Digital Proprietary Telephone
Digital Proprietary Telephone with Display
Digital Proprietary Telephone with Large Display
Digital Proprietary Telephone
Digital Proprietary Telephone
Digital Proprietary Telephone
Digital Proprietary Telephone with Display
Digital Proprietary Telephone with Display
Digital Proprietary Telephone with Large Display
DSS Console
DSS Console
DSS Console with Answer and Release buttons
User Manual3
Page 4
Cautions
Cautions
When using the KX-T7200 and KX-T7400 series, keep the following conditions in
mind:
•If there is any trouble, unplug the extension line and connect a known working phone. If the
known working phone operates properly, have the defective phone repaired by a specified
Panasonic Factory Service Center. If the known working phone does not operate properly,
check the Digital Super Hybrid System and the internal extension wiring.
•Keep the unit away from heating appliances and electrical noise generating devices such as
fluorescent lamps and motors.
•The unit should be kept free of dust, moisture and vibration, and should not be exposed to
direct sunlight.
•Do not use benzine, thinner, or any abrasive powder to clean the cabinet. Wipe it with a soft
cloth.
•Do not use any handset other than a Panasonic handset.
When you ship the product
Carefully pack and send it prepaid, adequately insured and preferably in the original carton.
Attach a postage-paid letter, detailing the symptom, to the outside of the carton. DO NOT send
the product to the Executive or Regional Sales offices. They are NOT equipped to make repairs.
Product service
Panasonic Factory Servicenters for this product are listed in the servicenter directory. Consult
with your authorized Panasonic dealer for detailed instructions.
The serial number of this product may be found on the label affixed to the bottom
of the unit. You should note the model number and the serial number of this unit
in the space provided and retain this book as a permanent record of your purchase to
aid in identification in the event of theft.
MODEL No.:
SERIAL No.:
4User Manual
Page 5
For your future reference
DATE OF PURCHASE
NAME OF DEALER
DEALER'S ADDRESS
DEALER'S TELEPHONE NO.
Cautions
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR ANY TYPE OF MOISTURE.
Note
If you connect the Panasonic Wireless System (model KX-TD336900) to the Digital Super
Hybrid System, the following features do not work with the Wireless System:
a) Call Forwarding — Follow Me
b) Limited Call Duration (Please refer to Programming Guide)
User Manual5
Page 6
Cautions
Accessory Order Information
•Replacement parts and accessories are available through your local authorized parts
distributor.
This manual is designed for users of Digital Super Hybrid System KX- TD500. It is to be used
after the system is installed and System Programming is completed. The focus is Digital
Proprietary Telephones (DPTs); KX-T7220/KX-T7230/KX-T7235/KX-T7250/KX-T7420/
KX-T7425/KX-T7431/KX-T7433/KX-T7436, Digital DSS Consoles; KX-T7240/KX-T7440/
KX-T7441, Single Line Telephones (SLTs) and their features. The step-by-step procedures
required to activate each feature are discussed in detail. Illustrations of the KX-TD500 system
and the required System Programming are provided under separate cover in the Installation
Manual and the Programming Guide.
Construction of This Manual
This manual consists of the following sections:
(Section 1) DPT Overview
Provides configuration information on DPTs. It provides an illustration of each telephone,
identifies their feature buttons, supplies background information on these feature buttons, and
provides initial settings.
(Section 2) Station Programming
Provides the steps required to assign features to DPT flexible buttons and to the DPT system.
(Section 3) User Programming
Provides the steps required to assign some features to the system using a PT.
(Section 4) Station Features and Operation (PT/SLT)
Provides background information on the PT features and lists the steps required to activate each
feature.
(Section 5) DSS Console Features
Provides configuration information on the DSS Console. It gives background information on
the DSS Console features and lists the steps required to activate each feature.
(Section 6) Appendix
Provides Display Examples, a Feature Number List, Tone List, and other information are
explained in this section.
Introduction
Features and Capabilities
The KX-TD500 System is a sophisticated and powerful system that satisfy just what you
expect of an office communication's system. Some of the remarkable features are listed below.
"*" are only available for the KX-7235 and KX-T7436.
•Automatic Callback Busy (Camp-On) informs you when the selected CO line or the
called party becomes idle.
•Call Log, Incoming (— Option) allows you to confirm the incoming CO call
information on the display. You can also call back the caller by selecting one of the
memorized numbers. This feature is available only for the KX-T7230,KX-T7235,KXT7433 and KX-T7436.
User Manual7
Page 8
Introduction
•Call Log, Outgoing* redials by selecting one of the last five CO calls you made,
according to the number information on the display.
•Conference, Unattended When you are in a conference with two outside parties, you
can leave the conference and allow the other two parties to continue the conversation.
You can also return to the conference.
•Data Line Security prohibits various tones, such as call waiting tone or hold recall tone,
from sounding at the extension in the data communication mode. It also blocks
overriding by other extensions, such as Executive Busy Override.
•Doorphone and Door Opener (— Option) enables the conversation between you and
a visitor at door. You can also unlock the door a few seconds from your phone.
•Executive Busy Override allows you to enter into an existing conversation at an
extension/CO line.
•Full One-Touch Dialing allows you to have easy access to a desired party or system
feature by pressing just one button.
•Message Waiting allows you to leave a message notification for another extension. The
message waiting lamp (MESSAGE indicator) gives a visual indication that a message
notification has been received.
•Paralleled Telephone Connection allows you to connect your DPT in parallel with an
SLT. Each telephone can have the same extension number so that you can use either
telephone. If the eXtra Device Port (XDP) feature is available through System
Programming, each telephone can be connected to the same extension port but have
different extension numbers so that they can act as completely different extensions.
•System Feature Access Menu* allows you to access various features easily by
following the display on the large LCD and pressing corresponding buttons.
•VPS Integration (— Option) enables forwarding any incoming call to Voice Mail.
Recording or Playing back the message(s) is also available. To use Voice Mail services,
installing a Voice Processing System (VPS) is required.
Terms used in the Descriptions
Feature Numbers
A feature number is an access code for various functions when programming or executing
features using proprietary or single line telephones connected to the system. You can access
available features by dialing the corresponding feature number (and additional number, if
required).
There are two types of feature numbers as follows:
•Flexible feature number
•Fixed feature number
While fixed feature numbers cannot be changed, flexible feature numbers can be changed.
Please refer to the Programming Guide for details. In this manual, the default numbers are used
to describe each operation and illustration. Use the new programmed number if you have
changed a flexible feature number. The lists of fixed numbers and default flexible feature
numbers are shown in Section "6 Appendix."
If you use a dial pulse (DP) type Single Line Telephone (SLT);
It is not possible to access features that have " " or "#" in their feature numbers.
8User Manual
Page 9
Introduction
Illustration
All illustrations of DPTs used in the operating instructions are KX-T7235's.
Ton es
Various tone types, such as Confirmation tone, Dial tone, Call Waiting tone, etc., are explained
in Section "6 Appendix."
Display
The display examples are in each operation step, if required. The display information list is in
Section "6 Appendix" for your convenience.
Installation Manual References
The required installation instruction titles described in the Installation Manual
your reference.
Programming Guide References
The related and required programming titles described in the Programming Guide
your reference.
System Programming should be done with PC.
Features Guide References
The related feature titles described in the Features Guide
User Manual References
The operation(s) required to implement the feature described in this User Manual
for your reference.
are noted for your reference.
are noted for
are noted for
is (are) noted
Note
•Throughout this manual the term "he" or "she," "his" or "her" may be used.
In order to improve readability rather than continually use he / she we have only used
one of these terms. The term "he" or "she" should be taken as being interchangeable.
About the Other Manuals
Along with this User Manual, the following manuals are available:
Features Guide
Describes every basic, optional and programmable features of the KX-TD500 System in
alphabetical order.
Installation Manual
Provides instructions for installing the hardware and system maintenance.
Programming Guide
Describes step-by-step instruction for performing System Programming using the
Maintenance Console software for a PC.
User Manual9
Page 10
Telephone Company and F.C.C. Requirements and Responsibilities
Telephone Company and F.C.C. Requirements
and Responsibilities
Telephone Company and F.C.C. Requirements and Responsibility
1. Notification to the Telephone Company
Customers, before connecting terminal equipment to the telephone network, shall upon
request of the Telephone Company, inform the Telephone Company of the particular line(s)
to which such connection is made, the F.C.C. registration number (see the label on the
bottom of the unit) and ringer equivalence number (REN) of the registered terminal
equipment.
The REN is useful in determining the quantity of devices you may connect to your
telephone line and still have all of those devices ring when your telephone number is called.
In most, but not all areas, the sum of the REN's of all devices connected to one line should
not exceed five (5.0). To be certain of the number of devices you may connect to your line,
as determined by the REN, you should contact your local telephone company to determine
the maximum REN for your calling area.
2. Connection to Telephone Line
This unit must not be connected to a coin operated line. If you are on a party line, check
with your local telephone company.
3. Incidence of Harm to the Telephone Lines
Should terminal equipment cause harm to the telephone network, the telephone company
shall, where practical, notify the customer that temporary discontinuance of service may be
required. However, where prior notice is not practical, the telephone company may
temporarily discontinue service forthwith, if such action is reasonable in the circumstances.
In case of such unnotified temporary discontinuance of service, the telephone company
shall:
1) Promptly notify the customer of such temporary discontinuance of service.
2) Afford the customer the opportunity to correct the situation which gave rise to the
temporary discontinuance.
3) Inform the customer of the right to bring a complaint to the Federal Communication
Commission pursuant to the procedures set out in Subpart E of Part 68 of FCC
Telephone Equipment Rules.
4. Compatibility of the Telephone Network and Terminal Equipment
a) Availability of telephone interface information.
Technical information concerning interface parameters and specifications not specified
in FCC Rules, including the number of Ringers which may be connected to a particular
telephone line, which is needed to permit Terminal Equipment to operate in a manner
compatible with Telephone Company communications facilities, shall be provided by
the Telephone Company upon customer's request.
b) Changes in Telephone Company Communications Facilities, Equipment,
Operations and Procedures.
The Telephone Company may make changes in its communications facilities,
equipment, operations or procedures, where such action is reasonably required in the
10User Manual
Page 11
Telephone Company and F.C.C. Requirements and Responsibilities
operation of its business and is not inconsistent with the rules and regulations in FCC
Part 68.
If such changes can be reasonably expected to render any customer Terminal Equipment
incompatible with Telephone Company Communications Facilities, or require
modification or alteration of such Terminal Equipment, or otherwise materially affect its
use or performance, the customer shall be given adequate notice in writing, to allow the
customer an opportunity to maintain uninterrupted service.
Notify the Telephone Company
Installation must be performed by a qualified professional installer. Before connecting this
equipment to any telephone, call the telephone company and inform them of the following:
•Telephone numbers to which the system will be connected
•Make: Panasonic
•Model: KX-TD500 and KX-TD520
•FCC Registration No.: found on the rear side of the unit
Allowing this equipment to be operated in such a manner as to not provide for proper answer
supervision is a violation of Part 68 of the FCC's rules.
and:
Proper answer supervision is when:
A. This equipment returns answer supervision to the PSTN when DID calls are:
• Answered by the called station
• Answered by the attendant
• Routed to a recorded announcement that can be administered by the CPE user.
• Routed to a dial prompt
B. This equipment returns answer supervision on all DID calls forwarded to the
PSTN. Permissible exceptions are:
• A call is unanswered
• A busy tone is received
• A reorder tone is received
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
User Manual11
Page 12
Telephone Company and F.C.C. Requirements and Responsibilities
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
Caution:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the users authority to operate this device.
Note: All illustrations used in the initial setting are
based on model KX-T7235.
User Manual19
Page 20
DPT Overview
1.1Configuration
1.1.1Configuration
Panasonic Digital Proprietary Telephones (DPTs) are available to utilize various features of the
KX-TD500 System, in addition to supporting basic telephone services (making or receiving
calls).
There are the following nine DPT models.
KX-T7420KX-T7425KX-T7431KX-T7433KX-T7436
KX-T7400 Series
Display
NoneNone
Soft Buttons
and
Function Buttons
Jo g Di alYesYesYesYesYes
CO Buttons1224122424
Fixed Feature
Buttons
Display
Soft Buttons
and
Function Buttons
NoneNoneNone3 Soft Buttons
Please refer to "Fixed Buttons" in Section "1.1.4Feature Buttons."
KX-T7200 Series
KX-T7220KX-T7230KX-T7235KX-T7250
None
None3 Soft Buttons
16 char./line,
2-line LCD
16 char./line,
1-line LCD
Tilt-up,
24 char./line,
6-line LCD
3 Soft Buttons/
10 Function
Buttons
Tilt-up,
16 char./line,
3-line LCD
None
None
Tilt-up,
24 char./line,
6-line LCD
3 Soft Buttons/
10 Function
Buttons
SpeakerphoneYesYesYesMonitor only
CO Buttons2424126
Fixed Feature
Buttons
Please refer to "Fixed Buttons" in Section "1.1.4Feature
Buttons."
20User Manual
Page 21
1.1.2Location of Controls
KX-T7420
PROGRAM Button
FWD/DND Button
CONF Button
INTERCOM Button
DPT Overview
Flexible CO Buttons
(Outside lines 01 through 12)
PAUSE Button
TRANSFER Button
REDIAL Button
HOLD Button
SP-PHONE Button
MESSAGE Button
AUTO DIAL/STORE Button
RINGER Volume Selector
Used to adjust the ringer volume.
AUTO ANSWER/MUTE Button
FLASH Button
Jog Dial
Microphone
User Manual21
Page 22
DPT Overview
KX-T7425
PROGRAM Button
FWD/DND Button
CONF Button
INTERCOM Button
Flexible CO Buttons
(Outside lines 01 through 24)
PAUSE Button
TRANSFER Button
MESSAGE Button
AUTO DIAL/STORE Button
REDIAL Button
HOLD Button
SP-PHONE Button
Microphone
RINGER Volume Selector
Used to adjust the ringer volume.
AUTO ANSWER/MUTE Button
FLASH Button
Jog Dial
22User Manual
Page 23
KX-T7431
Flexible CO Buttons
(Outside lines 01 through 12)
PROGRAM Button
FWD/DND Button
CONF Button
INTERCOM Button
DPT Overview
Display (Liquid Crystal Display)
With 16-character/1-line readout:
Shows the date, time, dialed number or name,
call duration time, etc. In Programming mode,
it shows the programming messages.
SELECT Button
MODE Button
PAUSE Button
REDIAL Button
HOLD Button
SP-PHONE Button
TRANSFER Button
MESSAGE Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
FLASH Button
Jog Dial
Microphone
User Manual23
Page 24
DPT Overview
KX-T7433
Flexible CO Buttons
(Outside lines 01 through 24)
PROGRAM Button
FWD/DND Button
CONF Button
INTERCOM Button
Display (Liquid Crystal Display)
With 16-character/3-line readout:
Shows the date, time, dialed number or
name, call duration time, etc. In
Programming mode, it shows the
programming messages.
Soft Buttons
(S1 through S3)
SHIFT Button
PAUSE Button
REDIAL Button
HOLD Button
SP-PHONE Button
To lift or set down the display:
– To lift the display
1 Press the LCD ADJ button.
2 Lift up the display.
– To set down the display
1 Press the LCD ADJ button.
2 Press down the display.
TRANSFER Button
MESSAGE Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
FLASH Button
Jog Dial
Microphone
LCD
LCD ADJ button
24User Manual
Page 25
KX-T7436
Function Buttons
(F1 through F5)
Flexible CO Buttons
(Outside lines 01 through 24)
DPT Overview
Display (Liquid Crystal Display)
With 24-character/6-line readout:
Shows the date, time, dialed number or name,
call duration time, etc. In Programming mode,
it shows the programming messages.
Soft Buttons
(S1 through S3)
PROGRAM Button
FWD/DND Button
CONF Button
INTERCOM Button
REDIAL Button
HOLD Button
SP-PHONE Button
Function Buttons
(F6 through F10)
SHIFT Button
PAUSE Button
TRANSFER Button
MESSAGE Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
FLASH Button
Jog Dial
Microphone
To lift or set down the display:
LCD
– To lift the display
1 Press the LCD ADJ button.
2 Lift up the display.
– To set down the display
1 Press the LCD ADJ button.
2 Press down the display.
LCD ADJ button
User Manual25
Page 26
DPT Overview
KX-T7220
MESSAGE Button
FWD/DND Button
CONF Button
INTERCOM Button
Flexible CO Buttons
(Outside lines 01 through 24)
RINGER Volume Selector
Used to adjust the ringer volume.
REDIAL Button
FLASH Button
HOLD Button
Microphone
SP-PHONE Button
TRANSFER Button
PROGRAM Button
VOLUME Control Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
26User Manual
Page 27
KX-T7230
PROGRAM Button
DPT Overview
Flexible CO Buttons
(Outside lines 01 through 24)
MESSAGE Button
FWD/DND Button
CONF Button
INTERCOM Button
REDIAL Button
Display (Liquid Crystal Display)
with 16-characters/2-line readout:
Shows the date, time, dialed number or
name, call duration time, etc. In
Programming mode, it shows the
Programming instructions.
Soft Buttons
(S1 through S3)
SHIFT Button
TRANSFER Button
PAUSE Button
FLASH Button
HOLD Button
Microphone
VOLUME Control Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
SP-PHONE Button
User Manual27
Page 28
DPT Overview
KX-T7235
Function Buttons
(F1 through F5)
PROGRAM Button
MESSAGE Button
FWD/DND Button
CONF Button
INTERCOM Button
REDIAL Button
FLASH Button
HOLD Button
Microphone
SP-PHONE Button
Display (Liquid Crystal Display)
with 24-characters/6-line readout:
Shows the date, time, dialed number or
name, call duration time, etc. In
Programming mode, it shows the
Programming instructions.
Function Buttons
(F6 through F10)
SHIFT Button
Soft Buttons
(S1 through S3)
Flexible CO Buttons
(Outside lines 01 through 12)
TRANSFER Button
PAUSE Button
VOLUME Control Button
AUTO DIAL/STORE Button
AUTO ANSWER/MUTE Button
To lift or set down the display:
LCD
– To lift the display
1 Press the LCD ADJ button.
2 Lift up the display.
– To set down the display
1 Press the LCD ADJ button.
LCD ADJ button
2 Press down the display.
28User Manual
Page 29
KX-T7250
Flexible CO Buttons
(Outside lines 01 through 06)
INTERCOM Button
DPT Overview
Memory Card
Pull out the card and write down the
names or phone numbers associated
with automatic dialing numbers.
RINGER Volume Selector
Used to adjust the ringer volume.
ER
G
IN
R
HIGH
LOW
ONááá
REDIAL Button
FLASH Button
HOLD Button
MONITOR Button
PROGRAM Button
VOLUME Control Button
AUTO DIAL/STORE Button
TRANSFER Button
User Manual29
Page 30
DPT Overview
1.1.3Connection
Connect as shown.
KX-T7400 Series DPTs
The included
telephone
line cord
→ Connect to the KX-TD500 System.
→ Connect to a Single Line Telephone (SLT)
jack, Telephone Answering Machine, or FAX for
XDP* or parallel connections.
<Back View>
* XDP(eXtra Device Port) expands the number of telephones available in the system by allowing an
extension port to contain two telephones. For more details, please consult your dealer.
KX-T7200 Series DPTs
The included
telephone
line cord
Connect to a Single Line Telephone (SLT) jack, Telephone
Answering Machine, or FAX for XDP* or parallel connections.
Connect to the KX-TD500 System.
* XDP(eXtra Device Port) expands the number of telephones available in the system by allowing an
extension port to contain two telephones. For more details, please consult your dealer.
30User Manual
Page 31
1.1.4Feature Buttons
Digital Proprietary Telephones (DPTs) have the following types of Feature Buttons:
•Fixed Buttons
•Flexible Buttons
Fixed Buttons
Fixed buttons have specific functions permanently assigned to them. These default function
assignments cannot be changed. The following table lists the fixed buttons located on each
DPT model.
The button is not provided with an LED (Light Emitting Diode).
"" indicates the button is available.
Usage
AUTO ANSWER/MUTE Button
Used for Hands-free answer back; and it turns the microphone off during a conversation.
AUTO DIAL/STORE Button
Used for System Speed Dialing and storing program changes.
CONF (Conference) Button
Used to establish a 3-party/5-party conference call.
FLASH Button
Sends an External Feature Access signal to the central office or host PBX to access their system
features. If a PBX is not being used, this button can be used to disconnect the current call and
start another call without hanging up.
Function (F1 through F10) Buttons
Used to perform the corresponding displayed function or operation.
FWD/DND (Call Forwarding/Do Not Disturb) Button
Used to program the Call Forwarding feature or set the Do Not Disturb (DND) feature.
HOLD Button
Used to place a call on hold.
INTERCOM Button
Used to make or receive extension calls.
Jog Dial
Used to adjust the volume of the handset receiver, headset, ringer and speaker. It also adjusts
the display contrast. Please refer to Section "1.1.5Initial Setting for KX-T7400 Series."
For KX-T7431, KX-T7433 and KX-T7436 users, it is also used to select data from the Call
Directory and the System Feature Access Menu.
MESSAGE Button
Used to leave a notification to a busy extension or call back the message notification sender.
MODE Button
Used to shift the display in order to access various features.
MONITOR Button
Used for a hands-free dialing operation.
PAUSE Button
Inserts a pause in speed dial numbers or in One-Touch dial numbers.
PROGRAM Button
Used to enter or exit the Programming mode.
32User Manual
Page 33
DPT Overview
REDIAL Button
Used for the Last Number Redialing.
SELECT Button
Used to select the displayed function or to call the displayed phone number.
SHIFT Button
Used to access the next level of Soft Button functions.
Soft (S1 through S3) Buttons
Used to perform the function or operation that appears on the bottom line of the display.
SP-PHONE (Speakerphone) Button
Used for a hands-free speakerphone operation.
TRANSFER Button
Transfers a call to another extension or external destination.
VOLUME Control Button
Used to adjust the volume of the handset receiver, headset, ringer and speaker; it also adjusts
the display contrast. Please refer to Section "1.1.6Initial Setting for KX-T7200 Series."
User Manual33
Page 34
DPT Overview
Flexible Buttons
Flexible Buttons do not have specific features permanently assigned to them. Features are
assigned to Flexible Buttons by Station, User or System Programming. "Flexible Button
Assignment" is addressed in "Station Programming." The three types of Flexible Buttons are
as follows:
The following table outlines the features that can be assigned to the Flexible Buttons:
Features to be assigned
•Flexible CO buttons (located on PT only)
•Flexible DSS buttons (located on DSS Console only)
Can only be assigned by User or System Programming.
3
*
Can only be assigned by System Programming.
† Available when the Digital Super Hybrid System is connected to a Digital Proprietary
Telephone capable Panasonic Voice Processing System (one that supports Digital
Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
" " indicates that the feature is available.
Line Access Buttons
The following three types of CO buttons can be used to seize a CO line when making a CO call.
•Single-CO (S-CO) button
•Group-CO (G-CO) button
•Loop-CO (L-CO) button
Conditions
•A flexible CO button can be assigned as a Line Access Button (S-CO, G-CO or L-CO) by
Station, User or System Programming. Once a flexible CO button is assigned as a Line
Access Button, it provides the line status by lighting patterns and green/red indication.
Please refer to Section "1.1.7LED Indication."
•You can set S-CO, G-CO and L-CO buttons on one Proprietary Telephone. Incoming and
outgoing calls on the line are shown on the button in the following priority.
S-CO > G-CO > L-CO
User Manual35
Page 36
DPT Overview
Single-CO (S-CO) button
An S-CO button is a CO line access button. This allows you to access a specific CO line by
pressing an S-CO button. An incoming CO call can be directed to an S-CO button.
Conditions
•The same CO line cannot be assigned to more than one S-CO button on a PT.
•It is possible to assign the same CO line to an S-CO button, a G-CO button and an L-CO
button respectively.
Programming Guide References
•4.3 Extension Line
– CO Key
•4.4 DSS Console
– DSS Key
Features Guide References
1.16 Button Features
•Button, Line Access
User Manual References
•1.1.4Feature Buttons
•2.2.3Flexible Button Assignment
•3.2.5[005] Flexible CO Button Assignment
•4.3.54Outward Dialing, Trunk Access
Group-CO (G-CO) button
To support efficient utilization of CO lines, a group of CO lines (trunk group) can be assigned
to a CO button. This button is referred to as Group-CO (G-CO) button. Any incoming calls
from any CO line in the same trunk group arrive at the G-CO button. To make a CO call, you
can access an idle CO line in the trunk group by simply pressing the assigned G-CO button.
Conditions
•It is possible to assign the same CO line to an S-CO button, a G-CO button, and an L-CO
button.
•It is necessary to program the extension for making or receiving calls or both in trunk
groups.
36User Manual
Page 37
•When your extension is assigned as an incoming call destination for a CO line, you cannot
receive any incoming CO calls unless a G-CO, L-CO or S-CO button associated with the
CO line is assigned.
Programming Guide References
•4.3 Extension Line
– CO Key
•4.4 DSS Console
– DSS Key
Features Guide References
1.16 Button Features
•Button, Line Access
User Manual References
•1.1.4Feature Buttons
•2.2.3Flexible Button Assignment
•3.2.5[005] Flexible CO Button Assignment
•4.3.54Outward Dialing, Trunk Access
DPT Overview
Loop-CO (L-CO) button
All CO lines can be assigned to a flexible CO button on a Proprietary Telephone. The assigned
button serves as an L-CO button. An incoming call on any CO line arrives at the L-CO button,
unless there are S-CO or G-CO buttons associated with the CO line or unless the button is
already in use. To make a CO call, you simply press the dedicated L-CO button. Pressing the
L-CO button provides the same operation as dialing the feature number for "Local CO Line
Access/ARS" (default = 9).
Programming Guide References
•4.3 Extension Line
– CO Key
Features Guide References
1.16 Button Features
•Button, Line Access
User Manual37
Page 38
DPT Overview
User Manual References
•1.1.4Feature Buttons
•2.2.3Flexible Button Assignment
•3.2.5[005] Flexible CO Button Assignment
•4.3.54Outward Dialing, Trunk Access
38User Manual
Page 39
1.1.5Initial Setting for KX-T7400 Series
The Jog Dial can be used for the display contrast and the volume control. Rotate the Jog Dial
in either direction as desired. The contrast or the volume level will change as follows.
DPT Overview
Left
(counterclockwise)
Level decreases
Right
(clockwise)
Level increases
Display Contrast Adjustment
The MODE button and the Jog Dial for KX-T7431 users, and a Soft button and the Jog Dial
for KX-T7433 and KX-T7436 users are used to adjust the display contrast. The contrast level
is indicated on the display by the number of asterisks.
—KX-T7431
1
MODE
2
While on-hook
1. Press the MODE button six times.
•The display shows:
<Example>
Contrast:***
( contrast level 3)
—KX-T7433 and KX-T7436
1
CONT
S 1
2
S 2
S 3
2. Rotate the Jog Dial in the desired direction.
While on-hook or during a conversation
1. Press the CONT (S1) button.
2. Rotate the Jog Dial in the desired direction.
•The display shows:
<Example>
Contrast:***
( contrast level 3)
User Manual39
Page 40
DPT Overview
When using the headset
Changing the ringing tone of a CO button / INTERCOM button
Volume Control — Handset Receiver/Headset/Ringer/Speaker
The Panasonic Digital Super Hybrid System supports the use of a headset with a Proprietary
Telephone (PT). When you use the headset (optional), you should switch the selection mode
first. Selection is explained in Section "2.2.5Handset / Headset Selection."
There are eight ringer frequencies available for each CO (Single-CO, Group-CO, Loop-CO)
button, DN (PDN, SDN) button and INTERCOM button. If you wish to change them, please
refer to Section "2.2.13Ringing Tone Selection for CO Buttons" or Section
"2.2.14Ringing Tone Selection for INTERCOM Button."
Allows you to adjust the following volumes as required.
— Handset Receiver volume (levels 1 through 4)
— Headset volume (levels 1 through 4)
— Ringer volume (levels 0 through 3)
— Speaker volume (levels 1 through 12)
If your Digital Proprietary Telephone is provided with a display (display DPT), the volume
level is indicated on the display by the number of asterisks. For ringer volume adjustment, three
levels (OFF/LOW/HIGH) are available with the KX-T7420 and KX-T7425.
To adjust the handset receiver volume
1
1. Lift the handset.
2. Rotate the Jog Dial in the desired direction.
•The display shows:
<Example>
2
Handset:***
•You may also adjust the handset receiver volume
during a conversation using the handset receiver.
( volume level 3)
40User Manual
Page 41
To adjust the headset volume
DPT Overview
1
SP-PHONE
2
To adjust the ringer volume
—KX-T7433 and KX-T7436
1
Be sure the headset is connected.
1. Press the SP-PHONE button.
2. Rotate the Jog Dial in the desired direction.
•The display shows:
<Example>
Headset:***
( volume level 3)
While the telephone is ringing
1. Rotate the Jog Dial in the desired direction.
•The display shows:
<Example>
Ringer:***
( volume level 3)
1
1. Press the RING (S2) button.
While the telephone is idle and on-hook
RING
S 1
2
S 2
S 3
•The telephone will ring.
2. Rotate the Jog Dial in the desired direction.
•The telephone will stop ringing in about 4 seconds.
•When the volume level is 0 (no "*" indication), the
display shows "RNGOFF."
User Manual41
Page 42
DPT Overview
—KX-T7431
1
MODE
2
—KX-T7420 and KX-T7425
1
OFF HIGH
LOW
To adjust the speaker volume
While the telephone is idle and on-hook
1. Press the MODE button five times.
•The display shows:
<Example>
Ringer:***
( volume level 3)
2. Rotate the Jog Dial in the desired direction.
•The telephone will stop ringing in about 4 seconds.
•When the volume level is 0, no "*" is indicated.
1. Adjust the RINGER Volume Selector lever to the
desired setting (OFF/LOW/HIGH).
1
SP-PHONE
1. Press the SP-PHONE button.
2. Rotate the Jog Dial in the desired direction.
•The display shows:
2
<Example>
SP:************
( volume level 12)
•You may also adjust the speaker volume while
listening to background music (BGM On mode),
receiving a voice call, receiving a page or hearing a
call progress tone such as a dial tone.
Conditions
•If the ringer volume of the KX-T7431 is set to OFF, the display while on-hook is as
follows.
Ring Off 12:00P
•By pressing " ," the display changes to show your extension number and name.
101: John Smith
42User Manual
Page 43
1.1.6Initial Setting for KX-T7200 Series
Display Contrast Adjustment (KX-T7230 and KX-T7235 only)
A Soft button and the VOLUME Control button are used to adjust the display contrast. The
contrast level is indicated on the display by the number of asterisks. You can adjust the contrast
level under the following conditions:
a) When on-hook, or
b) During an outside/intercom call.
DPT Overview
1
1. Press the CONT (S1) button.
2. Press the VOLUME (UP / DOWN ) Control button.
2
CONT
S 1
S 2
VOLUME
S 3
•The display shows:
<Example>
Contrast:***
( contrast level 3)
When using the headset
The Panasonic Digital Super Hybrid System supports the use of a headset with a Proprietary
Telephone (PT). When you use the headset (optional), you should switch the selection mode
first. Selection is explained in Section "2.2.5Handset / Headset Selection."
Changing the ringing tone of a CO button / INTERCOM button
There are eight ringer frequencies available for each CO (Group-CO, Loop-CO, Single-CO)
button, DN(PDN, SDN) button and INTERCOM button. If you wish to change them, please
refer to Section "2.2.13Ringing Tone Selection for CO Buttons" or Section
"2.2.14Ringing Tone Selection for INTERCOM Button."
Volume Control — Handset Receiver/Headset/Ringer/Speaker
Allows you to adjust the following volumes as necessary:
— Handset Receiver volume (level 1 through 3)
— Headset volume (level 1 through 3)
— Ringer volume (level 0 through 3)
— Speaker volume (level 1 through 12)
User Manual43
Page 44
DPT Overview
If your Digital Proprietary Telephone is provided with a display (display DPT), the volume
level is indicated on the display by the number of asterisks. For ringer volume adjustment, three
levels (OFF/LOW/HIGH) are available with the KX-T7220 and KX-T7250.
To adjust the handset receiver volume
1
2
VOLUME
To adjust the headset volume
1
SP-PHONE
2
VOLUME
1. Lift the handset.
2. Press the VOLUME (UP / DOWN ) Control button.
•The display shows:
<Example>
Handset:***
( volume level 3)
•You may also adjust the handset receiver volume
during a conversation using the handset receiver.
Be sure the headset is connected.
1. Press the SP-PHONE button.
2. Press the VOLUME (UP / DOWN ) Control button.
•The display shows:
<Example>
Headset:***
( volume level 3)
To adjust the ringer volume
—KX-T7230 and KX-T7235
1
While the telephone is ringing;
1. Press the VOLUME (UP / DOWN ) Control button.
VOLUME
•The display shows:
<Example>
Ringer:***
( volume level 3)
44User Manual
Page 45
DPT Overview
1
RING
S 1
S 2
S 3
2
VOLUME
—KX-T7220 and KX-T7250
1
OFF HIGH
LOW
To adjust the speaker volume
While the telephone is idle and on-hook;
1. Press the RING (S2) button.
•The telephone will ring.
2. Press the VOLUME (UP / DOWN ) Control button.
•The telephone will stop ringing in about 4 seconds.
•When the volume level is 0 (no "*" indication), the
display shows "RNGOFF."
1. Adjust the RINGER Volume Selector lever to the
desired setting (OFF/LOW/HIGH).
1
SP-PHONE
2
or
VOLUME
MONITOR
1. Press the SP-PHONE or MONITOR button.
2. Press the VOLUME (UP / DOWN ) Control button.
•The display shows:
<Example>
SP:************
•You may also adjust the speaker volume while
listening to the background music (BGM On mode),
receiving a voice call, receiving a page or hearing a
call progress tone such as a dial tone.
( volume level 12)
User Manual45
Page 46
DPT Overview
1.1.7LED Indication
The Light Emitting Diode (LED) buttons indicate the line conditions with lighting patterns.
Flashing light patterns
Slow flashing
(60 flash/minute)
Moderate flashing
(120 flash/minute)
Rapid flashing
(240 flash/minute)
LED Indication on the INTERCOM Button
The table below shows the lighting patterns for intercom line conditions.
1 s
INTERCOM buttonIntercom Line Condition
Off
Green On
Green slow flashing
Green moderate flashing
Green rapid flashing
Idle
Intercom call / Conference established
Intercom call hold
On exclusive hold / Consultation hold
Incoming intercom/doorphone call
LED Indication on the CO Button
The table below shows the lighting patterns for CO line conditions.
46User Manual
Page 47
CO ButtonCO Line Condition
DPT Overview
Off
Green On
Green slow flashing
Green moderate flashing
Green rapid flashing
Red On
Red slow flashing
Red rapid flashing
— Items marked with "*" are only available on the Single-CO button.
Idle
You are using the line.
You have a held call.
You have one of the following:
(1) Exclusive hold,
(2) CO-to-CO line call, or
(3) Conference, unattended
Privacy Release possible* / Hold Recall /
Incoming call (A CO call is coming in on a single
extension).
Other-use
Other-hold*
Incoming call (A CO call is coming in on multiple
extensions simultaneously).
BLF on DSS Button
The Busy Lamp Field (BLF) indicator button is red when the corresponding extension is busy.
This is available for Direct Station Selection (DSS) buttons on DSS Consoles and for flexible
CO buttons assigned as DSS buttons on Proprietary Telephones.
The following table shows the DSS Button indication and the status of Corresponding
Extension.
DSS Button indicationStatus of Corresponding Extension
OffLog-in
Red OnIncoming call/You or another extension is using the line.
Red slow flashingLog-out
User Manual47
Page 48
DPT Overview
48User Manual
Page 49
Station Programming
Section2
Station Programming
Note: All illustrations used in this section are based on
model KX-T7235.
User Manual49
Page 50
Station Programming
2.1Station Programming Instructions
2.1.1Station Programming Instructions
Station Programming allows you, the Proprietary Telephone (PT) users, to program certain
features from your telephone individually. To program, you need to switch your telephone to
the Station Programming mode. During programming mode, your telephone is in the busy
condition to both inside and outside callers. If you want to make a normal call handling
operation, you must finish the programming mode.
Programming Mode Display
When you enter into the Station Programming mode, the display shows the following message
as the initial programming mode;
PT-PGM Mode
We recommend a PT with display for Station Programming to avoid mis-operation.
The display also gives you helpful or stored data information related to your programming
steps. In this section, we note the display example in the programming steps, if required. You
can also refer to the "Display Examples" in Section "6 Appendix."
Entering Station Programming mode
PT
Be sure that the telephone is idle and on-hook.
PROGRAM
99
Press PROGRAM.
The STORE indicator lights.
If 99 is not dialed within 5 seconds after the PROGRAM button is
pressed, the Station Programming mode is canceled.
<PT Display Example>
PT-PGM Mode
If there is no entry within one minute, the Station Programming mode
is canceled and normal call handling mode resumes automatically.
Dial 99.
Initial programming
display
50User Manual
Page 51
Exiting Station Programming mode
PT
When the display shows the initial programming mode;
PROGRAM
Press PROGRAM.
To exit the Station Programming mode, press PROGRAM. You are in
the call handling mode.
Station Programming
User Manual51
Page 52
Station Programming
Confirming the assigned function data
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
program access number
Enter the program access number.
Press HOLD (END).
Enter the program access number* as follows.
- 1:Preferred Line Assignment
- 2:Preferred Line Assignment
-
-
- 3:Full One-Touch Dialing Assignment
- 4:Intercom Alert Assignment
- 5:Call Waiting Tone Type Assignment
- 6:Self-Extension Number Confirmation
- 7:Live Call Screening Mode Set†
-81:Initial Display Selection
-82:Bilingual Display Selection
- 9:Handset/Headset Selection
-01:Remote Station Look Control (
-02:Call Log Lock Control, Incoming (
-03:Live Call Screening Password Control (
- #:Station Programming Data Default Set
HOLD
The display shows the initial programming mode.
Outgoing
Incoming
-
Operator / Manager only)
-
Operator / Manager only)
-
Operator / Manager only)
The display shows the programmed data.
<PT Display Example>
When you press [5], the display shows:
C.W. Tone1
† Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic
Voice Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
(- The Call Waiting tone is currently programmed to Tone 1.)
—To exit the Station Programming mode: Press [PROGRAM].
— If you wish to change the data, follow the programming procedure explained in this section.
* A programming access number is required to program/confirm the function data by Station
Programming.
52User Manual
Page 53
Confirming the assigned data on the Flexible button
—Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
HOLD
Station Programming
Press the desired Flexible
(CO,DSS,PF) button.
Press HOLD (END).
—To exit Station Programming mode: Press [PROGRAM].
—If you wish to change the data, follow the programming procedure explained in this section.
Clearing the data on the Flexible button
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
2
Press the desired Flexible
(CO, DSS, PF) button that
you wish to cancel the
assignment.
Dial 2.
The display shows the initial programming mode.The display shows the current status.
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
— To exit Station Programming mode: Press [PROGRAM].
—The following lists are the buttons and programming access numbers used for Station
Programming. Detailed operating instructions are explained on each page in this section.
User Manual53
Page 54
Station Programming
Station Programming Outline [Flexible Button Assignment]
PROGRAM
(Station Programming)
Direct Station Selection (DSS) Button
1
One-Touch Dialing Button
2
9
9
CO
DSS
PF
3
Message Waiting (MESSAGE) Button
4
FWD/DND Button
5
SAVE Button
6
Account Button
70
Conference (CONF) Button
71
Log-In / Log-Out Button
72
Phantom Button
73
Day / Night Button
74
Primary Directory Number (PDN) Button
75
Secondary Directory Number (SDN) Button
77
Alarm Button
78
Tone Through Button
79
Group Log-In / Log-Out Button
8
Voice Mail (VM) Transfer Button
Two-Way Record Button
90
Two-Way Transfer Button
91
Live Call Screening (LCS) Button
92
Live Call Screening (LCS) Cancel Button
93
Answer Button
94
Release Button
95
Alert Button
97
*
*
*
*
Group FWD Button
98
Single-CO (S-CO) Button
0
Loop-CO (L-CO) Button
Group-CO (G-CO) Button
#
CO
ICM
PDN
Phantom
SDN
/
CO
ICM
Phantom
Function
(F1 - F10)
* : Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic
Voice Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
(Ringing Tone Selection for CO Button)
(Ringing Tone Selection for ICM Button)
(PDN/SDN Key Delayed Ringing Assignment)
76
(Phantom Button Ringing On/Off Assignment)
(Station Speed Dialing Number / Name Assignment)
[KX-T7235 / KX-T7436 only]
PROGRAM
(Exit)
54User Manual
Page 55
Note
•Please refer to "Flexible Buttons" in Section "1.1.4Feature Buttons" for
applicability of CO / DSS / PF buttons.
[Function Assignment]
Station Programming
PROGRAM
9
9
1
2
3
4
5
6
7
8
82
9
0
0
0
#
(Preferred Line Assignment - Outgoing)
(Preferred Line Assignment
(Full One-Touch Dialing Assignment)
(Intercom Alert Assignment)
(Call Waiting Tone Type Assignment)
(Self-Extension Number Confirmation)
(Live Call Screening Mode Set)†
(Initial Display Selection)
1
(Bilingual Display Selection)
(Handset / Headset Selection)
(Remote Station Lock Control)
1
-
see "Operator / Manager Service Features" (Section 4.4)
2
(Control of Call Log Incoming, Log Lock)
-
see "Operator / Manager Service Features" (Section 4.4)
3
(Live Call Screening Password Control)†
-
see "Operator / Manager Service Features" (Section 4.4)
(Station Programming Data Default Set)
(Station Speed Dialing Number / Name Assignment)
PROGRAM
-
Incoming)
(Exit)
† Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic
Voice Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
User Manual55
Page 56
Station Programming
2.2Station Programming
2.2.1Bilingual Display Selection
Allows you to select the display in English or French.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
8
2
Dial 82.
The display shows the current display type.
Dial 1 or 2.
1 : for the English display
2 : for the French display
or
1
2
AUTO DIAL
STORE
Press STORE.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "English display" mode.
The STORE indicator lights.
The display shows the initial programming mode.
56User Manual
Page 57
2.2.2Call Waiting Tone Type Assignment
Allows you to select the call waiting tone type (Tone 1 or Tone 2).
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
5
Dial 5.
The display shows the current tone type.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The tone type patterns are described in Section "6 Appendix."
•The default is "Tone 1."
or
1
Dial 1 or 2.
1 : to select Call Waiting Tone 1
2 : to select Call Waiting Tone 2
2
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
User Manual57
Page 58
Station Programming
2.2.3Flexible Button Assignment
Each Flexible (CO,DSS,PF) button on your PT and DSS Console can be assigned as various
feature buttons such as an Account Button, FWD/DND Button, etc. The features assignable are
limited by the button type. Please refer to "Flexible Buttons" in Section "1.1.4Feature
Buttons." The "Flexible CO Button Assignment" by User or System Programming can be used
for this assignment.
Account Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as an Account button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
6
Press the desired Flexible (CO, DSS,
PF) button you wish to assign as the
Account button.
Dial 6.
AUTO DIAL
STORE
Press STORE.
<PT Display Example>
Account
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
58User Manual
Page 59
Alarm Button (Assignment)
Allows you to assign a Flexible (CO) button as an Alarm button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
(CO)
Press the desired Flexible (CO)
button you wish to assign as the
Alarm button.
<PT Display Example>
ALARM
77
Dial 77.
Station Programming
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•Alarm button is available for the Manager only.
User Manual59
Page 60
Station Programming
Alert Button (Assignment)
Allows you to assign a Flexible (CO) button as an Alert button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
(CO)
Press the desired Flexible (CO)
button you wish to assign as the
Alert button.
<PT Display Example>
ALERT
97
Dial 97.
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
60User Manual
Page 61
Answer Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as an Answer button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
AUTO DIAL
94
STORE
Press the desired Flexible
(CO, DSS, PF) button you
wish to assign as the
Answer button.
Dial 94.
<PT Display Example>
Answer
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Press STORE.
User Manual61
Page 62
Station Programming
Conference (CONF) Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as a Conference (CONF) button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO,
DSS, PF) button you wish to
assign as the Conference button.
<PT Display Example>
Conference
7
Dial 70.
0
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
— To exit the Station Programming mode: Press [PROGRAM].
62User Manual
Page 63
DAY/NIGHT Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a DAY/NIGHT button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
AUTO DIAL
37
STORE
Press the desired Flexible (CO, DSS)
button you wish to assign as the
DAY/NIGHT button.
Dial 73.
<PT Display Example>
DAY/NIGHT
— To exit the Station Programming mode: Press [PROGRAM].
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
User Manual63
Page 64
Station Programming
Direct Station Selection (DSS) Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a DSS button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
extension no.
Enter the extension number
(3 or 4 digits).
Press the desired Flexible
(CO, DSS) button you wish
to assign as a DSS button.
1
Dial 1.
AUTO DIAL
STORE
Press STORE.
<PT Display Example>
EXT
CLR
<PT Display Example>
EXT xxxx
(-xxxx:extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or
the TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the
Station Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•DSS buttons are provided on a DSS Console without default setting. You can assign the
desired extension number or feature on each DSS button from the paired PT.
•You cannot enter non-existent extension numbers.
The STORE indicator lights.
The display shows the initial
programming mode.
64User Manual
Page 65
FWD/DND Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as an FWD/DND button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
AUTO DIAL
4
STORE
Press the desired Flexible (CO,DSS, PF) button you wish to
assign as the FWD/DND button.
Dial 4.
<PT Display Example>
FWD/DND
— To exit the Station Programming mode: Press [PROGRAM].
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
User Manual65
Page 66
Station Programming
Group FWD Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Group FWD button.
—Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
98
AUTO DIAL
FDN
STORE
Press the desired Flexible
(CO, DSS) button you wish to
assign as the Group FWD button.
Dial 98.Enter FDN of Incoming
group (3 or 4 digits).
<PT Display Example>
G-FWD FDN-
CLR
<PT Display Example>
G-FWD FDN-xxxx
(-xxxx:Incoming group number)
CLR
• To erase an incorrect entry, press the CLR (S2) button or
the TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the
Station Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•You cannot enter non-existent extension or a floating directory number.
Please refer to "Floating Station" of Section "1.3 System Features" in the Features Guide.
Press STORE.
• The STORE indicator lights.
• The display shows the initial
programming mode.
*1
Programming Guide References
•3.5 Incoming Group
– FDN
– Group Type
*1
A Floating Directory Number (FDN) is a virtual extension number which appears to be an extension.
66User Manual
Page 67
Group Log-In / Log-Out Button (Assignment)
Allows you to assign a Flexible (CO) button as a Group Log-In / Log-Out button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
(CO)
79
Press the desired Flexible
(CO) button you wish to
assign as the Group
Log-In / Log-Out button.
<PT Display Example>
G-Login FDN-
CLR
<PT Display Example>
G-Login FDN-xxxx
CLR
•
To erase an incorrect entry, press the CLR (S2) button or
the TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the
Station Programming mode.)
Dial 79.Enter FDN of Incoming
group (3 or 4 digits).
(-xxxx:Incoming group number)
AUTO DIAL
FDN
STORE
Press STORE.
• The STORE indicator lights.
• The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•You cannot enter non-existent extension or a floating directory number.
Please refer to "Floating Station" of Section "1.3 System Features" in the Features Guide.
*1
Programming Guide References
•3.5 Incoming Group
– FDN
– Group Type
*1
A Floating Directory Number (FDN) is a virtual extension number which appears to be an extension.
User Manual67
Page 68
Station Programming
Group-CO (G-CO) Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Group-CO button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible
(CO, DSS) button you wish
to assign as a G-CO button.
<PT Display Example>
TRK GRP-
Dial #.
trunk group no.
Enter the trunk group
number
(01 through 48).
The STORE indicator lights.
The display shows the initial
programming mode.
AUTO DIAL
STORE
Press STORE.
CLR
To erase an incorrect entry, press the CLR (S2)button or the TRANSFER (CLEAR)button.
(The TRANSFER button becomes the CLEAR button in the Station Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•A G-CO button assigned to a DSS button is available for monitoring the call activity only,
not available for making or receiving a call.
68User Manual
Page 69
Station Programming
Live Call Screening (LCS) Button (Assignment)
*1
Allows you to assign a Flexible (CO, DSS) button as a Live Call Screening (LCS) button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO,
DSS) button you wish to assign
as the Live Call Screening button.
<PT Display Example>
LCS
9
Dial 92.
2
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
— To exit the Station Programming mode: Press [PROGRAM].
Live Call Screening (LCS) Cancel Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Live Call Screening (LCS) Cancel
button.
*1
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO, DSS)
button you wish to assign as the
Live Call Screening Cancel button.
<PT Display Example>
LCS Cancel
9
Dial 93.
3
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
— To exit the Station Programming mode: Press [PROGRAM].
*1
Available when the Digital Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice Processing
System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
User Manual69
Page 70
Station Programming
Log-In / Log-Out Button (Assignment)
Allows you to assign a Flexible (CO) button as a Log-In / Log-Out button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
(CO )
7
Press the desired Flexible (CO)
button you wish to assign as
the Log-In/Log-Out button.
<PT Display Example>
Login/Logout
— To exit the Station Programming mode: Press [PROGRAM].
Dial 71.
Loop-CO (L-CO) Button (Assignment)
Allows you to assign a Flexible (CO) button as a Loop-CO button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
AUTO DIAL
1
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
PT
(CO)
Press the desired Flexible
(CO) button you wish to assign
as the L-CO button.
<PT Display Example>
Loop-CO
Dial .
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
— To exit the Station Programming mode: Press [PROGRAM].
70User Manual
Page 71
Message Waiting (MESSAGE) Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Message Waiting (MESSAGE) button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
AUTO DIAL
3
STORE
Press the desired Flexible(CO,DSS) button you wish to assign
as the Message Waiting button,
Dial 3
<PT Display Example>
Message Waiting
— To exit the Station Programming mode: Press [PROGRAM].
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
User Manual71
Page 72
Station Programming
One-Touch Dialing Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as a One-Touch Dialing button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
desired number
Enter the desired number
(extension number,
phone number, etc.).
Press the desired Flexible
(CO, DSS, PF) button you
wish to assign as a
One-Touch Dialing button.
<PT Display Example>
2
Dial 2.
CLR
• Up to 24 digits can be stored.
• To erase an incorrect entry, press the CLR (S2) button or the
TRANSFER (CLEAR)button.
(The TRANSFER button becomes the CLEAR button in the
Station Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The number can be an extension number, telephone number or a feature number. Up to 24
digits can be stored in a One-Touch Dialing button.
•To store the telephone number of an outside party, a line access code (9, or 801 through 848)
must be stored as the leading digit.
•You can store a number consisting of 25 digits or more by dividing it and assigning it in two
One-Touch Dialing buttons. In this case, the line access code should be stored in the first
button.
•You can use 0 through 9, , #, PAUSE, FLASH, CONF and INTERCOM for storing.
•KX-T7220 and KX-T7250 telephones do not have a PAUSE button. The PROGRAM
button can be used instead of the PAUSE button while programming.
AUTO DIAL
STORE
Press STORE.
• The STORE indicator lights.
• The display shows the initial
programming mode.
72User Manual
Page 73
Phantom Button (Assignment)
Allows you to assign a Flexible (CO) button as a Phantom button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
(CO)
Press the desired Flexible
(CO) button you wish to
assign as a Phantom button.
7
Dial 72.
phantom extension no.
2
Enter the phantom extension
number (3 or 4 digits).
<PT Display Example>
Phantom:
CLR
<PT Display Example>
Phantom:xxxx
(-xxxx:Phantom extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or the
TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the Station
Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Conditions
•The phantom extension numbers must be assigned by System Programming <Section 5.3
Phantom Extension in the Programming Guide> before assigning the Phantom button.
•If you assign the Phantom button to one of the CO buttons (CO 13 through CO 24) on a PT
with 24 CO buttons, such as KX-T7230, and change the telephone to a PT with 12 CO
buttons, such as KX- T7235, you must re-program the setting because CO 13 through CO
24 are not provided with the PT with 12 CO buttons. If you do not change the setting, the
phantom extension call appears on the INTERCOM (ICM type PT) or PDN (DN type PT)
button.
•More than one identical Phantom button cannot be assigned on a single extension.
User Manual73
Page 74
Station Programming
Primary Directory Number (PDN) Button (Assignment)
Allows you to assign a Flexible (CO) button as a PDN button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO)
button you wish to assign as a
PDN button.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•A PDN button can be assigned to any one of the flexible CO buttons on a PT by Station,
(CO)
7
Dial 74.
4
AUTO DIAL
STORE
Press STORE.
<PT Display Example>
PDN
The STORE indicator lights.
The display shows the initial programming mode.
User or System Programming. Up to three PDN buttons can be assigned to any flexible CO
button on a PT. However, the first PDN button should always be assigned to the CO 01
button regardless of the number of the PDN buttons assigned.
74User Manual
Page 75
Release Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as a Release button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO,
DSS, PF) button you wish to
assign as the Release button.
<PT Display Example>
Release
95
Dial 95.
Station Programming
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
SAVE Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as a SAVE button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO,
DSS, PF) button you wish to
assign as the SAVE button.
<PT Display Example>
Save
5
Dial 5.
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
User Manual75
Page 76
Station Programming
Secondary Directory Number (SDN) Button (Assignment)
Allows you to assign a Flexible (CO) button as an SDN button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
(CO)
Press the desired Flexible
(CO) button you wish to
assign as an SDN button.
7
Dial 75.
extension no. of the
5
owner extension
Enter the extension number
(3 or 4 digits) of the owner
extension.
<PT Display Example>
SDN—
CLR
<PT Display Example>
SDN—xxxx
(-xxxx:extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or
the TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the
Station Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Conditions
•An SDN button should have its associated PDN button of another extension. This
assignment is available for extensions on which at least one PDN button is already assigned
(DN type PT). Otherwise, the SDN button dose not function.
•Up to three different SDN buttons can be assigned to a PT.
•Up to eight SDN buttons per PDN button can be assigned to eight different PTs respectively.
76User Manual
Page 77
Single-CO (S-CO) Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Single-CO button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
trunk port physical number
Enter the trunk port physical
number.
Press the desired Flexible
(CO, DSS) button you wish
to assign as an S-CO button.
0
Dial 0.
Station Programming
AUTO DIAL
STORE
Press STORE.
<PT Display Example>
CO—
CLR
<PT Display Example>
CO—xxxxx
(-xxxxx: trunk port physical number)
CLR
• To erase an incorrect entry, press the CLR (S2) button or the
TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the Station
Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•You cannot assign the same CO line to more than one S-CO button on a PT.
•You can assign the same CO line to an S-CO button, a G-CO button and an L-CO button
respectively.
•An S-CO button assigned to a DSS button is available for monitoring the call activity only,
not available for making or receiving a call.
• The STORE indicator lights.
• The display shows the initial
programming mode.
User Manual77
Page 78
Station Programming
Tone Through Button (Assignment)
Allows you to assign a Flexible (CO, DSS) button as a Tone Through button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Press the desired Flexible (CO,
DSS) button you wish to assign
as the Tone Through button.
<PT Display Example>
Tone Through
— To exit the Station Programming mode: Press [PROGRAM].
Features Guide References
1.12 Conversation Features
•End-to-End DTMF Signaling (Tone Through)
7
Dial 78.
AUTO DIAL
8
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
78User Manual
Page 79
Station Programming
Two-Way Record Button (Assignment)
*1
Allows you to assign a Flexible (CO, DSS) button as a Two-Way Record button.
This allows you to record a conversation into your own mailbox.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Voice Mail
extension no.
Enter the Voice Mail
extension number
(3 or 4 digits).
Press the desired Flexible
(CO, DSS) button you wish
to assign as the Two-Way
Record button.
<PT Display Example>
9
Dial 90.
0
2 WAY-REC:
CLR
<PT Display Example>
2 WAY-REC :xxxx
(-xxxx:VM extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or
the TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the Station
Programming mode.)
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•You cannot enter a non-existent extension or floating directory number.
Please refer to "Floating Station" of Section "1.3 System Features" in the Features Guide.
•You should use a voice mail extension number that has been assigned by System
Programming. Please refer to Programming Guide References below.
Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice
Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
*2
A Floating Directory Number (FDN) is a virtual extension number which appears to be an extension.
User Manual79
Page 80
Station Programming
– [EXT No.2] Group No.
Two-Way Transfer Button (Assignment)
*1
Allows you to assign a Flexible (CO, DSS) button as a Two-Way Transfer button.
This allows you to record a conversation into a desired mailbox.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Voice Mail
extension no.
Enter the Voice Mail
extension number
(3 or 4 digits).
Press the desired Flexible
(CO, DSS) button you wish
to assign as the Two-Way
Transfer button.
<PT Display Example>
9
1
Dial 91.
2 WAY-TRANS:
CLR
<PT Display Example>
2 WAY-TRANS:xxxx
(-xxxx:VM extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or the
TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the Station
Programming mode.)
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•You cannot enter a non-existent extension or floating directory number.
Please refer to "Floating Station" of Section "1.3 System Features" in the Features Guide.
•You should use a voice mail extension number that has been assigned by System
Programming. Please refer to Programming Guide References below.
*2
Programming Guide References
•1.5 VPS (DPT) Port Assignment
– [EXT No.1] DN
*1
Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice
Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
*2
A Floating Directory Number (FDN) is a virtual extension number which appears to be an extension.
80User Manual
Page 81
– [EXT No.1] Group No.
– [EXT No.2] DN
– [EXT No.2] Group No.
Voice Mail (VM) Transfer Button (Assignment)
Allows you to assign a Flexible (CO, DSS, PF) button as a VM Transfer button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
Voice Mail
extension no.
Enter the Voice Mail
extension number
(3 or 4 digits).
Press the desired Flexible
(CO, DSS, PF) button you
wish to assign as the VM
Transfer button.
8
Dial 8.
<PT Display Example>
VTR-
CLR
<PT Display Example>
VTR-xxxx
(-xxxx:VM extension number)
CLR
To erase an incorrect entry, press the CLR (S2) button or the
TRANSFER (CLEAR) button.
(The TRANSFER button becomes the CLEAR button in the Station
Programming mode.)
— To exit the Station Programming mode: Press [PROGRAM].
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Conditions
•You cannot enter non-existent extension or a floating directory number.
Please refer to "Floating Station" of Section "1.3 System Features" in the Features Guide.
*1
Programming Guide References
•3.3 Extension Group
– FDN
– Group Type
•5.10 VPS Integration
*1
A Floating Directory Number (FDN) is a virtual extension number which appears to be an extension.
User Manual81
Page 82
Station Programming
2.2.4Full One-Touch Dialing Assignment
Allows you to enable or disable the "Full One-Touch Dialing" function. The "Hands-free
Operation" mode is activated by pressing a One-Touch Dialing button, DSS button, REDIAL
button or SAVE button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
or
3
Dial 3.
• The STORE indicator light turns off.
<PT Display Example>
1
Dial 1 or 2.
1 : to select the off mode
2 : to select the on mode
Hands-free:Off
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "On."
AUTO DIAL
2
STORE
Press STORE.
• The STORE indicator lights.
• The display shows the initial programming mode.
(–When disabled)
82User Manual
Page 83
2.2.5Handset / Headset Selection
Allows you to select the handset mode or headset mode.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
9
Dial 9.
The display shows the
current status.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "Handset."
or
1
Dial 1 or 2.
1 : to select Handset mode
2 : to select Headset mode
2
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
User Manual83
Page 84
Station Programming
2.2.6Initial Display Selection
Allows you to select the initial display, Caller ID, CO line name or DID name which is shown
on the display when a call is received.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
8
The display shows the
current display type.
11
Dial 81.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "Caller ID" mode.
or
2
Dial 1, 2 or 3.
1 : for the Caller ID
2 : for the CO line name
3 : for the DID name
AUTO DIAL
or
3
The STORE indicator lights.
The display shows the initial programming mode.
STORE
Press STORE.
84User Manual
Page 85
2.2.7Intercom Alert Assignment
Allows you to select the alert mode (tone / voice) when receiving an intercom (extension) call.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
or
14
Dial 4.
<PT Display Example>
When Ring-Calling (Tone Call) mode is selected;
Dial 1 or 2.
1 : to select the Ring-Calling (Tone Call) mode
2 : to select the Voice-Calling mode
2
The STORE indicator lights.
The display shows the initial programming mode.
AUTO DIAL
STORE
Press STORE.
Tone Call
When Voice-Calling mode is selected;
Voice Call
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "Ring-Calling (Tone Call)."
User Manual85
Page 86
Station Programming
2.2.8Live Call Screening (LCS) Mode Set
Assigns whether the recording message is monitored through the built-in speaker (Hands-free
mode) or an alert tone is sent (Private mode) while incoming callers are leaving a message in
the called extension's mailbox.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
7
Dial 7.
Dial 1 or 2.
1 : for the Hands-free
2 : for the Private mode
or
1
2
<PT Display Example>
When the Hands-free mode is selected;
Hands-free
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming mode.
*1
When the Private mode is selected;
Private
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is "Hands-free" mode.
*1
Available when the Digital Super Hybrid System is connected to a Digital Proprietary Telephone capable Panasonic Voice
Processing System (one that supports Digital Proprietary Telephone [DPT] integration; e.g., KX-TVS100).
86User Manual
Page 87
2.2.9PDN/SDN Button Delayed Ringing Assignment
Allows you to assign a delayed ringing function on the PDN/SDN button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Station Programming
(PDN)(SDN)
Press PDN or SDN
you wish to assign the
delayed ringing function.
or
7
<PT Display Example>
Dial 76.
delayed ringing type no.
6
Enter the delayed ringing type
number (0 through 4).
-0: Immediate Ring
-1: 1-ring Delay
-2: 3-ring Delay
-3: 6-ring Delay
-4: No Ring
Immediate Ring
<PT Display Example>
1-ring Delay
If you want to change the delayed ringing type, enter another
type number again.
— To exit the Station Programming mode: Press [PROGRAM].
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Conditions
•If more than one PDN button is assigned on a PT, Delayed Ringing can be set to the first
PDN button (assigned to the CO 01) only. This Delayed Ringing setting applies to all PDN
buttons on the same PT.
User Manual87
Page 88
Station Programming
2.2.10Phantom Button Ringing On/Off Assignment
Allows you to assign a ringing On/Off function on a Phantom button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
(Phantom)
Press Phantom you
wish to turn On/Off the
ringing.
— To exit the Station Programming mode: Press [PROGRAM].
Press the same Phantom
again.
The display shows
the current status.
<PT Display Example>
Ring On
or
1
Dial 1or 2.
-1: Ring Off
-2: Ring On
AUTO DIAL
2
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
88User Manual
Page 89
2.2.11Preferred Line Assignment — Incoming
Allows you to select the method used to answer incoming calls from the following three line
preferences:
a) No Line Preference
b) Ringing Line Preference (— default)
c) Prime Line Preference
Follow the corresponding programming procedure according to your selection.
Station Programming
User Manual89
Page 90
Station Programming
No Line Preference — Incoming (Assignment)
No line is selected when you go off-hook to answer a call. You must select a line to answer an
incoming call.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
2
Dial 2.
1
Dial 1.
AUTO DIAL
STORE
Press STORE.
The display shows the current
status.
<PT Display Example>
Pref.In :No
— To exit the Station Programming mode: Press [PROGRAM].
Ringing Line Preference — Incoming (Assignment)
You are connected to a call ringing on your extension automatically, when you go off-hook to
answer a call.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
AUTO DIAL
22
STORE
Dial 2.
Dial 2.
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
The display shows the current
status.
The STORE indicator lights.
The display shows the initial
programming mode.
<PT Display Example>
Pref.In :Ring
— To exit the Station Programming mode: Press [PROGRAM].
90User Manual
Page 91
Prime Line Preference — Incoming (Assignment)
You are connected to a call on the line assigned as the prime line automatically, when you go
off-hook to answer a call.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
32
Dial 3.Dial 2.
The display shows the current status.
<PT Display Example>
Pref.In :ICM
( When ICM is selected)
Press the desired line access
button.
(Selection)
ICM, S-CO, G-CO, L-CO, PDN, SDN
Station Programming
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Note
•If your PT is DN type, then you cannot select "ICM."
User Manual91
Page 92
Station Programming
2.2.12Preferred Line Assignment — Outgoing
Allows you to select the desired outgoing line preference to originate calls from the following
three line preferences:
a) No Line Preference
b) Idle Line Preference
c) Prime Line Preference (INTERCOM) (— default
Follow the programming procedure according to your selection.
Note
•If "Idle Line Preference," "No Line Preference" or "Prime Line Preference (S-CO, G-
CO or L-CO)" is selected, it is not possible to access any PT features after going offhook. To access these PT features, press the INTERCOM (ICM type PT) or PDN (DN
type PT) button before or after going off-hook.
No Line Preference — Outgoing (Assignment)
When you go off-hook to make a call, you are not connected to any line. You must choose the
line.
*1
)
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
AUTO DIAL
11
STORE
Dial 1.
The display shows the current
status.
<PT Display Example>
Dial 1.
Pref.Out:No
— To exit the Station Programming mode: Press [PROGRAM].
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
*1
If PT is DN type, then the default is PDN.
92User Manual
Page 93
Idle Line Preference — Outgoing (Assignment)
When you go off-hook to make a call, you are connected to an idle line automatically.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
1
Dial 1.
The display shows the current
status.
2
Dial 2.
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
<PT Display Example>
Pref.Out:Idle
— To exit the Station Programming mode: Press [PROGRAM].
User Manual93
Page 94
Station Programming
Prime Line Preference — Outgoing (Assignment)
When you go off-hook to make a call, you are connected to a line assigned as the prime line
automatically.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
1
The display shows the current status.
<PT Display Example>
Pref.Out:ICM
3
Dial 3.Dial 1.
( When ICM is selected)
Press the desired line access
button.
(Selection)
ICM, S-CO, G-CO, L-CO, PDN, SDN
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
Note
•If your PT is DN type, then you cannot select "ICM."
94User Manual
Page 95
2.2.13Ringing Tone Selection for CO Buttons
Allows you to assign a ringer frequency to each CO (S-CO, G-CO, L-CO) or DN (PDN, SDN)
button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
DPT
Station Programming
Press CO, PDN or SDN
which you wish to
change the ringing tone.
The display shows the current
status.
The display shows the selected tone type number and you hear
the selected tone until the STORE button is pressed.
<DPT Display Example>
If you want to change the tone type, enter another tone type
number.
— To exit the Station Programming mode: Press [PROGRAM].
Press the same CO,PDN
or SDN again.
Tone Type-X
tone type no.
Enter the tone type number
(1 through 8).
(-x:tone type number)
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Conditions
•The default is Ringing Tone Type 2.
•This feature applies to the following line access buttons:
S-CO, G-CO, L-CO, PDN, SDN
User Manual95
Page 96
Station Programming
2.2.14Ringing Tone Selection for INTERCOM Button
Allows you to assign a ringer frequency to the INTERCOM button.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
DPT
INTERCOMINTERCOM
Press INTERCOM.
The display shows the current
status
The display shows the selected tone type number and you hear
the selected tone until the STORE button is pressed.
<DPT Display Example>
If you want to change the tone type, enter another tone type
number.
— To exit the Station Programming mode: Press [PROGRAM].
Conditions
•The default is Ringing Tone Type 3.
Press INTERCOM again.
Tone Type-X
tone type no.
Enter the tone type number
(1 through 8).
(-x:tone type number)
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
96User Manual
Page 97
2.2.15Self-Extension Number Confirmation
Allows you to display your extension port physical number and extension number.
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
Station Programming
PT
<PT Display Example>
10101<=>EXT1001
extension port
physical number
— To exit the Station Programming mode: Press [PROGRAM].
6
Dial 6.
HOLD
Press HOLD (END).
• The display shows the initial programming
mode.
User Manual97
Page 98
Station Programming
2.2.16Station Programming Data Default Set
Allows you to return each of the following items assigned by Station Programming to their
default settings.
a) Bilingual Display Selection (default: English)
b) Call Waiting Tone Type Assignment (default: Tone 1)
c) Full One-Touch Dialing Assignment (default: On)
d) Handset/Headset Selection (default: Handset)
e) Initial Display Selection (default: Caller ID)
f) Intercom Alert Assignment (default: Tone Call)
g) Live Call Screen Mode Set (default: Hands-free)
h) Preferred Line Preference — Incoming (default: Ringing Line)
i) Preferred Line Preference — Outgoing (default: INTERCOM Line)
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
PT
Dial #.
<PT Display Example>
Clear Ready?
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial programming
mode.
— To exit the Station Programming mode: Press [PROGRAM].
Allows you to assign frequently dialed numbers and names to each Function button on your PT.
For KX-T7235 and KX-T7436 users
To store a number
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
7235/7436
F1
F2
F3
F4
PT-PGM Mode
F5
Press Function (F1-F10).
F6
F7
F8
F9
F10
Enter the desired number
(extension number,
phone number, etc.).
The STORE indicator light turns off.
The display shows the current status.
(If nothing is stored, “Not Stored” is displayed.)
<PT Display Example>
9-123-4567
CLR NEXT
(– Outside number, 123-4567,
is now programmed.)
desired number
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
Up to 24 digits, consisting of 0 through 9, , #, FLASH, PAUSE, INTERCOM,
(“[” or “]” : secret) and CONF (-:hyphen), can be stored.
To store the telephone number of an outside party, the line access code (9 or 801
through 848) must be stored as the leading digit.
To erase the line, press the CLR (S2) button.
To store a name, press the NEXT(S3) button and go to step 3 in “To store a name”
as described in the following procedure.
— To exit the Station Programming mode: Press [PROGRAM].
User Manual99
Page 100
Station Programming
To store a name
— Be sure that you are in the Station Programming mode: Press [PROGRAM] [9] [9].
7235/7436
F1
F2
F3
F4
PT-PGM Mode
F5
Press Function (F1-F10).Press NEXT (S3).
The STORE indicator light turns off.
The display shows the current status.
F6
F7
F8
F9
F10
S 1
S 2
The display shows the current status.
(If nothing is stored, "Not Stored" is displayed.)
<PT Display Example>
Bob Graham
desired name
Enter the name.*
NEXT
S 3
CLRNEXT
-
Name is now
(
programmed.)
AUTO DIAL
STORE
Press STORE.
The STORE indicator lights.
The display shows the initial
programming mode.
— To exit the Station Programming mode: Press [PROGRAM].
* Please refer to "Combination Table 1" and "Combination Table 2" in Section
"2.2.17Station Speed Dialing Number/Name Assignment [KX-T7235/KX-T7431/KXT7433/KX-T7436 only]" for information on how to enter each character.
Conditions
•Up to 10 characters can be stored.
100User Manual
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
