Panasonic LA03, TC-L37U22X Different Points

37 inch Class 1080p LCD HDTV

Model No. TC-L37U22X

LA03 Chassis

Please file and use this manual together with the service manual for Model No. TC-L37U22, ORDER NO. MTNC100209CE.

ORDER NO.MTNC100217AE

1 Different points

1.1. Mechanical Replacement Parts List

Ref. No. Parts No. Parts name & Description Pcs Remarks

TC-L37U22 TC-L37U22X THEJ024 THEJ024 SCREW(A-L2/A-S2/FLM8/P-S1/BTM1) 14 16pcs → 14pcs THTD020J THTD020J SCREW(A-PRINT:4) 10 12pcs → 10pcs TXJA110QGM TXJA040QGN SPEAKER LEAD 1 PAVCA TXFK04XSER TXFKP05XSER SIDE AV BRACKET 1 PAVCA

----- TMME378 CLAMPER (P2) 2 14 TMX2AE009 ----- BRACKET-IP 15 TQB2AA0568 TQB2AC0003 INSTRUCTION BOOK 1 18 TXFKY010QGM TXFKY010QGN CABINET ASSY 1

1.2. Electrical Replacement Parts List

Ref. No. Parts No. Parts name & Description Pcs Remarks

TC-L37U22 TC-L37U22X PCB TXN/A10QGMS TXN/A10QGNS CIRCUIT BOARD A 1 PCB TXN/V10QMMS TXN/V10QMMM CIRCUIT BOARD V 1 IC8004 TVRR296S TVRR339S IC 1 PAVCA IC8503 TVRR303S TVRR347AAS IC 1 PAVCA JS1000 D0GAR00Z0001 ----- C 0 OHM, 0.063W 1 JS1003 ----- D0GAR00Z0001 C 0 OHM, 0.063W 1

PAVCA PAVCA

(RTL) PAVCA (RTL) PAVCA
