Page 1
Operating Instructions
Expandable Digital Corded/Cordless
Answering System
Model No. KX-TG9391
with 2 Handsets
Model No. KX-TG9392
Model shown is KX-TG9391.
This unit is compatible with Caller ID. You must subscribe to the appropriate service offered
by your service provider/telephone company.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save them for future
reference.
For assistance, visit our website:
http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico.
Page 2
Table of Contents
Introduction
Product information. . . . . . . . . . . . . . . . . . . . . . .3
Accessory information. . . . . . . . . . . . . . . . . . . . . 4
System capabilities. . . . . . . . . . . . . . . . . . . . . . . 5
For your saf e ty . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Important safety in st ructions. . . . . . . . . . . . . . . . 7
For best performance . . . . . . . . . . . . . . . . . . . . .7
Preparation
Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Display/Indicators . . . . . . . . . . . . . . . . . . . . . . .10
Symbols used in these operating instructions. . 11
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Battery installation and replacement. . . . . . . . .15
Battery cha r g e. . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting up the unit before use. . . . . . . . . . . . . . 16
Making/Answering Calls
Making cal ls . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Answering c a l l s . . . . . . . . . . . . . . . . . . . . . . . . . 19
Useful features during a call. . . . . . . . . . . . . . . 20
Using the other line during a call. . . . . . . . . . . .21
Phonebook
Base unit/handset phonebook . . . . . . . . . . . . .22
Copying phonebook entries . . . . . . . . . . . . . . . 24
Programming
Programmable settin g s. . . . . . . . . . . . . . . . . . . 25
Special instructions for programmable settings 31
Registering a unit . . . . . . . . . . . . . . . . . . . . . . .32
Caller ID Service
Using Caller ID service . . . . . . . . . . . . . . . . . . . 33
Caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Answering System
Answering system. . . . . . . . . . . . . . . . . . . . . . .36
Turning the answering system on/off . . . . . . . . 36
Greeting message. . . . . . . . . . . . . . . . . . . . . . . 36
Listening to messages using the base unit. . . . 37
Listening to messages using the handset. . . . . 38
Remote operation . . . . . . . . . . . . . . . . . . . . . . . 39
Answering system settings . . . . . . . . . . . . . . . . 41
Voice Mail Service
Voice mail service. . . . . . . . . . . . . . . . . . . . . . .42
Intercom/Locator
Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 3
Transferring c a ll s. . . . . . . . . . . . . . . . . . . . . . . . 43
Conferenc e ca l l s . . . . . . . . . . . . . . . . . . . . . . . . 44
Handset locator. . . . . . . . . . . . . . . . . . . . . . . . .45
Useful Information
Wall mounting for charger. . . . . . . . . . . . . . . . . 46
Belt clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Headset (optional) . . . . . . . . . . . . . . . . . . . . . . 46
Error messages . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 48
FCC and other information . . . . . . . . . . . . . . . . 52
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Customer services . . . . . . . . . . . . . . . . . . . . . . 56
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Index
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
2
Page 3
Product information
Thank you for purchasing a Panasonic digital cordless phone.
Notable differences between the models
KX-TG9391 series
Introduction
L Model shown is
KX-TG9392.
Model No.
KX-TG9391
KX-TG9392 KX-TG9391 KX-TGA939 2
*1 Feature differences:
Intercom calls can be made between the handsets by purchasing and registering one or more optional
handsets (page 5).
*1
Base unit Handset
Part No. Part No. Quantity
KX-TG9391 KX-TGA939 1
For assistance, please visit http://www.panasonic.com/help
3
Page 4
Introduction
Accessory information
Supplied accessories
No. Accessory item/Order number Quantity
1 AC adaptor for base unit
2 4-wire telephone line cord with green plugs/PQJA10088Z 1 1
3 2-wire telephone line cord with transparent plugs/PQJA10075Z 1 1
4 Corded handset/PNLXP1001Z 1 1
5 Corded handset cord/PQJA212V 1 1
6 Rechargeable batteries
7 Handset cover
8 Belt clip/PNKE1004Z1 1 2
9 Charger/PNLC1001YT 1 2
j AC adaptor for charger
*1 Both of the AC adaptors function well.
*2 See page 4 for replacement battery information.
*3 The handset cover comes attached to the handset.
12345
*3
*1
/PQLV207T or PQLV219Z 1 1
*2
/PNYNTGA430BR 1 2
*1
/PQLV209T or PQLV219Z 1 2
KX-TG9391 KX-TG9392
24
6789j
Additional/replacement accessories
Please contact your nearest Panasonic dealer for sales information.
No. Accessory item Order number
1 Headset KX-TCA60, KX-TCA86, KX-TCA92, KX-TCA93, KX-TCA94, KX-TCA95
2 2-line splitter KX-J42
1
L Headset shown is
KX-TCA86.
Replacement battery information:
L Replace batteries only with a nickel metal hydride (Ni-MH) type of battery. This model requires 2 AAA
(R03) batteries for every handset. For best performance, we recommend using Panasonic
rechargeable batteries (Order No. HHR-4DPA). To order, please call 1-800-332-5368 or visit
http://www.panasonic.com/batterystore
4
For assistance, please visit http://www.panasonic.com/help
2
Page 5
Introduction
Expanding your phone system
You can expand your phone system by registering optional KX-TGA939 handsets (6 max.) to a single
base unit.
Sales and support information
L To order additional/replacement accessories, call 1-800-332-5368.
L TTY users (hearing or speech impaired users) can call 1-866-605-1277.
System capabilities
The unit can accommodate up to 2 external telephone lines and the following operations are available at
a time.
How many units can be in use at one time?
■ A maximum of 4 parties are available:
Line 1: Outside call (including 1 extension and 1 outside party)
Line 2: Outside call (including 1 extension and 1 outside party)
Ex. Outside call on line 1 Ex. Outside call on line 2
■ A maximum of 5 parties are available:
Line 1: Conference call (including 2 extensions and 1 outside party)
Line 2: Outside call (including 1 extension and 1 outside party)
Ex. Conference call on line 1 Ex. Outside call on line 2
■ The following operations are possible simultaneously:
L An outside call and 1 pair of intercom call can be made at a time.
L While a caller is leaving a message on your answering system through one line, the unit can make
an outside call through another line.
Note:
L The maximum operating number may decrease, depending on the state of usage, for example, when
the answering system is taking a call.
For assistance, please visit http://www.panasonic.com/help
5
Page 6
Introduction
For your safety
To prevent severe injury and loss of life/property,
read this section carefully before using the product
to ensure proper and safe operation of your
product.
become wet at all. This may cause a fire. If the
telephone line cord plug becomes wet,
immediately pull it from the telephone wall jack,
and do not use.
L Do not excessively pull the corded handset cord
from the base unit. This may cause the base unit
to fall, resulting in injury.
WARNING
Power connection
L Use only the power source marked on the
product.
L Do not overload power outlets and extension
cords. This can result in the risk of fire or electric
shock.
L Completely insert the AC adaptor/power plug
into the power outlet. Failure to do so may cause
electric shock and/or excessive heat resulting in
a fire.
L Regularly remove any dust, etc. from the AC
adaptor/power plug by pulling it from the power
outlet, then wiping with a dry cloth. Accumulated
dust may cause an insulation defect from
moisture, etc. resulting in a fire.
L Unplug the product from power outlets if it emits
smoke, an abnormal smell, or makes an
unusual noise. These conditions can cause fire
or electric shock. Confirm that smoke has
stopped emitting and contact the Panasonic Call
Center at 1-800-211-PANA (1-800-211-7262).
L Never touch the plug with wet hands. Danger of
electric shock exists.
Installation
L To prevent the risk of fire or electrical shock, do
not expose the product to rain or any type of
moisture.
L Do not place or use this product near
automatically controlled devices such as
automatic doors and fire alarms. Radio waves
emitted from this product may cause such
devices to malfunction resulting in an accident.
Medical
L Consult the manufacturer of any personal
medical devices, such as pacemakers or
hearing aids, to determine if they are adequately
shielded from external RF (radio frequency)
energy. (The product operates in the frequency
range of 1.92 GHz to 1.93 GHz, and the RF
transmission power is 115 mW (max.).)
L Do not use the product in health care facilities if
any regulations posted in the area instruct you
not to do so. Hospitals or health care facilities
may be using equipment that could be sensitive
to external RF energy.
CAUTION
Installation and relocation
L Never install telephone wiring during an
electrical storm.
L Never install telephone line jacks in wet
locations unless the jack is specifically designed
for wet locations.
L Never touch uninsulated telephone wires or
terminals unless the telephone line has been
disconnected at the network interface.
L Use caution when installing or modifying
telephone lines.
L The AC adaptor is used as the main disconnect
device. Ensure that the AC outlet is installed
near the product and is easily accessible.
L The cordless handset is unable to make calls
when:
– the handset batteries need recharging or
have failed.
– there is a power failure.
Operating safeguards
L Unplug the product from power outlets before
cleaning. Do not use liquid or aerosol cleaners.
L Do not disassemble the product.
L Do not spill liquids (detergents, cleansers, etc.)
onto the telephone line cord plug, or allow it to
6
For assistance, please visit http://www.panasonic.com/help
Battery
L We recommend using the batteries noted on
page 4. USE ONLY rechargeable Ni-MH
batteries AAA (R03) size.
L Do not mix old and new batteries.
Page 7
Introduction
L Do not open or mutilate the batteries. Released
electrolyte from the batteries is corrosive and
may cause burns or injury to the eyes or skin.
The electrolyte may be toxic if swallowed.
L Exercise care when handling the batteries. Do
not allow conductive materials such as rings,
bracelets, or keys to touch the batteries,
otherwise a short circuit may cause the batteries
and/or the conductive material to overheat and
cause burns.
L Charge the batteries provided with or identified
for use with this product only, in accordance with
the instructions and limitations specified in this
manual.
L Only use a compatible charger to charge the
batteries. Do not tamper with the charger.
Failure to follow these instructions may cause
the batteries to swell or explode.
Important safety instructions
When using your product, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the
following:
1. Do not use this product near water for example,
near a bathtub, washbowl, kitchen sink or
laundry tub, in a wet basement or near a
swimming pool.
2. Avoid using a telephone (other than a cordless
type) during an electrical storm. There may be
a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in
the vicinity of the leak.
4. Use only the power cord and batteries indicated
in this manual. Do not dispose of batteries in a
fire. They may explode. Check with local codes
for possible special disposal instructions.
SAVE THESE INSTRUCTIONS
For best performance
L For maximum coverage and noise-free
communications, place your base unit:
– at a convenient, high, and central location
with no obstructions between the cordless
handset and base unit in an indoor
environment.
– away from electronic appliances such as TVs,
radios, personal computers, wireless devices
or other phones.
– avoid facing radio frequency transmitters,
such as external antennas of mobile phone
cell stations (avoid putting the base unit on a
bay window or near a window).
L Coverage and voice quality depends on the
local environmental conditions.
L If the reception for a base unit location is not
satisfactory, move the base unit to another
location for better reception.
Environment
L Keep the product away from electrical noise
generating devices, such as fluorescent lamps
and motors.
L The product should be kept free from excessive
smoke, dust, high temperature, and vibration.
L The product should not be exposed to direct
sunlight.
L Do not place heavy objects on the power cord or
top of the product.
L When you leave the product unused for a long
period of time, unplug the product from the
power outlet.
L The product should be kept away from heat
sources such as heaters, kitchen stoves, etc. It
should not be placed in rooms where the
temperature is less than 5 °C (41 °F) or greater
than 40 °C (104 °F). Damp basements should
also be avoided.
L The maximum calling distance may be
shortened when the product is used in the
following places: Near obstacles such as hills,
tunnels, underground, near metal objects such
as wire fences, etc.
L Operating the product near electrical appliances
may cause interference. Move away from the
electrical appliances.
Base unit location/avoiding noise
The base unit and other compatible Panasonic
units use radio waves to communicate with each
other.
For assistance, please visit http://www.panasonic.com/help
Routine care
L Wipe the outer surface of the product with a
soft moist cloth.
7
Page 8
Introduction
L Do not use benzine, thinner, or any abrasive
powder.
Notice for product disposal, transfer, or return
L This product can store your private/confidential
information. To protect your
privacy/confidentiality, we recommend that you
erase the information such as phonebook or
caller list entries from the memory before you
dispose of, transfer, or return the product.
8
For assistance, please visit http://www.panasonic.com/help
Page 9
Controls
Base unit
Preparation
S {ANSWER ON}
T {LOCATOR} {INTERCOM}
U Navigator key ({^}/{V}/{7}/{8})
VOL. (Volume: {^}/{V})
Handset
B
A
C
D
E
F
H
I
J
K
L
M
A Co r de d handset
B Receiver
C Speaker
D {LINE 1}
LINE1 indicator
E {LINE 2}
LINE2 indicator
F {HOLD}
G {REDIAL} {PAUSE}
H {FLASH} {CALL WAIT}
I Display
J Soft keys
K MIC (Microphone)
L Dial keypad
({*}: TONE)
M {SP-PHONE} (Speakerphone)
SP-PHONE indicator
N {6} (Play)
Message indicator
O {ERASE}
P {■} (STOP) (EXIT)
Q {ANSWER SELECT}
R ANSWER ON indicator
G
A Speaker
B Soft keys
C Headset jack
D {C} (TALK)
E {s} (SP-PHONE: Speakerphone)
F Dial keypad
({*}: TONE)
G {FLASH} {CALL WAIT}
H Charge indicator
Ringer indicator
I Receiver
J Display
K {OFF}
L Navigator key ({^}/{V}/{<}/{>})
? (Volume: {^}/{V})
M {PAUSE} {REDIAL}
N {HOLD} {INTERCOM}
O Microphone
P Charge contacts
N
O
P
For assistance, please visit http://www.panasonic.com/help
9
Page 10
Preparation
Using the navigator keys
The navigator keys can be used to navigate
through menus and to select items shown on the
display by pressing:
Base unit: {^}, {V}, {7}, or {8}
Handset: {^}, {V}, {<}, or {>}
To adjust the receiver or speaker volume, press
{^} to increase the volume, or press {V} to
decrease the volume repeatedly while talking.
Base unit Handset
{^}
{7}{8}
{V}
{^}
{<}{>}
{V}
Soft keys
Each unit features 3 soft keys. By pressing a soft
key, you can select the feature shown directly
above it on the display.
Base unit
Handset
Display/Indicators
Base unit display items
Item Meaning
W
X
L1
L2
3 Night mode is on (page 31).
PRIV. Call privacy mode is on (page 21).
*1 Corresponding line number(s) is indicated
next to the item.
Handset display items
Item Meaning
1 Battery level
w Within range of the base unit
c
d
L1
L2
s Speaker is on (page 18).
3 Night mode is on (page 31).
E Alarm is on (page 31).
m Handset number
PRIV. Call privacy mode is on (page 21).
Indicates the selected line(s) for
answering system operations and
settings.
Ringer volume (page 29) is off.
L When flashing: Handset is
searching for the base unit
(page 48).
The line is in use.
L When flashing:
– the call is put on hold on that
line.
– the answering system is
answering a call on that line.
L When flashing rapidly: an
incoming call is now being
received on that line.
Ringer volume (page 29) is off.
*1
*1
10
*1 Corresponding line number(s) is indicated
next to the item.
For assistance, please visit http://www.panasonic.com/help
Page 11
Preparation
Menu icons
When in standby mode, pressing {MENU} (middle
soft key) reveals the main menu. From here you
can access various features and settings.
Base unit menu icons
Menu icon Menu/feature
View Caller ID
Phonebook
Set answering
Ringer settings
Initial settings
Customer support
Handset menu icons
Menu icon Menu/feature
View Caller ID
Phonebook
Answering device
Status Meaning
Flashing A call is put on hold or the
answering system is
answering a call.
Symbols used in these operating instructions
Symbol Meaning
: Perform with the base unit.
Y Pe rform with the handset.
{} The words in the brackets
indicate button names/soft key
names on the base unit and
handset.
Example:
Unit keys: {C}, {OFF}
Soft keys: {MENU},
{SELECT}
i Proceed to the next operation.
“” The words in quotations
indicate the menu on the
display.
Example: “Date and time”
{V}/{^}: “” Press {V} or {^} to select the
words in quotations.
Example: {V}/{^}: “Off”
Ringer settings
Initial settings
Customer support
LINE1 indicator/LINE2 indicator on
the base unit
The LINE1 indicator and LINE2 indicator show the
status of each line, respectively, as follows.
Status Meaning
Light off T he line is available.
Light on The line is in use.
Flashing
rapidly
A call is being received.
For assistance, please visit http://www.panasonic.com/help
11
Page 12
Preparation
Connections
Connecting the AC adaptor/corded handset
Connect the AC adaptor cord (A) by pushing the plug firmly (B). Connect the corded handset cord (C)
to the corded handset and the base unit.
Base unit
L Use only the supplied Panasonic AC adaptor PQLV207 or PQLV219.
B
Hook
Charger
L Use only the supplied Panasonic AC adaptor PQLV209 or PQLV219.
A
Note:
L The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during
use.)
L The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not
connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to
become disconnected.
During a power failure
The base unit will work as a standard telephone using power from the telephone line. Line 1 on the
corded handset can be used to make and answer calls. The base unit speakerphone and the cordless
handset will not function during a power failure.
A
(120 V AC, 60 Hz)
CCCCC
(120 V AC, 60 Hz)
B
Hooks
CCCCC
12
For assistance, please visit http://www.panasonic.com/help
Page 13
Connecting the telephone line cord
Refer to one of the following methods depending on your situation:
– To connect to a 2-line telephone jack: page 13
– To connect to 2 single-line telephone jacks: page 13
– If you use the unit as a single-line telephone only: page 13
Connect the telephone line cord until it clicks into the base unit and telephone line jack.
To connect to a 2-line telephone jack
“GREEN” plug
4-wire cord
To 2-line telephone jack (RJ14C)
To connect to 2 single-line telephone jacks
To single-line
“Transparent” plug
“GREEN” plug
2-wire cord
4-wire cord
telephone jacks (RJ11C)
Line 1
Line 2
Preparation
If you use the unit as a single-line telephone only
Be sure to connect the telephone line cord to LINE 1/2 to allow usage of the unit during a power failure
(page 12). Change the line selection mode from “Auto” to “Line1” (page 17).
“Transparent” plug
Note:
L “Check tel line 2” is displayed on the unit. To erase it, see page 47.
For assistance, please visit http://www.panasonic.com/help
2-wire cord
To single-line telephone jack (RJ11C)
13
Page 14
Preparation
If you subscribe to a DSL/ADSL service
Please attach a DSL/ADSL filter (contact your DSL/ADSL provider) to the telephone line between the
base unit and the telephone line jack in the event of the following:
– noise is heard during conversations.
– Caller ID features do not function properly.
To connect to a 2-line telephone jack
For this connection, please purchase a Panasonic 2-line splitter (page 4).
Example: DSL/ ADSL line is line 2
To connect to 2 single-line telephone jacks
Example: DSL/ ADSL line is line 2
“Transparent” plug
“GREEN” plug
4-wire cord
14
2-wire cord
DSL/ADSL filter
For assistance, please visit http://www.panasonic.com/help
To single-line telephone
jacks (RJ11C)
Line 1
Line 2
Page 15
Battery installation and replacement
Important:
L Use the supplied rechargeable batteries (Part
No. HHR-55AAABU).
L When installing the batteries:
– Wipe the battery ends (S, T) with a dry
cloth.
– Avoid touching the battery ends (S, T) or the
unit contacts.
– Confirm correct polarities (S, T).
L When replacing the batteries:
– USE ONLY rechargeable Ni-MH batteries
AAA (R03) size.
– Do NOT use Alkaline/Manganese/Ni-Cd
batteries.
– We recommend using the Panasonic
rechargeable batteries noted on page 4, 6.
1 Press the notch on the handset cover firmly,
and slide it in the direction of the arrow.
Preparation
Note:
L When replacing batteries, remove the old
batteries.
Attention:
A nickel metal hydride battery that is recyclable
powers the product you have purchased.
Please call 1-800-8-BATTERY (1-800-822-8837)
for information on how to recycle this battery.
2 Insert the batteries negative (T) end first.
Close the handset cover.
Rechargeable Ni-MH ONLY
For assistance, please visit http://www.panasonic.com/help
Battery charge
Place the handset on the charger for about 7
hours before initial use.
L While charging, “Charging” is displayed and
the charge indicator on the handset lights up.
When the batteries are fully charged, “Charge
completed” is displayed.
Note:
L It is normal for the handset to feel warm during
charging.
15
Page 16
Preparation
L If you want to use the handset immediately,
charge the batteries for at least 15 minutes.
L Clean the charge contacts of the handset and
charger with a soft and dry cloth once a month.
Clean more often if the unit is exposed to
grease, dust, or high humidity.
Battery level
Battery icon Battery level
1 High
2 Medium
3 Low
L When flashing: Needs
to be charged.
4 Empty
Note:
L The batteries need to be charged if the handset
beeps while you are engaged in a call or
operating the answering system remotely.
Panasonic Ni-MH battery performance
(supplied batteries)
Operation Operating time
In continuous use 12 hours max.
Not in use (standby) 6 days max.
Note:
L Actual battery performance depends on a
combination of how often the handset is in use
and how often it is not in use (standby).
L Even after the handset is fully charged, the
handset can be left on the charger without any ill
effect on the batteries.
L The battery level may not be displayed correctly
after you replace the batteries. In this case,
place the handset on the charger and let it
charge for at least 7 hours.
Setting up the unit before use
Display language
You can select either “English” or “Español”
as the display language. The default setting is
“English”.
: Base unit / Y Handset
1 {MENU} i {#}{1}{1}{0}
2 {V}/{^}: Select the desired setting.
3 Press the middle soft key to save.
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Voice guidance language
You can select either “English” or “Español”
as the voice guidance language of the answering
system. The default setting is “English”.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{1}{1}{2}
2 {V}/{^}: Select the desired setting.
3 {SAVE}
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Dialing mode
If you cannot make calls, change this setting
according to your telephone line service. The
default setting is “Tone”.
“Tone”: For tone dial service.
“Pulse”: For rotary/pulse dial service.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
16
1 {MENU} i {#}{1}{2}{0}
2 {V}/{^}: Select the desired setting.
3 {SAVE}
For assistance, please visit http://www.panasonic.com/help
Page 17
Preparation
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Date and time
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{1}{0}{1}
2 Enter the current month, date, and year by
selecting 2 digits for each.
Example: September 15, 2008
{0}{9} {1}{5} {0}{8}
3 Enter the current hour and minute (12-hour
clock format) by selecting 2 digits for each.
Example: 9: 30
{0}{9} {3}{0}
4 Press {*} to select “AM” or “PM”.
5 {SAVE}
6 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Note:
L When English is selected as the display
language, 12-hour clock format is used. When
Spanish is selected, 24-hour clock format is
used.
L To correct a digit:
Base unit: Press {^}, {V}, {7}, or {8} to
move the cursor to the digit, then make the
correction.
Handset: Press {^}, {V}, {<}, or {>} to move
the cursor to the digit, then make the correction.
L The date and time may be incorrect after a
power failure. In this case, set the date and time
again.
Line selection mode
The line selection mode determines which line is
selected when:
– you lift the corded handset
– you press {SP-PHONE} on the base unit (when
making/answering calls)
– you press {C}/{s} on the handset (when
making/answering calls)
The following setting is available:
– “Auto” (default): When making a call, line 1 is
selected. If that line is unavailable, line 2 is
selected. When you call back using the caller list
(page 33) or while listening to a message (page
37, 38), the indicated line is used. When
answering a call, the ringing line is selected.
– “Line1”: Line 1 is selected.
– “Line2”: Line 2 is selected.
: Base unit / Y Handset
1 {MENU} i {#}{2}{5}{0}
2 {V}/{^}: Select the desired setting.
3 {SAVE}
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Note:
L Y ou can select a line manually regardless of t he
line selection mode by pressing {LINE 1} or
{LINE 2}.
For assistance, please visit http://www.panasonic.com/help
17
Page 18
Making/Answering Calls
Making calls
Using the base unit :
Dial the phone number.
1
L To correct a digit, press {CLEAR}.
2 Lift the corded handset.
L An available line is automatically selected
and either the LINE1 indicator or LINE2
indicator lights up. To change the line
selection mode, see page 17.
L You can also select the line manually by
pressing {LINE 1} or {LINE 2} before lifting
the corded handset.
3 When you finish talking, place the corded
handset on the cradle.
Note:
L You can also dial the phone number after lifting
the corded handset.
L To switch to the cordless handset, press {LINE
1} or {LINE 2} on the cordless handset, then
place the corded handset on the cradle.
Using the speakerphone
1 During a conversation with the corded
handset, press {SP-PHONE} to turn on the
speakerphone.
L You can place the corded handset on the
cradle.
L Speak into the MIC.
L Speak alternately with the other party.
2 When you finish talking, press {SP-PHONE}.
Note:
L For best performance, use the speakerphone in
a quiet environment.
L T o switch to the receiver, lift the corded handset.
Using the handset Y
Lift the handset and dial the phone number.
1
L To correct a digit, press {CLEAR}.
2 {C}
L An available line is automatically selected
and the line number is displayed. T o change
the line selection mode, see page 17.
L You can also select the line manually by
pressing {LINE 1} or {LINE 2}.
3 When you finish talking, press {OFF} or place
the handset on the charger.
Note:
L The LINE1 indicator or LINE2 indicator on the
base unit lights up while using the handset.
Using the speakerphone
1 During a conversation, press {s} to turn on
the speakerphone.
L Speak alternately with the other party.
2 When you finish talking, press {OFF}.
Note:
L For best performance, use the speakerphone in
a quiet environment.
L To switch to the receiver, press {C}.
Adjusting the receiver or speaker
volume
: Base unit / Y Handset
Press {^} or {V} repeatedly while talking.
Making a call using the redial list
The last 10 phone numbers dialed are stored in the
redial list in each unit (each 48 digits max.).
: Base unit / Y Handset
1 {REDIAL}
2 {V}/{^}: Select the desired phone number.
3 Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
Erasing a number in the redial list
1 {REDIAL}
2 {V}/{^}: Select the desired phone number.
i {ERASE}
3 {V}/{^}: “Yes” i {SELECT}
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Pause (for PBX/long dist ance service
users)
A pause is sometimes required when making calls
using a PBX or long distance service. When
18
For assistance, please visit http://www.panasonic.com/help
Page 19
Making/Answering Calls
storing a calling card access number and/or PIN in
the phonebook, a pause is also needed (page 24).
: Base unit / Y Handset
Example: If you need to dial the line access
number “9” when making outside calls with a PBX:
1 {9} i {PAUSE}
2 Dial the phone number.
3 Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
Note:
L A 3.5 second pause is inserted each time
{PAUSE} is pressed. Repeat as needed to
create longer pauses.
Answering calls
Using the base unit :
When a call is being received, the LINE1 indicator
and/or LINE2 indicator on the base unit flashes
rapidly.
1 Lift the corded handset or press {SP-PHONE}
when the unit rings.
L The called line is automatically selected. To
change the line selection mode, see page
17.
L You can also answer the call by pressing
{LINE 1} or {LINE 2}.
2 When you finish talking, place the corded
handset on the cradle. When the
speakerphone is used, press {SP-PHONE}.
Using the handset Y
When a call is being received, the ringer indicator
and c and/or d flashes rapidly.
1 Lift the handset and press {C} or {s} when
the unit rings.
L The called line is automatically selected. To
change the line selection mode, see page
17.
L You can also answer the call by pressing
{LINE 1} or {LINE 2}.
L You can also answer the call by pressing
any dial key from {0} to {9}, {*}, or {#}.
(Any key answer feature)
2 When you finish talking, press {OFF} or place
the handset on the charger.
Auto talk
You can answer calls simply by lifting the handset
off the charger. You do not need to press {C}. To
turn this feature on, see page 28.
Adjusting the handset ringer volume
Press {^} or {V} repeatedly to select the desired
volume while the handset is ringing for an
incoming call.
Note:
L You can also program the handset ringer
volume beforehand (page 29).
Tem por ary handset ringer off
While the handset is ringing for a call, you can turn
the ringer off temporarily by pressing {OFF}.
Adjusting the base unit ringer volume
Press {^} or {V} repeatedly to select the desired
volume while the base unit is ringing for an
incoming call.
Note:
L You can also program the base unit ringer
volume beforehand (page 29).
Temporary base unit ringer off
While the base unit is ringing for a call, you can
turn the ringer off temporarily by pressing {~}.
For assistance, please visit http://www.panasonic.com/help
19
Page 20
Making/Answering Calls
Useful features during a call
Note:
L To change the flash time, see page 29.
Hold
This feature allows you to put an outside call on
hold.
: Base unit
1 Press {HOLD} during an outside call.
L If you are using the corded handset, you can
place it on the cradle.
2 To release hold, press {LINE 1} or {LINE 2}
that is flashing on the base unit.
Y Handset
1 Press {HOLD} 2 times during an outside call.
2 To release hold, press {LINE 1} or {LINE 2}
that is flashing on the handset.
Note for base unit and handset:
L If a call is kept on hold for more than 9 minutes,
an alarm tone starts to sound and the ringer
indicator flashes rapidly. After 1 additional
minute on hold, the call is disconnected.
L If another phone is connected to the same line,
you can also take the call by lifting its handset.
Mute
While mute is turned on, you can hear the other
party , but the other party cannot hear you.
: Base unit / Y Handset
1 Press {MUTE} during an outside call.
L{MUTE} flashes.
2 To return to the conversation, press {MUTE}
again.
Note:
L{MUTE} is a soft key visible on the display
during a call.
For call waiting or Call Waiting Caller
ID service users
To use call waiting, you must first subscribe to the
call waiting service of your service
provider/telephone company.
This feature allows you to receive calls while you
are already talking on the phone. If you receive a
call while on the phone, you will hear a call waiting
tone.
If you subscribe to both Caller ID and Call
Waiting with Caller ID services, the 2nd caller’s
information is displayed on the base unit or
handset that is in use after you hear the call waiting
tone.
: Base unit / Y Handset
1 Press {CALL WAIT} to answer the 2nd call.
2 To switch between calls, press {CALL WAIT}.
Note:
L Please contact your service provider/telephone
company for details and availability of this
service in your area.
Temporary tone dialing (for
rotary/pulse service users)
You can temporarily switch the dialing mode to
tone when you need to access touch-tone services
(for example, answering services, telephone
banking services, etc.).
: Base unit / Y Handset
Press {*} (TONE) before entering access
numbers which require tone dialing.
Flash
: Base unit / Y Handset
{FLASH} allows you to use the special features of
your host PBX such as transferring an extension
call, or accessing optional telephone services.
20
For assistance, please visit http://www.panasonic.com/help
Page 21
Making/Answering Calls
Call share
This feature allows you to join an existing outside
call.
: Base unit
To join the conversation, press {LINE 1} or {LINE
2} to select the line that is being used by another
extension for an outside call, then lift the corded
handset.
Y Handset
To join the conversation, press {LINE 1} or {LINE
2} to select the line that is being used by another
extension for an outside call.
Note for base unit and handset:
L A maximum of 3 parties (including 1 outside
party) can join a conversation.
Call privacy
Call privacy allows you to prevent other users from
joining your conversations with outside callers. To
allow other users to join your conversations, leave
this feature off. The default setting is “Off”.
: Base unit
1 Press {MENU} during an outside call.
L If any options appear on the display, perform
the following:
{V}/{^}: “Privacy” i {SELECT}
2 {V}/{^}: “On” or “Off” i {SELECT}
L When this feature is turned on, “PRIV.” is
displayed.
Y Handset
Using the other line during a call
You can use the other line in the following ways:
– When a call is being received on the other line
during a conversation, an interrupt tone will be
heard (page 28). You can answer the 2nd call
while holding the 1st call.
– During an outside call, you can also make a call
using the other line by holding the 1st call.
: Base unit
Example: If you are using line 1:
1 Press {HOLD} to put the 1st call (line 1) on
hold.
2 Press {LINE 2} to make or answer a 2nd call.
L To hold the 2nd call, press {HOLD}.
3 To return to the 1st call (line 1), press {LINE
1}.
Y Handset
Example: If you are using line 1:
1 Press {HOLD} 2 times to put the 1st call (line
1) on hold.
2 Press {LINE 2} to make or answer a 2nd call.
L T o hold the 2nd call, press {HOLD} 2 times.
3 To return to the 1st call (line 1), press {LINE
1}.
Note for base unit and handset:
L If you subscribe to Caller ID, the 2nd caller’s
information is displayed when a call is being
received on the other line (page 33).
1 Press {MENU} during an outside call.
2 {V}/{^}: “Privacy” i {SELECT}
3 {V}/{^}: “On” or “Off” i {SELECT}
L When this feature is turned on, “PRIV.” is
displayed.
Note for base unit and handset:
L This feature will turn off after you hang up the
call.
For assistance, please visit http://www.panasonic.com/help
21
Page 22
Phonebook
Base unit/handset phonebook
The phonebook allows you to make calls without
having to dial manually. You can add names and
phone numbers to the base unit and handset
phonebook independently, and assign each
phonebook entry to the desired group.
– Base unit: up to 100 entries
– Handset: up to 100 entries
Adding entries
: Base unit / Y Handset
1
Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 {ADD}
3 Enter the party’s name (16 characters max.).
i {OK}
4 Enter the party’s phone number (24 digits
max.). i {OK}
5 {V}/{^}: Select the desired group. i
{SELECT} 2 times
L To add other entries, repeat from step 3.
6 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Note:
L Caller ID subscribers can use group ringer tone
feature (page 33).
Character table for entering names
While entering characters, you can switch
between uppercase and lowercase by pressing
{*}.
Key Character
{1} Space # & ’ ( )
; ,–./1
{2} ABC2
abc2
{3} DEF3
def3
{4} GHI 4
ghi4
Key Character
{5} JKL5
jkl5
{6} MNO6
mn o6
{7} PQRS7
pqrs7
{8} TUV8
tuv8
{9} WX YZ9
wxyz9
{0} Space 0
L T o enter another character that is located on the
same dial key:
Base unit: Press {8} to move the cursor to the
next space.
Handset: Press {>} to move the cursor to the
next space.
Correcting a mistake
1 Proceed with the operation for your unit.
Base unit: Press {7} or {8} to move the
cursor to the character or number you want to
erase.
Handset: Press {<} or {>} to move the
cursor to the character or number you want to
erase.
2 Press {CLEAR}, and then enter the
appropriate character or number.
L Press and hold {CLEAR} to erase all
characters or numbers.
Groups
Groups can help you find entries in the phonebook
quickly and easily. When adding an entry to the
phonebook, you can assign it to one of 9 groups.
Y ou can change the names of groups assigned for
phonebook entries (“Friends”, “Family”, etc.) and
then search for phonebook entries by group. The
group ringer tone feature is available for Caller ID
subscribers (page 33).
Changing group names
The default group name is “Group 1” to “Group
9”.
: Base unit / Y Handset
22
For assistance, please visit http://www.panasonic.com/help
Page 23
Phonebook
1 Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 {MENU}
3 {V}/{^}: “Group” i {SELECT}
4 {V}/{^}: Select the desired group. i
{SELECT}
5 {V}/{^}: “Group name” i {SELECT}
6 Edit the name (10 characters max.; page 22).
i {SAVE}
7 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Finding and calling a phonebook
entry
: Base unit / Y Handset
Once you have found the desired entry using one
of the following 3 methods, make a call with your
unit.
Base unit: Lift the corded handset.
L You can also make a call by pressing {LINE 1}
or {LINE 2}, then lifting the corded handset.
Handset: {C}
L You can also make a call by pressing {CALL},
then pressing {LINE 1} or {LINE 2}.
Scrolling through all entries
1 Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 {V}/{^}: Select the desired entry.
Searching by first character (alphabetically)
1 Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 Press the dial key ({0} - {9}) which contains
the character you are searching for (page 22).
L Press the same dial key repeatedly to
display the first entry corresponding to each
character located on that dial key.
L If there is no entry corresponding to the
character you selected, the next entry is
displayed.
3 {V}/{^}: Scroll through the phonebook if
necessary.
Searching by group
1 Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 {GROUP}
3 {V}/{^}: Select the group you want to search.
i {SELECT}
L If you select “All groups”, the unit ends
the group search.
4 {V}/{^}: Scroll through the phonebook if
necessary.
Editing entries
: Base unit / Y Handset
1
Find the desired entry (page 23). i {MENU}
2 {V}/{^}: “Edit” i {SELECT}
3 Edit the name if necessary (16 characters
max.; page 22). i {OK}
4 Edit the phone number if necessary (24 digits
max.). i {OK}
5 {V}/{^}: Select the desired group (page 22).
i {SELECT} 2 times
6 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Erasing entries
: Base unit / Y Handset
Erasing an entry
1 Find the desired entry (page 23).
2 {MENU}
3 {V}/{^}: “Erase” i {SELECT}
4 {V}/{^}: “Yes” i {SELECT}
5 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Erasing all entries
1 Proceed with the operation for your unit.
Base unit: {C}
For assistance, please visit http://www.panasonic.com/help
23
Page 24
Phonebook
Handset: {MENU} i {#}{2}{8}{0}
2 {MENU}
3 {V}/{^}: “Erase all” i {SELECT}
4 {V}/{^}: “Yes” i {SELECT}
5 {V}/{^}: “Yes” i {SELECT}
6 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Chain dial
This feature allows you to dial phone numbers in
the phonebook while you are on a call. This feature
can be used, for example, to dial a calling card
access number or bank account PIN that you have
stored in the phonebook, without having to dial
manually.
: Base unit / Y Handset
1 Proceed with the operation for your unit.
During an outside call:
Base unit: {C}
Handset: {MENU} i {V}/{^}:
“Phonebook” i {SELECT}
2 {V}/{^}: Select the desired entry.
3 Press {CALL} to dial the number.
Note:
L When storing a calling card access number and
your PIN in the phonebook as one phonebook
entry, press {PAUSE} to add pauses after the
number and PIN as necessary (page 18).
L If you have rotary/pulse service, you need to
press {*} before pressing {C} on the base
unit or {MENU} on the handset in step 1 to
change the dialing mode temporarily to tone.
Copying phonebook entries
You can copy phonebook entries from the base
unit to a handset or vice versa.
Important:
L Group ringer tones are not copied.
L You cannot copy the phonebook entries
between handsets.
Copying an entry
: Base unit
1
{C}
2 {V}/{^}: Select the desired entry. i {MENU}
3 {V}/{^}: “Copy” i {SELECT}
4 {V}/{^}: Enter the handset number to copy to.
L When an entry has been copied,
“Completed” is displayed.
L To continue copying another entry:
{V}/{^}: “Yes” i {SELECT} i Find the
desired entry (page 23). i {SEND}
5 {■} (EXIT)
Y Handset
1 {MENU} i {#}{2}{8}{0}
2 {V}/{^}: Select the desired entry. i {MENU}
3 {V}/{^}: “Copy to base” i {SELECT}
L When an entry has been copied,
“Completed” is displayed.
L To continue copying another entry:
{V}/{^}: “Yes” i {SELECT} i Find the
desired entry (page 23). i {SEND}
4 {OFF}
Copying all entries
: Base unit
1
{C} i {MENU}
2 {V}/{^}: “Copy all” i {SELECT}
3 {V}/{^}: Enter the handset number to copy to.
L When all entries have been copied,
“Completed” is displayed.
4 {■} (EXIT)
Y Handset
1 {MENU} i {#}{2}{8}{0} i {MENU}
2 {V}/{^}: “Copy all to base” i
{SELECT}
L When all entries have been copied,
“Completed” is displayed.
3 {OFF}
24
For assistance, please visit http://www.panasonic.com/help
Page 25
Programmable settings
You can customize the unit by programming the following features.
To access the features, there are 2 methods:
– scrolling through the display menus (page 25)
– using the direct commands (page 28)
L Mainly the direct command method is used in these operating instructions.
Programming by scrolling through the display menus
: Base unit / Y Handset
1
{MENU}
2 Proceed with the operation for your unit.
Base unit: Press {V}, {^}, {7}, or {8} to select the desired main menu. i {SELECT}
Handset: Press {V}, {^}, {<}, or { >} to select the desired menu. i {SELECT}
3 Press {V} or {^} to select the desired item in sub-menu 1. i {SELECT}
L In some cases, you may need to select from sub-menu 2. i {SELECT}
4 Press {V} or {^} to select the desired setting. i {SAVE}
L This step may vary depending on the feature being programmed.
L To exit the operation, press {■}(EXIT) on the base unit or {OFF} on the handset.
Note:
L See page 28 for the default settings.
Programming
Base unit
Main menu Sub-menu 1 Sub-menu 2 Page
View Caller ID ––33
Phonebook ––22
Set answering Record greeting Line1&Line2 36
Line1
Line2
Play greeting Line1&Line2 37
Line1
Ring count
Recording time
Remote code
Call screening –36
For assistance, please visit http://www.panasonic.com/help
*1
*1
*1
Line2
–41
–41
–39
25
Page 26
Programming
Main menu Sub-menu 1 Sub-menu 2 Page
Ringer settings Ringer volume Line1 –
Line2
Ringer tone Line1 –
Line2
Interrupt tone ––
Night mode Start/End 31
On/Off 31
Initial settings Set date & time Date and time
Time adjustment
Contrast ––
Line select –17
Set tel line Caller ID edit 34
Set dial mode
Set flash time
– Line1
– Line2
Set line mode
– Line1
– Line2
VM tone detect
Change language Display language 16
Voice prompt
Customer support ––31
*1
*1
*1
*1
*1
*1
*1
17
–
16
29
–
42
16
*1 If you program these settings using the base unit, you do not need to program the same item using a
handset.
Handset
Main menu Sub-menu 1 Sub-menu 2 Page
View Caller ID ––33
Phonebook ––22
Answering device Play new msg. ––
Play all msg. ––
Erase all ––
Settings Ring count
Recording time
Remote code
*1
*1
*1
41
41
39
Call screening 36
26
For assistance, please visit http://www.panasonic.com/help
Page 27
Programming
Main menu Sub-menu 1 Sub-menu 2 Page
Ringer settings Ringer volume Line1 –
Line2 –
Ringer tone Line1 –
Line2 –
Interrupt tone ––
Night mode Start/End 31
On/Off 31
Initial settings Set date & time Date and time
Alarm 31
Time adjustment
Contrast ––
Key tone ––
Auto talk –19
Line select –17
Set tel line Caller ID edit 34
Set dial mode
Set flash time
– Line1
– Line2
Set line mode
– Line1
– Line2
VM tone detect
Registration HS registration 32
Deregistration 32
Change language Display language 16
Voice prompt
Customer support ––31
*1
*1
*1
*1
*1
*1
*1
17
–
16
29
–
42
16
*1 If you program these settings using one of the handsets, you do not need to program the same item
using another unit.
For assistance, please visit http://www.panasonic.com/help
27
Page 28
Programming
Programming using the direct commands
{MENU} i {#}
1
2 Enter the desired feature code.
3 {V}/{^}: Select the desired setting. i {SAVE}
L This step may vary depending on the feature being programmed.
L To exit the operation, press {■}(EXIT) on the base unit or {OFF} on the handset.
Note:
L The operating unit column shows the unit(s) that can be used to program the item.
:: Only the base unit can program the item.
Y: Only the handset can program the item.
:/Y: Both the base unit and handset can program the item.
L In the following table, < > indicates the default settings.
Operating
unit
Y Alarm {7}{2}{0} <Off>
Y Auto talk
:/Y Caller ID edit
:/Y Call screening {3}{1}{0} <On>
:/Y Contrast
:/Y Customer support {6}{8}{0} ––31
:/Y Date and time {1}{0}{1} – r 17
Y Deregistration {1}{3}{1} ––32
:/Y Display language {1}{1}{0} <English>
Y Erase all
Y HS registration
:/Y Interrupt tone
Y Key tone
:/Y Line select {2}{5}{0} <Auto>
:/Y Night mode
Feature Feature
code
*2
(Caller ID number auto
edit)
(Display contrast)
(Erasing all messages)
(Handset registration)
*4
(On/Off)
{2}{0}{0} On
{2}{1}{4} <On>
{1}{4}{5} Level 1–6 <3> – –
{3}{2}{5} ––38
{1}{3}{0} ––32
*3
{2}{0}{1} <On>
{1}{6}{5} <On>
{2}{3}{8} On
Setting System
setting
–31
Once
Daily
–19
<Off>
–34
Off
–36
Off
–16
Español
–43
Off
––
Off
–17
Line1
Line2
–31
<Off>
Page
*1
28
For assistance, please visit http://www.panasonic.com/help
Page 29
Programming
Operating
unit
:/Y Night mode
Feature Feature
code
{2}{3}{7} <11:00 PM/06:00 AM>–31
Setting System
setting
Page
*1
(Start/End)
:/Y Phonebook {2}{8}{0} ––22
Y Play all msg. {3}{2}{4} ––38
: Play greeting {3}{0}{3} ––37
Y Play new msg. {3}{2}{3} ––38
: Record greeting {3}{0}{2} ––36
:/Y Recording time {3}{0}{5} 1min
r 41
2min
<3min>
:/Y Remote code {3}{0}{6} <111> r 39
:/Y Ring count {2}{1}{1} Toll saver
r 41
2–7 rings <4>
:/Y Ringer tone
*5, *6
{1}{6}{1} Line 1
Line 2
Line 1: <Tone 1>
Line 2: <Tone 2>
––
Base unit:
Tone 1–3
Melody 1–3
Handset:
Tone 1–5
Melody 1–10
:/Y Ringer volume
{1}{6}{0} Line 1
Line 2
Base unit:
Level 1–<3>, Off
––
*7
Handset:
Level 1–<6>, Off
:/Y Set dial mode {1}{2}{0} <Tone>
r 16
Pulse
:/Y Set flash time
{1}{2}{1} Line 1
Line 2
80ms 90ms
100ms 110ms
r 20
*8
160ms 200ms
250ms 300ms
400ms 600ms
<700ms> 900ms
:/Y Set line mode
{1}{2}{2} Line 1
r –
*9
Line 2A<B>
:/Y Time adjustment
(Caller ID subscribers
*10
{2}{2}{6} <Caller ID[auto]>
Manual
r –
only)
:/Y View Caller ID {2}{1}{3} ––33
:/Y VM tone detect {3}{3}{2} <On>
r 42
Off
:/Y Voice prompt {1}{1}{2} <English>
r 16
Español
*1 If “System setting” column is checked, you do not need to program the same item using another unit.
*2 If you subscribe to Caller ID service and want to view the caller’s information after lifting up the handset
to answer a call, turn off this feature.
For assistance, please visit http://www.panasonic.com/help
29
Page 30
Programming
*3 This tone lets you know when you receive an outside call while you are on the other line or an intercom
call. If yo u select “On”, the tone sounds 2 times.
*4 Turn this feature off if you prefer not to hear key tones while you are dialing or pressing any keys,
including confirmation tones and error tones.
*5 If you subscribe to a distinctive ring service (such as IDENTA-RING), select a tone (base unit: tone 1
to 3/handset: tone 1 to 5). If you select a melody, you cannot distinguish lines by their ringers.
*6 If you select one of the melody ringer tones, the ringer tone will continue to play for several seconds
even if the caller has already hung up. You may either hear a dial tone or no one on the line when you
answer the call.
*7 When the ringer volume is turned off, ~ is displayed followed by the selected line number(s) and the
base unit and/or handset do not ring for outside calls.
*8 The flash time depends on your telephone exchange or host PBX. Contact your PBX supplier if
necessary. The setting should stay at “700ms” unless pressing {FLASH} fails to pick up the waiting
call.
*9 Generally, the line mode setting should not be adjusted. If the LINE1 indicator or LINE2 indicator does
not light when another phone connected to the same line is in use, you need to change the line mode
to “A”.
*10This feature allows the unit to automatically adjust the date and time setting when caller information
is received. To use this feature, set the date and time first.
30
For assistance, please visit http://www.panasonic.com/help
Page 31
Programming
Special instructions for programmable settings
Night mode
Night mode allows you to select a span of time
during which the unit will not ring for outside calls.
This feature is useful for those occasions when
you do not want to be disturbed, for example, while
sleeping. Night mode can be set independently for
each base unit and handset.
Important:
L Set the date and time beforehand (page 17).
L If you have set the alarm, the alarm sounds even
if the night mode is turned on.
Setting the start and end time
: Base unit / Y Handset
1 {MENU} i {#}{2}{3}{7}
2 Enter the desired hour and minute you wish to
start this feature.
3 Press {*} to select “AM” or “PM”. i {OK}
4 Enter the desired hour and minute you wish to
end this feature.
5 Press {*} to select “AM” or “PM”. i {OK}
6 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Note:
L To correct a digit:
Base unit: Press {7} or {8} to move the
cursor to the digit, then make the correction.
Handset: Press {<} or {>} to move the cursor
to the digit, then make the correction.
Turning night mode on/off
: Base unit / Y Handset
1 {MENU} i {#}{2}{3}{8}
2 {V}/{^}: Select “On” or “Off”. i {SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Note:
L When the night mode is turned on, 3 is
displayed.
For assistance, please visit http://www.panasonic.com/help
Alarm
An alarm sounds at the set time for 3 minutes once
or daily. Alarm can be set for each handset.
Important:
L Set the date and time beforehand (page 17).
Y Handset
1 {MENU} i {#}{7}{2}{0}
2 {V}/{^}: Select the desired alarm option. i
{SELECT}
Off Turns alarm off. Go to step 5.
Once An alarm sounds once at the set
time. Enter the desired month,
date, and year.
Daily An alarm sounds daily at the set
time.
3 Set the desired time. i {OK}
4 {V}/{^}: Select the desired ringer tone. i
{SELECT}
L We recommend selecting a ringer tone
different from the ringer tone set for outside
calls.
5 {V}/{^}: “Save” i {SELECT} i {OFF}
L When the alarm is set, E is displayed.
Note:
L To stop the alarm, press any dial key or place
the handset on the charger.
L When the handset is in use, the alarm will not
sound until the handset is in standby mode.
L If you select “Once”, the setting changes to
“Off” after the alarm sounds.
L The ringer volume for alarm follows the higher
volume level of the 2 lines (page 29).
L When the ringer volume for outside calls of the 2
lines is set to off (page 29), the alarm sound is
heard at a low level.
Customer support
The base unit and handset can display the Internet
address where you can download the operating
instructions or get further information for this
product by using your computer.
: Base unit / Y Handset
1 {MENU} i {#}{6}{8}{0}
31
Page 32
Programming
2 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Registering a unit
Operating additional handsets
Additional handsets
Up to 6 handsets can be registered to the base
unit.
Important:
L See page 5 for information on the available
model.
Registering a handset to the base
unit
The supplied handset and base unit are preregistered. If for some reason the handset is not
registered to the base unit, register the handset.
1 Handset:
{MENU} i {#}{1}{3}{0}
2 Base unit:
Press and hold {LOCATOR} for 5 seconds
until the registration tone sounds.
L If all registered handsets start ringing, press
the same button to stop. Then repeat this
step.
L The next step should be completed within
90 seconds.
3 Handset:
Press {OK}, then wait until a long beep
sounds.
Note:
L When you purchase an additional handset, refer
to the additional handset’s installation manual
for registration.
Deregistering a hands e t
A handset can cancel its own registration (or the
registration of another handset) that is stored in the
base unit. This allows the handset to end its
wireless connection with the system.
Y Handset
1 {MENU} i {#}{1}{3}{1}
2 {3}{3}{5} i {OK}
3 Select the handset you want to cancel by
pressing the desired handset(s) number.
L The selected handset number(s) flashes.
L To cancel a selected handset number,
press the number again. The number will
stop flashing.
4 {OK} i {V}/{^}: “Yes” i {SELECT}
L When you cancel a different handset than
the one you are now using, press {OFF} to
exit.
32
For assistance, please visit http://www.panasonic.com/help
Page 33
Using Caller ID service
Important:
L This unit is Caller ID compatible. To use Caller
ID features, you must subscribe to Caller ID
service. Contact your service
provider/telephone company for details.
Caller ID features
When an outside call is being received, the caller’s
name and phone number are displayed.
Caller information for the last 50 callers is logged in
the caller list from the most recent call to the
oldest.
L If the unit cannot receive caller information, the
following is displayed:
– “Out of area”: The caller dials from an
area which does not provide Caller ID service.
– “Private caller”: The caller requests not
to send caller information.
– “Long distance”: The caller makes a long
distance call.
L If the unit is connected to a PBX system, caller
information may not be received properly.
Contact your PBX supplier.
Missed calls
If a call is not answered, the unit treats the call as
a missed call. The display shows “Missed
call”. This lets you know if you should view the
caller list to see who called while you were away.
Phonebook name display
When caller information is received and it matches
a phone number stored in the phonebook, the
stored name in the phonebook is displayed and
logged in the caller list.
Group ringer tone for phonebook
This feature can help you identify who is calling by
using different ringer tones for different groups of
callers. When adding an entry to the phonebook,
you can assign it to the desired group (page 22).
When a call is received from a caller assigned to a
group, the group’s ringer you selected rings after
the caller information is displayed. If you select
“No ringer ID” (default), the unit uses the
ringer tone you selected for each line on page 29
when calls from this group are received.
Caller ID Service
: Base unit / Y Handset
1 Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU} i {#}{2}{8}{0}
2 {MENU}
3 {V}/{^}: “Group” i {SELECT}
4 {V}/{^}: Select the desired group. i
{SELECT}
5 {V}/{^}: Select the current setting of the group
ringer tone. i {SELECT}
6 {V}/{^}: Select the desired item. i {SAVE}
7 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Caller list
Important:
L Only 1 person can access the caller list at a
time.
Viewing the caller list and calling
back
: Base unit / Y Handset
1
Proceed with the operation for your unit.
Base unit: {CID}
Handset: {MENU} i {#}{2}{1}{3}
2 Press {V} to search from the most recent call,
or {^} to search from the oldest call.
3 Proceed with the operation for your unit.
Base unit:
– To call back, lift the corded handset.
– To exit, press {■} (EXIT).
Handset:
– To call back, press {C}.
– To exit, press {OFF}.
Note:
L In step 2;
– c and d indicate which line the caller
information was received from.
– If the item has already been viewed or
answered, “Q” is displayed, even if it was
viewed or answered using another unit.
For assistance, please visit http://www.panasonic.com/help
33
Page 34
Caller ID Service
– if an arrow (>) is displayed after the number,
the whole phone number is not shown.
Proceed with the operation for your unit.
Base unit:
Press {8} to see the remaining numbers. To
return to the previous display, press {7}.
Handset:
Press {>} to see the remaining numbers. To
return to the previous display, press {<}.
L In step 3, the unit automatically uses the line you
set in line selection mode (page 17) to call back.
When the line selection mode is set to “Auto”,
the indicated line (c or d) is used for the call.
If the indicated line is already being used or you
want to select the other line:
Base unit: Press {LINE 1} or {LINE 2}, then lift
the corded handset.
Handset: Press {CALL}, then press {LINE 1}
or {LINE 2}.
Editing a caller’s phone number
before calling back
You can edit a phone number in the caller list by
removing its area code and/or the long distance
code “1”.
: Base unit / Y Handset
1 Proceed with the operation for your unit.
Base unit: {CID}
Handset: {MENU} i {#}{2}{1}{3}
2 {V}/{^}: Select the desired entry.
3 Proceed with the operation for your unit.
Base unit: {EDIT}
Handset: {CALL}
4 Press {EDIT} repeatedly until the phone
number is shown in the desired format.
1 Local phone number
Example:
321-5555
2 Area code – Local phone number
Example:
555-321-5555
3 1 – Area code – Local phone number
Example:
1-555-321-5555
5 Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
L If the indicated line is already being used or
you want to select the other line:
Base unit: Press {LINE 1} or {LINE 2},
then lift the corded handset.
Handset: Press {LINE 1} or {LINE 2}.
Caller ID number auto edit feature
Once you call back an edited number, the unit
remembers the Area Code and Format of the
Edited Number. Next time when someone calls
from the same Area Code, caller information is
customized by the unit as follows:
– When the call is being received, the Caller ID
number is displayed in the same Format as the
Edited Number.
– After the call is ended, the phone number of the
caller, when reviewed from the Caller list, is
displayed in the same Format as the Edited
Number.
For example, you can use this feature to set the
unit to ignore the area code of callers in your area
code, so that you can call these local numbers
using caller information without dialing the area
code.
To activate this feature, you must edit an item in
the caller list, then call that number. After that,
phone numbers from that caller’s area code are
edited automatically.
This feature can be turned on or off (page 28).
Note:
L Phone numbers from the 4 most recently edited
area codes are automatically edited.
L If you move to another area, you can turn this
feature off to erase previously edited area
codes. To use this feature again, turn it on and
reprogram the area codes you want to edit once
again.
Erasing selected caller information
: Base unit / Y Handset
1
Proceed with the operation for your unit.
Base unit: {CID}
Handset: {MENU} i {#}{2}{1}{3}
2 {V}/{^}: Select the desired entry.
3 {ERASE}
34
For assistance, please visit http://www.panasonic.com/help
Page 35
Caller ID Service
4 {V}/{^}: “Yes” i {SELECT}
5 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Erasing all caller information
: Base unit / Y Handset
1
Proceed with the operation for your unit.
Base unit: {CID}
Handset: {MENU} i {#}{2}{1}{3}
2 {ERASE}
3 {V}/{^}: “Yes” i {SELECT}
4 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Storing caller information into the
phonebook
: Base unit
1
{CID}
2 {V}/{^}: Select the desired entry.
L T o edit the number, press {EDIT} repeatedly
until the phone number is shown in the
desired format.
3 {SAVE}
4 If necessary, edit the party’s name (16
characters max.). i {OK}
5 If necessary, edit the party’s phone number
(24 digits max.). i {OK}
6 {V}/{^}: Select the desired group (page 22).
i {SELECT} 2 times
L To add other entries, repeat from step 2.
7 {■} (EXIT)
Y Handset
5 If necessary, edit the party’s phone number
(24 digits max.). i {OK}
6 {V}/{^}: Select the desired group (page 22).
i {SELECT} 2 times
L To add other entries, repeat from step 2.
7 {OFF}
1 {MENU} i {#}{2}{1}{3}
2 {V}/{^}: Select the desired entry.
L To edit the number, press {SAVE}. i
Press {EDIT} repeatedly until the phone
number is shown in the desired format. i
{SAVE} i Go to step 4.
3 Press {SAVE} 2 times.
4 If necessary, edit the party’s name (16
characters max.). i {OK}
For assistance, please visit http://www.panasonic.com/help
35
Page 36
Answering System
Answering system
The answering system can answer and record
calls for you when you are unavailable to answer
the phone.
Important:
L Only 1 person can access the answering system
(listen to messages, record a greeting message,
etc.) at a time.
L When callers leave messages, the unit records
the day and time of each message. Make sure
the date and time have been correctly set (page
17).
Memory capacity
The total recording capacity (including your
greeting message) is about 40 minutes. A
maximum of 64 messages can be recorded.
Note:
L If message memory becomes full, the ANSWER
ON indicator on the base unit flashes rapidly.
L When the message memory becomes full:
– If you use the pre-recorded greeting
message, the unit automatically switches to
another pre-recorded greeting message
asking callers to call again later.
– If you recorded your own greeting message,
the same message is still announced to
callers even though their messages are not
recorded.
Call screening
: Base unit / Y Handset
While a caller is leaving a message, you can listen
to the call through the base unit’s or handset’s
speaker. To adjust the speaker volume, press {^}
or {V} repeatedly.
You can answer the call by lifting the corded
handset from the base unit or pressing {C} on
the handset.
Note:
L To turn this feature off, see page 41.
Greeting message
When the unit answers a call, callers are greeted
by a greeting message. You can record your own
greeting message or use a pre-recorded greeting
message.
Recording your greeting message
Greeting messages can be recorded in one of the
two following ways:
– for line 1 and line 2 with different greetings (2
minutes max. for each greeting)
– for line 1 and line 2 with the same greeting (2
minutes max.). Select “Line1&Line2” in step
2.
: Base unit
Turning the answering system on/off
: Base unit
■ To turn on:
Press {ANSWER SELECT} repeatedly to select
the desired line(s). i {ANSWER ON}
L The ANSWER ON indicator lights up.
■ To turn off:
Press {ANSWER ON}.
L The ANSWER ON indicator turns off.
36
For assistance, please visit http://www.panasonic.com/help
1 {MENU} i {#}{3}{0}{2}
2 {V}/{^}: Select the desired line(s). i
{SELECT}
3 After the base unit beeps, speak clearly about
20 cm (8 inches) away from the MIC.
4 Press {STOP} to stop recording.
L The message you have recorded is played
after the beep.
5 {■} (EXIT)
Using a pre-recorded greeting
message
If you erase or do not record your own greeting
message, the unit plays a pre-recorded greeting
message for callers and asks them to leave
messages.
Page 37
Answering System
Playing back the greeting message
: Base unit
1
{MENU} i {#}{3}{0}{3}
2 {V}/{^}: Select the desired line(s). i
{SELECT}
3 {■} (EXIT)
Erasing your greeting message
If you erase your own greeting message, the unit
plays a pre-recorded greeting message for callers.
: Base unit
1 {MENU} i {#}{3}{0}{3}
2 {V}/{^}: Select the desired line(s). i
{SELECT}
3 Press {ERASE} while your greeting message
is playing.
4 {■} (EXIT)
Listening to messages using the base unit
When new messages have been recorded, the
message indicator on the base unit flashes.
Press {6}.
L If new messages have been recorded, the base
unit plays back new messages.
L If there are no new messages, the base unit
plays back all messages.
Playing back messages for the desired line(s)
Press {ANSWER SELECT} repeatedly to select
the desired line(s), then press {6}.
Operating the answering system
Key Operation
{PAUSE} Pause message
To resume playback, press
{6}.
{■} (STOP) Stop playback
To exit the playback mode,
press {■} (EXIT).
{ERASE} Erase currently playing
message
*1 If pressed within the first 5 seconds of a
message, the previous message is played.
Calling back (Caller ID subscribers
only)
If caller information was received for the call, you
can call the caller back while listening to a
message.
1 Press {EDIT} during playback.
L To edit the number before calling back,
press {EDIT} repeatedly until the phone
number is shown in the desired format
(page 34).
2 Lift the corded handset.
L The unit automatically uses the line you set
in line selection mode (page 17) to call back.
When the line selection mode is set to
“Auto”, the indicated line (c or d) is
used for the call. If the indicated line is
already being used or you want to select the
other line, press {LINE 1} or {LINE 2}, then
lift the corded handset.
Erasing all messages
Erasing all messages for both line 1 and line 2
1 {ERASE}
L W and X are displayed.
2 Press {ERASE} again.
Key Operation
{^} or {V} Adjust the speaker volume
{7} Repeat message
(during playback)
{8} Skip message
(during playback)
For assistance, please visit http://www.panasonic.com/help
*1
Erasing all messages for the desired line(s)
Press {ANSWER SELECT} repeatedly to select
the desired line(s), then press {ERASE} 2 times.
37
Page 38
Answering System
Listening to messages using the handset
When new messages have been recorded, “New
message” is displayed.
1 To play new messages:
{MENU} i {#}{3}{2}{3}
To play all messages:
{MENU} i {#}{3}{2}{4}
2 When finished, press {OFF}.
Note:
L To switch to the receiver, press {C}.
Playing back messages for the desired line(s)
1 {MENU} i {V}/{^}: “Answering device”
i {SELECT}
2 Press {8} repeatedly to select the desired
line(s).
3 {V}/{^}: “Play new msg.” or “Play all
msg.” i {SELECT}
4 When finished, press {OFF}.
Operating the answering system
You can also operate the answering system by
pressing dial keys on the handset.
To use the following commands:
{MENU} i {V}/{^}: “Answering device” i
{SELECT} i Press {8} repeatedly to select
the desired line(s) if necessary.
Key Operation
{^} or {V} Adjust the receiver/speaker
{1} or {<} Repeat message (during
{2} or {>} Skip message (during
{3} Enter the “Settings” menu
{4} Play new messages
{5} Play all messages
{PAUSE} Pause message
{9} Stop playback
{0} Turn answering system off
{*}{4} Erase currently playing
volume
playback)
playback)
message
*1
*2
Key Operation
{*}{5} Erase all messages
{#}{1}
i {8}
{#}{2}
i {8}
{#}{0}
i {8}
*1 If pressed within the first 5 seconds of a
message, the previous message is played.
*2 To resume playback:
{V}/{^}: “Playback” i {SELECT}
*3 For English voice guidance only:
When you press a line selection number
({#}{1}, {#}{2}, or {#}{0}), the selected
line(s) is announced, then press {8}.
Turn answering system on for
*3
line 1 only
Turn answering system on for
*3
line 2 only
Turn answering system on for
*3
both line 1 and line 2
Calling back (Caller ID subscribers
only)
If caller information was received for the call, you
can call the caller back while listening to a
message.
1 Press {MENU} during playback.
2 {V}/{^}: “Edit & Call” i {SELECT}
L To edit the number before calling back,
press {EDIT} repeatedly until the phone
number is shown in the desired format
(page 34).
3 {C}
L The unit automatically uses the line you set
in line selection mode (page 17) to call back.
When the line selection mode is set to
“Auto”, the indicated line (c or d) is
used for the call. If the indicated line is
already being used or you want to select the
other line, press {LINE 1} or {LINE 2}.
Erasing all messages
Erasing all messages for both line 1 and line 2
1 {MENU} i {#}{3}{2}{5}
2 {V}/{^}: “Yes” i {SELECT}
3 {OFF}
38
For assistance, please visit http://www.panasonic.com/help
Page 39
Answering System
Erasing all messages for the desired line(s)
1 {MENU} i {V}/{^}: “Answering device”
i {SELECT}
2 Press {8} repeatedly to select the desired
line(s).
3 {V}/{^}: “Erase all” i {SELECT}
4 {V}/{^}: “Yes” i {SELECT}
5 {OFF}
Remote operation
Using a touch-tone phone, you can call your phone
number from outside and access the unit to listen
to messages or change answering system
settings. The unit’s voice guidance prompts you to
press certain dial keys to perform different
operations.
Remote access code
A 3-digit remote access code must be entered
when operating the answering system remotely.
This code prevents unauthorized parties from
listening to your messages remotely. The default
setting is “111”.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{3}{0}{6}
2 Enter the desired 3-digit remote access code.
i {SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Using the answering system
remotely
1
Dial your phone number from a touch-tone
phone.
2 After the greeting message starts, enter your
remote access code.
L The unit will announce the number of new
messages.
L The voice guidance announcements are
different depending on the voice guidance
language setting (page 16).
3 Follow the voice guidance prompts as
necessary or control the unit using remote
commands (page 40).
4 When finished, hang up.
Voice guidance
When the English voice guidance is selected
During remote operation, the unit’s voice guidance
starts and prompts you to press {1} to perform a
specific operation, or press {2} to listen to more
available operations. Operations are presented by
voice guidance in the following order:
– Play back all messages
– Play back new messages
– Record your message
– Erase all messages
– Record your greeting message
Note:
L If you do not press any dial keys within 10
seconds after a voice guidance prompt, the unit
disconnects your call.
When the Spanish voice guidance is selected
To start the voice guidance, press {9}. The voice
guidance announces the available remote
commands (page 40). See the Spanish quick
guide for details.
Note:
L If you do not press any dial keys within 10
seconds after a voice guidance prompt, the unit
disconnects your call.
For assistance, please visit http://www.panasonic.com/help
39
Page 40
Answering System
Remote commands
You can press dial keys to access certain
answering system functions without waiting for the
voice guidance to prompt you.
1 Select the desired line(s) while you are
accessing the answering system if necessary.
For line 1: {#}{1}
For line 2: {#}{2}
For line 1 and line 2: {#}{0}
2 Press the desired dial keys.
Key Operation
{1} Repeat message (during
playback)
{2} Skip message (during
playback)
{4} Play new messages
{5} Play all messages
{6} Play greeting message
{#}{1}{7} R ecord a greeting message
for line 1 only
{#}{2}{7} R ecord a greeting message
for line 2 only
{#}{0}{7} Record a common greeting
message for both line 1 and
line 2
{#}{1}{8} Turn answering system on
for line 1 only
{#}{2}{8} Turn answering system on
for line 2 only
{#}{0}{8} Turn answering system on
for both line 1 and line 2
{9} Stop recording
Stop playback
Start voice guidance
{0} Turn answering system off
{*}{4} Erase currently playing
message
{*}{5} Erase all messages
{*}{6} Erase greeting message
(during greeting message
playback)
{*}{#} End remote operation (or
hang up)
*1
*2
*3
*1 If pressed within the first 5 seconds of a
message, the previous message is played.
*2 For English voice guidance only:
T o resume operation, enter a remote command
within 3 seconds, or the voice guidance starts.
*3 For Spanish voice guidance only
Turning on the answering system
remotely
If the answering system is turned off, you can turn
it on remotely.
Important:
L The answering system can be remotely turned
on only for the line which you have currently
selected in “Turning the answering system
on/off”, page 36.
1 Dial your phone number.
2 Let the phone ring 15 times.
3 Enter your remote access code after the beep.
L The greeting message is played back.
L You can either hang up, or from a touch-
tone phone you can enter your remote
access code and begin remote operation
(page 39).
Note:
L If you want to turn on the answering system for
the line which has not been selected in “Turning
the answering system on/off”, page 36, enter the
desired remote commands, {#}{1}{8},
{#}{2}{8}, or {#}{0}{8} (refer to the column to
the left) to turn on and access the other line.
Skipping the greeting message to
leave a message
Y ou can leave a message just as any outside caller
can. Call your phone number from a touch-tone
phone. When the answering system picks up,
press {*} to skip the greeting message and
record your message after the beep.
40
For assistance, please visit http://www.panasonic.com/help
Page 41
Answering system settings
Number of rings before the unit
answers calls
You can change the number of times the phone
rings “Ring count” before the unit answers
calls. You can select 2 to 7 rings, or “Toll
saver”.
The default setting is “4”.
“Toll saver”: The unit’s answering system
answers at the end of the 2nd ring when new
messages have been recorded, or at the end of the
4th ring when there are no new messages. If you
call your phone from outside to listen to new
messages (page 39), you will know that there are
no new messages when the phone rings for the
3rd time. You can then hang up without being
charged for the call.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{2}{1}{1}
2 {V}/{^}: Select the desired setting. i
{SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
For voice mail service subscribers
If you subscribe to a flat-rate service package that
includes Caller ID, call waiting, voice mail, and
unlimited local/regional/long distance calls, please
note the following:
L To use the voice mail service provided by your
service provider/telephone company rather than
the unit’s answering system, turn off the
answering system (page 36).
L To use this unit’s answering system rather than
the voice mail service provided by your service
provider/telephone company, please contact
your service provider/telephone company to
deactivate your voice mail service.
If your service provider/telephone company
cannot do this:
– Set this unit’s “Ring count” setting so that
this unit’s answering system answers calls
before the voice mail service of your service
Answering System
provider/telephone company does. It is
necessary to check the number of rings
required to activate the voice mail service
provided by your service provider/telephone
company before changing this setting.
– Change the number of rings of the voice mail
service so that the answering system can
answer the call first. To do so, contact your
service provider/telephone company.
Caller’s recording time
Y ou can change the maximum message recording
time allotted to each caller. The default setting is
“3min”.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{3}{0}{5}
2 {V}/{^}: Select the desired setting. i
{SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Turning the call screening on/off
You can set the call screening feature “On” or
“Off”. For details, see page 36. The default
setting is “On”.
: Base unit / Y Handset
1 {MENU} i {#}{3}{1}{0}
2 {V}/{^}: Select the desired setting. i
{SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
For assistance, please visit http://www.panasonic.com/help
41
Page 42
Voice Mail Service
Voice mail service
Voice mail is an automatic answering service
offered by your service provider/telephone
company. Af ter you subscribe to this service, your
service provider/telephone company’s voice mail
system answers calls for you when you are
unavailable to answer the phone or when your line
is busy. Messages are recorded by your service
provider/telephone company, not your telephone.
Please contact your service provider/telephone
company for details of this service.
Important:
L To use the voice mail service provided by your
service provider/telephone company rather than
the unit’s answering system, turn off the
answering system (page 36). For details, see
page 41.
Voice Mail message indication
The unit lets you know that you have new voice
mail messages by showing “VoiceMail:Line1”
and/or “VoiceMail:Line2” on the display.
To listen to your voice mail messages, you must
dial your service provider/telephone company’s
voice mail access number.
Note:
L If the base unit or handset still indicates there
are new messages even after you have listened
to all new messages, turn it off by pressing and
holding {OFF} on the handset until a beep
sounds.
L If your voice mail service uses voice mail tones
and the message is over 3 minutes long, the unit
may not indicate new messages.
Turn this feature off when:
– You do not subscribe to voice mail service.
– Your service provider/telephone company does
not send voice mail tones.
– Your phone is connected to a PBX.
If you are not sure which setting is required,
contact your service provider/telephone company.
Turning VM tone detection on/off
The default setting is “On”.
Program this setting using either the base unit or
one of the handsets.
: Base unit / Y Handset
1 {MENU} i {#}{3}{3}{2}
2 {V}/{^}: Select the desired setting. i
{SAVE}
3 Proceed with the operation for your unit.
Base unit: {■} (EXIT)
Handset: {OFF}
Voice mail (VM) tone detection
Your service provider/telephone company sends
special signals (sometimes called “voice mail
tones” or “stutter tones”) to the unit to let you know
you have new voice mail messages. If you hear a
series of dial tones followed by a continuous dial
tone after you lift the corded handset or press
{C}, you have new voice mail messages.
Minutes after you hang up a call or after the phone
stops ringing, your unit checks the phone line to
see if new voice mail messages have been
recorded.
42
For assistance, please visit http://www.panasonic.com/help
Page 43
Intercom/Locator
Intercom
Intercom calls can be made:
– between the base unit and handset.
– between handsets.
Note:
L When paging unit(s) for an intercom call, the
paged unit(s) beeps for 1 minute.
L If you receive an outside call while talking on the
intercom, an interrupt tone will be heard (page
28).
– To answer the call with the base unit, place
the corded handset on the cradle, then lift it
again. If the speakerphone is used, press
{SP-PHONE} 2 times. You can also answer
the call by pressing {LINE 1} or {LINE 2}
after hanging up the intercom.
– To answer the call with the handset, press
{OFF}, then press {C}.
Making an intercom call
: Base unit
1
{INTERCOM}
L Lift the corded handset if needed.
L When only 1 handset is registered, the base
unit pages the handset automatically.
2 T o p age a specific handset, enter the handset
number.
To page all handsets, press {0} or wait for a
few seconds.
L To stop paging, press {INTERCOM}.
3 When you finish talking, press {INTERCOM}
or place the corded handset on the cradle.
Y Handset
1 {INTERCOM}
2 To page the base unit, press {0}.
To page another handset, enter its extension
number.
L To stop paging, press {OFF}.
3 When you finish talking, press {OFF}.
Answering an intercom call
: Base unit
1
Lift the corded handset or press {INTERCOM}
to answer the page.
2 When you finish talking, place the corded
handset on the cradle or press {INTERCOM}.
Y Handset
1 Press {C} to answer the page.
2 When you finish talking, press {OFF}.
Note for base unit and handset:
L The ringer volume for intercom calls follows the
higher volume level of the 2 lines (page 29).
Even when the ringer volume for both lines is set
to off (page 29), the base unit and/or handset
still rings at a low level for intercom calls.
Transferring calls
Outside calls can be transferred between 2 people.
: Base unit
1 During an outside call, press {INTERCOM} to
put the call on hold.
L When only 1 handset is registered, the base
unit pages the handset automatically.
2 To page a specific handset, enter the
extension number.
To page all handsets, press {0} or wait for a
few seconds.
3 Wait for the paged party to answer.
L If the paged party does not answer, press
the flashing {LINE 1} or {LINE 2} to return
to the outside call.
4 Place the corded handset on the cradle or
press {INTERCOM}.
L The outside call is being routed to the
handset.
Y Handset
1 During an outside call, press {INTERCOM}
once to put the call on hold.
For assistance, please visit http://www.panasonic.com/help
43
Page 44
Intercom/Locator
2 To page the base unit, press {0}.
To page another handset, enter its extension
number.
3 Wait for the paged party to answer.
L If the paged party does not answer, press
{LINE 1} or {LINE 2} that is flashing on the
handset to return to the outside call.
4 {OFF}
L The outside call is being routed to the
destination unit.
Answering a transferred call
: Base unit
Lift the corded handset or press {SP-PHONE} to
answer the page.
Y Handset
Press {C} to answer the page.
Note for base unit and handset:
L After the paging party disconnects, you can talk
to the outside caller.
Conference calls
3 people can establish a conference call.
Conferenc e call with 2 outside calls
While you are talking with an outside caller, you
can make or answer a 2nd call on the other line,
and then combine the calls to establish a
conference call.
: Base unit
1 During an outside call, press {HOLD}.
2 T o answer a 2nd call, press {LINE 1} or {LINE
2}.
To make a 2nd call, press {LINE 1} or {LINE
2}, then dial the phone number.
3 When the 2nd call is connected, press
{MENU}. i {V}/{^}: “Conference” i
{SELECT}
L The 2 calls are combined.
L T o hang up only one line, press {LINE 1} or
{LINE 2} for the party with which you want
to continue talking.
L T o put both lines on hold, press {HOLD}. T o
talk with only one caller, press {LINE 1} or
{LINE 2} for the party with which you want
to continue talking. T o resume both lines,
press {CONF}.
Y Handset
1 During an outside call, press {HOLD} 2 times.
2 T o answer a 2nd call, press {LINE 1} or {LINE
2}.
To make a 2nd call, press {LINE 1} or {LINE
2}, then dial the phone number.
3 When the 2nd call is connected, press
{MENU}. i {V}/{^}: “Conference” i
{SELECT}
L The 2 calls are combined.
L T o hang up only one line, press {LINE 1} or
{LINE 2} for the party with which you want
to continue talking.
L T o put both lines on hold, press {HOLD}. T o
talk with only one caller, press {LINE 1} or
{LINE 2} for the party with which you want
to continue talking. T o resume both lines,
press {CONF}.
Conference call with an outside call
and an intercom call
While you are talking with an outside caller, one
more extension can join the conversation and
establish a conference call.
: Base unit
1 During an outside call, press {INTERCOM} to
put the call on hold.
L When only 1 handset is registered, the base
unit pages the handset automatically.
2 T o page a specific handset, enter its extension
number.
To page all handsets, press {0} or wait for a
few seconds.
3 When the paged party answers, press
{CONF}.
L The 2 calls are combined.
L To leave the conference, place the corded
handset on the cradle or press {SP-
PHONE}. The other 2 parties can continue
the conversation.
Y Handset
44
For assistance, please visit http://www.panasonic.com/help
Page 45
1 During an outside call, press {INTERCOM}
once to put the call on hold.
2 To page the base unit, press {0}.
To page another handset, enter its extension
number.
3 When the paged party answers, press
{CONF}.
L The 2 calls are combined.
L To leave the conference, press {OFF}. The
other 2 parties can continue the
conversation.
Note for the base unit and handset:
L The outside call can be put on hold by pressing
{HOLD}. Only the person who placed the call on
hold can resume the full conference by pressing
{CONF}.
Handset locator
You can locate a misplaced handset by paging it.
1 Base unit:
{LOCATOR}
L All registered handsets beep for 1 minute.
2 To stop paging:
Base unit:
Press {LOCATOR}.
Handset:
Press {INTERCOM}, then press {OFF}.
Note:
L Even when the ringer volume for both lines is set
to off (page 29), the handset still rings at a low
level for paging.
Intercom/Locator
For assistance, please visit http://www.panasonic.com/help
45
Page 46
Useful Information
Wall mounting for charger
1 Drive the screws (not supplied) into the wall.
25.4 mm
(1 inch)
Screws
(120 V AC, 60 Hz)
2 Mount the charger (A), then slide it down (B)
and to the right (C) until it is secure.
A
B
C
Belt clip
You can hang the handset on your belt or pocket
using the supplied belt clip.
To attach the belt clip
To remove the belt clip
Headset (optional)
Connecting a headset to the handset allows for
hands-free conversations. We recommend using
the Panasonic headset noted on page 4.
46
For assistance, please visit http://www.panasonic.com/help
Page 47
Useful Information
Error messages
If the unit detects a problem, one of the following messages is shown on the display.
Display message Cause/solution
Busy L The called handset or base unit is in use.
L Other units are in use and the system is busy. Try again later.
L Privacy mode is on for the call you tried to join (page 21).
L The handset you are using is too far from the base unit. Move closer
and try again.
L The handset’s registration may have been canceled. Re-register the
handset (page 32).
Check tel line 1
Check tel line 2
Error!! L The handset’s registration has failed. Move the base unit and
Failed L Phonebook copy failed (page 24). Confirm the other unit (the
Incomplete L Phonebook copy is incomplete. The receiver’s phonebook memory
Memory full L The phonebook memory is full. Erase unnecessary entries (page
Messages full L Message memory is full. Erase unnecessary messages (page 37,
No link to base.
Reconnect AC adaptor.
Use rechargeable
battery.
You must first
subscribe to Caller
ID.
L The supplied telephone line cord has not been connected yet or not
connected properly. Check the connections (page 13).
L If you use the unit as a single-line telephone only, erase the message
as follows:
To erase “Check tel line 1”, press {MENU}. i
{#}{1}{8}{9}
To erase “Check tel line 2”, press {MENU}. i
{#}{1}{9}{0}
When a power failure occurs, the message is displayed again. Erase
again as above.
handset away from all electrical appliances and try again.
L Recording was too short. Try again.
receiver) is in standby mode and try again.
is full. Erase the unnecessary phonebook entries (page 23) from the
other unit (the receiver) and try again.
23).
L Message memory is full. Erase unnecessary messages (page 37,
38).
38).
L The handset has lost communication with the base unit. Move closer
to the base unit and try again.
L Unplug the base unit’s AC adaptor to reset the unit. Reconnect the
adaptor and try again.
L The handset’s registration may have been canceled. Re-register the
handset (page 32).
L A wrong type of batteries such as Alkaline or Manganese was
inserted. Use only the rechargeable Ni-MH batteries noted on page
4, 15.
L You must subscribe to Caller ID service. Once you receive caller
information after subscribing to Caller ID service, this message will
not be displayed.
For assistance, please visit http://www.panasonic.com/help
47
Page 48
Useful Information
Troubleshooting
If you still have difficulties after following the instructions in this section, disconnect the base unit’s AC
adaptor, then reconnect the base unit’s AC adaptor. Remove the batteries from the handset, and then
insert the batteries into the handset again.
General use
Problem Cause/solution
The unit does not work. L Make sure the batteries are installed correctly (page 15).
L Fully charge the batteries (page 15).
L Check the connections (page 12).
L Unplug the base unit’s AC adaptor to reset the unit.
Reconnect the adaptor and try again.
L The handset has not been registered to the base unit.
Register the handset (page 32).
I cannot hear a dial tone. L The base unit’s AC adaptor or telephone line cord is not
w is flashing. L The handset has not been registered to the base unit.
connected. Check the connections.
L If you are using a splitter to connect the unit, remove the
splitter and connect the unit to the wall jack directly. If the
unit operates properly, check the splitter.
L Disconnect the base unit from the telephone line and
connect the line to a known working telephone. If the
working telephone operates properly, contact our service
personnel to have the unit repaired. If the working
telephone does not operate properly, contact your service
provider/telephone company.
Register the handset (page 32).
L The handset is too far from the base unit. Move closer.
L The base unit’s AC adaptor is not connected. Check the
connections.
L You are using the base unit or handset in an area with high
electrical interference. Re-position the base unit and use
the handset away from interference sources.
Programmable set tings
Problem Cause/solution
I have changed the display language to
a language I cannot read.
While programming, the unit starts to
ring.
I cannot register a handset to a base
unit.
48
For assistance, please visit http://www.panasonic.com/help
L Change the display language (page 16).
L A call is being received. Answer the call and start again
after hanging up.
L The maximum number of handsets (6) is already
registered to the base unit. Cancel unused handset
registrations from the base unit (page 32).
L Place the handset and the base unit away from other
electrical appliances.
Page 49
Useful Information
Battery recharge
Problem Cause/solution
The handset beeps and/or 3
flashes.
I fully charged the batteries, but 3
still flashes or 4 is displayed.
I fully charged the batteries, but the
operating time seems to be shorter.
Making/answering calls, intercom
Problem Cause/solution
Noise is heard, sound cuts in and out. L You are using the base unit or handset in an area with high
The base unit and/or handset does not
ring.
I cannot make a call. L The dialing mode may be set incorrectly. Change the
I cannot make long distance calls. L M ake sure that you have long distance service.
L Battery charge is low. Fully charge the batteries (page 15).
L Clean the charge contacts and charge again (page 16).
L It is time to replace the batteries (page 15).
L Clean the battery ends (S, T) and the charge contacts
with a dry cloth, and charge again.
electrical interference. Re-position the base unit and use
the handset away from sources of interference.
L Move closer to the base unit.
L If you use a DSL/ADSL service, we recommend
connecting a DSL/ADSL filter between the base unit and
the telephone line jack. Contact your DSL/ADSL provider
for details.
L The ringer volume is turned off. Adjust the ringer volume
(page 29).
L Night mode is turned on. Turn it off (page 31).
setting (page 16).
L The handset is too far from the base unit. Move closer and
try again.
Caller ID
Problem Cause/solution
Caller information is not displayed. L You must subscribe to Caller ID service. Contact your
service provider/telephone company for details.
L If your unit is connected to any additional telephone
equipment such as a Caller ID box or cordless telephone
line jack, plug the unit directly into the wall jack.
L If you use a DSL/ADSL service, we recommend
connecting a DSL/ADSL filter between the base unit and
the telephone line jack. Contact your DSL/ADSL provider
for details.
L The name display service may not be available in some
areas. Contact your service provider/telephone company
for details.
L Other telephone equipment may be interfering with this
unit. Disconnect the other equipment and try again.
For assistance, please visit http://www.panasonic.com/help
49
Page 50
Useful Information
Problem Cause/solution
Caller information is displayed late. L Depending on your service provider/telephone company,
The caller list/incoming phone numbers
are not edited automatically.
I cannot dial the phone number edited
in the caller list.
Time on the unit is shifted. L Incorrect time information from incoming Caller ID
The 2nd caller’s information is not
displayed during an outside call.
Answering system
the unit may display the caller’s information at 2nd ring or
later.
L Move closer to the base unit.
L The Caller ID number auto edit feature is turned off. Turn
it on and try again (page 28).
L You need to call back the edited number to activate Caller
ID number auto edit.
L The phone number you dialed might have been edited
incorrectly (for example, the long distance “1” or the area
code is missing). Edit the phone number with another
pattern (page 34).
changes the time. Set the time adjustment to “Manual”
(off) (page 29).
L In order to use Caller ID, call waiting, or Call Waiting Caller
ID (CWID), you must first contact your service
provider/telephone company and subscribe to the desired
service.
After subscribing, you may need to contact your service
provider/telephone company again to activate this specific
service, even if you already subscribed to both Caller ID
and Call Waiting with Caller ID services (CWID).
Problem Cause/solution
The unit does not record new
messages.
I cannot operate the answering system. L Someone is using the unit. Wait for the other user to fini sh.
50
For assistance, please visit http://www.panasonic.com/help
L The answering system is not turned on for the line you
wish to record messages from. Select the desired line or
both lines, then turn the answering system on (page 36).
L The message memory is full. Erase unnecessary
messages (page 37).
L The answering system is activated for both lines, and the
1st caller is leaving a voice message. The 2nd caller
cannot leave a message, but the caller information will be
stored (page 33).
L If you subscribe to the voice mail service, messages are
recorded by your service provider/telephone company not
your telephone. Change the unit’s number of rings setting
or contact your service provider/telephone company
(page 41).
L A caller is leaving a message. Wait for the caller to finish.
L The handset is too far from the base unit. Move closer.
Page 51
Useful Information
Problem Cause/solution
I cannot operate the answering system
remotely.
While recording a greeting message or
listening to messages, the unit rings
and recording stops.
Liquid damage
Problem Cause/solution
Liquid or other form of moisture has
entered the base unit/handset.
Caution:
L To avoid permanent damage, do not use a microwave oven to speed up the drying process.
L You are entering the wrong remote access code. If you
forgot the remote access code, store a new remote
access code (page 39).
L Press each key firmly.
L The answering system is turned off. Turn it on (page 40).
L You are using a rotary/pulse telephone. Try again using a
touch-tone phone.
L A call is being received. Answer the call and try again
later.
L Disconnect the AC adaptor and telephone line cord from
the base unit. Remove the batteries from the handset and
leave to dry for at least 3 days. After the base unit/handset
are completely dry, reconnect the AC adaptor and
telephone line cord. Insert the batteries and charge fully
before use.
For assistance, please visit http://www.panasonic.com/help
51
Page 52
Useful Information
FCC and other information
This equipment complies with Part 68 of the
FCC rules and the requirements adopted by the
ACTA. On the bottom of this equipment is a
label that contains, among other information, a
product identifier in the format
US:ACJ----------.
If requested, this number must be provided to
the telephone company.
L Registration No............(found on the bottom
of the unit)
L Ringer Equivalence No. (REN).......0.1B (line
1 and line 2)
L Ringer Equivalence No. (REN: Under a power
failure).......1.0B (line 1)
A plug and jack used to connect this equipment
to the premises wiring and telephone network
must comply with the applicable FCC Part 68
rules and requirements adopted by the ACTA. A
compliant telephone cord and modular plug is
provided with the product. It is designed to be
connected to a compatible modular jack that is
also compliant.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may
result in the devices not ringing in response to
an incoming call. In most but not all areas, the
sum of RENs should not exceed five (5.0). To
be certain of the number of devices that may be
connected to a line, as determined by the total
RENs, contact the local telephone company. For
products approved after July 23, 2001, the REN
for the product is part of the product identifier
that has the format
US:AAAEQ##TXXXX. The digits represented by
## are the REN without a decimal point (e.g., 03
is a REN of 0.3).
If this equipment causes harm to the telephone
network, the telephone company will notify you
in advance that temporary discontinuance of
service may be required. But if advance notice
isn’t practical, the telephone company will notify
the customer as soon as possible. Also, you will
be advised of your right to file a complaint with
the FCC if you believe it is necessary.
The telephone company may make changes in
its facilities, equipment, operations or
procedures that could affect the operation of the
equipment. If this happens the telephone
company will provide advance notice in order
for you to make necessary modifications to
maintain uninterrupted service.
If trouble is experienced with this equipment, for
repair or warranty information, please contact a
Factory Service Center or other Authorized
Servicer. If the equipment is causing harm to
the telephone network, the telephone company
may request that you disconnect the equipment
until the problem is resolved.
Connection to party line service is subject to
state tariffs. Contact the state public utility
commission, public service commission or
corporation commission for information.
If your home has specially wired alarm
equipment connected to the telephone
line, ensure the installation of this equipment
does not disable your alarm equipment. If you
have questions about what will disable alarm
equipment, consult your telephone company or
a qualified installer.
This equipment is hearing aid compatible as
defined by the FCC in 47 CFR Section 68.316.
When you hold the phone to your ear, noise
might be heard in your Hearing Aid. Some
Hearing Aids are not adequately shielded from
external RF (radio frequency) energy. If noise
occurs, use an optional headset accessory or
the speakerphone option (if applicable) when
using this phone. Consult with your audiologist
or Hearing Aid manufacturer about the
availability of Hearing Aids which provide
adequate shielding to RF energy commonly
emitted by digital devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST CALLS
TO EMERGENCY NUMBERS:
1) Remain on the line and briefly explain to the
dispatcher the reason for the call.
52
For assistance, please visit http://www.panasonic.com/help
Page 53
Useful Information
2) Perform such activities in the off-peak hours,
such as early morning or late evenings.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including interference
that may cause undesired operation.
Privacy of communications may not be ensured
when using this phone.
CAUTION:
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate this device.
NOTE:
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
move the cordless telephone further away from
the TV or VCR. This will often reduce, or
eliminate, interference.
FCC RF Exposure Warning:
L This product complies with FCC radiation
exposure limits set forth for an uncontrolled
environment.
L To comply with FCC RF exposure
requirements, the base unit must be installed
and operated 20 cm (8 inches) or more
between the product and all person’s body
(excluding extremities of hands, wrist and
feet).
L This product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
L The handset may be carried and operated
with only the specific provided belt-clip. Other
non-tested belt-clips or similar body-worn
accessories may not comply and must be
avoided.
Notice:
L FCC ID can be found inside the battery
compartment or on the bottom of the units.
Compliance with TIA-1083 standard:
Telephone handsets identified with this logo
have reduced noise and interference when
used with T-Coil equipped hearing aids and
cochlear implants.
Compatible with
Hearing Aid T-Coil
T
TIA-1083
Some cordless telephones operate at
frequencies that may cause interference to
nearby TVs and VCRs. To minimize or prevent
such interference, the base of the cordless
telephone should not be placed near or on top of
a TV or VCR. If interference is experienced,
For assistance, please visit http://www.panasonic.com/help
53
Page 54
Useful Information
Notice
ENERGY STAR
As an
ENERGY STAR
Panasonic has determined that this product
meets the
energy efficiency.
registered mark.
ENERGY STAR guidelines for
®
Participant,
ENERGY STAR is a U.S.
54
For assistance, please visit http://www.panasonic.com/help
Page 55
Specifications
■ Standard:
DECT 6.0 (Digital Enhanced Cordless
Telecommunications 6.0)
■ Number of channels:
60 Duplex Channels
■ Frequency range:
1.92 GHz to 1.93 GHz
■ Duplex procedure:
TDMA (Time Division Multiple Access)
■ Channel spacing:
1,728 kHz
■ Bit rate:
1,152 kb it/s
■ Modulation:
GFSK (Gaussian Frequency Shift Keying)
■ RF transmission power:
115 mW (max.)
■ Voice c oding:
ADPCM 32 kbit/s
■ Power source:
120 V AC, 60 Hz
■ Power consumption:
Base unit:
Standby: Approx. 1.1 W
Maximum: Approx. 2.0 W
Charger:
Standby: Approx. 0.6 W
Maximum: Approx. 3.6 W
■ Operating conditions:
5 °C – 40 °C (41 °F – 104 °F), 20 % – 80 %
relative air humidity (dry)
■ Dimensions:
Base unit: Approx. 127 mm × 216 mm ×
155 mm
(5 inches × 8
Handset: Approx. 156 m m × 49 mm × 32 mm
1
/8 inches × 1 15/16 inches × 1 1/4 inches)
(6
Charger: Approx. 51 mm × 75 mm × 88 m m
(2 inches × 2
■ Mass (weight):
Base unit: Approx. 720 g (1.59 lb)
Handset: Approx. 130 g (0.29 lb)
Charger: Approx. 60 g (0.13 lb)
Note:
L Design and specifications are subject to change
without notice.
1
/2 inches × 6 3/32 inches)
15
/16 inches × 3 15/32 inches)
Useful Information
L The illustrations in these instructions may vary
slightly from the actual product.
For assistance, please visit http://www.panasonic.com/help
55
Page 56
Useful Information
Customer services
Customer Services Directory
Obtain Product Information and Operating Assistance; locate your nearest Dealer or Service
Center; purchase Parts and Accessories; or make Customer Service and Literature requests by
visiting our Web Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at: 1-800-211-PANA (1-800-211-7262),
Monday - Friday 9 am to 9 pm; Saturday - Sunday 10 am to 7 pm, EST.
TTY users (hearing or speech impaired users) can call 1-877-833-8855.
Accessory Purchases
Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by
visiting our Web Site at:
http://www.pstc.panasonic.com
or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday - Friday 9 am to 9 pm, EST.)
Panasonic Service and Technology Company
20421 84th Avenue South, Kent, WA 98032
(We Accept Visa, MasterCard, Discover Card, American Express, and Personal Checks.)
TTY users (hearing or speech impaired users) can call 1-866-605-1277.
Service in Puerto Rico
Panasonic Puerto Rico, Inc.
San Gabriel Industrial Park, Ave. 65 de Infantería, Km. 9.5,
Carolina, Puerto Rico 00985
Phone (787)750-4300, Fax (787)768-2910
56
For assistance, please visit http://www.panasonic.com/help
Page 57
Warranty
Useful Information
PANASONIC CONSUMER
ELECTRONICS COMPANY, DIVISION
OF PANASONIC CORPORATION OF
NORTH AMERICA
One Panasonic Way,
Secaucus, New Jersey 07094
PANASONIC PUERTO RICO, INC.
San Gabriel Industrial Park,
Ave. 65 de Infantería, Km. 9.5,
Carolina, Puerto Rico 00985
Panasonic Telephone Products
Limited Warranty
Limited Warranty Coverage
If your product does not work properly because of a defect in materials or workmanship, Panasonic
Consumer Electronics Company or Panasonic Puerto Rico, Inc. (collectively referred to as “the
warrantor”) will, for the length of the period indicated on the chart below, which starts with the date
of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new
or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or
replace will be made by the warrantor.
Parts Labor
One (1) Year One (1) Year
During the “Labor” Limited Warranty period there will be no charge for labor. During the “Parts”
Limited Warranty period, there will be no charge for parts. You must mail-in your product prepaid
during the Limited Warranty period. This Limited Warranty excludes both parts and labor for
batteries, antennas, and cosmetic parts (cabinet). This Limited Warranty only applies to products
purchased and serviced in the United States or Puerto Rico. This Limited Warranty is extended only
to the original purchaser and only covers products purchased as new.
Ship-In Service
✄
For assistance in the continental U.S.A. in obtaining repairs please ship the product prepaid to:
PSTC (Panasonic) Exchange Center,
4900 George McVay Drive, Suite B Door #12, McAllen, TX 78503
When shipping the unit carefully pack in a padded shipping carton, include all accessories, and
send it prepaid. Include a letter detailing the complaint, a return address and provide a day time
phone number where you can be reached. P.O. Boxes are not acceptable. Keep the tracking
number for your records. A copy of valid registered receipt is required under the 1 year parts and
labor Limited Warranty.
panacare@us.panasonic.com
For Limited Warranty service for headsets if a headset is included with this product please follow
instructions above.
For assistance in Puerto Rico call Panasonic Puerto Rico, Inc. (787)-750-4300 or fax (787)-768-2910.
IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE PURCHASER WILL
BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE
OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL BE
CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF
PURCHASE.
For assistance, please visit http://www.panasonic.com/help
57
Page 58
Useful Information
Y
Limited Warranty Limits And Exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and
DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES
NOT COVER damages which occurred in shipment, or failures which are caused by products not
supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect, bug
infestation, mishandling, misapplication, alteration, faulty installation, set-up adjustments,
misadjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, introduction of sand, humidity or liquids, commercial use such as hotel, office,
restaurant, or other business or rental use of the product, or service by anyone other than a Factory
Service Center or other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY
COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY
BREACH OF THIS LIMITED WARRANTY. (As examples, this excludes damages for lost time, lost
calls or messages, cost of having someone remove or re-install an installed unit if applicable, travel
to and from the servicer. The items listed are not exclusive, but are for illustration only.) ALL
EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or
limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This Limited Warranty gives you specific legal rights and you may also have other rights which vary
from state to state. If a problem with this product develops during or after the Limited Warranty
period, you may contact your dealer or Service Center. If the problem is not handled to your
satisfaction, then write to the warrantor’s Consumer Affairs Department at the addresses listed for
the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE
OUR RESPONSIBILITY.
58
For assistance, please visit http://www.panasonic.com/help
Page 59
Index
A Additional handset: 32
Alarm: 31
Answering calls
Base unit: 19
Handset: 19
Answering system
Call screening: 36
Erasing messages: 37, 38, 40
Listening to messages: 37, 38, 39
Memory capacity: 36
Number of rings: 41
Recording time: 41
Remote access code: 39
Remote operation: 39
Ring count: 41
Toll saver: 41
Turning on/off: 36, 40
Auto talk: 19
B Battery: 15
Belt clip: 46
C Caller ID number auto edit: 34
Caller ID service: 33
Caller list
Calling back: 33
Editing: 34
Erasing: 34, 35
Storing: 35
Viewing: 33
Call privacy: 21
Call share: 21
Call waiting: 20
Call Waiting Caller ID: 20
Check tel line 1: 47
Check tel line 2: 13, 47
CID (Caller ID): 33
Conference calls: 44
Customer support: 31
D Date and time: 17
Dialing mode: 16
Direct commands: 28
Display
Contrast: 28
Language: 16
E Error messages: 47
F Flash: 20, 29
G Greeting message: 36
Group ringer tone: 33
Index
H Handset
Deregistration: 32
Locator: 45
Registration: 32
Headset, optional: 46
Hold: 20
I Intercom: 43
Interrupt tone: 28
K Key tone: 28
L Line mode: 29
Line selection mode: 17
M Making calls
Base unit: 18
Handset: 18
Memory full: 23, 37, 38, 47
Menu icons: 11
Messages full: 36, 37, 38, 47
Missed calls: 33
Mute: 20
N Night mode: 31
P Pause: 18
Phonebook
Adding: 22
Chain dial: 24
Copying: 24
Editing: 23
Erasing: 23
Group: 22
Power failure: 12, 13, 47
Programmable settings: 25
R Redialing: 18
Ringer tone: 29
Rotary/pulse service: 20
S SP-PHONE (Speakerphone): 18
T Time adjustment: 29
Transferring calls: 43
Troubleshooting: 48
TTY: 5, 56
V VM (Voice mail): 42
Voice guidance language: 16
Voice mail: 41, 42
Volume
Receiver: 10, 18
Ringer (Base unit): 19, 29
Ringer (Handset): 19, 29
Speaker: 10, 18
W Wall mounting: 46
59
Page 60
If you need assistance with setup or operation
1 Visit our website: http://www.panasonic.com/help
2 Contact us via the web at: http://www.panasonic.com/contactinfo
3 Call us at: 1-800-211-PANA (1-800-211-7262)
TTY users (hearing or speech impaired users) can call 1-877-833-8855.
When you ship the product
Carefully pack your unit, preferably in the original carton.
L
Attach a letter, detailing the symptom.
L
Send the unit to PSTC (Panasonic) Exchange Center, prepaid and adequately insured.
L
Do not send your unit to Panasonic Consumer Electronics Company listed below or to executive
L
or regional sales offices. These locations do not repair consumer products.
For your future reference
We recommend keeping a record of the following information to assist with any repair under warranty.
Serial No. Date of purchase
(found on the bottom of the base unit)
Name and address of dealer
Attach your purchase receipt here.
Panasonic Consumer Electronics Company,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Puerto Rico, Inc.
San Gabriel Industrial Park, Ave. 65 de Infantería, Km. 9.5, Carolina,
Puerto Rico 00985
Copyright:
This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal
use only. All other reproduction, in whole or in p art, is prohibited without the written consent of Panasonic
Communications Co., Ltd.
© 2008 Panasonic Communications Co., Ltd. All Rights Reserved.
PNQX1454ZA CM0708SY0
Loading...
