I hank you for purchasing this Panasonic product.
reference. The images shown in this manual are for illustrative purposes only, Gracias por su decisi6n de comprar este producto marca Panasonic,
Lea estas instrucciones antes de utilizar su televisor y guardelas para consultarlas en
el futuro. Las imagenes mostradas en este manual tienen solamente fines ilustrativos.
V
IIIIIIIIIIIIIIIIIIIIIIIIIIIllUlllllllHIIIIIIHIIIIIII
TQB4GC0608
2010/12/24 13:40:0_ _
Experience
an amazing
of
multi ia
excitement
This product incorporates the following software:
(1) software developed independently by or for Panasonic Corporation, (2) software owned by a third party and licensed to Panasonic Corporation,
(3) software licensed under the GNU General Public License, Version 2 (GPL v2), (4) software licensed under the GNU LESSER General Public License (LGPL) and/or, (5) open source software other than software licensed under the GPL and/or LGPL
For the software categorized as (3) or (4), please refer to the terms and conditions of GPL v2 and LGPL, as the case may be at http://www.gnu.org/licenses/old-licenses/gpl-2.0.html and http://www.gnu.org/licenses/old-licenses/Igpl-2.1 .html In addition, software categorized as (3) or (4) is copyrighted by several individuals and/or entities. Please refer to the copyright notice of those individuals at http://www.am-lin ux.jp/dl/DTVl 1UT/.
GPL/LGPL SOFTWARE IS DISTRIBUTED IN THE HOPE THAT IT WILL BE USEFUL, BUT WITHOUT
ANY WARRANTY, EXPRESS, IMPLIED OR STATUTORY, INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. For at least three (3) years from delivery of products, Panasonic will give to anyone who contacts us at the
address provided below, for a charge of no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL v2/LGPL
Contact Information cd request@am-lin ux.jp Source code is also freely available to you and any other member of the public via our website below.
http://www.am-lin ux.jp/dl/DTVl 1UT/
2
tc_L3232c_en_0608Jndl) 2 2010/12/24 13:40:0:
I
VIfI'/ l..i K° VlERALinkTMisatrademark°f
H.-"am!
Panasonic Corporation.
HDMI, the HDMI logo and High- Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
SDHC Logo is a trademark of SD- 3C, LLC.
This product qualifies for ENERGY STAR in the "Home Use" setting
and this is the setting in which energy savings will be achieved. Any modifications to the "Home Use" setting or other factory default
settings could result in greater energy consumption beyond
levels that meet ENERGY STAR qualifications.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDAVl Control TM is a trademark of Panasonic Corporation.
Vlef_ .....
IMAGEVIEWER
Please read before using the unit
÷ Safety Precautions ......................................... 4
Getting started
Accessories/Optional Accessory ................... 7
Connections .................................................. 9
Identifying Controls ...................................... 11
FirstTime Setup ........................................ 12
Basic Features
÷ Watching TV ................................................. 15
÷ Using VIERATOOLS ................................... 18
÷ Watching content from external devices ...... 19
÷ Viewing photos with VlERA IMAGE VIEWER ..... 20
Advanced Features
÷ VIERA LinkTM "HDAVI Control TM''................... 22
÷ Editing and Setting Channels ....................... 28
÷ How to Use Menu Functions ........................ 30
o Picture settings ........................................... 31
o Audio settings ............................................. 32
o Timer settings ............................................. 32
Lock ............................................................ 33
o Closed caption ............................................ 33
o Setup .......................................................... 34
Support Information
÷ Ratings List for parental control ................... 35
÷ Technical Information ................................... 36
÷ Care and Cleaning ....................................... 40
÷ Specifications ............................................... 41
÷ Frequently Asked Questions (FAQ) ............. 42
÷ Index ............................................................ 44
÷ Limited Warranty
(for U.S.A. and Puerto Rico only) ................. 45
÷ Customer Services Directory
(for U. S. A. and Puerto Rico) ........................ 46
÷ Limited Warranty (for Canada) ..................... 47
IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIMIIIIIII3
tc_L3232c_en_O608Jndb 3 2010/12/24 13:40:0:
I
Safety Precautions
The{ightningflashwitharrowhead
CAUTION
WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
I#L'_ [_ [_-'_ill,vA[,._'[i'11 ri_"_l_I_-J'i
This reminder is provided to direct the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to ensure reliable operation of the LCD
TV and to protect it from overheating. These openings must not be blocked or covered. There should be at least 10 cm of space
around the TV. The openings should never be blocked by placing the LCD TV on a bed, sofa, rug or other similar surface. This LCD TV should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.
II'TClp"b'TilET'[[II[,-"_ll'_J"t,_I_
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Operate only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied15)
to your home consult your television dealer or local power company.
16)
Follow all warnings and instructions marked on the LCD TV.
17)
Never push objects of any kind into this LCD TV through cabinet slots as they may touch dangerous voltage points or short out parts
that could result in a fire or electric shock. Never spill liquid of any
kind on the LCD TV.
18)
If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges. In the U.S. Section 810-21 of the National Electrical Code
provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
EXAMPLE OF ANTENNA
GROUNDING AS PER (NEC) NATIONAL I_
ELECTRICAL I ....ANTENNA
CODE / _ LEAD-IN WIRE
/ GROUNOc,AMyJ \
I _E _¢'_ ,r_" i DISCHARGEUNtT
I A /idA- I J7_I(NECsEoTION810-20)
L EQUIPMENT J¢"t /7"_ J-eROUNDINe
_j...1_-_.. (NECSECTION810-21)
POWER SERVICE GROUNDING ELECTRODE SYSTEM (NECART 250, PART H)
4
withinatriangleisintendedto tellthe
userthatpartsinsidetheproductarea riskofelectricshocktopersons.
triangleis intendedto tellthe
userthatimportantoperatingand
Theexclamationpointwithina
servicinginstructionsareinthe paperswiththeappliance.
_/" 'f"_> .j_ ANTENNA
I'-_/ CONDUCTORS
"_ GROUND CLAMPS
tc_L3232c_en_LO608.indb 4 2010/12/24 13:40:01
I
19) An outside antenna system should not be located in the vicinity of overhead power lines, other electric light, power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
20) Unplug this LCD TV from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power cord or plug is damaged or frayed. b. If liquid has been spilled into the LCD TV.
c. If the LCD TV has been exposed to rain or water. d. Ifthe LCD TV does not operate normally by following the operating instructions.
e. Ifthe LCD TV has been dropped or the cabinet has been damaged.
f. When the LCD TV exhibits a distinct change in performance - this indicates a need for service.
21 ) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer that
have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.
22) WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN,
23) WARNING: SMALL PARTS CAN PRESENT CHOKING HAZARD IF ACCIDENTALLY SWALLOWED. KEEP SMALL
24) WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all
25) CAUTION: The Power switch on this unit will not completely shut off all power from AC outlet. Since the power
26) CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS PLUG WITH A RECEPTACLE OR OTHER OUTLET
27) CAUTION: USE WITH OTHER STAND MAY RESULT IN INSTABILITY POSSIBLY CAUSING INJURY.
28) CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME
29) CAUTION: This LCD TV is for use only with the following optional accessory. Use with any other type of optional
Adjust only those controls that are covered by the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the
LCD TV to normal operation.
MOISTURE, DRIPPING OR SPLASHING. DO NOT PLACE LIQUID CONTAINERS (FLOWER VASES, CUPS, COSMETICS, ETC.) ABOVE THE SET (INCLUDING ON SHELVES ABOVE, ETC.).
PARTS AWAY FROM YOUNG CHILDREN. DISCARD UNNEEDED SMALL PARTS AND OTHER OBJECTS, INCLUDING PACKAGING MATERIALS AND PLASTIC BAGS/SHEETS TO PREVENT THEM FROM BEING PLAYED WITH BY YOUNG CHILDREN,
CREATING THE POTENTIAL RISK OF SUFFOCATION.
times.
cord serves as the main disconnect device for the unit, you will need to unplug it from the AC outlet to shut down all power. Therefore, make sure the unit has been installed so that the power cord can be easily unplugged from AC outlet in case of an accident. To avoid fire hazard, the power cord should also be unplugged from the AC outlet when
left unused for a long period of time (for example, when on vacation).
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
OR EQUIVALENT TYPE.
accessories may cause instability which could result in the possibility of injury. (All of the following accessories are manufactured by Panasonic Corporation)
Wall-hanging bracket: TY-WK3L2RW Always be sure to ask a qualified technician to carry out set-up.
5
I
t(_L3232(_en_LO608.indl) 5 2010/12/24 13:40:01
I
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Caution: To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by
Panasonic Corp. of North America could void the user's authority to operate this device.
FCC Declaration of Conformity
Model No. TC-L3232C
Responsible Party:
Contact Source:
email:
Flat panel displays are not always supported on the
proper stands or installed according to the manufacturer's
recommendations. Flat panel displays that are inappropriately
situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and may cause personal injury or
even death.
The consumer electronics industry (of which Panasonic is
a member) is committed to making home entertainment
enjoyable and safe. To prevent personal injury or death, be
sure to follow the following safety guidelines:
TUNE INTO SAFETY:
One size does NOT fit all. Follow the manufacturer's recommendations for the safe installation and use of your
flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don't allow children to climb on or play with furniture and
television sets.
Don't place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching
a program, especially on "larger than life" flat panel displays. Care should be taken to install the display where it
cannot be pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables
connected to the fiat panel display so that they cannot be
pulled or grabbed by curious children.
Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094
Panasonic Consumer Electronics Company 1-877-95-VIE RA (958-4372)
consumerprod ucts@panasonic.com
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory
(such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure the wall where you are mounting the display is appropriate. Some wall mounts are not designed to
be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional
installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.
Panasonic recommends that a qualified installer perform the wall-mount installation. See page 5.
The American Academy of Pediatrics discourages
television viewing for children younger than two years of age.
6
t(_L3232(_en_O608.indl) 6 2010/12/24 13:40:01
I
Accessories/OptionalAccessory
d Check you have all the items shown.
[] Remote Control [] Batteries for the [] Pedestal
Transmitter Remote Control ® TBL5ZX0084
@ N2QAYB000570 Transmitter (2)
@ AA Battery
How to assemble (p. 8)
[] Owner's Manual [] Quick Start Guide [] Product Registration Card (U.S.A.)
fOptional Accessory
Wall-hanging bracket
@ TY-WK3L2RW
The angle of wall-hanging bracket can be adjusted in "zero tilting (vertical)", "5-degree tilting", "10-degree tilting", "15-degree tilting"
and "20-degree tilting" for this TV.
( WARNING ) @ Customers assumes liability if mounting the unit themselves or if a Panasonic bracket is not used. Any damage resulting
from not having a professional installer mount your unit will void your warranty.
@ Always be sure to ask a qualified technician to perform any necessary set-up. Incorrect fitting may cause equipment to
fall, resulting in injury and product damage.
@ Do not mount the unit directly below ceiling lights (such as spotlights, floodlights or halogen lights) which typically give off
high heat. Doing so may warp or damage plastic cabinet parts.
@ Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the wall
before hanging bracket.
@ When using an angled-type wall hanging bracket, please ensure that there is sufficient space for the connecting cables
so that they do not to press against the wall when the TV is tilted forward.
@ For safety reasons, remove units no longer being used from their wall-mounted locations.
Please contact your nearest Panasonic dealer to purchase the recommended wall-hanging bracket. For additional details, please refer to the wall-hanging
bracket installation manual.
Back of the TV
Holes )r wall-hanging bracket installation
[] Child safety
wall-hanging bracket (not supplied with the TV)
(View from the side)
fixing the TV onto the
..........................................Depth of screw:
_M4
Minimum: 0.39" (10.0 mm) Maximum: 0,47" (12.0 mm)
@ 3>
o o
(D oo oo
O (D
©
o
>
o o
o
,2
7
I
tc_L3232c_en_O608.indb 7 2010/12/24 13:40:01
I
==Assembling the pedestal
® Fix securely with assembly screws ,_,_. (Total 4 screws) ® Tighten screws firmly.
Front
Base
==Set-up
® Fix securely with assembly screws CB). (Total 4 screws) ® Tighten screws firmly.
s ..........................................................................................................................................................................................................................................
Accessories
Assembly screws (4 of each)
,_A)
XSS4+ 16FJK XYN4+F12FJK size (M4 x 16) size (M4 x 12)
Bracket (1) Base (1)
Foam mat or thick soft cloth
( WARNING )
Do not disassemble or modify the pedestal.
® Otherwise the TV may fall over and become damaged, and personal injury may result.
( Caution -)
Do not use any pedestal other than that provided with this TV.
® Otherwise the TV may fall over and become damaged, and personal injury may result.
Do not use the pedestal if it becomes warped or physically damaged.
® If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic
Dealer immediately.
During set-up, make sure that all screws are securely tightened.
® If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal will not be strong
enough to support the TV, and it might fall over and become damaged, and personal injury may result.
( Caution )
Open
Close
¢ Incorrect installation may cause
battery leakage and corrosion, resulting in damage to the remote
control. ÷ Do not mix old and new batteries.
÷ Do not mix different battery types (such
Hook
as alkaline and manganese batteries).
÷ Do not use rechargeable (Ni-Cd)
Note the correct polarity (+ or -).
batteries.
® Do not burn or break batteries.
8
tc_L3232c_en_O608.indb 8 2010/12/24 13:40:01
I
Connections
Front of the TV
SD card _ll slot(p. 20) I_'_ _ '
PC terminal
Back of the TV
Back ofthe TV
VHF/UHF Antenna
Power Cord
(Connect after all the other
connections have been made.)
VHF/UHF Antenna
NTSC (National Television System Committee):
ATSC (Advanced Television Systems Committee): Digital TV Standards include digital high-definition television (HDTV), standard-definition television
(SDTV), data broadcasting, multichannel surround-sound audio and interactive television.
Cable
® You need to subscribe to a cable TV service to enjoy viewing their programming. ® You may need to subscribe to a high-definition (HD) cable service to enjoy HD programming.
The connection for high-definition can be done with the use of an HDMI or Component Video cable. (p. 10)
DIGITAL AUDIO OUT
CB,
@@
3>O
o o
gg
O ,-,-
O
o
"3
3>
o o o
Co Co
o
® When using a Cable box, external equipment and video cables shown in this manual are not supplied with the TV. ® For additional assistance, visit us at: www.panasonic.com/help
www.panasonic.ca
Connection references
Antenna terminal Pin terminals
HDMI terminal
to
® Firmly tighten by hand.
Insert firmly..nsert firmly.
9
I
tc_L3232c_enf_O608Jndl) 9 2010/12/24 13:40:0'
Best
To use HDMI terminals
Good
Basic
HDMI-DVI Conversion cable
® VIERA Link connection, please refer to p. 23 ® The HDMI connection is required for a 1080p signal.
_ To use COMPONENT terminals
I" I
.I.,
I I
I I
white
_C)To use COMPOSITE terminals
red
_I HDMI
red
red
__L COMPOSITE _ e.g, DVDoRreCOrder
white I white OUT
AM OUT
-' DVI OUT
L
_) LAUDIO OUT
green
__P_ COMPONENT
VIDEO OUT
_d_R_ AV Equipment
ye_llow "% AV Equipment
AVEquipment
e.g. Blu-ray Disc
) :. :_-:@1
t player
e.g. Blu-ray Disc player
e.g. Blu-ray Disc
player
e.g. VCR
® The Green terminal is shared for both the COMPONENT and COMPOSITE (VIDEO IN 1) connection.
When using COMPOSITE (VIDEO IN 1) connection the Yellow connector (Video) should be inserted into Green connection.
V-'_'BIB1_
Audio equipment
DIGITAL
Optical cable
® For HDMI-ARC (Audio Return Channel) connection, see p. 22
RGB PC cable
Conversion adapter (if necessary)
!
Audio cable
10
tc_L3232c_eng_O608Jndb 10 2010/12/24 13:40:0_
Conoectcab',ewhichmatchesthe
AUDIO IN
e.g. Amplifier
PC OUT Computer
@ Audio OUT
audio out terminal on the computer
I
Identifying Controls
Front of the TV
Remote control sensor within about 23 feet (7 meters) in front of the
TV set
Power indicator
on: red, off: no light)
C.A.T.S (Contrast Automatic Tracking System)
channelsin sequence
up/down
navigations
_ges the input mode
Chooses menu and submenu entries
button
® The TV consumes a small amount of electric energy even when turned off. ® Do not place any objects between the TV remote control sensor and remote control.
I_t_1'_'_4_ I
Closed Caption On/Off (p. 15)
Switches TV On or Off (Standby) Select source to watch (p. 19)
Displays Main Menu (p. 30)
Displays Sub Menu for special functions
(when available) (p. 16) Colored buttons
(used for various functions)
Volume up/down
Sound mute On/Off
Changes aspect ratio and zoom (p. 16, 36)
Switches to previously viewed channel or input
External equipment operations
(p. 27)
I
Selects Secondary Audio Programming (p. 15)
Exits from menu screen
L-- VlERA Link menu (p. 26-27)
Display VIERATOOLS Menu (p. 18)
Selects!OK/Change Go back to previous menu Channel up/down, when viewing from
ANT/Cable source
Displays or removes the channel banner (p. 15)
Operates the Favorite channel list
function (p. 16)
Numeric keypad to select any channel
or press to enter alphanumeric input in
menus
Use for digital channels. (p. 15)
g from SD Card (p. 20-21)
@@
©__
o (D
"3 "3
o_
o
o
11
I
tc_L3232c_en_O608findb 11 2010/12/24 13:40:0!
I
First Time Setup
First time setup screen is displayed only when the TV is turned on for the first time after the power cord is inserted into a wall outlet and when "Auto power on" (p. 34) is set to "No".
Turn the TV On with the POWER button
(TV) (Remote)
POWER
or
Configure your viewing mode
d_ Select your language
)select
@OK
(2)Select your viewing mode (Be sure to select "Home use")
)select
@OK
÷ Pleaseconfirm yourselection (Home Use) before pressing OK button.
If you select "Store Demonstration" by mistake in _2),
confirmation screen will be displayed.
)select
@OK
® Select "No" and return to previous screen (2]. ® If you select "Yes", Screen enters the store demonstration mode.
To display the "Set viewing mode" screen again as shown above and select "Home Use", do one of the following:
Press and hold down the side POWER button for at least five seconds.
Unplug power cord for 30 seconds and plug it again.
® If you use any other step other than _ then turn the TV off, or if you used the EXIT
button to quit before completing the settings, the next time you turn the TV on, "First
time setup" will not be automatically displayed.
The settings up to that point are saved.
You can start "First time setup" at any time. (p. 34)
® Language, ANT/Cable setup, Input labels, Clock can also be changed from the
Settings Menu. (p. 34)
12
tc_L3232c_en_O608.indb 12 2010/12/24 13:40:0!
I
Auto channel setup (ANT/Cable setup)
Select the connected Antenna in terminal
Not used: Go to _)
Select "Not used" when no wire is connected to the "Antenna/Cable" terminal. ® Typical when a Cable/Satellite box is connected to a TV AV input.
® Prevents accidental tuning to an unavailable signal, when Cable or Satellite box is
used.
Select "Start"
Skip: Go to Q
)select
(Labelinputs)
(Labelinputs)
@ 77
m,
Press to go back to
the previous screen
RETURN
@
® About broadcasting
systems Analog (NTSC):
Conventional broadcasting
Digital (ATSC):
New programming
that allows you to view
more channels featuring
high-quality video and sound
Start scanning the channels (Available channels are automatically set.)
This process may take up to 20 minutes.
® This step is not needed when a Cable or Satellite
box is connected to an AV input.
_) Complete the Auto program setup
Completion message is displayed when the Auto program scan is successfully completed.
- OK channel, return to @ -
Operation of the EXIT button during "First time setup" Press the button once to display confirmation screen. Press again to close
confirmation screen.
[EXIT confirmation screen]
Yes _ Exit "First time setup" No _ Return to the original screen.
If there is no available
(ANT/Cable setup). "Not used" will be selected.
_--!.. q
¢D
03
"0
13
I
tc_L3232c_en_O608Jndb 13 2010/12/24 13:40:1(
I
Give names to the TV's inputs (Label inputs)
When done, select NEXT and press OK to go to the next step.
Follow the instructions on screen to complete the
following operations.
Label: [BLANK] Not used/Blu-ray/DVD/DVD REC/HOME THTR/GAME/COMPUTER/
VCR/CABLE/SATELLITE/DVR/CAMERA/MONITOR/AUX/RECEIVER/MEDIA CTR/MEDIA EXT/OTHER
Select "Not used" for any back-panel input that has no device connected to it. Afterward, the input will be skipped when pressing INPUT, for your convenience.
The input labels can be changed at any time from the TV's setup menu.
Adjust the Clock (Set clock)
When done, select NEXT and press OK to go to the next step.
or
Follow the instructions on screen to complete the
following operations.
Complete the First time setup
Congratulations! You are done.
Press to go back to
the previous screen
RETURN
@
14
The First time setup can be repeated at any time.
Press MENU and select SETUP; then "First time setup".
ITo watch TV via a Cable box, Satellite receiver, or any other source (DVD, DVR,gaming device, etc.), press the INPUT button and select the appropriate input. I
tc_L3232c_en_O608Jndb 14 2010/12/24 13:40:1;
I
Watching TV
Turn power on
(Remote) (TV)
POWER
or
Select a channel number
Also available side CH button on the unit. [For CablelSatellite box connection]
- Use your connected box s remote contro.
® Reselect "Cable" or "Antenna" in "ANT in" of "ANT/Cable setup" to switch the signal
reception between cable TV and antenna. (p. 13, 28)
® The channel number and volume level remain the same even after the TV is turned
off.
Other Useful Functions
m_m
or _[_m
INPUT
® Please select correct input --> _ (p. 19)
To directly enter the digital channel
number
When tuning to a digital channel, press the button to enter the minor number in a compound channel
number.
example: CH15-1: _ _ _
Select the Audio mode for watching TV
SAP Digitalmode
Switches the Closed Caption mode On or Off
PressSAP to select nextAudio track (ifavailable)when receiving a digital channel.
Analog mode
Press SAP to select the desired Audio mode.
Each press of SAP will change the Audio mode. (Stereo/SAP/Mono)
® SAP is not available when watching TV with a Cable or Satellite box connected via HDMI. ® Contact your Cable or Satellite operator for instructions on enabling SAP with their box.
cc _ ==_ _ ==_ _
q
® Closed Caption is not available when watching TV with a Cable or Satellite box connected via HDMI. ® Contact your Cable or Satellite operator for instructions on enabling CC with their box.
Displays and removes information. When watching programming via the Antenna/Cable input,
shows the channel banner.
INF0 Channel Clock
Station Signal Picture imer identifier resolution mode remaining time
Closed caption Rating Level Aspect ratio
15
I
tc_L3232c_en_O608Jndb 15 2010/12/24 13:40:1;
I
Press FORMAT to cycle through the aspect modes (p. 36)
FORMAT b_ 4 _l 480i, 480p: FULL/JUST/4:3/ZOOM
Press SUB MENU to show the Sub Menu screen This menu consists of shortcuts to convenient functions.
Sub menu is only available when the TV is using the Antenna/Cable input, not when using Cable or Satellite box.
SUB
MENU
1080p, 1080i, 720p: FULL/H-FILL/JUST/4:3/ZOOM Use when the picture does not fill the whole screen (bars appears on either side of
the image) or portions of the picture is trimmed.
1. Some content, such as film-based movies, are available in extra-wide format. Top and bottom bars are unavailable.
2. Connected devices, such as Cable/Satellite box, DVD/Blu-ray players and game consoles have their own aspect (format) settings. Adjust the device's aspect settings.
--Specify favorites or type of channels to view when pressing the channel up/ down button.
channel (below)
(p. 29)
signal strength (p. 29)
FAVORITE
Channel numbers registered in Favorite are displayed on the favorite tune screen. Select the desired broadcast station with the cursor or use the number buttons. (p. 15)
FAVORITE
16
or
Set the Favorite channel
SUB
MENU
S
Delete a favorite channel
To change the page
FAVORITE
® Favorite channels cannot be set when using Cable or Satellite box.
Press repeatedly to change between pages (1/3, 2/3, 3/3 or exit)
Changes the page forward/backward
)select the list
number
)save the displayed
channel
or
m _1 _ select the list number
m _ (to save the channel
m _ _ without pressing OK)
E3
_select
_@deiete
_ (while holding down)
t(_L3232(_en_O608.indl) 16 2010/12/24 13:40:1:
I
Other Useful Operations
You can use the remote control keys to enter the alphanumeric characters.
Switches input mode.
G
ABC _ abc _ 123
Press each number key to cycle through the
alphanumeric character.
You need to enter the password when you access locked channel or inputs.
I
Navigation area
Inputyour 4-digitpassword
mm_
® If it is your first time entering the password, enter the password twice in
order to register it.
® Make a note of your password. Do not forget it. (If you have forgotten your
password, consult your local dealer.)
® When you select a locked channel, a message will be displayed that
allows you to view the channel after you input your password.
® Change password (p. 33)
LC}
@
£o
B
CY
--4
<
17
I
tc_L3232c_en_O608.indb 17 2010/12/24 13:40:1:
I
Using VIERA TOOLS
VIERATOOLS is the easy way to access the TV's special features. They are displayed as shortcut icons on the TV screen.
_ isplay VIERA TOOLS
Select the item
Set each item
® VIERA Link
nl_ VIERA Link (p.26-27)
® Slideshow
Press to exit from
a menu screen
EXIT
Press to go back
to the previous screen
RETURN
@
18
I_ Slideshow (p. 20-21)
® VlERA IMAGE VIEWER
VIERA IMAGE VIEWER (p. 20-21 )
® Eco mode
ml_ ECO/energy saving (p. 34)
tc_L3232c_en_O608.indb 18 2010/12/24 13:40:1,
I
Watchingcontentfromexternaldevices
With the connected equipment turned On
Display the Input select menu
INPUT
Select the input mode
(shortcut) press the corresponding NUMBER button on the remote
control to select the input of your choice. Or, press the INPUT
or
)select
(example)
_2_enter
Terminal Label
(example)
button repeatedly, to cycle through the available inputs. * set unused input to "Not used" (below) for quick skipping.
Select the input of your choice, then press OK.
® During the selection, if no action
is taken for several seconds,
the "Input select" menu disappears.
® The terminal and label (names)
of the connected equipment are displayed.
To label each of the inputs, see below.
® The input label will be displayed on the "Input select" screen if the Input label was
customized.
Operate the connected device directly by using its own remote control.
® PC adjustments (p. 31)
Label each input Select "Input labels" in "Setup"
® Labeling each input with names of connected devices such as DVD Player, Cable box, etc.
will help you to identify and switch between them.
See p. 34 for list of available label names.
You can also enter the label name directly. (Entering characters (p. 17))
_2_For each input, press _ to select a
label or _ to edit
19
I
tc_L3232c_en_O608.indb 19 2010/12/24 13:40:1,
I
ViewingphotoswithVIERAIMAGEVIEWER
The VIERA Image Viewer lets you easily view still images on the television by simply inserting an SD card into the VIERA SD card slot.
Insert the SD card
÷ Insert the card ÷ Remove the card
Gently insert the SD Card label
surface facing front.
Label
surface\_ Press in lightly.
Push until a_ on SD Card,
click is heard then reIease.
Cutout
Display "VIERA IMAGE VIEWER"
Using VIERA TOOLS (p. 18)
® Auto play setting
Image viewer auto
play (p. 34)
VIERA IMAGE VIEWER _ Displayed Thumbnail screen. Slideshow iiiii1_,,Start slideshow.
Select the data to be viewed
® Compliant card type (maximum
capacity): SDHC Card (32 GB), microSDHC Card (32 GB), SD
Card (2 GB), miniSD Card (2 GB), microSD Card (2 GB) (requiring
microSDHC Card/miniSD Card/ microSD Card adapter)
® If a microSDHC Card, miniSD Card
or microSD Card is used, insert / remove it togetherwith the adapter.
® For cautions and details on SD
Cards (p. 37)
Select the item
To start Slideshow
picture information is displayed.
Total number of images.
® Depending on the JPEG file format, "Information" contents may not be displayed
correctly. Refer to p. 37 (Data format for SD card browsing) for details.
View
Navigation area status
Press to exit from
a menu screen
EXIT
Press to go back to
the previous screen
RETURN
@
® To display/hide the Navigation area
INFO
E!
® Return to the Thumbnail view
Displays one at a time
20
tc_L3232c_en_O608Jndl) 20 2010/12/24 13:40:1,
Single photo view
RETURN
To previous photo
(While reading the data)
Slideshow
90 degrees (counter-clockwise)
90 degrees (clockwise)
I
To sort by Folder, month or date
In@
_i) Select the sort type
Folders (ascending order of numeric/alphabetical) Sort by month(ascending order of the month) Sort by date (ascending order of the date )
_2_Select the directory.
In @ or @
_i) Display "Photo settings" @ Select the item
RETURN
Go back to previous
screen
Adjust the picture/Audio
example :Picture menu Picture menu/Audio menu (p. 31-32)
ust
Set the Soundtrack
@change
Select the music from 5 options.
(Off/Music l/Music 2/Music 3/Music 4/Music 6)
Slideshow settings
RIE_RN
FR ;;D
ust
................................................................................................................................(ShortlFastlNormallSlowNery slow)
Set how many seconds each image is displayed in the Slideshow mode.
Turn the slideshow Repeat (cycle) function on or off (Off/On).
Select the transition effect shown between photos (Off/Wipe JWipe 1"/Wipe _/wipe
/Comb 1"S/Comb _/Dissolve/Checker wipe/Random/Array/Collage)
Select the display effect (Off/Sepia/Gray scale)
® To stop in mid-cycle @ Press
21
I
tc_L3232c_en_0608.h]db 21 2010/12/24 13:40:11
I
VIERA Link TM"HDAVI Control TM''
Simultaneously control all Panasonic "HDAVI Control" equipped components using one button on the TV remote. Enjoy additional HDMI Inter-Operability with compatible Panasonic products. This TV supports "HDAVl Control 5" function. Connections to equipment (DVD recorder DIGA, HD Camcorder, Home theater system, Amplifier, etc.) with HDMI cables
enables VlERA Link controls.
Equipment with the "HDAVI Control" function enables the following operations:
HDAVl Control or later ÷ Automatic Input Switching
HDAVI Control 2 or later @
HDAVI Control 3 or later @
HDAVI Control 4 or later @ HDAVI Control 5 @
mWhen adding new equipment, reconnecting equipment or changing the setup after the connection,
turn the equipment on and then switch the TV on. Set the input mode to HDMI1 or HDMI2 (p. 19), and make sure that the image is displayed correctly.
VIERA Link "HDAVI Control", is based on the control functions provided by HDMI and industry standard known as HDMI
CEC (Consumer Electronics Control), with unique function that we have developed and added. As such, its operation with other manufacturers' equipment that supports HDMI CEC cannot be guaranteed. Please refer to the individual manuals for other manufacturers' equipment supporting the VIERA Link function.
÷ Power on link
@
Power off link
@
Default speakers
@
Speaker control
VIERA Link control only with the TV's remote control
@
Unselected device energy save (for available equipment only) Provides setting information (Language, time. etc.)
@
Automatic lip-sync function
Energy saving mode (with Quick Start mode)
Audio Return Channel Audio Return Channel (ARC) is a function that enables digital sound signals to
be sent via an HDMI cable back from the TV to a connected audio device.
HDMI cable
This function needs an HDMI compliant (fully wired) cable. Non-HDMI-compliant cables cannot be utilized. It is recommended that you use Panasonic's HDMI cable. Recommended part number: RP-CDHS15 (4.9 ft/1.5 m), RP-CDHS30 (9.8 ft/3.O m), RP-CDHS5O (16.4 ft/5.0 m)
* For more details on the external equipment's connections, please refer to the operating manual for the equipment.
22
tc_L3232c_en_O608.indb 22 2010/12/24 13:40:1'
Terminal overview
Back of the TV
Connecting DVD Recorder (DIGA)
4---
HDMI cable
DVD recorder (DIGA)
with VIERA Link function
Connecting Home theater system/AV amp HDMI 1is recommended.
HDMI cable
Optical cable AV amp with DVDrecorder(DIGA)
No optical cable is necessary when connecting a Home Theater supporting "HDAVI control 5" with an HDMI cable. Audio will be supported via ARC (Audio Return Channel) (p. 22)
® One AV amp and one DVD recorder (DIGA) can be operated with this unit.
Connecting HD Camcorder/Digital camera Press INPUT and select an available HDMI terminal, then connect the camcorder to this input. After connection, confirm the HDAVI control functions. (p. 24-27)
Hometheater systems with VIERALinkfunction
VlERA Link function with VIERALinkfunction
....................................................................................
@
<
m
>
F--
_5"
-4
E3
<>
C)
o
"-I
q- o
-4
HDMI / mini HDMI cable
HD Camcorder LUMIX with
with VlERA Link VlERA Link
function function
If connection (or setting) of equipment compatible with HDAVI control is changed, switch the power of this unit Off and
On again while the power of all equipment is On (so that the unit can correctly recognize the connected equipment) and check that the connected equipment playback operates.
® Individual HDMI equipment may require additional menu settings specific to each model. Please refer to their
respective manuals.
® When audio from other equipment connected to this unit via HDMI is output using "DIGITALAUDIO OUT" of this unit,
the system switches to 2CH audio. (When connecting to an AV amp via HDMI, you can enjoy higher sound quality.)
® Some devices use Mini-HDMI terminal. HDMI (type A) to Mini-HDMI (type C) cable or adapter should be used.
23
I
tc_L3232c_enft®608.indb 23 2010/12/24 13:40:1_
I
M_I=1z_T__III_TI__[ff_ l_i_l F:W_II1_1__JI_
To use all VIERA Link functions: After everything is connected, in VIERA Link settings menu, set "VIERA Link" to "On". Some features are disabled depending on the "HDAVI Control" version of the equipment. Please check the list (p. 22)
_ Display the menu
Select "VIERA Link settings" in "Setup"
Select "VIERA Link"
Select "On"
Press to exit from
a menu screen
EXIT
(default is On)
Select and make other settings
Press to go back
to the previous screen
RETURN
@
24
tc_L3232c_enftO608.indb 24 2010/12/24 13:40:1_
I
When using a Blu-ray Disc player, DVD player/recorder or Home theater system, the TV will automatically change to the appropriate input, when playback begins on one of those devices.
For a Home theater system the speakers automatically switch to the theater system.
Yes: The TV is turned on automatically and switches to the appropriate HDMI input whenever VIERA Link compatible equipment is initially turned on and the Play mode is selected.
When "Yes" is selected and the TV isturned off, all connected VIERA Link compatible equipment is also automatically turned off.
A Panasonic DVD Recorder will not turn off if it is still in Rec mode.
The TV remains on even if the VIERA Link compatible equipment is turned off.
Quick Start: When TV is turned off, all connected VIERA Link compatible equipment is moved to ECO Standby mode* automatically under these conditions.
Power off link:(Yes), The connected equipment has "HDAVI Control 4 or later (with Quick Start mode)"
* Minimum power consumption of Standby condition for the equipment.
Yes: The connected VIERA Link compatible equipment will be turned off automatically when not in use under these conditions.
The connected equipment has "HDAVI Control 2 or later" (for available equipment only) [ Example of timing for operation ]
When the input is switched from the HDMI.
"TV" is the default setting. To set the Home theater system as Default speakers, change the Default speakers setting from "TV" to "Theater". Sound will be output from the Home theater whenever the TV is powered on.
@ < rn
;U >
r--
_5"
-q
E3
<>
O o
"-I
o
-q
Minimizes lip-sync delays between the picture and audio when you connect to a Panasonic theater system or
Amplifier.
The following information about the TV settings can be transmitted to each piece of equipment (Recorder/Home theater/Player) that has "HDAVI Control 3 or later" function connected to a TV with an HDMI cable.
Transmittable data Recorder Home theater
(i7 On Screen Display Language setting
(English/Espa5ol/Frangais) 0 0 0
@.3Panel Aspect Ratio
(16:9 fixed) O O O
(3_Closed caption information
(Mode/CC type/Digital setting) O ......
@ Channel information
(Input signal/Channel list/Caption information) O ......
® There is a possibility that all the GUI language information might be set from equipment that has an HDMI CEC
function connected to the TV with an HDMI cable. Depending on the operating conditions or the specification for each piece of equipment the setting may or may not be applied.
® For more details on the external equipment's operation, please refer to the operating manual for the equipment.
Player
25
I
tc_L3232c_en_O608Jndl) 25 2010/12/24 13:40:1_
I
Somefeaturesaredisableddependingonthe"HDAVIControl"versionoftheequipment. Pleasecheckthelist(p.22)
_ Display the VIERA Link menu
or
Select the item
Items in the VIERA Link menu may be grayed out if no compatible equipment is connected (must be HDAVI Control 2 or later) or if the equipment has not initiated a connection with the TV. In that case, switch the equipment's power Off and On while the
TV is On. For further details, see "VIERA Link" on page 24.
Press to exit from a menu screen
EXIT
Press to go back to the previous
screen
RETURN
@
26
Select
-change
Set
tc_L3232c_enftO608.in(Ib 26 2010/12/24 13:40:1_
I
You can select the Home theater or TV speakers for audio output.
Control the theater speakers with the TV remote control.
This function is available only when a Panasonic Amplifier or Player theater is connected.
Select "Speaker output" Select "Home theater" or "TV"
)select
In the VIERA Link menu, you can select HDMI connected equipment and access it quickly. Continue using your TV remote control to operate the equipment, pointing it at the TV.
_1_Select "VIERA Link control" ® If there is more than one equipment item, a number
Select the equipment you want to access
(Recorder/Home theater/Player/Camcorder/LU MIX/ Digital camera)
® Using VIERATOOLS (p. 18)
)select
You can select available items only.
Home theater: Adjustment for the equipment
Volume up / down ÷
Mute ÷
÷ The sound of the TV is muted. ÷ When the equipment is turned off, the TV speakers
÷ Selecting "Home theater" turns the equipment on
TV: The TV speakers are on.
after the name indicates the number of items. (e.g. Recorder I/Recorder 2/Recorder 3...)
® The number of equipment items that can be connected
is three for recorders, and a total of three for Home theaterlPlayerlCamcorderlLU MiX/Digital camera.
® There is a limit to the number of HDMI connectors.
Operate the equipment with the TV remote control, pointing it at the TV
® To operate the equipment, read the manual of the
equipment.
MUI_
take over.
automatically if it is in Standby mode.
Available TV remote control buttons
Whether an operation is available differs depending on the connected equipment.
Move the cursor/Select Set/Access
Return to previous menu
&% Display the functions
O menu on the equipment
_ Available when the purpose of the keys
E×I_
is displayed on screen Exit
Channel Up!Down 0-9
_iiiiii m'll
Play Stop
Reverse/Forward
Skip Reverse/Forward
Pause Closed caption
SAP (Select Audio Mode) Select digital subchannel
@
<
m ;U
3>
r--
_5"
-4
ED
<>
C)
o
,m
q- o
-4
Returns the input selection of the device selected with the VIERA Link Controlto the TV input. Select "Back to TV"
)select
27
I
tc_L3232c_eng_O608.indb 27 2010/12/24 13:40:1!
I
Editing and Setting Channels
The current channel settings can be changed according to your needs and reception conditions.
the menu
Display
Select "Setup"
Select "ANT/Cable setup"
Press to exit from a menu screen
EXIT
Automatically searches and adds available channels to the memory.
_1_Select "ANT in"
÷Select "Cable" or "Antenna"
Or select "Not used" (p. 13).
Select "Auto program"
>next
)select
Select a scanning mode (p. 13)
)OK
® After the scanning is completed, select "Apply".
(see p. 29 _5_).
® All previously saved channels are erased.
28
tc_L3232c_en_O608.indb 28 2010/12/24 13:40:1!
I
Usethisprocedurewhenchangingthechannelsetupor changingthechanneldisplay. Also,usethistoaddorskipchannelsfromthechannellist
® Caption
manually. Youcanselectachanneltuningmode(Digitalonly/Analog only)in"Channelsurfmode"(p.34)
Select "Edit"
Edit
Select the item to edit
Favorite
Caption Add
R G
Go back to the previous page
Proceed to
_next page
To cancel the Edit
÷ Caption:
Changes the station identifier
÷ Favorite:
Registers channels to the Favorite List
÷ Add:
Adds or skips channels
Select or edit the station identifier.
RETURN
(maximum 7 characters available) ® Favorite
__i se'ect _)RN
__2) set
ISet favorite I Select the number
® Add
Press OK to select "Yes (add)" or "No (skip)" _ RETURN
@ Move the cursor to a channel number
Select "Apply"
@ FR
m.
{:3._ 03
O
::3" "-I
O_
Check the signal strength if interference is found or freezing occurs on a digital image.
® If the signal is weak, check the antenna.
If no problem is found, consult your local dealer.
m _ [_ or _i_change
l'_ @OK
_V channel
intensity
® Not available if "Cable" is selected in "ANT in" (see p. 28). ® Available only for digital antenna channels.
29
I
tc_L3232c_en_O608.h]db 29 2010/12/24 13:40:2I
I
How to Use Menu Functions
Various menus allow you to make settings for the picture, sound, and other functions so that you can enjoy watching TV best suited for you.
the menu
_ Display ® Shows the functions thatcan beadjusted.
® Some functions will be disabled depending on
the type of input signal.
Press to exit from
a menu screen
EXIT
Menu structure
(example: Input labels)
Menu bar Press OK to move to the Menu items.
Press OK to proceed to next screen if available.
information
Select the menu
gs
settings
On/Off timer)
(Channel, Game, Program etc.)
Caption setting
(other settings)
Adjust or select a menu item
items
guide
or
select
ust
Press to go back
to the previous screen
RETURN
@
(example: Picture menu)
3O
tc_L3232c_en_O608Jndb 30 2010/12/24 13:40:2(
I
@ "Reset to default" will be grayed out if no changes are made in the following menus:
"Picture", "PC adjustments", "Audio" and "Closed caption".
t::i (,, i(ill, "--_Jl! l,,,,lnllilll;-)NIIi_[o [;-](o] ilNo][_ (!l(;-](l l! _! I"hL_
Reset to defaults Resets all picture adjustments to factory default settings except for "Advanced picture". Picture mode Vivid Provides enhanced picture contrast and sharpness for viewing in a well-lit room.
Standard Recommended for normal viewing conditions with subdued room lighting. Cinema For watching movies in a darkened room. It provides a soft, film-like picture.
Custom (Photo} Customizes each item according to your taste.
Back light Adjusts the luminance of the back light.
Contrast, Adjusts the color, brightness, etc. for each picture mode to suit your taste Brightness, Color, Display range Contrast/Brightness/Color/Sharpness : 0 - 100 Tint, Sharpness Tint : -50 - +50
Color temp. Cool/Normal/Warm Selects a choice of Cool (blue), Normal, or Warm (red) color. A.I. picture Off/On Controls dark areas without affecting the black level or brightness in the overall picture. C.A.T.S. Off/On Automatically adjusts the screen brightness according to the ambient lighting condition.
Video NR Off/On Reduces noise, commonly called snow. Leave it off when receiving a strong signal.
Some menus are grayed out depending on the input signal or condition. (e.g. "Zoom adjustments" will be grayed out if the aspect is not set to Zoom.)
Aspect Screen format JUSTI4:31ZOOMI Changes the format (aspect ratio). adjustments FULL/H-FILL Lets you choose the aspect depending on the format of
H size Size l/Size 2 Adjusts the horizontal display range to reduce noise of both side
Zoom Adjusts vertical alignment and size when aspect setting is "ZOOM". adjustments
PC adjustments Reset to defaults Resets PC adjustments.
Sync H & V The Hand V sync signals are input from the HD/VD connector. (p. 39)
Dot clock
H-position Adjusts the horizontal position.
V-position
Photo is displayed in JPEG menu.
received signal. (p. 36)
edges of an image. Size 2: Adjusts the image size according to the aspect mode to reduce noise. (p. 36)
On green Uses a synchronized signal on the Video G signal, which is
Alleviates the problem if a picture appears to be vertically-striped, flickers partially or is blurred.
input from the G connector. (p. 39)
° I ,,
". @ - IO
o o
Adjusts the vertical position.
@
-F O
O C
00 (D
(D r-
-I"1 r- "m
o o 00
Clock phase
Input
resolution
H-frequency
V-frequency
Alleviates the problem if the whole picture appears to flicker or is blurred. First adjust the Dot Clock to get the best possible picture, then adjust the clock Phase so that a clear picture appears.
@ It may not be possible to display a clear picture due to poor input signals.
Switches to wide display.
@VGA (640x480 pixels), WVGA (852x480 pixels), XGA (1,024x768 pixels), WXGA
(1,280x768 pixels)
@ Options change depending on signals
Displays the H (Horizontal)IV (Vertical) frequencies. Display range
Horizontal:15 - 110 kHz Vertical: 48- 120 Hz
31
I
t(_L3232(_en_O608.indl) 31 2010/12/24 13:40:2
I
Some menus are grayed out depending on the input signal or condition. (e.g. "3:2 pulldown" will be grayed out if the input signal is high definition or you are viewing photos, etc.)
Advanced
3D Y/C filter Off/On Minimizes noise and cross-color in the picture. Color matrix SD/H D Selects image resolution of component-connected devices.
SD: Standard Definition HD: High Definition Only used with 480p video signal.
MPEG NR Off/On Reduces noise of specific digital signals of DVD, Cable box, etc.
Black level Dark/Light Selects Dark or Light. Valid only for external input signals.
3:2 pulldown Off/On/Auto Adjusts the picture recorded in 24 fps for optimum quality.
Reset to defaults Bass
Treble
Balance
Advanced audio Surround
Volume leveler TV speakers
HDMI 1-2 in
I_| li I i i [:-] di.:'[_ i | I i[, _ II_ |!----_':.1 ilia.Ill{.] Ii!:.ll[_.li_illiilll]_'TLl]iiEilil[;l[, [_ [,lt!:.l[_r, l, _i{_l t[, iilli[: _
If the Timer settings are grayed out, first set the clock (see p. 34) and make sure "Auto power on" is set to "No" (see p. 34)
Sleep (minutes) 0/15/30/60/90 Select how long for the TV to automatically turn off.Sleep (Off timer)
Timer 1-5 Timer set Enables or disables this timer. (Off/On) (On/Off timer) Inputs Sets the input to select when the TV turns on.
Channel Sets the channel to select when the TV turns on.
Day Sets the day when the TV turns on.
On time Sets the time when the TV turns on. The TV will turn off after 90 minutes or as
Off time Sets the time when the TV turns off within 24 hours.
Resets Bass, Treble, and Balance adjustments to factory default settings. Increases or decreases the bass response.
Increases or decreases the treble response. Emphasizes the left / right speaker volume.
Off/On Enhances audio L/R response when listening to stereo.
Minimizes volume disparity after switching to external inputs.
Off/On Switches to "Off" when using external speakers.
Digital/ The default setting is "Digital" for the HDMI connection. (Digital Comp.Nideo 1/ input signal)
Video 2
[SUN/MON/TUE/WED/THU/FRI/SAT(displays the nearest future date) MON-FRI/SAT-SUN/DAILY/Every SUN/Every MON/Every TUE/Every WED/Every THU/Every FRI/Every SAT]
specified.
Off: "Surround" and "Volume leveler" do not work if "Off" is selected.
Select audio input terminal when DVl cable is connected. (Analog audio input signal)
32
t(_L3232(_en_O608.indl) 32 2010/12/24 13:40:2
I
lilt,all I[0I_!'. I[eI0][&,1_'1eIt,10]llT_'eImi_1il i[t,]l_'lle]Ib'li[e_,vAv&,ll(elle]K_vL_i|_ _ _IK_illKe]liivAv_|_ _li[e |e]_ _| [e]i_1_[_e]i|_ You will be asked to enter your password each time you display the Lock menu.
Password setting/entering (p. 17) Set "Custom" in "Mode" to specify "Channel", "Game" and "Program" settings.
Mode Off Unlocks all the Lock settings of "Channel", "Game" and "Program".
All Locks all the inputs regardless of the Lock settings of "Channel", "Game" and
Custom Locks specified inputs of "Channel", "Game" and "Program".
Channel Mode Set channel lock status. (Off/All/Custom) (These channels All: Locks all channels
will be blocked Off: Unlocks all channels
regardless of the Custom: Locks specified channels. Set "Channel 1" - "Channel 7" program rating.) Channel 1-7 Select a channel to lock. (Select up to 7 (1-7) channels to block.)
Game On/Off Locks Channel 3, Channel 4, and external inputs. Program Mode Set program lock status. (Off/On) "V-chip" technology enables restricted shows to
(To set a rating lock according to TV ratings. On: Set each rating level (MPAA, US.TV, C.E.L.R., level) C.F.L.R.)
Change Change the password. Input the new 4-digit password twice. password
MPAA Select U.S. movie ratings to lock. U.S.TV U.S. TV program ratings. For more
C.E.L.R. Canadian English ratings. (p. 35) C.F.L.R. Canadian French ratings.
"Program".
information
This television is designed to support the "Downloadable U.S. Region Rating System" when available. (Available only in U.S.A.)
The Off rating is independent of other ratings.
When placing a lock on a specific-age-based-rating level, the Off rating and any other more restrictive ratings will also be blocked.
IccJ[_]['_1 [_.]03]lt'_ ID]_J _ li_t_. I[_..1,'I111111
The television includes a built-in decoder that is capable of providing a text display of the audio. The program being viewed must be transmitting the Closed caption (CC) information. (p. 38)
@
-I-
o
o C
or) o
o
¢..
-TI i-
-.m c)
o oo
Reset to defaults Resets all Closed caption settings to factory default settings. Mode On/Off/ On: To display Closed captions.
Analog CC1-4/T1-4 Choose the Closed caption service of Analog broadcasting.
Digital Primary/SecondJ The Digital Closed caption menu lets you configure the way you choose to view
Digital setting Size Text size (Set display Font Text font
settings in digital program) Style Text style (Raised, Depressed, etc.)
CC on mute CC on mute: To display Closed captions when the audio is muted.
Service 3141516 the digital captioning.
Foreground Color of text Fore. opacity Opacity of text
Background Color of text box Back. opacity Opacity of text box
Outline Outline color of text (Identify the setting options on the screen.)
(When not using, select "Off").
CC1-4: Information related to pictures (Appears at the bottom of the screen) T1-4: Textual information (Appears over the entire screen)
The settings in "Analog" or "Digital" depend on the broadcaster.
33
I
tc_L3232c_engO608.indb 33 2010/12/24 13:40:2
I
iiii____i__!_:_'_;il,:ii !i_i_i__!ii___;_i_iiii_ ____i_i_i_i_i_i'iiillii!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!li!i!llili
Channel surf All/Favorite/ Sets the mode to select the channel with the Channel up/down button. mode Digital only/ Favorite: Only channels registered as FAVORITE. (p. 16)
Analog only
Language English/ Selects the screen menu language.
Clock Adjusts the clock. (p. 14)
EspaSol/ Fran_:ais
Input labels (Display labels
of connected devices)
Selects the terminal and label of the external equipment.
Devices connected to external input terminals can be labeled for easier identification during the input selection. (input select (p. 19)) Terminals: HDMI 1-2/Comp./Video l/Video 2/PC
CABLE/SATELLITE/DVR/CAMERA/MONITOR/AUX/RECEIVER/MEDIA CTR/MEDIA EXT/
I Label: [BLANK] Not used/Blu-ray/DVD/DVD REC/HOME THTR/GAME/COMPUTER/VCR/
OTHER
You can also enter the label name directly. (Entering characters (p. 17))
ECO/energy
saving
Power save (Standard/
Saving)
Nosignal for 10 minutes
(Stay on/Power TV off)
No activity for 3 hours
(Stay on/Power TV off)
Reduces screen brightness to lower power consumption. Eye-friendly for viewing in a dark room.
To conserve energy, the TV automatically turns off when NO SIGNAL and NO OPERATION continue for more than 10 minutes.
Not in use when "Auto power on" is set to "Yes", or "On/Off Timer" is set.
"No signal for 10 minutes was activated" will be displayed for about 10 seconds when the TV is turned on for the first time after the power was turned off by "No
signal for 10 minutes".
The on-screen display will flash 3, 2 and 1 to indicate the last three (3) remaining minutes prior to the shut-off.
To conserve energy, the TV automatically turns off when no operation of remote and side panel key continues for more than 3 hours.
Not in use when "Auto power on" is set to "Yes", or "On/Off Timer" is set, or while "PC inputs" is selected.
"No activity for 3 hours was activated" will be displayed for about 10 seconds when the TV is turned on for the first time after the power was turned off by "No activity
for 3 hours".
The on-screen display will flash 3, 2 and 1 to indicate the last three (3) remaining minutes prior to the shut-off.
Advanced setup Auto power on Turns TV On automatically when the cable box or connected device is turned On.
(No/Yes) TVAC cord must be plugged into this device. TV turns on every time the power is restored. Image viewer Slideshow/ Sets the playback type to play back SD cards automatically.
auto play Thumbnail/ Set later: "Image viewer settings" menu will be displayed repeatedly.
Set later/Off "Viewing photos with VIERA IMAGE VIEWER" (p. 20)
First time setup Restarts the first time setup from "Language" setting. (p. 12)
About Displays TV version and software license.
Reset to defaults Performing Reset will clear all settings made with Setup, such as channel
settings.
Password setting/entering (p. 17)
34
t(_L3232(_en_LO608.indl) 34 2010/12/24 13:40:2
I
Ratings List for parental control
"V-chip" technology enables you to lock channels or shows according to standard ratings set by the entertainment industry.
U.S. MOVIE RATINGS (MPAA)
NR
G _ _
PG
PG-13
R
NC-17
X
NO RATING (NOT RATED)AND NA (NOT APPLICABLE) PROGRAMS. Movie which has not been rated or where rating does not apply.
GENERAL AUDIENCES. All ages admitted. PARENTAL GUIDANCE SUGGESTED. Some material may not be suitable for children.
PARENTS STRONGLY CAUTIONED. Some material may be inappropriate for children under 13. RESTRICTED. Under 17 requires accompanying parent or adult guardian.
NO ONE 17AND UNDER ADMITTED. ADULTS ONLY.
U.S. TV PROGRAMS RATINGS (U. S. TV)
NR (Not Rated) TV-NR
TV-Y
Youth
TV-Y7
TV-G
TV-PG
Guidance
TV-14
TV-MA
FV: Fantasy/Cartoon Violence. V: Violence S: Sex L: Offensive Language D: Dialogue with sexual content.
÷ Viewable ÷ Blocked
÷ Viewable ÷ Blocked ÷ FV Blocked
÷ Viewable ÷ Blocked ÷ Viewable
÷ Blocked ÷ D,L,S,V (all selected)
÷ Any combination of
D, L,S,V
÷ D,L,S,V (all selected) ÷ Any combination of
D, L,S,V
÷ L,S,V (all selected) ÷ Any combination of
L,S,V
Not Rated.
All children. The themes and elements in this program are specifically designed for a very young audience, including children from ages 2-6.
Directed to older children. Themes and elements in this program may include mild physical or comedic violence, or may frighten children
under the age of 7. General audience. It contains little or no violence, no strong language,
and little or no sexual dialogue or situations.
Parental guidance suggested. The program may contain infrequent coarse language, limited violence, some suggestive sexual dialogue and situations.
Parents strongly cautioned. This program may contain sophisticated themes, sexual content, strong language and more intense violence.
Mature audiences only. This program may contain mature themes,
profane language, graphic violence, and explicit sexual content.
@
-i-5.
o
8E
0o
C_
-n o oo
o3
gs__
CANADIAN ENGLISH RATINGS (C. E. L. R.)
E
C Programming intended for children under age 8. No offensive lanquage, nudity or sexual content.
C8+ Programming generally considered acceptable for children 8 years and over. No profanity, nudity or sexual content.
G General programming, suitable for all audiences.
PG Parental Guidance suggested. Some material may not be suitable for children.
14+ Programming contains themes or content which may not be suitable for viewers under the age of 14. Parents 18+ 18+ years old. Programming restricted to adults. Contains constant violence or scenes of extreme violence.
Exempt - Exempt programming includes: news, sports, documentaries and other information programming, talk shows, music videos, and variety programming.
are strongly cautioned to exercise discretion in permitting viewing by pre-teens and early teens.
CANADIAN FRENCH RATINGS (C. F. L. R.)
E
8 ans÷
13 ans+
ans÷
18 ans+
( Caution @
The V-Chip system that is used in this set is capable of blocking "NR" programs (non rated, not applicable and none) as per FCC Rules Section15.120(e)(2). If the option of blocking "NR" programs is chosen "unexpected and possibly confusing results may occur, and you may not receive emergency bulletins or any of the following types of programming:"
Emergency Bulletins (Such as EAS messages, weather warnings and others)
Locally originated programming News Political Public Service Announcements Religious Sports Weather
Exempt - Exempt programming. General - Programming intended for audience of all ages. Contains no violence, or the violence content is minimal or is depicted appropriately.
8+ General - Not recommended for young children. Programming intended for a broad audience but contains light or occasional violence. Adult supervision recommended. Programming may not be suitable for children under the age of 13 - Contains either a few violent scenes or one or more sufficiently violent scenes to affect them. Adult supervision strongly suggested.
Programming may not be suitable for children under the age of 16 - Contains frequent scenes of violence or intense violence.
Programming restricted to adults. Contains constant violence or scenes of extreme violence.
I
35
tc_L3232c_en_O608Jndb 35 2010/12/24 13:40:2
I
Technical Information
Press the FORMAT button to cycle through the aspect modes. This lets you choose the aspect depending on the format of the received signal and your preference. (p. 16) (e.g.: in case of 4:3 image)
® FULL ® JUST
I_ 4 --I I_ 4 _1
Enlarges the 4:3 image horizontally to the screen's side edges. Stretches to justify the 4:3 image to the four corners of the (Recommended for anamorphic picture) screen.
® H-FILL
I_ 4 _1 I 16_1
(Recommended for normal TV broadcast) ® 4:3
I_ 4 _1
Enlarges the 4:3 image horizontally to the screen's side edges. The side edges of the image are cut off.
® ZOOM
I_ 4 --I I--16--1
Enlarges the 4:3 image to the entire screen. (Recommended for Letter Box)
® Zoom adjustments
Vertical image position and size can be adjusted in "ZOOM".
_1_Select "Zoom adjustments" on the "Picture" menu. (p. 31 ) @ V-position: Vertical position adjustment (3_V-size: Vertical size adjustment
® To reset the aspect ratio ÷ @ (OK)
Standard (Note that "Image retention" of the side bar may occur from
displaying it for a long time.)
® 480i (4:3), 480i (16:9), 480p (4:3), 480p (16:9):
FULL, JUST, 4:3 or ZOOM
® 1080p / 1080i/720p:
FULL, H-FILL, JUST, 4:3 or ZOOM
I:1_.-T_
® Aspect Ratio: 4:3
Size 1 Size 2
® The width will be decreased on both sides to
reduce noise.
® Aspect Ratio: FULL/JUST(H-FILL/ZOOM)
® The width will be increased on both sides to
reduce noise.
36 See page 31 for more information
tc_L3232c_en_O608Jndb 36 2010/12/24 13:40:2
I
IJ)_T3161i11'F_161"1,-")J][_,_'Z;_]
Photo: Still images recorded with digital still cameras compatible with JPEG files of DCF* and EXIF**
Data format: Baseline JPEG (Sub-sampling: 4:4:4, 4:2:2 or 4:2:0) Max. number of files: 9,999 image resolution: 160 x 120 to 20,000,000
* DCF (Design rule for camera file system): A Japan Electronics and Information Technology Industries Association's standard
( Caution ) @ AJPEG image modified with a PC may not be displayed.
@ Partly degraded files might be displayed at a reduced resolution.
standards
** EXIF (Exchangeable Image File Format)
(N D
@ Folder structure viewed in PC
_DCIM
100_PANA-
m000001.JpG_4-digit arbitrary characters + 4-digit file number
i P1000002.JPG|@ Usable characters: 1-byte "a to z", "Ato Z", "0 to 9," and ....
I P1000003.JPG I P1000004.JPG _
@ The folder and file names may be different depending on the digital camera used. @ For the suitable SD Memory Cards, please confirm the latest information on the following website.
http://panasonic.jp/support/globallcs (This site is in English only)
@ Use an SD Card which meets SD standards. If not, it may cause the TV to malfunction. @ Do not remove the card while the unit is accessing data (this can damage card or unit). @ Do not touch the terminals on the back of the card.
@ Do not subject the card to high pressure or impact. @ insert the card in the correct direction (otherwise, card or unit may be damaged). @ Electrical interference, static electricity or erroneous operation may damage the data or card. E @ Back up the recorded data at regular intervals in case of deteriorated or damaged data or
erratic operation of the unit. (Panasonic is not liable for any deterioration or damage of recorded data.)
Created automatically 3-digit folder number + 5-digit arbitrary characters
[_,_3111BITt__ [FJlllh'1_i_/Ili_] [.1J)[_,_'t;k'"l
C
24 mm
kVi1:1t,;_'lIK'i'l,_lEI-'IJT_'\vAI[_S11I_1'''_
HDMI connections to some Panasonic equipment allows you to interface automatically. (p. 23) @ This function may not work normally depending on the equipment condition. @ The equipment can be operated by other remote controls with this function on even if TV is in Standby mode. @ image or sound may not be available for the first few seconds when the playback starts. @ image or sound may not be available for the first few seconds when Input mode is switched.
@ Volume function will be displayed when adjusting the volume of the equipment. @ If you connect equipment that has "HDAVl Control 2 or later" function to the TV with HDMI cable, the sound from DIGITAL
AUDIO OUT terminal can be output as multi channel surround.
@ "HDAVl Control 5" is the newest standard (current as of December, 2010) for the HDAVl Control compatible equipment.
This standard is compatible with the conventional HDAVl equipment.
37
@
o ::3"-
'm o
'm
6"
o 'm
I
tc_L3232c_en_O608.h]db 37 2010/12/24 13:40:2;
I
-'Is];AIl._.],l,[_._i [.],
HDMI (high-definition multimedia interface) allows you to enjoy high-definition digital images and high-quality sound by connecting
the TV unit and HD devices.
HDMI-compatible equipment ('1) with an HDMI or DVl output terminal, such as a Cable or Satellite box or a DVD player, can be connected to the HDMI connector using an HDMI compliant (fully wired) cable.
@ HDMI is the world's first complete digital consumer AV interface complying with a non-compression standard. @ If the external equipment has only a DVl output, connect to the HDMI terminal via a DVl to HDMI adapter cable (*2).
@ When the DVl to HDMI adapter cable is used, connect the audio cable to the audio input terminal. @ Audio settings can be made on the "HDMI 1 in" or "HDMI 2 in" menu screen. (p. 32)
Applicable audio signal sampling frequencies (L.PCM): 48 kHz, 44.1 kHz, 32 kHz
( Caution "_ @ Use with a PC is not assumed.
@ All signals are reformatted before being displayed on the screen. @ If the connected device has an aspect adjustment function, set the aspect ratio to "16:9". @ These HDMI connectors are "type A". @ These HDMI connectors are compatible with HDCP (High-Bandwidth Digital Content Protection) copyright protection. @ A device having no digital output terminal may be connected to the input terminal of either "COMPONENT" or "VIDEO" to
receive analog signals.
@ The HDMI input terminal can be used with only the following image signals: 480i, 480p, 720p, 1080i, 1080p.
Match the output setting of the digital device.
@ For details of the applicable HDMI signals, see p. 39.
('1): The HDMI logo is displayed on an HDMI-compliant device.
(*2): Enquire at your local digital equipment retailer shop.
I.] [e]i f:1! r_,_!JJ][e][.]ei IF.TI?III?_ I
You can enjoy your Home theater by connecting a Dolby Digital (5.1 channel) decoder and "Multi Channel" amplifier to the
DIGITALAUDIO OUT terminals. ( Caution ) @ Depending on your DVD player and DVD-Audio software the copyright protection function may operate and disable optical
output.
@ When an ATSC channel is selected, the output from the DIGITALAUDIO OUT jack will be Dolby Digital. When an NTSC
channel is selected, the output will be PCM.
@ For viewing the CC of digital broadcasting, set the aspect to FULL (If viewing with H-FILL, JUST, ZOOM or 4:3;
characters might be cut off).
@ The CC can be displayed on the TV only when the receiver (such as a Cable box or satellite receiver) has the CC set
to ON within the device itself. Check with your Cable or Satellite provider for instructions. The TV's CC button does not operate the Satellite or Cable box's CC function.
@ If the CC is set to On on both the receiver and TV when the signal is 480i (except for the HDMI connection), the CC
may overlap on the TV.
@ If a digital program is being output in analog format, the CC data will also be output in analog format. @ If the recorder or output monitor is connected to the TV, the CC needs to be set up on the recorder or output monitor.
38
t(_L3232(_en_O608.indb 38 2010/12/24 13:40:2;
I
* Mark: Applicable input signal for Component (Y, PB, PR), HDMI and PC
525 (480) / 60i 15.73 59.94 * 525 (480)/60p ' 31.47 ' 59.94 * ' * ' 750 (720)/60p 45.00 59.94 * * 1,125 (1,080) 160i ' 33.75 ' 59.94 * ' * '
1,125 (1,080)/60p 67.43 59.94 *
1,125 (1,080)t60p ' 67.50 ' 60.00 ' ' * '
1,125(1,080)/24p 26.97 23.98 *
1,125(1,080)124p ' 27.00 ' 24.00 ' ' * ' 640 x 400 @70 31.47 70.08 * 640 x 480 _,60 31.47 ' 59.94 ' ' * Macintosh13" (640 x 480) 35.00 66.67 * 640 x 480 @75 ' 37.50 ' 75.00 ' ' ' * 852 x 480 @60 31.44 59.89 *
800 x 600 _,60 ' 37.88 ' 60.32 ' ' * 800 x 600 @75 46.88 75.00 * 800 x 600 @85 ' 53.67 ' 85.08 ' ' ' * Macintosh16" (832 x 624) 49.73 74.55 * 1,024 x 768 @60 ' 48.36 ' 60.00 ' ' ' *
1,024 x 768 @70 56.48 70.07 *
1,024 x 768 @75 ' 60.02 75.03 ' ' ' *
1,024 x 768 @85 68.68 85.00 *
Macintosh 21" (1,152 x 870) 68.68 ' 75.06 ' ' ' *
1,280 x 768 @60 47.78 59.87 *
1,280 x 1,024 _..60 ' 63.98 ' 60.02 ' ' *
1,366 x 768 @60 48.39 60.04 *
@ Signals other than above may not be displayed properly. @ The above signals are reformatted for optimal viewing on your display. @ Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning
frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)
@ Signal Names for D-sub 15P Connector
(_i_ R (_) GND (Ground) @ NC (not connected) _ G _-7_ GND (Ground) @ NC
L-_ B _-_ GND (Ground) @ HD/SYNC @ NC (not connected) (9_ NC (not connected) _ VD
Pin Layout for PC input Terminal
@ GND (Ground) GND (Ground) NC
Signal Name signal Name Signal Name
39
@
('3 ::3"
"-I ('3
6'
o "-i
I
tc_L3232c_en_O608Jndb 39 2010/12/24 13:40:2;
I
Care and Cleaning
First, unplug the Power cord plug from the wall outlet.
The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint- free cloth.
@ If the surface is particularly dirty, soak a soft, lint-free cloth in diluted mild liquid dish soap (1 part mild liquid dish soap diluted
by 100 times the amount of water) and then wring the cloth to remove excess liquid. Use this cloth to wipe the surface of the
display panel, then wipe it evenly with a dry cloth of the same type until the surface is dry.
@ Do not scratch or hit the surface of the panel with fingernails or other hard objects. Furthermore, avoid contact with volatile
substances such as insect sprays, solvents, and thinner; otherwise, the quality of the surface may be adversely affected.
[,_,_'1)11'¢F._
If the cabinet becomes dirty, wipe it with a soft, dry cloth. @ If the cabinet is particularly dirty, soak the cloth in a weak mild liquid dish soap and then wring the cloth dry. Use this cloth to
wipe the cabinet and then wipe it dry with a dry cloth.
@ Do not allow any mild liquid dish soap to come into direct contact with the surface of the LCD TV.
If water droplets get inside the unit, operating problems may result.
@ Avoid contact with volatile substances such as insect sprays, solvents, and thinner; otherwise, the quality of the cabinet
surface may be adversely affected or the coating may peel off.
@ Do not let articles made from rubber or PVC be in contact with the TV for long periods of time.
@ Cleaning
Wipe the surfaces with a soft, dry cloth. If the unit is particularly dirty, clean it using a cloth soaked with water to which a small amount of mild liquid dish soap has been added and then wipe with a dry cloth.
Do not use products such as solvents, thinner, or household wax for cleaning, as they can damage the surface coating. (If using a chemically-treated cloth, follow the instructions supplied with the cloth.)
@ Do not attach sticky tape or labels, as they can make the surface of the pedestal dirty. Do not allow long-term contact with
rubber, vinyl products, or the like. (Doing so will cause deterioration.)
Wipe the plug with a dry cloth at regular intervals. (Moisture and dust can lead to fire or electrical shock.)
40
t(_L3232(_en_O608.indb 40 2010/12/24 13:40:2;
I
Specifications
AC 110-127 V, 60 Hz
Rated Power
Consumption i 106 W
Standby condition i 0.3 W Aspect Ratio i16:9
Visible screen size 32_' class ......
(W x H x Diagonal) 27.5 " x 15.4 " x 31.5 "
(No, of pixels) i 1,049,088 (1,366 (W) x 768 (H)) [4,098 x 768 dots]
Speaker i 1-way 2 bottom SP System
Audio Output 20 W [10 W + 10 W] (10 % THD)
VIDEO IN !_2 VIDEO: RCA PIN Type x 1 1.0 V [p-p] (75 [3)
COMPONENT IN PB, PR: +0.35 V [p-p]
HDMI t-2 i ÷ This TV supports "HDAVI Control 5" function.
PC ,D-SUB 15PIN: R,G,B / 0.7 V [p-p] (75 [3)
DIGITAL AUDIO OUT
Including TV stand 30.7" x 21.0" x 8.2" :::3-0
TV Set on!y i (779 mm x 497 mm x 85 mm) _)
Including TV stand ............22.0 lb. (10.0 kg) NET --. 5'-_"
..........................................TV Set only i 20.0 lb. (9.0 kg) NET
i
(,_][.olncnnes measurea alagonally)
i (698 mm x 392 mm x 800 mm)
i
VGA, SVGA, XGA, WXGA, SXGA Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
VHF/UHF: 2-69, CATV: 1-135
Temperature: 32 °F - 95 °F (0 °C - 35°C) Humidity: 20 % - 80 % RH (non-condensing)
AUDIO L-R: RCA PIN Type x 2 0.5 V [rms]
Y: 1.0 V [p-p] (including synchronization)
iAUDIO L-R: RCA PIN Type x 2 0.5 V [rms]
TYPE A Connector x 2
HD, VD / 1.0 - 5.0 V [p-p] (high impedance)
SD CARD slot x 1Card slot i PCM / Dolby Digital, Fiber Optic @ 3D Y/C FILTER, CLOSED CAPTION,
V-Chip, HDAVl Control 5 _ @ Vesa compatible, VlERA IMAGE VIEWER _ 03
i
(779 mm x 531 mm x 207 mm) O..
30.7" x 19.6" x 3.4" O=4---
©
_'O
G:3 00
[TC-L3232C]
30.7"(779 mm) (85 mm)
/ (350 mm)l 8.2"(207 mm)
® Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
3.4"
41
I
tc_L3232c_en_O608Jndl) 41 2010/12/24 13:40:2;
I
FrequentlyAskedQuestions(FAQ)
If there is a problem with your TV, please refer to the table below to determine the symptoms, then carry out the
suggested check. If this does not solve the problem, visit the Panasonic web site for further assistance. (see cover)
devices such as a: Cable/ Satellite box, game console,
How do I view the picture from Blu-ray,0 r DVD player?
Why is there no picture or just
a blue, black or snowy screen being displayed?
Why doesn't the picture look
like it is in High Definition?
Why do black bars appear on the top and bottom and/or sides
of the screen?
Why is the picture snowy when
"ANT/Cable in" is selected?
Why is the picture chaotic and/
or torn and/or with a buzz in the speakers?
input source.
_ ress the INPUT button on the remote to select the correct
Check that the device is turned on and functioning
® Check if the power cord is plugged in and the TV is turned
on (front red LED light should be on; not blinking)
® Pressthe INPUTbuttonon the remoteto selectthe correctinputsource. ® Ensure all connections are correct and secure.
® When using external video source, suchas a Cable/Satellite box or
DVDplayer, check that the device is on and functioning correctly.
® Press MENU on the TV's remote control. If the menu is
displayed, then the TV is working; recheck above steps.
'¢_ ress the INFO button on the remote to confirm the type of signal
being received (p. 15). HD signal should be 720P, 1080i or 1080p.
® Select a High Definition channel from your HD source
(Cable, Satellite or fiber optic service). HD channels
sometimes broadcast non-HD content.
® Ensure that your HD source (HD box, Blu-ray player, etc.)
is connected to the TV with an HDMI or Component cable
Change the format (aspect ratio) of the picture by pressing
the FORMAT button on the remote control. (p. 16)
such as Cable/Satellite box, DVD/Blu-ray Disc player, etc.
Note: Some content, such as film-based movies, are available in
extra-wide format. Top and bottom bars are unavoidable.
¢_ When using a cable service (without a box), check that all "_ / connections are secure.
When using a cable or satellite box, change the connection _ (wiring) to Composite, Component or HDMI. (p.lO) If you're using an antenna, then check that connections are
secure. Change the position or direction of the antenna and
/_ check t e"Signal meter"
Checkif electricalproductssuchaskitchenappliances,fluorescentlights
or lightdimmersare nearby.Theymayinterferewiththe TV'spicture.
or a game console to narrow down the source of the problem.
Why is there a black box on the
screen?
Why is the screen blank and the
power indicator blinking?
® Change settings of Closed Caption (CC). (p. 15, 38)
The TV hasgone intoshutdown modeto protect itself.Try unplugging
it for afew minutesand connectingit again. Iftherewas a temporary powersurge onthe AC lineit may nowbe OK. If the blinking returns, call 1-877-95VlERA(U.S.A.)or 1-866-330-0014(Canada).
Why do some small spots on
the screen remain bright or
dark?
42
tc_L3232c_en_O608.h]dl) 42 2010/12/24 13:40:2:
I
Why is there no sound coming from the TV?
Why is the sound unusual, distorted, low volume or in
another language?
Make sure the volume is up and MUTE is off.
® Confirm the TV speakers are set to ON by pressing MENU
and selecting "Audio"--> "Advanced audio". (p.32)
® Check that the correct SAP (Secondary Audio Program) is
selected by pressing the SAP button on the remote control. (p.15)
® If the TV is connected to a Panasonic Home Theater via
HDMI cable, then check VIERA Link controls. (p.22)
® If the TV is connected to a Home Theater via optical cable,
then: Check the connection, the audio system is on, the correct input is selected.
® Check "HDMI 1 in" or "HDMI 2 in" analog/digital audio
Check that the correct SAP (Secondary Audio Program) is
selected by pressing the SAP button on the remote control. connected to the TV are secure.
settings. (example: try changing the box's Audio Rangeto 'narrow')
Why is there a clicking, ticking
or buzzing sound coming from the TV unit?
What is the easiest and best way to connect a High-Definition
Cable or Satellite box to the TV?
Why is there no yellow jack
(video I input) on the back of
the TV?
Why does the CC button not display Closed Caption?
Why does the screen and back cover of the TV get warm?
Why doesn't the Remote Control work?
_ When TV power is turned on or shut off there are electrical
components that make a click sound. This is normal operation.
Changes in the temperature and humidity of the room may
cause thermal expansion and contraction that can produce
Use an HDMI cable. It carries both digital video and audio
signal in HD. HDMI cable is the only cable needed to connect an HD device to the TV.
The Video 1 input is shared with the Component input. Just connect the yellow plug into the green jack. Be sure to connect the red and white audio plugs into the appropriate
red and white audio inputs. (p. 10)
The main unit radiates heat and some of the parts may °_
become hot. This is normal operation and does not affect
the performance of the set. ® Ensure good ventilation. ® Do not block the ventilation holes of the TV and do not
Check that the batteries are fresh, are of the same type °_
and are installed with the correct polarity (+ & -). ® To operate other devices, such as changing channels when_
using Cable or Satellite boxes or operating non-Panasonic
..Q
@ "11
r-
>
0o
(I)
O_
O
r-
&
o
Oo
Why is the "ANT/Cable" option at the top of the "Input select"
menu gray-out and cannot be
selected?
Some menu items are grayed-
During "First time setup", step 3, you indicated that the
"Antenna/Cable in" connector is "not used" (p.13). This is the
proper setting if the TV is connected to a Cable or Satellite box via any of the other inputs. To re-activate the "ANT! Cable" input, press MENU, select SETUP and then redo the
Depending on certain modes or the selected input, some
out and cannot be selected. Why?
only available when the FORMAT is changed to zoom mode.
43
I
tc_L3232c_en_O608Jndb 43 2010/12/24 13:40:2:
I
Index
[] Accessories ............................................................. 7
ANT/Cable ....................................................... 13, 28
Antenna ............................................................. 9, 13
Audio ...................................................................... 32
Audio, Advanced .................................................... 32
Auto Power ON ...................................................... 34
Auto Program ......................................................... 28
[] Battery ..................................................................... 8
Blinking LED .......................................................... 42
[] Cable ................................................................. 9, 10
Care & Cleaning .................................................... 40
CC Closed Caption .................................... 15, 33, 38
Channel ........................................... 13, 15-16, 28-29
Channel Surf Mode .......................................... 16, 34
Clock ...................................................................... 14
Colored buttons ...................................................... 11
Component ...................................................... 10, 41
Composite .............................................................. 10
Connections ........................................................ 9-10
Customer Services Directory ................................. 46
[] ECO/energy ..................................................... 18, 34
Exit .......................................................................... 11
[] FAQ's ................................................................ 42-43
Favorite .................................................................. 16
First Time Setup .......................................... 12-14, 34
Format ............................................................. 16, 36
[] HDAVl Control ........................................................ 22
HDMI .......................................................... 10, 38, 41
Home use .............................................................. 12
[] Image ViewerAuto ................................................. 34
Info ......................................................................... 15
Input ....................................................................... 19
[] Language ......................................................... 12, 34
Last ......................................................................... 11
Lock / Parental control ..................................... 33, 35
[] Menu ...................................................................... 30
Mute ........................................................................ 11
[] Pedestal ............................................................... 7, 8
Photo ................................................................ 20-21
Picture, Advanced .................................................. 32
Picture settings ...................................................... 31
Power ...................................................................... 11
[] Remote control ....................................................... 11
Reset ..................................................................... 34
[] Safety ....................................................................... 4
SAP ........................................................................ 15
Scan ................................................................. 13, 28
SD Card ........................................................... 20, 37
Signal Meter ........................................................... 29
Sleep ...................................................................... 32
Specifications ......................................................... 41
Store Demonstration .............................................. 12
Sub menu .............................................................. 16
[] Technical Information ........................................ 36-39
Timer ...................................................................... 32
44
[] VIERA IMAGE VIEWER ........................................ 20
VIERA Link .................................................. 18, 22-27
VIERA TOOLS ....................................................... 18
Viewing Photos ...................................................... 20
Volume .................................................................... 11
[] Warranty .......................................................... 45, 47
Watching TV, DVD, Blu-ray, etc....................... 15, 19
[] Zoom ................................................................ 16, 36
tc_L3232c_en_O608Jndb 44 2010/12/24 13:40:2:
I
LimitedWarranty
PANASONIC CONSUMER ELECTRONICS COMPANY, DIVISION OF: PANASONIC CORPORATION OF NORTH AMERICA
One Panasonic Way Secaucus, New Jersey 07094
(forU.S.A.andPuertoRicoonly)
Panasonic LCD Televisions
Limited Warranty
Limited Warranty Coverage
If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics
Company (referred to as "the warrantor") will, for the length of the period indicated on the chart below, which starts with the date of original purchase ("warranty period"), at its option either (a) repair your product with new or refurbished parts,
(b) replace it with a new or a refurbished equivalent value product, or (c) refund your purchase price. The decision to repair, replace or refund will be made by the warrantor.
LCD TV CATEGORIES
Up to 42" (diagonal)
46" (diagonal) and larger
During the "Labor" warranty period there will be no charge for labor. During the "Parts" warranty period, there will
be no charge for parts. You must carry-in your product or arrange for on-site service during the Limited warranty period. If non-rechargeable
batteries are included, they are not warranted. This warranty only applies to products purchased and serviced in the
United States or Puerto Rico. This warranty is extended only to the original purchaser of a new product which was not
sold "as is". A purchase receipt or other proof of the original purchase date is required for warranty service. On-Site or Carry-in Service
For On-Site or Carry-In Service in the United States and Puerto Rico call 1-877-95-VIERA (1-877-958-4372)
On-site service where applicable requires clear, complete and easy access to the product by the authorized servicer and does not include removal or re-installation of an installed product. It is possible that certain on-site repairs will not be
completed on-site, but will require that the product or parts of the product, at the servicer's discretion be removed for shop diagnosis and/or repair and then returned.
Limited Warranty Limits And Exclusions This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal Q_ wear and tear or cosmetic damage, nor does it cover markings or retained images on the LCD panel resulting from "O
viewing fixed images (including, among other things, non-expanded standard 4:3 pictures on wide screen TV's, or _- onscreen data in a stationary and fixed location). The warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result from accidents, o
misuse, abuse, neglect, bug infestation, mishandling, misapplication, alteration, faulty installation, set-up adjustments, ;0 misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, or -.
commercial use (such as in a hotel, office, restaurant, or other business), rental use of the product, service by anyone @ o other than a Factory Service Center or other Authorized Servicer, or damage that is attributable to acts of God. _" o
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE".
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes
damages for lost time, cost of having someone remove or re-install an installed unit if applicable, or travel to and from the servicer. The items listed are not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have others rights which vary from state to state.
If a problem with this product develops during or after the warranty period, you may contact your dealer or Service Center. If the problem is not handled to your satisfaction, then write to the warrantor's Consumer Affairs
Department at the addresses listed for the warrantor.
PARTS AND SERVICE (INCLUDING COST OF AN ON-SITE SERVICE CALL, WHERE APPLICABLE) WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY ARE YOUR RESPONSIBILITY.
PARTS
1 (ONE) YEAR
LABOR SERVICE
1 (ONE) YEAR
Carry-In
On-Site
@
F--
q
m.
(D
£)_
q
"-I
,<
5"
C
b_
o_'-i
x _,.._
45
I
tc_L3232c_en_O608Jndb 45 2010/12/24 13:40:2:
I
CustomerServicesDirectory(forU.S.A.andPuertoRico)
Obtain Product Information and Operating Assistance; locate your nearest Dealer or Service Center; purchase Parts and Accessories; or make Customer Service and Literature requests by visiting our Web
Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at: 1-877-95-VIERA (958-4372)
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST.
For hearing or speech impaired TTY users, TTY: 1-877-833-8855
Purchase Parts, Accessories and Instruction Books on line for all Panasonic Products by visiting our Web Site at:
http://www.pstc.panasonic.com
or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at: 1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only) (Monday - Friday 9 am to 9 pm, EST.)
Panasonic Service and Technology Company 20421 84th Avenue South, Kent, WA 98032
(We Accept Visa, MasterCard, Discover Card, American Express, and Personal Checks)
For hearing or speech impaired TTY users, TTY: 1-866-605-1277
46
t(_L3232(_en_O608.indl) 46 2010/12/24 13:40:2:
I
Limited Warranty (for Canada)
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
PANASONIC PRODUCT - LIMITED WARRANTY
Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship under normal use and for a period as stated below from the date of original purchase agrees to, at its option either (a) repair your product with
new or refurbished parts, (b) replace it with a new or a refurbished equivalent value product, or (c) refund your purchase price. The decision to repair, replace or refund will be made by Panasonic Canada Inc.
Viera TV (42" & over) 1In-home service O__ (1) year, parts (including panel) and labour. Viera TV (under 42") Carry-in service lOne (1) year, parts (including panel) and labour.
In-home Service will be carried out only to locations accessible by roads and within 50 km of an authorized Panasonic service facility.
In-home service requires clear, complete and easy access to the product by the Authorized Servicer and does not include removal or re-installation of an installed product. If removal is required to service the product, it will be at the discretion of
the Servicer and in no event will Panasonic Canada Inc. or the Servicer be liable for any special, indirect or consequential damages.
This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a Panasonic brand product mentioned above sold by an authorized Panasonic dealer in Canada and purchased and used in Canada,
which product was not sold "as is", and which product was delivered to you in new condition in the original packaging.
IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE HEREUNDER, A PURCHASE RECEIPT OR OTHER PROOF OF DATE OF ORIGINAL PURCHASE, SHOWING AMOUNT PAID AND PLACE OF PURCHASE IS
REQUIRED
LIMITATIONS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in shipment, or
failures which are caused by products not supplied by Panasonic Canada Inc., or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment
of consumer controls, improper maintenance, power line surge, lightning damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other business or rental use of the product, or
service by anyone other than a Authorized Servicer, or damage that is attributable to acts of God. Dry cell batteries are also excluded from coverage under this warranty.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FORANY SPECIAL, INDIRECT OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT ORARISING OUT OFANY BREACH OFANY
EXPRESS OR IMPLIED WARRANTY. (As examples, this warranty excludes damages for lost time, travel to and from the Authorized Servicer, loss of or damage to media or images, data or other memory or recorded content. This list of items is
not exhaustive, but for illustration only.)
In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or the exclusion of implied warranties, so the above limitations and exclusions may not be applicable. This warranty gives
you specific legal rights and you may have other rights which vary depending on your province or territory.
/
/
@
O
o
3
(D O3
(D
2
o o
G0
EJ
o o@
_2 _r2.
---El
(Co-
>
73"_
r-O
_
_o
o_
om
WARRANTY SERVICE
For product operation and information assistance, please contact:
Our Customer Care Centre: 1-800 #: 1-866-330-0014
Email link: "Contact us _ email" on www.vieraconcierqe.ca
For product repairs, please contact Viera Customer Care Agent using the above contact info.
IF YOU SHIP THE PRODUCT TO A SERVlCENTRE
Carefully pack and send prepaid, adequately insured and preferably in the original carton.
Include details of the defect claimed, and proof of date of original purchase.
47
I
tc_L3232c_en_LO608Jndl) 47 2010/12/24 13:40:2:
I
Sienta
multi
increible de excitaci6n
Este producto incorpora el siguiente software: (1) software desarrollado de manera independiente por o para Panasonic Corporation,
(2) software de propiedad de terceros que han licenciado a Panasonic Corporation para su uso, (3) software licenciado bajo la Licencia P_blica General de GNU, Versi6n 2 (GLP v2), (4) software licenciado bajo la Licencia P_blica General Menor de GNU (LGPL) y/o, (5) software de fuente abierta adem&s del software autorizado bajo la GPL y/o LGPL
Para el software categorizado como (3) o (4), consulte los terminos y condiciones de la GPL v2 y LGPL, segOn corresponda, en http://www.gnu.org/licenses/old-licenses/gpl-2.0.html y http:/Iwww.gnu.orgtlicenseslold-licensesllgpl-2.1 .html Ademas, el software categorizado como (3) o (4) esta registrado oficialmente pot varios individuos y/o entidades. Consulte el aviso sobre derechos de autor de dichos individuos en http://www.am-linux.jp/dl/DTV11UT/.
EL SOFTWARE GLP/LGPL SE DISTRIBUYE CON LA ESPERANZA DE QUE SEA 0TIL, PERO SIN NINGUNA GARANTIA, EXPRESA, IMPLJCITA O ESTATUTARIA, INCLUIDAS LAS GARANTJAS IMPLJCITAS DE MERCANTIBILIDAD O IDONEIDAD PARA UN PROPOSITO PARTICULAR.
Durante por Io menos tres (3) aSos a partir de la entrega de los productos, Panasonic proporcionar& a cualquier persona que nos contacte a la direccion mencionada mas abajo, pot un cargo no mayor al de la distribucion fisica del codigo fuente, una copia legible por maquina del codigo fuente correspondiente cubierto pot la GPL v2/LGPL
Informacion de contacto cdrequest@am-lin ux.jp El codigo fuente tambien se encuentra disponible de manera gratuita para usted y otros miembros del pOblico a
traves de nuestro sitio Web.
http://www.am-lin ux.jp/dl/DTV11UT/
2
tc_L3232c_si)a_0608.indb 2 2010/12/21 15:40:31
I
VIEI' l.,irIK° VIERALinkTMesunamarcade
H.--Iml
Fabricado bajo licencia de Dolby Laboratories. DOLBY y
el simbolo de la D doble son marcas comerciales de Dolby
Laboratories. HDAVI Control TM es una marca de f&brica de Panasonic
Corporation.
fabrica de Panasonic Corporation,
HDMI, el Iogotipo HDMI y High- Definition Multimedia Interface
son marcas comerciales o marcas comerciales registradas de HDMi
Licensing LLC en Estados Unidos y otros paises.
El Iogotipo SDHC es una marca comercial de SD-3C, LLC.
Este producto cumple con los requisitos de ENERGY STAR cuando se emplea la configuracion "Uso en Hogar", una configuracion con la que se Iogra ahorrar energia.
Cualquier modificacion en la configuracion "Uso en Hogar" o en cualquier otra configuracion predeterminada en fabrica podria resultar en un consumo de energia superior a los niveles que cumplen
con los requisitos de ENERGY STAR.
VIEf/ ....
IMAGEVIEWER
Aseg_rese de leer
÷ Precauciones para su seguridad ................... 4
Inicio
Accesorios/Accesorio opclonal ...................... 7
Conexi6nes ................................................... 9
Identificaci6n de los controles ..................... 11
Ajuste Inicial ............................................. 12
Caracteristicas basicas
÷ Para ver la televisi6n .................................... 15
÷ Utilizaci6n de VIERATOOLS ....................... 18
÷ Visualizaci6n de contenido de dispositivos
externos ....................................................... 19
÷ Visualizaci6n de fotos con VIERA IMAGE
VIEWER ....................................................... 20
Funciones avanzadas
÷ VIERA LinkTM "HDAVI Control TM''.................. 22
÷ Edici6n y configuraci6n de canales .............. 28
÷ C6mo utilizar las funciones de los menQs.... 30
o Ajustes de imagen ...................................... 31
Ajustes de audio ......................................... 32
o Ajustes de temporizador ............................. 32
Bloqueo ....................................................... 33
Subtitulos .................................................... 33
o Ajuste .......................................................... 34
Informacion de soporte
÷ Lista de clasificaciones para el bloqueo ...... 35
÷ Informaci6n tecnica ...................................... 36
÷ Cuidados y limpieza ..................................... 40
÷ Especificaciones .......................................... 41
÷ Preguntas frecuentes ................................... 42
÷ indice ........................................................... 44
3
tc_L3232C_Sl)a_0608.indb 3 2010/12/21 15:40:31
I
Precauciones para su seguridad
Elray0conpuntadeflechadentr0deun
ADVERTENCIA
ADVERTENCIA: Para reducir el riesgo de sufrir una descarga el_ctrica, no retire
la cubierta ni el panel posterior. En el interior no hay piezas que deba reparar el usuario. Solicite las reparaciones al personal de servicio calificado.
Este recordatorio se ofrece para que el instalador del sistema CATV preste atenci6n al Articulo 820-40 de la NEC, el cual proporciona directrices para realizar una conexi6n a tierra apropiada y, en particular, especifica que la tierra del cable debe estar
conectada al sistema de tierra del edificio, tan cerca del punto de entrada del cable como sea pr&ctico.
Las ranuras y aberturas en el gabinete en la parte posterior o inferior se hart colocado para ventilar y asegurar una operaci6n confiable de la TV LCD y para protegerla de un sobre-calentamiento. Estas aberturas no deberan ser bloqueadas o cubiertas. Deben haber al menos 10 cm de espacio alrededor del TV. Deber& existir un espacio de pot Io menos 10 cm entre estas aberturas. Las aberturas nunca
deber&n ser bloqueadas al poner la TV LCD sobre una cama, sofa, alfombra o superficie similar. Esta TV LCD no debera ser colocada en una instalaci6n pre-fabricada tal como un librero a menos que tenga una ventilaci6n apropiada.
Leer las instrucciones.
1)
Guardar las instrucciones.
2) Atender todas las advertencias.
3)
4)
Seguir todas las instrucciones.
5)
No hacer uso de este aparato cerca del agua.
6)
Limpiar solo con un pal_o seco.
7)
No bloquear ninguna de las aperturas de ventilaci6n. Instale segOn las instrucciones del fabricante.
8)
No instalar cerca de ninguna fuente de calor como radiadores, reguladores de calefaccion, estufas u otros aparatos (incluyendo amplificadores) que generen calor.
9)
No desechar el proposito de seguridad del enchufe polarizado o de encalladura. Un enchufe polarizado posee dos cuchillas, una m&s ancha que la otra. Un enchufe de encalladura posee dos cuchillas y una tercera punta de encalladura. La cuchilla
ancha o la tercera punta son proporcionadas por su propia seguridad. Si el enchufe proporcionado no cabe en su salida de corriente, consulte a un electrico para reemplazar la salida de corriente obsoleta.
10)
Proteger el cable de corriente de ser pisado o pellizcado, especialmente alrededor del enchufe, los recept&culos y el punto en el que salen del aparato.
11)
Usar solo accesorios especificados por el fabricante.
12)
Usar el aparato solo con el carro, plataforma, triple, soporte o mesa especificado por el fabricante, o vendido con el aparato. Cuando un carro sea usado, tenga cuidado al mover dicho carro junto con el aparato para
evitar lesiones por volcaduras.
13)
Desconectar este aparato durante tormentas electricas o cuando no vaya a ser usado por largos periodos de tiempo.
14)
Referir toda necesidad de servicio a personal de servicio calificado. El servicio se requiere cuando el aparato ha sido daSado en cualquier manera, como cuando el cable de corriente o el enchufe ha sido daSado, liquido ha sido derramado,
objetos han caido dentro del aparato, el aparato ha sido expuesto a humedad o Iluvia, no opera normalmente o ha caido.
15)
Operar solamente desde el tipo de fuente de energia indicada en la etiqueta. Si usted no esta seguro del tipo de abastecimiento de energia
de su casa, consultar a su distribuidor o a la compafiia de energia local.
16)
Seguir todas las advertencias e instrucciones marcadas en la TV LCD.
17)
Nunca echar objetos de ninguna clase dentro del TV LCD a traves de las ranuras del gabinete ya que pueden tocar puntos de voltaje
peligroso o cortar partes que pudieran ocasionar un incendio o choque electrico. Nunca derramar liquido de ningt3n tipo dentro del TV LCD.
18)
Si una antena exterior es conectada a! equipo de la televisi6n, asegurar que el sistema de antena sea a tierra para proporcionar proteccion contra
subidas de voltaje y cargas de estatica. En los E.U.A. Ia Seccion 810-21 de la "National Electrical Code" proporciona informacion con respecto a
Ia conexion a tierra apropiada para el mastil y la estructura de soporte, ei cable principal a la unidad de descarga de la antena, el tamaSo de los
conductores a tierra, ubicacion de la unidad de descarga de la antena, la conexion a ios electrodos a tierra y requisitos para los electrodos a tierra.
EJEMPLO DE ANTENAA
A (NEC)NATIONAL
ELECTRICAL PRINCIPAL
CODE ATIERRA
SERVlClO DE ENERGIA DEL SISTEMA
DE ELECTRODOS ATIERRA
(ART. 250 NEC. PARTE H)
4
tri&ngul0equilater0tienelaflnalidaddeavisar alusuari0dequehaypiezasenel interiordel
pr0duct0quesilast0cantaspersonasestas puedenrecibirunadescargael@trica.
El signo de exclamacion dentro de un triangulo equilaterc tiene la finalidad
de avisar at usuario de la existencia de instrucciones de utilizaci6n y
servicio importantes en el material impreso que acompafia at aparato.
ABRAZADERAS A TIERRA
UNIDADDEDESCARGA ATIERRA(SECCION NEC810-20) CONDUCTORESA
TERRA(SECClONNEC 810-21)
t(_L3232(_si)a_0608.indl) 4 2010/12/21 15:40:3_
I
19)UnsistemadeexteriornodeberadeberasercolocadocercadelaslineasdepoderOotroscircuitosdeenergiaoluzo dondeestapuedacaerentaleslineasdepoderocircuitos.Cuandoseinstaleunsistemadeantenaexterior,extremar cuidadosparaevitartocartaleslineasocircuitosyaqueestecontactopudiesetenerconsecuenciasfatales.
20)DesconectarlaTVdeLCDdelcontactodepared,yreferirapersonaldeserviciocalificadoenlacondicionessiguientes: a. CuandoelcabledepoderocontactoestedaSadoodesgastado. b. SisehaderramadoliquidodentrodelaTVdeLCD. c. SilaTVdeLCDhasidoexpuestaaIluviaoagua. d. SilaTVdeLCDnooperanormalmente,siguiendolasinstruccionesdeoperaci6n.
Ajustarsolamenteaquelloscontrolesqueestancubiertosporlasinstruccionesdeoperaci6nyaqueel ajusteinapropiadodeotroscontrolespuedeocasionardaSoyamenudorequerirademayortrabajopara
untecnicoespecializadopararestaurarlaoperaci6nnormaldelTVdeLCD.
e. SilaTVdeLCDsehacaidooelgabineteseencuentrada5ado.
f. CuandolaTVdeLCDexhibeuncambiodistintoensufuncionamiento-estoindicaquerequieredeservicio.
21)Cuandopartesderepuestoseanrequeridas,asegurarsequeeltecnicodeservicioutilicepartesespecificadasporel
fabricantequetenganlasmismascaracteristicasdelaspartesoriginales.Sustitutosnoautorizadospuedenocasionarun
incendio,choqueelectrico_otrosriesgos.
22)ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO O DESCARGA ELECTRICA, NO EXPONGA ESTE
APARATO A LA LLUVIA, HUMEDAD, GOTEO O SALPICADURA. NO COLOCAR ENVASES CON LIQUlDO (FLOREROS, COPAS, COSMETICOS, ETC.) SOBRE EL TELEVISOR (INCLUYENDO
23) ADVERTENCIA: RETIRAR PIEZAS PEQUEI_IAS INNECESARIAS Y OTROS OBJETOS FUERA DEL ALCANCE DE LOS
24) ADVERTENCIA: Para evitar la dispersi6n del fuego, mantenga velas asi como otras llamas abiertas lejos
25) AVISO: El interrupter de la alimentacion de esta unidad no desconectara completamente toda la
26) PRECAUClON: PARA EVITAR CHOQUE ELECTRICO NO USAR ESTE ENCHUFE CON UN RECEPTJkCULO 00TRA
27) PRECAUClON: USAR OTRA BASE PUEDE RESULTAR INESTABLE Y CAUSAR POSIBLEMENTE ALGUN DANO.
28) PRECAUClON: PELIGRO DE EXPLOSION SI LA BATERiA ES COLOCADA INCORRECTAMENTE REPONER
29) PRECAUClON: Este televisor de LCD ha sido diseSado para ser utilizado solamente con los accesorios opcionales
ANAQUELES COLOCADOS ARRIBA DE ESTE, ETC.).
NII_OS PEQUEI_OS. ESTOS OBJETOS PUEDEN SER TRAGADOS ACCIDENTALMENTE. TAMBIEN TENER CUIDADO AL EMPACAR MATERIALES Y HOJAS DE PLASTICO.
de este producto en todo momento.
alimentacion procedente de la toma de CA. Como el cable de la alimentacion sirve como dispositivo de desconexion principal de la unidad, usted tendr& que desenchufarlo de la toma de CA para desconectar toda la alimentacion. Por Io tanto, asegQrese de que la unidad este instalada de forma que el cable de alimentacion pueda desenchufarse facilmente de la toma de CA en caso de accidente. Para evitar un incendio, el cable de la alimentacion tambien debera desenchufarse de la toma de CA cuando la unidad no se vaya a utilizar durante un periodo largo de tiempo (durante unas vacaciones, por ejemplo).
SALIDAA MENOS QUE LAS CLAVIJAS PUEDAN SER INSERTADAS FIRMEMENTE PARA EVITAR QUE LA CLAVIJA QUEDE EXPUESTA.
SOLAMENTE CON EL MISMO TIPO O EL EQUIVALENTE.
siguientes. La utilizaci6n con cualquier otro tipo de accesorio opcional puede causar inestabilidad que, a su vez, podria tener como resultado posibles lesiones. (Todos los accesorios siguientes son fabricados por Panasonic Corporation)
Soporte de montaje en pared: TY-WK3L2RW AsegQrese siempre de solicitar a un tecnico calificado que le haga la instalacion.
5
I
t(_L3232(_si)a_O608.indl) 5 2010/12/21 15:40:3!
I
IJ]=(qIf;1_!;I_] [_ _ IJ]=IIf;1I;[_q
Este equipo ha sido probado y ha demostrado cumplir con las limitaciones para los dispositivos digitales de la Clase B, de conformidad con el Apartado 15 de las Normas de la FCC. Estos limites han sido diseSados para proporcionar una protecci6n razonable contra
las interferencias perjudiciales en una instalacion residencial. Este equipo genera, utiliza y puede radiar energia radioelectrica, y si no se instala y utiliza de acuerdo con las instrucciones, puede causar interferencias perjudiciales en las comunicaciones por radio. Sin
embargo, no existe ninguna garantia de que las interferencias no se produzcan en una instalaci6n particular. Si este equipo causa interferencias perjudiciales en la recepcion de la radio o televisi6n, Io que se puede determinar apagando y encendiendo el equipo, al
usuario se le recomienda intentar corregir la interferencia tomando una o mas de las medidas siguientes:
Cambie la orientacion o el lugar de instalacion de la antena.
Aumente la separacion entre el equipo y el receptor.
Conecte el equipo a una toma de corriente diferente de aquella a la que est& conectada el receptor.
Consulte a su concesionario o a un tecnico en radio/television con experiencia para solicitar su ayuda.
Este dispositivo cumple con el Apartado 15 de las normas de la FCC. El funcionamiento esta sujeto alas dos condiciones siguientes: (1) este dispositivo no debera causar interferencias perjudiciales y (2) este dispositivo debera ser aceptar cualquier interferencia que
reciba, incluyendo la interferencia que pueda causar un funcionamiento no deseado.
Aviso de la FCC:
Para asegurar el cumplimiento ininterrumpido, siga las instrucciones de instalaci6n adjuntas y utilice solamente cables de interfaz blindados cuando conecte a un ordenador o a dispositivos perif6ricos. Cualquier cambio o modificaci6n que no haya
sido aprobado explicitamente por Panasonic Corp. of North America podria anular la autorizaci6n que tiene el usuario para utilizar este dispositivo.
Declaraci6n de conformidad de la FCC
N. ° de modelo TC-L3232C
Responsable: Panasonic Corporation of North America
Direccion de contacto: Panasonic Consumer Electronics Company
email: consumerproducts@panasonic.com
One Panasonic Way, Secaucus, NJ 07094
1-877-95-VIE RA (958-4372)
L,\vA_."[,_ IJ]= _-"]_lJ [_11J7:1J]IJ]:1I!-'I [*,]_'-'_I_'-'I_,1-'II_I_[*_-"]
MONTAJE EN LA PARED: SI DECIDE INSTALAR LA
PANTALLA PLANA EN LA PARED, TENGA PRESENTE QUE
Las pantallas planas no siempre estan montadas sobre bases adecuadas o instaladas de acuerdo con las recomendaciones
del fabricante. Las pantallas planas real colocadas en estanterias, librerias, estantes, escritorios, altavoces, baQles
o muebles con ruedas pueden caer y provocar daSos personales e incluso la muerte.
La industria de sistemas electr6nicos para consumidores (de la cual es miembro Panasonic) trabaja por que el
entretenimiento en casa sea entretenido y seguro. Siga siempre las siguientes normas de seguridad para prevenir posibles da_os personales e incluso la muerte:
AJUSTES DE SEGURIDAD:
Un mismo tamaSo NO sirve para todo Siga las
recomendaciones del fabricante para garantizar una instalacion y un uso seguro de la pantalla plana
Lea atentamente todas las instrucciones adjuntas y asegOrese de que las comprende para garantizar un uso
correcto del producto
No permita que los nii_os se suban o jueguen con los
muebles y los equipos de television
No coloque la pantalla plana en muebles que se puedan
utilizar facilmente como escalon, como por ejemplo una
estanteria
Recuerde que los niSos se dejan Ilevar por las emociones al ver la tele, especialmente en una pantalla plana "mas grande que el mundo" Asegt_rese de instalar la pantalla en un lugar donde no se pueda empujar, volcar o golpear y caer
Tenga cuidado de colocar todos los cables de la pantalla
plana de forma que los niSos no puedan cogerlos o tirar de
ellos si sienten curiosidad
SIEMPRE DEBE:
Utilizar un soporte recomendado pot el fabricante de la pantalla y/o pot un organismo independient (por ejemplo UL, CSA, ETL)
Seguir todas las instrucciones de los fabricantes de la pantalla y el soporte de pared
Si no se siente capaz de instalar con seguridad la pantalla plana, pongase en contacto con su distribuidor para contratar un servicio de instalacion especializado
AsegOrese que la pared donde se va a instalar el soporte es apropiada Algunos soportes de pared no estan diseSados
para la instalaci6n en paredes utilizando esparragos de acero o estructuras cilindricas antiguas En caso de dudas, pongase en contacto con un instalador profesional
Para instalar la pantalla se necesitan dos personas como minimo Las pantallas planas pueden ser muy pesadas
Panasonic recomienda encargar la instalaci6n en la pared a un instalador calificado. V_ase la p&gina 5.
los ni_os menores de dos a_os vean televisi6n.
La Academia Americana de Pediatria desalienta que
6
tc_L3232(_si)a_O608.indl) 6 2010/12/21 15:40:3!
I
Accesorios/Accesorioopcional
d Compruebe que ha recibido todos los elementos que se indican.
[] Transmisor de [] Pilas para el transmisor [] Pedestal
mando a distancia de mando a distancia (2) ® TBL5ZX0084
@ N2QAYB000570 ® Pila AA
tje (pag. 8)
[] Manual de usuario [] Guia de inicio rapido [] Tarjeta del cliente (para EE. UU.)
Accesorio opcional
Abrazadera de suspensi6n de pared
® TY-WK3L2RW
El &ngulo de la abrazadera de suspensi6n de pared se puede ajustar en una "inclinacion cero (vertical)", en una "inclinacion de 5
grados", en una "inclinacion de 10 grados", en una "inclinacion de 15 grados" yen una "inclinacion de 20 grados" para este TV.
( Advertencia ) ® Si los clientes montan la unidad ellos mismos o si no se utiliza una mensula de Panasonic, esto significa que ellos
asumen todas las responsabilidades pertinentes. Cualquier dafio resultante de no haber sido un instalador profesional el que haya montado su unidad anulara la garantia.
® AsegQrese siempre de solicitar a un tecnico cualificado que realice todo el trabajo de instalaci6n necesario. Una
instalaci6n incorrecta podria ser la causa de que el equipo cayera, causando lesiones a personas y daSos en el producto.
® No monte directamente la unidad debajo de las luces del techo (proyectores, focos o luces halogenas) que producen
tipicamente bastante calor. De Io contrario puede que se deformen o daSen partes de la caja de pl&stico.
® Tome precauciones al fijar los soportes de la montura en la pared. AsegQrese siempre de que no haya cables electricos
o tuberia en la pared antes de instalar los soportes.
® AI utilizar el tipo angular para montura en pared, asegQrese de que haya suficiente espacio para conectar los cables y
que estos no queden oprimidos contra la pared cuando esta sea inclinada hacia adelante.
® Por razones de seguridad, desmonte de la pared las unidades que ya no esten siendo utilizadas.
P6ngase en contacto con su concesionario Panasonic mas cercano para adquirir la mensula de montaje en pared recomendada. Para conocer mas detalles, consulte el manual de instalaci6n de la mensula de montaje en pared.
Parte posterior del televisor la unidad de TV en los
Orificios para la instalaci6n de (Vista de lado) soportes para montura en pared
[] Seguridad para ni5os
soportes para montura en pared (no incluidos con la unidad de TV)
@ 3>
o o
(D oo
O O
oo
o o
o o
o
'o
o o
7
I
tc_L3232c_spa_O608.indb 7 2010/12/21 15:40:3!
I
[.!'_'JB'_ BF"JIff'_F'_ [,_,]F"JI[',F'JF'_
IIMontaje del pedestal
® Fije firmemente con los tornillos de ensamblaje (A_.
(4 tornillos en total)
® Apriete firmemente los tomillos.
s ..........................................................................................................................................................................................................................................
Accesorios
Tomillo de montaje (4 de cada uno)
QA)
Mensula
Frente
Base
XSS4+] 6FJK XYN4+F] 2FJK Tama_o (M4 x ]6) Tama_o (M4 x ]2)
Mensula (1) Base (1)
IIInstalacion
® Fije firmemente con los tomillos de ensamblaje _B).(4 tomillos en total) ® Apriete firmemente los tornillos.
Estera de espuma o paso blando y grueso
( Advertencia )
No desarme ni modifique el pedestal.
® De Io contrario, la unidad podria caerse y da_arse, y tambien podria causar heridas a personas. ( Precauci6n )
No utilice ningt_n otro pedestal que no sea el que viene incluido con el TV.
® En caso de no ser asi, la unidad puede caerse y da_arse, pudiendo sufrir da_os personales.
No utilice el pedestal si est_ doblado, partido o est_ roto.
® Si utiliza un pedestal roto, puede da_arse todavia mas y puede resultar usted da_ado. Comuniquese a la tienda donde
Io compr6, Io antes posible.
Durante la instalaci6n, asegt_rese de apretar bien todos los tornillos.
® Si no se tiene cuidado y los tomillos no estan bien apretados durante el armado, la instalaci6n no sera Io
suficientemente fuerte como para sostener el televisor y este podra caerse y da_arse, y podra causar da_os a las personas.
( Precaucidn )
Abrir.
Gancho
Ponga las polaridades (+ o -) ® No queme ni rompa las pilas.
en las posiciones correctas
® La instalaci6n incorrecta puede causar
Cierre fugas de electrolito y corrosi6n, Io que
podria daSar el mando a distancia. ÷ No mezcle pilas viejas y nuevas.
÷ No mezcle pilas de tipos diferentes
(pilas alcalinas y de manganeso, por ejemplo).
÷ No utilice baterias (Ni-Cd).
8
tc_L3232c_spa_0608.indb 8 2010/12/21 15:40:4I
I
Conexibnes
Parte delantera del TV
Ranura de--
tarjeta SD (pag. 20)
Terminal de PC
Salida de audio digital
Parte posterior del TV
Parte posterior del TV
Antena de VHF/UHF
Cable de alimentaci6n de CA
(Conecte despues de haber terminado
todas las demas conexiones.)
Antena de VHF/UHF
NTSC (National Television System Committee):
ATSC (Advanced Television Systems Committee): Las normas de televisi6n digital incluyen la television de alta definicion digital (HDTV), la televisi6n
de definicion estandar (SDTV), la emision de dates, el audio multicanal de sonido envolvente y la
Cable
® Usted necesita suscribirse a un servicio de televisi6n por cable para poder versus programas. ® Puede que necesite suscribirse a un servicio de cable de alta definici6n (HD) para disfrutar de la programaci6n HD.
La conexi6n para alta definici6n se puede hacer empleando un cable de HDMI o de video componente. (pag. 10)
television interactiva.
@@
3>O
o o
__x.
-'_ O,
¢D
O O
Co
o o
o o
o
-3
® Cuando utilice una caja de cable, los equipos y cables de video externos que aparecen en este manual no vienen
incluidos con el TV.
® Para obtener mas ayuda, visitenos en: www.panasonic.com
Referencias de conexibn
Terminal de antena Terminal de contactos
verde!am_
@Apriete firmemente a mano. ® Inserte firmemente nserte firmemente.
Terminal HDMI
9
I
tc_L3232c_spa_O608.indb 9 2010/12/21 15:40:4;
I
[_ _[_I _ .,3_z\v4
Superior
Buena
(_ Para utilizar terminales HDMI
_I I_ HDMI
Cable de conversion HDMI-DVI
_) LAUDIO OUT
® Para las "VIERA Link TM Conexiones", consulte la pag. 23. ® Para una serial de 1080p se requiere una conexi6n de HDMI.
_1_Para utilizar terminales de VIDEO COMPONENTE
o_PB
azul
rojo
rojo
blanco
rojo
Para utilizar terminales de VIDEO COMPUESTO
AV OUT
DVl OUT
VIDEO OUT COMPONENT /
deAV
e],Reproductor
Equipo de AV
t Blu-ray Disc
ej, Reproductor Blu-ray Disc
Equipo de AV
>
ej. Reproductor Blu-ray Disc
Basica *- i"c
l'_b_ OMPOSITE _ ej. GrabadoraDVDo
o,o .........................................................................................................................................................................................................................
® La terminal Verde es compartida por ambas: conexi6n COMPONENTE y COMPUESTA (VIDEO IN 1).
Cuando se utiliza la conexi6n COMPUESTA (VIDEO IN 1) el conector Amarillo (Video) debe estar insertado en la conexi6n Verde.
_ _ AUDIO IN
Cable optico
® Para la conexi6n HDMI-ARC (Canal de retorno de audio), consulte la pag. 22
Cable RGB PC
Cable de audio
10
Adaptador de conversion (si fuera necesario)
®y OOT ,I I 'Ot
DIGITAL
PC OUT rdenador
(_ Audio OUT
o_e _ _::*b*i*:°que correspon de
con la terminal de salida de audio en la computadora.
i Equipo de AV
ej. Videograbadora
Equipo de audio
ej. Amplificador
i
lO
tc_L3232c_si)a_0608.indb 10 2010/12/21 15:40:4:
I
Identificacibn de los controles
[_;'J?_ F'_kI'TtSI"_+ L'_ _F"JIt',F"JF'_
Parte delantera del TV
canales en orden.
jada del volumen
gaciones del mene
Sensor del control remoto dentro de unos 7 metros
enfrente del televisor
Indicador de alimentacion boton POWER
- (conectada: rojo, desconectada: apagado)
S.S.A.C. (sistema de seguimiento autom&tico de contraste)
la se5al de entrada.
Selecciona el menQ y la entrada de submenQ.
® El televisor consume una pequeSa cantidad de energia electrica incluso estando apagado. ® No coloque ningen objeto entre el sensor de control remoto del televisor y el mando a distancia.
Conecta la alimentaci6n del televisor o la pone en espera
Seleccione la fuente aver (pag. 19)
Visualiza el menQ principal (pag. 30) --
Despliega el submenQ para funciones especiales (cuando esta disponible) (pag. 16)
Botones de color (utilizados para varias funciones)
Subida/bajada del volumen
Encendido/Apagado del silenciamiento -- del sonido
Cambia la relaci6n de aspecto y -- acercamiento (pag. 16, 36)
Cambia al canal visto previamente o -- modo de entrada
Operaciones con equipos externos (pag. 27)
-- MenQs de salida
Subtitulos Si/No (pag. 15) Selecciona el Programa de audio
secundario (pag. 15)
L_ MenQ VIERA Link (pag. 26-27)
de imagenes de tarjetas SD
(pag. 20-21) Selecci6n!OK/Cambio
menQ anterior
Canal arriba/abajo, cuando visualice la
fuente ANT/Cable
Visualiza o elimina la bandera de canal (pag. 15)
Controla la funci6n de la lista de canales
favoritos (pag. 16)
cualquier canal o para hacer
introducciones alfanumericas en los menQs
Utilizaci6n con canales digitales (pag. 15)
(pag. 18)
para seleccionar
@@
©__
o (l) x
o :o
09 O,
"m O_
o
00
o o
-m
q- o
00
11
I
tc_L3232c_si)a_0608.indb 11 2010/12/21 15:40:4,
I
Ajuste Inicial
La pantalla "Ajuste lniciaF se visualiza solamente cuando el TV se enciende por primera vez despues de enchufar el cable de alimentaci6n en una toma de corriente y cuando "Autoencendido" (pag. 34) se pone en "No".
Encienda el televisor con el interruptor POWER.
(TV) (mando a distancia)
POWER
Configure su modo de visualizacibn
@ Seleccione su idioma
)Seleccione
_2)Aceptar
Seleccione su modo de visualizacion
(AsegQrese de seleccionar "Uso en Hogar")
÷ Confirme su selecci6n (Usoen Hogar) antes de pulsar el bot6n OK.
Si selecciona "Exhibicion en Mostrador" por equivocacion en se visualizara la pantalla de confirmacion.
)Seleccione
{2) Aceptar
® Seleccione "No" y vuelva a la pantalla anterior @. ® Si selecciona "Si", la pantalla entra en el modo de demostraci6n de mostrador.
Para visualizar otra vez "Ajuste Modo de Visualizaci6n" como se muestra arriba. Realice algo de Io siguiente para volver a seleccionar "Uso en Hogar":
Presione y mantenga apretado el bot6n lateral POWER por al menos cinco
segundos.
Desenchufe el cable de la alimentaci6n electrica por 30 segundos y
enchQfelo de nuevo.
® Si emplea otro paso distinto a @ para apagar la TV, o si usa el bot6n EXIT para
salir antes de completar los ajustes, la siguiente vez que encienda la TV no se
mostrara automaticamente "Ajuste Iniciar'.
Los ajustes que se hayan hecho hasta ese momento se guardaran.
Puede comenzar el "Ajuste inicial" en cualquier momento. (pag. 34)
® El Idioma, Ajuste ANT/Cable, Titulos de entradas, Reloj tambien pueden
cambiarse desde el menQ "Ajuste" (pag. 34).
12
tc_L3232c_si)a_O608.indb 12 2010/12/21 15:40:4,
I
Configuracion automatica de canales (Ajuste ANT/Cable)
@ Seleccione la antena conectada en terminal
No utilizado:vaya a
___) (Etiqueta de entradas)
Seleccione "No utilizado" si no hay ningQn cable conectado a la terminal "Antena/ Cable".
@ Tipico cuando el decodMcador de cable/satelite esta conectado a una entrada de TV/
AV.
@ Evita la sintonizaci6n accidental a una serial no disponible, cuando se utiliza la
caja de cable o satelital.
Seleccione "lniciar"
Inicie la exploracion de los canales
(Los cannes disponibles se establecen automaticamente.)
Este proceso puede demorar hasta 20 minutos.
@ Este paso no es necesario cuando una caja de
cable o satelital esta conectada a una entrada
AV.
Seleccione
@Aceptar
/Seleccione
@Aceptar
Saltar: vaya a
(Etiqueta de entradas)
@
(1]
"-I
o_.
@ Complete la configuracion Programa auto
Para volver a la
pantalla anterior
RETURN
O
CNND
@ Acerca de los
sistemas de emisi6n Analdgico (NTSC):
programaci6n de TV tradicional
Digital (ATSC):
nueva programaci6n
que le permite ver mas canales
con imagen y sonido de alta
calidad
El mensaje de finalizaci6n se muestra cuando la exploraci6n automatica de
programa se haya Ilevado a cabo exitosamente.
-Aceptar regrese a @- @
Operaci6n del bot6n EXIT durante "Ajuste Inicial" Presione el bot6n una vez para mostrar la pantalla de confirmaci6n. Presione de nuevo para cerrar la pantalla de confirmaci6n.
[Pantalla de confirmaci6n EXIT]
Si @ Sale de "Ajuste Inicial". No @ Regresa a la pantalla de origen.
Si no hay canal disponible
(Ajuste ANT/Cable). Se seleccionara "No
utilizado".
13
I
tc_L3232c_si)a_0608.indb 13 2010/12/21 15:40:41
I
Asigne titulos a las entradas de TV (Etiqueta de
entradas)
Cuando este listo, seleccione Siguiente y pulse OK para ir al siguiente paso.
)Seleccione
-@Cambie
Etiqueta: [BLANCO] No utilizado/Blu-ray/DVD/Grab de DVD/HOME THTR/JUEGO/PC/
VCRICABLEISATELITEIVGDICAMARAIMONITORIAUXlRECEPTORIMEDIA
CTR/MEDIA EXT!OTROS
Seleccione "No utilizado" para cualquier conector del panel posterior que no cuenta con ningQn dispositivo conectado a 61. Despues, la entrada se omitira cuando pulse INPUT, para su conveniencia.
Los titulos de entrada se pueden cambiar en cualquier momento posterior desde el menQ de ajuste del TV
O
Siga las instrucciones que se indican en la pantalla para
completar las operaciones siguientes.
Ajuste el reloj (Ajustar reloj)
Cuando este listo, seleccione Siguiente y pulse OK para ir al siguiente paso.
)Seleccione° _=Minuto
-@Cambie
Siga las instrucciones que se indican en la pantalla para
completar las operaciones siguientes.
Para volver a la
14
pantalla anterior
RETURN
O
Complete Ajuste Inicial
iFelicitaciones! Usted esta listo.
El Ajuste inicial se puede repetir en cualquier momento. Pulse MENU y seleccione Ajuste; luego "Ajuste Inicial"
Para ver TV mediante una caja de cable, receptor satelital o cualquier otro medio (DVD, DVR, dispositivo de juegos, etc.), pulse el bot6n INPUT y seleccione la
entrada adecuada.
tc_L3232c_si)a_0608.indb 14 2010/12/21 15:40:41
I
Para ver la televisibn
Encienda el televisor
(mando a distancia) (TV)
Otras funciones utiles
POWER
Seleccione un numero de canal
m _ m Para introducir directamente el
o _m
Bot6n CH disponible tambien en la unidad.
[Para conexidn de la caja de cable/ satelital]
- Use el control remoto de la caja
conectada.
® Vuelva a seleccionar "Cable" o "Antena" en "Entrada ANT" de "Ajuste ANT/Cable" para
cambiar la recepci6n de la seSal entre televisi6n por cable y antena. (pag. 13, 28)
® El nQmero del canal y el nivel del volQmen se fijan incluso despues de apagar el
televisor.
m _ numero del canal digital
® Seleccione la entrada correcta
INPUT
--> _ (pag. 19)
_ Cuando se sintonicen canales
digitales, presione el bot6n para introducir el nQmero menor en un
nQmero de canal complejo.
Ejemplo: CH15-1: _]_ _ _
Seleccione el modo de audio para ver la television
SAP Mododigital
PulseSAPpara seleccionarlasiguientepistade audio (siesta disponible)cuandoserecibeun canaldigital.
Modo anal6gico
Pulse SAP para seleccionar el modo de audio como se describe a continuaci6n.
Cadavez quesepulsa el bot6nSAP, el modode audiocambiara comose muestraa continuaci6n.(Estereo/SPA/Mono)
® SAP no esta disponible cuando se ve la TV con una caja de cable o satelital conectada mediante HDMI. ® Comuniquesecon su operador decable o satelital paraobtener instruccionessobre c6mohabilitar SAPen dichacaja.
Activa o desactiva el modo Subtitulos
Q
® Los subtitulos no estan disponiblescuando se ve la TV con una caja de cable o satelital conectada mediante HDMI. ® Comuniqueseconsuoperadordecableosatelitalparaobtenerinstruccionessobrec6mohabUitarlossubtitulos(CO)endichacaja.
Despliega y elimina informacion. Cuando se ve la programacion mediante la entrada de la
antena/cable, aparece el titular del canal.
INFO Canal Reloj
Identificador
de emisora
Subtitulos
Resoluci6n Modo de _mpo restante de se_ales imagen temporizador de apagado
Niv® de clasificaci6n Relaci6n de aspecto
15
I
tc_L3232c_spa_O608.indb 15 2010/12/21 15:40:4'
Pulse FORMAT para cambiar entre los modos de aspecto (pag. 36)
FORMAT b_ 4_l 480i, 480p: COMP/JUSTO/4:3/ACERC
Pulse SUB MENU para mostrar la pantalla del submenu Este ment_ consiste en atajos a funciones de uso convenientes.
El subment_s61oesta disponible cuando el TV esta usando la entrada de antena/cable, no cuando usa la caja de cable o satelital.
SUB
MENU
1080p, 1080i, 720p: COMP/H-LLENO/JUSTO/4:3/ACERC Utilice cuando la imagen no Ilena toda la pantalla (aparecen barras en alguno de
los dos lados de la imagen) o parte de la imagen esta recortada.
1. AIgunos contenidos, tales come ciertas peliculas, estan disponibles en formate extra-ancho. Las barras superiores e inferiores no estan disponiNes.
2. Los dispositivos conectados, como la caja de cable/satelital, reproductores DVD/ Blu-ray y consolas de juego tienen sus propios ajustes de aspecto (formato). Realice los ajustes de aspecto de los dispositivos.
programas favoritos o los tipos de cannes cuando pulse el
boton de arriba/abajo del canal.
ustar el canal favorito (abajo)
cannes (pag. 29)
recepcion de la seSal (pag. 29)
FAVORITOS
Los nt_meros de canales de Favoritos se visualizan en la pantalla de sintonizaci6n de favoritos. Seleccione la
emisora deseada con el cursor o usando las teclas de nt3meros. (pag. 15)
FAVORITE
16
o m l_'_m
Ajustar el canal favorito
SUB
MENU
m _ de la lista (para guardar
m m _ Seleccionar el nQmero m _ _ el canal sin pulsar OK)
)Seleccionar el
numero de la lista
)Guardar el canal
visualizado
Eliminar un canal favorito
_@ Seleccione
_@Eliminar
_ (manteniendo pulsado)
Para cambiar la pagina
FAVORITE
® Los canales favoritos no se pueden ajustar cuando se usa una caja de cable o satelital.
Pulsar repetidamente para cambiar entre paginas (1/3, 2/3, 3/3 o salir)
Avanza/retrocede la pagina
tc_L3232c_spa_O608.indb 16 2010/12/21 15:40:4_
I
Otras operaciones utiles
Puede usar la tecla del mando a distancia para introducir los caracteres alfanumericos.
Conmuta el modo de entrada.
G
ABC _ abc _ 123
Pulse cada tecla de numero para pasar por los caracteres
alfanumericos.
I
Area de navegacion
Necesita ingresar la contrase_a cuando acceda al canal o entradas bloqueadas.
Introduzca su contrase_a de 4 digitos @Si es la primera vez que introduce una contrase_a, introduzca el nOmero
m m _ dos veces en orden para registrarlo.
@Tome nota de su contrase_a. No la olvide. (Si ha olvidado su contrase_a,
consulte a su concesionario local.)
@Cuando seleccione un canal bloqueado se visualizara un mensaje que le
permitira ver el canal si usted introduce su contraseSa.
@Cambio de contraseSa (pag. 33)
17
I
tc_L3232c_spa_O608.indb 17 2010/12/21 15:40:4!
I
Utilizacibn de VIERA TOOLS
VIERATOOLS es ta forma mas facit de acceder a las caracteristicas especiales de TV. listos se muestran como iconos de acceso directo en la pantalla de la TV.
Visualice VIERA TOOLS
Seleccione el elemento
iguiente
Ajuste cada elemento
® VIERA Link
n_ VIERA Link (pag. 26-27)
Pulse para salir
de la pantalla de menu
EXIT
Para volver a la
pantalla anterior
RETURN
O
® Diapositivas
=_, Diapositivas (pag. 20-21)
® VlERA IMAGE VIEWER
VIERA IMAGE VIEWER (pag. 20-21 )
® Modo eco
Eco/ahorro energia (pag. 34)
18
tc_L3232c_si)a_0608.indb 18 2010/12/21 15:40:4!
I
Visualizacibndec0ntenid0dedisp0sitiv0sextern0s
Con el equipo conectado encendido
Visualizacibn del menu de seleccibn de entrada
INPUT
Seleccione el modo de entrada
(atajo) Pulse la tecla de nQmero correspondiente en el mando a distancia para seleccionar
la entrada de su elecci6n. 0 bien pulse el bot6n INPUT
repetidamente para pasar por las
)Selecdone
(ejemplo)
_2_Introdu®
Terminal
Etiqueta
(ejemplo)
entradas disponibles. * ajuste la entrada sin uso a "No utilizado" (abajo) para una omisi6n rapida
Pulse laflecha ascendente/descendente paraseleccionar la entradade su
elecci6n,y luego pulse OK. ® Durante la selecci6n, el ment_
"Seleccionar entrada" desaparece si no se realize ninguna acci6n durante varios segundos.
® El terminal y el titulo (nombres)
del equipo conectado se visualizan.
Para cambiar la etiqueta de
entrada, vea debajo.
® EL titulo de entrada se desplegara en la pantalla si se personaliz6 el titulo de
entrada.
Opere directamente el dispositivo conectado utilizando
su propio control remoto.
® Ajuste PC (pag. 31)
Ponga un titulo a cada entrada
Para cada entrada, pulse _ para
_0 enSelecci°ne"Ajuste""Titul°sde entradas" _2_seleccionar un titulo o _'v para editar
® Titular cada entrada con los nombres de los dispositivos conectados como Reproductor
DVD, Caja de cable, etc. le permitira identificarlas e intercambiarlas.
Consulte la pag. 34 para obtener una lista de los nombres de titulos disponibles.
Puede ingresar tambien el nombre del titulo directamente. (Introducci6n de caracteres (pag. 17))
I
19
tc_L3232c_si)a_0608.indb 19 2010/12/21 15:40:51
I
Visualizacibndef0t0sconVIERAIMAGEVIEWER
VIERA IMAGE VIEWER le permite ver facilmente imagenes fijas en el televisor insertando simplemente una tarjeta SD
en la ranura de la tarjeta VIERA SD.
Inserte la tarjeta SD
÷ Inserte la tarjeta ÷ Retire la tarjeta Inserte la tarjeta SD con la
etiqueta orientada de frente.
Superficie Pulse \
de Iigeramente
etiqueta sobre ta tarjeta
hastaoir un
ruido seco Recorte
SD y Iuego
suetteta.
Visualice "VIERA IMAGE VIEWER"
Utilizacion de VIERA TOOLS (pag. 18)
® Ajuste de reproducci6n
automatica
Repro& automatica
de imageries (pag. 34)
VIERA IMAGE VIEWER _, Desplegar miniaturas en pantalla. Diapositivas _ Iniciar las diapositivas
Seleccione los datos que va a ver
Lgenminiatura
@ Tarjetasquepuedenutilizarse
(capacidadm&xima):TarjetaSDHC(32 GB),TarjetamicroSDHC(32GB),Tarjeta SD(2 GB),TarjetaminiSD(2GB),Tarjeta
microSD(2GB)(serequiereadaptador paraTarjetamicroSDHC/TarjetaminiSD/
TarjetamicroSD)
® Sise utilizaunaTarjetamicroSDHC,
TarjetaminiSD,TarjetamicroSD insertela/retirelajunto consuadaptador.
® Paraconocerdetallesy precauciones
retacionadosconlastarjetasSD.(pag.37)
Seleccione el elemento
Para iniciar las diapositivas Se visualiza informaci6n de la imagen seleccionada.
de im&genes
® DependiendodelformatoJPEG,elcontenidode"lnformaci6n"puedequenosevisualicecorrectamente.
Consultelapag.37(FormatodedatosparaexaminartarjetasSD)paraconocerdetalles.
Vea la imagen
Area de navegaci6n actual
Pulse para salir
de la pantalla de
menu
EXIT
Para volver a la
pantalla anterior
RETURN
@
20
tc_L3232c_si)a_0608.indb 20 2010/12/21 15:40:5
® Para visualizar/ocultar el area de
navegaci6n ÷
® Volver a la vista de imagen en
miniatura _
Visualizado uno cada vez
RETURN
Visualizaci6nde unasolafoto
A la foto anterior
(Mientrasseieen losdatos)
Diapositivas
I
Para ordenar por carpeta, mes o fecha
En@
_1_Seleccione el tipo de orden
Fichero (orden ascendente onumerico/alfabetico) Clasificar por mes (meses en orden ascendente) Clasificar por fecha (fechas en orden ascendente)
Seleccione el directorio
RETURN
Para volver a la
pantalla anterior
En@o@
_i_Visualice "Menu de imagenes fijas" _2_Seleccioneel elemento
Ajustar la imagen/Audio
uste
Ejemplo: MenO Imagen
MenO Imagen/MenQ Audio (pag. 31-32)
Ajuste de diapositivas
uste
Puede ajustar los segundos que se va a visualizar cada imagen en el modo de Diapositivas. (CortolR&pidalNormallLentalMuy lenta)
Si o No la funci6n de repetici6n (ciclo) de Diapositivas (No/Si). Seleccione el efecto de transici6n mostrado entre fotos (No/Borrar JBorrar l"/Borrar _/
Borrar _/Rastreo l'JRastreo _lDisolverlDamerolAleatoriolArreglolCollage) Seleccione el efecto de despliegue (No/Sepia/Escala de gris)
Ajustar la Musica de Fondo
@ Cambie
Seleccione la mOsica de entre 5 tipos. (No/M_sica l/M_sica 2/M_sica 3/M_sica 4/M_sica B)
RETURN
® Para detenerse en medio del ciclo _ Pulse
Fr] ;;U
21
I
tc_L3232c_si)a_O608.indb 21 2010/12/21 15:40:5:
I
VIERA Link TM"HDAVI Control TM''*
Control simultaneo de todos los componentes de Panasonic equipados con "HDAVI Control" utilizando un bot6n de un mando a distancia.
Disfrute de la interoperabilidad HDMI adicional con productos compatibles de Panasonic. Este televisor soporta la funci6n "HDAVI Control 5". Las conexiones a equipos (grabadora DVD DIGA, videocamara HD, sistema de teatro en casa, amplificador, etc.) con
cables HDMI habilita los controles de VIERA Link.
El equipo con la funci6n "HDAVI Control" permite las operaciones siguientes:
HDAVI Control o posterior
HDAVI Control 2 o posterior ÷ Control VIERA Link s61o con el mando a distancia del TV
HDAVI Control 3 o posterior ÷ Suministro de la informaci6n de ajuste (Idioma, tiempo, etc.)
HDAVI Control 4 o posterior ÷ Modo de Ahorro de energia (con modo de arranque rapido) HDAVI Control 5 ÷ El canal de retorno de audio
e Cambio de entrada automatico ÷Enc. Vinculado
÷ Apaga Vinculado ÷ Altavoz inicial
÷ Control de altavoces
÷ Ahorro energia de equipo no usado (para equipo disponible solamente)
÷ Funci6n de sincronizaci6n automatica de voz
El Canal de retorno de audio (ARC) es una funci6n que permite alas seSales digitales de sonido ser enviadas por un cable HDMI de vuelta desde el TV a un dispositivo de audio conectado.
Cuando se agrega un equipo nuevo, se reconecta un equipo o se cambia la instalacion despues
de hacer la conexion, encienda el equipo y luego encienda el televisor. Seleccione el modo de entrada al HDMI 1 o HDMI 2 (pag. 19) y asegurese de que la imagen se visualice correctamente.
VIERA Link "HDAVI Control", basado en las funciones de control proporcionadas por HDMI, que es un estandar industrial
conocido como HDMI CEC (Consumer Electronics Control), es una funci6n 0nica que hemos desarrollado y a5adido. Como tal, su funcionamiento con equipos de otros fabricantes que soportan HDMI CEC no puede ser garantizado. Consulte los manuales individuales de los equipos de otros fabricantes que soportan la funci6n VIERA Link.
Cable HDMI
Esta funci6n necesita de un cable que cumpla con la norma HDMI (completamente cableado). Los cables que no cumplan con la norma HDMI no se pueden utilizar. Se recomienda utilizar un cable HDMI de Panasonic. N0mero de pieza recomendada: RP-CDHS15 (4,9 pies/1,5 m), RP-CDHS3O (9,8 pies/3,0 m), RP-CDHS5O (16,4 pies/5,0 m)
* Para conocer detalles de las conexiones del equipo externo, consulte los manuales de instrucciones del equipo.
22
tc_L3232c_si)a_0608.indl) 22 2010/12/21 15:40:5'
Generalidades de las terminales
Parte posterior del TV
Conexion de la Grabadora de DVD (DIGA)
Cable HDMI
Grabadora DVD (DIGA) con funcion VIERA Link
Conexion del sistema teatro en casa/amplificador AV Se recomienda HDMI 1.
Cable optico
No se requiere un cable 6ptico al conectar un sistema de teatro en casa con soporte "HDAVI control 5"
mediante un cable HDMI. El audio estara soportado a traves de ARC (Canal de Retorno de Audio) (pag. 22)
® Con esta unidad se puede controlar un amplificador AV y un Grabadora DVD (DIGA).
Conexion de una videograbadora HD/Camara digital Presione INPUT y seleccione un terminal HDMI disponible, luego conecte la videograbadora a esta entrada. Confirme las funciones del control HDAVI despues de conectar. (pag. 24-27)
....................................................................................
Equipode cinepara casa confuncionVIERA Link
Amplificador AV con GrabadoraDVD(DIGA) funcion VlERA Link confuncionVIERALink
@
<
rrl ;;U
3>
r--
_5"
-4
E)
<>
© o
q- o
-4
Cable HDMI/mini HDMI
Videocamara HD LUMIX con funcion con funcion VlERA Link VlERA Link
Si se cambia la conexi6n (o ajuste) del equipo compatible con el HDAVI control, apague y encienda nuevamente la unidad mientras el equipo esta conectado (de manera que la unidad pueda reconocer correctamente el equipo conectado) y verifique el funcionamiento de reproducci6n del equipo conectado.
® Los equipos HDMI individuales tal vez requieran configuraciones de ment]s especificas adicionales para cada modelo.
Consulte sus manuales de instrucciones respectivos.
® Cuando el audio de otro equipo conectado a esta unidad a traves de HDMI salga tilizando "DIGITAL AUDIO OUT" de
esta unidad, el sistema cambiara a audio 2CH. (Cuando conecte a un amplificador AV a traves de HDMI podra disfrutar de un sonido de calidad mas alto.)
® Algunos dispositivos utilizan un terminal Mini-HDMI. Se debe utilizar un cable o adaptador HDMI (tipo A) a Mini-HDMI (tipo C).
23
I
tc_L3232c_spa_0608.indb 23 2010/12/21 15:40:5'
Para utilizar las funciones VIERA Link: Una vez conectado todo, configure "VIERA Link" en "Si" en el menQ de ajustes de
VIERA Link. Algunas caracteristicas estan deshabilitadas dependiendo de la versiSn del equipo "HDAVI Control".
Por favor verifique la lista. (pag. 22)
Visualice el menu
Seleccione "Ajuste VIERA Link" en "Ajuste"
Aj_
Seleccione "VIERA Link"
Seleccione "Si"
Pulse para salir
de la pantalla de
menu
EXIT
Para volver a la
pantalla anterior
RETURN
(La opciSn predeterminada es "Si')
Seleccione y realice otros ajustes
Cambie
24
tc_L3232c_si)a_O608.indb 24 2010/12/21 15:40:5_
I
AI usar un reproductor Blu-ray Disc, reproductor/grabadora de DVD o sistema de teatro en casa, la TV automaticamente cambiara a la seSal de entrada adecuada cuando comience la reproducci6n de alguno de estas
seSales de video.
Para un sistema de teatro en casa, los altavoces cambian automaticamente al modo de cine para casa.
Si: El televisor se enciende automaticamente y cambia a la entrada HDMI apropiada siempre que el equipo
compatible con "VIERA Link" se enciende inicialmente y se selecciona el modo de reproducci6n.
Cuando se selecciona "Si" y se apaga el televisor, todos los equipos compatibles con VIERA Link que estan
conectados se apagan tambien automaticamente.
La Grabadora DVD de Panasonic no se apagara si at_n esta en el modo de grabaci6n.
El televisor permanece encendido aunque se apague el equipo compatible con VIERA Link.
Inicio Rapido: Bajo las condiciones mencionadas arriba, cuando se apaga el televisor, todos los equipos conectados
que sean compatibles con VIERA Link pasan automaticamente al modo de espera ECO*.
Apaga Vinculado:(Si), El equipo conectado tiene "HDAVI Control 4 o posterior (con modo de arranque rapido)"
* En el estado en espera, el consumo electrico del equipo es minimo.
Si: El equipo VIERA Link compatible conectado se apagara automaticamente cuando no sea utilizado en estas
condiciones.
El equipo conectado tiene "HDAVI Control 2 o posterior". (para equipo disponible solamente) [ Ejemplos de temporizaci6n para operaci6n ]
Cuando cambie la entrada desde HDMI.
@ < rrl
>
r--
_5"
-q
CJ
<>
C)
o
"lnterno" es el ajuste predeterminado. Para porter el sistema de teatro en casa como altavoces predeterminados, cambie la configuraci6n de altavoces predeterminada de "lnterno" a "Externo'. El sonido saldra del sistema de cine
para casa siempre que se suministre alimentaci6n al televisor.
Reduce al minimo los retardos de sincronizaci6n de voz entre la imagen y el sonido cuando se hace la conexi6n a un
sistema de cine para casa o a un amplificador de Panasonic.
Alguna informaci6n de ajuste del televisor se puede transmitir a cada equipo (Grabador/Cine para casa/Reproductor) con la funci6n "HDAVI Control 3 o posterior" conectada al televisor mediante un cable HDMI.
Datos que se pueden transmitir Grabador Cine para casa Reproductor
_ Puesta del idioma de visualizaci6n en pantalla
(English/EspaSol/Frangais) O O O
@]Relaci6n de aspecto del panel
(16:9, fija) O O O
(_)Informaci6n de subtitulos
(Modo/Tipo de CC/Ajustes digitales) O ......
(4_Informaci6n de canal
(Serial de entrada/Lista de canales/Informaci6n O ......
de titulos)
® Hay una posibilidad de que la informaci6n del idioma GUIse pueda poner desde todos los equipos con la funci6n
HDMI CEC conectada al televisor mediante un cable HDMI. Dependiendo de las condiciones de funcionamiento o
de la especificaci6n de cada pieza del equipo, el ajuste puede que sea aplicable o no Io sea.
® Para conocer detalles del funcionamiento del equipo externo, lea los manuales de instrucciones del equipo.
o
-q
25
I
tc_L3232c_si)a_0608.indb 25 2010/12/21 15:40:5_
I
l=II_ LvAI:I_:lI111,IL,j_ _ItL_,,1_i11.,'1F_L'_
Algunas caracteristicas estan deshabilitadas dependiendo de la versi6n "HDAVI Control" del equipo.
Por favor verifique la lista. (pag. 22)
Visualizacibn del menu VIERA Link
_Seleccione
uiente
Seleccione el elemento
Los elementos en el menQ VIERA Link pueden desactivarse si se conecta un equipo no compatible (debe ser HDAVI Control 2 o posterior) o si el equipo no ha iniciado la conexi6n con el televisor. En ese caso, apague y encienda el equipo mientras el televisor se encuentra
encendido.
Para mas detalles, ver "VIERA Link" en la pag. 24.
Pulse para salir de la pantalla de
menu
EXIT
Para volver a la pantalla anterior
RETURN
@
26
Seleccione
- Cambie
Establezca
tc_L3232c_si)a_0608.indb 26 2010/12/21 15:40:5!
I
Para la salida de audio puede seleccionar los altavoces
de cine para casa o del televisor.
Controle los altavoces de cine para casa con el control remoto del televisor.
Esta funci6n s61oesta disponible cuando esta conectado un
amplificador o reproductor de cine para casa de Panasonic.
Seleccione "Salida altavoz"
_ Seleccione "Externo" o "lnterno"
'Seleccione
,Cambie
En el menO VIERA Link, usted puede seleccionar el equipo conectado mediante HDMI y acceder a el rapidamente. ContinQe utilizando el control remoto de su televisor para utilizar el equipo, apuntandolo al televisor.
Seleccione "Control VIERA Link" ÷ Si hay mas de un elemento del equipo, un nQmero
_) Seleccione el equipo al que quiera acceder (ej., Grabadora 1/Grabadora 2/Grabadora 3...)
(Grabador/Cine para casa/Reproductor/Videocamara/LUMIX/÷ El nOmero de elementos del equipo que podran Camara digital) conectarse es tres para grabadoras, y tres en total
÷ Utilizaci6n de VIERATOOLS (pag. 18)
Seleccione
_Cambie
$61o puede seleccionar los elementos disponibles.
Control remoto del televisor disponible El que funcione o no dependera del equipo conectado.
Mover el cursor/Seleccionar Configurar/Acceder
Volver al menQ anterior
s,, Visualizar el menQ de funciones del
O equipo
Disponible cuando se visualiza la finalidad de las teclas
Salir Canal superior/inferior
_-_ 0-9
Externo: Ajuste para el equipwo
Subida/bajada del volumen ÷
Silenciamiento del sonido ÷ Q
÷ El sonido del televisor se silencia. ÷ Cuando se apaga el equipo, los altavoces del televisor
se activan.
÷ AI seleccionar "Externo", el equipo se enciende
automaticamente siesta en el modo de espera.
Interno: Los altavoces del televisor estan activados.
despues del nombre indica el nemero de elementos.
para Cine para casa/ReproductorlVideocamara/
LUMIX/Camara digital.
÷ Hay un limite en el nQmero de conectores HDMI.
_3_Utilice el equipo con el control remoto del
televisor, apuntandolo al televisor
÷ Para utilizar el equipo, lea el manual del mismo.
Reproducci6n
D Parada
Atras/adelante
_ Omitir atras/adelante
Pausa Subtitulos
SAP (Seleccione el modo de audio)
m Seleccionar subcanal digital
MUTE
@
<
m ;;U
:1>
i--
5"
ID
<>
© o
.m
o
Regresa la selecci6n de sepal de entrada del dispositivoseleccionado con el Control VIERA Link ala sepal de TV. Seleccione "Volver a TV"
)Seleccione
-(_)Aceptar
27
I
tc_L3232c_si)a 0608,indb 27 2010/12/21 15:41:0
I
Edicibny configuracibndecanales
Los ajustes del canal actual se pueden cambiar segQn sus necesidades y las condiciones de la recepci6n.
Visualice el menu
Seleccione "Ajuste"
uiente
-(1.)Seleccione
Seleccione "Ajuste ANT/Cable"
Pulse para salir de la pantalla de
menu
EXIT
Busca y agrega automaticamente los canales que pueden recibirse en la memoria.
0) Seleccione "Entrada ANT" (3) Seleccione el modo de exploracion (pag. 13) ÷ Seleccione "Cable" o "Antena"
O seleccione "No utilizado" (pag. 13) 3tar
Seleccione "Programa auto" -_Seleccione
uiente
)Seleccione
@ Despues de finalizar la bOsqueda, seleccione
"Aceptar" (vea pag. 29 (5)).
@ Todos los canales memorizados previamente se
borraran.
28
tc_L3232c_si)a 0608,indb 28 2010/12/21 15:41:0;
I
UtiliceesteprocedimientocuandocambielaconfiguraciSn deloscanalesderecepciSnocuandocambiela visualizaciSndeloscanales.Ademas,utilicelotambien
® Titulos
paraagregarobrincarmanualmentecanalesquese encuentranenlalistadecanales.
PuedeseleccionarunmododesintonizaciSndecanal(S61o digital/S61oanal6gico)en"Mododenavegaci6n".(pag.34)
_1_Seleccione "Editar"
Seleccione o edite el identificador de emisora. (maximo de 7 caracteres disponibles)
® Favoritos
_2_Seleccione el elemento que quiera editar
Favoritos
Titulos Agregar
R G la p&gina
Vuelva a la pagina anterior.
Vaya a
siguiente.
÷ Titulos:
Cambio del identificador de emisoras
÷ Favoritos:
Registra los canales en la lista de favoritos.
÷ Agregar:
Agrega o brinca canales
I Configurar favorito I Seleccione el nOmero
® Agregar
@ Mueva el cursor al numero del canal
@ Seleccione "Aceptar"
Edite
__/Selecci°ne RETURN
Pulse OK para seleccionar "Si" (agregar) o "No" (brincar)
W_w
Seleccione
sintonizar el canal
para
@ FR
N
£)._
(2_. O,
"-I
,<
('b o
(Q
C
(2_. o,
Para cancelar la edicion
Compruebe la intensidad de la seSal si se encuentra interferencia o se congela una imagen digital.
m_m
de la seSal
_Seleccione local.
el canal
® Si la seSal es debil compruebe la antena. Si no
encuentra ningOn problema, consulte a su concesionario
® No esta disponible si se selecciona "Cable" en
"Entrada ANT" (vea pag. 28).
® S61o es eficaz para los canales digitales.
29
I
tc_L3232c_si)a_0608,indb 29 2010/12/21 15:41:0:
I
Cbmoutilizarlasfuncionesdelosmends
Varios menOs te permiten seleccionar configuraciones para la imagen, el sonido y otras funciones, para que
usted pueda disfrutar viendo ta televisi6n como usted desee.
Visualice el menu
® Muestra las funciones que pueden ser
ajustadas
® Algunas funciones se deshabilitaran
dependiendo del tipo de sepal de entrada
Estructura del ment_
(Ejemplo: Titulos de entradas)
Seleccione el ment)
Pulse para salir _ Ajuste
de la pantalla de menu
EXIT
Barra de menO Presione OK para mover los elementos del men&
menO
Presione OK para proceder a la siguiente pagina si esta disponible.
ayuda
de operaci6n
ustes de imagenes ustes de audio
)orizador (Apagado, Temporizador de encendido/apagado)
Canal, Juego, Programa etc.)
uste de subtitulos (CC)
(otros ajustes)
o seleccione un elemento del menu
uste
O
Seleccione
Para volver a la
pantalla anterior
RETURN
@
(Ejemplo: MenQ Imagen)
3O
tc_L3232c_si)a 0608,indb 30 2010/12/21 15:41:01
I
® Regreso prefijados se tornara gris (deshabilitado) en caso que no se realicen cambios en los siguientes menQs:
"lmagen", "Ajuste PC", "Audio" y "Subtitulos".
Regreso prefijados Restablece la configuracion del menQ de imagen (excepto para "lmagen avanzada"). Modo Vivido Provee un cantraste y una nitidez de imagen realzados para ver programas en una
Est&ndar Recomendado para vet bajo condiciones normales en una habitacion con iluminacion atenuada.
Cinema Para ver peliculas en una habitacion oscura. Proporciona una imagen suave, come la del cine. Usuario Personaliza cada elemento segQn sus preferencias.
(Fotografico) La foto se visualiza en el menQ JPEG.
Luz de Fondo Ajusta la luminancia de la luz de fanda.
Contraste, Ajusta el color, el brille, etc. para que cada mode de imagen se ajuste a sus gustos. Brillo, Color, Gama de visualizaciones Centraste/Brillo/ColoriNitidez : 0 - 100 Tinte, Nitidez Tinte : -50 - +50
Temp. color AzullNormallRojo Selecciona una opcion de color fria (azul), normal o cNida (rajo). Imagen con IA No/Si Controla las areas oscuras sin afectar al nivel del negro ni al brillo de la imagen en general.
S.S.A.C. No/Si Ajusta automaticamente ei briilo de la panta!la de acuerdo al estado de iluminacion del ambiente. Reduc. de ruido No/Si Reduce el ruido en el canal, camQnmente Ilamado efecto de nieve. Permanece en
Algunas menQs est&n en gris dependienda de la seSal de entrada a estado. (Ej.: "Ajuste acercamiento" se tornara gris si el aspecta no est& determinado en ACERC.)
Ajustes de Formato pantalla JUSTOI4:31ACERCl Cambie el formate (Relacion de aspecto). aspecto COMP/H-LLENO Le permite escoger la relacion de aspecto dependiendo del
Tama_o de H Tama6o 1/ Ajustar el margen de visualizacidn horizontal para reducir el ruido a
Ajuste acercamiento Ajusta la alineacion vertical y el tamaSa cuanda el ajuste del aspecto es "ACERC"
Ajuste PC Regreso prefijados Repone el ajuste del PC.
Sincronia HN Las seSales de sincronizacion horizontal y vertical se
Pto. de reloj
Pos. horiz.
habitacion bien iluminada.
No cuanda se recibe una seSal intensa.
formate de la seSal recibida (p&g. 36)
Tama_o 2 ambos lados de una imagen.
Tamafio 2: Ajustar el tamaSo de la imagen en funcidn del mode de aspecto para eliminar el ruido. (p&g. 36)
intraducen desde el conectar HD/VD. (pag. 39)
En verde Utiliza una seSal sincronizada en la seSal G de video que fue
intraducida per el conectar G. (p&g. 39)
Alivia el problema si una imagen parece que tiene franjas verticales a parpadea a queda borrosa parcialmente.
Ajusta la posicion horizontal. Q I 1
@
C)
O,
3
o
£
m
o0
c_
o .._ CD
o0
0._ (D
0 o0
3
(D
t-,
(D
o o
Posicidn vert
Ajustalaposicionvertical. ' _ O L! @J
Fase de reloj
Resolucidn
Frecuencia H Frecuencia V
Alivia el problema si toda la imagen parece que parpadea o est& borrosa. Ajuste primero el reloj de puntos para obtener una imagen tan buena como sea posible, y luego ajuste la fase de reloj para que aparezca una imagen clara.
® Tal vez no sea posible visualizar una imagen clara debido a que las se_ales de
entrada no son buenas.
Cambia a visualizacion panoramica.
® VGA (640x480 pixeles), WVGA (852x480 pixeles),XGA (1.024x768 pixeles),
WXGA (1.280x768 pixeles)
® Las opciones cambian dependiendo de las seSales.
Visualiza las frecuencias H (horizantal)/V (vertical). Gama de visualizaciones
Hodzantal:15 - 110 kHz Vertical: 48- 120 Hz
31
I
tc_L3232c_spa_0608,indb 31 2010/12/21 15:41:01
I
Algunos menQs estan en gris dependiendo de la seSal de entrada o estado. (" Pelicula a video" estar& en gris (deshabilitado) si la se5al de salida es de alta definici6n o si est& mirando fotos, etc.)
Imagen avanzada 3D Y/C filtro No/Si Minimiza el ruido y la diafonia cromatica de la imagen.
Matriz color SD/HD Selecciona la resoluci6n de la imagen de los dispositivos
MPEG NR No/Si Reduce el ruido de las seSales digitales especificas de DVD,
Nivel obscuro Obscuro/Claro Seleccione Obscuro o Claro. $61o es valido para las se5ales de
Pelicula a video No/Si/Auto Ajusta la imagen grabada en 24 fps para una calidad 6ptima.
conectados a componentes. SD: Visi6n normal HD: Visi6n de alta definici6n
Se utiliza solo cuando la seSal de video es 480p.
STB, etc.
entrada externas.
.... !iiiiiiiiUi!Li! i i..................................... i!ii iii i i iiiiiiiiii!i!i i!i !iiiiiiii ii ii;!i:i:iiiii iiiiH i!i!!!!!!i!!!i!!!:!!i !iHi!!!i!! iiiii!!!!! !! !! !!i!! !i iiii!!iii9i;i iiiii
Regreso prefijados Repone los ajustes de Bajos, Altos y Balance a los ajustes predeterminados en la
Bajos Aumenta o disminuye la respuesta de los graves.
Altos Aumenta o disminuye la respuesta de los agudos.
Balance Realza el volQmen de los altavoces izquierdo/derecho.
Audio avanzado Envolvente No/Si Mejora la respuesta de audio izquierda/derecha cuando se
Nivel de volumen Minimiza la diferencia de volQmen despues de cambiar a
Altavoces de TV No/Si Cambia a "No" cuando se utilizan altavoces externos.
Entrada HDMI 1-2 Digital/ El ajuste predeterminado para la conexion HDMI es "Digital".
f&brica.
escucha en estereo.
entradas externas.
No: "Envolvente" y "Nivel de volumen" no funcionan si se selecciona "No".
Comp./Video 1/ (SeSal de entrada digital) Video 2 El terminal de entrada de audio se puede seleccionar cuando
esta conectado el cable DVl. (SeSal de entrada anal6gica)
I1_]_ i I l-"_ (:-._"! ! _ (:-] i i 1 iIe] II I'_. [ ! [e7- _1_ [t,] t[I [t,_l;_ II}[I _!_.|! I {I]I l _111[l_.l I l [t,] tl (t,lt,] i _l [_v/l.'_l]
SJ los aJustes del ]emporizador est_in en gris, ajuste prJmero el reloj (ver pag. 34) y asegQrese que "Autoencendido" este fijado en "No" (pag. 34).
Apagado
(Temporizador de apagado)
Cron6metro 1-5 (Temporizador
de encendido/ apagado)
Apagado 0/15130160190 (minutos)
Fijar temporizador Habilita o deshabilita este temporizador. (NoiSi) Entradas Establece la entrada a seleccionar cuando se encienda el TV.
Canal Establece el canal a seleccionar cuando se encienda el TV. Dia Establece el dia que se enciende el TV.
[DOM, LUN, MAR, MIE, JUE, VIE, SAB, (Visualiza la fecha futura mas pr6xima) LUN-VIE, SAB-DOM, DIARIO, Cada DOM, Cada LUN, Cada MAR, Cada MIE, Cada JUE, Cada VIE, Cada SAB]
Encender Establece la hora en que se enciende el TV. El TV se apagara luego de 90 minutos o
de acuerdo a Io especificado.
Apagar Establece la hora en que se apaga el TV dentro de 24 horas.
Seleccione el tiempo para el apagado autom&tico del TV.
32
tcL3232csi)aO608,indl) 32 2010/12/21 15:41:01
I
CadavezquevisualiceelmenQBloqueoselepedir&queintroduzcasucontraseSa.
Ajuste/ingresodecontraseSa(p&g.17) Ajuste"Usuario"en "Mada" para especificar ajustes de "Canal", "Juego" y "Pragrama'.
Modo No Desbloquea toda la configuracion de bloqueo de "Canal", "Juego" y "Programa".
Total Bloquea tadas las entradas independientemente de la canfiguracion de bloqueo
Usuario Bloquea las entradas especificadas de "Canal", "Juego" y "Pragrama".
Canal Modo Selecciona el estada de bloqueo de canal (NaiTotal/Usuario) (Estos canales Total: Bloquea todas los cannes
se bloquear&n No: Desbloquea todas los cannes independientemente Usuario: Bloquea cannes especificadas. Seleccione "Canal 1" - "Canal 7"
de la clasificaci6n Canal 1-7 Seleccione el canal que va a bloquear. (Seleccione hasta 7 (1-7) cannes para del programa.) bloquearlos.)
Juego Si/No Bloquea Canal 3, Canal 4 y las entradas externas. Programa Modo Seleccione el estada de bloquea de programa. (No/Si) La tecnalogia "V-chip" permite
(Para establecer que los pragramas restringidos sean blaqueados segQn las clasificacianes de el nivel de television. Si: Fije cada nivel de calificaci6n (MPAA, US.TV, C.E.LR., C.F.L.R.)
clasificacion) MPAA Seleccione la clasificacion de peliculas de EE.UU a ser bloqueadas.
U.S.TV Clasificaciones para pragramas de television de los EE.UU. Para m&s C.E.L.R. Clasificaciones para el ingles de Canad&. (p&g. 35)
C.F.L.R. Clasificaciones para el frances de Canada
Cambio de Cambie la clave. Introduzca dos veces la nueva cantraseSa de 4 digitos. contraseSa
Este televisor ha sido diseSado para soportar el "Downloadable U.S. Region Rating System" cuando se encuentre disponible. ($61o esta dispanible en los EE.UU.)
La clasificacion No es independiente de otras clasificaciones.
Cuando bloquee un nivel de clasificacion especifico basado en la edad, la clasificacion No y cualquier otra clasificacion m&s restrictiva tambien se bloquearan.
co !."]'1"1_1[[1"1 [o_ TtF.'!!_l IlrA¢.[o_[o]ll[o [;-]F.'!! Iol I__! [o_
La televisi6n incluye un decodificadar incorporado capaz de proporcionar una visualizaci6n de texto del audio. El programa que este siendo transmitido deber& tenet informacion de subtitulos (CC). (p&g. 38)
"Canal", "Juego" y "Programa".
informacion
@
C)
O,
3
o
m
00
c) o
...m CD
oo Q_
(D 0
oo
3
r-, (D
Regreso prefijados Reconfigura todos los ajustes de subtitulos a los ajustes predeterminadas en f&brica Modo Si/No/ Si: Para mostrar subtitulos ocultos.
An_logo CC4-4/TI-4 Elija el servicio de subtitulos de las emisiones analogicas.
Digital Principal/Secund./ El men_ Subtitulos digitales le permite configurar la forma en que va a ver los
Ajustes digitales TamaSo TamaSo del texto (Establece ajustes Letra Fuente del texto
de visualizacion para programa Estilo Estilo del texto (Elevado, Deprimido, etc.)
digital) Frente Color del texta
La configuraci6n en "AnNogo" o "Digital" depende de la emisora.
CC en mudo CC en mudo: Para mostrar los subtitulos acultas cuando el audio este en silencio.
(Cuando no se utiliza seleccione "No")
CC1-4: Informacion relacionada can las imagenes (Aparece en la parte inferior de la pantalla.)
T1-4: Informacion textual (Aparece en toda la pantalla.)
Servicio 3141516 subtitulos digitales.
Opacidad frontal Opacidad del texto
Fondo Color de la caja de texto
Opacidad trasera Opacidad de la caja de texto
Contorno Color del cantorna del texto (Identifique las opciones de configuracion en la pantalla.)
33
I
tc_L3232c_si)a_O608,indb 33 2010/12/21 15:41:01
I
Mode de Todos/Favoritos/ Selecciona el canal con el bot6n de canal arfiba/abajo. navegaci6n S61o digital/ Favorites: S61o cuando se registran canales come FAVORITE (p&g. 16).
Idioma English/ Selecciona el idioma para los menus de la pantalla.
Reloj Ajusta el reloj. (p&g. 14)
S61o anal6gico
EspaSol/ Fran_ais
Titulos de entradas
(Etiquetas de visualizaci6n
de dispositivos
externos)
Eco/ahorro
energia
Ajuste avanzado Autoencendido Enciende automaticamente el televisor cuando se enciende el receptor de television
Ajuste Inicial Reinicie la configuraci6n inicial desde configuraci6n de "ldioma". (p&g. 12) Acerca de Visualiza la versi6n del televisor y la licencia del software.
Regreso prefijados AI realizar la reposicion se cancelar&n todos los elementos establecidos con Ajuste
Seleccione la terminal y la etiqueta del equipo externo. Los dispositivos conectados a los terminales de entrada externos se pueden etiquetar para identificarlos m&s facilmente durante la selecci6n de entrada. (Seleccionar entrada (p&g. 19)) Terminales: HDMI 1-2/Comp./Video ltVideo 2/PC
VCRICABLEISATELITEIVGDICAMARAIMONITORIAUXIRECEPTORIMEDIA
I Etiqueta:[BLANCO]N°utilizad°iBlu-ray/DVD/GrabdeDVD/HOMETHTR/JUEGO/Pc/ 1
CTR/MEDIA EXT/OTROS
Es posible ingresar tambien el nombre del titulo directamente. (Introducci6n de caracteres (pag. 17))
Economia de energia
(Est_ndar/Ahorra) Si no hay seSal
por 10 minutos (Encendido/
Apagar TV)
Si no hay operaci6n por
3 horas (Encendido/
Apagar TV)
(No/Si) per cable o un dispositivo conectado. El cable de CA del televisor debe estar
Reprod. Diapositivas/ Define el tipo de reproduccion para reproducir tarjetas SD autom_tica de Miniaturasl autom&ticamente.
im_genes Ajustar despues/ Ajustar despues: Se mostrara repetidamente el menu "Ajustes
Reduce el brillo de la pantalla para disminuir el consume de energia. Para ver programas en habitaciones oscuras sin que se canse la vista.
Para conservar energia, el televisor se apaga automaticamente cuando no se recibe ninguna seSal y no se realiza ninguna operaci6n durante mas de 10 minutes.
No se utilize cuando "Autoencendido" se pone en "Si", o cuando esta establecido "Cron6metro".
"Si no hay seSal per 10 minutes rue activado" se visualizara durante unos 10 segundos cuando el televisor se encienda per primera vez despues de desconectarse la alimentaci6n mediante "Si no hay seSal per 10 minutes".
La visualizaci6n en pantalla mostrar& parpadeando los nQmeros 3, 2 y 1 para indicar los Qltimos tres (3) minutes que quedan hasta que se produzca el apagado.
Para ahorrar energia, el TV se apaga automaticamente cuando no se realiza ninguna operaci6n con las teclas del mando a distancia y del panel delantero durante
mas de 3 horas.
No se utilize cuando "Autoencendido" se pone en "Si", o cuando esta establecido "Cron6metro", o mientras esta seleccionada la "Entrada de PC".
"Si no hay operaci6n per 3 horas rue activado" se visualizara durante unos 10 segundos cuando el televisor se encienda per primera vez despues de desconectarse la alimentaci6n mediante "Si no hay operaci6n per 3 horas".
La visualizaci6n en pantalla mostrar& parpadeando los n_meros 3, 2 y 1 para indicar los Qltimos tres (3) minutes que quedan hasta que se produzca el apagado.
enchufado en este dispositivo. El televisor se enciende cada vez que se restaura la alimentacion.
No "Visualizaci6n de fetes con VIERA IMAGE VIEWER" (pag. 20)
come, per ejemplo, los ajustes de canales..
Ajuste/ingreso de contraseSa (p&g. 17)
de Visor de Im&genes".
34
tcL3232(si)aO608,indl) 34 2010/12/21 15:41:0'
Listadeclasificacionesparaelbloqueo
La tecnologia "V-chip" le permite bloquear canales o programas seg0n clasificaciones estandar
establecidas por ta industria del entretenimiento.
TABLA DE CLASIFICACIONES DE PELJCULAS PARA LOS EEUU (MPAA)
No tienen restricciones o las restricciones no son aplicables.
PG SE SUGIERE LA SUPERVISION DE LOS PADRES. AIg0n material puede no ser apropiado para los ni5os.
PG,i3 SE RECOMIENDA ENCARECIDAMENTE LA SUPERVISION DE LOS PADRES. AIg0n material puede no ser
NC-17 NO SE ADMITE AL P(JBLICO MENOR DE 17ANOS.
X ADULTOS SOLAMENTE.
TABLA DE CLASIFICACIONES DE PROGRAMAS DE TV PARA LOS EEUU
CONTIENE PROGRAMAS SIN RESTRICCIONES Y PROGRAMAS NA (NO APLICABLES). Las peliculas no
G PUBLICO EN GENERAL. Se admiten a todos los p0blicos.
apropiado para los ni5os menores de 13 afios. RESTRINGIDAS. Los j6venes menores de 17 aSos y los ni5os necesitan estar acompa5ados de sus padres o
una persona adulta que los supervise.
@ ©@
o,_r_.
B_
o_ co.
_'o__
NR (Si TV-NR clasificaci6n)
Youth
Guidance
FV: FANTASIA/CARICATURAS CON VlOLENClA V: VlOLENCIAS: SEXO L: LENGUAJE OFENSlVO D: DIALOGO CON CONTENIDO SEXUAL
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
÷ Viewable (Visible) ÷ Blocked (Bloqueado) ÷ Viewable (Visible)
÷ Blocked (Bloqueado) ÷ FV (Bloquear FV)
÷ Viewable (Visible) ÷ Blocked (Bloqueado)
÷ Viewable (Visible) ÷ Blocked (Bloqueado)
÷ D,L,S,V(Todasselecci0nadas ÷ Cualquier combinacion
deD, L,S,V
÷ D,L,S,V(Todasseleccionadas ÷ Cuaiquierc0mbinaci6ndeD,L S,V contenido sexual, lenguaje inapropiado, y violencia mas intensa.
÷ L,S,V (Todas seleccionadas) Solo audiencia Madura. Este programa puede contener temas para ÷ Cuatquierc0mbinaci6ndeL, S,V adultos, lenguaje profano, violencia grafica y contenido sexual explicito.
No clasificado.
Todos los niSos. Los temas y elementos en este programa estan especialmente diseSados para un publico infantil, inciuyendo niSos de 2-6 aSos.
Dirigido a nii_os mayores. Los temas y elementos en este programa
pueden incluir ligera violencia fisica o comica, o puede asustar a ni5os
menores de 7 afios.
Audiencia General. Contiene poca o nada de violencia, nada de lenguaje fuerte, y poco o nada de di&logo o situaciones con contenido sexual.
Guia de los padres sugerida. El programa puede contener lenguaje obsceno infrecuente, violencia limitada, dialogos o situaciones
sexualmente sugestivas. Advertencia a los padres. Este programa puede contener temas sofisticados,
TABLA DE CLASIFICACIONES PARA INGLES DE CANADA (C. E. L. R)
E Exenta - La programacion exenta incluye: noticias, deportes, documentales y otros programas de informacion,
entrevistas, videos musicales y programas de variedades.
C Programacion para niSos menores de 8 a5os. Sin lenguaje ofensivo, desnudos ni contenido sexual.
Programaci6n considerada generalmente aceptable para niSos de 8 afios y menos. Sin blasfemias, desnudos ni contenido sexual.
G Programacion general para todos los p0blicos.
PG Se sugiere la supervision de los padres. AIg0n material puede no ser apropiado para los niSos.
14÷ La programacion contiene temas que pueden no ser apropiados para el pQblico menor de 14 aSos. A los padres
i8+ Mayores de 18 a5os. Programacion limitada a los adultos. Contiene escenas de violencia constante o de
se les avisa que no deben dejar ver estos programas a los niSos ni a los j6venes menores de 14 a5os.
excesiva violencia.
TABLA DE CLASIFICACIONES PARA FRANCES DE CANADA (C. F. L. R)
E Exenta - La programacion exenta.
G minimo o se muestra apropiadamente.
8 ans÷ 8+ General - No se recomienda para los niSos pequeSos. La programaci6n es para un p0blico diverso, pero
13 ans+ violencia o una o mas escenas suficientemente violentas como para afectarlos.
16 ans÷ La programacion puede que no sea apropiada para menores de 16 afios. Contiene frecuentes escenas de
18 ans+ Programacion limitada a los adultos. Contiene escenas de violencia constante o de mucha violencia.
( Precauci6n ) @ El sistema V-Chip que se utiliza en este aparato es capaz de bloquear los programas "NR" (no clasificados, no aplicables y ninguno)
de acuerdo con las normas de la FCC indicadas en la Secci6n 15.120(e)(2). Si se elige la opci6n de bloqueo de programas "NR", "podr&n producirse resultados inesperados y posiblemente confusos, y usted tal vez no pueda recibir anuncios de emergencia o ninguno de los tipos de programaci6n siguientes".
Anuncios de emergencia (mensajes EAS, avisos del tiempo y otros)
Programas locales Noticias Politica Anuncios de servicios p0blicos Religion Deportes Tiempo
General - Programacion para pQblico de todas las edades. No contiene violencia, o el contenido de la misma es
contiene violencia de vez en cuando. Se recomienda la supervision de adultos. La programacion tal vez no sea adecuada para nii_os menores de 13 aSos. Contiene pocas escenas de
Se recomienda encarecidamente la supervision de personas adultas.
violencia o de mucha violencia.
coo c-o
o_
BS-
_ t'-- r-,t_
mo
35
m
I
tc_L3232c_si)a_0608.indb 35 2010/12/21 15:41:0'
Informacibn tdcnica
Pulse el bot6n "FORMAT" para pasar por los modos de aspecto. Esto le permite elegir el aspecto dependiendo del formato de la seSal recibida y sus preferencias. (pag. 16) (ej.: en el caso de una imagen 4:3)
@ COMP
I-- 4 --I I 16ul
@ JUSTO
I 4_1 1_16_1
Amplia horizontalmente la imagen 4:3 hasta los bordes
laterales de la pantalla. (Recomendada para la imagen anam6rfica)
@ H-LLENO
I-- 4 --I I-- 16--1
Amplia horizontalmente la imagen 4:3 hasta los bordes
laterales de la pantalla. Los bordes laterales de la imagen se recortan.
@ ACERC
I-- 4 --I I-- 16--1
Amplia la imagen 4:3 para que ocupe toda la pantalla.
(Recomendada para Letter Box)
Alarga para justificar la imagen 4:3 alas cuatro esquinas de la pantalla.
(Recomendada para la emisi6n de televisi6n normal) @ 4:3
Estg_ndar (Tenga en cuenta que puede quedar una "Retenci6n de imagen" de la barra lateral debido a que se muestra durante mucho tiempo.)
@ 480i (4:3), 480i (16:9), 480p (4:3), 480p (16:9):
COMP, JUSTO, 4:3 oACERC
@ 1080p/1080i1720p: COMP, H-LLENO, J USTO, 4:3 o ACERC
÷ Ajuste acercamiento
La posici6n y el tamaSo vertical de la imagen se pueden ajustar en "ACERC".
_1)Seleccione "Ajuste acercamiento" en el menQ "lmagen". (pag. 31)
0) Posici6n V: Ajuste de posici6n vertical _ TamaSo V: Ajuste de tamaSo vertical
lateral
@ Para restablecer la relaci6n de aspecto @ (OK)
IIl_ff_'i_ B_ I-'1
® Relaci6n de aspecto: 4:3
TamaiSo 1 TamaiSo 2 @ La anchura se reducirg_ en ambos lados para
@ Relaci6n de aspecto: COMP/JUSTO (H-LLENO/ACERC)
reducir el ruido.
@ La anchura aumentarg_ en ambos lados para
reducir el ruido.
36 Vea la p&gina 31 para obtener mg_s informaci6n
tc_L3232c_si)a 0608,indb 36 2010/12/21 15:41:0'
Foto: Imagenes fijas grabadas con camaras digitales compatibles con archivos JPEG de las
Formato de datos: Baseline JPEG (Submuestreo: 4:4:4, 4:2:2 o 4:2:0) M&ximo nQmero de archivos: 9.999
Resolucion de imagen: 160 x 120 a 20.000.000
* DCF (Norma de dise5o para sistemas de archivos de camaras): Una norma de la Asociacion de las Industrias de la
( Precauci6n ) ** EXIF (Exchangeable Image File Format) @ Una imagen JPEG modificada con un PC no se puede visualizar.
@ Los archivos parcialmente degradados tal vez puedan visualizarse con una resolucion reducida.
normas DCF* y EXlF**
Tecnologia de la Informacion y la Electronica del Japon.
@ Estructura de carpetas vistas en PC
_DCIM
_ 100_PANA
P100000_.JPG_Caracteres arbitrarios de 4 digitos + NOmero de archivo de 4 digitos
,/J P1000002.JPG @ Caracteres que se pueden utilizar: 1-byte "a a z" "A a Z" "0 a 9" y ....
Creada autom&ticamente
Nt3mero de carpeta de 3 digitos + Caracteres arbitrarios de 5 digitos
i , , _
@ Los nombres de carpetas y archivos pueden ser diferentes dependiendo de la c&mara digital utilizada. @ Para conocer las tarjetas de memoria SD mas apropiadas, confirme la informaci6n mas reciente en el sitio Web siguiente.
http://panasonic.jp/support/global/cs (En este sitio solo se emplea el idioma ingles.)
@ Use una tarjeta SD que cumpla con los estandares para estas tarjetas. No hacerlo asi puede que
cause problemas en el funcionamiento de la unidad de TV.
@ No retire la tarjeta mientras la unidad est& accediendo a los datos (esto puede da5ar la tarjeta o la
unidad). @ No toque las terminales de la parte posterior de la tarjeta SD. @ No ejerza sobre la tarjeta una presion fuerte ni la golpee. @ Inserte la tarjeta en el sentido correcto (de Io contrario, la tarjeta o el televisor podria da5arse).
@ La interferencia electrica, la electricidad est&tica o el funcionamiento erroneo pueden da5ar los datos
o la tarjeta. @ Haga una copia de seguridad de los datos grabados a intervalos regulares por si estos se
deterioran o se da_an, o por si la unidad funciona de forma err&tica. (Panasonic no acepta ninguna
responsabilidad por el deterioro o da5o que puedan sufrir los datos grabados.)
24 mm
@
.m
6"
o o*
'm
o 'm
o
kvA1:1t,;-'1I_3 El-"IJT-'\vAI [e,]'_'_ ",',"
Las conexiones HDMI para algunos equipos Panasonic le permiten hacer interfaz automaticamente. (pag. 23)
@ Esta funcion puede no funcionar normalmente dependiendo de la condicion del equipo. @ Con esta funcion activada, aunque el televisor este en el mode de espera, el equipo podra ser controlado por otros mandos a distancia. @ Cuando empieza la reproduccion puede que no se disponga de imagen ni sonido durante los primeros segundos. @ Cuando se cambia el modo de entrada puede que no se disponga de imagen ni sonido durante los primeros segundos. @ Cuando se ajuste el volOmen del equipo se visualizara la funcion del volt3men.
@ Si conecta el equipo que tiene la funcion "HDAVl Control 2 o posterior" al televisor con un cable HDMI, el sonido procedente
del terminal DIGITALAUDIO OUT podra salir como sonido ambiental multicanal. @ "HDAVl Control 5" es la norma mas reciente (valida a partir de Diciembre de 2010) para el equipo compatible con HDAVl
Control. Esta norma es compatible con el equipo HDAVl convencional.
37
I
tc_L3232c_si)a_0608.indb 37 2010/12/21 15:41:0{
I
HDMI(interfazmultimediadealtadefinici6n)lepermitedisfrutardeimagenesdigitalesdealtadefinici6nydesonidodealta calidadconectandoeltelevisorylosdispositivosHD. ElequipocompatibleconHDMI('1)quetengaunterminaldesalidaHDMIoDVl,como,porejemplo,unreceptordigitalmultimedia ounreproductorDVD,podr&serconectadoalterminalHDMIutilizandouncablequecumplaconHDMI(funci6ncompleta).
@HDMIeslaprimerainterfazAVcompletamentedigitaldelmundoparaelconsumidorquecumpleconunestandardeno
compresi6n. @Sieldispositivoexternos61otieneunasalidaDVl,conectealterminalHDMImedianteuncableadaptadorDVlaHDMI(*2). @CuandoseutilizaelcableadaptadorDVlaHDMI,conecteelcabledeaudioalterminaldeentradadeaudio. @Losajustesdeaudiosepuedenhacerenlapantalladelmenu"EntradaHDMI1"o"EntradaHDMI2".(p&g.32)
Frecuenciasdemuestreodelaseffaldeaudioaplicable(LPCM):48kHz,44,1kH@32kHz
('1):ElIogotipoHDMIsevisualizaenunequipocompatibleconHDMI.
(*2):Pregunteenelestablecimientodelvendedordeequiposdigitaleslocal.
( Precauci6n ) @ No se asume el funcionamiento con un PC.
@ Todas las seffales se reformatean antes de visualizarse en la pantalla. @ Si el equipo conectado tiene una funci6n de ajuste de relaci6n de aspecto, ajuste la relaci6n de aspecto a "16:9".
@ Estos conectores HDMI son de "tipo A". @ Estos conectores HDMI son compatibles con la protecci6n de los derechos de autor de HDCP (protecci6n de contenido digital
de elevado ancho de banda). @ Un dispositivo que no tenga terminal de salida digital podra conectarse al terminal de entrada de "COMPONENT" o "VIDEO"
para recibir seffales analsgicas. @ El terminal de entrada HDMI s61o puede utilizarse con las seffales de imagen siguientes: 480i, 480p, 720p, 1080i, 1080p.
Procure que concuerde con el ajuste de salida del dispositivo digital. @ Para conocer detalles de las seffales HDMI aplicables, vea la pag. 39.
/L'_'i'I'111?1_1F'._L'_IJ][_ inf:1| p':AuJJ][o][o]uad
Puede disfrutar de su equipo de cine para casa conectando un decodificador Dolby Digital (5.1 canales) y un amplificador "Multi Canal" a los terminales DIGITALAUDIO OUT.
C Precaucidn ) @ Dependiendo de su reproductor DVD y del software DVD-Audio, la funci6n de protecci6n del copyright tal vez se active y
apague la salida 6ptica. @ Cuando se seleccione un canal ATSC, la salida procedente de la toma DIGITALAUDIO OUT ser& Dolby Digital. Cuando se
seleccione un canal NTSC, la salida ser& PCM.
[{ala!]
@ Para ver los CC de las emisiones digitales, establezca la relaci6n de aspecto en COMR (siesta viendo con
H-LLENO, JUSTO, ACERC o 4:3 faltaran caracteres) @ Es posible mostrar CC en el TV s61o cuando el receptor (como por ejemplo la caja de cable o el receptor de
satelite) tiene CC activado dentro del dispositivo mismo. Consulte a su proveedor de Cable o Satelite respecto a
instrucciones. El bot6n CC del TV no opera la funci6n CC del receptor de satelite o de la caja de cable. @ Si los CC esta encendidos en el receptor y el televisor cuando la seffal es 480i (excepto para la conexi6n HDMI), los
CC puede que se superpongan en el televisor. @ Si un programa digital esta saliendo en el formato anal6gico, los CC tambien saldran en el formato anal6gico. @ Si la grabadora o el monitor de salida estan conectados al televisor, los CC necesitaran configurarse en la grabadora
o en el monitor de salida.
38
tcL3232csi)aO608,indb 38 2010/12/21 15:41:0_
I
* Marca: SeSal de entrada aplicable para componente (Y, PB, PR) HDMI y PC
525 (480) / 60i 15,73 525 (480)/60p 31,47 750 (720)/60p 45,00
1.125 (1.080)/60i ' 33,75
1.125 (1.080)/60p 67,43
1.125 (1.080)/60p ' 67,50
1.125(1.080)/24p
1.125(1.080)124p 640 x 400 @70 640 x 480 @,,60 Macintosh 13" (640 x 480) 640 x 480 @75 852 x 480 @60
800 x 600 @,,60 800 x 600 @75 800 x 600 @85 Macintosh 16" (832 x 624)
1.024 x 768 @60 ' 48,36
1.024 x 768 @70 56,48
1.024 x 768 @75 60,02 ' 75,03 ' ' ' *
1.024 x 768 @85 68,68 85,00 *
Macintosh 21" (1,152 x 870 68,68 75,06 ' ' ' *
1.280 × 768 @60 47,78 59,87 *
1.280 x 1.024 @..60 ' 63,98 60,02 ' ' *
1.366 x 768 @60 48,39 60,04 *
@ Las seSales que no sean las mostradas arriba pueden no visualizarse correctamente. @ Las seSales de arriba son reformateadas para poder verlas de forma optima en su pantalla. @ Las se5ales de ordenador que pueden entrar son las que tienen una frecuencia de exploracion horizontal de 15 a 110 kHz y
una frecuencia de exploracion vertical de 48 a 120 Hz. (Sin embargo, las seSales que exceden 1.200 lineas no se visualizaran correctamente.)
26,97 27,00 31,47
31,47 35,00 37,50 31,44
37,88 46,88
53,67 49,73
59,94 * 59,94 * ' * ' 59,94 * * 59,94 * ' * ' 59,94 *
60,00 ' ' * ' 23,98 * 24,00 ' ' * ' 70,08 *
59,94 ' ' * 66,67 * 75,00 ' ' ' * 59,89 *
60,32 ' ' * 75,00 *
85,08 ' ' ' * 74,55 * 60,00 ' ' ' * 70,07 *
@ Nombres de las seSales del conector D-sub 15 patillas
Nombre de la seSal Nombre de la seifial Nombre de la seifial
_.) R _j GaD (tierra) @ ac (no conectado) @ G _7_ GND (tierra) @ NC _3_ B _ GND (tierra) @ HD/SYNC @ NC (no conectado) _ NC (no conectado) _4_ VD
Forma de Ias patillas para ei terminal de entrada PC
(5_ GND (tierra) GND (tierra) NC
I
39
@
6"
('3 O,
"-I
('3 "-I
O
tc_L3232c_si)a_0608.indb 39 2010/12/21 15:41:0!
I
Cuidados y limpieza
Desenchufe primero la clavija del cable de alimentacion de CA del toma de corriente.
El frente del panel de la pantalla ha recibido un tratamiento especial. Limpie suavemente la superficie del panel utilizando un paso suave.
@ Si la superficie est& muy sucia, empape un paso blando y sin pelusa en una soluci6n de agua y jab6n liquido suave de los
empleados para lavar vajillas (1 parte de jab6n por cada 100 partes de agua) y luego esctirralo para quitar el exceso de agua,
frote uniformemente con un paso seco del mismo tipo hasta que la superficie quede completamente seca. @ No raye 6 golpee la superficie del panel con sus uSas u otros objetos duros ya que la superficie puede daSarse. Adem&s, evite
el contacto con sustancias volatiles tales como rociadores de insecticida, disolventes y diluyentes de pintura, de Io contrario
puede verse afectada la calidad de la superficie.
Si el mueble se ensucia, limpie con un paso suave y seco.
@ Si la caja esta muy sucia, empape el paso en una soluci6n de agua y jab6n liquido suave de los empleados para lavar vajillas
y luego esctirralo para quitar el agua. Utilice el paso para limpiar el mueble y seque frotando con un paso seco. @ No permita que el jab6n liquido suave de los empleados para lavar vajillas toque directamente la superficie del televisor.
Si las gotas de agua entran en el interior del aparato, pueden surgir problemas en el funcionamiento. @ Evite el contacto con sustancias vol&tiles tales como rociadores de insecticida, disolventes y diluyentes de pintura debido a
que puede verse afectada la superficie del mueble y puede desprenderse el revestimiento. @ No permita que elementos de caucho o PVC esten en contacto con el TV durante largos periodos.
@ Limpieza
Limpie las superficies pasando un paso blando y seco. Si la unidad est& muy sucia, limpiela con un paso empapado en agua
a la que se haya aSadido una pequeSa cantidad de jab6n liquido suave de los empleados para lavar vajillas y luego pase un
paso seco.
No utilice productos tales como disolventes, diluyente 6 cera del hogar para la limpieza ya que pueden daSar el revestimiento
de la superficie. (Si utiliza un paso con tratamiento quimico, siga las instrucciones que vienen con el paso.) @ No pegue cinta adhesiva 6 etiquetas ya que pueden ensuciar la superficie del pedestal. No permita el contacto durante mucho
tiempo con productos de goma, vinilo 6 similares. (Hacerlo puede causar deterioros.)
Limpie la clavija con un paso seco a intervalos frecuentes. (La humedad y el polvo pueden causar un incendio o una descarga electrica.)
40
tcL3232csi)aO608,indl) 40 2010/12/21 15:41:0!
I
Especificaciones
Aliment_@n
Consumo nominal de energia 106 W
Condici6n de espera
Relaci6n de aspecto
_; Tama_o de pantalla
visible
_ (An. x AI. x Diagonal)
(N_mero de pixeles) Altavoces
Salida de audio
_ici_ _ Temperatura: funciOilami_nto Humedad:
1 I!v,oEo,.,.2
iii ii i l!
HDMI 1-2
_:_ PC
Ranura de tarjeta
.........................................DIGITAL AUDIO OUT
Incluyendo pedestal 779 mm x 531 mm x 207 mm
Televisor solamente 779 mm x 497 mm x 85 mm
Incluyendo pedestal 22,0 lb. (10,0 kg) NETO Televisor solamente 20,0 lb. (9,0 kg) NETO
i i ii
110-127 V C@ 60 Hz
0,3W 16:9 Clase 32"
(31,5 pulgadas medidas diagonalmente) 698 mm x 392 mm x 800 mm
27,5 " x 15,4 " x 31,5 ")
.049.088 (1.366 (An.) x 768 (AI.)) [4.098 x 768 puntos]
2 altavoces de 1 via
20 W [10 W + 10 W] (10 % de distorsi6n arm6nica total) VGA, SVGA, XGA, WXGA, SXGA
Frecuencia de escaneo horizontal 31 - 69 kHz Frecuencia de escaneo vertical 59 - 86 Hz
VHF/UHF: 2-69, CATV: 1-135
VIDEO: Tipo RCA PIN x 1 1,0 V [p-p] (75 fl) AUDIO L-R: Tipo RCA PIN x 2 0,5 V [rms]
P8, PR: +0,35 V [p-p] AUDIO L-R: Tipo RCA PIN x_ 0,5 V [rms_ Conector tipo A x 2
¢ Este televisor soporta la funcion "HDAVl Control 5". D-SUB 15PIN: R,G,B / 0,7 V [p-p] (75 C2)
ranura de tarjeta SD PCM / Dolby Digital, Fibra optica FILTRO Y/C 3@ Subtitulos,
V-Chip, HDAVl Control 5, Compatible con Vesa, VlERA IMAGE VIEWER
30,7 " x 21,0 " x 8,2 ")
30,7 " x 19,6 " x 3,4 ")
32 °F- 95 °F (0 °C- 35 °C) 20 % - 80 % RH (sin condensaci6n)
_] (-_'ncl-_'yend o sincr_
HD, VD / 1,0 - 5,0 V [p-p] (alta impedania)
@
O _-@
O-ITI o.. "_
oo G0 o
--o
_m
_ NO
o
[TC-L3232C] 85 mm
779mm(30,7 ") (3,4 ")
i 03,8,) i 207 mm (8,2 ")
@ El diseSo y las especificaciones est&n sujetos a cambios sin previo aviso. La masa y dimensiones son aproximadas.
41
I
tc_L3232c_si)a 0608.indb 41 2010/12/21 15:41:0!
I
Preguntas frecuentes
Si hubiera algen problema con su TV, refierase a la tabla abajo para determinar los sintomas y luego realice la verificaci6n sugerida. Si aQn no resolviese el problema visite el sitio Web de Panasonic para asistencia adicional. (ver portada)
Presione el bot6n INPUT en el control remoto y seleccione la fuente de entrada correcta.
® Verifique que el dispositivo este encendido y que funcione
correctamente.
_®°Verifique que ei cable de alimentaci6neste enchufado y elTV
encendido(la iuz LEDrojafrontal debe estar encendida,no titiiando
® Presione el bot6n INPUT en el control remoto y seleccione
&Por que no se ve la imagen o solo se muestra una pantalla
azul, negra o nevada?
&Por que no se ve la pelicula en Alta Definicion?
&Por que aparecen barras negras en la parte superior e
inferior y/o a los lados de la pantalla?
&Por que se ve la imagen nevosa cuando se selecciona "Entrada ANT/Cable"?
&Por que se ve la imagen caotica y/o rasgada y/o con un
zumbido en los parlantes?
la fuente de entrada correcta.
® Verifique que todas las conexiones sean correctas y seguras. ® AI utilizar una fuente externa de video tal como una conexi6n de
caja de cable/satelite o un reproductor de DVD verifique que el dispositivo este encendido y este funcionando correctamente.
® PresioneMENUen el controlremotodeltelevisor.Si se despliegaei
_' Presione el bot6n INFO en el control remoto para confirmar
que tipo de serial se esta recibiendo (pag. 15). La serial HD debe ser 720P, 1080i 6 1080p.
® Seleccione un canal de Alta Definici6n de su fuente HD (servicio
de cable, satelite o fibra 6ptica). Los canales HD en ocasiones
transmiten contenidos que no son de alta definici6n.
® Asegt_rese que su fuente HD (caja HD, reproductor Blu-ray, etc.)
este conectado al televisor con un cable HDMI o componente y configurado para transmitir una serial de video HD.
Cambie el formato (relaci6n de aspecto) de la imagen presionando el bot6n FORMAT en el control remoto. (pag.
formatoextra-ancho.Lasbarras superiorese inferioresson inevitabies.
Cuando utilice el servicio de cable (sin caja) verifique que
_ todas las conexiones sean correctas.
_1® AI utilizar una caja de cable o satelite cambie la conexi6n _ (cableado) a Compuesto, Componente o HDMI. (pag. 10) pl® Siesta utilizando una antena verifique que las conexiones
--_ sean correctas. Cambie la posici6n o direcci6n de la _,_ antena y verifique el "Medidor de serial". (p g. 29)
Verifique si existen productos electricos como
electrodomesticos, luces fiuorescentes o reguladores de
deDVDounaconsoladejuegosparaacotarlafuentedel problema.
&Por que hay un cuadro negro en la pantalla?
&Por que la pantalla esta en blanco y el indicador de encendido titila?
&Por que algunos puntos en la pantalla quedan brillosos u oscuros?
® Cambie los ajustes de los subtitulos (CC). (pag. 15, 38)
ElTVpas6amododeapagadoparaprotegerse.Intentedesenchufarlodurante unosminutosy conectarlonuevamente.Sihubounaoscilaci6ntemporariade
flameal 1-877-95VIERA(EE.UU.)o 1-866-330-0014(Canada).
S_ El panel de LCD esta formado pot unos pocos millones"_ ...... _
_ pixeles, y se fabrica con una tecnologia avanzada que emplea
_ un complicado proceso. No obstante, algunas veces puede p_ aber unos pocos pixeles brillantes u oscuros. Estos pixeles
no indican que un panel este defectuoso, y no causaran
42
t(-L3232(-si)aO608,indb 4,2 2010/12/21 15:41:0!
I
&Por que no emite sonido el
TV?
&Por que el sonido es raro, distorsionado, el volumen es
bajo o en otto idioma?
&Por que se escucha un chasquido, un tic-tac o un
zumbido proveniente de la
unidad de TV?
f_ AsegOrese que el volumen este alto y que MUTEeste enA_ '_
® Confirme que los parlantes delTV esten en Encendido presionando
el MENUy seleccionandoAudio --> Audio avanzado. (pag. 32)
® Verifique la selecci6n del SAP (Programa de audio secundario)
correcto presionando el bot6n SAP en el control remoto. (pag. 15)
® Si eiTV esta conectado a un teatro en casa de Panasonicpor medio
de un cable HDMI,verifique los controles VlERA Link.(pag. 22)
® Si el TV esta conectado al teatro en casa a traves de un cable
6ptico, entonces: Verifique la conexi6n, que el sistema de audio este encendido y la selecci6n de la entrada correcta.
® Verifique las entradas "Entrada HDMI 1"o "Entrada HDMI2" en los
Verifique si la selecci6n del SAP (Programa de audio secundario esta correcta presionando el bot6n SAP en el control remoto.
conectados al TV sean seguros.
Audio del rece a "limitado")
Cuando se enciende o se apaga el
noes una seSalde o mal funcionamiento.
$Cual es la manera mas_f_cil°y-_or _
para conectar una caja de Cable o
Satelite de Alta Definicion al TV?
_ nrque _- _i_n_ _ ( )_est6ninstaladasconlapolaridadcorrecta +&--. _
_P,., n-,-n..,....,., el C _1® Paraoperar otros dispositivostalescomo el cambiodecanal al utilizar
Utilice un cable HDMI. Este transporta tanto la serial video digital como la de audio en HD. El cable HDMI es el Onico cable necesario para conectar un dispositivo HD al TV.
AI ver televisi6n a traves de un dispositivo conectado por
HDMI, como por ejemplo la caja de cable o satelite, el CC
(subtitulo) debe estar habilitado en el dispositivo.
programaci6n de lue Io
La unidad principal radia calory algunas piezas se calientan. Esta es la operaci6n normal y no afecta el
desempefio del dispositivo.
® Garantice una buena ventilaci6n. ® No bloquee los orificios de ventilaci6n del TV y no coloque
_, el TV sobre otro equipo.
_ Verifique que las baterias sean nuevas, del mismo tipo y
_ cajas decableo sateliteo cuandoseopere conreproductoresBlu-ray
Duranteel "AjusteInicial",paso 3, se indic6que el conector"Entrada.....
ANT/Cable"sea "no utilizado"(pag. 13).Estees el ajustecorrectosi el TV esta conectadola caja de cableosatelite atraves de cualquierade
lasotras entradas.Parare-activarlaentrada"ANT/Cable",presione
MENUparaseIeccionarAjustey luego vuelvaa realizarel ajuste
inicial,seleccionandola entradade Cableo antenaen el paso3.
(.C}
@ 33
t-
('D
C_
r'-
('D ('D
43
I
tc_L3232c_si)a_O608.indb 43 2010/12/21 15:41:11
I
f
Indice
[] Accesorios ............................................................... 7
Acercamiento ............................................. 16, 31,36
Ajuste Inicial ................................................ 12-14, 34
Ajustes de la imagen ............................................. 31
Alimentaci6n ........................................................... 11
ANT/Cable ....................................................... 13, 28
Antena ............................................................... 9, 13
Apagado ................................................................ 32
Audio ...................................................................... 32
Audio avanzado ..................................................... 32
Auto encendido ...................................................... 34
[] Bloqueo ............................................................ 33, 35
Botones de color ..................................................... 11
[] Cable ................................................................. 9, 10
Canal ............................................... 13, 15-16, 28-29
CC Subtitulos ............................................. 15, 33, 38
Componente .................................................... 10, 41
Compuesto ............................................................ 10
ConexiSnes ......................................................... 9-10
CronSmetro ............................................................ 32
Cuidados y limpieza ............................................... 40
[] ECO/energia .................................................... 18, 34
Entrada .................................................................. 19
Escaneo ........................................................... 13, 28
EspecMcaciones .................................................... 41
ExhibiciSn en Mostrador ........................................ 12
EXIT (salida) ........................................................... 11
[] Favorito .................................................................. 16
Formato ........................................................... 16, 36
Foto ................................................................... 20-21
[] HDAVl Control ........................................................ 22
HDMI .......................................................... 10, 38, 41
[] Idioma .............................................................. 12, 34
Imagen avanzada .................................................. 32
INFO (Informaci6n) ................................................ 15
Informaci6n tecnica ........................................... 36-39
[] LAST (01timo) ......................................................... 11
LED titilante ........................................................... 42
[] Medidor de serial ................................................... 29
MenQ ...................................................................... 30
Mirar TV, DVD, Blu-ray, etc .............................. 15, 19
Modo de navegaci6n ....................................... 16, 34
MUTE (Silenciamiento del sonido) ......................... 11
[] Pedestal ............................................................... 7, 8
Pila ........................................................................... 8
Preguntas frecuentes ........................................ 42-43
Programa auto ....................................................... 28
[] Reconfiguraci6n ..................................................... 34
Reloj ....................................................................... 14
Reproducir Automatica de imagenes ..................... 34
[] SAP ........................................................................ 15
Seguridad ................................................................ 4
SubmenQ ............................................................... 16
[] Tarjeta SD ........................................................ 20, 37
Transmisor de mando a distancia ........................... 11
44
[] Uso en Hogar ......................................................... 12
[] VIERA IMAGE VIEWER ........................................ 20
VIERA Link .................................................. 18, 22-27
VIERA TOOLS ....................................................... 18
Vista de fotos ......................................................... 20
Volumen .................................................................. 11
tcL3232csi)aO608,indb 44 2010/12/21 15:41:1I
I
Nota
@
Q_
CD
45
I
tc_L3232c_spa_O608,indb 45 2010/12/21 15:41:1I
I
This product has a fluorescent lamp that contains mercury.
Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your
local authorities, or the Electronic Industries Alliance: http://www.eiae.org.
Este producto tiene una lampara fluorescente que contiene mercurio. Debido a consideraciones ambientales, puede que deshacerse de este material est6 regulado en su comunidad. Para obtener informaci6n sobre c6mo deshacerse o reciclar este material, p6ngase en contacto con las
autoridades de su Iocalidad o con Electronics Industries Alliance: http://www.eiae.org.
Customer's Record The model number and serial number of this product can be found on its back cover. You should note this serial number in
the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number Serial Number
Anotaci6n del cliente
El modelo y el nQmero de serie de este producto se encuentran en su panel posterior. Debera anotarlos en el espacio provisto a continuaci6n y guardar este manual, mas el recibo de su compra, como prueba permanente de su adquisici6n, para que le sirva de ayuda al identificarlo en el caso de que le sea sustraido o Io pierda, y tambien para disponer de los servicios que le ofrece la garantia.
Modelo NQmero de serie
Panasonic Consumer Electronics Company, Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus
New Jersey 07094 U.S.A.
© 2011 Panasonic Corporation of North America. All Rights Reserved. ¢_ 2011 Panasonic Corporation of North America. Todos los Derechos Reservados.
tc_L3232c_en_O608Jndb H4 2010/12/24 13:40:0;
Panasonic Canada Inc. 5770 Ambler Drive
Mississauga, Ontario L4W 2T3 CANADA
Printed in Malaysia
Impreso en Malasia
M1210-0
I
Panasonic
Modele
TC-L3232C
Fran_ais Nous vous remercions d'avoir arr6te votre choix sur cet appareil Panasonic.
tc_L3232c_fl'a_O608.indb 1 2010/12/24 13:42:1'
Avant d'utiliser I'appareil, lire attentivement le present manuei et Ie conserver pour ref6rence ulterieure. Les images montrees dans le present manuei n'y sont qu'a des fins d'illustration.
IIIIIIIIIIIIIIHIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
TQB4GC0608
I
Le multim ia a son meilleur!
Cet appareil int&gre les Iogiciels suivants : (1) Iogiciels developp6s independamment par ou pour le compte de Panasonic Corporation,
(2) Iogiciels appartenant & une tierce pattie et utilises sous licence par Panasonic Corporation, (3) Iogiciels utilises sous licence en vertu de la Licence publique g6nerale GNU, version 2 (GPL v2), (4) Iogiciels utilises sous licence en vertu de la Licence publique g6nerale limitee GNU (LGPL), et/ou, (5) Iogiciels libres autres que ceux utilises sous licence en vertu de GPL et/ou LGPL
Pour les Iogiciels des categories (3) ou (4), veuillez vous reporter aux conditions d'utilisation de GPL v2 et LGPL & http:/Iwww.gnu.org/licenseslold-licenses/gpl-2.0.html et http:/Iwww.gnu.org/licenseslold-licenses/Igpl-2.1 .html. De plus, plusieurs personnes physiques et/ou morales detiennent des droits d'auteur sur les Iogiciels des categories (3) et (4). Veuillez vous reporter aux avis de droits d'auteur de ces personnes physiques et morales a http:/Iwww.am-linux.jpldllDTV11 UT/.
LES LOGIClELS GPL/LGPL SONT DISTRIBUES DANS LE BUT D'ETRE UTILES MAIS NE SONT COUVERTS PAR AUCUNE GARANTIE, EXPLICITE, IMPLICITE OU L#GALE, Y COMPRIS LES GARANTIES IMPLICITES
DE VALEUR MARCHANDE OU D'ADEQUATION ,ik UNE UTILISATION PARTICULI#RE. Pendant une periode d'au moins trois (3) ans apres la livraison des produits, Panasonic fournira a quiconque
communiquera avec nous a I'adresse suivante et ce, sans autres frais que ceux encourus pour la distribution du code source, une copie complete lisible par machine du code source en vertu de GPL v2/LGPL.
Ecrivez & : cd request@am-lin ux.jp Le code source est egalement disponible, sans frais, depuis notre site Web & I'adresse suivante :
http://www.am-lin ux.jp/dl/DTV11 UT/
2
tc_L3232c_fl'a_0608.indb 2 2010/12/24 13:42:H
I
Vlf(/_ Li k_'V,ER_Lin_'°estunemarquede
H---IITII
_'jl_ '_ Le logo SDHC est une marque de
Fabrique sous licence de Dolby Laboratories. DOLBY et le symbole double D sont des marques de commerce de
Dolby Laboratories. HDAVl Control TM est une marque de commerce de
Panasonic Corporation.
rl commerce de Panasonic Corporation.
HDMI, le logo HDMI et High- Definition Multimedia Interface sont
des marques de commerce ou des marques depos6es de HDMI Licensing LLC aux Etats-Unis et dans
d'autres pays.
commerce de SD-3C, LLC.
Ce produit est conforme aux normes
ENERGY STAR dans le mode
(< Usage a domicile >)lequel permet des economies d'energie. Toute modification du parametrage du
mode <<Usage & domicile >)ou des autres parametrages par defaut pourrait entraTner une consommation d'energie depassant les normes
ENERGY STAR.
Taledes
A lire attentivement
÷ Mesures de securite ....................................... 4
Mise en route
Accessoires/Accessoire en option ................. 7
Connexions .................................................. 9
Emplacement des commandes .................. 11
Reglage initial .............................................. t2
Fonctions de base
÷ Visionnement de la television ....................... 15
÷ Utilisation des fonctions VIERATOOLS ....... 18
÷ Visionnement de contenu a partir de
÷ Visionnement avec visualiseur de photos
&
res
p@iph@iques ............................................... 19
VIERA IMAGE VIEWER TM ........................... 20
Fonctions avancees
÷ VIERA LinkTM "HDAVI Control TM''................... 22
÷ Programmation et edition des canaux ......... 28
÷ Utilisation des fonctions des menus ............. 30
o Reglages de I'image ................................... 31
Reglages audio ........................................... 32
o Reglage de la minuterie .............................. 32
Blocage ....................................................... 33
Sous-titres ................................................... 33
Reglage ...................................................... 34
Renseignementssupplementaires
÷ Liste des classifications pour contr61e
parental ........................................................ 35
÷ Informations techniques ............................... 36
÷ Entretien et nettoyage .................................. 40
÷ Specifications ............................................... 41
÷ Foire aux questions (FAQ) ........................... 42
÷ Index ............................................................ 44
÷ Garantie limitee ............................................ 45
IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIMIIIIIII3
tc_L3232c_fl'a_0608.indb 3 2010/12/24 13:42:1_
I
Mesures de sdcurit
I
ATTENTION
AVERTISSEMENT: Pour r_duire les risques de choc _lectrique, ne pas retirer le couvercle ni le panneau arri_re. Cet appareil ne contient aucune piece qui puisse
&tre r_par_e par I'utilisateur; I'entretien dolt &tre effectu_ par du personnel qualifi&
_1_ esymbolede1'6clair,nscrftdansunt_angleequila#al,
,_ Lesymboledupointd'exclamation,inscritdaneun
apou[obietdappelefIattentiondeI'utilisate_rsurla pr6sence,&I'interie_rduproduit_depiecesnonisoCes
_0r_eesaune"tensiondangereusequipeutav0irune amplitudesuf_santepourpr0vequerunch0eelectnque
triangleequiateral,apourobjetd'appelerl_attention deI_tilisateursurlapresence,dansladocumentation
accompagnantleFoduit,d'importantesinstructions conceroantsonmodeop6ratoireetsonentretien,
[.t'STTt_PXI_F;I.].riI_I_'PX!I"itSlI"I_,'_ , " _, ., , + ..
II est recommande de consulter le Code canadien de I'electricit6 en ce qui a trait a la mise a la terre du fil de c&blodistribution. Ce code specifie que le fil dolt 6tre relie au systeme de mise & la terre de I'edifice, le plus pres possible du point d'entree.
kV_'._'Tfll_ _-.iYr_
Les fentes et les ouvertures situees a I'arriere ou en dessous du tel6viseur sont prevues pour assurer sa ventilation, et garantir ainsi son bon fonctionnement en evitant toute surchauffe. Ces ouvertures ne doivent pas 6tre recouvertes ou obstruees. Laissez un espace libre d'au moins 10 cm tout autour du tel6viseur. Ainsi, ne posez jamais I'appareil sur un lit, un canape, un tapis ou
toute autre surface qui risquerait de g6ner la ventilation. Ce t61eviseur ACL ne dolt pas 6tre encastre dans un meuble, & moins de
prevoir une ventilation adequate.
1) Lisez ces instructions.
2) Conservez ces instructions en lieu sOr.
3) Respectez toutes les consignes de securit&
4) Suivez toutes les instructions fournies.
5) N'utilisez pas ce televiseur & proximite d'une source d'eau.
6) Ne nettoyez cet appareil qu'avec un chiffon sec.
7) N'obstruez pas les events de ventilation de I'appareil. Installez-le en respectant les instructions du fabricant.
8) N'installez pas le televiseur ACL pres d'une source de chaleur, par exemple un radiateur, un rechaud ou tout autre appareil (y compris des amplificateurs) produisant de la chaleur.
9) N'invalidez pas les caracteristiques de securite de la fiche polarisee ou avec mise & la terre. Une fiche polarisee possede deux lames dont une est plus large que I'autre. Une fiche avec mise a la terre possede deux lames plus une troisieme lame
pour la mise & la terre. La lame large ou la lame de mise a la terre sont congues pour des raisons de securit& Si la fiche
fournie ne peut pas 6tre branchee dans votre prise secteur, consultez un electricien pour faire remplacer la prise.
10) Faites en sorte que personne ne puisse marcher sur le cordon d'alimentation ou le plier, tout particulierement & ses deux extremites.
11) Utilisez uniquement les accessoires prevus par le fabricant.
12) N'utilisez I'appareil qu'avec un chariot, meuble, trepied, support ou table recommande par le fabricant ou vendu avec I'appareil. Lors de I'utilisation d'un chariot, deplacez-le avec le plus grand soin afin d'eviter tout dommage.
13) Debranchez I'appareil pendant les orages ou Iorsque vous ne comptez pas vous en servir pendant une periode protongee.
14) Pour toute intervention, adressez-vous a un technicien qualifi& Une intervention est necessaire Iorsque I'appareil a ete endommage, par exemple en cas de rupture du cordon secteur ou de sa fiche, Iorsque du liquide s'est
repandu sur le televiseur ou qu'un objet est tombe & I'interieur, Iorsque I'appareil a ete expose a la pluie ou & I'humidite, quand il ne fonctionne pas normalement ou quand il est tomb&
15) N'alimentez I'appareil que par une source electrique conforme aux indications apposees sur I'etiquette de I'appareil. Si vous avez des doutes
sur les caract@istiques de votre courant domestique, consultez votre detaillant de television ou votre fournisseur d'electricit&
16) Respectez toutes les instructions et consignes de securite figurant sur le televiseur ACE
17) N'introduisez aucun objet par les ouvertures du televiseur ACL; il pourrait entrer en contact avec des composants sous tension
elevee ou provoquer un court-circuit susceptible d'engendrer un incendie ou un choc electrique. Ne repandez jamais de liquide sur
le televiseur ACE
18) Si une antenne exterieure est reliee & ce televiseur, assurez-vous que celle-ci a ete mise a la terre afin de proteger I'appareil contre
les surtensions et I'accumulation d'electricite statique. La partie 1 du Code canadien de I'electricite contient des informations
concernant la mise & la terre des m&ts d'antenne et de leurs structures, celle du fil de descente, le calibre du fil de descente requis et les exigences concernant la tige de la mise & la terre.
Exemple de mise &
la terre de I'antenne recommande par le Code
canadien de I'electricite
Systeme de mise & la terre du
reseau electrique
(Code canadien de I'electricite)
Parafoudre (partie 1 du Code
canadien de I'electricit6) Fils de terre (partie 1 du Code canadien de I'electricit@
_. Sangles de mise a la terre
4
de descente
tcL3232cffaO608.in(lb 4, 2010/12/24 13:42:2_
I
19)Unsystemed'antenneexterieurnedoltjamaissesituer&proximitedeligneselectriques aeriennes ou de tout autre circuit
d'eclairage ou circuit electrique, ni & un endroit o0 il risque d'en 6tre trop pres. Lors de I'installation d'un systeme d'antenne exterieur, prenez bien soin de ne pas toucher ces lignes ou ces circuits electriques, car le moindre contact peut 6tre fatal.
20) Debranchez le tel6viseur ACL de la prise murale et demandez les services d'un technicien qualifie dans les cas suivants: a. Quand le cordon d'alimentation ou sa fiche sont endommages ou uses. b. Si du liquide s'est renverse sur le tel6viseur ACL. c. Si le tel6viseur ACL a et6 en contact avec la pluie ou I'eau. d. Si le t61eviseur ACL ne fonctionne pas normalement alors que vous respectez son manuel d'utilisation.
e. Si le tel6viseur ACL est tombe ou si son coffret a et6 endommage.
f. Lorsque le t61eviseur ACL subit un changement notable au niveau des performances (cela indique qu'il faut le reparer).
21 ) Lorsqu'iI faut remplacer des pieces, assurez-vous que Ie technicien utilise les pieces preconis6es par Ie fabricant, avec Ies m6mes caract@istiques
que celles d'origine. Un re.replacement non conforme risque de causer un incendie, un choc etectrique ou tout autre dommage.
22) AVERTISSEMENT:POUR REDUlRE LES RISQUES D'INCENDIE ET DE CHOC ELECTRIQUE, N'EXPOSEZ PAS CET
23) AVERTISSEMENT:LES PETITES PIECES PEUVENT PRESENTER DES DANGERS D'ETOUFFEMENT SI ELLES SONT
24) AVERTISSEMENT:Pour pr_venir un incendie, gardez les bougies ou toute autre source de flamme nue loin de
25) ATTENTION: L'interrupteur de cet appareil ne coupera pas entierement I'alimentation de la prise secteur. Le
26) ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, N'UTILISEZ PAS CETTE FICHE POLARISEE DANS UNE
27) ATTENTION: UNE UTILISATION AVEC UN AUTRE SUPPORT QUE CELUI FOURNI OU RECOMMANDE PEUT RENDRE
28) ATTENTION: IL EXISTE UN RISQUE D'EXPLOSION EN CAS D'UTILISATION DE PILES NON CONFORMES. NE
29) MISEENGARDE:Ce t_l_viseur _ _cran & cristaux liquides ne doit _tre utilis_ qu'avec les accessoires en option suivants. L'utilisation
Reglez uniquement les parametres decrits dans le manuel d'utilisation, car des reglages incorrects d'autres parametres risquent de provoquer des dommages et de demander davantage de travail & un technicien qualifie pour une remise en etat du tel6viseur ACL.
APPAREIL A L'HUMIDITI_, ,&.LA PLUlE ET AUX I_CLABOUSSURES. NE PLACEZ AUCUN RI_ClPIENT CONTENANT DE L'EAU (VASE DE FLEUR, TASSE, BOUTEILLE DE PRODUIT DE BEAUTI_, ETC.) SUR
L'APPAREIL (OU.SUR UNE ETAGI_RE LE DOMINANT).
AVALEES PAR ACCIDENT. GARDEZ LES PETITES pII_CES HORS DE LA PORTEE DES ENFANTS. JETEZ LES PETITES pII_CES INUTILES, AINSI QUE LES AUTRES OBJETS INUTILES, Y COMPRIS
LES MATF:RIAUX D'EMBALLAGE ET LES SACS/FEUlLLES EN PLASTIQUE, AFIN D'EVITER QUE DES ENFANTS JOUENT AVEC, CRC:ANT UN RISQUE POTENTIEL DE SUFFOCATION.
I'appareil en tout temps.
cordon d'alimention etant le dispositif principal de deconnexion de I'appareil, il sera necessaire de le debrancher de la prise secteur afin de couper toute I'alimentation. II convient donc de s'assurer
d'installer I'appareil de maniere a ce que le cordon d'alimentation puisse 6tre facilement debranch6 de la prise secteur en cas d'accident. Pour eviter tout risque d'incendie, debranchez egalement le cordon d'alimentation de la prise secteur dans le cas d'une inutilisation prolongee (par exemple, Iorsque en vacances.)
PRISE O0 ELLE NE PEUT ETRE INSEREE COMPLETEMENT.
L'ENSEMBLE INSTABLE ET ETRE CAUSE DE BLESSURES CORPORELLES.
REMPLACEZ LES PILES QUE PAR DES PILES IDENTIQUES OU DE TYPE EQUIVALENT.
d'accessoires autres que ceux-ci peut entrainer une instabilit_ susceptible de causer des blessures. (Les accessoires indiques ci-dessous sont fabriques par Panasonic Corporation)
Support de montage mural: TY-WK3L2RW. Confiez I'installation a un technicien qualifie.
5
tc_L3232c_ffn_O608,indb 5 2010/12/24 13:42:2_
I
I
Cet equipement a 6te teste et declar6 conforme aux limitations d'un appareil numerique de Classe B, d'apres la section 15 des normes FCC. Ces limitations sont congues pour offrir un niveau de protection raisonnable contre les interferences nuisibles dans
une zone residentielle. Cet equipement produit, utilise et peut emettre une energie de frequence radio et, s'il n'est pas installe ni utilise conformement aux instructions, il risque de causer des interferences nuisibles pour les communications radio. II n'y a toutefois aucune garantie que des interferences ne se produisent pas dans une installation en particulier. Si cet equipement cause des interferences g6nantes pour la reception radio ou t61evision, ce qui peut 6tre aisement determin6 en I'eteignant puis en
le rallumant, I'utilisateur est invite & prendre les mesures correctives suivantes :
Reorientez ou deplacez I'antenne de reception.
Augmentez la distance entre I'equipement et le recepteur.
Branchez I'equipement dans une prise situee sur un autre circuit que celui auquel est relie le recepteur.
Si vous avez besoin d'aide, consultez le detaillant ou un technicien radio-tel6vision exp6rimente.
Cet appareil est conforme a la section 15 des normes FCC. Son fonctionnement est sujet aux deux conditions suivantes : (I) Cet appareil ne peut 6tre cause d'interf@ence nuisibte et (2) il dolt pouvoir accepter toute interf@ence re£ue, incluant toute interf@ence pouvant perturber son fonctionnement.
Precautions FOG: Pour assurer une compatibilit_ continue, suivez les instructions de ce manuel et utilisez uniquement un c_ble d'interface blind_ Iors de la connexion du t_l_viseur _ un ordinateur ou autres appareils p_riph_riques. Tout changement ou modification non express_ment approuv_e
par la pattie responsable peut causer des interferences nuisibles et peut annuler I'autorit_ de I'utilisateur d'utiliser I'appareil.
D_claration de conformit_ FCC
N° de module : TC-L3232C
Responsable:
Contact:
Courriel:
Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094
Panasonic Consumer Electronics Company 1-877-95-VIE RA (958-4372)
consumerprod ucts@panasonic.com
Les ecrans plats ne sont pas toujours installes sur des supports de montage appropries ou selon les
recommandations du fabricant. Les ecrans plats qui sont installes sur des commodes, bibliotheques, etageres, bureaux, haut-parleurs, coffres ou chariots peuvent tomber et causer des blessures graves, voire mortelles.
L'industrie des produits electroniques de consommation (dont Panasonic est membre) s'est engagee & rendre le divertissement a la maison agreable et securitaire. Afin de prevenir les risques d'accident, suivez les conseils de securit6
suivants :
OPTEZ POUR LA SC:CURITI_ :
II n'existe pas de guide unique. Suivez les recommandations du fabricant pour I'installation et I'emploi securitaire de votre ecran plat.
Lisez attentivement le manuel de I'utilisateur et assurez-vous de bien comprendre les instructions pour une utilisation
appropriee de ce produit.
Ne permettez pas aux enfants de grimper sur le mobilier et les t61eviseurs ou de jouer avec ceux-ci.
N'installez pas d'ecran plat sur un meuble pouvant servir de marchepied tel un bureau a tiroirs.
Gardez & I'esprit que les enfants peuvent s'exciter Iorsqu'ils regardent la tel6vision, surtout sur des ecrans plats <<plus
grands que nature >>.Le televiseur devrait 6tre installe la o0 il ne peut 6tre pousse, tire ou bascule.
Prenez soin de disposer les c&bles ou les cordons d'alimentation de fagon a ce qu'ils ne puissent 6tre tires ou agrippes par des enfants.
SUPPORT MURAUX : SI VOUS DC:CIDEZ DE FIXER VOTRE TELEVISEUR ,_,UN SUPPORT MURAL, IL FAUT TOUJOURS :
Utiliser un support mural recommande par le fabricant du televiseur ou homologue par un organisme independant (tel que UL, ACNOR, ETL).
Suivre les instructions fournies par les fabricants du televiseur et du support mural.
Communiquer avec votre detaillant et se renseigner sur une installation faite par un professionnel si vous avez des
doutes sur votre capacite a installer votre televiseur a ecran plat de fagon securitaire.
S'assurer que lemur sur lequel vous installez le support est en mesure de I'accepter. Certains supports ne sont pas
faits pour 6tre installes sur des murs supportes par des poteaux d'acier ou des blocs de ciment. En cas de doute, communiquez avec un installateur professionnel.
Pour installer ou retirer le televiseur, il faut le concours de deux personnes. Les televiseurs a ecran plat peuvent 6tre tres Iourds.
Panasonic recommande qu'un technicien qualifi_ proc_de
toute installation murale.
Pour plus de d_tails, reportez-vous & la page 5.
L'American Academy of Pediatrics (Acad_mie
am_ricaine de p_diatrie) recommande fortement de ne pas laisser les enfants de moins de deux ans regarder
la t_l_vision.
6
t(L3232(ffaO608,indl) 6 2010/12/24 13:42:2I
I
Accessoires/Accessoireen option
d Verifiez que les accessoires et leselements ci-dessous sont bien inclus en cochant leur case.
Accessoires
[] Telecommande [] Piles pour la [] Piedestal
® N2QAYB000570 telecommande (2) ® TBL5ZX0084
@ Format AA
[] Manuel d'utilisation
Montage (p. 8)
[] Guide de mise en route rapide [] Securite des enfants
f
Accessoire en option
Support de montage mural
@ TY-WK3L2RW
L'angle du support de montage mural pour ce t61eviseur peut 6tre Trous our I'installation du support (Vue laterale)
regl6 a differentes inclinaisons :"zero de montage mural (position verticale)", "5 degres", "10 degres", "15 degres" et "20 degres".
( AVERTISSEMENTS
@ L'utilisateur assume toute responsabilite s'il decidait d'installer lui-m6me le tel6viseur ou s'il choisissait de ne pas utiliser
I'adaptateur de montage mural Panasonic. Tout dommage resultant d'une installation qui n'aurait pas et6 effectuee par un technicien qualifie entrafnera la resiliation de la garantie.
@ Confiez toujours I'installation du tel6viseur a un technicien qualifie. Une installation inadequate peut causer la chute de
I'appareil susceptible de I'endommager ou de causer des blessures.
@ N'installez jamais ee tel6viseur directement sous un eelairage au plafond (tel un projecteur, un reflecteur ou une lampe & halogene)
gen6rant un haut degre de chaleur: les pieces en plastique du boftier pourraient 6tre deform6es ou endommagees par la chaleur.
@ Installez le support mural avec le plus grand soin. Assurez-vous qu'il n'y a aucun fil electrique ni tuyau dans lemur avant
d'installer le support mural.
@ Lots de I'utilisation d'un support a angle, assurez-vous qu'il y a assez d'espace afin que les c_bles de raccordement ne
soient pas coinces contre lemur lots de I'inclinaison avant du tel6viseur.
@ Pour des raisons de s6curite, retirez les tel6viseurs de leur support mural Iorsqu'ils ne sont plus utilises.
Communiquez avec un detaillant Panasonic pour vous procurer le support de montage mural recommand& Pour de plus amples renseignements, reportez-
vous a la notice d'installation du support de montage mural.
Panneau arriere du televiseur
pour fixation du tel6viseur au support de
montage mural (non fournies avec le tel6viseur
@ :l>
o o
(D oo oo
o
>
o o m
o
o
o
7
tc_L3232c_fl'a_O608.indb 7 2010/12/24 13:42:2I
I
I
==Montage du piedestal
_A_'.® Fixez de mani_re securitaire avec les vis de montage Y'_
(4 vis au total)
® Serrez les visa fond.
Su
Avant
Base
Installation
@ Fixez de mani_re securitaire avec les vis de montage _. (4 vis au total) @ Serrez les visa fond.
Tapis de mousse ou linge doux epais
s ..........................................................................................................................................................................................................................................
Accessoires
Vis de montage (4 de chaque)
XSS4+ 16FJK XYN4+F12FJK taille (M4 x 16) taille (M4 x 12)
Support (1) Base (1)
( AVERTISSEMENT )
Ne d_montez nine modifiez le pi_destal.
® Cela pourrait faire basculer rappareil et rendommager ou blesser quelqu'un. ( Misesen garde )
N'utilisez que le pi_destal fourni avec ce t_l_viseur.
@ Sinon, rappareil pourrait tomber et 6tre abfme, ce qui pourrait causer des blessures.
N'utilisez pas le pi_destal s'il est tordu ou endommag&
@ Si vous utilisez le piedestal alors qu'il est rompu, il risque d'6tre endommage encore davantage, et vous risqueriez de
vous blesser. Adressez-vous d_s que possible a votre detaillant Panasonic.
Lors de rinstallation, veillez _ bien serrer toutes les vis.
@ Si vous ne serrez pas suffisamment les vis Iors du montage, le piedestal ne sera pas assez solide pour supporter le
televiseur ACL, et il risquerait de tomber et d'6tre endommag& ce qui pourrait causer des blessures.
(
Mises en garde )
@
Ouvrez.
Crochet
Respectez la polarite (+ ou -).
Refermez.
8
L'installation incorrecte des piles peut entrafner une fuite de relectrolyte provoquant la corrosion de la
telecommande. ÷ N'utilisez pas & la lois une pile neuve
et une pile usagee.
÷ N'utilisez pas en m6me temps deux
types de piles (par exemple, une pile au carbone zinc et une pile alcaline).
÷ N'utilisez pas de piles rechargeables
(Ni-Cd).
Ne demontez pas et ne chauffez pas les piles.
tc_L3232c_fl'a_0608.indb 8 2010/12/24 13:42:2
I
Loading...
