Parrot ASTEROID SMART User Manual
User guide
Table of content
Before you begin
Installation
.......................................................................................................................................................6
...........................................................................................................................................................................................................6Software updates
...........................................................................................................................................................................................................6SD card
...........................................................................................................................................................................................................6Warnings
...........................................................................................................................................................................................................7Steering wheel control interface
.......................................................................................................................................................8
...........................................................................................................................................................................................................8Safety instructions
...........................................................................................................................................................................................................8Before you begin
...........................................................................................................................................................................................................9Installation diagram
...........................................................................................................................................................................................................10Installation using the holder
...........................................................................................................................................................................................................10Installation using the side screw holes
...........................................................................................................................................................................................................11Installing the GPS receiver
...........................................................................................................................................................................................................12Connecting the parking brake lead
...........................................................................................................................................................................................................12Installing a rear view camera
...........................................................................................................................................................................................................12Installing the microphone
...........................................................................................................................................................................................................13Installing the ISO cable
...........................................................................................................................................................................................................13Installing the USB cables
...........................................................................................................................................................................................................14Basic operations
Getting started
Phone
.......................................................................................................................................................15
...........................................................................................................................................................................................................15Turning the Parrot ASTEROID Smart on / off
...........................................................................................................................................................................................................15Home screen
...........................................................................................................................................................................................................15Personalizing the home screen
...........................................................................................................................................................................................................16Changing settings
...........................................................................................................................................................................................................16Connecting a phone via Bluetooth
...........................................................................................................................................................................................................16Connecting two phones
...........................................................................................................................................................................................................17Synchronising the phonebook
.......................................................................................................................................................18
...........................................................................................................................................................................................................18Receiving a call
...........................................................................................................................................................................................................18Making a call
...........................................................................................................................................................................................................19Consulting the call history
...........................................................................................................................................................................................................20Manage favourite contacts
...........................................................................................................................................................................................................20Using the Parrot ASTEROID whilst on a call
Music
Internet
.......................................................................................................................................................22
...........................................................................................................................................................................................................22Using vocal music search
...........................................................................................................................................................................................................22Screen commands
...........................................................................................................................................................................................................23iPod
...........................................................................................................................................................................................................23USB storage device
...........................................................................................................................................................................................................23SD card
...........................................................................................................................................................................................................24Audio player connected via Bluetooth
...........................................................................................................................................................................................................25Analogue audio player
...........................................................................................................................................................................................................25Radio
.......................................................................................................................................................27
...........................................................................................................................................................................................................27Connection with a 3G/4G key
...........................................................................................................................................................................................................28Connection via Bluetooth
...........................................................................................................................................................................................................28Connection via USB
...........................................................................................................................................................................................................29Connection to a Wi-Fi network
...........................................................................................................................................................................................................29Using the ASTEROID Market
Video
Settings
...........................................................................................................................................................................................................31Using the browser
.......................................................................................................................................................35
...........................................................................................................................................................................................................35Rear view camera
...........................................................................................................................................................................................................35Playback of a video via an external source
...........................................................................................................................................................................................................36Playback of a video via a SD card
...........................................................................................................................................................................................................36Screen connected to video output terminals
.......................................................................................................................................................37
...........................................................................................................................................................................................................37Time / Date
...........................................................................................................................................................................................................37Bluetooth
...........................................................................................................................................................................................................38Phone
...........................................................................................................................................................................................................38Audio
...........................................................................................................................................................................................................41Music
...........................................................................................................................................................................................................41Display
...........................................................................................................................................................................................................42Network
...........................................................................................................................................................................................................43Other settings
Gallery
.......................................................................................................................................................44
...........................................................................................................................................................................................................44Using the gallery
...........................................................................................................................................................................................................44Zooming in/out
...........................................................................................................................................................................................................44Editing a photo
...........................................................................................................................................................................................................45Defining an image as screen background
Pre-installed applications
.......................................................................................................................................................46
...........................................................................................................................................................................................................46Calculator
...........................................................................................................................................................................................................46Diary
General information
.......................................................................................................................................................49
5
Before you begin
Software updates
Download the latest update for free (and consult the update procedure) on the Parrot
ASTEROID Smart support page on our website www.parrot.com. These updates will
enable you to receive new features and improve the product’s compatibility.
Note: You can also download the Parrot ASTEROID Smart's updates while connected to the
Internet. The availability of an update is indicated on the notification bar.
SD card
An SD card is included with the Parrot ASTEROID Smart. It allows you to play music
tracks and is mandatory in order to use applications.
Note: The iGO application is provided for free with the Parrot ASTEROID Smart. The
necessary navigation datas are stored on the provided SD card. Do not delete or move the
SD card content. Without it you will not be able to use the iGo application.
Warnings
All functions requiring an increased attention should only be used while the vehicle is
stationary. Your safety and the one of the other road users prevails over phone calls,
music and driving assistance applications. Be responsible: drive carefully and pay full
attention to your surrounding. Parrot denies any liability should you choose not to
respect this warning.
Use the Parrot ASTEROID Smart with a reasonable volume level so that you can hear
all external noises while driving.
The Parrot ASTEROID Smart includes NdFeB magnets which can damage objects
sensitive to magnetic fields (pacemakers, credit cards, mechanical clocks…).
6
The Parking Brake wire of Parrot ASTEROID Smart's ISO cable detects whether or not
the parking brake is on. It must be connected following the installation instructions
provided in this document. Incorrect installation or connection may be dangerous and
illegal in many states / countries. If the screen is located in the driver's field of vision,
under no circumstances should videos be played whilst the vehicle is moving. The
same applies to any applications other than those for driving or navigation assistance.
Before you begin
If you attempt to use an application that is not intended for navigation or driving
assistance when you are driving, an on-screen warning will be displayed. To watch a
video on the Parrot ASTEROID Smart's screen, make sure that the vehicle is stopped in
a safe area and that the parking brake is on.
Steering wheel control interface
A steering wheel control interface can be used to connect your vehicle’s steering wheel
controls to your Parrot ASTEROID Smart. With this interface, you will be able to make
phone calls via the steering wheel controls while keeping your hands on the wheel.
Refer to our website www.parrot.com for more information.
7Before you begin
Installation
Safety instructions
Note: We advise our customers to have the Parrot ASTEROID Smart installed by a Parrot
certified installer.
Turn the ignition off before installing the Parrot ASTEROID Smart.
Do not install the Parrot ASTEROID Smart where it may interfere with the driver
operation of the vehicle.
Do not drill holes in the dashboard or any panel without first making sure there is
nothing behind it. Do not damage any fuel line, electronic component or cable.
If you need to use screws, do not allow them to come into contact with any power
cable.
Install the Parrot ASTEROID Smart only on vehicles with a 12 V battery. If your vehicle
(e.g. : truck) has a 24V battery, the use of a step-down converter is essential.
Place all cables away from hot places (heater outlet) and moving parts (gear shift, seat
rails...). Make sure they will never wind around the steering column or gearstick.
Confirm the proper function of your vehicle's other equipment after installing the
Parrot ASTEROID Smart.
Do not install the Parrot ASTEROID Smart or one of its components where the airbag
may deploy.
Do not install the Parrot ASTEROID Smart in places subject to high temperatures or
humidity.
Make sure you leave enough space behind the Parrot ASTEROID Smart once installed
so that proper heat dispersal is ensured.
8
Before you begin
Remove your car stereo from your vehicle. You may need release keys to do so.
Try to connect the audio and power connectors of the Parrot ASTEROID Smart to the
connectors of your vehicle. If this connection is impossible, you have to obtain an ISO
Installation
adapter before installing the Parrot ASTEROID Smart. Refer to the vehicle
Parrot ASTEROID Smart antenna
connector
Example of antenna adaptor -DIN / Fakra (not provided)
compatibility section on the Parrot ASTEROID Smart support page for more
information.
Compare the Parrot ASTEROID Smart antenna connector to the antenna connector of
your vehicle. If an adapter is necessary, contact your local car audio specialist.
Note : Make sure you also supply power to your antenna if it is amplified. Power to the
antenna can be supplied using the Parrot ASTEROID Smart ISO cable.
Installation diagram
9Installation
Installation using the holder
1. Loosen the 4 screws to remove the Parrot ASTEROID Smart holder.
2. Insert the holder into the dashboard. To do so, bend the tabs 90 degrees.
3. Install the Parrot ASTEROID Smart and fasten the screws.
4. Attach the trim ring.
Installation using the side screw holes
1. Loosen the 4 screws to remove the Parrot ASTEROID Smart holder.
2. Remove the two side brackets.
3. Position the Parrot ASTEROID Smart so that its screw holes are aligned with the
screw holes of the bracket.
4. Tighten as many screws as necessary depending on the model of your vehicle. Only
use the provided screws.
10
Installation
Installing the GPS receiver
The GPS receiver antenna is located on the side where "Parrot ASTEROID GPS"
is written and where the star-shaped logo is. This logo must always be directed
towards the sky.
Stick the GPS receiver in an unobstructed area inside the car.
Athermic windshields and windows with a built-in antenna can interfere with GPS
reception and reduce the reliability of information from navigation applications.
If your vehicle has an athermic windshield, stick the GPS receiver on the windshield on
the non athermic area. The side where the star-shaped logo is must be stuck on the
windshield.
Note : The non athermic area of the windshield depends on the model of your vehicle. It is
usually located near the rear view mirror.
If your vehicle does not have an athermic windshield, stick the GPS receiver on the
dashboard. The side where the star-shaped logo is must be visible.
To make sure the adhesive tape adheres well :
use the provided adhesive tape ;
clean the area with an appropriate cleaning product before sticking the support ;
once you have stuck the support on the dashboard, wait for approximately 2 hours
without handling it.
Note: Once the GPS receiver is connected to the Parrot ASTEROID Smart, the GPS receiver
light becomes white while searching for a GPS signal. The light blinks as soon as a signal is
11Installation
detected. Select Settings > Location & security > Activate the external GPS LED to activate/
deactivate the light.
Connecting the parking brake lead
The parking brake lead allows you to use the Parrot ASTEROID Smart video function or
applications only when the parking brake is set. If this cable is not connected to your
vehicle parking brake system, the video function will not be available.
1. Connect the parking brake extension lead to the Parrot ASTEROID Smart green
cable.
2. Locate and test the parking brake signal cable in the vehicle. This cable connects
your parking brake to the parking brake signal on your dashboard.
3. Route the Parrot ASTEROID Smart parking brake extension lead (green) safely and
securely from the Parrot ASTEROID Smart and connect this to the parking brake
signal cable using a suitable method.
Warning: An improper connection or use of this cable is dangerous and illegal in many
states.
Installing a rear view camera
If you are to use the Parrot ASTEROID Smart with a rear view camera (not provided),
the orange cable on the Parrot ASTEROID Smart ISO cable will detect when the
gearstick is moved to "reverse". Connect this cable to the one providing power to the
reverse lamp of your vehicle in order to display the rear view camera image when
backing your vehicle.
Connect the rear view camera video cable to the Video CAM connector located at the
back of the Parrot ASTEROID Smart.
Installing the microphone
The optimum location for the microphone is in the centre of the vehicles roof near the
rear view mirror. The microphone ideally needs to be less than 60cm’s from the users
mouth pointing directly towards them with no obstructions.
Please take care when routing the microphone cable through the vehicle to the desired
location, we recommend routing alongside existing manufacture’s wiring looms
12
securing as you go making sure the microphone cable is not pinched or trapped.
Warning: Do not run the microphone cable in such a way as to obstruct or interfere with
the vehicles operation or cause injury to its occupants. In particular vehicle safety device
such as airbags and other SRS systems.
Installation
Installing the ISO cable
Connect the audio and power connectors of the Parrot ASTEROID Smart to the ones
of your vehicle.
Note: Use the provided cable ties to make sure the cables are well fixed to the car stereo.
Insert one of the cable ties into the slots in the top of the back of the car stereo.
Once the connections are made, check your installation. To do so, turn the ignition on
then off. The "Goodbye" message must be displayed. If it is not the case, it is necessary
to swap the positions of the red and yellow wires. Indeed, the red wire of the power
cable must be connected to the 12V ignition, the yellow wire to the permanent 12V and
the black wire to the ground. This can be done simply by reversing both bullet
connectors located on the Parrot wiring.
Installing the USB cables
Connect the USB cables to the Parrot ASTEROID Smart. We recommend you connect
all audio cables to the Parrot ASTEROID Smart even if you do not plan on using them.
Route the audio cables to a suitable location in your vehicle such as the glove box or
arm rest compartment. It may be necessary to drill a hole in your dashboard to do so.
Avoid using USB extension cables.
The USB cable (1.2m - 2A) to which you will connect the USB / iPod cable extension
must be connected to its specific white USB port. "iPod" is written above it.
To guarantee an optimal reception quality we recommend you do not connect your
internet USB key 3G on the Parrot ASTEROID Smart directly : use the USB cable to
install your device on the dashboard (or any other open area).
13Installation
Basic operations
The Parrot ASTEROID Smart faceplate can be removed to protect your unit from theft.
The Parrot ASTEROID Smart cannot work without its faceplate.
Handle the faceplate with care. Do not force while installing or removing it. Keep it
away from sunlight, humidity or high temperatures.
To remove the faceplate, hold down the button on the top left and slide it downwards.
To replace the faceplate, insert the lower part first and then press the top until you hear
a click.
14
Installation
Getting started
Turning the Parrot ASTEROID Smart on / off
Hold down the button for 2 seconds to turn the Parrot ASTEROID Smart on / off.
Home screen
Slide your finger horizontally to the left. You will discover more space for adding
functions shortcuts.
Touch an icon to get to the corresponding function. Touch the Applications icon for
instance. The list of the available applications is displayed. Slide your finger downward
to browse through the applications list.
Press to get back to previous menu. Press to get to the home screen.
Press to access the pop-up menu corresponding to the current application. The
pop-up menu allows you to change several settings or to access more functions.
Press to display the last applications used or currently in use.
Press to adjust the volume. Then slide the cursor to the left or to the right.
Personalizing the home screen
To add an application shortcut on your home screen:
1. Tap Applications.
2. Press and hold the application icon you are interested in.
3. Drag the icon to the home screen where you want to add it.
To remove an application shortcut:
1. Press and hold the shortcut you want to remove.
15Getting started
2. Drag the icon upwards to the Remove indication. When the icon turns red, lift your
finger.
Changing settings
To change the Parrot ASTEROID Smart settings, tap Applications, then Settings. You
can also tap , then Settings.
Connecting a phone via Bluetooth
Note : Refer to the compatibility page of our website to check if your phone is compatible
with the Parrot ASTEROID Smart and to consult the specific pairing procedures for the most
common phones : www.parrot.com/uk/compatibility.
If you are using the Parrot ASTEROID Smart with your phone for the very first time, you
must initially pair both devices. Once your telephone is paired with the Parrot
ASTEROID Smart, the 2 devices will automatically connect when they are turned on
(as well as
1. In the Settings menu, press Wireless & networks > Bluetooth.
2. If necessary, activate the
3. From your phone, search for
Smart».
4. The pairing procedure depends on which telephone model you have:
Note: Depending on the model of your phone, you may need to authorize the connection
to the Parrot ASTEROID Smart to allow further automatic connections. Refer to the user
guide of your phone for more information.
Bluetooth®
If the phone asks you to enter the
If the Parrot ASTEROID Smart and your telephone display two codes, verify that
the codes are identical, then either confirm or invalidate.
features) and in proximity of each other.
Bluetooth
and Discoverable options.
Bluetooth
peripherals and select «Parrot ASTEROID
Bluetooth
PIN code, enter “0000”.
Connecting two phones
16
To activate Dual Mode (multipoint) and connect two phones :
1. Tap Phone.
2. Tap , then Bluetooth > Options.
3. Activate the Dual Mode option.
When the Parrot ASTEROID Smart is switched on, it attempts to connect to all paired
phones in the vehicle. If there are more than two paired phones in the vehicle, the
device connects to the two phones with the oldest pairing.
Getting started
Loading...
