CI ELITE LCR SERIES.
The CI Elite LCR series is crafted right here in our Canadian
facility and has all the technology advantages of the CI Pro LCR
series, plus oversized voice coils, X-PAL™ pure aluminum cone
technology for the ultimate in sound performance.
FEATURING:
Screen Compensation Mode
Ensures true acoustic transparency
when placed behind micro-perforated
projection screens.
43”
43”
32”
Metal Baffle Metal Baffle Metal Baffle
E7-LCR E5-LCR
Left/Center/Right In-Wall Speaker with
Integrated Back Box
• Reduced Edge Diffraction (RED™) Technology
(patent pending) with added heat dissipation
• High Frequency Response compensation when
mounting speaker behind projection screen
• X-PAL Brushed pure-aluminum cone driver
• 1.5” high power handling voice coil
Tweeter/Midrange: One 1” X-PAL
PPA™ Tweeter; One 6.5” X-PAL cone.
Bass Drivers: Two 8” X-PAL cones with
overmolded ART™ surrounds.
Passive Drivers: Two 8” X-PAL cones with
overmolded ART™ surrounds.
Left/Center/Right In-Wall Speaker
with Integrated Back Box
• Reduced Edge Diffraction (RED™) Technology
(patent pending) with added heat dissipation
• High Frequency Response compensation when
mounting speaker behind projection screen
• X-PAL Brushed pure-aluminum cone driver
• 1.5” high power handling voice coil
Tweeter/Midrange: One 1” X-PAL
PPA™ Tweeter; One 6.5” X-PAL cone.
Bass Drivers: Two 6.5” X-PAL cones with
overmolded ART™ surrounds.
Passive Drivers: Two 6.5” X-PAL cones with
overmolded ART™ surrounds.
E3-LCR
Left/Center/Right In-Wall Speaker with
Integrated Back Box
• Reduced Edge Diffraction (RED™) Technology
(patent pending) with added heat dissipation
• High Frequency Response compensation when
mounting speaker behind projection screen
• X-PAL Brushed pure-aluminum cone driver
• 1.5” high power handling voice coil
Tweeter: One 1” X-PAL PPA™ Tweeter
Bass/Mid Range Drivers: Two 5.5”
X-PAL cones with overmolded ART™ surrounds
Passive Drivers: Two 5.5” X-PAL cones
with overmolded ART™ surrounds
E7-LCR E5-LCR E3-LCR
Design
Crossover
High Frequency Driver
Midrange Driver
Bass/Midrange Driver
Bass Driver
Passive Driver
4-driver, 3-way, shallow enclosure
in-wall design
3rd-order electro-acoustic at 3 kHz,
2nd-order electro-acoustic @ 480 Hz
1" (2.5cm) X-PAL™ dome, ferro-fluid
damped / cooled, Reduced Edge Diffraction
(RED™) Technology, Perforated PhaseAligning (PPA™) Tweeter Lens
6.5" (16.5cm) coaxial X-PAL™ driver,
die-cast aluminum chassis, 1.5" (3.8cm]
high-temp voice coil
N/A
Two 8" (20.3cm) high-excursion X-PAL™
drivers, overmolded Active Ridge
Technology (ART™) surround, die-cast
aluminum chassis, 1.5" (3.8cm] high-temp
voice coil
Two 8" (20.3cm) high-excursion X-PAL™
drivers, overmolded Active Ridge
Technology (ART™) surrounds
4-driver, dual passive radiator, 3-way,
shallow enclosure in-wall design
3rd-order electro-acoustic at 3 kHz,
2nd-order electro-acoustic @ 450 Hz
1” (2.5cm) X-PAL™ dome, ferro-fluid
damped / cooled, Reduced Edge Diffraction
(RED™) Technology, Perforated PhaseAligning (PPA™) Tweeter Lens
6.5” (16.5cm) coaxial X-PAL™ driver,
die-cast aluminum chassis,1.5” (3.8cm]
high-temp voice coil
N/A
Two 6.5” (16.5cm) high-excursion
X-PAL™ drivers, overmolded Active Ridge
Technology (ART™) surround, die-cast
aluminum chassis, 1.5” (3.8cm] high-temp
voice coil
Two 6.5” (16.5cm) high-excursion
X-PAL™ drivers, overmolded Active Ridge
Technology (ART™) surrounds
3-driver, dual passive radiator, 2-way,
shallow enclosure in-wall design
3rd-order electro-acoustic at 2.3 kHz
1” (2.5cm) X-PAL™ dome, ferro-fluid
damped / cooled, Reduced Edge Diffraction
(RED™) Technology, Perforated PhaseAligning (PPA™) Tweeter Lens
N/A
Two 5.5” (13.9cm) high-excursion
X-PAL™ drivers, overmolded Active Ridge
Technology (ART™) surround, die-cast
aluminum chassis, 1.5” (3.8cm] high-temp
mid-bass voice coil
N/A
Two 5.5” (13.9cm) high-excursion
X-PAL™ drivers, overmolded Active Ridge
Technology (ART™) surrounds
Low Frequency Extension
Frequency Response
(0-15 degree window)
Frequency Response
(30-45 degree window)
Sensitivity - Room
Sensitivity - Anechoic
Suitable Amplifier Power Range
Maximum Input Power
Impedance
Dimensions with Grille
(h x w x d)
Cut-Out Dimensions
(h x w)
Minimum Mounting Depth
Distance behind 1/2” drywall,
or similar material.
Finish
Weight
Optional PB Bracket
55 Hz
±3 dB from 80 Hz - 22 kHz
±3 dB from 80 Hz - 19 kHz
95 dB
92 dB
15-220 W
150 W
Compatible with 8 ohms
43” x 9-1/2” x 4-1/8”
(109.2cm x 19.5cm x 10.5cm)
42” x 8-1/2”
(106.6cm x 21.5cm)
3-7/8" (9.8cm)
Paintable White Grille
33.0 lbs (14.9 kg)
PB-5/7 PB-3
56 Hz
±3 dB from 82 Hz - 22 kHz
±3 dB from 82 Hz - 19 kHz
94 dB
91 dB
15-220 W
150 W
Compatible with 8 ohms
43” x 9-1/2” x 4-1/8”
(109.2cm x 19.5cm x 10.5cm)
42” x 8-1/2”
(106.6cm x 21.5cm)
3-7/8” (9.8cm)
Paintable White Grille
34.0 lbs (15.4 kg)
PB-5/7
57 Hz
±3 dB from 93 Hz - 22 kHz
±3 dB from 93 Hz - 19 kHz
92 dB
89 dB
15-200 W
130 W
Compatible with 8 ohms
32” x 7-5/8” x 4-1/8”
(81.4cm x 19.5cm x 10.5cm)
31”x 6-5/8”
(78.8cm x 16.0cm)
3-7/8” (9.8cm)
Paintable White Grille
23.0 lbs (10.4 kg)
