe
microbolometer, long-wavelength infrared (LWIR) camera that
delivers up to 640 x 480 thermal video. These cameras feature an
amorphous silicon detector, which has lower fixed pattern noise and
a more uniform response than vanadium oxide detectors, while still
maintaining high resolution and sensitivity when exposed directly to
the sun during normal daylight hours.
The Sarix TI Series provides outstanding sensitivity below 50 mK
at f/1.0. It is capable of multiple display formats, including white hot,
black hot, and color signatures. The Sarix TI Series is available
with multiple lens configurations for effective deployment in a wide
range of applications.
®
pan/tilt
The Sarix TI Series is available in 640 x 480 and 384 x 288
resolution options. The camera has an input voltage of 24 VAC or a
selectable power source of 120/230 VAC.
In IP installations, the Sarix TI Series can support two simultaneous
video streams. The two streams can be compressed in MJPEG and
H.264 formats across several resolution configurations. The streams
can be configured to a variety of frame rates, bit rates, and group of
pictures (GOP) structures for additional bandwidth administration.
When used in analog installations, the Sarix TI Series supports
®
camera control and limited camera setup using Coaxitron
, Pelco P,
and Pelco D protocols.
The Sarix TI Series provides variable pan and tilt speeds ranging
from 0.1 to 40 degrees per second in manual pan mode and 0.1 to
20 degrees per second in manual tilt mode. Pan preset and turbo
speeds are 100 degrees per second in wind speeds of 50 mph and
50 degrees per second in the 90 mph wind-speed profile. Tilt preset
speed is 30 degrees per second. The Sarix TI Series is capable of
360 degrees of continuous pan rotation. The tilt range allows for
horizontal viewing of +33 to –83 degrees. Preset positions have a
preset accuracy of one-quarter degree.
The powder-coated aluminum enclosure makes the Sarix TI Series
ideal for either indoor or outdoor applications. The system has a
sustained operating temperature range of –40° to 50°C
(–40° to 122°F). A built-in heater/defroster and sun shroud are
standard features on the Sarix TI Series.
International Standards
Organization Registered Firm;
ISO 9001 Quality System
C1317 / REVISED 8-20-14
TECHNICAL SPECIFICATIONS
PELCO ANALYTICS
Pelco™ Analytics enhance the flexibility and performance of the
Sarix TI Series when used in an IP video system. Pelco Analytics are
easy to configure for alarm notification when used with Endura® or a
third-party system that supports Pelco’s Analytics API system.
The Sarix TI Series includes five user-configurable behaviors. The
camera is capable of running up to three behaviors simultaneously.
Note: For each behavior, you can create several custom profiles that
contain different camera settings. With these profiles, you can set up
different scenarios for the behavior, which will automatically detect
and trigger alarms when specific activity is detected.
Pelco Analytics are configured and enabled using a standard Web
browser, and Pelco behavior alarms are compatible with Endura or a
third-party system that supports Pelco’s API system. Multiple Pelco
analytics can be scheduled to work during a certain time or condition.
For example, during the day, a camera can be configured with Object
Counting to count the number of people that enter a lobby door. At
night, the operator can change the profile to Camera Sabotage to
trigger an alarm if a camera is moved or obstructed. Each suite
includes the following behaviors:
• Adaptive Motion Detection: Detects and tracks objects that enter a
scene and then triggers an alarm when the objects enter a user-defined
zone or cross a trip wire. This behavior is primarily used in outdoor
environments with light traffic to reduce the number of false alarms
caused by environmental changes.
• Camera Sabotage: Detects contrast changes in the field of view. An
alarm is triggered if the lens is obstructed with spray paint, a cloth, or
covered with a lens cap. Any unauthorized repositioning of the camera
also triggers an alarm.
• Loitering Detection: Identifies when people or vehicles remain in a
defined zone longer than the user-defined time allows. This behavior is
effective in real-time notification of suspicious behavior around ATMs,
stairwells, and school grounds.
• Object Counting: Counts the number of objects that enter a defined
zone or cross a trip wire. This behavior might be used to count the number
of people at a store entrance/exit or inside a store where the traffic is
light. This behavior is based on tracking and does not count people in a
crowded setting.
• Stopped Vehicle: Detects vehicles stopped near a sensitive area longer
than the user-defined time allows. This behavior is ideal for airport
curbside drop-offs, parking enforcement, suspicious parking, traffic lane
breakdowns, and vehicles waiting at gates.
WEB INTERFACE
The Sarix TI Series uses a standard Web browser for powerful remote
setup and administration.
ADDITIONAL PRODUCT FEATURES
• Operational in 145 km/h (90 mph) Winds, Can Withstand Wind Velocity
up to 209 km/h (130 mph)
• Pan Preset Speed of 100°/Sec in 80 km/h (50 mph) Winds and 50°/Sec in
145 km/h (90 mph) Winds
• Variable Scan Speeds (1 to 40°/Sec)
• Multiple Lens Options
• Designed for Maximum Environmental Protection
• Compact, Lightweight Aluminum Construction
• Meets NEMA Type 4X and IP66 Standards
• Complete with Sun Shroud and Heater/Defroster
• Analog Control using Coaxitron, Pelco P, or Pelco D Protocols
THERMAL CAMERA/OPTICS
Detector Uncooled, sun-safe, amorphous silicon
Array Format 640 x 480 or 384 x 288
Pixel Size
640 x 480 17 µm
384 x 288 25 µm
Effective Resolution 307,200 (640 x 480); 110,592 (384 x 288)
Spectral Response 7.5 to 13.5 µm, LWIR
Normalization Source Internal shutter (offset only), 0.3 second video
Temporal NETD 50 mK at f/1.0
Front Window Germanium with Diamond-Like Coating (DLC)
Display Formats White hot, black hot, and rainbow
microbolometer
freeze during shutter
with resistance to abrasion, salts, acids,
alkalis, and oil
LENS
640 x 480
Lens (mm) F-Number (f)
35 1.4 18° x 13° x 22° 13.0 m (42.6 ft)
50 1.2 12° x 9° x 15° 22.0 m (72.2 ft)
100 1.6 6° x 5° x 8° 92.0 m (301.8 ft)
14.25 1.2 39° x 29° x 48° 1.6 m (5.2 ft)
35 1.4 16° x 12° x 19° 8.8 m (28.8 ft)
50 1.7 11° x 8° x 14° 15.0 m (49.2 ft)
100 1.6 6° x 4° x 7° 63.0 m (206.6 ft)
Field of View
(H/V/D)
384 x 288
Near Focus
Distance
TECHNICAL SPECIFICATIONS
VIDEO
IP/NETWORK
Video Encoding H.264 High, Main, or Base profiles; MJPEG,
and JPEG
Video Streams Up to 2 simultaneous streams; the second
stream is variable based on the setup of the
primary stream
Frame Rate Up to 30, 25, 24, 15, 12.5, 12, 10, 8, 7.5, 6, 5,
4, 3, 2.5, 2, 1 (dependent upon stream
configuration)
Available Resolutions
Resolution JPEG
Width
Height
Aspect Ratio
Maximum IPS*
Recommended
H.264 High
Profile
Bit Rate (Mbps)
Maximum IPS*
Recommended
Bit Rate (Mbps)
640 x 480 Resolution
640 480 4:3 30 4.79 30 1.41
320 240 4:3 30 1.17 30 0.49
384 x 288 Resolution
384 288 4:3 30 1.71 30 0.63
320 240 4:3 30 1.17 30 0.49
320 176 16:9 30 0.88 30 0.34
*Models with a “-X” suffix part number have a maximum images per
second (ips) of 25. Models with a “-X1” suffix part number have a
maximum ips of 8.3.
Supported Protocols TCP/IP, UDP/IP (Unicast, Multicast IGMP),
UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, IPv6
SNMP, QoS, HTTP, HTTPS, LDAP (client), SSH,
SSL, SMTP, FTP, and 802.1x (EAP)
Users
Unicast Up to 20 simultaneous users depending on
resolution settings (2 guaranteed streams)
Multicast Unlimited users H.264
Security Access Password protected
Software Interface Web browser view and setup
Pelco System Integration Endura 2.0 (or later) Digital Sentry
®
7.3
(or later)
Open API Pelco API or ONVIF v1.02
ANALOG
Video/Coaxitron Port 75 ohms, unbalanced
Video Modes NTSC or PAL
Video Level 1 Vp-p
†
Supports mixed IPv4 and IPv6 environments, but not IPv6-only deployments.
MECHANICAL
Pan Movement 360° continuous pan rotation
Vertical Tilt 33° to –79° unobstructed from horizontal
Variable Pan/Tilt Speed Analog Control
Pan 0.5° to 40°/sec 0.1° to 100°/sec
100°/sec turbo
Tilt 0.5° to 20°/sec 0.1° to 30°/sec
Preset Speeds
Pan 100° per second
Tilt 30° per second
Latching 2 captive Torx
‡
Assumes maximum operating capacity.
™
screws
IP Control
ELECTRICAL
Ethernet Port Inline RJ-45 for 100Base-TX, auto MDI/
Ethernet Cabling Required Cat5 or better for 100Base-TX
Input Power 24/120/230 VAC, 50/60 Hz, switch selectable
Input Power Range +15%/–20%
Power Consumption Lens
24 VAC 14.25, 35, 50 mm 3.87 A, 102.2 VA (100 W)
115 VAC 14.25, 35, 50 mm 0.83 A, 109.4 VA (105 W)
230 VAC 14.25, 35, 50 mm 0.41 A, 109.4 VA (105 W)
24 VAC Fuse 8.0 A, slow-blow
120/230 VAC Fuse 2 A, slow-blow
Heater Thermostat controlled
Local Storage Micro SD
Alarm Inputs N.O. switch, N.C. switch, or 1 kohm;
Mechanical Relay Output
Solid-State Relay Output
Audio
Input UTP 600 ohm mono, 12 VDC power source,
Compression G.711 PCM, 64 kbps
Serial Control Port 4-wire, RS-422/RS-485 (Pelco D or Pelco P)
Serial Control Cabling Type UTP
MDI-X
for 120/230 VAC
Power
100 mm 6.12 A, 161.6 VA (160 W)
100 mm 1.30 A, 171.6 VA (170 W)
100 mm 0.65 A, 172.4 VA (170 W)
supervised
‡
Voltage Current Power
60 VDC, 125 VAC 1 A 62.5 VA, 30 W
‡
32 V 100 mA (N/A)
line level/external microphone input, 1 Vp-p
maximum signal level
GENERAL
†
,
Construction Aluminum
Finish Gray polyester powder coat
Environment Indoor/outdoor
Operating Temperature –40° to 50°C (–40° to 122°F)
Storage Temperature –40° to 60°C (–40° to 140°F)
Weight Unit Shipping
ESTI314-2N/5N 11.2 kg (24.6 lb) 15 kg (33 lb)
ESTI314-2W/5W 11.8 kg (26.1 lb) 16 kg (34 lb)
ESTI335-2N/5N 11.3 kg (24.9 lb) 15 kg (33 lb)
ESTI335-2W/5W 12.0 kg (26.4 lb) 16 kg (35 lb)
ESTI350-2N/5N 11.3 kg (25.0 lb) 15 kg (33 lb)
ESTI350-2W/5W 12.0 kg (26.5 lb) 16 kg (35 lb)
ESTI3100-2N/5N 11.4 kg (25.2 lb) 15 kg (33 lb)
ESTI3100-2W/5W 12.1 kg (26.7 lb) 16 kg (35 lb)
ESTI635-2N/5N 11.3 kg (24.9 lb) 15 kg (33 lb)
ESTI635-2W/5W 12.0 kg (26.4 lb) 16 kg (35 lb)
ESTI650-2N/5N 11.3 kg (25.0 lb) 15 kg (33 lb)
ESTI650-2W/5W 12.0 kg (26.5 lb) 16 kg (35 lb)
ESTI6100-2N/5N 11.4 kg (25.2 lb) 15 kg (33 lb)
ESTI6100-2W/5W 12.1 kg (26.7 lb) 16 kg (35 lb)
CERTIFICATIONS/RATINGS/PATENTS
• CE, Class A
• FCC, Class A
• UL/cUL Listed
•C-Tick
• Meets NEMA Type 4X and IP66 standards
• Shock and Vibration, Meets NEMA TS 2; IEC613736-8, -9, -10
®
•Cisco
Medianet (MSP) Compatible
• ONVIF v1.02
TECHNICAL SPECIFICATIONS
19.71
(7.76)
25.91
(10.20)
32.49
(12.79)
60.07
(23.65)
12.57
(4.95)
12.06
(4.75)
15.24
(6.00)
Ø 2.03 X 0.95
(0.8 X 0.375)
Ø 0.381 (0.150) 3X
7.62 (3.00) B.C.
Ø 3.81
(1.50)
PEDESTAL MOUNT MODELS
WALL MOUNT MODELS
PEDESTAL MOUNTING PATTERN WALL MOUNTING PATTERN
NOTE: VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE CENTIMETERS.
12.57
(4.95)
19.71
(7.76)
25.91
(10.20)
57.15
(22.50)
23.32
(9.18)
2.54 X 0.95
(1.0 X 0.375)
12.06
(4.75)
13.97
(5.50)
TECHNICAL SPECIFICATIONS
Analytics Recognition
‡
Analytics Detection
‡
Identification
†
Recognition
†
Detection
†
309 m (1,014 ft)
442 m (1,450 ft)
885 m (2,904 ft)
618 m (2,028 ft)
883 m (2,897 ft)
1.77 km (5,807 ft)
130 m (426 ft)
190 m (624 ft)
390 m (1,281 ft)
270 m (885 ft)
390 m (1,281 ft)
790 m (2,592 ft)
1.5 km (1.0 mi)
3.1 km (2.0 mi)
Lens
50 mm
Lens
35 mm
Lens
395 m (1,296 ft)
564 m (1,850 ft)
1.13 km (3,707 ft)
789 m (2,589 ft)
1.13 km (3,707 ft)
2.26 km (7,415 ft)
330 m (1,083 ft)
480 m (1,575 ft)
1.0 km (0.6 mi)
670 m (2,199 ft)
1.0 km (0.6 mi)
1.9 km (1.2 mi)
3.8 km (2.4 mi)
7.6 km (4.7 mi)
100 mm
Lens
50 mm
Lens
35 mm
Lens
Detection, Recognition, and Identification
of a Human Target
Detection, Recognition, and Identification
of a Vehicle Target
‡
‡
†
†
109 m (358 ft)
268 m (879 ft)
383 m (1,257 ft)
767 m (2,516 ft)
219 m (719 ft)
537 m (1,762 ft)
767 m (2,516 ft)
1.53 km (5,020 ft)
115 m (378 ft)
270 m (885 ft)
350 m (1,149 ft)
760 m (2,493 ft)
230 m (756 ft)
550 m (1,806 ft)
700 m (2,298 ft)
1.5 km (0.9 mi)
2.2 km (1.4 mi)
2.6 km (1.6 mi)
5.3 km (3.3 mi)
100 mm
Lens
50 mm
Lens
35 mm
Lens
14.25 mm
Lens
600 m (1,969 ft)
300 m (984 ft)
210 m (689 ft)
86 m (282 ft)
1.2 km (3,937 ft)
600 m (1,969 ft)
420 m (1,378 ft)
171 m (561 ft)
270 m (885 ft)
130 m (426 ft)
95 m (312 ft)
40 m (132 ft)
540 m (1,773 ft)
270 m (885 ft)
190 m (624 ft)
80 m (264 ft)
2.1 km (1.3 mi)
1.1 km (0.7 mi)
760 m (2,493 ft)
100 mm
Lens
50 mm
Lens
35 mm
Lens
Lens
Detection, Recognition, and Identification
of a Human Target
Detection, Recognition, and Identification
of a Vehicle Target
RANGE PERFORMANCE*
640 x 480
100 mm
384 x 288
14.25 mm
1.1 km (0.7 mi)
320 m (1,050 ft)
2.7 km (1.7 mi)
0.9 km (0.6 mi)
*Range performance can vary based on camera setup, user experience, environmental conditions, and display type used. Calculations are based on 2°C (36°F)
difference, 50 percent probability of target detection, and 0.85/km atmospheric attenuation factor.
†
The number of pixels on target are assumed to be 1.5 pixels for detection, 6 pixels for recognition, and 12 pixels for identification; the size of a human target is
assumed to be 1.8 m (5.9 ft) vertical and 0.5 m (1.6 ft) horizontal; the size of a vehicle target is assumed to be 2.3 m (7.6 ft) vertical and 2.3 m (7.6 ft) horizontal.
‡
User-configured analytics will trigger an alarm at the full analytics detection range; however, analytics will only classify objects at the analytics recognition range.
Because a vehicle is larger than a human, the vehicle analytics detection and recognition ranges can be larger than the human ranges as described below:
Range Human Analytics Vehicle Analytics
Detection 1.8 m/6 pixels 2.3 m/6 pixels
Recognition 1.8 m/12 pixels 2.3 m/12 pixels
Detection†
Recognition
Identification
Analytics Detection
Analytics Recognition
TECHNICAL SPECIFICATIONS
Pelco, the Pelco logo, and other trad emarks associated with Pelco products referred
to in this publication are trademarks of Pelco, Inc. or its affiliates. ONVIF and the
ONVIF logo are trademarks of ONVIF Inc. All othe r product names and
services are the property of their respective comp anies.
Product specifications and availability are subject to change without no tice.
©Copyright 2014, Pelco, Inc. All rights reserved.
MODELS*
640 x 480
Lens Format
35 mm
50 mm
100 mm
384 x 288
Lens Format
14.25 mm
35 mm
50 mm
100 mm
NTSC ESTI635-2N ESTI635-5N ESTI635-2W ESTI635-5W
PAL ESTI635-2N-X ESTI635-5N-X ESTI635-2W-X ESTI635-5W-X
PAL, 8.33 ips ESTI635-2N-X1 ESTI635-5N-X1 ESTI635-2W-X1 ESTI635-5W-X1
NTSC ESTI650-2N ESTI650-5N ESTI650-2W ESTI650-5W
PAL ESTI650-2N-X ESTI650-5N-X ESTI650-2W-X ESTI650-5W-X
PAL, 8.33 ips ESTI650-2N-X1 ESTI650-5N-X1 ESTI650-2W-X1 ESTI650-5W-X1
NTSC ESTI6100-2N ESTI6100-5N ESTI6100-2W ESTI6100-5W
PAL ESTI6100-2N-X ESTI6100-5N-X ESTI6100-2W-X ESTI6100-5W-X
PAL, 8.33 ips ESTI6100-2N-X1 ESTI6100-5N-X1 ESTI6100-2W-X1 ESTI6100-5W-X1
NTSC ESTI314-2N ESTI314-5N ESTI314-2W ESTI314-5W
PAL ESTI314-2N-X ESTI314-5N-X ESTI314-2W-X ESTI314-5W-X
PAL, 8.33 ips ESTI314-2N-X1 ESTI314-5N-X1 ESTI314-2W-X1 ESTI314-5W-X1
NTSC ESTI335-2N ESTI335-5N ESTI335-2W ESTI335-5W
PAL ESTI335-2N-X ESTI335-5N-X ESTI335-2W-X ESTI335-5W-X
PAL, 8.33 ips ESTI335-2N-X1 ESTI335-5N-X1 ESTI335-2W-X1 ESTI335-5W-X1
NTSC ESTI350-2N ESTI350-5N ESTI350-2W ESTI350-5W
PAL ESTI350-2N-X ESTI350-5N-X ESTI350-2W-X ESTI350-5W-X
PAL, 8.33 ips ESTI350-2N-X1 ESTI350-5N-X1 ESTI350-2W-X1 ESTI350-5W-X1
NTSC ESTI3100-2N ESTI3100-5N EST3100-2W ESTI3100-5W
PAL ESTI3100-2N-X ESTI3100-5N-X ESTI3100-2W-X ESTI3100-5W-X
PAL, 8.33 ips ESTI3100-2N-X1 ESTI3100-5N-X1 ESTI3100-2W-X1 ESTI3100-5W-X1
24 VAC 120/230 VAC 24 VAC 120/230 VAC
24 VAC 120/230 VAC 24 VAC 120/230 VAC
Pedestal Mount
Pedestal Mount
†
†
Wall Mount
Wall Mount
‡
‡
*Some models may be subject to US government export control regulations.
†
Pedestal mount models include Esprit EPP pedestal adapter plate. Use with PM2000/PM2010 mount (not supplied) for pedestal application.
‡
Wall mount models include Esprit EWM wall mount. Optional mounting adapters for corner, pole, and parapet applications are available.
RECOMMENDED MOUNTS AND ADAPTERS
ECM100 Corner mount adapter; for use with EWM
wall mount
EPM Pole mount adapter; for use with EWM wall
RECOMMENDED POWER SUPPLIES
MCS Series Multiple 24 VAC camera power supply, indoor
WCS Series Single/multiple 24 VAC camera power supply,
outdoor
mount
EA4348 Parapet mount adapter; for use with EWM
wall mount
PM2000/PM2010 Pedestal mount with cable feedthrough; for
use with Esprit systems with EPP pedestal
OPTIONAL ACCESSORIES
SECURE-SLA License Enables Information Assurance compliant
mode of operation
adapter plate
PP4348 Rooftop parapet mount; use with EA4348
adapter
Pelco by Schneider Electric
3500 Pelco Way, Clovis, California 93612-5699 United States
USA & Canada Tel (800) 289-9100 Fax (800) 289-9150
International Tel +1 (559) 292-1981 Fax +1 (559) 348-1120
www.pelco.com www.pelco.com/community
Loading...
