Model No.
Portable CD Player
SL-SX330/
Operating Instructions
SL-SX331C
Dear Customer
Thank you for purchasing this product. Before connecting, operating or
adjusting this product, please read these instructions completely. Please
keep this manual for future reference.
The model number and serial
number of this product can be
found on either the back or the
bottom of the unit.
Please note them in the space
provided below and keep for
future reference.
MODEL NUMBER
SERIAL NUMBER
P PC
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way Secaucus, New Jersey 07094 http://www.panasonic.com
Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc. (“PSC”)
Ave. 65 de Infantería, Km. 9.5 San Gabriel Industrial Park, Carolina, Puerto Rico 00985
PY
p
Troubleshooting guide
Before requesting service, make the following checks. If you are in doubt about some of the
check points, or if the remedies indicated in the chart do not solve the problem, see “Product
information”(
No play.
No sound or there is
a lot of noise.
Play doesn’t resume
from the track where
play stopped at.
Play doesn’t start from
the first track.
Cannot specify the
AB segment.
The unit stops
working.
The battery indicator
fails to appear or is
incorrect.
➪right) for assistance.
≥The HOLD function is on. Release HOLD (➪page 3).
≥The disc isn’t correctly set.
≥The disc is scratched or dirty. (Tracks skipped.)
≥There is moisture on the lens. Wait for about an hour
and then try again.
≥The lens is dirty: clean it with a blower
(recommended product: SZZP1038C).If the lens gets
marked with fingerprints, gently wipe them off with a
cotton swab.
≥Ensure the plugs are inserted firmly.
≥Wipe the plugs clean with a clean cloth.
≥The elapsed playing time disappears and sound is
interrupted if bumps continue repeatedly.
≥Separate this unit from mobile telephones.
≥This doesn’t work if you open the lid while the unit is
in stop mode.
≥This doesn’t work during random play.
≥It may not work correctly under some conditions.
≥Random play modes may be on (➪page 4).
≥Play resumes from the track where you last stopped
play(play may start from a different track if you
change discs after the power has been turned off).
You may not be able to specify segment A or B at the
end of disc.
Disconnect then reconnect all power sources (batteries
and AC adaptor).
≥The indicator does not appear when an AC adaptor is
connected.
The indicator does not appear correctly under some
≥
conditions.
This function causes the unit to ignore accidental button presses.
Set to HOLD so the unit doesn’t power on accidentally or play is interrupted.
Note on CD-R and CD-RW
HOLD
This unit can play CD-DA format audio CD-R and CD-RW that have been
finalized§upon completion of recording. It may not be able to play some
CD-R or CD-RW due to the condition of the recording.
§Finalizing is a process that enables CD-R/CD-RW players to play audio
CD-R and CD-RW.
Resume function
The player stores the track where you stopped play.
Opening the lid when the unit is in stop mode cancels the function.
Auto off function
If the unit is left in stop mode for approximately 10 minutes, the unit turns
itself off automatically.
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 www.panasonic.ca
C 2003 Matsushita Electric Industrial Co., Ltd.
Printed in China
RQT7178-P
F1003TR0
Display
(
)
*
'
The HOLD function is on. Release HOLD (➪page 3).
≥You haven’t inserted a disc or it isn’t inserted
correctly.
≥You have inserted a disc this unit cannot play.
The disc lid is open.
The program already contains 20 tracks.
Product service
1. Damage requiring service—The unit should be serviced by qualified service
personnel if:
1. (a) The AC power supply cord or AC adaptor has been damaged; or
1. (b) Objects or liquids have gotten into the unit; or
1. (c) The unit has been exposed to rain; or
1. (d) The unit does not operate normally or exhibits a marked change in
performance; or
1. (e) The unit has been dropped or the cabinet damaged.
2.
Servicing—Do not attempt to service the unit beyond that described in these
operating instructions. Refer all other servicing to authorized servicing personnel.
3.
Replacement parts—
specified by the manufacturer or parts that have the same characteristics as the original
parts. Unauthorized substitutes may result in fire, electric shock, or other hazards.
4. Safety check—After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
Product information
For product information or assistance with product operation:
In the U.S.A., contact the Panasonic Customer Call Center at 1-800-211-7262, or
e-mail [email protected], or the website (http://www.panasonic.com).
In Canada, contact the Panasonic Canada Inc. Customer Care Centre at 905-624-5505,
or visit the website (www.panasonic.ca), or an authorized Servicentre closest to you
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
When parts need replacing ensure the servicer uses parts
.
TELEPHONE NUMBER
