Pelco ESCE1-2X40-RLU, ESCE1-4X36-RLU, ESCE1-8X36-RLU specification sheets

ESPRIT COMPACT PTZ CAMERA

2 MP 4 MP 8 MP

The Esprit Compact is a hardened, mission-critical pan-tilt-zoom (PTZ) camera that can withstand the most extreme environmental factors. This security camera is built to withstand most outdoor environments while maintaining continuous clear, high-resolution live and recorded video, with up to 8 MP and 40x zoom. Built for operations that have extreme operational requirements, this camera is ideal for monitoring cities, ports, industrial plants and enterprise facilities.

Designed to have superior strength and durability, it is tested to MIL-STD-167-1A and 810G, allowing for extreme shock and vibration tolerance. It also is NEMA TS2 and IP66/67 rated to withstand extreme weather, shock, vibration and humidity.

The Esprit Compact is built with Smart Analytics, powered by Motorola Solutions, equipped with ONVIF Profile S, G and T and is NDAA-compliant, allowing for open connectivity with Pelco VideoXpert and leading partner VMS’.

FEATURES

SMART ANALYTICS WITH AUTO-TRACKING POWERED BY MOTOROLA SOLUTIONS

Detects more objects with expanded object classifications and automatically tracks objects in zone for faster, decisive responses.

WIDE DYNAMIC RANGE

Captures high-quality image details in scenes with dark and light backgrounds per IEC 62676-5.

DUST & WATER RESISTANT

IP66/67 rating for resistance from dust and water.

ONVIF® COMPLIANT

ONVIF Profile S, G and T compliance allows for easy integration with existing ONVIF infrastructures. Integrates with Pelco VideoXpert and other leading video management systems.

ONVIF is a trademark of Onvif, Inc.

SIMPLE DEPLOYMENT, INSTALLATION AND REPAIR

Reduce installation times with accessory options such as power supplies, mounting brackets and IR/white light illuminators.

H.264 AND H.265 WITH SMART COMPRESSION

Optimizes compression levels for regions in a scene to help maximize bandwidth savings and keep storage costs down.

IMPACT RESISTANT

IK10 rated for 20 joule impact resistance.

PEACE OF MIND

We back our Esprit Compact camera with a 5-year industryleading warranty, with onsite support and 24/7 phone support.

SPECIFICATIONS

IMAGE PERFORMAN CE 2.0 MP 4.0 MP 8.0 MP

Image Sensor 1/2.8" progressive scan CMOS 1/2.5" Type "Exmor R" CMOS sensor

Active Pixels (H x V) 1937 (H) × 1097 (V) 2688 (H) × 1512 (V) 3840 (H) × 2160 (V)

Imaging Area (H x V)

PEC-UEI8AA 100 m (328 ft) 30 m (98 ft)

PEC-UEI8AAP 200 m (656 ft) 75 m (246 ft)

IR Illumination Max Distance

Minimum Illumination

Dynamic Range 120 dB 100 dB

Image Rate Up to 60 fps Up to 30 fps

Aspect Ratio (Resolution Scaling) Down to (16:9) 384×216 or (5:4) 320×256

3D Noise Reduction Filter Yes

PEC-UEI9AA 75 m (246 ft) 20 m (66 ft)

PEC-UEIWAA 150 m (492 ft) 50 m (164 ft)

PEC-UEIWAAP 200 m (656 ft) 100 m (328 ft)

LENS 2.0 MP 4.0 MP 8.0 MP

Lens

Angle of View

Zoom Up to 40x

Up to 36x zoom is achieved with Image Stabilization off. Image Stabilization set to on will provide 30x zoom..

Horizontal 66.35° - 1.9° 69.7° - 2.2°

Vertical 39.99° – 1.11° 42.8° – 1.3°

5.568 mm (H) × 3.132 mm (V); 0.219 ” (H) × 0.123 ” (V)

0.03 lux (F/1.6) in color mode; 0.02 lux (F/1.6) in monochrome

4.25 to 170 mm, F/1.6 – F/4.95, autofocus

6.22 mm (H) × 3.50 mm (V); 0.245" (H) × 0.137" (V)

0.3 lux (F/2.0) in color mode; 0.09 lux (F/2.0) in monochrome

4.4 to 88 mm, F/2.0 - F/3.8, autofocus

Up to 36x

IMAGE CONTROL 2.0 MP 4.0 MP 8.0 MP

Video Compression H.264 and H.265 Pelco Smart Compression, Motion JPEG

Streaming Multi-stream H.264, Multi-stream H.265, Motion JPEG

Motion Detection Pixel motion: Selectable sensitivity and threshold. Classified object detection

Electronic Shutter Control Automatic, Manual (1/1 to 1/10,000 sec)

Iris Control Automatic, Open, Closed

Day/Night Control Automatic, Manual

Flicker Control 60 Hz, 50 Hz

White Balance Automatic, Manual

Backlight Compensation On/Off

Privacy Zones 3D, up to 64 zones

Presets 500 named presets

Tours 10 named tours

Electronic Image Stabilization No Yes

Digital Defog Adjustable/Off

IMAGE CONTROL
